INFINITY™ 35-6/55-6

SERIES ROTORS

With the industry’s largest selection of high performance nozzles and Trujectory™ adjustment the New INFINTY
35-6/55-6 Series with SMART ACCESS® allows you to put water precisely where you want it for maximum
distribution uniformity. And the part/full circle drive allows you to simply and economically adjust the area
of coverage to match your seasonal watering needs or meet water rationing mandates in seconds with no
disassembly or additional parts required.

Features & Benefits

Industry’s Largest Nozzle Selection

Nozzles from 42’ to 100’ radius plus a wide assortment
of back nozzles lets you put the precise amount of water
exactly where you need it. All nozzles threaded in from
the front.

Hot Spot Watering

Nozzle base can be turned in either direction and held
to put down as much water as needed, precisely where
you want it. Standard on all Toro Part circle Golf rotors!

Adjustment With No Disassembly

A Toro original, simply pull up the riser and ratchet it
to the precise position you want to water.

True Part and Full-Circle in One – (40° - 330° part circle)

These sprinklers can be full circle today and part circle
tomorrow allowing you to simply and economically
adjust the area of coverage to match your seasonal
needs or meet water rationing mandates.

SMART ACCESS

Provides top accessibility to all critical components.

• No digging or unsightly turf repair scars

• No buried wire splices or ground faults

• Pilot valve removable with water “ON”

• Lower long term cost of ownership

• Customizable marker

• Replaceable cover if damaged

• Increased labor efficiency

INFINITY™ 35-6/55-6 SERIES ROTORS

B

C

INF35-6 Trajectory Performance

Nozzle/PSI/GPM #31 Nozzle @ 65 psi, 15.5 GPM #32 Nozzle @ 65 psi, 20.5 GPM #33 Nozzle @ 65 psi, 22.9 GPM

Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°

"A" Radius 46' 46' 50' 53' 54' 50' 46' 49' 51' 55' 63' 54' 54' 56' 59' 62' 66' 61'

"B" Spray Height 4' 4' 5' 8' 11' 13' 3' 4' 6' 9' 12' 15' 4' 5' 7' 9' 13' 15'

"C" Distance from Head 25' 25' 26' 33' 33' 33' 20' 24' 28' 34' 34' 34' 23' 28' 32' 34' 35' 35'

Nozzle/PSI/GPM #34 Nozzle @ 65 psi, 30.0 GPM #35 Nozzle @ 65 psi, 32.4 GPM #36 Nozzle @ 80 psi, 34.0 GPM

Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°

"A" Radius 58' 60' 63' 67' 74' 70' 59' 61' 64' 70' 76' 74' 64' 68' 76' 80' 84' 82'

"B" Spray Height 4' 4' 6' 11' 14' 17' 4' 5' 7' 11' 15' 17' 5' 7' 9' 14' 17' 22'

"C" Distance from Head 24' 26' 35' 39' 39' 39' 30' 32' 36' 43' 43' 43' 25' 38' 40' 45' 49' 45'

A

Nozzle/PSI/GPM #37 Nozzle @ 80 psi, 39.8 GPM

Trajectory 7° 10° 15° 20° 25° 30°

"A" Radius 65' 69' 78' 82' 86' 84'

"B" Spray Height 5' 7' 9' 14' 18' 22'

"C" Distance from Head 30' 39' 41' 46' 50' 46'

INF55-6 Trajectory Performance

Nozzle/PSI/GPM #51 Nozzle @65 psi, 15.7 GPM #52 Nozzle @65 psi, 20.8 GPM #53 Nozzle @65 psi, 23.4 GPM

Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°

"A" Radius 46' 46' 51' 53' 54' 50' 49' 50' 51' 55' 64' 65' 54' 56' 59' 62' 68' 61'

"B" Spray Height 4' 4' 6' 10' 13' 15' 4' 4' 6' 9' 11' 13' 5' 6' 7' 9' 13' 15'

"C" Distance from Head 26' 27' 32' 38' 40' 41' 22' 26' 31' 35' 34' 30' 30' 33' 32' 35' 37' 37'

Nozzle/PSI/GPM #54 Nozzle @ 65 psi, 31.2 GPM #55 Nozzle @ 65 psi, 33.8 GPM #56 Nozzle @ 80 psi, 35.7 GPM

Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°

"A" Radius 58' 60' 63' 67' 74' 70' 59' 62' 66' 70' 76' 77' 72' 73' 75' 82' 85' 82'

"B" Spray Height 5' 6' 8' 10' 15' 17' 6' 6' 9' 11' 15' 17' 5' 7' 9' 14' 17' 22'

"C" Distance from Head 31' 34' 40' 41' 41' 42' 34' 36' 43' 45' 45' 45' 25' 38' 40' 45' 49' 45'

Nozzle/PSI/GPM #57 Nozzle @ 80 psi, 41.9 GPM #58 Nozzle @ 80 psi, 46.2 GPM #59 Nozzle @ 80 psi, 53.3 GPM

Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°

"A" Radius 72' 74' 77' 83' 89' 85' 75' 77' 83' 87' 92' 88' 77' 78' 84' 89' 96' 92'

"B" Spray Height 5' 7' 9' 14' 18' 22' 6' 7' 10' 15' 18' 22' 7' 8' 11' 16' 21' 25'

"C" Distance from Head 30' 39' 41' 46' 50' 46' 38' 40' 43' 47' 52' 48' 42' 44' 45' 47' 53' 49'

Information is for reference only. Actual results may vary.
