Toastmaster 3A20D Installation Manual

HOT FOOD SERVERS

FREE STANDING MODELS

3A81D

3B82D, 3B84D

3C84D, 3D8XD

BUILT-IN MODELS

3A20A, 3A80A

3B20A, 3B80A,3B84A

3C80A, 3C84A

Installation and

3B84D

Operation

Instructions

2M-3102301, Rev. C, October 05, 2015

IL2087

3A20A

These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual

CAUTION WARNING

accompanying the appliance.

Using any part other than genuine Toastmaster factory supplied parts relieves the
manufacturer of all liability.

Toastmaster reserves the right to change specications and product design

without notice. Such revisions do not entitle the buyer to corresponding changes,
improvements, additions or replacements for previously purchased
equipment.

Due to periodic changes in designs, methods, procedures, policies and

regulations, the specications contained in this sheet are subject to change

without notice. While Toastmaster exercises good faith efforts to provide
information that is accurate, we are not responsible for errors or omissions
in information provided or conclusions reached as a result of using the

specications. By using the information provided, the user assumes all risks in

connection with such use.

SAFETY SYMBOLS

RETAIN THIS MANUAL FOR FUTURE REFERENCE

NOTICE

MAINTENANCE AND REPAIRS

Contact your local authorized service agent for service or required maintenance.
Please record the model number, serial number, voltage and purchase date in the area below and have it
ready when you call to ensure a faster service.

Authorized Service Agent Listing

Model No.

Serial No.

Voltage

Purchase Date

Reference the listing provided with the unit

or

for an updated listing go to:

Website: www.toastmastercorp.com
E-mail [e-mail]
Telephone: [phone]

The Service Help Desk

Business 8:00 am to 4:30 p.m. Central Standard Time
Hours:

Telephone: [phone]

Fax: [phone]

E-mail [e-mail]

Website: www.toastmastercorp.com

Mailing Address: Toastmaster

10 Sunnen Drive
St. Louis, MO 63143
U.S.A

2

2

TABLE OF CONTENTS

Page

Electrical Specications ................................ 1

Specications .......................................2

Features & Descriptions ...............................3

Accessories .........................................4

Installation

Inspection for Shipping Damage ....................4

Unpacking ..................................... 4

Installation of Free-Standing Models ................. 5

Installation of Built-In Units ........................6

Initial Start-up ................................... 7

Operation

Location of Controls .............................. 8

Function of Controls .............................. 8

Operation ...................................... 8

Shutdown ...................................... 9

Pre-heating ....................................9

Capacity Per Pan ................................ 9

Recommended Temp & Humidity Setting .............10

Daily Cleaning ................................ 10-11

Clean & Lubricate ...............................11

Warranty ...........................................13

Exploded View & Parts List

Single Drawer Units ............................ 14-16

Two, Three & Four Drawer, Single Controls ......... 18-21

Two, Three & Four Drawer, Individual Controls ....... 22-24

ELECTRICAL SPECIFICATIONS

ELECTRICAL SPECIFICATIONS

Model No Voltage Watts Phasee Hz Power Cord

7C-3A20AT09-120 3A20A 120 .45 KW 1 50/60
7C-3A80AT09-120 3A80A 120 .45 KW 1 50/60
7C-3A80AT72-240 3A80A 240 .4/.54 KW 1 50/60

7C-3A80AWC-120V 3A80A 120 .45 KW 1 50/60 5-15P
7C-3A81D-120KFC 3A81D-KFC 120 .45 KW 1 50/60
7C-3A81DT09-120 3A81D 120 .45 KW 1 50/60
7C-3A81DT72-240 3A81D 208/240 .45/.54 KW 1 50/60

7C-3B20AT09-120 3B20A 120 1.0 KW 1 50/60
7C-3B20AT72-240 3B20A 208/240 .9/1.2 KW 1 50/60
7C-3B80AT09-120 3B80A 120 1.0 KW 1 50/60
7C-3B80AT72-240 3B80A 208/240 .9/1.2 KW 1 50/60

7C-3B80AWC-120V 3B80A 120 1.0 KW 1 50/60 5-15P
7C-3B82DT09-CFA 3D82D 120V 1.0KW 1 50/60 5-15P

7C-3B84AT09-120 3B84A 120 .9 KW 1 50/60
7C-3B84AT72-240 / -SA 3B84A 208/240 .85/.98 KW 1 50/60

7C-3B84DT09-120 3B84D 120 .9 KW 1 50/60
7C-3B84DT09-KFC 3B84D-KFC 120 .9 KW 1 50/60
7C-3B84DT72-240 3B84D 208/240 .85/.98 KW 1 50/60

