Toro 51847T Operator's Manual

FormNo.3443-540RevB
Flex-ForcePowerSystem PoleSaw
ModelNo.51847T—SerialNo.321000001andUp
60V
Registeratwww.T oro.com. OriginalInstructions(EN)
Forassistance,pleasesee www.Toro.com/support forinstructionalvideosor contactyourAuthorized ServiceDealerbefore returningthisproduct.
Introduction
Thispolesawisdesignedfortrimmingsmallbranches andlimbsupto6inches(15.2cm)indiameter.Itis tobeusedonlybyadults.ItisdesignedtouseToro Flex-Forcelithium-ionbatterypackModel81820, 81825,81850,81860,or81875.Thesebatterypacks aredesignedtobechargedonlybybatterycharger Models81801,81101,81802,or81805.Usingthese productsforpurposesotherthantheirintendeduse couldprovedangeroustoyouandbystanders.
Important:Withyourmobiledevice,youcan
scantheQRcode(ifequipped)ontheserial numberplatetoaccesswarranty ,parts,andother productinformation.
g374224
Figure1
1.Modelandserialnumberlocation.
Important:Ifyouareusingthismachinewith
batterypackModels81850,81860,or81875,you mustinstalltheincludedquick-releaseharness forpropersupportandbalance.
Donotuseotherharnessesormultipleharnesses whenoperatingthemachine.
Readthisinformationcarefullytolearnhowtooperate andmaintainyourproductproperlyandtoavoid injuryandproductdamage.Youareresponsiblefor operatingtheproductproperlyandsafely .
Visitwww.Toro.comformoreinformation,including safetytips,trainingmaterials,accessoryinformation, helpndingadealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,or additionalinformation,contactanAuthorizedService DealerorToroCustomerServiceandhavethemodel andserialnumbersofyourproductready.Figure1 identiesthelocationofthemodelandserialnumbers ontheproduct.Writethenumbersinthespace provided.
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas safetymessagesidentiedbythesafety-alertsymbol (Figure2),whichsignalsahazardthatmaycause seriousinjuryordeathifyoudonotfollowthe recommendedprecautions.
sa-black
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation. Importantcallsattentiontospecialmechanical informationandNoteemphasizesgeneralinformation worthyofspecialattention.
©2022—TheToro®Company 8111LyndaleAvenueSouth Bloomington,MN55420
Contactusatwww.Toro.com.
2
PrintedinChina
AllRightsReserved
Contents
Safety.......................................................................3
SafetyandInstructionalDecals..........................7
Setup........................................................................8
InstallingtheBarandChain................................8
AssemblingthePoleSaw...................................9
AddingBarandChainOiltothePole
Saw...............................................................10
InstallingtheHarness........................................11
ProductOverview....................................................11
Specications..................................................12
Operation................................................................13
BeforeUsingthePoleSaw...............................13
StartingthePoleSaw.......................................13
ShuttingOffthePoleSaw.................................13
CuttingwiththePoleSaw.................................14
PruningaTree..................................................15
RemovingtheBatteryPack..............................15
Maintenance...........................................................16
RecommendedMaintenanceSchedule(s)...........16
CheckingtheOilLevelandAddingBarand
ChainOil.......................................................16
CheckingtheFlowofBarandChain
Oil.................................................................17
AdjustingtheChainT ension.............................17
ServicingtheGuideBar,Chain,andDrive
Sprocket........................................................19
InstallingtheGuideBarandChain....................20
SharpeningtheChain.......................................20
Service.............................................................20
Storage...................................................................21
Troubleshooting......................................................22
Safety
WARNING
Readallsafetywarnings,instructions, illustrationsandspecicationsprovidedwith thispowertool.
Failuretofollowallinstructionslistedbelow mayresultinelectricshock,reand/or seriousinjury.
Saveallwarningsandinstructionsforfuture reference.
Theterm“powertool”inallthewarningsrefers toyourmains-operated(corded)powertoolor battery-operated(cordless)powertool.
IMPORTANTSAFETY INSTRUCTIONS
I.Workareasafety
1.Keepworkareacleanandwelllit.Cluttered
ordarkareasinviteaccidents.
2.Donotoperatepowertoolsinexplosive atmospheres,suchasinthepresenceof ammableliquids,gasses,ordust.Power
toolscreatesparkswhichmayignitethedust orfumes.
3.Keepchildrenandbystandersawaywhile operatingapowertool.Distractionscancause
youtolosecontrol.
II.Electricalsafety
1.Powertoolplugsmustmatchtheoutlet. Nevermodifythepluginanyway.Donotuse anyadapterplugswithearthed(grounded) powertools.Unmodiedplugsandmatching
outletswillreduceriskofelectricshock.
2.Avoidbodycontactwithearthedorgrounded surfaces,suchaspipes,radiators,ranges andrefrigerators.Thereisanincreasedrisk
ofelectricshockifyourbodyisearthedor grounded.
3.Donotexposepowertoolstorainorwet conditions.Waterenteringapowertoolwill
increasetheriskofelectricshock.
4.Donotabusethecord.Neverusethecord forcarrying,pullingorunpluggingthepower tool.Keepcordawayfromheat,oil,sharp edgesormovingparts.Damagedorentangled
cordsincreasetheriskofelectricshock.
5.Whenoperatingapowertooloutdoors,use anextensioncordsuitableforoutdooruse.
