Congratulations on the purchase of your TeleMatrix model SP-300 telephone.
The SP-300 includes advanced features that are suitable in today’s business
environment. TeleMatrix has designed the SP-300 to be simple to install and
easy to use.
The SP-300 telephone is a precision electronic device that requires minimum
maintenance. Please be sure to read the contents set forth in the user’s guide
to become familiar with the wiring and functionality of this product.
3
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to
persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming
pool.
5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation, to protect it from overheating, these openings must not be
blocked or covered. The openings should never be blocked by placing the product on the bed, sofa, rug, or other similar surface. This product
should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation unless proper ventilation
is provided.
IF UNIT IS EQUIPPED WITH POWER ADAPTER:
7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply
to your home, consult your dealer or local power company.
IF ADAPTER IS PROVIDED WITH A GROUNDED TYPE ATTACHMENT PLUG:
8. This product is equipped with a three wire grounding type plug, a plug having a third (grounding) pin. This plug will only fit into a grounding type
power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the grounding type plug.
IF ADAPTER IS PROVIDED WITH A POLARIZED ATTACHMENT PLUG:
This product is equipped with a polarized line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to inset the plug fully into the outlet, try reversing the plug. If the plug should still not fit, contact
your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
9. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be abused by personswalking on it.
10. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock.
11. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could
result in a risk of fire or electric shock. Never spill liquid of any kind on the product.
12. To reduce the risk of electric shock, do not disassemble this product, but take it to a qualified serviceman when some service or repair work is
required. Opening or removing covers may expose you to dangerous voltages or other risks. Incorrect re-assembly can cause electric shock when
the appliance is subsequently used.
13. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating instructions. Adjust only those controls, that are covered by the operating
instructions because improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to
restore the product to normal operation.
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinct change in performance.
14. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electrical shock from lightning.
15. Do not use the telephone to report a gas leak in the vicinity of the leak.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
4
FCC Part 15 Compliance
Warning Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio TV technician for help.
The term “IC:” before the certification/registration number only signifies that the Industry Canada technical specifications were met.
Canadian Emissions Compliance
" This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. "
"Le present appareil numerique n'emet pas de bruits radiolectriques depassant les limites applicables auix appareils numeriques de la
class B prescrites dans le Reglement sur le brouillage radioelectrique edicte par le ministere des Communications du Canada."
5
DOC - NOTICE AND LOAD NUMBER STATEMENT
NOTICE: The Canadian Department of Communications label identifies certified equipment. This certification means that the
equipment meets certain telecommunications network protective, operational and safety requireme nts. The Department does
not guarantee the equipment will operate to the user's satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the
company's inside wiring associated with a single line individual service may be extended by means of a certified connector
assembly (telephone extension cord). The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier.
Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications
company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and
internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural
areas.
Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.
The Load Number (LN) assigned to each terminal device denotes the percentage of the total load to be connected to a telephone loop, which is used by the device, to prevent overloading. The termination on a loop may consist of any combination of
devices subject only to the requirement that the total of the Load Numbers of all the devices does not exceed 100. An alphabetic suffix is also specified in the Load Number for the appropriate ringing type (A or B), if applicable. For example, LN = 20 A
designates a Load Number of 20 and an "A" type ringer.
NOTIFICATION TO THE TELEPHONE COMPANY
Before you may connect your telephone you must notify the telephone company of particular line(s)to which such conne ctions is to be made, and provided to the telephone company the FCC registration number and ringer equivalence number of
the registered protective circuitry. The customer shall give notice to the telephone company upon final disconnection of such
equipment or circuitry from the particular line(s).
Malfunction Of Telephone
In the event that your telephone fails to work properly during your ownership and use of it, you should disconnect it from the
telephone line to determine if it is your phone that is not working properly or if it is a problem in the telephone company's network. If the problem is with your telephone you should discontinue its use until it is repaired.
Telephone Connection Requirements
Except for telephone company- provided ringers, all connections to the telephone network shall be made through standard
telephone company provided jacks, in such a manner as to allow for easy and immediate disconnection of the terminal
equipment. Standard jacks shall be so arranged that if the plug connected thereto is withdrawn, no interference to the operation of the equipment at the customer's premises which remains connected to the telephone net work shall occur by reason
of such withdrawal. These telephones may not be used on party lines or coin operated lines.
Changes In Telephone Company Equipment Or Facilities
The telephone company is entitled to make changes in its facilities equipment, operations, and procedures. Should these
changes be expected to render your terminal equipment incompatible with the telephone company's facilities you will be
given sufficient notice to allow you to make the necessary modification to your terminal equipment without any interruption of
your service.
