Thomson MG1476C, MG1476CT User Manual
Bedienungs-
anleitung•
Istruzioni-
per l'uso•
Notice d'uti-
lisation•
Instructions-
for use•
Libro de
instrucciones
Folheto de
utilização
Bruksan-
vis ning
Betjenings-
vejledning
Oδηγεσ
χρσεωσ
• MG 1476 C - MG 1476 CT •
THOMSON
CONSUMER
ELECTRONICS
SALES GmbH
Göttinger
Chaussee76
30453 Hannover
Germany
THOMSON CONSUMER
ELECTRONICS
MARKETING FRANCE
19 Avenue
Dubonnet
92400 Courbevoie
FranceRCS
NanterreB
322019464
03 97 - 207 561 80
SAFE USE OF THE EQUIPMENT
10
cm
5
cm
10 cm
10 cm
10 cm
1. TO TURN ON
LEAVE ROOM FOR VENTILATION.
AVOID HEAT,
WATER,
DIRECT SUNLIGHT.
Do not place audio loudspeakers near to
television. The magnets in the speakers could
cause patches of colour to appear on the
screen.
To ensure your personal safety and the efficient operation of
your equipment, please follow the advice given below :
Television sets need ventilation to avoid overheating which can cause
damage to the components. The ventilation slots at the back of the set should
not be covered up by curtains, small covers, newspapers, etc… There must
be enough room in built-in cupboards to allow the cooling air to circulate.
The set should not be placed directly next to heating.
This appliance is designed for use in dry areas. If occasionally you should
wish to operate it outdoors (for example, on the balcony or veranda), you
must insure that it is protected against all forms of moisture (dew, rain,
splashed water).
A cold set may be switched on in a warm room only after any condensation
which may happen to be on the screen has evaporated. Never remove the
cabinet back. Have your aerial installed by an authorised dealer or service
technician.
In the evenings, after the TV programmes, or in case of a prolonged
absence, it is recommended that the appliance be switched off using the
on/off switch.
Even if the ON/OFF switch is in OFF position the set is not completely
separated from the mains. In order to separate the set completely from the
mains, the set has to be disconnected by unplugging the mains plug.
Remove the power plug from the wall outlet under the following conditions :
1. During a thunderstorm, it is also recommended that you disconnect the
aerial plug.
2. In case of malfunction, if the set does not operate normally.
Additional information :
Your TV set is adequately shielded to prevent emission of X-rays.
The acceleration voltage does not exceed the maximum value of 26 kV.
Work by non-qualified technicians, modification of the high voltage setting
or the replacement of the tube with a model that does not comply with the
manufacturer's specifications may lead to X-radiation.
A set changed in any of the above ways no longer satisfies the initial
specifications and should not be put back into service.
2. CARE OF THE EQUIPMENT
The screen should be cleaned with liquid glass cleaner.
• Never use abrasive cleaners.
• To clean the front and the cabinet of your equipment use a soft cloth dipped in mild detergent. The use of strong solvents
such as white spirits or alcohol based products could damage your equipment.
• Clean the vents on the rear panel of your set regularly.
3. DEMAGNETISATION
The earth's magnetic field may have an effect on your television by causing patches of colour to appear on the screen.
If this happens :
• Switch off the television with the on-off button
• Wait a few minutes, and then press again to switch on.
This allows the screen to be demagnetised automatically. If patches of colour are still visible repeat the procedure.
- 3 -
RC1132
/
STOP VT FUNCT VT
MENU VT
TVPR
-
PR
+
+
–
+
–
THE REMOTE CONTROL
MENU
MAIN MENU
PREF.
——:——
Program.
Organis.
TIMER MENU
to call up the menus :
———————————————————————————
A
Setting the clock
A
Manual channel setting
A
Re-organizing programmes
A
to select functions :
Stand-By (Sleep timer)
A
———————————————————————————————
Alarm
A
page 9
——————————————————————
———————————————
—————————————
———————————
page 11
11
13
8
12
The menus Program., Organis. and TIMER can be locked. If you cannot
ENGLISH
display them, see page 18 on how to unlock them. The first line of the menus
is automatically selected. To select another line, simply press the button again,
to move down through the menus.
