TESTO 308 Instruction Manual
testo 308 · Smoke tester
Instruction manual
2
0970 3080 en 01 testo AG
1 Contents
0970 3080 en 01 3
Pos: 1 /TD/Überschriften/1. Inhalt @ 0\mod_1 177587817070_79.d oc @ 1243
1 Contents
1 Contents .............................................................................................3
2 Safety and the environment ..............................................................5
2.1. About this document ..................................................................5
2.2. Ensure safety.............................................................................6
2.3. Protecting the environment ........................................................7
3 Specifications.....................................................................................8
3.1. Use .........................................................................................8
3.2. Technical data............................................................................8
4 Product description .........................................................................10
5 First steps.........................................................................................12
5.1. Charging the battery ................................................................12
5.2. Connecting the mains unit .......................................................13
5.3. Switching the instrument on/off................................................13
6 Using the product ............................................................................15
6.1. Performing the leakage test .....................................................15
6.2. Performing settings ..................................................................15
6.3. Measuring ................................................................................16
6.4. Printing the measurement results ............................................18
6.5. Transferring the measurement results .....................................18
7 Maintaining the product ..................................................................19
7.1. Emptying the condensate trap .................................................19
7.2. Changing the battery................................................................20
7.3. Changing the filter paper..........................................................21
7.4. Replacing the particle filter.......................................................23
7.5. Cleaning the instrument ...........................................................24
7.6. Calibration................................................................................24
1 Contents
4
0970 3080 en 01 testo AG
8
Tips and assistance .........................................................................25
8.1. Questions and answers ...........................................................25
8.2. Accessories and spare parts....................................................26
8.3. Service information ..................................................................27
Pos: 2 /TD/--- Seitenwechsel --- @ 0\mod_1173774430601_0.doc @ 283
2 Safety and the environment
0970 3080 en 01 5
Pos: 3 /TD/Überschriften/2. Sic herheit und Umwelt @ 0\mod_11737747 19351_79.doc @ 292
2 Safety and the environment
Pos: 4 /TD/Überschriften/2.1 Zu diese m Dokument @ 0\mod_117377525 2351_79.doc @ 346
2.1. About this document
Pos: 5 /TD/Sicherheit und Umwelt/Zu diese m Dokument/Verwendung (St andard) @ 0\mod_1173775 068554_79.doc @ 337
Use
> Please read this documentation through carefully and
familiarize yourself with the product before putting it to use.
Pay particular attention to the safety instructions and
warning advice in order to prevent injuries and damage to
the products.
> Keep this document to hand so that you can refer to it when
necessary.
> Hand this documentation on to any subsequent users of the
product.
Pos: 6 /TD/Sicherheit und Umwelt/Zu diese m Dokument/Symbole und Sc hreibkonv. [Standard] @ 0\mod_1174982140622_7 9.doc @ 515
Symbols and writing standards
Representation Explanation
Warning advice, risk level according to the
signal word:
Warning! Serious physical injury may occur.
Caution! Slight physical injury or damage to
the equipment may occur.
> Implement the specified precautionary
measures.
Note: Basic or further information.
1. ...
2. ...
Action: more steps, the sequence must be
followed.
> ... Action: a step or an optional step.
- ... Result of an action.
Menu Elements of the instrument, the instrument
display or the program interface.
[OK] Control keys of the instrument or buttons of
the program interface.
... | ... Functions/paths within a menu.
“...” Example entries
2 Safety and the environment
6
0970 3080 en 01 testo AG
Pos: 7 /TD/Überschriften/2.2 Sic herheit gewährleisten @ 0\mod_ 1173780783960_79. doc @ 366
2.2. Ensure safety
Pos: 8 /TD/Sicherheit und Umwelt/Sicher heit gewährleisten/Pr odukt bestimmungsg emäß verwenden @ 0\mod_11737 81261848_79.doc @ 386
> Only operate the product properly, for its intended purpose
and within the parameters specified in the technical data. Do
not use any force.
Pos: 9 /TD/Sicherheit und Umwelt/Sicher heit gewährleisten/So nden abkühlen lassen @ 0\ mod_1190094931187_7 9.doc @ 4873
> After the final measurement, allow probes and probe shafts
to cool down sufficiently in order to avoid burns from the hot
sensor tip or the probe shaft.
Pos: 10 /TD/Sicherheit und Umwelt/Sicher heit gewährleisten/ Nicht mit Lösungsmitt eln lagern @ 0\mod_1175692 375179_79.doc @ 583
> Do not store the product together with solvents. Do not use
any desiccants.
