Toastmaster 389U User Manual

Toaster Oven

Broiler

USE AND CARE GUIDE

AND RECIPE BOOK

MODEL 389U

READ AND SAVE THESE INSTRUCTIONS

WARNING: A risk of fire and electrical shock exists in all electrical appliances and may cause personal injury or death. Please follow all safety instructions.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the following:

◆ Read all instructions before using appliance.

◆ Do not immerse cord, plug or appliance in water or any other

liquid (see instructions for cleaning).

◆ Do not touch hot surfaces. Always use oven mitts when handling

the bake/broil pan and wire rack.

◆ This appliance is not for use by children.

◆ Close supervision is necessary when this appliance is used near

children.

◆ Unplug from outlet when not in use and before cleaning. Press

stop button before unplugging. Allow to cool before attaching or removing parts while cleaning.

◆ To disconnect, press the stop button, then grip the plug and pull

out from the wall outlet. Never pull on the cord.

◆ Do not operate a damaged appliance. Do not operate with a

damaged cord or plug or after the appliance malfunctions, or has been dropped or damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair, electrical or mechanical adjustment.

◆ Use accessory attachments only if recommended by Toastmaster

Inc.

◆ Do not use outdoors or while standing in a damp area.

◆ Do not use appliance for other than intended use.

◆ Do not let cord hang over edge of table or counter or touch hot

surfaces.

◆ Do not place appliance or cord on or near any hot surface,

including a gas or electric burner or in a heated oven.

◆ Do not leave appliance unattended while broiling or toasting.

◆ Do not clean with metal scouring pads. Pieces can break off the

pad and touch electrical parts.

◆ When using this appliance, provide at least 4 inches space above

and on all sides for air circulation. Do not use on surfaces where heat may cause a problem.

◆ Extreme caution must be used when moving an appliance

containing hot oil or other hot liquids.

◆ Use extreme caution when removing tray or disposing of hot grease.

◆ A fire may occur if this appliance touches or is covered by

flammable material, including curtains, draperies, walls, etc., when in operation.

◆ Do not store any materials other than the manufacturer’s

recommended accessories in this appliance when not in use.

◆ Do not cover the crumb tray or any part of the oven with metal

foil. This will cause overheating of the oven.

◆ Extreme caution should be exercised when using containers

constructed of material other than metal.

◆ Do not place any flammable material such as paper, cardboard,

plastic, etc., next to, on top of, or in the oven.

◆ When broiling, the bake/broil tray and wire rack must be used.

◆ Oversized foods or utensils must not be inserted into the oven.

◆ CAUTION: Never leave the toaster-oven-broiler unattended when

broiling or toasting.

SAVE THESE INSTRUCTIONS

CAUTION: A short power supply cord is provided to reduce the risk of personal injury resulting from becoming entangled in or tripping over a longer cord. Extension cords are available from local hardware stores and may be used if care is exercised in their use. If an extension cord is required, special care and caution is necessary. Also the cord must be: (1) marked with an electrical rating of 125 V, and at least 13 A., 1625 W., and (2) the cord must be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over accidentally.

ELECTRIC POWER: If electric circuit is overloaded with other appliances, your Toaster Oven Broiler may not operate properly. The Toaster Oven Broiler should be operated on a separate electrical circuit from other operating appliances.

POLARIZED PLUG: This appliance has a polarized plug, (one blade is wider than the other). As a safety feature to reduce the risk of electrical shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature.

Toaster Oven Broiler Use and Care Guide

Before Your First Use

Carefully unpack the Toaster Oven Broiler, removing all packaging materials. To remove any dust that may have accumulated during packaging, wash the bake/broil pan, wire rack and crumb tray. Wipe the outside of the machine with a damp cloth. Do not use harsh or abrasive cleaners on any part of the machine.

Fill out warranty information on the back of the book.

Place away from edge of counter on a dry, clean stable surface away from burners and away from areas where cooking grease or water may splatter onto it.

Plug into a 120 V ~ 60 Hz outlet.

Important Safety Tips

◆ The oven cavity, crumb tray, bake/broil pan, wire rack and food

will be very hot after use. Use oven mitts.

◆ Unplug unit and allow to cool before cleaning. Remove any bread

crumbs or other materials from inside the oven using a damp sponge, cloth or a small, portable vacuum cleaner.

Power Outage

Your Toastmaster Toaster Oven Broiler has a 15 minute power interrupt feature on all functions, toast-bake-broil. If the power comes back on within 15 minutes, the program will resume.

Toaster Oven Broiler Introduction

Control Panel

DISPLAY WINDOW

Indicates function, crust color, amount of time left for completion of program and temperature.

OPERATION light will be on to show unit is in operation.

COMPLETE operation light will flash

continually when program is complete. When door is opened the light will turn off.

BAKE

Press to select PREHEAT BAKE and BAKE programs.

BROIL

Press to select the BROIL program.

WARM

Press to select the WARM program.

START

After selecting the function, temperature (if required) and time (if required), press to start the program.

TOAST

Press to select 4 or 2 slices toast programs.

TEMPERATURE

Press to display temperature for PREHEAT BAKE, BAKE or BROIL.

TIME

Press to select time before using arrow keys to adjust. Must be set to BAKE and BROIL.

