TOMTOM GO 540 User Manual

TomTom GO

What’s in the box1.

What’s in the box

aTomTom GO

AOn/Off button BMicrophone CLight sensor DSpeaker

EMemory card (micro SD card)

slot

bActive Dock cUSB car charger

dHome dock eDocumentation pack

Before you start2.

Before you start

Switching on and off

Install your TomTom GO navigation device in your car following the instructions in the installation section at the start of this book.

To switch on your navigation device, press and hold the On/Off button until you see the start-up screen. The first time you switch on your device, it may take a short time to start.

To set up your device you need to answer a few questions by tapping the screen.

Device not starting

In rare cases, your TomTom GO navigation device may not start correctly or may stop responding to your taps.

First, check that the battery is properly charged. To charge the battery, connect your device to the car charger. It can take up to 2 hours to fully charge the battery.

Battery notes

Active Dock

If this does not solve the problem, you can reset the device. To do this, press and hold the On/Off button for fifteen seconds and release the button when your device begins to restart.

The battery in your TomTom GO navigation device charges when you connect it to the car charger or to your computer.

The light next to the On/Off button is orange while the battery is charging and is green when the battery is fully charged.

When you connect your device to a computer, you are asked if you want to connect to the computer. If you select No and then do not tap the screen within three minutes, the device will automatically switch off. This happens so that the battery can charge faster.

Note: You should plug the USB connector directly into a USB port on your

computer and not into a USB hub or USB port on a keyboard or monitor.

Use the Active Dock to install your TomTom GO inside your car. Make sure that both the Active Dock and your windscreen are clean and dry

before you attach the holder. Place the Active Dock so that it does not interfere with your view of the road or of any of the controls in your car.

Home dock

GPS reception

To attach the Active Dock, press the suction cup firmly against the windscreen on an area where the glass is flat. Then twist the rubber grip near the base of the Active Dock in a clockwise direction until you hear a click.

The Home dock is used for charging your TomTom GO when it is not in the car and for connecting your GO to your computer.

When connected to your computer, you can use TomTom HOME to manage your GO.

When you first start your TomTom GO navigation device, the device may need a few minutes to determine your GPS position and show your current position on the map. In future, your position will be found much faster, usually within a few seconds.

To ensure reception of a strong GPS signal, you should use your device outdoors. Large objects such as tall buildings can sometimes interfere with reception.

The TomTom GO 940 includes Enhanced Positioning Technology or EPT. EPT is automatically used to estimate your location when the GPS signal is lost while you are driving, such as when you are driving through a tunnel. When EPT is being used, an icon is shown on the Status bar.

Safety Notice

Your TomTom GO contains a GSM/GPRS module which can interfere with electrical devices such as cardiac pacemakers, hearing aids and aviation equipment.

Interference with these devices may endanger the health or life of others. Do not use near unprotected electrical units nor in areas where the use of

mobile telephones is prohibited, such as hospitals and airplanes.

Take care of your device

Never leave your TomTom GO navigation device or accessories on view when you leave the car or they may become an easy target for thieves.

You can set a password for your device which must be entered every time you start it.

It is important to take care of your device.

• Your device is not designed for use in ext reme temperatures and any s uch exposure may cause permanent damage.

• Do not open the casing of your device under any circumstances. Doing so may be dangerous and will invalidate the warranty.

• Wipe or dry the screen of your device using a soft cloth. Do not use any liquid cleaners.

Safety3.

Safety

Positioning the dock

Consider carefully where to attach the dock in your car. The dock should not block or interfere in any way with the following:

• Your view of the road

• Any of the controls in your car

• Any of your mirrors

• The airbag

You should be able to reach your navigation device easily when it is in the dock without leaning or stretching. The diagrams show where you can safely attach the dock.

You can attach the dock to the windscreen, side window or use a Dashboard Mount Disk to attach the dock to your dashboard. TomTom also offers alternative mounting solutions for your TomTom navigation device. For more information about Dashboard Mount Disks and alternative mounting solutions, go to www.tomtom.com/accessories.

Installing the Active Dock

Make sure that both the Active Dock and your window are clean and dry.

