Texas Instruments DAC7568EVM, DAC8168EVM, DAC8568EVM User Manual

User's Guide

SLAU301–November 2009

DACxx68EVM

The DACxx68 Evaluation Module is an evaluation board containing all the necessary components to
evaluate the eight-channel DAC7568, DAC8168, or DAC8568 series of high-performance digital-to-analog
converters from Texas Instruments. The EVM is designed so that a single printed-circuit board (PCB)
supports the entire family of high-speed, 12- to 16-bit serial DACs. The EVM is provided with Grade C
devices which reset to zero and have a full-scale output range of 0 V to 5 V.

The modular EVM form factor allows for direct evaluation of the DAC’s performance and operating
characteristics. This EVM is compatible with the 5-6K Interface Board (SLAU104) from Texas Instruments
as well as the HPA-MCU Interface Board (SLAU106).

Contents

1 EVM Overview ............................................................................................................... 2

2 Analog Interface ............................................................................................................. 2

3 Digital Interface .............................................................................................................. 2

4 Power Supplies .............................................................................................................. 3

4.1 DAC Power ......................................................................................................... 3

4.2 Stand-Alone Operation ............................................................................................ 3

5 EVM Operation .............................................................................................................. 3

5.1 Analog Output ...................................................................................................... 3

5.2 Reference In/Out ................................................................................................... 4

5.3 Digital Control ...................................................................................................... 4

5.4 SYNC ................................................................................................................ 4

5.5 LOAD DAC (LDAC) ................................................................................................ 4

5.6 CLEAR (CLR) ...................................................................................................... 5

5.7 Default Jumper Locations ......................................................................................... 5

6 Bill of Material and EVM Schematic ...................................................................................... 6

6.1 Bill of Materials ..................................................................................................... 6

6.2 EVM Schematic .................................................................................................... 7

7 Related Documentation from Texas Instruments ....................................................................... 8

1 Top Layer Assembly Drawing and Jumper Locations.................................................................. 5

1 Digital Control ............................................................................................................... 2

2 J3 Power Input .............................................................................................................. 3

3 EVM Default Jumper Settings............................................................................................. 5

4 Bill of Materials.............................................................................................................. 6

SLAU301–November 2009 DACxx68EVM

Submit Documentation Feedback

List of Figures

List of Tables

1

Copyright © 2009, Texas Instruments Incorporated

EVM Overview

1 EVM Overview

• Full-featured Evaluation Board for the 12-/14-/16-bit, eight-channel DAC7568, DAC8168, or DAC8568
digital-to-analog converters

• Onboard reference and buffer circuits

• High-speed serial interface

• Modular design for use with a variety of DSP and DACxx68 DAC Controller Interface Boards

2 Analog Interface

For maximum flexibility, the DACxx68EVM is designed for easy interfacing to multiple analog sources.
Samtec part numbers SSW-110-22-F-D-VS-K and TSM-110-01-T-DV-P provide a convenient 10-pin,
dual-row header/socket combination at J2. This header/socket provides access to the analog input pins of
the ADC. Consult Samtec at www.samtec.com or call 1-800-SAMTEC-9 for a variety of mating connector
options.

Pin Number Signal Description

J2.2 DAC OUT_G Voltage output for DAC channel G
J2.4 DAC OUT_E Voltage output for DAC channel E
J2.6 DAC OUT_C Voltage output for DAC channel C

J2.8 DAC OUT_A Voltage output for DAC channel A
J2.10 DAC OUT_B Voltage output for DAC channel B
J2.12 DAC OUT_D Voltage output for DAC channel D
J2.14 DAC OUT_F Voltage output for DAC channel F
J2.16 DAC OUT_H Voltage output for DAC channel H
J2.18 REF(–) Unused
J2.20 REF(+) External reference source input (2.5 V NOM, 2.525 V maximum)
J2.15 VCOM Common-mode voltage output option

J2.1–J2.19 (odd) AGND Analog ground connections (except J2.15)

www.ti.com

3 Digital Interface

The DACxx68EVM is designed for easy interfacing to multiple control platforms. Samtec part numbers
SSW-110-22-F-D-VS-K and TSM-110-01-T-DV-P provide a convenient 10-pin, dual-row header/socket
combination at J2. This header/socket provides access to the digital control and serial data pins of the
DACxx68 DAC EVM. Consult Samtec at www.samtec.com or 1-800-SAMTEC-9 for a variety of mating
connector options.

