Toro 20332 Operator's Manual

22inRecycler

ModelNo.20332—SerialNo.402082000andUp

®

Introduction

Thisrotary-blade,walk-behindlawnmowerisintended
tobeusedbyresidentialhomeowners.Itisdesigned
primarilyforcuttinggrassonwell-maintainedlawns
onresidentialproperties.Itisnotdesignedforcutting
brushorforagriculturaluses.

Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.

YoumaycontactT orodirectlyatwww.T oro.comfor
productandaccessoryinformation,helpndinga
dealer,ortoregisteryourproduct.

Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready .Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.

Important:Withyourmobiledevice,youcan

scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.

Figure1

1.Modelandserialnumberlocation

ModelNo.

FormNo.3418-785RevA

LawnMower

Operator'sManual

g000502

Figure2

Safety-alertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.

WARNING

CALIFORNIA

Proposition65Warning

Thisproductcontainsachemical

orchemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orreproductiveharm.

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.

g226621

TheenclosedEngineOwner'sManualis
suppliedforinformationregardingtheUS
EnvironmentalProtectionAgency(EPA)and
theCaliforniaEmissionControlRegulationof
emissionsystems,maintenance,andwarranty.
Replacementsmaybeorderedthroughtheengine
manufacturer.

SerialNo.

Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.

©2017—TheT oro®Company
8111L yndaleAvenueSouth
Bloomington,MN55420

Registeratwww.Toro.com.

GrossorNetTorque:Thegrossornettorque
ofthisenginewaslaboratoryratedbytheengine
manufacturerinaccordancewiththeSocietyof
AutomotiveEngineers(SAE)J1940orJ2723.As
conguredtomeetsafety,emission,andoperating
requirements,theactualenginetorqueonthisclass
ofmowerwillbesignicantlylower.Pleasereferto
theenginemanufacturer’sinformationincludedwith
themachine.

OriginalInstructions(EN)

PrintedinMexico

AllRightsReserved

*3418-785*A

Contents

Safety

Introduction...............................................................1

Safety.......................................................................2

GeneralSafety...................................................2

SafetyandInstructionalDecals..........................3

Setup........................................................................5

1AssemblingandUnfoldingtheHandle..............5

2InstallingtheRecoil-starterRopeinthe

RopeGuide.....................................................5

3FillingtheEnginewithOil.................................6

4AssemblingtheGrassBag...............................6

ProductOverview.....................................................7

Operation..................................................................7

BeforeOperation...................................................7

BeforeOperationSafety.....................................7

FillingtheFuelTank............................................8

CheckingtheEngine-OilLevel............................9

AdjustingtheHandleHeight...............................9

AdjustingtheCuttingHeight.............................10

DuringOperation.................................................10

DuringOperationSafety...................................10

StartingtheEngine............................................11

ShuttingOfftheEngine......................................11

RecyclingtheClippings.....................................11

BaggingtheClippings.......................................12

OperatingtheBag-on-DemandLever...............12

Side-DischargingtheClippings.........................14

OperatingTips.................................................14

AfterOperation....................................................15

AfterOperationSafety......................................15

CleaningundertheMachine.............................15

FoldingtheHandle...........................................15

Maintenance...........................................................17

RecommendedMaintenanceSchedule(s)...........17

MaintenanceSafety..........................................17

PreparingforMaintenance...............................17

ServicingtheAirFilter.......................................17

ChangingtheEngineOil...................................18

ReplacingtheBlade..........................................19

AdjustingtheSelf-PropelDrive.........................20

Storage...................................................................20

PreparingtheMachineforStorage...................20

RemovingtheMachinefromStorage................20

Thismachinehasbeendesignedinaccordancewith
ANSIB71.1-2012.

GeneralSafety

Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjury .

Usingthisproductforpurposesotherthanitsintended
usecouldprovedangeroustoyouandbystanders.

•Read,understand,andfollowtheinstructions

andwarningsinthisOperator’sManualandon
themachineandattachmentsbeforestartingthe
engine.

•Donotputyourhandsorfeetnearmovingpartsof

orunderthemachine.Keepclearofanydischarge
opening.

