About This Manual
This user’s guide describes the setup and operation of the TUSB3200EVM2 platform.
How to Use This Manual
Related Documentation From Texas Instruments
Preface
Read This First
This document contains the following chapters:
-
Chapter 1—Equipment
-
Chapter 2Detailed Description of the TUSB3200EVM2
-
Appendix ASchematic Diagrams
Related Documentation From Texas Instruments
TUSB3200A Literature Number SLES018 TL V2362 Literature Number SLOS195A TPS7233QD Literature Number SLVS102G CS4228 www.crystal.com for product detail information
FCC Warning
This equipment is intended for use in a laboratory test environment only . It gen­erates, uses, and can radiate radio frequency energy and has not been tested for compliance with the limits of computing devices pursuant to subpart J of part 15 of FCC rules, which are designed to provide reasonable protection against radio frequency interference. Operation of this equipment in other en­vironments may cause interference with radio communications, in which case the user at his own expense will be required to take whatever measures may be required to correct this interference.
Read This First
iii
iv
Running TitleAttribute Reference
Contents
1 Equipment 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Hardware 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1.1 EEPROM Evaluation (Internal Mode) 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1.2 In-Circuit Emulator (ICE) Evaluation 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Detailed Description of the TUSB3200EVM2 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 TUSB3200EVM2 Setup 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Interfaces and Ports 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Power Supplies 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Light Emitting Diode (LED) 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5 Jumpers 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6 Complete Analog Stage 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.7 EEPROM 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.8 TUSB3200A Development Tool Recommendations 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.9 TUSB3200EVM2 Design Platform Schematic/Layout 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figures
1–1 TUSB3200EVM2 Design Platform Equipment 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tables
1–1 Jumpers Set Up for Internal Mode 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–1 Jumpers and Switches 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents
v
vi
Chapter 1
Equipment
This user’s guide describes the setup and operation of the TUSB3200EVM2 platform. This PCB contains two main active parts: TUSB3200A STC (TI USB streaming controller) and crystal CS4228 codec. This PCB is referred to as the TUSB3200EVM2 from this point on. Familiarity with emulator hardware and software is required and assumed throughout this user’s guide.
Topic Page
1.1 Hardware 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Equipment
1-1
Hardware
1.1 Hardware
Figure 1–1 shows the equipment necessary to perform evaluation of the TUSB3200EVM2.
Figure 1–1.TUSB3200EVM2 Design Platform Equipment
USB EVM2
The TUSB3200EVM2 hardware platform measures 6.0′′ X 5.5′′ (W × L). Throughout this document text inside of parentheses (ex.) represents reference designators that identify components located on the TUSB3200EVM2.
The hardware setup for the TUSB3200EVM2 can be accomplished by two separate methods—EEPROM evaluation and in-circuit emulator (ICE) evaluation. Use of the EEPROM installed on the board is recommended when performing a quick initial check to verify if the board works properly. The respective evaluation procedures are detailed in the following section.
1.1.1 EEPROM Evaluation (Internal Mode)
The TUSB3200EVM2 comes with a preprogrammed EEPROM. This EEPROM is inserted in the 8-pin DIP socket. The jumper configuration for the internal mode is listed in T able 1–1. Use the following procedure for EEPROM evaluation:
-
Set J8 to position 1–2 to bus-power the TUSB3200EVM2; set J8 to 2–3 to put the TUSB3200EVM2 in self-powered mode (a power supply is required).
-
In self-powered mode, a single 9-V dc at 500-mA supply must be connected to the power terminals 9V and ground (GND) of the TUSB3200EVM2. Once the board is powered, GPIO, and the LEDs should turn on, and the power drawn from the supply should not exceed the USB specification of 500 mA.
-
Connect a USB cable from the root hub of the PC to type-B connector J1 on the EVM. This should start the USB enumeration on a host PC. Enumeration signals that a USB (audio) device has been detected by the
1-2
host PC and the device is ready to stream audio via a USB. A speaker icon should show up once the enumeration is complete. Double click this icon to confirm that the USB is the preferred device for audio output; if not, reconfigure the PC for USB audio output.