Pin Number Signal Description

J2.1 CNTL Active-low input to SYNC enables data transfer – jumper configurable (see schematic) via JP5
J2.3 SCLK Serial clock
J2.5 SCLK(R) Serial clock return (for DSP host systems)
J2.7 FSX Frame synchronization for DSP host systems – default SYNC input through JP5 (see schematic)

J2.9 FS(R) Frame synchronization return (for DSP host systems)
J2.11 DX Serial data input
J2.13 DR Unused – Serial data return (for DSP host systems)
J2.15 INT External source for LOAD DAC (LDAC) strobe via JP6
J2.17 TOUT Default source for LOAD DAC (LDAC) strobe via JP6
J2.19 GPIO5 Optional source for active low CLEAR (CLR) input

Table 1. Digital Control

2

DACxx68EVM SLAU301–November 2009

Copyright © 2009, Texas Instruments Incorporated

Submit Documentation Feedback

www.ti.com

Pin Number Signal Description

J2.4
J2.10 GND System (EVM) ground
J2.18

4 Power Supplies

The DACxx68EVM board is built with grade C devices and requires a single +5 V DC for proper operation.
This 5-V supply powers the onboard voltage reference (U2) and the common-mode voltage output buffer
(U3). When used in combination with one of the DAP Interface boards, J3 provides connection to the
common power bus described in document SLAA185. Table 2 shows the pinout of J3.

Power Supplies

Table 1. Digital Control (continued)

Table 2. J3 Power Input

When power is supplied to J3, JP4 allows for one of two different DC voltage sources to be applied to the
DAC installed on the EVM. Review the schematic and PCB silkscreen for details.

4.1 DAC Power

JP4 allows the user to select the power supply used by the DAC installed in position U1 on the EVM.
When JP4 is in the default factory position (Shunt on pins 1-2), power to the DAC comes from J3 pin 5,
which is designated as a +5VDC input. When the shunt on JP4 is moved to pins 2-3, the user may apply
an external power source to the DAC via TP1, referenced to TP4.

4.2 Stand-Alone Operation

When used as a stand-alone EVM, the analog power can be applied directly to TP5 referenced to pin
TP4. Optimal performance of the EVM requires a clean, well-regulated power source.

The DACs that are compatible with this EVM have a variety of power supply
requirements. Check the appropriate data sheets and verify that all power
supplies are within the safe operating limits of the converter before applying
power to the EVM.

Signal Pin Signal

Number

Unused 1 2 Unused

+5VA 3 4 Unused

GND 5 6 GND
Unused 7 8 Unused
Unused 9 10 Unused

CAUTION

5 EVM Operation

5.1 Analog Output

The analog output from the EVM is applied directly to J2 (top or bottom side) pins 2-16 (even). The
DACxx68EVM does not provide any additional filtering or buffering of the output voltage, so that the user
may evaluate the converter’s low-glitch output performance.

SLAU301–November 2009 DACxx68EVM

Submit Documentation Feedback

3

Copyright © 2009, Texas Instruments Incorporated

EVM Operation

5.2 Reference In/Out

The DAC8568, DAC8168, and DAC7568 provide the ability to use an internal reference or an external
reference in the range of 0 V to 2.5 V. The DACxx58 internal reference is powered OFF by default. The
following sections describe how to apply an external reference or use the internal reference.

5.2.1 External Reference

provides an external reference via JP3 (shorted pins 1-2 by default) from U2, a precision REF5025 source
of 2.5 VDC. When JP3 is shorted on pins 2-3, an external reference may be applied to J2 pin 20 or TP3
reference to TP2.

These external reference sources are applied to pin 8 of the DAC installed on the EVM and are also fed to
U3, a unity gain buffer configured OPA379. The output of U3 may be used to provide a 2.5-V,
common-mode input to external signal-conditioning circuits via J2 pin 15.