•Donotoperatethemachinewithoutallguards

andothersafetyprotectivedevicesinplaceand
workingonthemachine.

•Keepbystandersandchildrenasafedistance

awayfromthemachine.Donotallowchildrento
operatethemachine.Allowonlypeoplewhoare
responsible,trained,familiarwiththeinstructions,
andphysicallycapabletooperatethemachine.

•Stopthemachineandshutofftheenginebefore

servicing,fueling,oruncloggingthemachine.

Improperlyusingormaintainingthismachinecan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalwayspay
attentiontothesafety-alertsymbol,whichmeans
Caution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.

Youcanndadditionalsafetyinformationwhere
neededthroughoutthismanual.

2

SafetyandInstructionalDecals

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.

Manufacturer'sMark

1.Thismarkindicatesthatthebladeisidentiedasapart
fromtheoriginalmachinemanufacturer .

decaloemmarkt

decal94-8072

94-8072

decal125-5026

125-5026

1.Recyclingmode2.Baggingmode

decal117-2718

117-2718

decal131-4514b

131-4514

1.Warning—readtheOperator'sManual.

2.Cutting/dismembermenthazardofhand,mower
blade—stayawayfrommovingparts;keepallguardsand
shieldsinplace.

3.Cutting/dismembermenthazardofhand,mower
blade—disconnectthespark-plugwireandreadthe
instructionsbeforeservicingorperformingmaintenance.

4.Thrownobjecthazard—keepbystandersasafedistance
awayfromthemachine;shutofftheenginebeforeleaving
theoperatingposition;pickupanydebrisbeforemowing.

5.Cutting/dismembermenthazardoffoot,mowerblade—do
notoperateupanddownslopes;operatesidetosideon
slopes;lookbehindyouwhenbackingup.

3

decal132-4470

132-4470

TractionAdjustment

1.Attention;readthe
Operator'sManual—1)
Loosentheknobbyturning
itcounterclockwise;2)Pull
thecable(s)awayfrom
theenginetodecrease
thetraction,orpushthe
cable(s)towardtheengine
toincreasethetraction;

3)Tightentheknobby
turningitclockwise.

2.ScantheQRcodefor
moreinformationon
tractionadjustment.

137-9196

1.Lock2.Unlock

decal137-9196

4

Setup

Important:Removeanddiscardtheprotectiveplasticsheetthatcoverstheengineandanyother

plasticorwrappingonthemachine.

1

AssemblingandUnfoldingtheHandle

NoPartsRequired

Procedure

Note:Ensurethatthecablesareroutedontheoutsideofthehandleandarenotpinched(DofFigure3).

Figure3

5

g236451

2

InstallingtheRecoil-starterRopeintheRopeGuide

NoPartsRequired

Procedure

Figure4

g230719

3

FillingtheEnginewithOil

NoPartsRequired

Procedure

Important:Y ourmachinedoesnotcomewithoilintheengine,butitdoescomewithabottleofoil.

Beforestartingtheengine,lltheenginewithoil.

Figure5

6

g222533

4

AssemblingtheGrassBag

NoPartsRequired

Procedure

ProductOverview

g230447

Figure6

Figure7

1.Handle

2.Blade-controlbar

3.Adjustmentknobforthe
self-propeldrive

4.Fuel-tankcap10.Bag-on-demandlever

5.Airlter11.Handleknob(2)

6.Cutting-heightlever(4)

7.Sparkplug

8.Side-dischargedeector

9.Oilll/dipstick

12.Recoil-starthandle

g036586

Figure8

1.Grassbag2.Side-dischargechute

Operation

BeforeOperation

BeforeOperationSafety

GeneralSafety

g036585

•Becomefamiliarwiththesafeoperationofthe

equipment,operatorcontrols,andsafetysigns.

•Checkthatallguardsandsafetydevices,suchas

deectorsand/orgrasscatcher,areinplaceand
workingproperly.

•Alwaysinspectthemachinetoensurethatthe

blades,bladebolts,andcuttingassemblyarenot
wornordamaged.

