Toro 20333 Operator's Manual

22inRecycler

ModelNo.20333—SerialNo.402000000andUp

®

Introduction

Thisrotary-blade,walk-behindlawnmowerisintended
tobeusedbyresidentialhomeowners.Itisdesigned
primarilyforcuttinggrassonwell-maintainedlawns
onresidentialproperties.Itisnotdesignedforcutting
brushorforagriculturaluses.

Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.

YoumaycontactT orodirectlyatwww.T oro.comfor
productandaccessoryinformation,helpndinga
dealer,ortoregisteryourproduct.

Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready .Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.

Important:Withyourmobiledevice,youcan

scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.

FormNo.3418-807RevA

LawnMower

Operator'sManual

g000502

Figure2

Safety-alertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.

WARNING

CALIFORNIA

Proposition65Warning

Thisproductcontainsachemical

orchemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orreproductiveharm.

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.

Figure1

1.Modelandserialnumberlocation

ModelNo.

SerialNo.

Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.

©2017—TheT oro®Company
8111L yndaleAvenueSouth
Bloomington,MN55420

Registeratwww.Toro.com.

g226621

GrossorNetTorque:Thegrossornettorque
ofthisenginewaslaboratoryratedbytheengine
manufacturerinaccordancewiththeSocietyof
AutomotiveEngineers(SAE)J1940orJ2723.As
conguredtomeetsafety,emission,andoperating
requirements,theactualenginetorqueonthisclass
ofmowerwillbesignicantlylower.Pleasereferto
theenginemanufacturer’sinformationincludedwith
themachine.

Contents

Introduction...............................................................1

Safety.......................................................................2

GeneralSafety...................................................2

OriginalInstructions(EN)

PrintedinMexico

AllRightsReserved

*3418-807*A

SafetyandInstructionalDecals..........................3

Setup........................................................................5

1AssemblingandUnfoldingtheHandle..............5

2InstallingtheBlade-ControlBar........................6

3InstallingtheRecoil-StarterRopeinthe

RopeGuide.....................................................6

4FillingtheEnginewithOil.................................7

5AssemblingtheGrassBag...............................7

ProductOverview.....................................................8

Operation..................................................................8

BeforeOperation...................................................8

BeforeOperationSafety.....................................8

FillingtheFuelTank............................................9

CheckingtheEngine-OilLevel............................9

AdjustingtheCuttingHeight.............................10

DuringOperation..................................................11

DuringOperationSafety....................................11

StartingtheEngine............................................11

UsingtheSelf-PropelDrive...............................12

ShuttingOfftheEngine.....................................12

EngagingtheBlade..........................................12

DisengagingtheBlade......................................13

CheckingtheBlade-Brake-Clutch

Operation......................................................13

RecyclingtheClippings....................................13

BaggingtheClippings.......................................14

OperatingtheBag-on-DemandLever...............15

Side-DischargingtheClippings.........................15

OperatingTips.................................................16

AfterOperation....................................................17

AfterOperationSafety......................................17

CleaningundertheMachine.............................17

FoldingtheHandle...........................................18

Maintenance...........................................................19

RecommendedMaintenanceSchedule(s)...........19

MaintenanceSafety..........................................19

PreparingforMaintenance...............................19

ChangingtheEngineOil...................................20

ReplacingtheBlade..........................................21

CleaningtheBlade-Brake-ClutchShield...........22

AdjustingtheSelf-PropelDrive.........................22

Storage...................................................................23

PreparingtheMachineforStorage...................23

RemovingtheMachinefromStorage................23

Safety

Thismachinehasbeendesignedinaccordancewith
ANSIB71.1-2012.

GeneralSafety

Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjury .

Usingthisproductforpurposesotherthanitsintended
usecouldprovedangeroustoyouandbystanders.

•Read,understand,andfollowtheinstructions

andwarningsinthisOperator’sManualandon
themachineandattachmentsbeforestartingthe
engine.

•Donotputyourhandsorfeetnearmovingpartsof

orunderthemachine.Keepclearofanydischarge
opening.

•Donotoperatethemachinewithoutallguards

andothersafetyprotectivedevicesinplaceand
workingonthemachine.

•Keepbystandersandchildrenasafedistance

awayfromthemachine.Donotallowchildrento
operatethemachine.Allowonlypeoplewhoare
responsible,trained,familiarwiththeinstructions,
andphysicallycapabletooperatethemachine.

•Stopthemachine,shutofftheengine,andwaitfor

allmovingpartstostopbeforeservicing,fueling,
oruncloggingthemachine.