6
Consumer Information:
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the bottom of
this equipment is a label that contains, among other information, a product identifier in the format US:2N3MT06B19300 If
requested, this number must be provided to the telephone company.
An applicable certification jacks Universal Service Order Codes (USOC) for the equipment is provided (i.e., RJ11C ) in the
packaging with each piece of approved terminal equipment.
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See installation
instructions for details.
The REN is used to determine the number of devices that may be connected to a telephone line. Excessive Ringer
Equivalences on a telephone line may result in the devices not ringing in response to an incoming call. In most but not all
areas, the sum of Ringer Equivalences should not exceed five (5.0). To be certain of the number of devices that may be
connected to a line, as determined by the total Ringer Equivalences, contact the local telephone company. [For products
approved after July 23, 2001, the Ringer Equivalence for this product is part of the product identifier that has the format
US:2N3MT06B19300 The digits represented by 06 are the Ringer Equivalence without a decimal point (e.g., 06 is a
Ringer Equivalence of 0.6). For earlier products, the Ringer Equivalence is separately shown on the label.]
If this equipment 19300/193001 causes harm to the telephone network, the telephone company will notify you in advance
that temporary discontinuance of service may be required. But if advance notice isn't practical, the telephone company
will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you
believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the
operation of the equipment. If this happens the telephone company will provide advance notice in order for you to make
necessary modifications to maintain uninterrupted service.
Please follow instructions for repairing if any (e.g. battery replacement section); otherwise do not alternate or repair any
parts of device except specified.
Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service co mmission or corporation commission for information.
This equipment is hearing aid compatible.
NOTICE: If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this
[equipment ID] does not disable your alarm equipment. If you have questions about what will disable alarm equipment,
consult your telephone company or a qualified inst aller.
Should you experience trouble with this equipment, please contact (TeleMatrix, Inc.Customer Care Center 5025 Galley
Road Colorado Springs, CO. 80915 . Toll Free:1-800-462-9446 Direct:719 -638-8821 Fax:719-638-8815 www.
telematrixusa.com) for repair or warranty information. If the equipment is causing harm to the telephone network, the
telephone company may request that you disconnect the equipment until the problem is resolved.
[NOTICE: According to telephone company reports, AC electrical surges, typically resulting from lightning strikes, are very destructive to telephone equipment connected to AC power sources. To minimize
damage from these types of surges, a surge arrestor is recommended. ]
7
Features ......................................... ………..................................... 9
Controls …….................................................................................. 10
Parts List …………………………………………………………. 14
Installation ....…….. ....................................................................... 15
Wall Mounting .....…..............................……................................ 20
Switch Settings ..... ….......................….…....................................… 22
Programming ..…….............................. …....................................... 23
Headset Installation and Operation……........…............................... 27
Operation …………………………………………………………. 29
Care and Maintenance ……………………………………………. 37
Service ……………………………………………………………. 38
Spare Parts ……………………………………………………….. 39
Warranty ..................................................…...................……........ 40
8
? One Line Operation
? SteelTrap
? FreeSpeech
TM
Memory Technology (No Batteries Required)
TM
Talk Feature: Allows Free Toggle between Handset, and Headset.
? Visual Message Waiting Indication* – Auto Detection for SDT, FSK or NEON.
? TouchLite
TM
One Touch Message Retrieval Key
? Headset Port with ON/OFF Switch (built-in Amplifier)
? Microphone Mute
? 11 Speed Dial Locations
? Electronic Hold with LED Indicator (with Standard Line Hold or Programmable System Hold
Switch Option)
? Audible Ring Tone Selection (4 options)
? Speaker, Headset and Ringer Volume Control (Soft Key)
? Convenient Data Port
? ADA Compliant Handset with 8-step Volume Control
? Disconnect Key to Activate New Call
? Last Number Redial
? Programmable Flash Key (100mS to 1000 mS)
? Pause Key (2 seconds)
? Desk or Wall Mo untable
? Fully Modular, Easy To Install
*Caller ID and Class Visual Message Waiting are features that require subscription to your local telephone
company provided services. These telephone features will not work unless you are a subscriber.
9
TOP PANEL
(1)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(13)
(12)
(2)
10
(11)
(10)
1. Speed Dial Feature Keys……………..…… 11 programmable one-touch keys used for speed dialing
2. Disconnect Key ………………………...… Used to disconnect the line, place new call or exit the store
programming.