Pos: 11 /TD/Sicherheit und Umwelt/Sicher heit gewährleisten/ Nur beschriebene W artungsarbeiten durchf ühren @ 0\mod_117569270519 5_79.doc @ 601
> Carry out only the maintenance and repair work on this
instrument that is described in the documentation. Follow
the prescribed steps exactly. Use only original spare parts
from Testo.
Pos: 12 /TD/Sicherheit und Umwelt/Sicher heit gewährleisten/ Akku-Sicherheits hinweise (LiIon) @ 0\mod_1187184666109_79. doc @ 2363
> Improper use of the rechargeable battery can lead to
destruction or injuries by means of current surges, fire or
escaping chemicals. The following instructions must be
observed to avoid such hazards:
• Only use in accordance with the directions in the
instruction manual.
• Do not short, take apart or modify.
• Do not expose to heavy impacts, water, fire or
temperatures above 60 °C.
• Do not store in the proximity of metal objects.
• Do not use leaky or damaged rechargeable batteries. In
the event of contact with battery acid: Thoroughly wash
affected area with water and consult a doctor, if
necessary.
• Only charge in the measuring instrument or the
recommended charging station.
• Immediately stop the charging process if this is not
completed in the given time.
• In the event of improper function or signs of overheating,
immediately remove the rechargeable battery from the
measuring instrument/charging station. Caution:
Rechargeable battery may be hot!
2 Safety and the environment
0970 3080 en 01 7
Pos: 13 /TD/Überschriften/2.3 Umwelt sc hützen @ 0\mod_117378084 3645_79.doc @ 375
2.3. Protecting the environment
Pos: 14.1 /TD/Sicherheit und Umwelt/Um welt schützen/Akkus/ Batterien entsorgen @ 0\ mod_1175693637007_79. doc @ 619
> Dispose of faulty rechargeable batteries/spent batteries in
accordance with the valid legal specifications.
Pos: 14.2 /TD/Sicherheit und Umwelt/Um welt schützen/Produk t entsorgen @ 0\mod_1173780 307072_79.doc @ 357
> At the end of its useful life, send the product to the separate
collection for electric and electronic devices (observe local
regulations) or return the product to Testo for disposal.
Pos: 15 /TD/--- Seitenwechsel --- @ 0\mod_1173774430601_0.doc @ 283
3 Specifications
8
0970 3080 en 01 testo AG
Pos: 16 /TD/Überschriften/3. Leistungs beschreibung @ 0\mod_1 173774791554_79.d oc @ 301
3 Specifications
Pos: 17 /TD/Überschriften/3.1 Verwendun g @ 0\mod_1176211016437_ 79.doc @ 695
3.1. Use
Pos: 18 /TD/Leistungsbeschreibung/Ver wendung/testo 308 @ 0\m od_1177404646997_7 9.doc @ 1182
Functions and use
The digital smoke tester is a hand-held instrument for
determining the smoke number of oil firing installations.
These systems can be monitored using the testo 308 and
checked for compliance with the applicable limit values.
The measuring instrument is approved for measurements under
the First Federal Immission Control Ordinance (1. BImSchV,
German ordinance).
Pos: 19 /TD/Überschriften/3.2 Techni sche Daten @ 0\mod_11762110 88437_79.doc @ 704
3.2. Technical data
Pos: 20 /TD/Leistungsbeschreibung/ Technische Daten/test o 308 @ 0\mod_1176727248645 _79.doc @ 797
Characteristic Values
Sensor Photodiode
Measuring range 0 - 6 smoke number
Resolution 0.1 smoke number
Accuracy ±0.2 smoke number
Test sample volume
1.63 ± 0.1 reference litre (990 mbar,
20 °C / 68°F)
Storage/transport
temperature
-20 to 50°C / -4 to 122°F
Operating
temperature
5 to 45°C / 41 to 113°F
Rechargeable
battery
Lithium ion, 2600mAh / 3.7V
Battery operation
time
45 individual measurements
Protection class IP 40
Interfaces IR, IRDA, optional: Bluetooth (0632 0309)
Dimensions 270 x 63 x 120 mm / 10.63 x 2.48 x 4.73"
Weight 600g / 1.33lb (including battery)
3 Specifications
0970 3080 en 01 9
Characteristic Values
Warranty
2 years, warranty conditions: See
guarantee card
EU Directive 2004/108/EC
Standards/Tests
1st Federal Immission Control Ordinance
(German ordinance)
Pos: 21 /TD/--- Seitenwechsel --- @ 0\mod_1173774430601_0.doc @ 283