7C-3C80AT09-120 3C80A 120 1.35 KW 1 50/60
7C-3C80AT72-240 3C80A 208/240 1.22/1.6 KW 1 50/60
7C-3C84AT09-120 3C84A 120V
7C-3C84AT72-240 3C84D 208/240 1.28/1.47 KW 1 50/60

7C-3C84DT09-120 3C84D 120 1.35 KW 1 50/60
7C-3C84DT72-240 3B84D 208/240 .85/.98 KW 1 50/60
7C-3D8XDT09-120 3D8XD 120 1.35 KW 1 50/60
7C-3D8XDT72-240 3D8XD 208/240 1.22/1.6 KW 1 50/60

1

Width

SPECIFICATIONS

Top View

Depth

Height

Front View Side View

IL2088

MODEL CHART

Model

3A81D

3A20D 1 YES 18.8 26.2 24 1/16 22 9/16 12 1/4 84 lbs 94 lbs

3A21D 1 YES 18.8 26.2 24 1/16 22 9/16 12 1/4 84 lbs 94 lbs

3B22D 2 NO 17.2 24.8 23 1/16 24 1/4 22 1/8 129 lbs 144 lbs

3B82D 2 NO 18.8 26.2 29 1/16 20 5/16 21 1/8 120 lbs 139 lbs

3B84D 2 YES 18.8 26.2 29 1/8 20 7/16 21 5/8 120 lbs 139 lbs

3C8XD 3 NO 20.6 28.2 29 1/16 20 5/16 28 3/4 201 lbs 229 lbs

3C84D 3 YES 18.8 26.2 29 1/8 20 7/16 32 5/16 201 lbs 229 lbs

3D8XD 4 NO 22.3 29.7 29 1/16 20 5/8 36 5/16 237 lbs 252 lbs

3A20A

3A80A 1 YES 18.8 26.2 29 1/16 19 1/8 11 72 lbs 84 lbs

3B20A 2 NO 17.2 21.8 23 1/16 23 22 1/2 120 lbs 138 lbs

3B80A 2 NO 18.8 26.2 29 1/16 19 1/4 21 1/2 125 lbs 144 lbs

3B84A 2 YES 18.8 26.2 29 1/16 19 1/4 21 3/4 125 lbs 144 lbs

3C80A 3 NO 20.6 28.2 29 1/16 19 1/4 29 5/16 171 lbs 186 lbs

3C84A 3 YES 18.8 26.2 29 1/16 19 1/4 32 1/2 206 lbs 228 lbs

Built-In /

Free Standing

Free Standing

Built-In

Drawers

Individual

Drawer
Control

1 YES 18.8 26.2 29 1/16 20 3/8 11 84 lbs 94 lbs

1 YES 18.8 25.8 23 1/16 23 11 1/4 70 lbs 82 lbs

Preheat Times

(minutes)

150°F

(65°C)

175°F

(79°C)

Dimensions Weight

“W” “D” “H” w/o legs Installed Shipped

Body Dimensions

2

Moisture

FEATURES & DESCRIPTIONS

COMPONENT LOCATION & FUNCTION

Control Adjustment

Handle Latching

Mechanism

Drawer

Pan Insert

Third Member

Drawer Rail

Thermometer Indicator

Light

Toastmaster Hot Food Servers are heated drawer-type cabinets designed to HOLD food cooked in
advance at serving temperature and proper moisture content.

Thermostat: The thermostat is graduated from 0 to 10 which makes is adjustable

Thermometer: The thermometer is used to visually check if the holding temperature is

Note: On models with one drawer and on models with individual temperature controls for each drawer

the thermostat knob and thermometer are protected with either a wire guard, or the are recessed into the
front panel.

Moisture Control: The moisture control consist of a slide which is used to control the

Indicator Light: The light will illuminate when the unit is calling for heat and will shut off

from 100°F to 200°F (38°C to 93°C) holding temperature. Some
models are equipped with separate thermostat for each drawer. Refer
to Specications on the previous page.

at the desired setting. Chicken, beef, ribs, sh, potatoes, vegetables
and sauces can be held at temperatures with condence because you
can see that the actual holding temperature is safe. The thermometer
will tell at a glace if the holding temperature is high enough to retard
dangerous bacteria growth and low enough to prevent overcooking and
drying out food.

amount of moisture allowed to escape form the foods being held.

when it has reached the set temperature.