3. Store Key………………………………….. Used to program features and speed dialing keys.
4. Pause Key ...............................…………… Used to program a delay in speed dialing.
5. Redial Key ......................…………….…... Redials the last dialed manually dialed.
6. Flash Key ..................…………….....……. Provides a 100mS to 1000mS timed line break (programmable).
7. Mute Key …………………………...……. Key that disables the handset and speaker phone
microphones for privacy.
8. Numeric Dial Pad ………………………... Used for outbound dialing.
9. Hold Key ……………………………….… Lighted Key used for placing callers on hold.
10. Headset ON/OFF key …………………..… Lighted key used to turn the headset ON or OFF.
11. Volume Bar …………………..………….... Adjusts the loudness of the handset receiver and headset
12. Handset …………………………..………. Hearing-aid compatible handset.
13. Message Waiting Lamp...………….............. LED indicator that will blink to indicate a new message in the
user’s voice mail box (user must subscribe to a messaging
system).
11
RIGHT SIDE
(6)
LEFT SIDE
REAR
(7)
(5)
LINE
(1)
(2)
(3)
(4)
12
1. Data Port .....................................…...………... Convenient port to connect a computer,
modem, fax or answering device.
2. Line Jack ……………………………………... Modular receptacle for connecting the line cord.
3. Headset Jack .................................…………… Convenient port for a headset connection.
4. Handset Jack ..................................………….. Connection for handset coil cord.
5. Power Adapter Receptacle ……..…………… For optional coaxial power adapter.
6. Hold Key Switch ……………...……………. Used to select standard line hold or
programmable system hold.
7. Elevation Stand Lock ……………………… Used to “lock” the elevation stand.
13
Parts Check List
(4)
(8)
(9)
O
U
T
11223344556677889
9
112233445566778899101011
11
2
3. Lift off clear plastic
3
1
For models SP-100 and SP-200 Fo
r model
s with memory: SP-30
0,SP-400,SP-550,SP-
750,SP-8312
11223344556677889910101111112233445566778899101011
11
1.800.462.9446
Use this perforated sheet to customize your telephone
1. Clear plastic overlay
2
3. Lift off clear plastic
3
1
For model
s SP-100 and SP-200 For mode
ls
with memory
: SP-300,SP-400
,SP-550,SP-750,SP-8312
The following parts are included with the SpectrumPLUSTM SP300:
1. Base Unit
2. Handset
3. Two (2) 15’ Modular telephone line cords.
4. 10’ Modular coiled handset cord.
5. 6” Modular wall mount line cord.
6. Power Adapter.
7. Twenty-two (22) Speed Dial Preprinted Keycaps
8. Four (4) Additional Clear Keycaps
9. Two (2) Index Sheets
1.800.462.9446
www.telematrixusa.com
10 10
11 11
www.telematrixusa.com
(1)
(5)
(6)
P
H
O
N
E
1. Clear plastic overlay
2. Tear index paper
being remove from the
from the index sheet.
index card area on the
telephone.
Use this perforated sheet to customize your telephone
2. Tear index paper
being remove from the
from the index sheet.
index card area on the
telephone.
keycap and insert the
paper key label.
keycap and insert the
paper key label.
(2)
(7)
(3)
NOTE: SpectrumPLUSTM Line Cords are 6-Pin 6-Conductor Line cords
(6P6C line cord). Replacement Line Cords must be same.
14
Caution
? Never install telephone wiring during a lightning storm.
? Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
? Never touch uninstalled telephone wires or terminals unless the telephone line
has been disconnected at the network interface.
? Use caution when installing or modifying telephone lines.
Power Outlet Configuration
The SpectrumPLUSTM Series telephone requires external power from a standard 120V outlet (60Hz).
The telephone will not function if the line cord connections are not correct. Be sure that the telephone line cord
connections are not reversed (“LINE”/”PHONE”). Attach the line cords to the power adapter and the wall before
!
connecting to the telephone. SpectrumPLUSTM Line Cords are 6-Pin 6-Conductor Line cords (6P6C line cord) .
Replacement Line Cords must be same.
IMPORTANT!
15
120V AC Outlet Recovery Power Adapter (provided)
NEL
_
OUT
The 120 VOLT AC OUTLET RECOVERY POWER ADAPTER is an featured TeleMatrix
product. It provides both the telephone lines and the power source in one cable (6P6C line
cord) and is designed to recover the use of the power outlet.
Connector Configuration
The 120V Outlet Recovery Power Adapter has two (2) modular jacks. One jack is labeled “LINE”
and the other jack is labeled “PHONE”. These jacks allow for a fully modular installation.
Power Adapter “LINE” Connection
The power adapter “LINE” connection is used to
connect the telephone line from the wall jack to
the power adapter. Using one of the 15 foot
modular telephone line cord, connect one end of
the cord to the RJ14 telephone jack on the wall or
base board. The remaining end of the cord plugs
into the “LINE” side of the power adapter.