Improperlyusingormaintainingthismachinecan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalwayspay
attentiontothesafety-alertsymbol,whichmeans
Caution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.

Youcanndadditionalsafetyinformationwhere
neededthroughoutthismanual.

2

SafetyandInstructionalDecals

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.

Manufacturer'sMark

1.Thismarkindicatesthatthebladeisidentiedasapart
fromtheoriginalmachinemanufacturer .

decaloemmarkt

decal94-8072

94-8072

decal125-5026

125-5026

1.Recyclingmode2.Baggingmode

decal117-2718

117-2718

decal125-5092

125-5092

1.Steponthemowerhousingtostarttheengine.

3

131-4514

1.Warning—readtheOperator'sManual.

2.Cutting/dismembermenthazardofhand,mower
blade—stayawayfrommovingparts;keepallguardsand
shieldsinplace.

3.Cutting/dismembermenthazardofhand,mower
blade—disconnectthespark-plugwireandreadthe
instructionsbeforeservicingorperformingmaintenance.

4.Thrownobjecthazard—keepbystandersasafedistance
awayfromthemachine;shutofftheenginebeforeleaving
theoperatingposition;pickupanydebrisbeforemowing.

5.Cutting/dismembermenthazardoffoot,mowerblade—do
notoperateupanddownslopes;operatesidetosideon
slopes;lookbehindyouwhenbackingup.

decal131-4514b

decal132-4470

132-4470

TractionAdjustment

137-9196

1.Lock2.Unlock

1.Attention;readthe
Operator'sManual—1)
Loosentheknobbyturning

2.ScantheQRcodefor
moreinformationon
tractionadjustment.

itcounterclockwise;2)Pull
thecable(s)awayfrom
theenginetodecrease
thetraction,orpushthe
cable(s)towardtheengine
toincreasethetraction;

decal137-9196

3)Tightentheknobby
turningitclockwise.

4

Setup

Important:Removeanddiscardtheprotectiveplasticsheetthatcoverstheengineandanyother

plasticorwrappingonthemachine.

1

AssemblingandUnfoldingtheHandle

NoPartsRequired

Procedure

Note:Ensurethatthecablesareroutedontheoutsideofthehandleandarenotpinched(DofFigure3).

Figure3

5

g236451

2

InstallingtheBlade-Control Bar

NoPartsRequired

Procedure

g235299

Figure4

3

InstallingtheRecoil-Starter RopeintheRopeGuide

NoPartsRequired

Procedure

Important:Tostarttheenginesafelyandeasilywheneveryouusethemachine,installtherecoil-starter

ropeintheropeguide.

Figure5

g236533

6

4

FillingtheEnginewithOil

NoPartsRequired

Procedure

5

AssemblingtheGrassBag

NoPartsRequired

Procedure

g231765

Figure6

Figure7

7

g230447

ProductOverview

Figure8

1.Handle

2.Blade-controlbar

3.Adjustmentknobforthe
self-propeldrive

4.Ignitionswitch11.Bag-on-demandlever

5.Fuel-tankcap

6.Airlter

7.Cutting-heightlever(4)14.Control-barlock

8.Sparkplug

9.Side-dischargedeector

10.Oilll/dipstick

12.Handleknob(2)

13.Recoil-starthandle

Operation

Note:Determinetheleftandrightsidesofthe

machinefromthenormaloperatingposition.

BeforeOperation

BeforeOperationSafety

GeneralSafety

•Becomefamiliarwiththesafeoperationofthe

equipment,operatorcontrols,andsafetysigns.

•Checkthatallguardsandsafetydevices,suchas

deectorsand/orgrasscatcher,areinplaceand
workingproperly.

•Alwaysinspectthemachinetoensurethatthe

blades,bladebolts,andcuttingassemblyarenot
wornordamaged.

g036579

•Inspecttheareawhereyouwillusethemachine,

andremoveallobjectsthatcouldinterferewith
theoperationofthemachineorthatthemachine
couldthrow.

•Adjustingthecuttingheightmaybringyouinto

contactwiththemovingblade,causingserious
injury.

–Shutofftheengine,removetheignitionkey

(electric-startmodelonly),andwaitforall
movingpartstostop.

Figure9

1.Grassbag2.Side-dischargechute

–Donotputyourngersunderthehousing

whenadjustingthecuttingheight.

FuelSafety

•Fuelisextremelyammableandhighlyexplosive.