1. Press the suction cup firmly against the window on an area where the glass is flat.

2. Twist the rubber grip near the base of the Active Dock in a clockwise direction until you hear a click.

The Active Dock is now installed.

Safety preferences

We recommend using the safety preferences to make your driving as safe as possible. The safety preferences include, for example, the following options:

• Hide most menu options when driving

• Show safety reminders

• Warn when driving faster than allowed

You can also drive more safely by using voice commands to control your TomTom GO.

Making your first journey4.

Making your first journey

Planning a route with your TomTom GO navigation device is easy. To plan a route, follow the steps below.

Important: For safety reasons, you should always plan a route before you

start your journey.

1. Tap the screen to bring up the Main Menu.

Note: The buttons on your navigation device are shown in full colour unless a button is currently unavailable. For example, the button named Find alternative in the Main Menu is not available until you have planned a route.

2. Tap Navigate to...

3. Tap Address.

When you enter an address, you can choose from the following options:

• City centre - tap this button to set your destination as the centre of a city

or town.

• Street and house number - tap this button to set an exact address as your

destination.

• Postcode - tap this button to enter a postcode as your destination.

Note: You can enter a postcode for any country. In the UK and the Netherlands, postcodes are detailed enough to identify a house on their own. In other countries you can enter a postcode to identify a town or area. You will then have to enter a street and house number.

• Crossing or intersection - tap this button to set your destination as the

point where two streets meet.

• Spoken address - tap this button to set your destination by saying the

address to your navigation device.

In this example, we will enter an exact address.

4. Tap Street and house number.

Note: When planning a trip for the first time your navigation device asks you to choose a state or country. Your choice is saved and used for all routes you plan.

You can change this setting at any time by tapping the flag.

5. Start to type the name of the town where you want to go.

As you type, the names of the towns that match what you have typed are shown. When your destination appears in the list, tap the name of the town to set the destination.

Tip: Instead of typing the name, tap this button to say the address by

speaking to your navigation device.

6. Start to type the street name and tap on the street when it appears in the list. As with the name of the town, the names of the streets that match what you

have typed are shown. When your destination appears in the list, tap the name of the street to set the destination.

7. Enter the house number and then tap Done.

8. Your navigation device asks if you need to arrive at a particular time. For this exercise, tap NO.

The route is calculated by your device using IQ RoutesTM. IQ Routes is used to plan the best possible route taking into account the real

average speeds measured on the roads.

9. When the route has been calculated, tap Done.

Your TomTom GO navigation device will warn you about any traffic delays and immediately begin to guide you to your destination, using both spoken instructions and on-screen directions.

Using your voice to plan a route

Instead of tapping the screen you plan a route, you can use your voice to plan a route.

For information about the different ways you can plan a route using your voice, see Voice control.

Arrival times

When you plan a route, your TomTom GO asks you if you need to arrive at a particular time.

Tap YES to enter a preferred arrival time. Your GO calculates your arrival time and shows you whether you will arrive

on time. You can also use this information to work out when you need to leave. If your

GO shows that you will arrive 30 minutes early, you can wait and leave in 30 minutes time, rather than arrive early.

Your arrival time is constantly recalculated during your journey. The status bar shows whether you will arrive on time or if you are going to be late, as shown below:

You will arrive 55 minutes before the arrival time you entered. If the estimated arrival time is more than five minutes before

the time you entered, it is shown in green. You will arrive 3 minutes before the arrival time you entered.

If the estimated arrival time is less than 5 minutes before the time you entered, it is shown in yellow.

You will arrive 19 minutes late. If the estimated arrival time is later than the time you entered,

it is shown in red.

Tap Status bar preferences in the Preferences menu, to enable or disable arrival time notifications.

Status bar

preferences

Select the required options on the first menu screen and then tap Done. To enable arrival time notifications, select Show leeway to arrival time.

Other navigation options

When you tap Navigate to..., you can set your destination in many ways, not just by entering the address. The other options are listed below:

Tap this button to use TomTom Local Search with Google search to help you find shops and businesses in and around your current location.

Local search

Home

You can choose to search for shops and businesses near you, near your destination, near any other destination or in a city.