Table 1–1.Jumpers Set Up for Internal Mode
Jumper Position
JP1 Open JP2 Open JP3 Position 2–3 JP4 Open JP5 Open JP6 Open JP7 Open JP8 Position 2–3 JP9 Position 2–3
JP10 Position 2–3
Hardware
JP11 Position 2–3 JP12 Position 2–3 JP13 Position 2–3 JP14 Open JP15 Close JP16 Open JP17 Open JP18 Open
1.1.2 In-Circuit Emulator (ICE) Evaluation
Use the following procedure for in-circuit emulator evaluation:
-
Install the emulator. Refer to the respective ICE user’s guide for the emula- tor.
-
Attach emulator POD to TUSB3200EVM2 ICE Socket (J3). A 40-pin ex­tension adapter may be required to allow enough clearance for access to the buttons, jumpers, and connectors. Pin 1 is designated by a triangle on the opposite side of the J3 reference designator.
Equipment
1-3
1-4
Chapter 2
Detailed Description of the TUSB3200EVM2
This chapter presents a detailed description of the TUSB3200EVM2.
Topic Page
2.1 TUSB3200EVM2 Setup 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Interfaces and Ports 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Power Supplies 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Light Emitting Diode (LED) 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5 Jumpers 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6 Complete Analog Stage 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.7 EEPROM 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.8 TUSB3200A Development T ool Recommendations 2-4. . . . . . . . . . . . . . .
2.9 TUSB3200EVM2 Design Platform Schematic/Layout 2-4. . . . . . . . . . . . .
Detailed Description of the TUSB3200EVM2
2-1
TUSB3200EVM2 Setup
2.1 TUSB3200EVM2 Setup
The TUSB3200EVM2 is designed to allow development and evaluation of the TUSB3200A for multichannel applications. The USB controller (U1) accepts USB data streams and generates output at the C-port, I2C port, and/or GPIO port. A full explanation of how to configure the TUSB3200A to control the streaming data and set up the interface ports and registers is contained in the TUSB3200A data manual. A standard USB cable is required to connect the EVM platform to a downstream port. The EVM uses a standard type-B connector. Set JP8 to position 2–3 to send the MCLKO to the codec. Set JP3 to position 2–3 for normal mode operation; this action disables the external interrupt signal to the TUSB3200A. Note that an arrow always designates position 1 of any jumper. The TUSB3200A must be set to external mode to use the in-circuit emulator. The TUSB3200EVM2 board is shipped in internal mode. For internal mode, JP4 is open and JP15 is closed. T o switch to external mode, simply move the jumper from JP15 to JP4.
2.2 Interfaces and Ports
The USB port interface is the only connection required for full operation. The in-circuit emulator is required for the external emulator pad. All other connections are used to increase further development and evaluation functionality. The USB connector has four pins defined as VBUS (pin 1), D+ (pin 2), D– (pin 3), and GND (pin 4).
2.3 Power Supplies
The TUSB3200EVM2 board can be self-powered, or can use USB bus power (when J8 is set to position 2–3). In the self-powered mode, the TUSB3200EVM2 PCB requires a single positive 9-V dc supply at 500 mA. An LM317EMP regulator is used to generate a steady 5-V dc supply . This 5-V dc supply is connected to an onboard, low-dropout regulator to generate a 3.3-V dc supply. In the USB bus-powered mode, connect one end of a USB cable to the EVM board and another end of the cable to a PC root port.
2.4 Light Emitting Diode (LED)
A set of green and yellow LEDs is installed on the TUSB3200EVM2 board for quick and easy GPIO evaluation. The green LEDs are connected to port 1 bits 0 through 7 of the in-circuit emulator for external mode. The yellow LEDs are connected to port 1 bits 0 through 7 and port 3 bits 0, 1, and 3–5 of the TUSB3200A for normal mode. Note that yellow LEDs illuminate in external mode but are not GPIO functions and should not be treated as such.