5.2.2 Internal Reference

The internal reference can be powered up and powered down by using a serial command that requires a
32-bit write sequence as defined in the device data sheet (see the Serial Interface section and Table 1 of
document SBAS430).

Before enabling the internal reference of the DAC installed on the evaluation
board, ensure that any shunt jumper applied to JP3 is completely removed.

www.ti.com

CAUTION

The internal reference is enabled by setting the feature bits of the DAC control register. The
DAC7568/8168/8568 data sheet provides specific details on both the static and flexible operating modes
of the internal reference. For more information on using the internal reference source, review the Internal
Reference section of document SBAS430.

The internal reference source is applied to U3, a unity gain buffer configured OPA379. The output of U3
may be used to provide a 2.5-V, common-mode input to external signal conditioning circuits via J2 pin 15.

5.3 Digital Control

The digital control signals can be applied directly to J1 (top or bottom side). The DACxx68EVM also can
be connected directly to a DSP or microcontroller capable of supplying the necessary serial control inputs.
Visit the product folder for the EVM or the installed device for a current list of compatible interface and/or
accessory boards.

5.4 SYNC

For synchronous DAC update operations, jumper JP5 is provided to allow the source selection of the
signal applied to the SYNC input of the DAC installed on the EVM. The factory default condition for the
EVM is to place a shunt jumper between pins 1-2 of JP5. This allows the Frame Sync (FS) signal from
DSP host systems to be used as the SYNC input to the DAC. This signal originates from J1.7. When the
shunt on JP5 is moved to pins 2-3, a GPIO input applied via J1.1 can be used to control the SYNC input
to the DAC. JP2 may also be used to hold the LDAC input to the DAC low, allowing synchronous DAC
output updates.

5.5 LOAD DAC (LDAC)

For asynchronous updates to the DAC outputs, jumper JP6 is provided to allow the source selection of the
signal applied to the LDAC input of the DAC installed on the EVM. The factory default condition for the
EVM is to place a shunt jumper between pins 1-2 of JP6. This allows the Timer Output (TOUT) signal from
DSP host systems to be used as the LDAC input to the DAC. This signal originates from J1.17.

4

DACxx68EVM SLAU301–November 2009

Copyright © 2009, Texas Instruments Incorporated

Submit Documentation Feedback

www.ti.com

When the shunt on JP6 is moved to pins 2-3, a user-provided GPIO input may be applied to the LDAC pin
via J1.15. This external input acts as an interrupt input to a DSP host processor which can in turn trigger a
serial transfer to the DAC. JP2 can be used to hold the LDAC input to the DAC at ground potential if
synchronous updates are required.

5.6 CLEAR (CLR)

Jumper JP1 is provided to allow the manual application of a CLR input pulse. The DACxx68EVM user
may also apply a CLR input via J1 pin 19. Bringing the CLR pin low clears the content of all DAC registers
and all DAC buffers, and replaces the code with the code determined by the clear code register. Jumper
JP1 is open by default and uses a 10-kΩ pullup resistor (R1) to maintain logic high on the CLR input pin.

5.7 Default Jumper Locations

Table 3 provides a list of jumpers found on the EVM and their factory default conditions.

Jumper Shunt Position Jumper Description

JP1 N/A

JP2 OPEN

JP3 Pins 1-2

JP4 Pins 1-2
JP5 Pins 1-2 Controls SYNC source selection – see Section 5.3 for details

JP6 Pins 1-2 Controls LDAC source selection – see Section 5.4 for details

Allows CLR to be monitored or controlled via external pulse source. Used with signals applied to
J1.19

Allows LDAC to be kept at GND potential when installed; it is recommended to remove any
shunt jumper installed on JP6 if JP1 is installed.

Controls reference voltage applied to the installed DAC. When JP3 is moved to pins 2-3, and
external reference may be applied to the EVM via J2.20 or to TP3 referenced to TP2

Analog power source control. Default is from J3.3. When shunt is placed on pins 2-3, power to
the DAC may be applied to TP1 referenced to TP4.