For example, if you are looking for a swimming pool near your current location, enter ’swimming pool’ and choose the best search result.

Tap this button to navigate to your Home location. You will probably use this button more than any other.

Tap this button to select a Favourite as your destination.

Favourite

Address

Recent

destination

Point of Interest

Point on map

Tap this button to enter an address as your destination.

Tap this button to select your destination from a list of places you have recently used as destinations.

Tap this button to navigate to a Point of Interest (POI).

Tap this button to select a point on the map as your destination using the map browser.

Tap this button to enter a destination using latitude and longitude values.

Latitude

Longitude

Tap this button to navigate to the last known position of a TomTom Buddy. Don’t forget that the Buddy may move before you reach him.

TomTom

Buddy

Tap this button to select your last recorded position, as your destination.

Position of

last stop

Planning a route in advance

You can use your GO to plan a route in advance, selecting your start ing poin t and your destination.

Here are some more reasons to plan a route in advance:

• Find out how long a journey is going to take before you start. You can also compare journey times for the same route at different times of

the day or on different days of the week. Your TomTom GO uses IQ Routes when planning a route. IQ Routes calculates routes based on the real average speeds measured on roads.

• Study the route of a journey you are planning.

Prepare route

• Check a route for someone who is coming to visit you and then explain the route to them in detail.

To plan a route in advance, follow these steps:

1. Tap the screen to bring up the main menu.

2. Tap the arrow button to move to the next menu screen and tap Prepare route.

3. Select the starting point for your journey in the same way that you would select your destination.

4. Set the destination for your journey.

5. Choose the type of route that should be planned.

• Fastest route - the route which takes the least time.

• Shortest route - the shortest distance between the locations you set. This

may not be the quickest route, especially if the shortest route is through a town or city.

• Avoid motorways - a route which avoids motorways.

• Walking route - a route designed for making the journey on foot.

• Bicycle route - a route designed for making the journey on a bicycle.

• Limited speed - a route for a vehicle which can only be driven at a limited

speed. You have to specify the maximum speed.

6. Choose when you will make the journey you are planning. There are three options:

• Now

• Specific date and time - you will be asked to enter the date and time.

• No specific date and time If you select either Now or Specific date and time, your GO uses IQ Routes

to work out the best possible route at that time, using the real average speeds measured on roads. In this way you can compare how long a journey takes at different times of day, or on different days of the week.

7. Your TomTom GO plans the route between the two locations you selected.

More information about a route

You can access these options for the route you last planned by tapping View route in the Main Menu or the Details button on the route summary screen.

You can then select from the following options:

Tap this button for a list of all the turn instructions on the route. This is very useful if you need to explain a route to someone else.

Browse as

text

Tap this button to see each turn in the journey. Tap the right and left arrows to move forwards and backwards through the journey.

Browse as

images

Browse map

of route

Show route

summary

View route

Tap the screen to turn off the 3D display and view the map from above.

Tap this button to see an overview of the route using the map browser.

Tap this button to open the route summary screen.

Tap this button to see your route.

Voice control5.

Voice control

Instead of tapping the screen to control your TomTom GO, you can now give instructions to your GO using your voice.

For example, to increase the volume on your GO, you can say, "Increase volume."

Important: To use voice control, you must have a computer voice installed on

your TomTom GO. If you don’t have a computer voice installed, use TomTom HOME to install one.

To view the list of available commands, tap Voice Control preferences in the Preferences menu and then tap What can I say?

Using voice control

Note: You must select a computer voice in order to use voice control. To select a computer voice, tap Change preferences in the Main menu. Then tap Voice preferences and Change voice. Select a computer voice.

In this example, you will use voice control to plan a journey to your Home address.

1. Tap the voice control button in the Driving View.

Note: To add or remove this button from the Driving View, tap Voice control preferences in the Preferences menu and then tap Enable voice control or Disable voice control.

The voice control monitor is shown in colour, unless voice control is busy with another task.

2. When you hear a beep, say, "Navigate to Home." When you speak, the voice control monitor shows if you are talking too

loudly or quietly:

A green bar means your voice is at the right level for your GO to hear your commands.

A red bar means your voice is too loud.

A grey bar means your voice is too quiet.