L2L1+L2
Power Adapter “PHONE” Connection
The power adapter “PHONE” connection is used
to provide both the telephone lines and the
power source to the telephone. Using one of the
15 foot modular telephone line cord, plug one
EHNOP
end of the line cord into the back of the
telephone. Plug the remaining end to the power
adapter jack labeled “PHONE”.
ORDER SEPERATELY
16
Installing The Wall Power Adapter
POWER
(optional)
To install, simply plug the power adapter
into a standard 120V AC power outlet. A
mounting hole is provided to secure the
power pack to the AC wall outlet. Plug the
AC power pack directly into the wall outlet
and then plug the coaxial connector into the
receptacle marked “POWER” located on the
back of the telephone.
120V AC POWER
ORDER SEPERATELY
17
Directory Index Card
10101111112233445566778899101011
11
Use this perforated sheet to customize your telephone
2
3. Lift off clear plastic
3
For models SP-100 and SP-200
The SpectrumPlusTM telephone series has
a tilting display located in the upper right
section of the telephone that allows for
sliding in directory cards, index cards,
and/or a company logo. You can even
personalize this area with photographs of
your family, friends or pets.
Customized printing of faceplates is
available by calling TeleMatrix Priority
Care for information. There is a minimum
order quantity required.
For models with memo ry: S P-300,SP-400,SP-55 0,SP-750,SP-8312
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
1.800.462.9446
www.telematrixusa.com
1
1. Clear plastic overlay
being remove from the
index card area on the
telephone.
2. Tear index paper
from the index sheet.
keycap and insert the
paper key label.
18
Connecting the Handset Cord
Handset Cord
PLASTIC KEYTOP
PLASTIC TOP CABINET
A 10 foot modular coil handset cord is
provided. (Be sure that the wall/desk eleva-
tion stand has not been attached). To install
the cord, simply plug the short end of the
handset cord into the modular jack on the
handset. The long end of the handset cord
plugs into the jack labeled “Handset” located
on the bottom of the SpectrumPLUSTM base
unit. Place the line cord into the line cord
channel located directly below the jack.
Installing the Keycaps
Twenty-two preprinted named feature
keycaps are provided to identify the speed
dial key.
There are 11 clear keycaps already installed.
To install pre-printed keys, remove the clear
keycap by simply pulling up. Replace with
the preprinted keycaps or place hand written
paper index sheets under a clear keycap.
Program each speed dial key for the specific
function of the key.
LINE
CLEAR "SNAP-ON" KEY CAP
OR SILK SCREEN KEY CAP
PLASTIC TOP CABINET
For speed dial programming instructions, see the section on “Programming Procedure For
SpectrumPlustm Speed Dial Features” in this manual.
There are 4 additional clear keycaps and 2 index sheets provided as spares. Use these for your
own personal speed dial identities. Write the speed dial name on the blank speed dial index
cards and insert into the blank keycaps. Place the keycap on the correct memory speed dial
location. (see index sheets provided in box) .
The twenty-two preprinted keycaps are described below:
Call Fwd On Call Back Paging Skip Msg Information
Call Fwd Off Cancel Call Back Ring Again FF Msg 911
Transfer Call Park Save Msg aRew Msg
Conf Call Pick-up Del Msg Emergency
DND Group Call Pick-up Rpt Msg Help Desk
19
Wall Mounting the SpectrumPLUSTM Telephone
1. UNSNAP
3. SNAP INTO PLACE.
Mounting Wedge
Spectrum Plus Bottom
The SpectrumPLUSTM was designed to be conveniently
wall mounted without requiring additional hardware.
Follow these easy steps:
1.The handset retaining clip must be in the correct
position to secure the handset into the handset cradle.
To engage the clip, pull the clip forward (outward) with
your fingers, rotate the clip 180º and snap the clip back
into place (figure 1). The retaining clip cannot be
removed because it is spring loaded.
2. The SpectrumPLUSTM has provisions for a mounting
wedge that must be correctly positioned. This wedge
allows the telephone to be viewed at a correct angle
when the phone is wall mounted. Remove the wedge
from the phone base (figure 2).
3. Secure the wiring in place prior to installing the wall
mount wedge. The wall mount base has extra large
wiring channels and strain relief poles for containing
the wires in a neat and orderly way. Wrap the wires
around the strain relief poles and then secure the wires
through the channel.
4. To wall mount, place the narrow edge at the top edge
of the phone base and slide the wedge upward into
place (figure 3) .