•Inspecttheareawhereyouwillusethemachine,

andremoveallobjectsthatcouldinterferewith

7

theoperationofthemachineorthatthemachine
couldthrow.

•Adjustingthecuttingheightmaybringyouinto

contactwiththemovingblade,causingserious
injury.

–Shutofftheengine,removetheignitionkey

(electric-startmodelonly),andwaitforall
movingpartstostop.

–Donotputyourngersunderthehousing

whenadjustingthecuttingheight.

FuelSafety

•Fuelisextremelyammableandhighlyexplosive.

Areorexplosionfromfuelcanburnyouand
othersandcandamageproperty.

–Topreventastaticchargefromignitingthefuel,

placethecontainerand/ormachinedirectlyon
thegroundbeforelling,notinavehicleoron
anobject.

–Fillthefueltankoutdoors,inanopenarea,

whentheengineiscold.Wipeupanyfuelthat
spills.

–Donothandlefuelwhensmokingoraroundan

openameorsparks.

–Donotremovethefuelcaporaddfueltothe

tankwhiletheengineisrunningorhot.

–Ifyouspillfuel,donotattempttostartthe

engine.Avoidcreatingasourceofignitionuntil
thefuelvaporshavedissipated.

–Storefuelinanapprovedcontainerandkeep

itoutofthereachofchildren.

•Fuelisharmfulorfatalifswallowed.Long-term

exposuretovaporscancauseseriousinjuryand
illness.

–Avoidprolongedbreathingofvapors.

–Keepyourhandsandfaceawayfromthe

nozzleandthefuel-tankopening.

–Keepfuelawayfromyoureyesandskin.

•Donotstorefueleitherinthefueltankorinfuel

containersoverthewinterunlessfuelstabilizer
hasbeenaddedtothefuel.

•Donotaddoiltogasoline.

Fillthefueltankwithfreshunleadedregulargasoline
fromamajorname-brandservicestation(Figure9).

Important:Toreducestartingproblems,add

fuelstabilizertothegasolineallseason.Mixthe
stabilizerwithgasolinelessthan30daysold.

Refertoyourengineowner’smanualforadditional
information.

g230458

Figure9

FillingtheFuelTank

•Forbestresults,useonlyclean,fresh,unleaded

gasolinewithanoctaneratingof87orhigher
((R+M)/2ratingmethod).

•Oxygenatedfuelwithupto10%ethanolor15%

MTBEbyvolumeisacceptable.

•Donotuseethanolblendsofgasoline,such

asE15orE85,withmorethan10%ethanolby
volume.Performanceproblemsand/orengine
damagemayresult,whichmaynotbecovered
underwarranty.

•Donotusegasolinecontainingmethanol.

8

CheckingtheEngine-OilLevel

ServiceInterval:Beforeeachuseordaily

Important:Iftheoillevelinthecrankcaseistoolowortoohighandyouruntheengine,youmay

damagetheengine.

Figure10

g222533

AdjustingtheHandle Height

Youcanraiseorlowerthehandlein1of2positions
thatismorecomfortableforyou(Figure11).

Figure11

1.Loosenbothhandleknobsuntilyoucanpush

thesquareedgesofthecarriageboltsoutofthe
squareholesinthehandlebrackets.

2.Pushtheknobsuntiltheyareloose.

3.Movethehandletotheupperorlowerheight

position.

4.Pulltheknobsuntilthesquareedgesofeach
carriagebolttsintoitsrelatedsquarehole.

5.Tightenthehandleknobsastightasyoucan.

g032867

9

AdjustingtheCuttingHeight

CAUTION

Iftheenginehasbeenrunning,themuferwillbehotandcanseverelyburnyou.

Keepawayfromthehotmufer.

Adjustthecuttingheightasdesired.Setallwheelstothesamecuttingheight(Figure12).

DuringOperation

DuringOperationSafety

GeneralSafety

•Wearappropriateclothing,includingeye

protection;longpants;slip-resistant,substantial
footwear;andhearingprotection.Tiebacklong
hair,securelooseclothing,anddonotwear
jewelry.