For some phrases, your GO will always repeat the command and then ask you if the command has been correctly recognised.

3. If the command is correct, say, "Yes." If the command is incorrect, say, "No" and when prompted, say the

command again after the beep .

Your GO plans a route from your current position to your Home address.

Tips

• Voice control switches off after a few seconds if you don’t say anything. For example, if your GO asks you to confirm the last command you gave and you don’t say anything, voice control switches off after a few seconds.

• You can stop your GO from listening for commands either by tapping the screen or by saying any of the following commands: Back, Cancel, Quit.

• To select an item from a list, tap the screen to select the ite m. Voice control cannot be used to select items from a list.

Planning a journey using your voice

Important: You should always plan your journey before you start driving. It is

dangerous to plan a route while driving.

To plan a route to an address using speech, do the following:

1. Tap the voice control button in the Driving View.

2. When you hear a beep, say, "Navigate to address." When you speak, the voice control monitor shows if you are

talking too loudly or quietly:

A green bar means your voice is at the right level for your GO to hear your commands.

A red bar means your voice is too loud.

A grey bar means your voice is too quiet.

For some phrases, your GO will always repeat the command and then ask you if the command has been correctly recognised.

You can now enter an address using speech.

Alternatively, you can tap the screen to start planning a journey, then tap Spoken address (dialogue) or Spoken address to start entering an address by voice.

3. Say the city name.

When you say the city name, you are then shown a list of six names that match what you said.

Your GO tells you the name at the top of the list. If the name you hear is correct, then say, "Done" or "OK" or "Yes" or "One" or tap on the name.

If the city name you hear is not correct, but the name appears in the list, then say the number next to the correct name or tap on the correct name.

For example, if the correct name is Rotterdam and this name is number two in the list, you could say, "Two" or tap on the name, Rotterdam.

If the city name is not shown in the list, then say "Back" or "No" or tap the Back button to return to the previous screen. Then say the city name again.

Note: You need to say numbers in the same language that is used for menu buttons.

4. Say the street name. Your GO states the name shown at the top of the list. If the name you hear

is correct, then say, "Done" or "OK" or "Yes" or "One" or tap on the name.

Note: Different locations may have similar names, such as a road that has multiple postcode locations. In such cases, all of these locations are shown in the list and you need to look at the screen and select the correct location.

If the name you hear is incorrect but the correct name is shown in the list, then say the number next to the correct name or tap on the streetname.

If the streetname is not shown in the list, say "Back" or "No" or tap the Back button to return to the previous screen. Then say the street name again.

5. Say the house number.

Numbers should be pronounced normally. For example, you would say the number 357 as one continuous sentence, "Three hundred and fifty seven."

If the number is shown incorrectly, say, "Back" or "No" or tap the Backspace key. Then say the number again.

Tip: If you say, "Back" when there are no numbers shown on the screen, then

your GO will return you to the previous screen.

When the number is shown correctly say, "Done" or "OK." Alternatively, enter the number by tapping the screen.

To select a crossroads as the location, say, "Crossing".

Note: You need to say numbers in the same language that is used for menu buttons.

6. Your GO asks if you need to arrive at a particular time. For this exercise, tap NO.

The route is calculated by your GO.

7. When the route has been calculated, tap Done.

Voice address input

Important: You should always plan your journey before you start driving. It is

dangerous to plan a route while driving.

If you don’t use voice control to start planning a journey, you can still enter an address using speech.

To start planning a journey, tap Navigate to... in the Main Menu, then tap Address.

To enter your destination using your voice, tap one of these buttons:

Tap this button to enter an address using only speech. Using this option, your GO can recognise the following:

Spoken

address

(dialogue)

• Commands: Yes, No, Back, Done, OK, Crossing.

• Street names.

•Place names.

• Numbers: Numbers should be pronounced as individual numerals. For example, to say the number 35, say, "Three" and then say, "Five."

Using Spoken address (dialogue), you can enter information without tapping the screen.

Spoken

address

Tap this button to enter an address using both speech and by tapping the screen. Using this option your GO can recognise the following:

• Street names.

•Place names.

Using Spoken address is typically faster than using Spoken address (dialogue).