3
Useofacordsuitableforoutdoorusereduces theriskofelectricshock.
6.Ifoperatingapowertoolinadamplocation isunavoidable,usearesidualcurrentdevice (RCD)protectedsupply.UseofanRCD
reducestheriskofelectricshock.
III.Personalsafety
1.Stayalert,watchwhatyouaredoinganduse commonsensewhenoperatingapowertool. Donotuseapowertoolwhileyouaretired orundertheinuenceofdrugs,alcohol,or medication.Amomentofinattentionwhile
operatingpowertoolsmayresultinserious personalinjury.
2.Usepersonalprotectiveequipment.Always weareyeprotection.Protectiveequipment
suchasdustmask,non-skidsafetyshoes,hard hat,orhearingprotectionusedforappropriate conditionsreducespersonalinjuries.
3.Preventunintentionalstarting.Ensure theswitchisintheOFF-positionbefore connectingtopowersourceand/orbattery pack,pickinguporcarryingthetool.Carrying
powertoolswithyourngerontheswitchor energizingpowertoolsthathavetheswitchon invitesaccidents.
4.Removeanyadjustingkeyorwrenchbefore turningthepowertoolon.Awrenchorakey
leftattachedtoarotatingpartofthepowertool mayresultinpersonalinjury.
5.Donotoverreach.Keepproperfootingand balanceatalltimes.Thisenablesbettercontrol
ofthepowertoolinunexpectedsituations.
6.Dressproperly.Donotwearlooseclothing orjewelry .Keepyourhair,clothing,and glovesawayfrommovingparts.Loose
clothes,jewelry,orlonghaircanbecaughtin movingparts.
7.Ifdevicesareprovidedfortheconnection ofdustextractionandcollectionfacilities, ensuretheseareconnectedandproperly used.Useofdustcollectioncanreduce
dust-relatedhazards.
8.Donotletfamiliaritygainedfromfrequent useoftoolsallowyoutobecomecomplacent andignoretoolsafetyprinciples.Acareless
actioncancausesevereinjurywithinafraction ofasecond.
9.Donotallowchildrenoruntrainedpeopleto operateorservicethisdevice.Allowonly peoplewhoareresponsible,trained,familiar withtheinstructions,andphysicallycapable tooperateorservicethedevice.
IV.Powertooluseandcare
1.Donotforcethepowertool.Usethecorrect powertoolforyourapplication.Thecorrect
powertoolwilldothejobbetterandsaferatthe rateforwhichitwasdesigned.
2.Donotusethepowertooliftheswitch doesnotturnitonandoff.Anypowertool
thatcannotbecontrolledwiththeswitchis dangerousandmustberepaired.
3.Disconnecttheplugfromthepowersource and/orremovethebatterypack,ifdetachable, fromthepowertoolbeforemakingany adjustments,changingaccessories,or storingpowertools.Suchpreventivesafety
measuresreducetheriskofstartingthepower toolaccidentally.
4.Storeidlepowertoolsindoors,outofthe reachofchildren,anddonotallowpersons unfamiliarwiththepowertoolorthese instructionstooperatethepowertool.Power
toolsaredangerousinthehandsofuntrained users.
5.Maintainpowertoolsandaccessories. Checkformisalignmentorbindingofmoving parts,breakageofparts,andanyother conditionthatmayaffectthepowertool’s operation.Ifdamaged,havethepowertool repairedbeforeuse.Manyaccidentsare
causedbypoorlymaintainedpowertools.
6.Keepcuttingtoolssharpandclean.Properly maintainedcuttingtoolswithsharpcuttingedges arelesslikelytobindandareeasiertocontrol.
7.Usethepowertool,accessories,andtoolbits etc.inaccordancewiththeseinstructions, takingintoaccounttheworkingconditions andtheworktobeperformed.Useofthe
powertoolforoperationsdifferentfromthose intendedcouldresultinahazardoussituation.
8.Keephandlesandgraspingsurfacesdry, cleanandfreefromoilandgrease.Slippery
handlesandgraspingsurfacesdonotallow forsafehandlingandcontrolofthetoolin unexpectedsituations.
V.Batterytooluseandcare
1.Rechargeonlywiththechargerspeciedby themanufacturer.Achargerthatissuitablefor
onetypeofbatterypackmaycreateariskofre whenusedwithanotherbatterypack.
2.Usepowertoolsonlywithspecically designatedbatterypacks.Useofanyother
batterypacksmaycreateariskofinjuryandre.
3.Whenbatterypackisnotinuse,keepitaway fromothermetalobjects,likepaperclips, coins,keys,nails,screwsorothersmall metalobjects,thatcanmakeaconnection
4
fromoneterminaltoanother.Shortingthe batteryterminalstogethermaycauseburnsor are.
4.Underabusiveconditions,liquidmaybe ejectedfromthebattery;avoidcontact.If contactaccidentallyoccurs,ushwithwater. Ifliquidcontactseyes,additionallyseek medicalhelp.Liquidejectedfromthebattery
maycauseirritationorburns.
5.Donotuseabatterypackortoolthatis damagedormodied.Damagedormodied
batteriesmayexhibitunpredictablebehavior resultinginre,explosionorriskofinjury.
6.Donotexposeabatterypackortooltore orexcessivetemperature.Exposuretoreor
temperatureabove100°C(212°F)maycause explosion.
