Thomson VTH6050F, VTH6050G User Manual

VCR
FRANÇAIS . . . . . . . . . . . . . . . .
1
1
1
1
2
3
10 cm
7 cm
10 cm
10 cm
7 cm
F
F
DEUTSCH . . . . . . . . . . . . . . . . .
ITALIANO . . . . . . . . . . . . . . . .
ENGLISH . . . . . . . . . . . . . . . . .
NEDERLANDS . . . . . . . . . . . . .
ESPAÑOL . . . . . . . . . . . . . . . .
D
D
I
I
GB
GB
NL
NL
E
E
F
10
13
15
11
12
18
16
17
19
20
21
22
26
28
9
14
2 4 5 6 7 81 3
23
29
25
24
27
1112
1
3

Important

10 cm
7 cm
10 cm
10 cm
7 cm

Precautions Contents

SETTING UP - Ensure that the mains supply in your house complies with
that indicated on the identification sticker located on the back of your appliance. Install the video recorder horizontally, away from any source of heat (fireplace) or appliances creating strong magnetic or electric fields. The components of this video recorder are sensitive to heat. The maximum ambient temperature should not exceed 40° Celsius. Leave sufficient space around the video recorder to allow adequate ventilation: 10 cm on either side and at the rear, as well as 7 cm above the top are minimum requirements. The humidity of the room should not exceed
80%. If you have to use the video recorder outdoors, do not expose it to water from rain or splashing. Moving it from a cold atmosphere into a
warm one is likely to cause condensation on some components inside the video recorder. Let the condensation disappear by itself before turning the video recorder on again.
USE - If your appliance, or a cassette, has been stored in a very cold
atmosphere for a certain amount of time (transported during winter for example), wait approximately 2 hours before using your video recorder. The openings located on the top and the bottom are for ventilation purposes. They should not be obstructed. During thunder storms, we recommend that you disconnect the video recorder from the mains and aerial so that it is not affected by electrical or electromagnetic surges that could damage it. For this reason, keep the mains socket and aerial socket accessible so they can be disconnected. When the unit is on standby, some components remain connected to the mains. To fully disconnect your set, you have to unplug the mains connector from the mains socket. Immediately disconnect the video recorder if you notice it giving off a smell of burning or smoke. Under no circumstances whatsoever must you open the video recorder yourself. You risk electrocution if you do so.
CLEANING – Use a soft, dry and clean cloth. Regularly dust the vents at the
back or sides. Using solvents, abrasive or alcohol based products risks damaging the set. If an object or liquid enters inside the appliance, unplug it immediately and have it checked by an authorised technician. To avoid deterioration of your video recorder’s heads, never use a cleaning tape.

Guarantee

The type and production number of your appliance are printed on the guarantee certificate delivered with your video recorder. Keep this certificate as well as the invoice. These documents are indispensable for claiming your guarantee rights. All repairs during the guarantee period must be carried out by an authorised technician representing our brand. If this condition is not met, your rights will no longer be valid. Never open the appliance yourself, since this may be dangerous for you or damage the equipment. Thomson Multimedia is not liable if the television is used other than in accordance with this manual.
Prior to using your video recorder, you'll have to follow the set-up procedure and make the settings described on pages 2 to 9.
ON THIS USER MANUAL: This user manual being common to several VCR models, some
J
functions or settings may not be available on the model you have bought.
Set-up
Before you start . . . . . . . . . . . . . . . . . .2
Making the connections . . . . . . . . . . . .3
Initial Set-up . . . . . . . . . . . . . . . . . . . . .4
Automatic channel search Sorting the channels - Clock setting New or encoded channels
Modulator . . . . . . . . . . . . . . . . . . . . . . .6
Settings to be made on the video recorder Settings to be made on the television
Satellite/cable receiver . . . . . . . . . . . . .7
Recommended connection scheme Video recorder settings
Other sets . . . . . . . . . . . . . . . . . . . . . . .9
AV1 / AV2 / AV3 / AV4
Sockets
Use
Using the remote control . . . . . . . . . .10
Controlling the video recorder - Controlling the television set - Programming the remote control with the TV code
Controlling the operation . . . . . . . . . .11
On the display - On the screen
Viewing a tape
Playing a tape - Accelerated play Still image - Pause - Variable slow motion - Stop Rewind or Fast forward - Ejection of the tape Jog shuttle - Index search
Recording
Recording - Recording with a NexTView Link television set - S.O.S. record - Mark a scene with an index
Programming a recording . . . . . . . . .14
With the ShowView codes - Without the ShowView codes - When the video recorder is programmed - Deleting a programmed recording Recording programmed by an external unit connected - Error messages likely to occur when programming - Storage of the programme numbers with the ShowView feature
Tape control . . . . . . . . . . . . . . . . . . . .16
Clear index - Go to a particular position - Return to a particular position - Non-standard tape
Adjusting the picture . . . . . . . . . . . . .17
Tracking and stability in the play mode Format - Colour systems supported
Adjusting the sound . . . . . . . . . . . . . .18
Adjusting the sound in the play mode Setting the type of sound to be recorded
Preferences . . . . . . . . . . . . . . . . . . . . .19
Eco mode- Auto LP - Auto clock - ShowView +10 mn - VPS/PDC - External timer - Beep sound - Language
Other functions . . . . . . . . . . . . . . . . . .20
Electronic key - Continuous play / recording Resetting the counter - Playing NTSC tapes
More information . . . . . . . . . . . . . . . .21
TV code list - Concerning video tapes
Technical features . . . . . . . . . . . . . . . .22
. . . . . . . . . . . . . . . . . . . . . .12
. . . . . . . . . . . . . . . . . . . . . . . . . .13
1
GB
GB
Set-up
-
+
SIZE AA 1,5 V 0%MERCURY
GREENELL
EXTRA HEAVY DUTY
-
+
SIZE AA 1,5 V 0%MERCURY
GREENELL
EXTRA HEAVY DUTY
VCR

