Thomson 21DG15CH User Manual

Manuel

d’utilisation

User

manual

21DG15CH

Recommendations and Precautions

1.Operation

Please read the following instructions carefully and follow them closely, they concern your personal safety and
can affect the operation of your equipment.

Television sets require venti lation to avoid overheating which can
damagecomponents. Makesure that therearventilation openingsare
not covered up by curtains, cloths, newspapers, etc. There must be
enoughroominsidebuilt–inunits to allow coolingair to circulatefreely.

Do not install the set next to heating.
Theappliance isdesignedtooperatein adry room. Shouldyou,forany

special reason, wish to use it outdoors (e.g. balcony, veranda, tent,
etc.), always make sure it is properly protected against any form of

DO NOT OBSTRUCT VENTILATION OPE`
NINGS.

AVOID WATER,
HEAT,
DIRECT SUNLIGHT.

Do not place audio loudspeakers next to
your TV set as the magnets in the spea­kers may cause coloured patches on the
screen.

2. Cleaning

The screen should be cleaned using liquid window cleaner.

· Never use abrasive cleaners.

· Clean the front and cabinet using a soft cloth dipped in mild detergent. The use of solvents such as white spirit or
alcohol–based products may damage your set.

· Make sure to clean the vents at the rear of your set regularly.

moisture (dew, rain, splashing).
Before turning on a cold set in a warm room, wait until any

condensation on the screen has evaporated. Never open up the rear
panel of the television set. Haveyour aerial installed by anauthorised
dealer or specialist.

At the end of the evening TV programme or in the event of prolonged
absence, you should switch off your set using the ON/OFF button.

Even if the ON/OFF switch is in the OFF position, the set is not
completely disconnected from the mains. To disconnect the set
completely,pull out the mains plug.

Remove the mains plug from the wall outlet in the following cases:

1. During thunderstorms. It is wise to disconnect the aerial plug too in
thiscase.

2. If you notice any odour or smoke coming from your set.

Additional information:
Your TV set is adequately shielded to prevent X–ray emission.
Acceleration voltage does not exceed the maximum value of 26 kV.
Work by unqualified technicians, modification of the high–voltage

setting or replacement of the tube with a model that does not comply
with the manufacturer’s specifications can lead to a considerable
increase in X–ray emission.

A set changed in any of the above ways no longer complies with the
manufacturer’s specifications and should not beput back into service.

GB

3. Demagnetisation

The earth’s magnetic field may affect your television set, causing coloured patches to appear on the screen.
If this happens:

· Switch off the set using the ON/OFF button.

· Wait about an hour and then switch on again using the ON/OFF button.
This operation demagnetises the screen automatically.If coloured patches are still visible, repeat the procedure.

1

Connections

GB

220-240V~50Hz

2

1. Aerial Socket

Enables connection of the aerial and, if required, a video recorder (see manual for latter).
To tune the channel reserved for your video recorder, start up the recorder then carry out

MANUAL CHANNEL SETTING operations.
Store at programme 99 if you have a SECAM video recorder or at any programme ending with a 9

(9,19,29, etc.) if you have a P AL recorder.
Each time you use the video recorder, switch to the channel assigned to it.

2. SCART Socket

This is used to connect:

– a VHS, 8 MM, S–VHS or Hi–8 video recorder or camcorder,
– a PAY TV decoder,
– a video games console.
To use the connected device, select the audiovisual programme by pressing the

This selection is automatic for some devices.
AV is displayed at the bottom of the screen.
IfyouhaveanS-VIDEOdevice,pressthe

of the screen for a few seconds.
When you switch off the device and if you have not changed channel during play, the TV set

automatically returns to the previous channel.
If the TV set has beenswitchedon by the videorecorder,itwill be placedon stand–by when the video

recorder is switched off.

buttonagain. S-VIDEO is then displayedat the bottom

button.

GB

3. Audio / Video CINCH Sockets

These are used to connect a VHS or 8 mm camcorder .
Press the

When you switch off the connected device, the TV set remains in audiovisual (AV) mode.
Call up the channel you wish to watch using the numerical keypad on the remote control.
In order to maintain the optimumsound and picture quality of yourTV set, avoidconnecting2 devices

to the SCART socket and the AUDIO/VIDEO sockets simultaneously.

button to select the audiovisual programme to view your recordings.

3