•Donotoperatethemachinewhileill,tired,or

undertheinuenceofalcoholordrugs.

•Thebladeissharp;contactingthebladecanresult

inseriouspersonalinjury.Shutofftheengine,
removetheignitionkey(electric-startmodelonly),
andwaitforallmovingpartstostopbeforeleaving
theoperatingposition.

•Whenyoureleasetheblade-controlbar,the

engineshouldshutoffandthebladeshouldstop
within3seconds.Ifnot,stopusingyourmachine

g223084

Figure12

immediatelyandcontactanAuthorizedService
Dealer.

•Keepbystanders,especiallysmallchildren,outof

theoperatingarea.Stopthemachineifanyone
entersthearea.

•Alwayslookdownandbehindyoubeforemoving

themachineinreverse.

•Operatethemachineonlyingoodvisibilityand

appropriateweatherconditions.Donotoperate
themachinewhenthereistheriskoflighting.

•Wetgrassorleavescancauseseriousinjuryif

youslipandcontacttheblade.Avoidmowingin
wetconditions.

•Useextremecarewhenapproachingblind

corners,shrubs,trees,orotherobjectsthatmay
blockyourview.

•Watchforholes,ruts,bumps,rocks,orother

hiddenobjects.Uneventerraincouldcausethe
machinetooverturnorcauseyoutoloseyour
balanceorfooting.

10

•Stopthemachineandinspectthebladesafter

strikinganobjectorifthereisanabnormal
vibrationinthemachine.Makeallnecessary
repairsbeforeresumingoperation.

•Beforeleavingtheoperatingposition,shutoff

theengine,removetheignitionkey(electric-start
modelonly),andwaitforallmovingpartstostop.

•Iftheenginehasbeenrunningthemuferwillbe

hotandcanseverelyburnyou.Keepawayfrom
thehotmufer.

•Checkthegrasscatchercomponentsand

thedischargechutefrequentlyforanywear
ordeteriorationandreplacethemwiththe
manufacturer'srecommendedpartswhen
necessary.

•Useaccessoriesandattachmentsapprovedby

TheToro®Companyonly .

SlopeSafety

•Mowacrossthefaceofslopes;neverupand

down.Useextremecautionwhenchanging
directiononslopes.

ShuttingOfftheEngine

ServiceInterval:Beforeeachuseordaily

Toshutofftheengine,releasetheblade-controlbar.

Important:Whenyoureleasetheblade-control

bar,boththeengineandbladeshouldstopwithin
3seconds.Iftheydonotstopproperly,stop
usingyourmachineimmediatelyandcontactan
AuthorizedServiceDealer.

RecyclingtheClippings

Yourmachinecomesfromthefactoryreadytorecycle
thegrassandleafclippingsbackintothelawn.

Ifthegrassbagisonthemachineandthe
bag-on-demandleverisinthebaggingposition,
movethelevertotherecyclingposition;referto

OperatingtheBag-on-DemandLever(page12).If

theside-dischargechuteisonthemachine,remove
it;refertoRemovingtheSide-DischargeChute(page

14).

•Donotmowonexcessivelysteepslopes.Poor

footingcouldcauseaslip-and-fallaccident.

•Mowwithcautionneardrop-offs,ditches,or

embankments.

StartingtheEngine

1.Holdtheblade-controlbaragainstthehandle
(AofFigure13).

2.Pulltherecoil-starthandle(BofFigure13).

Note:Whenyoupulltherecoil-starthandle,

pullitlightlyuntilyoufeelresistance,thenpullit
sharply.Allowtheropetoreturntothehandle
slowly.

Note:Ifthemachinedoesnotstartafterseveral

attempts,contactanAuthorizedServiceDealer.

Figure13

g233422

11

BaggingtheClippings

Usethegrassbagwhenyouwanttocollectgrassandleafclippingsfromthelawn.

Iftheside-dischargechuteisonthemachine,removeit;refertoRemovingtheSide-DischargeChute(page

14).Ifthebag-on-demandleverisintherecyclingposition,moveittothebaggingposition;refertoOperating
theBag-on-DemandLever(page12).