Before you start

Thank you for purchasing one or our videos. Unpack
J
the set completely and tear off the protection films.
Video recorder
Remote control of the video recorder or of the television set, depending on the selection or either VCR or TV.
2 non-rechargeable batteries, type AA
Power cord
2
Coaxial cable (75 Ω)
Scart cable (12 pins connected) depending on the video recorder model
Set-up and user manual
To respect the environment, we have printed this document on unbleached recycling paper.
Please respect the environment and prevailing regulations. Before you dispose of batteries or accumulators, ask your dealer whether they are subject to special recycling and it they will accept them for disposal.
Set-up
AV1 EXT1 AUX1
AV1
IN
OUT
220V/240V - 50Hz

Making the connections

Connecting the video recorder and television set with this
J
cable simplifies set-up and subsequent use, and considerably improves the picture and sound reproduction quality. If your television set has no SCART socket, you'll have to adjust the modulator of the video recorder and assign a channel number to the video recorder on the television set (refer to page 6).
1 Disconnect the aerial cable from your TV set and reconnect it to the IN socket of your
video recorder.
2 By means of the coaxial cable supplied, connect the video recorder's OUT socket to the
gg
television's aerial socket
3 With the SCART cable supplied, connect the video recorder's AV 1 socket
(audio/video 1) to the television's SCART socket (AV 1, EXT 1, AUX 1 depending on the make).
4 Connect the video recorder to the mains with the power cord supplied by first plugging
in the connector at the video recorder rear.
.
1
2
GB
GB
Other possible connection schemes are shown on page 7 and 9
J
4
3
3
Set-up

Initial Set-up

If you have not connected the television set to the video recorder with the SCART cable, you must
J
first make the modulator and then the television settings (refer to page 6) before you start the automatic channel set-up. The video recorder was not pre-set to receive the channels of your region. Thus, you'll have to set them up yourself, by carrying out the automatic channel set-up procedure described below. Your video recorder will automatically perform channel search and store each of the channels found with its own channel number.

Automatic channel search

1 Switch on the television. 2 Press key VCR (1) on your remote control. 3 Switch on your video recorder, making use either of the remote control key
the appropriate key (ON) on the video recorder front side.
ð When switching on the video recorder for the first time, a language selection menu
comes up. Should it not appear, press key MENU (15).
4 With key CC(13) or BB(11) select the language you prefer to display the menus in on
the screen.
5 Validate your choice with the OK (10) key.
ð The
6 Press key CC(13) or BB(11) to select the country where you usually live. 7 Validate with the OK (10) key.
8 Press key
COUNTRY menu comes up.
Your video recorder comes with the NexTView Link feature. This function simplifies the channel
J
set-up procedure, as the channels already set up on a TV set fitted with the NexTView Link or similar feature (Easy Link, Smart Link, Megalogic, etc.) can be downloaded to the video recorder. The channels downloaded this way to the video recorder preserve the same properties as on your TV set (same number, same name, etc.).
ð If your TV set is fitted with the NextView Link function or similar, the video
recorder automatically initiates channel download once you have selected the country. You can view channel download on the video recorder display (Pr1, Pr2, Pr3…). On completion of download, the video recorder switches over to standby. Channel set-up is achieved.
ð When your television set is not fitted with the NextView Link or any similar feature,
a message tells you that your video recorder is searching and storing the channels you can receive in your region. Keep patient until a message informs you that your channels are stored.
BB
ð The
(11) to sort your channels.
ORGANISER menu comes up.
B (3) or of