5. Lock the wall mount into position by sliding the
locking button to the right (figure 4).
Retaining Clip
PULL OUTWARD
2. ROTATE 180 .
Remove Mounting Wedge
Replace Mounting Wedge
Spectrum Plus Bottom
Lock Mounting Wedge
Mounting WedgeSpectrum Plus Bottom
Mounting Wedge
CLIP IS SPRING LOADED
figure 1
figure 2
figure3
Note: A 6 inch line cord is provided for wall mount
installation. Connect one end of the line cord to the
!
phone jack and the oth er end to the wall jack.
Desk Mounting
To install the wedge for desk mounting, be sure the lock mechanism is positioned to the left clear of the
locking arm. Place the wedge in the slots, wide end toward top of phone base unit, and slide the wedge
upward into position. Lock the wedge into place.
Lock mounting wedge
figure 4
20
Message Waiting Light Indicator
The SpectrumPLUSTM telephone has a Message
Waiting (MW) Light Indicator (figure 1). The
indicator will blink to indicate that a new message
is in the user’s voice mailbox. The SpectrumPLUSTM supports the following telephone or PBX
supplied message waiting signals:
1. Telephone Company VMWI Service (FSK
signal compatible, subscription to local telephone company is required).*
2. Audible Stutter Dial Tone (SDT) signals
provided by local telephone company.
3. 90-Volt NEON message waiting light indic ator signal is provided by your PBX.
The PBX system or telephone service provider
has to activate the voice mail feature for the light
to illuminate and work properly. Be sure that your
telephone service provider or PBX system has the
compatible messaging service available in your
area or facility.
!
MW Light Indicator
figure 1
NOTE: The SpectrumPLUS
telephone automatically reads the
Message Waiting (MW) signals
supplied by your service provider.
TM
*Definition: VMWI is Visual Message Waiting Indication. This option requires a
d
subscription to your local telephone service provider for TouchLite
21
TM
to activate.
System Hold Feature Option Switch
A hold feature switch is located on the
bottom of the phone. The switch options are
standard “LINE” hold or programmable*
“SYSTEM” hold.
The standard line hold allows for normal
hold function operation. The programmable*
system hold feature is used for optional
system operations.
The switch default is standard line hold.
* Programming System Hold is an Administrator function.
To program System Hold, follow the speed dial instructions
in this manual. To store the dialing pattern, press the HOLD
key in place of the memory location.
22
Programming Flash Timing into Memory
Flash Timing can be programmed into the SpectrumPLUSTM speed dial memory. This function
allows the user to dial a timed line break in the sequence of the dialing patterns when using the
speed dial keys. This function may be required for accessing line features provided by your
telephone system or local telephone company.
Programming The Flash Timing
To Program Flash Timing
1. Press the STORE key.
2. Enter the desired flash timing by entering
the desired timing using dial key pad. The
timing can be programmed between 100mS
to 1000mS. Check with your local service
provider or PBX provider to select the
appropriate correct timing.
3. The factory default Flash timing is
programmed at 600mS, which is the most
used timing option.
Using A Flash When Dialing
To use a Flash, simply press the Flash key at the appropriate point in the number sequence being
dialed from the key pad.
NOTE: Each “Flash” function counts as 1 digit when stored into a speed dial memory location. .
23
Programming Flash Timing
Flash timing can be programmed for different timing options listed below.
1. Position the handset in the Off-Hook position (lift the handset).
2. Press the “STORE” key .
3. Press following keys on the keypad in the order shown:
For 100mS press "*" "1" "#".
For 200mS press "*" "2" "#".
For 300mS press "*" "3" "#".
For 400mS press "*" "4" "# ".
For 500mS press "*" "5" "#".
For 600mS press "*" "6" "#".
For 700mS press "*" "7" "#".
For 800mS press "*" "8" "#".
For 900mS press "*" "9" "#".
For 1000mS press "*" "0" "#".
4. Place the handset cradle to the On-Hook position.
Go Off hook with handset, press “store”, then “*”, then “1”,
then “#”. Place the handset into cradle to the On hook Position.
Programming Example for 100mS
NOTE: The Flash Timing default is 600mS
24
Programming A Pause into Memory
Pause(s) can be programmed into the speed dial. This function allows the user to delay the dia ling pattern of a number. This function may be required for accessing line features provided by
your telephone system or local te lephone company. For example, a speed dial number may need
to pause during its dialing sequence to insure proper connections.