InstallingtheGrassBag

1.Raiseandholdupthereardeector(AofFigure14).

2.Installthegrassbag,ensuringthatthepinsonthebagrestinthenotchesonthehandle(BofFigure14).

3.Lowerthereardeector.

Figure14

g233434

RemovingtheGrassBag

Toremovethebag,reversethestepsinInstallingtheGrassBag(page12).

Operatingthe Bag-on-DemandLever

Thebag-on-demandfeatureallowsyoutoeither
collectorrecyclegrassandleafclippingswhilethe
grassbagisattachedtothemachine.

•Tobagthegrassandleafclippings,pressthe

buttononthebag-on-demandleverandmovethe
leverforwarduntilthebuttonontheleverpopsup
(Figure15).

1.Bag-on-demandlever(inthebaggingposition)

•Torecycleorside-dischargethegrassand

leafclippings,pressthebuttonontheleverand
movetheleverrearwarduntilthebuttononthe
leverpopsup.

g009497

Figure15

Important:Forproperoperation,remove

anygrassclippingsanddebrisfromthe
bag-on-demanddoorandthesurrounding
opening(Figure16)beforeyoumovethe
bag-on-demandleverfrom1positionto
another.

12

1.Cleanhere

g009583

Figure16

13

Side-DischargingtheClippings

Usethesidedischargeforcuttingverytallgrass.

Ifthegrassbagisonthemachineandthebag-on-demandleverisintheBaggingposition,movetheleverto
theRecyclingposition;refertoOperatingtheBag-on-DemandLever(page12).

InstallingtheSide-DischargeChute

Liftupthesidedeectorandinstalltheside-dischargechute(AandBofFigure17).

Figure17

RemovingtheSide-DischargeChute

g233435

Toremovetheside-dischargechute,liftupthesidedeector,removetheside-dischargechute,andlowerthe
side-dischargedeector.

OperatingTips

GeneralMowingTips

•Inspecttheareawhereyouwillusethemachine

andremoveallobjectsthatthemachinecould
throw.

•Avoidstrikingsolidobjectswiththeblade.Never

deliberatelymowoveranyobject.

•Ifthemachinestrikesanobjectorstartstovibrate,

immediatelyshutofftheengine,removethekey
(ifequipped),disconnectthewirefromthespark
plug,andexaminethemachinefordamage.

•Forbestperformance,installanewbladebefore

thecuttingseasonbegins.

•ReplacethebladewhennecessarywithaToro

replacementblade.

•Wetgrassandleavestendtoclumpontheyard

andcancausethemachinetoplugortheengine
tostall.Avoidmowinginwetconditions.

•Beawareofapotentialrehazardinverydry

conditions,followalllocalrewarnings,andkeep
themachinefreeofdrygrassandleafdebris.

•Alternatethemowingdirection.Thishelps

dispersetheclippingsoverthelawnforeven
fertilization.

•Ifthenishedlawnappearanceisunsatisfactory,

try1ormoreofthefollowing:

–Replacethebladeorhaveitsharpened.
–Walkataslowerpacewhilemowing.
–Raisethecuttingheightonyourmachine.
–Cutthegrassmorefrequently.
–Overlapcuttingswathsinsteadofcuttingafull

swathwitheachpass.

CuttingGrass

•Cutonlyaboutathirdofthegrassbladeatatime.

Donotcutbelow51mm(2inches)unlessthe
grassissparseoritislatefallwhengrassgrowth
beginstoslowdown.

•Whencuttinggrassover15cm(6inches)tall,

mowatthehighestcuttingheightsettingandwalk
slower;thenmowagainatalowersettingforthe
bestlawnappearance.Ifthegrassistoolong,the
machinemayplugandcausetheenginetostall.

CuttingLeaves

•Aftercuttingthelawn,ensurethathalfofthelawn

showsthroughthecutleafcover.Y oumayneed
tomakemorethanasinglepassovertheleaves.

•Iftherearemorethan13cm(5inches)ofleaves

onthelawn,mowatahighercuttingheightand
thenagainatthedesiredcuttingheight.