SOUND SELECTION
PICTURE SELECTION
PROGRAMME SELECTION
PR —PR +
VOLUME LEVEL,
and adjustment or selection in menus.
INFORMATION DISPLAY,
(current channel, time, pre-sets)
and to leave menus.
SOUND MUTE
TELETEXT
and scroll up through the menus.
STAND-BY
(MG 1476 C : optionally)
- 4 -
STOP VT FUNCT VT
TV
VT
Batteries : Remove the lid at
the back of the remote control
and insert two 1,5 V batteries,
TYPE LR03 (AAA) or
equivalent.
For a cleaner environment,
please dispose of used
batteries in the containers
provided for this purpose.
CONTENTS
Page
CONNECTIONS AND CONTROLS........................... 5
TO TURN ON ............................................................ 5
AUTOMATIC CHANNEL SETTING............................ 6
RE-ORGANIZING PROGRAMMES.......................... 8
PICTURE ADJUSTMENTS.......................................... 9
DAY TO DAY OPERATION ..................................... 10
OTHER FUNCTIONS ............................................... 11
CONNECTIONS AND CONTROLSMG 1476 C/CT
At the back of the set.
Telescopic antenna
Aerial socket
Connect to A. C. main supply
220 - 240 V ~ 50 Hz.
Page
ALARM..................................................................... 12
MANUAL CHANNEL SETTING............................... 13
CHILD LOCK ............................................................ 14
TELETEXT - FASTEXT - TOP TEXT........................... 15
CONNECTIONS....................................................... 17
LOCKING MENU..................................................... 18
ENGLISH
SCART socket
In front of the set.
On/off switch
Programme selection
— PR
On/Stand-By light
Green : on/Red : Stand-By
Volume Audio CINCH
+
— PR
+
Headphone socket
Ø 3,5 mm
socket
AUDIO VIDEO
Video CINCH
socket
TO TURN ON
Press the on/off switch; the indicator light comes on.
Press button 1 on the remote control.
If your television set has not been tuned in, you may now begin tuning the channels.
Proceed to selecting the menu language in the INSTALLATION MENU page 6.
- 5 -
English press
Deutsch
Français
Français (Belgique, Suisse)
Italiano
Español
INSTAL. MENU
+
AUTO-PROGRAMMING
Searching for stations
EURO
Stations found : XX
CCXX
Stations found : X X
Search stations in
other standards ?
Yes No
+
—
AUTOMATIC CHANNEL SETTING
This set is equipped with an automatic search system which will search and store all channels
available in your region. To help identify the programmes, we suggest that you have to hand a TV
guide or daily newspaper.
Ensure that the aerial lead is connected to the television and any VCR or SAT equipment that is
connected via the antenna is turned on but do not switch on if also/only connected to a Scart/AV input.
Searching for stations and storing them in memory depends on the language selected in the
INSTALLATION MENU.
FRENCH AND ENGLISH
Searches DKK’ channels then BG channels.
OTHER LANGUAGES AND FRENCH (BELGIUM, SWITZERLAND)
Searches BG channels then DKK’ channels.
ENGLISH
1. INSTALLATION MENU
When the television set is turned on for the first time,
the Installation menu appears automatically.
If this menu is not displayed, you can make it
appear as follows :
- Switch the television to Stand-By.
- Switch off the television by pressing the on/off switch and wait for the light to go out.
- Switch the set back on, whilst keeping the PR —button on the television keypad
MENU
pressed down until the INSTALLATION MENU appears.
Press repeatedly the button to select the menu
language you require.
FUNCT VT
Press briefly, a new menu appears, automatic
search begins.The cursor will move from left to right.
Please wait until the following
menu appears.
FUNCT VT
Press briefly to restart the search in other
broadcasting standard,
or
STOP VT
press briefly to display the PROGRAMME
ORGANIZER menu.
The PROGRAMME ORGANIZER menu appears automatically when the search for
channels in other standard is complete.
- 6 -
