Telian K2000 User Manual
K2000 Phone
User’s Manual
Thank you for purchasing Kyocera cellular phone!
Product registration is an important step toward enjoying your new product.
Registering helps us facilitate warranty service, and permit us to contact you
should your product require an update or other service. Registration is not
required for warranty coverage.
Please retain your original dated sales receipt for your records.
Please read safety information prior to use.
The content of this manual and functions of cellular phone are subject to change
depending on the software version.
CONTENTS
PRIOR TO USE
Safety Information
Unpacking
Phone Layout and Key Description
LCD Icon Description
Charging Battery
SIM Card
BASIC FUNCTIONS
Power On/Off
Call Function
Multimedia Function
Text Input Mode
Phonebook
MENU FUNCTIONS
Menu Tree
Phone Book
Message Center
Call History
Settings
Multimedia
Fun & Games
User Profiles
Organizer
Internet
PRIOR TO USE
Safety Information
Unpacking
Phone Layout and Key Description
LCD Icon Description
Charging Battery
SIM Card
Safety Information
For the safe and efficient operation of your phone, observe the following
guidelines:
When using this phone, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, or personal injury. Read this information
before using your phone.
1. Read and understand all instructions. Follow all warnings and instructions
marked on this unit.
2. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.
3. Do not use this unit near water, for example, near a bathtub, washbowl,
kitchen sink, or similar.
4. Place this unit securely on a stable surface. Serious damage and / or injury may
result if the unit falls.
5. Do not cover the slots and openings on the unit. They are provided for
ventilation against overheating. Never place the unit near radiators, or other
sources of heat, or in a place where proper ventilation is not provided.
6. Use only the power source marked on the unit. If you are not sure of the type
of power supplied to your home or office, consult your dealer or local power
company.
7. Do not place objects on the power cord. Install the unit where no one can step
on or trip on the cord.
8. Do not overload wall outlets and extension cords. This can result in the risk of
fire or electric shock.
9. Never push any objects through the slots in the unit. This can result in the risk
of fire or electric shock. Never spill any liquid on the unit.
10. To reduce the risk of electric shock, do not disassemble this unit. Take the
unit to an authorized dealer when service is required. Opening or removing
covers may expose you to dangerous voltages or other risks and may void the
warranty. Incorrect reassembly can result in electric shock when the unit is
subsequently used.
11. Unplug the unit from the wall outlet and refer to an authorized dealer when
the following conditions occur:
a. If liquid has been spilled into the unit.
b. If the unit has been exposed to rain or water.
c. If the unit does not work normally by following the operating instructions.
Adjust only the controls covered by the operating instructions. Improper
adjustments may damage the unit.
d. If the unit has been dropped or is physically damaged.
e. If the unit exhibits a distinct change in performance.
f. When the power cord or plug is damaged or frayed.
12. Do not use this unit to report a gas leak when in the vicinity of the leak.
13. NEVER attempt to remove the antenna while the phone is in use or
switched on. Always disconnect the AC supply and remove the batteries before
disconnecting the antenna. Failure to take this precaution may result in damage to
the phone and void the warranty.
14. The batteries are for emergency backup only. Connect the AC supply and
confirm that the telephone is working normally before installing the batteries.
This phone is not intended for use without the AC adapter.
15. In the event of power failure the call may be disconnected.
16. Replace the batteries every six months to ensure proper service in the event
of power failure.
17. Making changes to the Network Settings section may prevent the phon
e from functioning normally.
Everyday Use of Your Phone
For normal operating position, hold your phone as you would any other
telephone, with the antenna pointed up and over your shoulder.
Do not touch the antenna unnecessarily when your phone is in use, as this will
affect call quality and may cause the phone to operate at a higher power level
than otherwise needed.
As with any other radio transmitting equipment, you are advised that for the
satisfactory operation of your phone and for your own safety, you should use
your phone only in the normal operating position.
Using Your Phone in a Vehicle
Safety comes first, and is the ultimate responsibility of the driver. Please:
Give full attention to driving – driving safely is your first responsibility.
Use Hands-free Kit, if available.
If you have those kits make sure it is done pre-programmed numbers where
possible, and keeping calls brief and to a minimum.
If you don’t have a Hands-free Kit, pull off the road and park your vehicle before
making or answering a call in driving conditions so require.
Radio Frequency (RF) Exposure and SAR
This phone is designed and manufactured not to exceed limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission
(FCC) of the U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the general population.