EVM Operation

Table 3. EVM Default Jumper Settings

The following diagram provides an overview of the DACxx68 assembly and locations of the various
jumpers and connectors.

Figure 1. Top Layer Assembly Drawing and Jumper Locations

SLAU301–November 2009 DACxx68EVM

Submit Documentation Feedback

5

Copyright © 2009, Texas Instruments Incorporated

Bill of Material and EVM Schematic

6 Bill of Material and EVM Schematic

Table 4 contains a complete bill of materials for the DACxx68EVM. The schematic diagram also is

provided for reference.

6.1 Bill of Materials

Designators Description Manufacturer Mfg. Part Number

C1, C11 CAP CER 10UF 6.3V X5R 20% 0603 TDK C1608X5R0J106M
C2 CAP CER 10UF 16V X5R 0805 Taiyo Yuden EMK212BJ106KG-T
C3 CAP CER 22UF 10V X5R 0805 Taiyo Yuden LMK212BJ226MG-T
C4, C5, C6 CAP CER .10UF 50V X7R 10% 0603 TDK C1608X7R1H104K
C7, C10 NI
C8 CAP CER 1.0UF 16V X7R 10% 0603 TDK C1608X7R1C105K
C9 CAP CER 2.2UF 10V X5R 0603 TDK C1608X5R1A225K
J1A, J2A (Top Side) 10 Pin, Dual Row, SM Header (20 Pos.) Samtec TSM-110-01-T-DV-P
J1B, J2B (Bottom Side) 10 Pin, Dual Row, SM Header (20 Pos.) Samtec SSW-110-22-F-D-VS-K
J3A (Top Side) 5 Pin, Dual Row, SM Header (10 Pos.) Samtec TSM-105-01-T-DV-P
J3B (Bottom Side) 5 Pin, Dual Row, SM Header (10 Pos.) Samtec SSW-105-22-F-D-VS-K
JP1, JP2 Header Strip ( 2 x 1) Samtec TSW-102-07-L-S
JP3 - JP6 Header Strip (3 x 1) Samtec TSW-103-07-L-S
R1, R2, R10 RES 10.0K OHM 1/10W 1% 0603 SMD Yageo RC0603FR-0710KL
R3, R6 RES 0 OHM, 1/16W 5% 0603 Chip Resistor Yageo RC0603JR-070RL
R4 RES 1.5 OHM 1/10W 5% 0603 SMD Yageo RC0603JR-071R5L
R5 RES 2.00K OHM 1/10W 1% 0603 SMD Yageo RC0603FR-072KL
R7, R8, R9 RES 33.0 OHM 1/10W 1% 0603 SMD Yageo RC0603FR-0733RL
TP1, TP3, TP5 TEST POINT PC MINI 0.040"D RED Keystone 5000
TP2, TP4 TEST POINT PC MINI 0.040"D BLACK Keystone 5001

(1)

U1
U2 IC PREC V-REF 2.5V LN 8-SOIC TI REF5025AID
U3 IC OPAMP GP R-R 90KHZ SOT23-5 TI OPA379AIDBVT

(1)

The device installed at location U1 is dependent on the EVM ordered. This device is soldered to the board for best performance.
U1 may be replaced with any device listed in the EVM Compatible Device Data Sheets table found at the beginning of this
document.

Device Under Test TI DAC8568/8168/7568ICPW

www.ti.com

Table 4. Bill of Materials

6

DACxx68EVM SLAU301–November 2009

Copyright © 2009, Texas Instruments Incorporated

Submit Documentation Feedback

+5VA

SCLK

SDI

OUT_A

OUT_B

OUT_C

OUT_D

VDD

-VA

2

-5VA

4

AGND

6

VD1

8

+5VD

10

+VA1+5VA3DGND5+1.8VD7+3.3VD

9

J3A

DAUGHTER-POWER

A0(+)2A1(+)4A2(+)6A3(+)8A410A512A614A716REF-18REF+

20

A0(-)1A1(-)3A2(-)5A3(-)