•Slowdownyourmowingspeedifthemachine

doesnotcuttheleavesnelyenough.

14

AfterOperation

AfterOperationSafety

GeneralSafety

•Cleangrassanddebrisfromthemachinetohelp

preventres.Cleanupoilorfuelspills.

•Allowtheenginetocoolbeforestoringthemachine

inanyenclosure.

•Neverstorethemachineorfuelcontainerwhere

thereisanopename,spark,orpilotlight,such
asonawaterheateroronotherappliances.

HaulingSafety

•Removetheignitionkey(ifequipped)before

loadingthemachineforhauling.

•Usecarewhenloadingorunloadingthemachine.

•Securethemachinefromrolling.

CleaningundertheMachine

ServiceInterval:Beforeeachuseordaily

g033492

Figure18

1.Washoutport

6.Turnthewateron.

7.Starttheengineandrunituntiltheclippingsno
longercomeoutfromunderthemachine.

8.Shutofftheengine.

9.Shutoffthewateranddisconnectthegarden
hosefromthemachine.

10.Starttheengineandrunitforafewminutesto
drytheundersideofthemachinetopreventit
fromrusting.

11.Shutofftheengineandallowittocoolbefore
storingthemachineinanenclosedarea.

Forbestresults,cleanthemachinesoonafteryou
havecompletedmowing.

1.Movethemachineontoaatpavedsurface.

2.Shutofftheengineandwaitforallmovingparts
tostopbeforeleavingtheoperatingposition.

3.Lowerthemachinetoitslowestcutting-height
setting.RefertoAdjustingtheCuttingHeight

(page10).

4.Washouttheareaunderthereardoorwherethe
clippingsgofromtheundersideofthemachine
tothegrassbag.

Note:Washouttheareawiththe

bag-on-demand(ifequipped)inboththefully
forwardandfullyrearwardpositions.

5.Attachagardenhosethatisconnectedtoa
watersupplytothewashoutport(Figure18).

FoldingtheHandle

WARNING

Foldingorunfoldingthehandleimproperly
candamagethecables,causinganunsafe
operatingcondition.

•Donotdamagethecableswhenfoldingor
unfoldingthehandle.

•Ifacableisdamaged,contactan
AuthorizedServiceDealer.

1.Removeandsavethe2handleknobsand2
carriageboltsfromthehandlebrackets(Figure

19).

Important:Routethecablestotheoutside

ofthehandleknobsasyoufoldthehandle.

15

1.Handleknob

Figure19

2.Carriagebolt

g032869

1.Handleknob

Figure21

2.Carriagebolt

g032865

2.Foldthehandlebyrotatingitforward(Figure20).

Figure20

1.Operatingposition

2.Foldedposition

3.Insertthecarriagebolt(withtheboltheadtoward
theinside)throughthehandlebracketandthe
upperholeinthehandleend.Ensurethatthe
squareedgesofeachcarriagebolttsintothe
upperorlowersquareholeinitsrelatedhandle
bracket(Figure21).

4.Looselyinstallthehandleknobsandcarriage
boltsonthehandlebrackets.

5.Tounfoldthehandle,referto1Assemblingand

UnfoldingtheHandle(page5).

g032870

16

Maintenance

RecommendedMaintenanceSchedule(s)

MaintenanceService

Interval

Beforeeachuseordaily

Every25hours

Yearly

Yearlyorbeforestorage

MaintenanceProcedure

•Checktheengine-oillevelandaddoilasneeded.

•Ensurethattheengineshutsoffwithin3secondsafterreleasingtheblade-control
bar.

•Cleangrassclippingsanddirtfromunderthemachine.

•Servicetheairlter;serviceitmorefrequentlyindustyoperatingconditions.

•Replacetheairlter;replaceitmorefrequentlyindustyoperatingconditions.

•Changetheengineoil.

•Replacethebladeorhaveitsharpened(morefrequentlyiftheedgedullsquickly).

•Cleantheenginebyremovingdirtanddebrisfromitstopandsides;cleanitmore
frequentlyindustyoperatingconditions.

