Topcom BUTLER 920 User Manual 2
BUTLER 920
Important
To use ‘Caller ID’ (display caller), this service has to be activated on your
phone line. Normally you need a separate subscription from your telephone
company to activate this function. If you don’t have the Caller ID function on
your phoneline, the incoming telephone numbers will NOT be shown on the
display of your telephone.
Belangrijk
Om de ‘Nummerweergave’ te kunnen gebruiken, moet deze dienst geactiveerd zijn op uw telefoonlijn. Om deze dienst te activeren, hebt U hiervoor
meestal een apart abonnement van uw telefoonmaatschappij nodig. Indien U
geen nummerweergavefunctie hebt op uw telefoonlijn, zullen de inkomende
telefoonnummers NIET op de display van uw toestel verschijnen.
Important
Pour utiliser la fonction ‘Caller ID/Clip’ (affichage de l’appelant), ce service
doit être activé sur votre ligne téléphonique. Généralement, vous avez besoin
d’un abonnement séparé de votre compagnie de téléphone pour activer cette
fonction. Si vous n’avez pas la fonction ‘Caller ID - Affichage Appelant’ sur
votre ligne téléphonique, les numéros de téléphone entrants n’apparaîtront
PAS sur l’écran de votre téléphone.
User Guide / Handleiding / Manuel d’utilisateur
Bedienungsanleitung / Manuale d’uso
v 1.1
Wichtig
Zur Verwendung der ‘Rufnummernanzeige’ muss dieser Dienst erst für Ihre
Telefonleitung freigegeben werden. Zur Aktivierung dieser Dienstleistung
benötigen Sie meistens ein separates Abonnement Ihrer Telefongesell-
schaft.Wenn Sie für Ihre Telefonleitung keine Rufnummernanzeigefunktion
haben, erscheinen die eingehenden Telefonnummern NICHT im Display
Ihres Gerätes.
Importante
Per utilizzare la funzione „Caller ID" (visualizzazione chiamante), è necessa-
rio che questo servizio sia attivato sulla propria linea telefonica. General-
mente, è necessario sottoscrivere un abbonamento separato con la propria
società telefonica, per poter attivare questa funzione. Se la propria linea telefonica non è dotata della funzione „Caller ID", i numeri telefonici delle chiamate in arrivo NON verranno visualizzati sul display del proprio telefono. In
caso di chiamata entrante, suona soltanto il ricevitore e non la base.
7
4
2
5
8
3
6
9
1
ABC
DEF
GHI
JKL
MNO
PQRS
TUV
WXYZ
0
INT
R
1
2
3
4
5
6
78
9
12
11
10
15
13
14
Butler 920
This product is in compliance with the essential requirements and other
relevant provisions of the R&TTE directive 1999/5/EC.
The Declaration of conformity can be found on:
http://www.topcom.net/support/cedeclarations.php
UK To be connected to the public analogue telephone network.
NL Geschikt voor aansluiting op het openbare analoog geschakelde
telefoonnetwerk.
FR Il est destiné à être raccordé au réseau de télécommunication
public.
DE Kompatibel für den analogen telefonanschluss.
IT Destinato ad essere collegato alla rete telefonica analogica
pubblica.
UK The features described in this manual are published with
reservation to modifications.
NL De in deze handleiding beschreven mogelijkheden worden
gepubliceerd onder voorbehoud van wijzigingen.
FR Les possibilités décrites dans ce manuel sont publiées sous réserve
de modifications.
DE Die in dieser Bedienungsanleitung umschriebenen Möglichkeiten,
werden vorbehaltlich Änderungen publiziert.
IT Le caratteristiche descritte nel presente manuale vengono
pubblicate con riserva di modifica.
UK The CE symbol indicates that the unit complies with the essential
requirements of the R&TTE directive.
NL Het toestel voldoet aan de basiseisen van de R&TTE-richtlijn. Dit
wordt bevestigd door de CE-markering.
FR La conformité de l’appareil avec les exigences fondamentales de la
directive européenne R&TTE relative aux terminaux, est confirmée
par le label CE.
DE Die Übereinstimmung des Gerätes mit den grundlegenden
Anforderungen der R&TTE-Directive ist durch das CEKennzeichen bestätigt.
IT Il simbolo CE indica che l’unità è conforme ai requisiti
fondamentali della direttiva R&TTE.