Areorexplosionfromfuelcanburnyouand
othersandcandamageproperty.

g009527

–Topreventastaticchargefromignitingthefuel,

placethecontainerand/ormachinedirectlyon
thegroundbeforelling,notinavehicleoron
anobject.

–Fillthefueltankoutdoors,inanopenarea,

whentheengineiscold.Wipeupanyfuelthat
spills.

–Donothandlefuelwhensmokingoraroundan

openameorsparks.

–Donotremovethefuelcaporaddfueltothe

tankwhiletheengineisrunningorhot.

–Ifyouspillfuel,donotattempttostartthe

engine.Avoidcreatingasourceofignitionuntil
thefuelvaporshavedissipated.

8

–Storefuelinanapprovedcontainerandkeep

itoutofthereachofchildren.

•Fuelisharmfulorfatalifswallowed.Long-term

exposuretovaporscancauseseriousinjuryand
illness.

–Avoidprolongedbreathingofvapors.

–Keepyourhandsandfaceawayfromthe

nozzleandthefuel-tankopening.

–Keepfuelawayfromyoureyesandskin.

FillingtheFuelTank

•Forbestresults,useonlyclean,fresh,unleaded

gasolinewithanoctaneratingof87orhigher
((R+M)/2ratingmethod).

•Oxygenatedfuelwithupto10%ethanolor15%

MTBEbyvolumeisacceptable.

•Donotstorefueleitherinthefueltankorinfuel

containersoverthewinterunlessfuelstabilizer
hasbeenaddedtothefuel.

•Donotaddoiltogasoline.

Fillthefueltankwithfreshunleadedregulargasoline
fromamajorname-brandservicestation(Figure10).

Important:Toreducestartingproblems,add

fuelstabilizertothegasolineallseason.Mixthe
stabilizerwithgasolinelessthan30daysold.

Refertoyourengineowner’smanualforadditional
information.

•Donotuseethanolblendsofgasoline,such

asE15orE85,withmorethan10%ethanolby
volume.Performanceproblemsand/orengine
damagemayresult,whichmaynotbecovered
underwarranty.

Figure10

•Donotusegasolinecontainingmethanol.

CheckingtheEngine-OilLevel

ServiceInterval:Beforeeachuseordaily

Important:Iftheoillevelintheengineistoolowortoohighandyouruntheengine,youmaydamage

theengine.

g230458

Figure11

9

g231765

AdjustingtheCuttingHeight

WARNING

Adjustingthecuttingheightmaybringyouintocontactwiththemovingblade,causing
seriousinjury.

•Shutofftheengineandwaitforallmovingpartstostop.

•Donotputyourngersunderthehousingwhenadjustingthecuttingheight.

CAUTION

Iftheenginehasbeenrunning,themuferwillbehotandcanseverelyburnyou.

Keepawayfromthehotmufer.

Adjustthecuttingheightasdesired.Setallthewheelstothesameheight;refertoFigure12.

Figure12

g223084

10

DuringOperation

•Useextremecarewhenapproachingblind

corners,shrubs,trees,orotherobjectsthatmay
blockyourview.

DuringOperationSafety

GeneralSafety

•Wearappropriateclothing,includingeye

protection;longpants;slip-resistant,substantial
footwear;andhearingprotection.Tiebacklong
hair,securelooseclothing,anddonotwearloose
jewelry.

•Donotoperatethemachinewhileill,tired,or

undertheinuenceofalcoholordrugs.

•Thebladeissharp;contactingthebladecanresult

inseriouspersonalinjury.Shutofftheengine,
removetheignitionkey(electric-startmodelonly),
andwaitforallmovingpartstostopbeforeleaving
theoperatingposition.

•Whenyoureleasetheblade-controlbar,the

engineshouldshutoffandthebladeshouldstop
within3seconds.Ifnot,stopusingyourmachine
immediatelyandcontactanAuthorizedService
Dealer.

•Keepbystanders,especiallysmallchildren,outof

theoperatingarea.Stopthemachineifanyone
entersthearea.

•Alwayslookdownandbehindyoubeforemoving

themachineinreverse.

•Operatethemachineonlyingoodvisibilityand

appropriateweatherconditions.Donotoperate
themachinewhenthereistheriskoflighting.

•Wetgrassorleavescancauseseriousinjuryif

youslipandcontacttheblade.Avoidmowingin
wetconditions.

•Watchforholes,ruts,bumps,rocks,orother

hiddenobjects.Uneventerraincouldcausethe
machinetooverturnorcauseyoutoloseyour
balanceorfooting.