•Emptythefueltankbeforerepairsasdirectedandbeforeyearlystorage.

Important:Refertoyourengineowner’smanualforadditionalmaintenanceprocedures.

MaintenanceSafety

•Disconnectthespark-plugwirefromthesparkplug

beforeperforminganymaintenanceprocedure.

•Wearglovesandeyeprotectionwhenservicing

themachine.

•Thebladeissharp;contactingthebladecanresult

inseriouspersonalinjury .Weargloveswhen
servicingtheblade.Donotrepairoralterthe
blade(s).

•Nevertamperwithsafetydevices.Checktheir

properoperationregularly .

•Tippingthemachinemaycausethefueltoleak.

Fuelisammableandexplosive,andcancause
personalinjury.Runtheenginedryorremovethe
fuelwithahandpump;neversiphonthefuel.

•Toensureoptimumperformanceandcontinued

safetycerticationofthemachine,useonly
genuineTororeplacementpartsandaccessories.
Replacementpartsandaccessoriesmadeby
othermanufacturerscouldbedangerous,and
suchusecouldvoidtheproductwarranty .

PreparingforMaintenance

1.Shutofftheengineandwaitforallmovingparts
tostop.

2.Disconnectthespark-plugwirefromthespark
plug(Figure22).

g032617

Figure22

3.Afterperformingthemaintenanceprocedure(s),
connectthespark-plugwiretothesparkplug.

Important:Beforetippingthemachineto

changetheoilorreplacetheblade,allowthe
fueltanktorundrythroughnormalusage.If
youmusttipthemachinepriortorunning
outoffuel,useahandfuelpumptoremove
thefuel.Alwaystipthemachineontoits
side,withthedipstickdown.

ServicingtheAirFilter

ServiceInterval:Every25hours

Yearly

1.Unclipthetopoftheair-ltercover(Figure23).

17

Figure23

1.Clip3.Airlter

2.Air-ltercover

3.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure24).

g031274

Figure24

1.Dipstick3.Full

2.Add

g033493

4.Tipthemachineontoitsside(sothattheair
lterisup)todraintheusedoilfromtheoil-ll
tube(Figure25).

2.Removetheairlter(Figure23).

3.Inspecttheairlter.

Note:Iftheairlterisexcessivelydirty,replace

itwithanewlter.Otherwise,gentlytaptheair
lteronahardsurfacetoloosendebris.

4.Installtheairlter.

5.Usethecliptoinstalltheair-ltercover.

ChangingtheEngineOil

ServiceInterval:Yearly

Changingtheengineoilisnotrequired,butif
youwanttochangetheoil,usethefollowing
procedure.

Note:Runtheengineafewminutesbeforechanging

theoiltowarmit.Warmoilowsbetterandcarries
morecontaminants.

EngineOilSpecications

Engineoilcapacity

OilviscositySAE30orSAE10W-30

APIserviceclassicationSJorhigher

1.Movethemachinetoalevelsurface.

2.RefertoPreparingforMaintenance(page17).

0.44L(15oz)

detergentoil

g027457

Figure25

5.Afterdrainingtheusedoil,returnthemachineto
theoperatingposition.

6.Carefullypourabout3/4oftheenginecapacity
ofoilintotheoil-lltube.

7.Wait3minutesfortheoiltosettleintheengine.

8.Wipethedipstickcleanwithacleancloth.

9.Insertthedipstickintotheoil-lltube,then
removethedipstick.

10.Readtheoillevelonthedipstick(Figure24).

•Iftheoillevelonthedipstickistoolow,

carefullypourasmallamountofoilintothe
oil-lltube,wait3minutes,andrepeatsteps

18

8through10untiltheoillevelonthedipstick

iscorrect.

4.Removetheblade,savingallmountinghardware
(Figure26).

•Iftheoillevelonthedipstickistoohigh,

draintheexcessoiluntiltheoillevelonthe
dipstickiscorrect.

Important:Iftheoillevelintheengineistoo

lowortoohighandyouruntheengine,you
maydamagetheengine.

11.Installthedipstickintotheoil-lltubesecurely.