You can use speech to enter destinations wherever you see this button. You can use speech to enter these types of destination:

• City centre - to say the centre of a city or town, tap the speech button at the bottom of the keyboard.

• Street and house number - to say an address, tap the speech button at the bottom of the keyboard.

• Crossing or intersection - to say the point where two streets meet, tap the speech button at the bottom of the keyboard.

When this button is shown in grey, you cannot use speech to enter an address.

Note: Postcode address entry is not possible using speech.

Your GO recognises place and street names spoken using the local language and pronunciation.

It is not possible to use voice address input to say place and street names in all countries.

Driving View6.

Driving View

When your TomTom GO starts, you are shown the Driving View along with detailed information about your current location.

Tap the centre of the screen at any time to open the Main Menu.

Note: The Driving View is shown in black and white until your GO locates your current position.

ATap + and - to zoom in and out. BQuick menu - switch this on in the Preferences menu. CYour current position. DThe name of the next major road or road sign information, if applicable.

The name of the next major road, road sign information, if applicable, or the next street name, if enabled.

ETraffic sidebar. FVoice control button . GNavigation instruction for the road ahead.

Tap this area to repeat the last spoken instruction and to change the volume.

HThe name of the street you are on. IInformation about your journey such as journey time, remaining distance

and arrival time. To change the information shown, tap Status bar preferences in the

Preferences menu.

JGPS signal strength.

Advanced Lane Guidance7.

Advanced Lane Guidance

Your TomTom GO helps you prepare for motorway exits and junctions by showing you which lane you should be in.

Note: This information is not available for all junctions or in all countries.

For some exits and junctions, an image shows the turn and the lane you should take.

To turn the images off, tap Hide lane images in the Preferences menu. For other exits and junctions, your GO shows the lane you should take in the

Status bar. To turn this guidance off, tap Change preferences in the Main Menu, then tap Status bar preferences. Clear the checkbox for Show lane guidance.

Finding alternative routes8.

Finding alternative routes

Once you have planned a route, you may want to change something about the route, without changing your destination.

Why change the route?

Maybe for one of these reasons:

• You can see a roadblock or a line of traffic ahead.

• You want to travel via a particular location, to pick someone up, stop for lunch or fill up with petrol.

• You want to avoid a difficult junction or a road you don’t like.

Tap Find alternative... in the Main Menu to change the route that is currently planned.

Find alterna-

tive...

Calculate

alternative

The Find alternative... button is also shown in the route summary screen after you plan a route.

Tap this button to calculate an alternative to the route already planned. Your GO will look for another route from your current location to your

destination. If you decide you would prefer to use the original route after all, tap

Recalculate original.

Avoid

roadblock

Why would I need to do this?

Apart from the roads near your position and near your destination, the new route will use totally different roads to reach your destination. This is an easy way of calculating a totally different route.

Tap this button if you can see a roadblock or a line of traffic ahead. Y o u then have to choose how much of the route ahead you want to avoid.

Choose from the different options: 100m, 500m, 2000m, 5000m. Your GO will recalculate your route avoiding the section of the route for the distan ce you selected.

Don’t forget that once a new route is calculated, you may have to turn off the road you are on very soon.

If the roadblock suddenly clears, tap Recalculate original to return to your original route.

Travel via...

Recalculate

original

Avoid part of

route

Tap this button to change your route so that it passes a particular location, perhaps to pick someone up on the way. When you do this, a marker is shown on the map for the location you choose the travel via.

You choose the location you want to pass in the same way as you choose a destination. So you can select from all the same options: for example, Address, Favourite, Point of Interest and Point on map.

Your GO will calculate a new route to your destination that passes the location you chose. Unlike your final destination, your GO does not inform you when you pass by this location.

Using this button, you can only travel via one location. If you want to pass more than one, use an Itinerary.

Tap this button to return to the original route without deviations to avoid roadblocks or travelling via particular locations.

Tap this button to avoid a part of the route. Use this button if you see that your route includes a road or junction you don’t like, or which is wellknown for traffic problems.

You then choose the road you want to avoid from a list of the roads on your route.