•Ifthemachinestrikesanobjectorstartstovibrate,

immediatelyshutofftheengine,removethekey
(ifequipped),waitforallmovingpartstostop,and
disconnectthewirefromthesparkplugbefore
examiningthemachinefordamage.Makeall
necessaryrepairsbeforeresumingoperation.

•Beforeleavingtheoperatingposition,shutoff

theengine,removetheignitionkey(electric-start
modelonly),andwaitforallmovingpartstostop.

•Iftheenginehasbeenrunningthemuferwillbe

hotandcanseverelyburnyou.Keepawayfrom
thehotmufer.

•Checkthegrasscatchercomponentsand

thedischargechutefrequentlyforanywear
ordeteriorationandreplacethemwiththe
manufacturer'srecommendedpartswhen
necessary.

•Useaccessoriesandattachmentsapprovedby

TheToro®Companyonly .

SlopeSafety

•Mowacrossthefaceofslopes;neverupand

down.Useextremecautionwhenchanging
directiononslopes.

•Donotmowonexcessivelysteepslopes.Poor

footingcouldcauseaslip-and-fallaccident.

•Mowwithcautionneardrop-offs,ditches,or

embankments.

StartingtheEngine

Figure13

Note:Ifthemachinedoesnotstartafterseveralattempts,contactanAuthorizedServiceDealer.

11

g236579

UsingtheSelf-PropelDrive

EngagingtheBlade

Tooperatetheself-propeldrive,simplywalkwithyour
handsontheupperhandleandyourelbowsatyour
sides,andthemachinewillautomaticallykeeppace
withyou(Figure14).

Figure14

Note:Ifthemachinedoesnotfreelyrollbackward

afterself-propelling,stopwalking,holdyourhands
inplace,andallowthemachinetorollacoupleof
centimeters(inches)forwardtodisengagethewheel
drive.Youcanalsotryreachingjustundertheupper
handletothemetalhandleandpushingthemachine
forwardacoupleofcentimeters(inches).Ifthe
machinestilldoesnotrollbackwardeasily,contactan
AuthorizedServiceDealer.

Whenyoustartyourengine,thebladedoesnotturn.
Youmustengagethebladetomow.

1.Pullthecontrol-barlockback(Figure16).

g003123

Figure16

g009549

2.Pulltheblade-controlbartothehandle(Figure

17).

g003124

Figure17

ShuttingOfftheEngine

ServiceInterval:Beforeeachuseordaily

Toshutofftheengine,pressandholdthe
engine-shutoffbutton(Figure16)untiltheengine
shutsoff.

Figure15

3.Holdtheblade-controlbaragainstthehandle
(Figure18).

g003125

Figure18

g236566

12

DisengagingtheBlade

Releasetheblade-controlbar(Figure19).

2.Setall4wheelstothe83mm(3-1/4inch)
cutting-heightsetting.

3.Takeahalfsheetofnewspaperandcrumpleit
intoaballsmallenoughtogounderthemachine
housing(about76mmor3inchesindiameter).

4.Placethenewspaperballabout13cm(5inches)
infrontofthemachine.

5.Starttheengine.

6.Engagetheblade.

Figure19

Important:Whenyoureleasetheblade-control

bar,thebladeshouldstopwithin3seconds.Ifit
doesnotstopproperly,stopusingyourmachine
immediatelyandcontactanAuthorizedService
Dealer.

Checkingthe Blade-Brake-Clutch Operation

Checkthecontrolbarbeforeeachusetoensurethat
theblade-brake-clutchsystemisoperatingproperly.

UsingtheGrassBag

ServiceInterval:Beforeeachuseordaily

Youcanusethegrassbagtoperformanadditional
testtochecktheblade-brakeclutch.

1.Installtheemptygrassbagonthemachine.

2.Starttheengine.

3.Engagetheblade.

g003126

7.Releasetheblade-controlbar.

8.Immediatelypushthemachineoverthe
newspaperball.

9.Shutofftheengineandwaitforallmovingparts
tostop.

10.Gotothefrontofthemachineandcheckthe
newspaperball.

Note:Ifthenewspaperballdidnotgounder

themachine,repeatsteps4through10.

11.Ifthenewspaperisunravelledorshredded,the
bladedidnotstopproperly,whichcouldresult
inanunsafeoperatingcondition.Contactan
AuthorizedServiceDealer.

RecyclingtheClippings

Yourmachinecomesfromthefactoryreadytorecycle
thegrassandleafclippingsbackintothelawn.