7.Followallcharginginstructionsanddo notchargethebatterypackortooloutside thetemperaturerangespeciedinthe instructions.Chargingimproperlyorat
temperaturesoutsidethespeciedrangemay damagethebatteryandincreasetheriskofre.
8.Donotexposeabatterypackortooltorain orwetconditions.Waterenteringapowertool
willincreasetheriskofelectricshock.
9.CAUTION—Amistreatedbatterypackmay presentariskofreorchemicalburn.Donot
disassemblethebatterypack.Donotheatthe batterypackabove68°C(154°F)orincinerate it.ReplacethebatterypackwithagenuineToro batterypackonly;usinganothertypeofbattery packmaycauseareorexplosion.Keep batterypacksoutofthereachofchildrenand intheoriginalpackaginguntilyouarereadyto usethem.
VI.Service
1.Haveyourpowertoolservicedbya qualiedrepairpersonusingonlyidentical replacementparts.Thiswillensurethatthe
safetyofthepowertoolismaintained.
2.Neverservicedamagedbatterypacks.
Serviceofbatterypacksshouldonlybe performedbythemanufacturerorauthorized serviceproviders.
VII.Polesawsafety
1.Keepallpartsofthebodyawayfromthe sawchain.Donotremovecutmaterialor holdmaterialtobecutwhenthesawchain ismoving.Makesuretheswitchisoffand thebatterydisconnectedwhenclearing jammedmaterial.Sawchaincontinuesto moveaftertheswitchisturnedoff.Before youstartthepolesaw,makesurethesaw
chainisnotcontactinganything.Amoment
ofinattentionwhileoperatingpolesawsmay causeentanglementofyourclothingorbody withthesawchain.
2.Carrythepolesawbythehandlewiththe sawchainstopped.Whentransportingor storingthepolesaw,alwaystthesawchain devicecover.Properhandlingofthepolesaw
willreducepossiblepersonalinjuryfromthesaw chain.
3.Holdthepowertoolbyinsulatedgripping surfacesonly,becausethesawchainmay contacthiddenwiring.Sawchainsorblades
contactinga″live″wiremaymakeexposed metalpartsofthepowertool″live″andcould givetheoperatoranelectricshock.
4.Donotusethepolesawinbadweather conditions,especiallywhenthereisarisk oflightning.Thisdecreasestheriskofbeing
struckbylightning.
5.Toreducetheriskofelectrocution,never usenearanyelectricalpowerlines.Contact
withorusenearpowerlinesmaycauseserious injuryorelectricshockresultingindeath.
6.Alwaysusetwohandswhenoperatingthe polesaw.Holdthepolesawwithbothhands
toavoidlossofcontrol.
7.Alwaysuseheadprotectionwhenoperating thepolesawoverhead.Fallingdebriscan
resultinseriouspersonalinjury .
8.Dressproperly—Wearappropriateclothing, includingeyeprotection;longpants; substantial,slip-resistantfootwear;gloves; andhearingprotection.Tiebacklonghair anddonotwearloosejewelrythatcanget caughtinmovingparts.Useafacemask industyoperatingconditions.Adequate
protectiveclothingwillreducepersonalinjuryby yingdebrisoraccidentalcontactwiththesaw chain.
9.Donotoperateapolesawinatree,on aladder,fromarooftop,oranyunstable support.Operationofapolesawinthismanner
couldresultinseriouspersonalinjury .
10.Alwayskeepproperfootingandoperate thepolesawonlywhenstandingonxed, secureandlevelsurface.Slipperyorunstable
surfacessuchasladdersmaycausealossof balanceorcontrolofthepolesaw.
11.Whencuttingalimbthatisundertensionbe alertforspringback.Whenthetensioninthe
woodbersisreleased,thespringloadedlimb maystriketheoperatorand/orthrowthepole sawoutofcontrol.
5
12.Useextremecautionwhencuttingbrushand
saplings.Theslendermaterialmaycatchthe sawchainandbewhippedtowardyouorpull youoffbalance.
13.Carrythepolesawwithbothhands,thepole sawswitchedoffandawayfromyourbody . Whentransportingorstoringthepolesaw, alwaysttheguidebarcover.Properhandling
ofthepolesawwillreducethelikelihoodof accidentalcontactwiththemovingsawchain.
14.Followinstructionsforlubricating,chain tensioning,changingthebarandchain.
Improperlytensionedorlubricatedchainmay eitherbreakorincreasethechanceforkickback.
15.Cutwoodonly.Donotusepolesawfor purposesnotintended.Forexample:do notusepolesawforcuttingmetal,plastic, masonryornon-woodbuildingmaterials.
Useofthepolesawforoperationsdifferentthan intendedcouldresultinahazardoussituation.
16.Keephandlesdry,clean,andfreefromoil andgrease.Greasy ,oilyhandlesareslippery
causinglossofcontrol.
whileclearingjammedmaterialorservicingmay resultinseriouspersonalinjury .
20.Onlyusereplacementbarsandchains speciedbythemanufacturer.Incorrect
replacementbarsandchainsmaycausechain breakageand/orkickback.
21.Followthemanufacturer’ssharpeningand maintenanceinstructionsforthesawchain.
Decreasingthedepthgaugeheightcanleadto increasedkickback..
SAVETHESE INSTRUCTIONS
17.Avoidkickback.Kickbackmayoccurwhenthe
noseortipoftheguidebartouchesanobject,or whenthewoodclosesinandpinchesthesaw chaininthecut.
