Thermon E4X-1 Installation Procedures Manual

E4X-1
WARNING:
Disconnect Circuit Before Removing Cover
E4X Thermostat
E4X-35235 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
E4X-1-SR 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
E4X-1-ZN 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
for use in NEMA 4X Ordinary Locations
PN 27085-0707
Pipe Mounted Thermostat Kit
INSTALLATION PROCEDURES
Picture Of Completed Product
E4X-1 INSTALLATION PROCEDURES
WARNING:
Disconnect Circuit Before Removing Cover
E4X Thermostat
E4X-35235 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
E4X-1-SR 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
E4X-1-ZN 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
for use in NEMA 4X Ordinary Locations
PN 27085-0707
The following installation procedures are suggested guidelines for the installation of termination and connection systems.
Receiving, Storing and Handling . . .
1. Inspect materials for possible damage incurred during shipping.
2. Report any damages to the carrier for settlement.
3. Identify parts against the packing list to ensure the proper type and quantity has been received.
4. Store in dry location prior to installation.
Kit Contents . . .
4
1
3
2
Installation Precautions . . .
• To minimize the potential for arcing and fi re caused by product damage or improper installation use ground-fault protection. The National Electrical Code (NEC) and Canadian Electrical Code (CEC) require ground-fault protection of equipment for each branch circuit supplying electric heat tracing.
• Installation must comply with Thermon requirements and be installed in accordance with the NEC, CEC, or any other applicable national and local codes.
• Component approvals and performance ratings are based on the use of Thermon specifi ed parts only.
• De-energize all power sources before opening enclosure.
• Keep ends of heating cable and kit components dry before and during installation.
• Individuals installing these products are responsible for complying with all applicable safety and health guidelines. Proper personal protective equipment, or PPE, should be utilized during installation. Contact Thermon if you have any additional questions.
Tools Required . . .
Item Quantity Description
1 1 E4X-1 Kit Assembly
2 1 Junction Box Cover
3 2 Stainless Steel Pipe Band
4 1 Thermostat Sensor
Order Separately . . . PETK Power and End Termination Kits (per cable)
PETK-1D for BSX, RSX, VSX PETK-2D for KSX, HTSX PETK-3D for HPT, FP
1
2 64
Item Quantity Description
1 1 RTV Tube
2 1 Power Connection Boot
3 1 End Cap
4 1 Tape Strip Tefl on 6" (PETK-3D only)
5 1 End Termination Caution Label
3 5
61
GRW-G Grommet (PETK-3D only) (Not used with E4X-1)
2
E4X-1 INSTALLATION PROCEDURES
WARNING:
Disconnect Circuit Before Removing Cover
E4X Thermostat
E4X-35235 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
E4X-1-SR 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
E4X-1-ZN 30A/250 Vac, 25A/277 Vac, 15A/480 Vac
for use in NEMA 4X Ordinary Locations
PN 27085-0707
45°
min.
Heating Cable
Overjacket
300 mm
(12")
1 Cut end of cable at angle to aid in piercing
grommet.
Heating Cable vs. Sensor Location
Heating
90
Sensor
45
Cable
Attachment Tape
Thermost at
Sensor
2 Insert cable into expediter piercing grommet.
Slide expediter toward pipe.
TBX Boot
Ground Braid
Screwdriver
3 Mount expediter to pipe using banding.
Do not band over cable.
Incoming Power
(by others)
4 Secure thermostat sensor to pipe using
attachment tape. Position thermostat sensor parallel to heating cable approximately 90° away from cable. See illustration showing heating cable vs. sensor location.
Decrease
Temperature
Increase
Temperature
220
235
180
160
200
140
150
120
100
Setpoint
Indicator
80
60
40
35
7 Turn thermostat dial clockwise to increase
setpoint, and counter clockwise to decrease setpoint.
5 Terminate cable with appropriate PETK
termination kit. Refer to PETK installation instructions.
L1
L2/N
G
Wiring Schematic
6 Connect incoming power (by others) and complete
system wiring. See wiring schematic.
8 Install junction box cover and tighten.
3
THERMON . . . The Heat Tracing Specialists
100 Thermon Dr. PO Box 609 • San Marcos, TX 78667-0609 Phone: 512-396-5801 Facsimile: 512-396-3627 1-800-820-HEAT www.thermon.com In Canada call 1-800-563-8461
Specifi cations and information are subject to change without notice. Form 50024-0811
®