Ifthegrassbagisonthemachineandthe
bag-on-demandleverisinthebaggingposition,
movethelevertotherecyclingposition;referto

OperatingtheBag-on-DemandLever(page15).If

theside-dischargechuteisonthemachine,remove
it;refertoRemovingtheSide-DischargeChute(page

16).

Note:Thebagshouldbegintoinate,indicating

thatthebladeisengagedandrotating.

4.Releasetheblade-controlbar.

Note:Ifthebagdoesnotimmediatelydeate,

thebladeisstillrotating.Theblade-brakeclutch
maybedeterioratingand,ifignored,could
resultinanunsafeoperatingcondition.Have
themachineinspectedandservicedbyan
AuthorizedServiceDealer.

5.Shutofftheengineandwaitforallmovingparts
tostop.

NotUsingtheGrassBag

1.Movethemachineontoapavedsurfaceina
non-windyarea.

13

BaggingtheClippings

Usethegrassbagwhenyouwanttocollectgrassandleafclippingsfromthelawn.

Iftheside-dischargechuteisonthemachine,removeit;refertoRemovingtheSide-DischargeChute(page

16).Ifthebag-on-demandleverisintherecyclingposition,moveittothebaggingposition;refertoOperating
theBag-on-DemandLever(page15).

InstallingtheGrassBag

1.Raiseandholdupthereardeector(AofFigure20).

2.Installthegrassbag,ensuringthatthepinsonthebagrestinthenotchesonthehandle(BofFigure20).

3.Lowerthereardeector.

Figure20

g233434

RemovingtheGrassBag

Toremovethebag,reversethestepsinInstallingtheGrassBag(page14).

14

Operatingthe Bag-on-DemandLever

Thebag-on-demandfeatureallowsyoutoeither
collectorrecyclegrassandleafclippingswhilethe
grassbagisattachedtothemachine.

•Tobagthegrassandleafclippings,pressthe

buttononthebag-on-demandleverandmovethe
leverforwarduntilthebuttonontheleverpopsup
(Figure21).

movetheleverrearwarduntilthebuttononthe
leverpopsup.

Important:Forproperoperation,shutoff

theengine,waitforallmovingpartstostop,
andthenremoveanygrassclippingsand
debrisfromthebag-on-demanddoorandthe
surroundingopening(Figure22)beforeyou
movethebag-on-demandleverfrom1position
toanother.

Figure21

1.Bag-on-demandlever(inthebaggingposition)

g033491

1.Cleanhere

Figure22

•Torecycleorside-dischargethegrassand

leafclippings,pressthebuttonontheleverand

Side-DischargingtheClippings

Useside-dischargingforcuttingverytallgrass.

Ifthegrassbagisonthemachineandthebag-on-demandleverisinthebaggingposition,movethelevertothe
recyclingposition;refertoOperatingtheBag-on-DemandLever(page15).

InstallingtheSide-DischargeChute

Liftupthesidedeectorandinstalltheside-dischargechute(AandBofFigure23).

g036581

Figure23

g233435

15

RemovingtheSide-DischargeChute

Toremovetheside-dischargechute,liftupthesidedeector,removetheside-dischargechute,andlowerthe
side-dischargedeector.

OperatingTips

GeneralMowingTips

•Inspecttheareawhereyouwillusethemachine

andremoveallobjectsthatthemachinecould
throw.

•Avoidstrikingsolidobjectswiththeblade.Never

deliberatelymowoveranyobject.

•Ifthemachinestrikesanobjectorstartstovibrate,

immediatelyshutofftheengine,removethekey
(ifequipped),disconnectthewirefromthespark
plug,andexaminethemachinefordamage.

•Forbestperformance,installanewbladebefore

thecuttingseasonbegins.

•ReplacethebladewhennecessarywithaToro

replacementblade.

CuttingGrass

•Cutonlyaboutathirdofthegrassbladeatatime.

Donotcutbelow51mm(2inches)unlessthe
grassissparseoritislatefallwhengrassgrowth
beginstoslowdown.

CuttingLeaves

•Aftercuttingthelawn,ensurethathalfofthelawn

showsthroughthecutleafcover.Y oumayneed
tomakemorethanasinglepassovertheleaves.

•Iftherearemorethan13cm(5inches)ofleaves

onthelawn,mowatahighercuttingheightand
thenagainatthedesiredcuttingheight.

•Slowdownyourmowingspeedifthemachine

doesnotcuttheleavesnelyenough.

•Whencuttinggrassover15cm(6inches)tall,

mowatthehighestcuttingheightsettingandwalk
slower;thenmowagainatalowersettingforthe
bestlawnappearance.Ifthegrassistoolong,the
machinemayplugandcausetheenginetostall.