Programming the Pause Time
To Program the Timing of the Pause
The SpectumPlusTM Telephone allows you to program the timing of the Pause delay. The options are 1.0 seconds, 2.0 seconds, 3.6 seconds and 4.0 seconds. To change the timing:
1. Position the handset in the off-hook position (lift handset)
2. Press the “STORE” key.
3. Press the folowing keys on the keypad in the order shown.
For 1.0 seconds, press “#”, “1”, “0”, “#”
For 2.0 seconds, press “#”, “2”, “0”, “#”
For 3.6 seconds, press “#”, “3”, “6”, “#”
For 4.0 seconds, press “#”, “4”, “0”, “#”
4. Place the handset to the on-hook position.
Programming Pause Into Voice Mail
To Program A Timed Pause
1. To store a Pause into Voice Mail memory,
simply press the Pause key in the numbe ring sequence when programming speed
dial memory keys. See the following page
for programming speed dial.
NOTE: The default Pause timing is
2.0 Seconds. A multiple of Pauses
can be programmed into speed dial
memory to increase the delay.
Using A Pause When Dialing
To use a Pause, simply press the Pause key at the appropriate point in the number sequence being
dialed from the key pad.
NOTE: Each “Pause” function counts as 1 digit when stored into a speed dial memory location..
25
Programming Procedure For SpectrumPlustm Speed Dial Features
The SpectrumPLUSTM Telephone has 11 one -touch speed dial locations that are convenient for
dialing frequently used telephone numbers and one Voice Mail speed dial location. Each speed
dial location can store up to 32 digits. Follow the procedure below for programming the speed
dial information.
Note 1: Speed dial programming must be done with the telephone plugged into the telephone
line and power adapter.
Note 2: Programming can be performed with the telephone off-hook.
Programming Procedure
1. Speed dial or Voice Mail programming must be done with the telephone plugged into the
telephone line.
2. The handset must be “off-hook”.
3. Press the “Store” key.
4. Dial the telephone number that is to be saved using the numeric dial pad.
5. Press the desired speed dial location keys (1-11) or the Voice Mail key where the number
is to be saved.
6. To program additional numbers, repeat steps 3 thru 5.
7. Place the convenient pre-printed speed dial keycaps on the selected speed dial memory key
or complete the paper index card and place it into the clear protective keycap. Install the
keycap on the appropriate speed dial memory key.
NOTE: Blank index card sheets are provided for
convenience. Complete and place the index
card into the speed dial memory key.
26
Headset Feature
The SpectrumPLUSTM is equipped with a
separate port for plugging in an optional
headset. The port is located on the bottom of
the base unit. The TeleMatrix FreeSpeechTM
Talk Feature is a unique TeleMatrix feature that
allows the user the freedom to “toggle” between
the headset and handset modes during a
conversation.
The headset can be purchased from a
TeleMatrix distributor . There are many varieties
of headset models available.
!
NOTE: An external amplifier is NOT
recommended. The phone has a built
in amplifier.
Installing a Headset
? The headset port is located on the bottom
side of the telephone base.
? Plug the modular end of the headset cord
into the modular port of the telephone
labeled “HEADSET” (figure 1).
? Press the “HEADSET ON/OFF” key to
activate the headset. The LED above the
key will illuminate to indicate that the
headset is on (figure 2) .
27
Figure 1
Figure 2
Using A Headset
The “HEADSET ON/OFF” key controls the activation of the Headset. When using the headset
feature, the handset remains on-hook at all times.
Placing/Answering a Call
using the Headset On/Off Feature
? To answer an incoming call, press the “HEADSET ON/OFF” key to activate the headset. The
LED above the “HEADSET ON/OFF” key will be illuminated when in ON position.
? Adjust the volume, if necessary.
? Use the features of the headset that are available with the handset in use.
? You can dial using the the keypad or a speed dial key.
? To end headset activation, press the “HEADSET ON/OFF” key. The LED above the
“HEADSET ON/OFF” key will not be lighted when in OFF position.
Volume Lock Feature — When the handset or headset volume feature is selected,
the volume will automatically stay at that setting in the next use.
f
FreeSpeechTM Talk Feature is a unique TeleMatrix feature that allows the user
the freedom to “toggle” between the headset and, handset modes during a conver-
f
sation.
28
Ring Cadence Selection
The SpectrumPLUSTM allows for four
different and distinct ring cadence
selections.
To pr ogram the ring cadence, follow these
instructions.
1. Place the handset in a “on-hook” state.
2. Press the “VOLUME BAR” in either
direction to adjust the volume. This
controls the volume for listening to the
ring cadence while you are setting it
up.
3. Press the “#” key once to select the
first optional ringer cadence.
4. Press the “#” key again to select additional ringer cadences.
5. To store the desired ring cadence,
simply stop pressing the “#” key after
ringing stops. The last ring cadence
played will store into memory
automatically.