12.Recycletheusedoilproperly.

ReplacingtheBlade

ServiceInterval:Yearly

Important:Youwillneedatorquewrenchto

installthebladeproperly.Ifyoudonothavea

torquewrenchorareuncomfortableperforming
thisprocedure,contactanAuthorizedService
Dealer.

Examinethebladewheneveryourunoutoffuel.Ifthe
bladeisdamagedorcracked,replaceitimmediately.
Ifthebladeedgeisdullornicked,haveitsharpened
andbalanced,orreplaceit.

WARNING

5.Installthenewbladeandallmountinghardware
(Figure27).

g231390

Figure27

Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.

Weargloveswhenservicingtheblade.

1.RefertoPreparingforMaintenance(page17).

2.Tipthemachineontoitssidewiththeairlterup.

3.Useablockofwoodtoholdthebladesteady
(Figure26).

Important:Positionthecurvedendsofthe

bladetopointtowardthemachinehousing.

6.Useatorquewrenchtotightenthebladebolt
to82N∙m(60ft-lb).

Important:Abolttorquedto82N∙m(60

ft-lb)isverytight.Whileholdingtheblade
withablockofwood,putyourweight
behindtheratchetorwrenchandtightenthe
boltsecurely.Thisboltisverydifcultto
overtighten.

Figure26

g231389

19

AdjustingtheSelf-Propel

Storage

Drive

Wheneveryouinstallanewself-propelcableorif
theself-propeldriveisoutofadjustment,adjustthe
self-propeldrive.

1.Turntheadjustmentknobcounterclockwiseto
loosenthecableadjustment(Figure28).

Figure28

Storethemachineinacool,clean,dryplace.

PreparingtheMachinefor Storage

1.Onthelastrefuelingoftheyear,addfuel
stabilizer(suchasToroPremiumFuel
Treatment)tothefuelasdirectedonthelabel.

2.Disposeofanyunusedfuelproperly .Recycle
itaccordingtolocalcodesoruseitinyour
automobile.

Note:Oldfuelinthefueltankistheleading

causeofhardstarting.Donotstorefuelwithout
fuelstabilizermorethan30days,anddonot
storestabilizedfuelmorethan90days.

3.Runthemachineuntiltheengineshutsofffrom
runningoutoffuel.

4.Starttheengineagainandallowittorununtil

g027231

itshutsoff.Whenyoucannolongerstartthe
engine,itissufcientlydry.

1.Handle(leftside)

2.Adjustmentknob5.Turntheknob

3.Self-propel-drivecable

2.Adjustthetensiononthecable(Figure28)by
pullingitbackorpushingitforwardandholding
thatposition.

4.Turntheknobclockwiseto
tightentheadjustment.

counterclockwiseto
loosentheadjustment.

Note:Pushthecabletowardtheengineto

increasethetraction;pullthecableawayfrom
theenginetodecreasethetraction.

3.Turntheadjustmentknobclockwisetotighten
thecableadjustment.

Note:Tightentheknobrmlybyhand.

5.Disconnectthewirefromthesparkplugand
connectthewiretotheretainingpost(if
equipped).

6.Removethesparkplug,add30ml(1oz)of
engineoilthroughthespark-plughole,andpull
thestarterropeslowlyseveraltimestodistribute
oilthroughoutthecylindertopreventcylinder
corrosionduringtheoff-season.

7.Looselyinstallthesparkplug.

8.Tightenallnuts,bolts,andscrews.

RemovingtheMachine fromStorage

1.Checkandtightenallfasteners.

2.Removethesparkplugandspintheengine
rapidlybypullingtherecoil-starthandletoblow
theexcessoilfromthecylinder.

3.Installthesparkplugandtightenitwithatorque
wrenchto20N∙m(15ft-lb).

4.Performanymaintenanceprocedures;referto

Maintenance(page17).

5.Checktheengine-oillevel;refertoCheckingthe

Engine-OilLevel(page9).

6.Fillthefueltankwithfreshfuel;refertoFilling

theFuelT ank(page8).

7.Connectthewiretothesparkplug.

20