•Wetgrassandleavestendtoclumpontheyard

andcancausethemachinetoplugortheengine
tostall.Avoidmowinginwetconditions.

•Beawareofapotentialrehazardinverydry

conditions,followalllocalrewarnings,andkeep
themachinefreeofdrygrassandleafdebris.

•Alternatethemowingdirection.Thishelps

dispersetheclippingsoverthelawnforeven
fertilization.

•Ifthenishedlawnappearanceisunsatisfactory,

try1ormoreofthefollowing:

–Replacethebladeorhaveitsharpened.

–Walkataslowerpacewhilemowing.

–Raisethecuttingheightonyourmachine.

–Cutthegrassmorefrequently.

–Overlapcuttingswathsinsteadofcuttingafull

swathwitheachpass.

16

AfterOperation

AfterOperationSafety

GeneralSafety

•Cleangrassanddebrisfromthemachinetohelp

preventres.Cleanupoilorfuelspills.

•Allowtheenginetocoolbeforestoringthemachine

inanyenclosure.

•Neverstorethemachineorfuelcontainerwhere

thereisanopename,spark,orpilotlight,such
asonawaterheateroronotherappliances.

HaulingSafety

•Removetheignitionkey(ifequipped)before

loadingthemachineforhauling.

•Usecarewhenloadingorunloadingthemachine.

•Securethemachinefromrolling.

CleaningundertheMachine

ServiceInterval:Beforeeachuseordaily

g033492

Figure24

1.Washoutport

6.Turnthewateron.

7.Starttheengineandrunituntiltheclippingsno
longercomeoutfromunderthemachine.

8.Shutofftheengine.

9.Shutoffthewateranddisconnectthegarden
hosefromthemachine.

10.Starttheengineandrunitforafewminutesto
drytheundersideofthemachinetopreventit
fromrusting.

11.Shutofftheengineandallowittocoolbefore
storingthemachineinanenclosedarea.

Forbestresults,cleanthemachinesoonafteryou
havecompletedmowing.

1.Movethemachineontoaatpavedsurface.

2.Shutofftheengineandwaitforallmovingparts
tostopbeforeleavingtheoperatingposition.

3.Lowerthemachinetoitslowestcutting-height
setting.RefertoAdjustingtheCuttingHeight

(page10).

4.Washouttheareaunderthereardoorwherethe
clippingsgofromtheundersideofthemachine
tothegrassbag.

Note:Washouttheareawiththe

bag-on-demand(ifequipped)inboththefully
forwardandfullyrearwardpositions.

5.Attachagardenhosethatisconnectedtoa
watersupplytothewashoutport(Figure24).

17

FoldingtheHandle

WARNING

Foldingorunfoldingthehandleimproperly
candamagethecables,causinganunsafe
operatingcondition.

•Donotdamagethecableswhenfoldingor
unfoldingthehandle.

•Ifacableisdamaged,contactan
AuthorizedServiceDealer.

1.Removeandsavethe2handleknobsand2
carriageboltsfromthehandlebrackets(Figure

25).

Important:Routethecablestotheoutside

ofthehandleknobsasyoufoldthehandle.

3.Insertthecarriagebolt(withtheboltheadtoward
theinside)throughthehandlebracketandthe
upperholeinthehandleend.Ensurethatthe
squareedgesofeachcarriagebolttsintothe
upperorlowersquareholeinitsrelatedhandle
bracket(Figure27).

g032865

Figure27

Figure25

1.Handleknob

2.Carriagebolt

2.Foldthehandlebyrotatingitforward(Figure26).

1.Handleknob

2.Carriagebolt

4.Looselyinstallthehandleknobsandcarriage
boltsonthehandlebrackets.

5.Tounfoldthehandle,referto1Assemblingand

UnfoldingtheHandle(page5).

g032869

1.Operatingposition

g036582

Figure26

2.Foldedposition

18

Maintenance

RecommendedMaintenanceSchedule(s)

MaintenanceService

Interval

Beforeeachuseordaily

Every25hours

Yearly

Yearlyorbeforestorage

MaintenanceProcedure

•Checktheengine-oillevel.

•Ensurethatthebladestopswithin3secondsafterreleasingtheblade-controlbar.

•Checktheblade-brake-clutchoperation.

•Cleangrassclippingsanddirtfromunderthemachine.

•Cleantheblade-brake-clutchshield.

•Changetheengineoil.