ARROWS

Press to adjust temperature for PREHEAT BAKE or BAKE. Or, press to select toast color.

STOP

Press for more than 2 seconds during use to cancel a program.

When a Toaster Oven Broiler is packaged for shipment, a clear plastic film is placed over the control panel as protection. This film may either be removed or left on. You may choose to leave it on, but it will come off with use.

PROGRAM CANCEL

Toa s ter Oven Broiler Use and Care Guide

If you want to cancel the selected program, press the STOP pad and hold it down for more than 2 seconds at any time during the program.

Parts and Accessories

The illustrations in this use and care guide are for information purposes only. You may find your toaster oven broiler and parts look different, however, the steps for operation are the same.

CONTROL

RELEASE

PUSH TO

Accessories

PANEL

DOOR

OPEN

Crumb Tray Bake/Broil Pan

Wire Rack

Bake/Broil Pan and Wire Rack

For best results use bake pan to bake, defrost, top brown, keep warm and to minimize clean up due to spills.

When toasting, place bread directly on wire rack. Place into oven position #3. The crumb tray must be used.

When baking, you may either use the bake pan or wire rack and your own pan. Place into oven position #2 unless more height is required and then place into position #1.

When broiling, both the broil pan and the wire rack must be used. Place into oven position #3 or #2 depending on thickness of food.

When roasting, both the broil pan and the wire rack must be used. Place into oven position #1.

When warming, you may either use the bake pan or wire rack and your own pan. Place into position #2 unless more height is required and then place into position #1.

POSITION 3 POSITION 2

POSITION 1

CRUMB TRAY

CAUTION: APPLIANCE SURFACES ARE HOT DURING AND AFTER USE.

CAUTION: Always wear protective, insulated oven mitts on hands when touching hot oven or hot dishes and food, or when inserting or removing rack, bake/broil pan, baking dishes, or crumb tray.

Toaster Oven Broiler Use and Care Guide

Oven Broiler Functions

The BAKE and BROIL programs of your new toaster oven broiler have the versatility to bake, broil, defrost and keep foods warm. The toaster oven broiler has an adjustable thermostat with temperatures ranging from 100°F/37°C up to 500°F/260°C. This allows you to prepare your favorite recipes according to package or recipe directions. The bake program has a 4 hour timer and the broil program a 1 hour timer. The OPERATION light on the control panel will be on while the unit is operating. The OPERATION light will flash continually when program is COMPLETE and when the door is opened it will turn off.

Ovenware manufacturers do not recommend using see-through glass containers or lids in this oven. Opaque glass-ceramic baking containers may be used. Do not use oven roasting bags in this oven, as they may come in contact with the heating elements.

Programming Preheat Bake, Bake and Broil

1. Plug unit into a 120 V ~ 60 Hz outlet. Close the door.

2. Press BAKE button to select a BAKE program. If pressed once, the PREHEAT BAKE program is selected. If pressed twice, the BAKE program is selected. Press BROIL to select broil program.

3. When any oven program is chosen, the clock will appear in the window first. Set the time by pressing the UP ARROW to move to the desired time. To move the time along more quickly, hold the arrow and it will advance in 10 minute intervals. If you go past the desired time, you may push the down arrow to reduce the total time. When using the PREHEAT BAKE program, the time will not begin to count down until the oven goes into the BAKE program. If you prefer, you may program your time after the PREHEAT BAKE is complete and when you place your food into the oven.

4. Press the TEMPERATURE button. The default temperature for the PREHEAT BAKE and BAKE functions is 300°F/148°C (this will show in the display window). To change the temperature for PREHEAT BAKE and BAKE, press the UP or DOWN ARROW to move to the desired temperature. The temperature will go up or down by 5°F at a time. The preset temperature for the BROIL function is 500°F/260°C (this cannot be adjusted). Preheating the oven is not necessary for BROIL.

5. If you are using the PREHEAT BAKE program, when the desired temperature has been chosen, press START. The OPERATION light will be on. Once the oven has reached its pre-selected temperature, it will beep and the temperature will flash in the display window.

6. Open the door and place your food in the oven. PREHEAT BAKE will change to BAKE. Press START. The OPERATION light will come on and the time counter will begin to count down. The oven will beep if the START button is pressed and no time has been set. Press the UP or DOWN arrows to move to the desired time then press START. The colons in the time counter will flash. If you don’t open the door and place your food in the oven right away, it will continue to maintain the preheat temperature for up to 30 minutes. If you have not opened the door within this time, the oven will turn off automatically.

7. The unit will beep and the OPERATION light will flash continually to indicate the program is COMPLETE. When the door is opened, the light will turn off. Use oven mitts to remove hot pan, rack and food.

8. Unplug and allow to cool completely before cleaning.

Hints For Bake And Broil

◆

If no time is selected and the START button is pressed, the unit will beep to indicate that no time has been selected. Unit will not bake or broil unless a time is selected.

◆

The time can be changed at any time during the BAKE or BROIL programs. Press the UP ARROW to increase the time. Press the DOWN ARROW to decrease the time. The temperature can be changed at any time during the BAKE program only.

◆

Press the STOP button at any time to stop the unit.

◆

The oven will pause for up to 10 minutes when the door is opened. If the door is open longer than 10 minutes, the oven will turn off.

Toa s ter Oven Broiler Use and Care Guide