Minimise

delays

Tap this button to recalculate your route so that it avoids traffic problems as much as possible. Your GO will check if there are any traffic problems on your route and work out the best route to avoid the problems.

Note: This button is only available with TomTom Traffic enabled.

Browse Map9.

Browse Map

To look at the map in the same way as you might look at a traditional paper map, tap Browse map in the Main Menu.

You can move the map by touching the screen and moving your finger across the screen.

AThe scale bar BGPS button

Tap this button to centre the map on your current position.

COptions DThe cursor

Options

EThe Find button

Tap this button to find specific addresses.

FThe Cursor button

Tap this button to navigate to the cursor position, make a Favourite of the cursor position, or find a Point of Interest near the cursor position.

GThe zoom bar

Zoom in and out by moving the slider.

Tap the Options button to set the information shown on the map. You can choose to show the following information:

• Points of interest. Tap POI below the list of options to select which POIs are shown.

• Favourites

• Traffic

• Images

• Names

• Coordinates

10.

TomTom Map Share

With TomTom Map Share, you can correct errors on your map and share those corrections with other people in the TomTom Map Share community, as well as receiving corrections made by others.

If you find a street that has recently been blocked to traffic which was open before, you can use Map Share to correct your map and then share the correction with other Map Share members.

You can use Map Share to send and receive map corrections during the first year after the map’s release date. This means that one year after the release date, you will no longer be able to send or receive map corrections for that version of the map - You will still be able to make corrections to your own map for use on your own device.

You choose the type of corrections you want and each time you connect your TomTom GO to TomTom HOME, the map is automatically updated.

Note: TomTom Map Share is not available in all regions. For more information, go to tomtom.com/mapshare

Map corrections

There are two types of map correction:

• Corrections that are immediately shown on the map. These include,

• Corrections that are reported to TomTom but not shown immediately on

This type of correction is investigated by TomTom and once verified, is included in the next map release. These corrections are therefore not shared with the Map Share community.

changing the traffic flow of a street, blocking or renaming a street and adding or editing POIs.

This type of change is immediately shown on your own map. You can h ide these corrections at any time in the Map Share preferences menu.

your map. These include, missing streets, errors in motorway entrances and exits and missing roundabouts.

Tip: If you cannot see the Map corrections button in the Main Menu, tap Show

ALL menu options in the Preferences menu.

Making a map correction

Important: For safety reasons, you should only mark a location when you are

driving. Do not enter the full details of an error while you are driving.

1. Tap Map corrections in the Main Menu.

2. Tap Correct a map error.

Correct a map

error

A list of possible map corrections is shown.

3. Select the type of correction you want to report.

Note: If you tap Add missing POI or Report other error you will be asked for some additional information before the next step.

4. Select the method you want to use for selecting the location of the correction.

5. When you have found the location, tap Done.

6. Enter correction or confirmation of correction now.

Receiving the latest map updates

When you connect your TomTom GO to your computer, TomTom HOME automatically downloads any available map corrections and sends any changes you have made, to the Map Share community.

There are several types of corrections which can be set in the Correction preferences menu.

Marking a map error while on the move

Important: For safety reasons, you should only mark a location when you are

driving. Do not enter the full details of an error while you are driving.

If you notice an item on your map that needs attention, you can mark the location using the Report button and then enter the details when you are no longer driving.

To show the Report button in the Driving View or in the quick menu, do the following:

1. Tap Map corrections in the Main Menu.

Tip: If you cannot see the Map corrections button in the Main Menu, tap Show

ALL menu options in the Preferences menu.

2. Tap Correction preferences.

3. Tap Done and then tap Done again.

4. Select Show report button, then tap Done.

The Report button is shown on the left-hand side of the Driving View. After you mark a location, you can add more information about the change when you open the Map corrections menu.

For example, you are driving to a friend's house and you notice that the name of the street you are on is different from the one on your map. To report the change, tap the Report button and your GO will save your current location. You can then send the correction to TomTom Map Share when you have finished your journey.

TomTom Map Share community

To join the Map Share community, do the following:

1. Tap Map corrections in the Main Menu.

Tip: If you cannot see the Map corrections button in the Main Menu, tap Show

ALL menu options in the Preferences menu.

