T36BB915SS
36-INCH STAINLESS STEEL BUILT-IN 2-DOOR
BOTTOM FREEZER, PRE-ASSEMBLED
FREEDOM® COLLECTION, MASTERPIECE® SERIES HANDLES
GENERAL PROPERTIES
Home Connect™ (Wi-Fi Enabled) Yes
Reversible Door Swing Yes
SoftClose® Door Yes
SoftClose® Drawers Yes
Carbon Air Filter Ye s
Lighting LED Sidewall and
Refrigerator Shelves 3
Adjustable Shelves – Refrigerator 2
Shelf Material Glass w/Aluminum
Full Extension Drawers @ 115° Door Opening Angle Yes
Full Extension Drawers @ 90° Door Opening Angle Yes
Adjustable Temperature Drawer 1
Humidity Managed Drawer 1
Door Bins – Refrigerator 2
Gallon Door Bins – Refrigerator 1
Also Available In:
T36BB925SS – Professional Series Handles
FEATURES & BENEFITS
- Full Stainless Steel Inner Liner
- Freedom® Hinge enables true ush design
- Auto Door Opening provides the opening of the door with just
a slight push or pull
- ThermaFresh System, Humidity and Temperature controlled
drawers
- SoftClose® Drawers for easy and controlled storage
- Sleek clean design for the perfect symmetry when paired with
additional columns
- TFT control panel managing all your columns functions
TEMPERATURE RANGES
Refrigerator 36°F (2°C) to 46°F (8°C)
Deli Drawer Just above 32°F (0°C)
SuperCool 36°F (2°C) for
Energy Saving (Economy) Mode Refrigerator: 45°F (7°C)
Freezer -11°F (-24°C) to 7°F
SuperFreeze
®
approximately 6 hours
Freezer: 3°F (-16°C)
(-14°C)
-22°F (-30°C) for
approximately 52 hours
Defrost Process – Freezer Frost-Free
Freezer Baskets 2
Ice Maker with Diamond Ice System Yes
Door Open Alarms Yes
Open Door Assist Yes
SuperCool Yes
SuperFreeze
Special Modes Sabbath, Economy,
CAPACITY
Total Capacity (cu. ft.) 19.6 cu. ft.
Refrigerator Capacity (cu. ft.) 14.0 cu. ft.
Freezer Capacity (cu. ft.) 5.6 cu. ft.
TECHNICAL DETAILS
Watts (W) 350 W
Current (A) 15 A
Volts (V) 110-120 V
Frequency (Hz) 60 Hz
Power Cord Length (in.) 118
Plug Type 120V-3 Prong
DIMENSIONS & WEIGHT
Appliance Dimensions (H x W x D) (in.) 83 3/4"* x 35 3/4" x
Required Cutout Size (H x W x D) (in.) 84" x 36" x 25"
Net / Gross Weight (lbs) 537 / 584 lbs
EFFICIENCY
ENERGY STAR® Qualied Yes
Annual Energy Consumption 504 kWh
*Height adjus table + / -11/22" (+ / -13 mm)
®
Theater Lighting
Prole
Yes
Vacation
24 3/4"
Page 1 of 3
3 / 21
90°
115°
** Door handle must be added
to this dimension
Frame
16
7/8
"**
(428 mm)
24"
(610 mm)
38
11/16
"
(980 mm)
36" (914 mm)
35
3/4
"
(908 mm)
1/8
"
(3 mm)
1/8
"
(3 mm)
3/4" (19 mm)
7
/16"
(11 mm)
T36BB915SS
36-INCH STAINLESS STEEL BUILT-IN 2-DOOR
BOTTOM FREEZER, PRE-ASSEMBLED
FREEDOM® COLLECTION, MASTERPIECE® SERIES HANDLES
WARRANTY
Limited, Entire Appliance, Parts and Labor on Any Part of the Refrigerator that Fails Because of a Manufacturing Defect 2 Year
Limited Warranty for Sealed Refrigeration System*; Parts and Labor 3rd to 6th Year
Limited Warranty for Sealed Refrigeration System*; Parts Only 7th to 12th Year
Limited Warranty for Stainless Steel Rust-Through Lifetime
*Sealed refrigeration system includes compressor, evaporator, condenser, dryer / strainer and connection tubing
CUTOUT DIMENSIONS
TOP VIEW CLEARANCE
Page 2 of 3
3 / 21
