Telefunken TF-PS2201 User Manual

PORTABLE MINI MUSIC SYSTEM WITH
BLUETOOTH
ПОРТАТИВНАЯ МУЗЫКАЛЬНАЯ MINI СИСТЕМА
С BLUETOOTH

TF-PS2201

Instruction manual

Руководство по
эксплуатации

Instruction manual

Dear customer!

Thank you for purchasing our product. For safety, it is strongly recommended to read
this manual carefully before connecting, operating and/or adjusting the product and keep
the manual for reference in future.

Description

Top panel

1. USB port

2. SD memory card slot

3. LINE input

4. PLAY/PAUSE ( ) button

5. PREVIOUS (PREVIOUS (

6. SOURCE button

7. POWER ON-OFF / Battery level

) butto((

) button 8. NEXT (

9. Display

10. Master volume knob

11. Microphone volume knob

12. Microphone input

13. Handle

Side panel

1. AC power socket

13

1
2

3
4

5
6

8

7

10

9

12
11

1

3

Instruction manual

Utilization of the product

If you want to dispose this product, do not
mix it with general household waste. There is a
separate collection system for used electronic
products in accordance with legislation that
requires proper treatment, recovery and
recycling.

Please contact your local authorities for
the correct method of disposal. By doing so,
you will ensure that your disposed product
undergoes the necessary treatment, recovery
and recycling and thus prevent potential
negative effects on the environment and
human health.

Important safeguards

• The instruction manual contains important
operating and maintenance instructions. For
your safety, it is necessary to refer the manual.
Keep the manual for use in future.

• Do not hit or drop the unit.

• Do not expose the unit to vibration, direct
sunlight, too high or low temperature or humidity.

• Do not disassemble the unit yourself.
Refer servicing to qualified service personnel.

Power supply

• The unit operates on an internal
rechargeable Li-ion battery.

• The battery can be recharged with
the provided AC power cord. Before first
plugging the appliance check that voltage
indicated on the rating label corresponds to
the mains voltage in your home.

• Insert the power cord into the
AC power input socket on the side of the unit.

• Plug the power cord into the wall outlet.

• Press and hold the POWER button to

switch on the unit.

• The percentage of battery charge will be
shown on the screen when you press the
POWER button shortly.

• For best results, try to fully charge the
battery before each use. If the battery is
drained, please allow it to recharge for a few
hours.

Checking the battery life

• This device is designed with a smart

battery check feature for your convenience.

• Press the battery level button to display
the current battery charge level while the unit
is not charging. The charging indicator lines

will keep flashing during charging.

4 lines are lit ~ 100% full
3 lines are lit ~ 75% full
2 lines are lit ~ 50% full
1 line is lit ~ 25% full (charging is needed).

General operations

Power on/off

Press and hold the POWER button to switch
the unit on. Press and hold it again to switch
the unit off.

Line input

You can connect the audio output of an
external device to this unit, to listen to the sound
of that device through the speakers of this unit.

• To connect an external audio device,
please use a standard audio cable with 3.5­to-3.5 mm plugs to connect the input terminal
LINE IN on the unit.

• Press the SOURCE button to
switch to the LINE IN mode. The display

screen will show "LINE".

• Turn on the external device. You cannot
control playback with the buttons of this unit
except adjusting the volume.

Volume control

Rotate the master volume knob to adjust the

general volume level of the unit.

You can also separately adjust the volume of
microphone (if connected) by rotating the
microphone volume knob.

Modes

Press the SOURCE button repeatedly to
select an operation mode: Bluetooth => LINE
=> USB => SD => TUNER. The USB and SD
modes are available only if an appropriate
storage device is plugged in.

4

Bluetooth operation

Instruction manual

• The Bluetooth pairing name of the unit is
TF-PS2201.

• Press the SOURCE button on the top
panel to switch to the Bluetooth mode.

• Use your mobile phone to search the
Bluetooth signal of the unit, then input the
password 0000 if necessary. The units
are paired when "bt" appears on the
screen.

• Switch off the Bluetooth function on your
mobile phone to disconnect the units.
When paired successfully for the first
time, this unit will automatically connect
the paired device when it switches on.

• Effective connection range is 10
meters.

••You can unpair the devices by

deleting the TF-PS2201 Bluetooth
connection from your mobile phone
connected devices list or by
pressing and holding the PLAY/
PAUSE button in Bluetooth mode.
In Bluetooth mode you can control
playback and volume using the
standard control elements of this
unit.

Microphone

• You can insert a microphone for karaoke
or other purposes into this unit by
connecting it to the Microphone input.

• While connected, you can control the
microphone volume and echo effect by
rotating the corresponding knobs.

USB/SD operation

USB/SD playback

• Insert a USB drive/SD CARD in the
corresponding USB port / SD card slot, the unit
will switch automatically to USB/SD CARD play
mode .

Playback operations

• During playback press the PLAY/PAUSE
button on the unit to pause playback. Press
this button again to resume playback.

• During playback press PREVIOUS/NEXT
buttons to go to a previous or a next track.

General USB/SD notes

• This unit is equipped with a USB port
that can read and play MP3 files stored on
standard USB flash drives (compatible with
USB version 2.0) up to 32 GB.

• This unit is also equipped with an SD
card socket that can accept and play MP3 files
stored on standard SD cards up to 32 GB.

Always switch off the unit or change
mode to another one before removing a USB
flash drive or SD card, to prevent damage to
your USB device or memory card.

Note: Although this product is fully

compatible with USB 2.0 and SD card standard
formats, a small percentage of USB flash drives
and SD cards might not be readable, due to
those device manufacturers’ non-compliance
with the full (official) USB and SD card
standards.

• FAT and FAT32 file system are

supported by USB and SD ports of this unit.

According to the USB 1.1/2.0 standard,
usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power
for connected USB drives with power
consumption exceeding this value as well as
defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warranty cases.
Warning: use of external USB drives
containing BIN files in root directory may
cause malfunction of unit or damage to the
software.