•Replacethebladeorhaveitsharpened(morefrequentlyiftheedgedullsquickly).

•Cleantheenginebyremovingdirtanddebrisfromitstopandsides;cleanitmore
frequentlyindustyoperatingconditions.

•Emptythefueltankbeforerepairsasdirectedandbeforeyearlystorage.

Important:Refertoyourengineowner’smanualforadditionalmaintenanceprocedures.

MaintenanceSafety

•Disconnectthespark-plugwirefromthesparkplug

beforeperforminganymaintenanceprocedure.

•Wearglovesandeyeprotectionwhenservicing

themachine.

•Thebladeissharp;contactingthebladecanresult

inseriouspersonalinjury .Weargloveswhen
servicingtheblade.Donotrepairoralterthe
blade(s).

•Nevertamperwithsafetydevices.Checktheir

properoperationregularly .

•Tippingthemachinemaycausethefueltoleak.

Fuelisammableandexplosive,andcancause
personalinjury.Runtheenginedryorremovethe
fuelwithahandpump;neversiphonthefuel.

•Toensureoptimumperformanceandcontinued

safetycerticationofthemachine,useonly
genuineTororeplacementpartsandaccessories.
Replacementpartsandaccessoriesmadeby
othermanufacturerscouldbedangerous,and
suchusecouldvoidtheproductwarranty .

PreparingforMaintenance

1.Shutofftheengineandwaitforallmovingparts
tostop.

2.Disconnectthespark-plugwirefromthespark
plug(Figure28).

g032617

Figure28

3.Afterperformingthemaintenanceprocedure(s),
connectthespark-plugwiretothesparkplug.

Important:Beforetippingthemachineto

changetheoilorreplacetheblade,allowthe
fueltanktorundrythroughnormalusage.If
youmusttipthemachinepriortorunning
outoffuel,useahandfuelpumptoremove
thefuel.Alwaystipthemachineontoits
side,withthedipstickdown.

19

ChangingtheEngineOil

ServiceInterval:Yearly

Changingtheengineoilisnotrequired,butif
youwanttochangetheoil,usethefollowing
procedure.

Note:Runtheengineafewminutesbeforechanging

theoiltowarmit.Warmoilowsbetterandcarries
morecontaminants.

EngineOilSpecications

Engineoilcapacity

OilviscositySAE30orSAE10W-30

APIserviceclassicationSJorhigher

0.44L(15oz)

detergentoil

1.Movethemachinetoalevelsurface.

2.RefertoPreparingforMaintenance(page19).

3.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure29).

g037003

Figure30

5.Afterdrainingtheusedoil,returnthemachineto
theoperatingposition.

6.Carefullypourabout3/4oftheenginecapacity
ofoilintotheoil-lltube.

7.Wait3minutesfortheoiltosettleintheengine.

8.Wipethedipstickcleanwithacleancloth.

9.Insertthedipstickintotheoil-lltube,then
removethedipstick.

10.Readtheoillevelonthedipstick(Figure29).

•Iftheoillevelonthedipstickistoolow,

carefullypourasmallamountofoilintothe
oil-lltube,wait3minutes,andrepeatsteps

8through10untiltheoillevelonthedipstick

iscorrect.

•Iftheoillevelonthedipstickistoohigh,

draintheexcessoiluntiltheoillevelonthe
dipstickiscorrect.

Figure29

1.Dipstick3.Full

2.Add

4.Tipthemachineontoitsside(sothattheair
lterisup)todraintheusedoilfromtheoil-ll
tube(Figure30).

g187518

20

lowortoohighandyouruntheengine,you
maydamagetheengine.

11.Installthedipstickintotheoil-lltubesecurely.

12.Recycletheusedoilproperly.

Important:Iftheoillevelintheengineistoo

ReplacingtheBlade

ServiceInterval:Yearly

Important:Youwillneedatorquewrenchto

installthebladeproperly.Ifyoudonothavea

torquewrenchorareuncomfortableperforming
thisprocedure,contactanAuthorizedService
Dealer.

Examinethebladewheneveryourunoutoffuel.Ifthe
bladeisdamagedorcracked,replaceitimmediately.
Ifthebladeedgeisdullornicked,haveitsharpened
andbalanced,orreplaceit.

WARNING

Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.

Weargloveswhenservicingtheblade.

1.RefertoPreparingforMaintenance(page19).

2.Tipthemachineontoitssidewiththeairlterup.

3.Useablockofwoodtoholdthebladesteady
(Figure31).

g231390

Figure32

Important:Positionthecurvedendsofthe

bladetopointtowardthemachinehousing.