Tipcontactinsomecasesmaycauseasudden reversereaction,kickingtheguidebarupand backtowardyou.
Pinchingthesawchainalongthetopofthe guidebarmaypushtheguidebarrapidlyback towardyou.
Eitherofthesereactionsmaycauseyoutolose controlofthesaw,whichcouldresultinserious personalinjury.Donotrelyexclusivelyuponthe safetydevicesbuiltintoyoursaw.Asapolesaw user,youshouldtakeseveralstepstokeepyour cuttingjobsfreefromaccidentorinjury.
Kickbackistheresultoftoolmisuseand/or incorrectoperatingproceduresorconditionsand canbeavoidedbytakingproperprecautionsas givenbelow:
18.Maintainarmgrip,withthumbsandngers encirclingthepolesawhandles,withboth handsonthehandleandpositionyourbody andarmtoallowyoutoresistkickback forces.Kickbackforcescanbecontrolledby
theoperator,ifproperprecautionsaretaken.Do notletgoofthepolesaw.
19.Whenclearingjammedmaterial,storingor servicingthepole-mountedpruner,make suretheswitchisoffandthebatterypackis removed.Unexpectedactuationofthemachine
6
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
139-5348
1.Donotdisposeimproperly.
decal139-5348
139-5345
1.Warning—readtheOperator’sManual;wearhearing protection;weareyeprotection;wearahardhat,wear gloves,wearsubstantialslip-resistantshoes,donotexpose torain;Caution—Cutting/dismembermenthazardofhands; entanglementhazard—stayawayfrommovingparts; keepbystandersawayduringoperation;Electricalshock hazard—keepawayfrompowerlines.
decal139-5345
7
Setup
InstallingtheBarandChain
DANGER
Contactwiththepolesawteethcancauseseriouspersonalinjury.
Removethebatterypackbeforeadjustingormaintainingthepolesaw.
Alwaysweargloveswhenadjustingormaintainingthepolesaw.
1.Placethepolesawonaatsurfaceanddonotinstallthebatterypack.
2.Removethesidecover;turnthebarcoverknobcounterclockwiseuntiltheknobisremovedandthen
removethesidecover(Figure3).
Figure3
1.Barcoverknob
2.Sidecover6.Guidebar10.Chainadjustingstud
3.Chain
4.Chainadjustingstudslot8.Guidebarstud
3.Placethechainaroundthesprocketonthefrontendoftheguidebar,withthecuttingedgeofthechain
teethonthetopofthebarfacingforwardasshowninthediagrambeneaththesidecoverofthepolesaw.
4.Continuetofeedthechainaroundtheguidebarandalignthechainintothegrooveoftheguidebar.
5.Positiontheopenloopofthechain(thesidenotontheguidebar)aroundthedrivesprocketonthepole
saw(Figure3).
5.Guidebarslot9.Oiloutlet
7.Drivesprocket
Important:Ensurethatthechainadjustingstudisinsertedintothechainadjustingstudslot
ontheguidebar(Figure3). Youmayneedtorotatethechain-tensioningscrewtotthestudintotheslotontheguidebar
(Figure18).
6.Installthesidecoverandbarcoverknobandlooselytightenthesidecoverbyturningtheknobclockwise.
7.Adjustthechaintension;refertoAdjustingtheChainT ension(page17).
g374226
8
AssemblingthePoleSaw
1.Unfoldthesectionsofthehandle(Figure4).
g374227
Figure4
1.Handlepolesection
2.Middlepolesection
3.Sawpolesection
2.Alignthelockingbuttononthemiddlepolesectionwiththeslottedholeattheendofthehandlepole
sectionandslidethe2shaftstogether(Figure5).
Note:Thelockingbuttonclicksintotheslottedholewhentheshaftsaresecured
3.Usetheprovidedwrenchtosecurethese2sectionsofthepoletogether(EofFigure5).
4.Repeatthisproceduretoconnectthesawpolesectiontothemiddlepolesection(Figure5).
9
Figure5
AddingBarandChainOiltothePoleSaw
Important:Useonlybarandchainoil(soldseparately).
Fillthepolesawwithbarandchainoilbeforerstoperation;refertoCheckingtheOilLevelandAdding
BarandChainOil(page16).
10
g374228
InstallingtheHarness
Connectthemetalhookontheshoulderharnessto thestrapcollaronthepolesawhandle(Figure6).
Figure6
1.Strapadjuster3.Strapcollar
2.Metalstraphook
Thestraplengthisadjustable;slidethestrapadjuster uptodecreasethelengthofthestrap,ordownto increasethelengthofthestrap(Figure6).
4.Shoulderstrap
ProductOverview
g374229
g374230
Figure8
1.Buttonlatch6.Barcoverknob
2.Triggerlock
3.Fronthandle
4.Oilcap9.Guidebarandchain
5.Trigger
7.Guidebarcover
8.Cuttingguide
Ifthereiseveranemergencyandyouneedtorapidly removetheharness,disconnectthequick-release buckleasfollows:
1.Pressinonthesidesofthebuckle(AofFigure
7).
2.Allowthebuckletodisconnect(BofFigure7).