Sorting the channels

The automatic channel set-up assigns the numbers to the channels in a predefined order. These
J
numbers may therefore not match the actual channel numbers. Should this be the case, change these numbers by carrying out the instructions below. For easy channel identification, we suggest that you have a TV magazine at hand.
9a If the proposed channel number matches the displayed picture, press
to the next channel.
9b If the proposed channel number does not correspond to the picture that you see, select
the Swap with Pr. line with key
4
When the picture of a channel is of poor quality or encoded, try out the fine tuning feature.
L
Refer to page 5 (section New or encoded channel, step 9).
WW
(12).
BB
(11) to pass on
Set-up
-
+
SIZE AAA 1,5 V 0%MERCURY
GREENELL
EXTRA HEAVY DUTY
-
+
SIZE AAA 1,5 V 0%MERCURY
GREENELL
EXTRA HEAVY DUTY
10 With the number keys, enter the correct channel number or select it with keys CC(13)
BB
or
(11).
11 Validate your choice with key OK (10). 12 If the channel name is incomplete or does not correspond to the channel’s actual name,
select the Name line, and choose an available name with keys CC/ BB(13) / (11) or use keys 1 and 2 and then CC/ BB(13) / (11) to store a new one.
13 To delete a channel, select the Delete program. line and press OK (10) twice. 14 When all channels are organised, press EXIT (14) to leave the menus.

Clock setting

Your video recorder is fitted with an automatic clock setting feature that detects the clock setting
J
signals sent by some channels. If your video recorder clock is not right, you can set it right by carrying out the steps below.
1 Press key VCR (1) on your remote control. 2 With key MENU (15) call up the 3 With key
ð The
4 With key
ð The
WW
(12), select the Installation line and confirm with OK (10).
INSTALLATION menu comes up.
WW
(12), select the Clock set line and confirm with OK (10).
CLOCK SET menu comes up.
SUMMARY menu.
5 If the displayed time is incorrect or was not transmitted, set the clock with the number
keys 0 to 9 (19). Press key
BB
(11), then enter time and date in the following order:
hour, minute, day, month, year.
6 Store with OK (10). 7 Quit with EXIT (14).

New or encoded channel

To complete the set-up of your video recorder when the automatic channel set-up has not stored all
J
of the channels or when you wish to store a new channel.
1 Press key VCR (1) on your remote control. 2 With key MENU (15) call up the
WW
3 With key
ð The
(12), select the Installation line and confirm with OK (10).
INSTALLATION menu comes up.
4 The Manual installation line is already selected. Press OK (10).
ð The M
ANUAL INSTALLATION menu comes up.
5 The Standard line is already selected. Press
standard (L: France, BG: Western Europe, DK: Eastern Europe).
6 Select the Reception line with
your roof aerial) or cable (for the cable network channels) with C (13) or B (11).
7 Press W (12) to select the Autosearch line. 8 Press C (13) or B (11) several times to search for the channel of a programme (you
may also directly enter a number with keys 0 to 9 (19). ð When a channel is found, the pictures come up on the screen.
9 When the picture is poor, try the Fine tuning (</>) with W (12), then C (13) or B (11). 10 If the channel is encoded (and you have a decoder connected to socket AV2), set the
cursor on
DECODER with W (12), and check the box with key OK (10).
11 Position the cursor on Store on Pr and assign a channel number by means of the
number keys 0 to 9 (19) (example: 0, 1 for Pr1).
12 Press OK (10) to store this number. 13 If you wish to continue with TV channel set-up, repeat the steps 3 to 9.
Otherwise press EXIT (14).
SUMMARY menu.
C (13) or B (11) to select the reception
W (12) and choose Aerial (for the channels received via
GB
GB
Did you insert the batteries in the remote control? For detailed instructions,
J
see inside the cover
5