Note: Press the volume bar “?” for 5 seconds to shut off ringer.
Press the volume bar “?” for 5 seconds to turn on ringer.
29
In-Use Indicators
In-use indicator lights located above each key indicate in -use operations.
Hold Key Indicators
When the “HOLD” key is activated, the
light above the HOLD KEY will be
steadily RED.
Headset Key Indicators
When the “HEADSET ON/OFF” key is
activated, the Headset indicator will be
steadily RED.
30
Using the Data Port
The SpectrumPLUSTM is equipped with a
convenient data port on the bottom of the base
unit. This modular receptacle is used to plug
in any standard telephone device such as a
computer modem, answering machine, or fax
machine.
31
Using the Hold Feature
The “HOLD” key is used to place a caller
on hold. To use, simply press the “HOLD”
key. The LED above the HOLD key will
illuminate to indicate that the line is on
hold.
When the “HOLD” key is active, the
handset can be lifted off-hook or returned to
its on-hook position and the line will not be
disconnected. To return to the caller, simply
lift the handset
Hold will also release when the call is
picked up from an additional extension
phone.
If the headset is active prior to placing the
caller on hold, press the “HEADSET ON/
OFF” feature will re-activate.
32
Using The Mute Feature
A “MUTE” key is provided to allow
privacy during a background conversation.
When the “MUTE” key is activated, the
microphones in the handset and/or headset
are disabled.
When the “MUTE” key is activated, the
caller will not hear voice. When activated,
the LED above the Mute key will illuminate
steadily RED.
To de-activate, press the “MUTE” key
again.
33
Using the Redial Feature
The “REDIAL” key is used to automatically
redial the last number that was dialed from the
keypad.
To use:
? Lift the handset (or activate the speaker).
? Press the “REDIAL” key.
? The last number dialed will be redialed.
34
Using The Disconnect Feature Key
The “DISC” (DISCONNECT) key is a 2
second electronic timed line break. The key
can be used to automatically hang-up the
call that you are currently on and regain a
new dial tone to establish a new call.
To use:
? Simply press the “DISC” key when the
conversation is complete.
? The “DISC” key can be used with
headset or handset activation.
? The “DISC” key provides a convenient
way to disconnect the line when not
using the handset.
*NOTE: The telephone system provider or
PBX system provider must offer this feature
within their system. The telephone only
!
receives the signal from the operating
company or PBX system.
35
Handset Volume Control
The SpectrumPLUSTM is equipped with an
ADA/FCC compliant handset volume
control located on the front of the phone .
When the right end of the “VOLUME”
key is pressed, the volume of the handset
receiver is increased.
When the left end of the “VOLUME” key
is pressed, the volume of the handset
receiver is decreased.
The “VOLUME” key is an eight-step
volume control with the “1” setting being
OFF.
Volume Lock Feature — When the handset or headset volume feature is
selected, the volume will automatically stay at that settin g in the next use.
f
36
Keep the telephone dry. If it gets wet, wipe it dry immediately.
Liquids might contain minerals that can corrode the electronic
circuits.
Use and store the telephone only in normal temperature
environments. Temperature extremes can shorten the life of
electronic de vices, damage batteries, and distort or melt plastic
parts.
Keep the telephone away from excessive dust and dirt that can
cause premature wear of parts.
Wipe the telephone with a damp cloth occasionally to keep it
looking new. Do not use harsh chemicals, cleaning solvents,
or strong detergents to clean the system.
37
When problems arise during installation or service that cannot be
resolved using this or related documents, contact the TeleMatrix
Technical Service department 8:30a.m. - 4:30p.m. MST:
Toll Free: 1-800-462-9446
Direct: 719-638-8821
Fax: 719-638-8815
www.telematrixusa.com
Many times a problem is either installation or user related. Please
contact TeleMatrix PRIOR to sending a telephone to our service
center for repair. In the unlikely event that a factory repair be
necessary:
1. Include a brief description of the trouble that you are experiencing.
2. Include a proof of purchase for a repair under warranty.
3. Send the telephone prepaid by UPS or Parcel Post insured to:
TeleMatrix, Inc.
Customer Care Center
5025 Galley Road
Colorado Springs, CO. 80915
TeleMatrix will pay to return the repaired telephone to you. Allow 23 weeks for delivery.
38
Parts List
The following SpectrumPLUS
from TeleMatrix.