7

AGND9AGND11AGND

13

VCOM

15

AGND17AGND

19

J2A

OUTPUTHEADER

GPIO02DGND4GPIO16GPIO28DGND10GPIO312GPIO414SCL16DGND18SDA

20

CNTL1CLKX3CLKR

5

FSX

7

FSR

9DX11DR13

INT

15

TOUT

17

GPIO5

19

J1A

DAUGHTER-SERIAL

R1

10K

R2

10K

C5

0.1uF

C2

10uF

JP4

R6 0

R8 33

JP2

JP1

VIN

2

VOUT

6

TRIM

5

GND

4

TEMP

3

U2

REF5025ID

C1

10uF

C4

0.1uF

R7 33

C6

0.1uF

TP3

C8

1uF

C7 NI

C10

NI

C9

2.2F

TP1

TP4

TP2

JP5

/SYNC

LDAC

1

GND

14

VoutE

6

Vrefin/Out

8

VoutC

5

VoutA

4

CLR

9

VoutB

13

VoutD

12

DIN15SCLK16SYNC

2

VDD

3

VoutG

7

VoutH

10

VoutF

11

U1

DAC8568ICPW

OUT_E

OUT_F

OUT_G

OUT_H

FSX

CNTL

VDD

R4

1.5

R5

2K

3

4

1

2 5

U3

OPA379

JP6

C3

22uF

JP3

/CLR

/LDAC

R9

33

C11

10uF

/CLR

/LDAC

R3 0

R10

10k

VDD

VDD

VDD

DAC8168ICPW

DAC7568ICPW

TP5

www.ti.com

6.2 EVM Schematic

Bill of Material and EVM Schematic

SLAU301–November 2009 DACxx68EVM

Submit Documentation Feedback

Copyright © 2009, Texas Instruments Incorporated

7

Related Documentation from Texas Instruments

7 Related Documentation from Texas Instruments

The following devices data sheet is DACxx68EVM compatible.

• DAC7568, DAC8168, DAC8568, 12-/14-/16-Bit, Octal-Channel, Ultra-Low Glitch, Voltage Output
Digital-to-Analog Converters With 2.5V, 2ppm/°C Internal Reference data sheet (SBAS430)

blank paragraph to eliminate last blank page

www.ti.com

8

DACxx68EVM SLAU301–November 2009

Copyright © 2009, Texas Instruments Incorporated

Submit Documentation Feedback

Evaluation Board/Kit Important Notice

Texas Instruments (TI) provides the enclosed product(s) under the following conditions:
This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION

PURPOSES ONLY and is not considered by TI to be a finished end-product fit for general consumer use. Persons handling the
product(s) must have electronics training and observe good engineering practice standards. As such, the goods being provided are
not intended to be complete in terms of required design-, marketing-, and/or manufacturing-related protective considerations,
including product safety and environmental measures typically found in end products that incorporate such semiconductor
components or circuit boards. This evaluation board/kit does not fall within the scope of the European Union directives regarding
electromagnetic compatibility, restricted substances (RoHS), recycling (WEEE), FCC, CE or UL, and therefore may not meet the
technical requirements of these directives or other related directives.

Should this evaluation board/kit not meet the specifications indicated in the User’s Guide, the board/kit may be returned within 30
days from the date of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE WARRANTY MADE BY
SELLER TO BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.

The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user indemnifies TI from all
claims arising from the handling or use of the goods. Due to the open construction of the product, it is the user’s responsibility to
take any and all appropriate precautions with regard to electrostatic discharge.

EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE TO THE OTHER
FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not exclusive.
TI assumes no liability for applications assistance, customer product design, software performance, or infringement of

patents or services described herein.

Please read the User’s Guide and, specifically, the Warnings and Restrictions notice in the User’s Guide prior to handling the
product. This notice contains important safety information about temperatures and voltages. For additional information on TI’s
environmental and/or safety programs, please contact the TI application engineer or visit www.ti.com/esh.

No license is granted under any patent right or other intellectual property right of TI covering or relating to any machine, process, or
combination in which such TI products or services might be or are used.