The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed to assure the
safety of all persons, regardless of age or health.
The exposure standard for this phone employs a unit of measurement known as
the Specific absorption Rate, or SAR. The SAR limits set by the FCC are
1.6W/kg. Tests for SAR are conducted using standard operating positions
accepted by the FCC with the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is determined at the
highest certified power level, the actual SAR level of the phone while operating
can be well below the maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base station, the lower the
output power. Before a phone model is available for sale to the public in the U.S.
and Canada, it must be tested and certified by the FCC that it does not exceed the
limits established by each government for safe exposure. The tests are performed
in positions and locations (e.g., at the ear and worn on the body) that conform to
a uniform testing methodology determined by an expert standards body and then
reported to the FCC. The highest SAR values for this model phone when tested
for use on the body will 0.363W/kg (GSM 850MHz head), 1.040W/kg (GSM
850MHz body), 0.570W/kg(GSM 1900MHz head) and 0.853W/kg
(GSM1900MHz body).
\
While there may be differences between the SAR levels of various phones and at
various positions, they all met the governmental requirements for safe exposure.
Please note that improvements to this product model could generate differences
in the SAR value for later products; in all cases, products are designed to be
within the guidelines.
The SAR Body-worn testing was performed with a 15mm air gap. The Users
must be informed that they must maintain 15mm separation to the body when
using body-worn accessories and the accessories must not contain metallic
components.
Caution
Modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC compliance Information
This device complies with part 15 of FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received. Including interference that
may cause undesired operation.
Information to User
This equipment has been tested and found to comply with the limits for a Class B
digital device, Pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio Frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
▪ Reorient or relocate the receiving antenna.
▪ Increase the separation between the equipment and receiver
▪ Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Pacemakers
The Health industry Manufacturers Association recommends that a minimum
separation of six inches be maintained between a mobile phone and a pacemaker
to avoid potential interference with the pacemaker. Users with pacemakers:
Always keep your phone at least 20 cm (6inches) from your pacemakers when
the phone is switched on.
Do not carry your phone in your breast pocket.
Use the ear opposite the pacemakers to minimize the potential for interference.
Switch off your phone immediately if you suspect that interference is being
caused.
Hearing Aids
Some mobile phones, including your mobile phone, may interfere with certain
hearing aids. In the event of such interference you may consult the hearing
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other medical devices, please consult a physician or the
manufacturer of the medical devices to determine if they are adequately shielded
from external RF energy. Your physician may be able to assist you in obtaining
this information. Always check the regulations of the healthcare facilities, which
generally request that all mobiles are switched off on entry.
Operating Environment
Remember to follow any special regulations in force in any area, and always turn
off your phone wherever it is forbidden to use it, or when it may cause
interference or danger.
Aircraft Safety
FCC regulations prohibit using your phone while in the air. Switch off your
phone before boarding an aircraft.
Explosive Atmospheres and Materials
Turn your phone off and do not remove the battery when in any area with a
potential explosive atmosphere and obey all signs and instructions. You must
observe restrictions on the use of radio equipment in fuel depots; below deck on
boats; fuel or chemical transfer or storage facilities; areas where the air contains
chemicals or particles, such as grain, dust, or metal powders; areas with signs
about explosive atmospheres or where blasting operations are in progress; any
other areas where you would normally be advised to turn off your vehicle
engines.
For Vehicle Equipped with an Air Bag
Al air bag inflates with great force. Do not place objects, including both installed
and portable wireless equipment, in the area over the air bag or in the air bag
development area. If in-vehicle wireless equipment is improperly installed and
the air bag inflates, serious injury could result.
Battery
Batteries can cause property damage and/or bodily injury such as burns if
conductive materials such as jewelry, keys, or beaded chains touch exposed
terminals. The conductive material may complete an electrical circuit (short
circuit) and become quite hot. Exercise care in handling any charged battery,
particularly when placing it inside a pocket, purse or other container with metal
objects. Use only K2000 original batteries and chargers.
- User Information regarding FCC label requirements.
The label will be visible at the time of purchase because the battery is
installed by the user before the first use.