Part List
Description Number Price*
Handset Unit (light ash) 90027086 -ASH $24.00
Handset Unit (black) 900220801-BLK $24.00
Passthrough Power Supply Adapter (light ash) 90036006-ASH $15.00
Passthrough Power Supply Adapter (black) 900360061-BLK $15.00
Direct Connect Pwr Supply Adapter (light ash) 90036007-ASH $12.00
Direct Connect Pwr Supply Adapter (black) 900360071-BLK $12.00
15 foot Modular Line Cord (light ash) 90017023 -ASH $8.00
15 foot Modular Line Cord (black) 900170231-BLK $8.00
6 inch Modular Line Cord (light ash) 90017019-ASH $3.00
6 inch Modular Line Cord (black) 900170191-BLK $3.00
10 foot Coil Cord (light ash) 90017040 -ASH $6.50
10 foot Coil Cord (lig ht ash) 90017041-ASH $6.50
Preprinted Opaque Keycaps (Kit) STD $6.50
Custom Preprinted Opaque Keycaps CSTM Call for quote
Keycap Blank Index Card Sheet BLNK $1.50
Headset Call for quote
*Pricing in US$ Currency. Freight is Prepay and Additional. Pricing is subject to
change without notice.
tm
accessories and parts are available
To Place An Order
1. Contact TeleMatrix Customer Service department, Monday through Friday,
8:30a.m. - 4:30p.m. MST.
Toll Free: 1-800-462-9446
Direct: 719-638-8821
Fax: 719-638-8815
2. Or visit our web site for ordering information and local distributors.
39
STATEMENT OF LIMITED WARRANTY
TeleMatrix, Inc. and TeleMatrix Equipment, LLC (TMX) warrants to its [original end customer] [purc haser]
that Spectrum, Spectrum Plus and Marquis branded products manufactured by TMX are free from defects in
materials and workmanship for five (5) years after the date of purchase, and Regency branded products
manufactured by TMX are free from defects in materials and workmanship for three (3) years, other than the
following products for which the warranty period shall be one (1) year: handset batteries, either NiCd or
NiMH, used in TMX cordless products. If a product fails this warranty during the warranty period, TMX will,
at its option, either repair or replace the defective product or parts, or deliver replacements for defective pro ducts or parts on an exchange basis at no additional charge to the customer except as set forth below. Repair
parts or replaceme nt products may be either new or reconditioned. Products or parts returned to TMX under
this warranty will become the property of TMX. Warranties on products repaired by TMX expire at the
termination of the original warranty period.
This limited warranty does not cover:
1. Products or parts which are damaged, abused or misused;
2. Any damage resulting from improper installation, maintenance or operation of the product;
3. Damage resulting from unauthorized modification or repair of the product, or from improper
connection of the product to other equipment;
4. Cords, connectors and replaceable batteries;
5. Damage in transit to the TMX repair facility;
6. Any product or part unless proof of date of purchase is submitted with the product when returned for
warranty repair; or
7. Costs incurred by the customer in removing and shipping the product to TMX for repair or
replacement, and costs of reinstallation of the product.
8. Products or parts which are not owned and used by the original end user customer.
The cost and risk of loss or damage for sending the product to TMX will be borne by the customer .
TMX EXPRESSLY DISCLAIMS ALL WARRANTIES EXCEPT THE LIMITED WARRANTY SET
FORTH HEREIN, WHICH IS THE SOLE AND EXCLUSIVE WARRANTY OF THE PRODUCT, AND IS
IN LIEU OF ALL OTHER WARRANTIES, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED,
OR STATUTORY. THERE ARE NO IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. THE CUSTOMER’S SOLE REMEDY UNDER THE TMX
WARRANTY SHALL BE REPAIR OR REPLACEMENT AS PROVIDED ABOVE. IN NO EVENT WILL
TMX BE LIABLE TO CUSTOMER OR ANY OTHER PARTY FOR ANY INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES, INCLUDING, WITHOUT LIMITATION, DAMAGES OF LOST
PROFITS, LOST REVENUES, LOSS OF USE OF FACILITIES OR EQUIPMENT, OR COST OF
SUBSTITUTE EQUIPMENT ARISING OUT OF THE USE OR INABILITY TO USE THIS PRODUCT,
EVEN IF THE CUSTOMER HAS ADVISED TMX OF THE POSSIBILITY OF SUCH DAMAGES. TMX
LIABILITY FOR DAMAGES SHALL NOT EXCEED THE PURCHASE PRICE OF THE DEFECTIVE
PRODUCT.
This limited warranty is non-transferable without the prior written approval of TMX. It gives the customer
specific legal rights. The customer may have other rights which vary under local law. Some jurisdictions may
not allow limitations on the term of an implied warranty or exclusions or limitations of incidental or
consequential damages.
40
Loading...