FCC Warning

This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION
PURPOSES ONLY and is not considered by TI to be a finished end-product fit for general consumer use. It generates, uses, and

can radiate radio frequency energy and has not been tested for compliance with the limits of computing devices pursuant to part 15
of FCC rules, which are designed to provide reasonable protection against radio frequency interference. Operation of this
equipment in other environments may cause interference with radio communications, in which case the user at his own expense
will be required to take whatever measures may be required to correct this interference.

EVM Warnings and Restrictions

It is important to operate this EVM within the input voltage range of 0 V to 5 V and the output voltage range of 0 V to 5 V .
Exceeding the specified input range may cause unexpected operation and/or irreversible damage to the EVM. If there are

questions concerning the input range, please contact a TI field representative prior to connecting the input power.
Applying loads outside of the specified output range may result in unintended operation and/or possible permanent damage to the

EVM. Please consult the EVM User's Guide prior to connecting any load to the EVM output. If there is uncertainty as to the load
specification, please contact a TI field representative.

During normal operation, some circuit components may have case temperatures greater than 30° C. The EVM is designed to
operate properly with certain components above 30° C as long as the input and output ranges are maintained. These components
include but are not limited to linear regulators, switching transistors, pass transistors, and current sense resistors. These types of
devices can be identified using the EVM schematic located in the EVM User's Guide. When placing measurement probes near
these devices during operation, please be aware that these devices may be very warm to the touch.

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

Copyright © 2009, Texas Instruments Incorporated

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements,
and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should
obtain the latest relevant information before placing orders and should verify that such information is current and complete. All products are
sold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standard
warranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except where
mandated by government requirements, testing of all parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products and
applications using TI components. To minimize the risks associated with customer products and applications, customers should provide
adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right,
or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Information
published by TI regarding third-party products or services does not constitute a license from TI to use such products or services or a
warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual
property of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of TI information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompanied
by all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptive
business practice. TI is not responsible or liable for such altered documentation. Information of third parties may be subject to additional
restrictions.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids all
express and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is not
responsible or liable for any such statements.

TI products are not authorized for use in safety-critical applications (such as life support) where a failure of the TI product would reasonably
be expected to cause severe personal injury or death, unless officers of the parties have executed an agreement specifically governing
such use. Buyers represent that they have all necessary expertise in the safety and regulatory ramifications of their applications, and
acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products
and any use of TI products in such safety-critical applications, notwithstanding any applications-related information or support that may be
provided by TI. Further, Buyers must fully indemnify TI and its representatives against any damages arising out of the use of TI products in
such safety-critical applications.

TI products are neither designed nor intended for use in military/aerospace applications or environments unless the TI products are
specifically designated by TI as military-grade or "enhanced plastic." Only products designated by TI as military-grade meet military
specifications. Buyers acknowledge and agree that any such use of TI products which TI has not designated as military-grade is solely at
the Buyer's risk, and that they are solely responsible for compliance with all legal and regulatory requirements in connection with such use.

TI products are neither designed nor intended for use in automotive applications or environments unless the specific TI products are
designated by TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated
products in automotive applications, TI will not be responsible for any failure to meet such requirements.

Following are URLs where you can obtain information on other Texas Instruments products and application solutions:

Products Applications

Amplifiers amplifier.ti.com Audio www.ti.com/audio
Data Converters dataconverter.ti.com Automotive www.ti.com/automotive
DLP® Products www.dlp.com Broadband www.ti.com/broadband
DSP dsp.ti.com Digital Control www.ti.com/digitalcontrol
Clocks and Timers www.ti.com/clocks Medical www.ti.com/medical
Interface interface.ti.com Military www.ti.com/military
Logic logic.ti.com Optical Networking www.ti.com/opticalnetwork
Power Mgmt power.ti.com Security www.ti.com/security
Microcontrollers microcontroller.ti.com Telephony www.ti.com/telephony
RFID www.ti-rfid.com Video & Imaging www.ti.com/video
RF/IF and ZigBee® Solutions www.ti.com/lprf Wireless www.ti.com/wireless

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

Copyright © 2009, Texas Instruments Incorporated

Mouser Electronics

Authorized Distributor

Click to View Pricing, Inventory, Delivery & Lifecycle Information:

Texas Instruments:
DAC7568EVM DAC8168EVM DAC8568EVM