Figure7
g340477
11
Specications
Model51847T
BarLength(with88619and 88621equipped)
ChainGauge(with88619 and88621equipped)
ChainPitch(with88619and 88621equipped)
ChainLength(with88619 and88621equipped)
RatedVoltage
Weight(withoutabattery)4.1kg(9lbs)
ChargerType
BatteryType81820,81825,81850,81860,
*Ifyouareusingthismachinewithbatterypack Models81850,81860,or81875,youmustinstallthe includedquick-releaseharness.
25.4cm(10inches)
0.050inches
1/4inch
58links
60VDCmaximum,54VDC nominalusage
81801,81101,81802,or 81805
or81875*
AppropriateTemperatureRanges
Charge/storethebatterypack at
Usethebatterypackat
Usethetoolat
*Chargingtimewillincreaseifyoudonotchargethe batterywithinthisrange.
Storethetool,batterypack,andbatterychargerinan enclosedclean,dryarea.
5°C(41°F)to40°C(104°F)*
-30°C(-22°F)to49°C(120°F)*
0°C(32°F)to49°C(120°F)*
12
Operation
BeforeUsingthePoleSaw
Beforeusingthepolesaw,dothefollowing:
Checkthechaintension;refertoAdjustingthe
ChainT ension(page17).
Cleanthepolesawcomponents,inspectthemfor
excessivewearordamage,andreplacethemas needed;refertoServicingtheGuideBar,Chain,
andDriveSprocket(page19).
Checkthechainforsharpnessanddamage,and
sharpenorreplaceasneeded;refertoSharpening
theChain(page20).
Checktheoillevel;refertoCheckingtheOilLevel
andAddingBarandChainOil(page16).
Checkthepolesawfordamage,general
appearance,andperformance;ensurethatthe switchesmovefreely,theventsandhandlesare clean,andthebarisnotbentordamaged.
g374232
Figure10
4.Pushthebatterypackintothehandleuntilthe batterypacklocksintoplace.
5.Removetheguidebarcoverfromthechain.
6.Pressthetriggerlock,thenpressthetriggerto startthepolesaw.
ShuttingOffthePoleSaw
StartingthePoleSaw
1.Ensurethattheventsonthepolesawarefree fromdustanddebris(Figure9).
Figure9
Toshutoffthepolesaw,releasethetrigger.
Wheneveryouarenotusingthesaworare transportingthesawtoorfromtheworkarearemove thebatterypack;refertoRemovingtheBatteryPack
(page15).
g374231
1.Vents
2.Setthepolesawdownonalevelsurface.
3.Alignthecavityinthebatterypackwiththe tongueonthehandlehousing(Figure10).
13
CuttingwiththePoleSaw
WARNING
Operatingapolesawimproperlycancause seriouspersonalinjuryordeath.
Readandfollowalloperatinginstructions carefullytoavoidpossiblepersonalinjury.
1.Gripthepolesawwith2hands.
2.Standonsolid,evengroundinfrontofthetreeto betrimmedandpositionyourselfforbalanced, stablefootingwhilecutting.
3.Ensurethatyouonlycutthewoodthatyou intendtocut;donotallowthesawchainto contacttheearth,otherlogs,oranyother objectswhencutting.
4.Ensurethatthesawchainisrotatingatfull speedbeforestartingacut.
WARNING
Donotoperatenearelectricalpowerlines;the polesawhasnotbeendesignedtoprovide protectionfromelectricshockintheeventof contactwithoverheadelectriclines,
Consultlocalregulationsforsafedistances fromoverheadelectricpowerlinesandensure thattheoperatingpositionissafeandsecure beforeoperatingthepolesaw.
WARNING
Kickbackcancauseseriousorfatalinjuryto you.
Avoidtouchingobjectstobecutwiththe noseofthepolesawguidebar.
Thereare2typesofkickback:
Afastupwardmotionofthepolesawthatresults
whenthechainatthenoseortopofthebar contactsanobject
Afastbackwardmotionofthepolesawthat
resultswhenthechainatthenoseortopofthebar ispinchedbytheobjectbeingcut
Figure11showstheareaofthebartoavoidcontacting
anobjecttopreventkickback.
5.Cutwiththebranchneartherearoftheguide bar,closetothecuttingguide;pressthesaw chainlightlyagainstthewoodandallowthe weightofthepolesawtodrivethecutting (Figure12).
Important:Ifthechainbindsinthecut,do
notattempttofreeitbyrunningthemotor. Shutoffthepolesaw,removethebattery, andliftthelimbwhileholdingthesaw;this shouldreleasethepinchandfreethepole saw.
g374233
Figure12
1.Cuttingguide
6.Keepsteadypressureonthepolesaw,cutting inastraightline,andreleasepressureonlynear theendofthecut.
1.Kickbackarea(nose,top ofthebar)
7.Releasethetriggerassoonasyoucomplete acut.
g318677
Figure11
2.Nose
14
PruningaTree
WARNING
Cuttinghigherlimbsfromatreeofftheground canputyouinanunstablepositionthatcould beunsafeforyouwhilehandlingapolesaw, resultinginpossibleseriouspersonalinjury ordeathtoyouorbystanders.
Whencuttinglimbsfromastandingtree,use thefollowingpractices:
Donotclimbonlimbsorbrancheswitha polesaw.
Donotoverreach,andcutwithbothhands onthepolesaw.
Ensurethatallbystandersareawayfrom theareawherebranchesmayfall.
1.GripthepolesawasdescribedinCuttingwith
thePoleSaw(page14).