Unpacking
1. Handset
K2000 Cellular Phone
2. Battery and Travel Charger
Battery
3. Accessories
User Manual
Phone Layout and Key Description
Function Keys
Left Soft Key
Right Soft key
[Basic Function]
Performs the functions indicated by the text in the leftbottom line of the display screen. Usually works as
‘selection’ key
[Idle Mode]
Enter main menu
[MPEG4 Mode]
Play & Pause MPEG4 file
[Basic Function]
Performs the functions indicated by the text in the rightbottom line of the display screen. Usually works as
‘backward’ key
[Idle Mode]
Enter Phonebook list menu
[MPEG4 Mode]
Stop playing MPEG4 file
Makes or answers a call. In the idle mode, launches the
Navigation Keys
call log menu.
Ends a call. Also switches the phone on or off when
pressed and held. In the menu, returns to the idle mode or
cancels your input.
Clear Key, Usually works as ‘cancel’ key
[Idle Mode]
Enter WAP browser mode (press and hold)
[Text Input Mode]
Switch the input methods
[Basic Function]
move the cursor or selection bar up (Text edit mode or
menu mode)
[Idle Mode]
Initiates the Audio Player.
[Camera Mode]
Zooms in, magnifying the image (Digital Zoom Function)
[ Audio Player Mode]
Play & Pause MP3 file
[Basic Function]
move the cursor or selection down (Text edit mode or
menu mode)
[Idle Mode]
Enter the Alarm menu.
[Camera Mode]
Reduce the image (Digital Zoom Function)
Audio Player Mode]
[
Stop playing MP3 file
[Basic Function]
move the cursor or selection left (Text edit mode or
menu mode)
[Idle Mode]
Enter the User Profiles menu. Set up alert tones.
[Camera Mode]
Adjust the Exposure Level
[Audio Player Mode]
Go to previous MP3 file
Video Player Mode]
[
Rewind the video file
[Basic Function]
move the cursor or selection right (Text edit mode or
menu mode)
[Idle Mode]
Enter the Tone Setup menu
[Camera Mode]
Alphanumeric Keys
Adjust
[
Audio Player Mode]
the Exposure Level
Go to next MP3 file
Video Player Mode]
[
Fast forward the video file
[Press]
Enter number and string
[Press and Hold]
: Enter ‘+’ (international call)
: On and Off silent mode
[Video Play Mode]
Wide screen view
Side Keys
[Basic Function]
move the cursor or selection bar up in menu mode
[Idle Mode]
Increase the key-tone volume
[Audio/Video Player Mode]
Increase the volume
[Basic Function]
move the cursor or selection down (Text edit mode or
menu mode)
[Idle Mode]
Decrease the key-tone volume
[ Audio/Video Player Mode]
Decrease the volume
[Short Press]
Enter the Camera Mode
[Press and Hold]
Enter the Take Video Record Mode
LCD Icon Description
This picture will be changed later
Å Fixed Icon Area
Å Network Status Area
Å User Setting Screen Area
Å Time & Date Area
Å Soft Key Area
Icon Description
Rssi Bar
Battery Bar
Shows the received signal strength. The greater the
number of bars, the better the signal strength.
Shows the current battery charge level. The green area
shows charge level of battery.
Appears when the alarm clock is set.
Appears GPRS Mode is on
Indicate the phone number line you select
Show Phone Lock mode
Roaming
Appears when you miss call
Appear when e-mail has been received
Appear when FAX has been received
Appears when Voice mail has been received
Appears when SMS has been received
Appears when MMS has been received
Appears when MMS client is busy
Appears when phone is mute mode
Appears when alert mode is selected as ring
Appears when alert mode is selected as Silent
Appears when alert mode is selected as Vibrator
Appears when alert mode is selected as Vibration and
Ring
Appears when alert mode is selected as Vibration then
Ring
Appears when WAP push is arrived
Appears when stopwatch application is undergoing
Inserting Battery
How to insert the battery
a. Align the bottom of the battery with the slot in the bottom of the phone.
b. Then sit the battery on the back of the phone until it clicks into place.
How to remove the battery
a. Turn off your phone first.
b. Push up the battery release latch
c. Slowly lift the battery away from the up.
How to charge the battery
a. Plug your charger in the wall socket.
b. Connect the other end to the interface connector on the bottom of the phone.
c. Battery can be charged if you connect USB cable to your PC from the
phone.
! Note
The phone will automatically check the battery status while the charger
connector is installed on the phone. Once it detects that the battery level
z Full status, it automatically recharges the battery.
z Normally the phone completes battery charging in one hour.
z For a new or completely discharged battery, it takes at least 4 hours of
charging to achieve optimum performance.
z You can make calls while charging your phone.
z Do not charge the phone without the battery in place.