Thermostat Knob

(Adj 100°F to 200°F)

Nameplate

IL2089

3

DESCRIPTION continued

3 & 4 Drawer Free Standing Models:

7C-3L6 Square legs 6” high, stainless steel, set of 4, leveling adj. up to 3/4”

7C-3L9 Square legs 9” high, stainless steel, set of 4, leveling adj. up to 3/4”

7C-3L12 Square legs 12” high, stainless steel, set of 4, leveling adj. up to 3/4”

7C-3L15 Square legs 15” high, stainless steel, set of 4, leveling adj. up to 3/4”

7C-3M3 Casters, 3”, set of four (swivel without brakes) adds 4-1/4” to unit height

7C-3M4 Casters, 3”, set of four (two swivel/lock, two xed), adds 4-1/4” to unit height

2 Drawer Free Standing Models:

7C-3M338STSB Casters, 3” set of four swivel (two with brakes), 360lbs. Load capacity

INSTALLATION

Accessories

INSTALLATION

A. Inspect for Shipping Damage

All shipping containers should be examined for damage before and during
unloading. This equipment was carefully inspected and packaged at
the factory. The freight carrier has assumed responsibility for its safe
transit and delivery. If equipment is received in damage condition, either
apparent of concealed, a claim must be made with the delivery carrier.

1. Apparent Damage or Loss - If damage or loss is apparent it must be
noted on the freight bill or express receipt at the time of delivery, and
it must be signed by the carrier’s agent (driver). If this is not done, the
carrier may refuse the claim. The carrier will supply the necessary claim forms.

2. Concealed Damage or Loss - If damage or loss is NOT apparent until after equipment is
unpacked, a request for inspection of concealed damage must be made with carrier within
15 days. The carrier will make an inspection and will supply necessary claim forms. Be
certain to retain all contents plus external and internal packaging materials for inspection.

B. Unpacking Hot Food Server

1. Open carton and remove it from around hot food server, then remove the empty carton from
the area.

2. Remove all tape from unit and set food server on its side on three 2x4’s (as shown in Figure
2-1) so the packing skid attached to the bottom of the unit is off the ground.

WARNING: DO NOT set the unit on its back, damage could be occur to the power cord or

conduit. Place unit on its side.

3. Remove 4 bolts attaching skid to bottom of unit.

4

INSTALLATION continued

C. Installation of Free-Standing Models

1. Counter top Models 3B22D, 3A81D, 3A20D, 3A21D , 3B82D AND 3B84D.

a. Countertop models are shipped with a set of four 4”(102mm) adjustable legs or an

optional set of 4 casters (see Accessories Chart on previous page) can be ordered.
Screw the legs or casters into the threaded holes in the corners of the unit bottom.

b. Hot food servers with legs can be set on the oor or on the counter. Units with

casters can only be set on the oor. Do not set the hot food server with casters

on a counter top.

c. Level unit with legs by turning the hexagonal adjustment feet located at the bottom

of the legs.

2. Floor Models 3B82DT, 3C8XD, 3C84D AND 3D8XD are usually installed as oor models

due to their size. One of the available leg or caster accessory kits must be used in the
installation.

a. Leg Installation using accessory kit (see chart for available leg or caster accessories,

sold separately)

Locate and open the accessory leg kit and the hardware package included with it.

With the hot food server on it side and the 2x4’s still positioned under the unit, align

the square corner of a leg ange with a corner of the unit. Attach the leg ange using
5 of the bolts furnished. Refer to gure 2-2.

Repeat for remaining three legs.

Carefully set unit upright, using a level, level the server by turning the adjustable feet.

b. Caster Installation using accessory kit (see chart for available leg or caster

accessories, sold separately)

The casters kits are installed the same as the leg kits above, except 2 of the casters

are xed and should be installed at one end or at the rear. The other 2 swivel casters
with brakes are installed opposite the xed casters.

BOLT

LEG

2” x 4”

IL2094

Fig. 2-1, Leg / Caster Installation

5

INSTALLATION continued

3. Electrical Connections:

FREE STANDING UNITS: All free standing hot food servers are quipped with a factory installed 36”

(914mm) cord and plug.

• 120V models: Plug conforms to NEMA Standard 5-15P

• 208/240V models: Plug conforms to NEMA Standard 6-15P

BUILT-IN UNITS: Most units are provided with a 48” exible metal conduit for electrical connections

(see electrical specications for specics).

D. Installation of Built-In Units:

All of these units are true built-in models and are designed to be installed into the front face of a counter xture.
Front of units extends beyond the body to form a self-trimming ange that covers the cut out in the xture.