Figure31

4.Removetheblade,savingallmountinghardware
(Figure31).

5.Installthenewbladeandallmountinghardware
(Figure32).

6.Useatorquewrenchtotightenthebladebolt

to82N∙m(60ft-lb).

Important:Abolttorquedto82N∙m(60

ft-lb)isverytight.Whileholdingtheblade
withablockofwood,putyourweight
behindtheratchetorwrenchandtightenthe
boltsecurely.Thisboltisverydifcultto
overtighten.

g231389

21

Cleaningthe

AdjustingtheSelf-Propel

Blade-Brake-ClutchShield

ServiceInterval:Every25hours

Cleantheblade-brake-clutchshieldyearlytoprevent
thebladefromstallingwhileyoumow.

1.Disconnectthespark-plugwirefromthespark
plug;refertoPreparingforMaintenance(page

19).

2.Tipthemachineontoitssidewiththedipstick
down.

3.Removethe2bladenutsandthestiffener
(Figure33).

Drive

Wheneveryouinstallanewself-propelcableorif
theself-propeldriveisoutofadjustment,adjustthe
self-propeldrive.

1.Turntheadjustmentknobcounterclockwiseto
loosenthecableadjustment(Figure34).

g027231

Figure34

Figure33

1.Bladenuts4.Bladedriver

2.Stiffener

3.Blade6.Blade-brake-clutchshield

4.Removetheblade(Figure33).

5.Removethebladedriveranddisk(Figure33).

6.Removetheblade-brake-clutchshield(Figure

33).

7.Brushorblowoutdebrisfromtheinsideofthe
shieldandaroundalltheparts.

8.Installtheblade-brake-clutchshieldthatyou
previouslyremoved.

9.Installthebladedriveranddiskthatyou
previouslyremoved.

10.Installthebladeandthestiffenerthatyou
previouslyremoved(Figure33).

5.Disk

1.Handle(leftside)

2.Adjustmentknob5.Turntheknob

g003133

3.Self-propel-drivecable

2.Adjustthetensiononthecable(Figure34)by
pullingitbackorpushingitforwardandholding
thatposition.

4.Turntheknobclockwiseto
tightentheadjustment.

counterclockwiseto
loosentheadjustment.

Note:Pushthecabletowardtheengineto

increasethetraction;pullthecableawayfrom
theenginetodecreasethetraction.

3.Turntheadjustmentknobclockwisetotighten
thecableadjustment.

Note:Tightentheknobrmlybyhand.

11.Installthebladenutsandtorquethemto20to
37N∙m(15to27ft-lb).

22

Storage

Storethemachineinacool,clean,dryplace.

PreparingtheMachinefor Storage

1.Onthelastrefuelingoftheyear,addfuel
stabilizer(suchasToroPremiumFuel
Treatment)tothefuelasdirectedonthelabel.

2.Disposeofanyunusedfuelproperly .Recycle
itaccordingtolocalcodesoruseitinyour
automobile.

Note:Oldfuelinthefueltankistheleading

causeofhardstarting.Donotstorefuelwithout
fuelstabilizermorethan30days,anddonot
storestabilizedfuelmorethan90days.

3.Runthemachineuntiltheengineshutsofffrom
runningoutoffuel.

4.Starttheengineagainandallowittorununtil
itshutsoff.Whenyoucannolongerstartthe
engine,itissufcientlydry.

5.Disconnectthewirefromthesparkplugand
connectthewiretotheretainingpost(if
equipped).

6.Removethesparkplug,add30ml(1oz)of
engineoilthroughthespark-plughole,andpull
thestarterropeslowlyseveraltimestodistribute
oilthroughoutthecylindertopreventcylinder
corrosionduringtheoff-season.

7.Looselyinstallthesparkplug.

8.Tightenallnuts,bolts,andscrews.

RemovingtheMachine fromStorage

1.Checkandtightenallfasteners.

2.Removethesparkplugandspintheengine
rapidlybypullingtherecoil-starthandletoblow
theexcessoilfromthecylinder.

3.Installthesparkplugandtightenitwithatorque
wrenchto20N∙m(15ft-lb).

4.Performanymaintenanceprocedures;referto

PreparingforMaintenance(page19).

5.Checktheengine-oillevel;refertoCheckingthe

Engine-OilLevel(page9).

6.Fillthefueltankwithfreshfuel;refertoFilling

theFuelT ank(page9).

7.Connectthewiretothesparkplug.

23