Inserting SIM Card
SIM Card provides additional services and functions besides making a call.
These functions will only display and work on the menu of the phone if your
SIM card supports them. Some menu may not be shown depending on the SIM
card supplied.
The content and the terms of the function lists will depend on your network
service provider.
Please contact your network service provider (a network operator or the service
provider) regarding availability of services related to the SIM card, application
information and the costs.
How to place the SIM card
Ensure the phone is powered off and the travel charger is detached first before
you start the following steps.
Orientate your SIM card with its gold contacts facing downwards and push it
fully into the holder as show below.
How to remove the SIM card
Ensure the phone is switched off and the travel charger is detached first
before you start the following steps.
a. Remove the battery.
b. Remove the SIM card from the holder.
! Note: The SIM card is a computer chip containing information about your
subscription, security, phonebook etc. When you register as a subscriber with
GSM network operator, you are provided with the SIM card. Always handle the
SIM card with care and insert with the gold contacts facing down.
Inserting SD Card
SD Card provides large storage capacity for use with phone. It is compatible with
TransFlash and full size SD slots when used with an adaptor.
How to place SD card
Open the SD card slot on the right side of phone and ensure the direction of the
SD card with its gold contacts facing forward and gently press until hearing click
sound.
How to remove the SD card
Open the SD card slot on the right side of phone and gently press until hearing
click sound, then the SD card comes forward.
! Note: Please don’t forget insert with the gold contacts facing up.
BASIC FUNCTIONS
Power On/Off
Call Function
Multimedia Function
Text Input Mode
Phonebook
Power On/Off
To switch your phone On and Off, make sure that the battery is inserted.
① Open the folder.
② To switch your phone on, press and hold down [END] until you hear the
power-on melody.
③ To switch your phone off, press and hold down [END] until you hear the
power-off melody.
! Note : Some SIM card may be protected with PIN. If Enter PIN is prompted,
enter your PIN and then press [Ok soft key]. For more details, please see Security
Setting in ‘Operation – Menu’.
Call Function
Making a Call
To make a call with your phone, insure that phone screen is idle mode, then key
in the area code and phone number using the numeric keys and press the Dial &
Menu confirmation key.
You can hear the connect tone when the call is answered by the called person, if
you set the Connect tone to ON.
Making International Calls
Press and hold the ‘0’ key to display “+” character.
Enter the country code, area code (without the leading zero) and the phone
number. And then press the Dial & Menu confirmation key. The ‘+’ tells the
network that the call is international.
Edit Phone Number
Key Description
[Press]
Delete a digit on the left side of cursor
[Press and Hole]
Delete the whole digit
Move cursor to the digit you want to edit
Using Phonebook
You can store the names and phone numbers dialed regularly in the SIM card and
phone memory.
9 See Phonebook List : If you want to go to the phonebook list, push
right soft key, and then choose the name what you want to find using
Navi-Up & Down keys. Push Dial key when you want to make a call
or push left soft key to go to option menu.
9 Search Phonebook : If you want to search phonebook list with special
name, push right soft key and then push navi-down key, and then
enter the name what you want to find. Input full name or even a start
letter and select “OK” menu. If there is the name you want to call,
choose the name by moving navi-up & down key. Push Dial key when
you want to make a call or push left soft key to go to option menu.
Making a Call from Message
You can make a call from message by pushing Dial & Menu Confirmation key
when the message you want to call back is highlighted. And you can also make
by choosing “Call Back” Menu in the option of “Inbox” after you read a message.
Redialing the last Number
The phone stores the last 30 numbers dialed. To recall any of these numbers,
proceed as follows.
① Press the Dial key to display a list of the last numbers.
② Use Up & Down navigation keys to scroll through the numbers until the
required number is highlighted.
③ Dial the number highlighted
Ending a Call
When you have finished your call, briefly press the Menu exit key, or close the
folder.
Answering a Call
When you answer a call, the phone rings or vibrates according to the setting with
the incoming call animation.
When the caller can be identified, the caller’s phone number and name, if stored
in phonebook, will be displayed. If the caller cannot be identified, only the
caller’s phone number will be displayed.
9 If necessary, open the folder. Press the Dial & Menu confirmation key. If
the Any key Answer option is set to ON, you can press any key to
answer a call except for the power on/off key when the folder is open.