2.Whilecuttingsmallbranches,applylight pressuretothebranchtobecut.
Figure13
1.Firstreliefundercut
2.Secondthroughcut4.Branchcollar(wherethe
3.Finalpruningcutto removethelimbstub
trunktransitionstothe limb)
g316577
3.Whilecuttinglargerbranches,makeashallow undercutandthencompletethecutfromthe topsideofthebranch.
A.Cutfromtheundersideofthelimbabout15
cm(6inches)fromthetrunk.Cutathirdof thewaythroughthelimb.
B.Cut5.0to10.0cm(2to4inches)farther
outonthelimbandfromabove.Cutthe limbuntilitfalls.
C.Cutthelimbstubatthebranchcollar
(Figure13).
Important:Donotcutthelimbpastthe
collar,ushtothetrunk,orleavealarge limbstub;thisdamagesthetree.
RemovingtheBatteryPack
1.Placethepolesawonaatsurface.
2.Pressdownonthelatchbuttonandremovethe batterypackfromthehandle.
g374234
Figure14
1.Latchbutton
15
Maintenance
RecommendedMaintenanceSchedule(s)
MaintenanceService
Interval
Beforeeachuseordaily
Aftereachbatterydrain
cycle
Yearlyorbeforestorage
MaintenanceProcedure
•Checktheoillevelandaddbarandchainoilifnecessary .
•Checkthatoilisowingtothechain.
•Checkthechaintensionandadjustitifnecessary .
•Ensurethatthebarisstraightandundamaged
•Checkthechainforsharpness;contactanAuthorizedServiceDealertohavethe chainsharpenedorreplaced.
•Checktheoillevelandaddbarandchainoilifnecessary .
•Checkthechaintensionandadjustitifnecessary .
•Servicetheguidebar,chain,anddrivesprocket.
•Checkthechainforsharpness;contactanAuthorizedServiceDealertohavethe chainsharpenedorreplaced.
CheckingtheOilLeveland AddingBarandChainOil
ServiceInterval:Beforeeachuseordaily
Aftereachbatterydraincycle
Important:Useonlybarandchainoil(sold
separately).
Important:Donotllthepolesawhigher
thanthebottomofthellneck.
6.Cleanupanyspilledoilandsecuretheoilcap.
7.Ensurethatoilisowingtothechain;referto
CheckingtheFlowofBarandChainOil(page
17).
1.Shutoffthepolesawandremovethebattery pack;refertoRemovingtheBatteryPack(page
15).
2.Checktheoillevelinthewindow.Iftheoildoes notllthewindow,addbarandchainoilas needed(Figure15).
Figure15
1.Oilwindow2.Oilcap
3.Placethepolesawonaatsurfacewiththeoil capfacingup.
4.Cleantheareaaroundtheoilcap(Figure15).
Note:Ensurethatyoudonotallowdebris/wood
chipstoentertheoiltank.
g374235
5.Removethecap,andpourbarandchainoilinto thepolesawuntiltheoilllsthetank(Figure15).
16
CheckingtheFlowofBar
AdjustingtheChain
andChainOil
ServiceInterval:Beforeeachuseordaily
1.Preparetousethepolesaw;refertoBefore
UsingthePoleSaw(page13).
2.T oensurethatoilisowingtothechain,point thenoseofthepolesawafewinchesfroma surface(e.g.paper,cardboard,astump)and runthepolesaw;youshouldbeabletoseea lightsprayofoilonthesurface(Figure16).
Figure16
1.Runthepolesawafew
inchesfromasurface.
3.Ifoilisnotowing,ensurethatthereisoilinthe tankandthattheareaunderthesidecoveris clean;refertoCheckingtheOilLevelandAdding
BarandChainOil(page16)andServicingthe GuideBar,Chain,andDriveSprocket(page19).
2.Iftheoilisowing,itwill sprayoffthechainand accumulate.
Tension
ServiceInterval:Beforeeachuseordaily
Aftereachbatterydraincycle
Ensurethatthechainisproperlytensioned.
Aloosechainshortensthelifeofthedrivesprocket andtheguidebarandmaycausethechaintofalloff.
Anovertightenedchainoverheatstheguidebarand chain,causingrapidwear,andmayburnoutthemotor orbreakthechain.
Thechaintensioniscorrectwhenyouareabletouse aglovedhandtopullthechainsmoothlyaroundthe guidebar.Thechainshouldremainincontactwith thebottomedgeoftheguidebar.
Also,checkthechaintensionofanewchainaftera fewcuts;anewchainusuallystretchesandrequires adjustmentafterafewcuts.
g374236
DANGER
Contactwiththepolesawteethcancause seriouspersonalinjury.
Removethebatterypackbeforeadjusting ormaintainingthepolesaw.
Alwaysweargloveswhenadjustingor maintainingthepolesaw.
17
1.Placethepolesawonalevelsurfaceand removethebatterypack;refertoRemovingthe
BatteryPack(page15).
2.Allowthesawchaintocool.
Important:Donottensionahotchain;it
maycontractasitcools,resultinginan overtightenedchain.
3.Inspecttheguidebarforbendsordamage, replaceifnecessary.
4.Turnthebarcoverknobcounterclockwiseto loosenthebarcover,butdonotremoveit (Figure17).
g374238
Figure18
1.Chaintensioningscrew
Adjustthechaintensionuntilthechaintouches thebottomedgeoftheguidebar,thenpullthe chainawayfromthebottomedgeoftheguide bar;aproperlyadjustedchaincanonlybepulled
3.2to6.4mm(1/8to1/4inch)awayfromthe guidebar,andsnapsbackonrelease.