2-2
2.5 Jumpers
Table 2–1 provides jumper configurations for different modes of operation.
Table 2–1.Jumpers and Switches
Jumpers
Jumper/
Switch
JP1 Position 1–2 on: Ground CRESET; JP1.1 CRESET JP2 Position 1–2 on: Ground CDA TI; JP2.1 CDATI JP3 Position 1–2:external interrupt enabled; Position 2–3:no external interrupt JP4 Position 1–2 on:external mode; Position 1–2 off: internal mode JP5 Position 1–2 on: Ground CDA TO; JP5.1 CDATO JP6 Position 1–2 on: Ground CSCHNE; JP6.1 CSCHNE JP7 Position 1–2 on: Ground CSCLK; JP7.1 CSCLK JP8 Position 1–2: MCLK to JP16.1; Position 2–3: MCLKO to CS4228
JP9 Position 1–2: CRESET to JP1.1; Position 2–3: CRESET to CS4228 JP10 Position 1–2: CDA TI to JB2.1; Position 2–3: CDA TI to CS4228 JP11 Position 1–2: CDATO to JP5.1; Position 2–3: CDATO to CS4228 JP12 Position 1–2: CSYNC to JP14.1; Position 2–3: CSYNC to CS4228 JP13 Position 1–2: CSCLK to JP7.1; Position 2–3: CSCLK to CS4228 JP14 Position 1–2: Ground CSYNC; JP14.1 CSYNC JP15 Position 1–2 on: internal mode; Position 1–2 off: external mode JP16 Position 1–2 on: Ground MCLKO; JP16.1 MCLKO
Description
JP17 Do not jumper position 1–2; JP17.1 SDA JP18 Do not jumper position 1–2; JP18.1 SCL
S1A GPIO P3.3 general-purpose momentary
button internal MCU mode
S2A GPIO P3.4 general-purpose momentary
button internal MCU mode
S3A GPIO P3.5 general-purpose momentary
button internal MCU mode
S1B GPIO P3.3 general-purpose momentary
button external MCU mode
S2B GPIO P3.4 general-purpose momentary
button external MCU mode
S3B GPIO P3.5 general-purpose momentary
button external MCU mode
J8 Position 1–2: Self-powered mode; Position 2–3: Bus-powered mode
Reset Reset EVM platform and in-circuit emulator (external mode)
Detailed Description of the TUSB3200EVM2
2-3
Complete Analog Stage
2.6 Complete Analog Stage
A complete analog output stage is provided on the TUSB3200EVM2 platform to eliminate the need for back-end development for evaluation purposes. The analog stage includes a crystal CS4228 codec and line output amplifiers with second-order low-pass filters for all six channels. A line input and a line output are also provided.
2.7 EEPROM
The EEPROM is used to set up the TUSB3200EVM2. The EEPROM is recommended to be 8K bytes to match the RAM memory size. Firmware for the TUSB3200EVM2 must be loaded for correct operation. An 8-pin DIP socket allows easy installation and removal of the EEPROM. TUSB3200A automatically downloads the data from the EEPROM into memory and begins executing code once the board is powered up and connected to the host via the USB.
2.8 TUSB3200A Development Tool Recommendations
Check the following websites for TUSB3200A development tool recommenda­tions:
8051/8052 Emulators
http://www.nohau.com EMUL51-PC/E128–16 and POD–C32–HF–42 http://www.signum.com USP–51E and POD51FX http://www.phyton.com PICE–51 and P051–RX/FA and A051–D40
8051/8052 Code Development Tools
http://www.keil.com/c51/default.htm PK51 or DK51 or CA51 (price varies
with package)
2.9 TUSB3200EVM2 Design Platform Schematic/Layout
An electronic copy of the TUSB3200EVM2 schematic is available on the TUSB3200EVM2 CD.