2. Tap Download corrections made by others.

3. Tap Join. When you connect your GO to your computer, TomTom HOME downloads

new corrections and sends your corrections to the Map Share community.

Important: TomTom Map Share corrections are not sent to your navigation

device using a wireless connection. You should regularly connect your device to your computer and use TomTom HOME to check for new updates.

Correction preferences

The correction preferences set the way TomTom Map Share works on your device.

You can set the following preferences:

• Use the trust level slider to choose the types corrections from the Map Share community you want to use on your maps.

• Decide if you want to share your corrections with others.

• Show or hide the report button in the Driving View.

To set your preferences, Map corrections in the Main Menu.

Tip: If you later decide you want to remove corrections from the map, clear

the checkbox next to the types of correction you want to remove. If you clear all the checkboxes, your map returns to the original state before the first correction.

Trust slider

Use the Trust level slider to set the type of map corrections you want added to your map. To do this, tap Correction preferences in the Map corrections menu.

There are four levels of trust that you can choose. The level changes when you move the slider:

• TomTom - only accept changes made by TomTom.

• Trusted sources - accept changes made by TomTom and by trusted users who have been verified by TomTom.

• Many users - accept changes made by TomTom, by trusted users who have been verified by TomTom and changes made by a high number of Map Share community members.

• Some users - accept changes made by TomTom, by trusted users who have been verified by TomTom and all changes that have been made by Map Share community members.

Types of map correction

There are several types of correction that you can make to a map.

To make a correction to your map, tap Map corrections in the Main Menu then tap Correct a map error. The following types of corrections are shown.

Tap this button to block or unblock a street. You can block or unblock the street in one or both directions.

(Un)block

street

For example, to correct a street near to your current location, do the following:

1. Tap (Un)block street.

2. Tap Near you to sel ect a street near your current location. You can select a street by name, a street near your Home location or a street on the map.

3. Select the street or section of a street you want to correct by tapping it on the map.

The street you select is highlighted and the cursor shows the name of the street.

4. Tap Done. Your device shows the street and whether the traffic is blocked or

allowed in each direction.

Reverse traffic

direction

5. Tap one of the direction buttons to block or unblock the flow of traffic in that direction.

6. Tap Done. The next time you connect your device to TomTom HOME, your

corrections are shared with the TomTom Map Share community.

Tap this button to correct the traffic direction of a one-way street, where the direction of traffic is different to the direction shown on your map.

Note: Reverse traffic direction only works for one-way streets. If you select a two-way street you will be given the chance to block/unblock the street rather than changing the direction.

Edit street

name

Change turn

restrictions

Tap this button to change the name of a street on your map. For example, to rename a street near to your current location:

1. Tap Edit street name.

2. Tap Near you.

3. Select the street or section of a street you want to correct by tapping it on the map.

The street you select is highlighted and the cursor shows the name of the street.

4. Tap Done.

5. Type the correct street name.

6. Tap Done.

Tap this button to change and report incorrect road turn directions.

Tap this button to change and report road speed limit.

Change road

speed

Add missing

POI

Tap this button to add a new Point of Interest (POI). For example to add a new restaurant near to your current location:

1. Tap Add missing POI.

2. Tap Restaurant in the list of POI categories.

3. Tap Near you.

4. Select the location of the missing restaurant. You can select the location by entering the address or by selecting the

location on the map. Select Near you or Near home to open the map at your current location or at your Home location.

5. Tap Done.

6. Type the name of the restaurant then tap OK.

7. If you know the telephone number of the restaurant you can type it, then tap OK.

If you don’t know the number, just tap OK without typing a number.

Edit POI

Report other

error

Tap this button to edit an existing POI. You can use this button to make the following changes to a POI:

• Delete the POI.

• Rename the POI.

• Change the telephone number of the POI.

• Change the category that a POI belongs to.

• Move the POI on the map.

Tap this button to report other types of corrections. These corrections are not immediately applied to your map. Your

TomTom GO sends a special report to TomTom Map Share. You can report missing streets, errors in motorway entrances and exits and

missing roundabouts. If the correction you want to report is not covered by any of these report types, enter a general description then tap Other.

+ 67 hidden pages