Figure17
1.Barcoverknob
5.Adjustthechaintensionusingthechain tensioningscrew(Figure18),andthensecure thesidecovertothepolesawbyturningthe barcoverknobclockwisebeforecheckingthe tension(Figure17).
Totightenthechain,turnthechain
tensioningscrewclockwise.
Toloosenthechain,turnthechain
tensioningscrewcounterclockwise.
Note:Whileadjustingthechaintension,liftup
g374237
thetipoftheguidebarwithaglovedhandto ensuretheguidebardoesnotsagandaffect chaintension.
6.Useaglovedhandtopullthechainaroundthe guidebar.Aproperlytensionedchainshould movesmoothlyandremainincontactwiththe bottomedgeoftheguidebar.
7.Ifthechainisnotproperlytensioned,repeat steps4through7.
18
ServicingtheGuideBar, Chain,andDriveSprocket
Yearlyorbeforestorage
8.Cleantheguidebarandchain;useawireora smallat-headscrewdrivertoremovedirtand debrisfromthegroovealongtheedgeofthe guidebar,startingfromthesprocketonthefront endandmovingrearward.
DANGER
Contactwiththepolesawteethcancause seriouspersonalinjury.
Removethebatterypackbeforeadjusting ormaintainingthepolesaw.
Alwaysweargloveswhenadjustingor maintainingthepolesaw.
1.Placethepolesawonaatsurfaceandremove thebatterypack;refertoRemovingtheBattery
Pack(page15).
2.Removethesidecover;turnthebarcoverknob counterclockwiseuntiltheknobisremovedand thenremovethesidecover(Figure19).
Ensurethattheoilchannelinthebarthataligns withtheoiloutletonthepolesawiscleanso thatoilcanowfreelytothechain(Figure20).
Figure20
Internalsectionsoftheguidebarshown
1.Ensurethatthischannel connectingtotheoiloutlet isclean.
2.Ensurethatthebar sprocketiscleanand rotatesfreely.
9.Inspecttheguidebarandchain;ifthebar isbent,thegroovesaredamaged,orifthe sprocketonthefrontenddoesnotrotatefreely, replacetheguidebar;ifthechainisexcessively wornordamaged,replaceit.
10.Installtheguidebarandchain;refertoInstalling
theGuideBarandChain(page20).
g315856
Figure19
1.Barcoverknob
2.Sidecover
3.Chain8.Guidebarstud
4.Chainadjustingstudslot9.Oiloutlet
5.Guidebarslot10.Chainadjustingstud
6.Guidebar
7.Drivesprocket
3.Loosenthechainbyturningthechain-tightening screwcounterclockwise(Figure18).
4.Separatethechainfromtheguidebarandset themaside.
5.Cleananydebrisfromtheareaundertheside cover.
6.Inspectthedrivesprocket;ifitisexcessively wornordamaged,replaceit;contactyour authorizedservicedealer.
11.Ensurethatoilisowingtothechain;referto
CheckingtheFlowofBarandChainOil(page
17).
g374226
7.Checktheoiloutlet(Figure19)fordebrisand cleantheareaifnecessary.
19
InstallingtheGuideBarand
SharpeningtheChain
Chain
DANGER
Contactwiththepolesawteethcancause seriouspersonalinjury.
Removethebatterypackbeforeadjusting ormaintainingthepolesaw.
Alwaysweargloveswhenadjustingor maintainingthepolesaw.
1.Ifthesidecoverisinstalledtothemachine, removeit;refertoServicingtheGuideBar,
Chain,andDriveSprocket(page19).
2.Placethechainaroundthesprocketonthefront endoftheguidebar,withthecuttingedgeof
thechainteethonthetopofthebarfacing forwardasshowninthediagrambeneaththe
sidecoverofthepolesaw.
3.Feedthechainaroundtheguidebarandalign thechainintothegrooveoftheguidebar.
Yearlyorbeforestorage
Asharpchainensuresbettercuttingperformanceand longerbatterylife.
Thechainneedstobesharpenedorreplacedifyou mustforceitontothewood,orifitproducessawdust insteadoffullwoodchips.
ContactanAuthorizedServiceDealertohavethe chainsharpenedorreplaced.
Service
Shouldthepolesawneedservice,takethetoolto yourAuthorizedServiceDealer.
Note:Ifyouareinstallinganewchain,ipthe
guidebartoavoidunevenwear.
4.Positiontheopenloopofthechain(notonthe guidebar)aroundthedrivesprocketonthepole sawandinstalltheguidebarandattachedchain ontothepolesaw.
Important:Ensurethatthechainadjusting
studisinsertedintothechainadjustingstud slotontheguidebar(Figure19).Y oumay needtorotatethechain-tensioningscrewto tthestudintotheholeintheguidebar.
5.Installthesidecover,butdonotfullytightenthe sidecoverknob.
6.Adjustthechaintension;refertoAdjustingthe
ChainT ension(page17).
20
Storage
Important:Storethemachine,batterypack,and
chargeronlyintemperaturesthatarewithinthe appropriaterange;refertoSpecications(page
12).