1. Cabinet Cut Out and Support. Cut out the face of the counter xture according to the drawing that is

provided with your hot food server. Figure 2-5 can also be used for the cut out drawing of your model
number. As shown in the drawing allow 1/2” (13mm) minimum cabinet face material above top of cut out
opening. This allows unobstructed seating of hot food server ange.

Be sure counter xture has adequate depth from front face to inside of back to accept the hot food server.

Minimum depths are shown for each model in Figure 2-5.

a. The hot food server body must be supported from the bottom. This can be accomplished by

installing metal support angles of wooden support blocks as shown in Figure 2-5. The supports
are not supplied and must be furnished using a suitable strength metal or wood. The top surface
of these supports must be 1/16” (3mm) below the bottom edge of the face cut out. A metal or
wood crossbrace approximately 2-1/2” (64mm) wide should be securely mounted between the
supports as shown. The center line of the crossbrace must be 4” (102mm) from the face of the
cut out and its top surface must be ush with the side supports.

b. An alternate support method is to install a solid at platform in lieu of the side supports and

crossbrace. The top surface of the platform must be 1/16” (3mm) below the bottom edge of the

cut out.

2. Install Leveling Feet (shown
below). Open the top drawer
and remove the small cloth bag
containing four hex head cap
screws & two mounting screws.
Thread these four screws hand
tight up into the four holes in
the bottom of the unit. Refer to

2-6.

B

Right: Leveling Feet for
Built-in Units.
(pn: 2C-1513D8805)

IL2100

BUILT-IN MODELS OPENING DIMENSIONS

Model “A” Width “B” Height “C” Depth

3A20A
3B20A 22 3/4” 578 mm

23 3/8” 594 mm

3A80A

11 1/2” 292 mm

24 1/2” 622 mm

11 1/4’ 286 mm 20 5/8” 524 mm
3B80A 21 3/4” 552 mm
3C80A 29 1/2” 749 mm
3B84A 22” 559 mm

29 3/8” 746 mm

20 3/4” 527 mm

3C84A 32 3/4” 832 mm

Cut Opening for

1/2” Minimum

1/2” Minimum

Hot Food Server

A

Figure 2-5, Cabinet Mounting

C

IL2090-01

6

INSTALLATION continued

3. Electrical Connection. All electrical connections required for this unit must be performed by a certied

electrician. Built-in models are equipped with a 3/4” (19mm) diameter x 4ft. (122cm) long exible conduit
containing power lead pigtails and a ground wire. It is necessary that this conduit and the wiring leads
connect at a junction box in accordance with local codes. Be sure to check the data plate on the front of
the unit to be sure the power supply is correct. 115V units operate on voltage ranging from 110V to 125V.
220V units operate on voltage ranging from 208V to 240V.

4. Mount Unit in Cabinet.
a. Remove the drawer(s) from the unit, pull the drawer(s) out to the stop. Grasp the entire drawer

assembly at the sides as if to lift it and locate your thumbs on the tabs of the drawer slide (gure
2-7). Press down on these tabs with your thumbs and simultaneously pull out on the drawer. Set
drawer assembly aside.

b. Lift the unit form both sides and start its backside into the cut out. Push back until the trim ange

meets the face of the xture.

c. Place a level on the oor of the unit and check from side to side and front to back. If adjustments

are necessary, slide the entire unit out of the xture and adjust the leveling feet as required.

d. Secure the unit into position after leveling. There are two holes in the unit bottom for this purpose

(See Figure 2-6). Place a drill bit down through these two holes and bore two pilot holes into the
crossbrace beneath. Tighten a pair of at head sheet metal screws down through these holes
and into the crossbrace. The unit is now installed.

e. Replace the drawers. NOTE: The drawers of multiple drawer units are individually identied

(ex: “TOP”, “2” AND “3”). They should be reinstalled in their respective positions.

E. Initial Start-up

1. Turn on the branch line circuit

breaker

2. Set the thermostat control dial

at “10” the indiactor light will
come on indicating that unit is
calling for heat.

3. After a few minutes have

elapsed, open a drawer and
check that the unit is heating.

NOTE: If your unit is equipped with

a separate thermostat for each
drawer, complete Steps 2 & 3
for each drawer individually.

4. If unit fails to heat, recheck to

be sure circuit breakers are
on and electrical connections
are properly made. If it still
fails to heat, call a Toastmaster
Authorized Service Agent.

Drawer

Release Tabs

Bolts used as
leveling feet

Drill starter holes and attach
hot food server to support through
these two holes.
Use flat head screws.

Bolts used as
leveling feet

Above: Figure 2-6, Cabinet Mounting

Left: Figure 2-7, Drawer Release Tabs

IL2090-02

IL2101

7