¾ To reject an incoming call, press and hold the volume keys on the
right side of the phone without opening the folder.
¾ If the Cover Answer option is set to ON, you do not need to press
any key. You can answer the call simply by opening the folder when
the folder is closed.
9 End the call by closing the phone or pressing the Menu exit key.
Emergency Call
Ensure that the phone is switched on and in service.
Enter the emergency number (Official emergency number or another official
emergency number) and press the Dial & Menu confirmation key. Give your
location. Do not end the call until given permission to do so.
End the call by closing the folder or pressing the Menu exit key.
! Note : In the situation such as power-on that Enter Lock Code or Enter PIN is
prompted, Some network may not allow the emergency call and may request to
insert SIM card.
Entering a “Pause” Character in a Dial String
A pause (“P”) character may be entered into a dial string by pressing the left
special function key( “*” ) three times.
Adjusting Earpiece Volume
During a call, you can adjust the earpiece volume by pressing up side or down
side of folder key on the right side of this phone. If you want to change keypad
tone, press up side or down side of folder volume key in idling mode.
Using the Earphone
If you insert the earphone to the jack of your phone, you can use it in the same
way as your phone’s earpiece and microphone.
You can answer or end a call by pressing the hook button on the earphone.
To answer another call while you are on the phone, you can answer the waiting
call by pressing the hook button on the earphone.
Multimedia Function
Camera
If you want to take a photo, please follow the procedure as below
① Open the folder.
② Press ‘Camera’ key to enter camera mode
③ Press ‘Wap’ key to take a photo
④ If you want to save the image, press save button and write the title,
otherwise press back button.
! Note: For more detailed information about this and other functions of camera,
you can refer to the below menu. (II Operation instruction => A. Menu Operation
=> 5. multimedia)
Video Recorder
If you want to take a video in your phone, choose the [Video Recorder] menu in
[Multimedia] menu.
① Open the folder.
② Choose the [Video Recorder] menu in [Multimedia] menu or press and
hold “Camera key” to enter video recorder mode
③ Press the ‘Wap’ key to take a video.
! Note: For more detailed information of the functions of camcorder, you can
refer to the below menu (II Operation instruction => A. Menu Operation => 5.
multimedia)
Video player
If you want to play MPEG4 file, please follow the procedure as below
① Open the folder.
② Choose the [Video Player] menu in [Multimedia] menu.
③ Press ‘Wap’ key to play MPEG4 file.
! Note: For more detailed information of the functions of Video Player, you can
refer to the below menu (II Operation instruction => A. Menu Operation => 5.
multimedia)
Audio player
If you want to play MP3 file, please follow the procedure as below.
① Open the folder
② Choose the [MP3] menu in [Multimedia] menu.
③ Press play button to play MP3 file or press left soft key (List) to enter
MP3 file list
Or,
① Press and hold the play key on the folder closed status.
! Note: For more detailed information of the functions of Audio Player, you can
refer to the below menu (II Operation instruction => A. Menu Operation => 5.
multimedia)
Text Input Mode
Text Input mode general
You can input and edit text by this phone.
9 Write and edit a message (SMS/MMS)
9 Enter Name (Phonebook)
9 Search mode
9 Write and edit the name of photo (Camera)
9 Write and edit the name of bookmark and WAP profile (WAP)
Text Input Methods
Mode
Screen
(SMS writing mode)
Mode
(SMS writing mode)
Screen
Multitap ES Multitap es
Smart ES Smart es
Multitap ABC
Multitap abc
Smart ABC
Smart abc
MultiTap Spanish mode (ES, es)
Key Description
[Option Soft Key] Go to option menu screen
[Press] Clear a character
[Press and Hold] Clear the entire entry
[Press] Move the cursor to the left direction by a character
[Press and Hold] Scroll the cursor leftward.
[Press] Move the cursor to the right direction by a character
[Press and Hold] Scroll the cursor rightward.
[Press] Move the cursor one line up
[Press and Hold] Scroll the cursor upward
~
[Press] Move the cursor one line down
[Press and Hold] Scroll the cursor downward
Go back to the idle screen
Insert a blank or “0”
Insert symbols ( . , - ? ! ’ @ : # $ / _
1 )
Select Spanish characters. Switch the character until the
desired character is highlighted by pressing the
alphanumeric key from 2 to 9.
Select Symbols.
Loading...