Important:Ifyouarestoringthebatterypack
fortheoff-season,chargeituntil2or3LED indicatorsturngreenonthebattery.Donotstore afullychargedorfullydepletedbattery.When youarereadytousethemachineagain,charge thebatterypackuntiltheleftindicatorlightturns greenonthechargerorall4LEDindicatorsturn greenonthebattery.
Disconnectthemachinefromthepowersupply
(i.e.,removethebatterypack)andcheckfor damageafteruse.
Cleanallforeignmaterialfromthemachine.
Donotstorethemachinewiththebatterypack
installed.
Storethemachine,batterypack,andbattery
chargerinawell-ventilatedplacethatis inaccessibletochildren.
Keepthemachine,batterypack,andbattery
chargerawayfromcorrosiveagentssuchas gardenchemicalsandde-icingsalts.
Toreducetheriskofseriouspersonalinjury ,do
notstorethebatterypackoutsideorinvehicles.
Storethemachine,batterypack,andbattery
chargerinanenclosedclean,dryarea.
21
Troubleshooting
Performonlythestepsdescribedintheseinstructions.Allfurtherinspection,maintenance,andrepairwork mustbeperformedbyanauthorizedservicecenterorasimilarlyqualiedspecialistifyoucannotsolvethe problemyourself.
Problem
Thepolesawdoesnotrunordoesnotrun continuously.
Thepolesawruns,butthechaindoesnot rotate.
Thepolesawdoesnotproperlycut.
PossibleCauseCorrectiveAction
1.Thebatterypackislowoncharge.
2.Thebatterypackisnotfullyseated.
3.Thebatterypackisoverorunderthe appropriatetemperaturerange.
4.Thebatterypackhasexceededhigh amperagelimits.
5.Thereismoistureontheleadsofthe batterypack.
6.Thereisdebrisunderthecover .6.Removethecoverandcleanoutany
1.Thechainisnotproperlyseatedonthe drivesprocket.
2.Thereisdebrisunderthecover .2.Removethecoverandcleanoutany
1.Thechainisnottensionedcorrectly.
2.Thechainisdullordamaged.2.Replacethechain.
3.Theguidebarisbentorthegrooves aredamaged.
4.Thechainisinstalledbackward.4.Installthechaincorrectly .
5.Thechainisnotbeinglubricated properly.
1.Chargethebatterypack.
2.Ensurethatthebatterypackisinserted allthewayintothehousing.
3.Movethebatterypacktoaplace whereitisdryandthetemperatureis between5°C(41°F)and40°C(104°F).
4.Releasethetrigger,thenpressthe triggerswitch.
5.Allowthebatterypacktodryorwipeit dry.
debris.
1.Installthechainandensurethatthe linksareproperlyseatedinthedrive sprocket.
debris.
1.Setthepropertensiononthechain.
3.Replacetheguidebar
5.Checktheoillevelandensurethatoil isowingtothechain.
Thechainoilisnotlubricatingproperly .
1.Theoillevelislow.
2.Theoiloutletisplugged.
3.Thereisdebrisunderthecover .3.Removethecoverandcleanoutany
4.Theoilchannelorgrooveintheguide barisplugged.
1.Checktheoillevel.
2.Cleanoutdebrisfromtheoiloutlet.
debris.
4.Cleanoutdebrisinthebar.
22
Notes:
EEA/UKPrivacyNotice
Toro’sUseofYourPersonalInformation
TheT oroCompany(“T oro”)respectsyourprivacy.Whenyoupurchaseourproducts,wemaycollectcertainpersonalinformationaboutyou,eitherdirectly fromyouorthroughyourlocalT orocompanyordealer.T orousesthisinformationtofullcontractualobligations-suchastoregisteryourwarranty, processyourwarrantyclaimortocontactyouintheeventofaproductrecall-andforlegitimatebusinesspurposes-suchastogaugecustomer satisfaction,improveourproductsorprovideyouwithproductinformationwhichmaybeofinterest.Toromayshareyourinformationwithoursubsidiaries, afliates,dealersorotherbusinesspartnersinconnectiontheseactivities.Wemayalsodisclosepersonalinformationwhenrequiredbylaworin connectionwiththesale,purchaseormergerofabusiness.Wewillneversellyourpersonalinformationtoanyothercompanyformarketingpurposes.
RetentionofyourPersonalInformation
Torowillkeepyourpersonalinformationaslongasitisrelevantfortheabovepurposesandinaccordancewithlegalrequirements.Formoreinformation aboutapplicableretentionperiodspleasecontactlegal@toro.com.
Toro’sCommitmenttoSecurity
YourpersonalinformationmaybeprocessedintheUSoranothercountrywhichmayhavelessstrictdataprotectionlawsthanyourcountryofresidence. Wheneverwetransferyourinformationoutsideofyourcountryofresidence,wewilltakelegallyrequiredstepstoensurethatappropriatesafeguardsare inplacetoprotectyourinformationandtomakesureitistreatedsecurely.
AccessandCorrection
Youmayhavetherighttocorrectorreviewyourpersonaldata,orobjecttoorrestricttheprocessingofyourdata.Todoso,pleasecontactusbyemail atlegal@toro.com.IfyouhaveconcernsaboutthewayinwhichTorohashandledyourinformation,weencourageyoutoraisethisdirectlywithus. PleasenotethatEuropeanresidentshavetherighttocomplaintoyourDataProtectionAuthority.
374-0282RevC
Loading...
