Telefunken TF-LED22S14T2 User manual

LED TV Телевизор цветного изображения c жидкокристаллическим экраном

TF-LED22S14T2

Instruction manual

Руководство по эксплуатации

Table of contents

Dear customer!

Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully before connecting, operating and/or adjusting the product and keep the manual for reference in the future.

Table of contents Before you start

Utilization of the product Important safeguards Installation

Base installation Wall mounting

Connection

Outdoor antenna connection Other connections

Operation

Control elements

Front panel

Back panel Remote controller

Changing the battery

General operations

Signal sources

Teletext operations

OSD operation

Picture setting Sound setting Channel setting Feature setting Setup menu

USB operation

General playback information Operations of file playback

Electronic programme guide (EPG) General information

Troubleshooting

Causes of interference Accessories Specifications

2 3 3 3 4 4 4 5 5 5 6 6 6 6 7 7 8 8 8 9

9 10 10 11 11 12 12 12 13 14 14 14 15 15

Before you start

Utilization of the product

If you want to dispose of this product, do not mix it with general household waste. There is a separate collection system for used electronic products in accordance with legislation that requires proper treatment, recovery and recycling.

Please contact your local authorities for the correct method of disposal. By doing so, you will ensure that your disposed product undergoes the necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment and human health.

Before you start

Important safeguards

• Please unplug the power cord from the AC outlet and contact a service center for repair if following occurs: any obvious abnormality appears in the unit, such as smoky, peculiar smell or strange sound; liquid has been spilled or other objects have fallen into the unit; no picture or sound; cover or panel is broken; although you have operated the unit following the operating instructions, it still cannot work normally.

• This unit can be connected to a power supply outlet without the third ground contact as well as with a ground contact.

• Always disconnect the power cord and antenna during a storm.

• Do not fix the power cord with a metal nail.

• Unplug the power cord from the AC outlet; also unplug the signal cables from the input ports when the unit is unused for long periods of time.

• When unplugging the plug, always hold the wide slot, do not touch the metal part, and do not destroy, twist, pull or roast the power cord.

• When connecting cables, make sure the power is switched off.

• Please contact the service center immediately if you found that the core is showed in the air or has been broken.

• Please replace the AC outlet if the metal bolt cannot be inserted into the power socket completely or it cannot be fastened even when

it was pushed in, otherwise, any accidents of shocks and fires would happen.

• Never touch the antenna lie or power plug

if it stars to thunder.

• Do not touch the power plug with wet

hands.

• Do not use any non-rated power socket with numerous devices jointed on one power socket or cable device. The wire of nondesignated capacity may cause the fire due to the generation of heat.

• All instructions must be read and understood well before you operate the unit. Heed all warnings and follow all instructions.

• Please use the accessories provided by the manufacturer. Using inadequate accessories may result in accidents.

• Please adjust the product through the panel buttons or the remote controller, do not remove the cover or attempt to service the product by yourself. Do not disassemble back cover and do not make maintenance by yourself to avoid the electric shock.

• Over-press the panel may destroy the product.

• Do not place the product on an unstable cart, stand surface, tripod, bracket, or table. The product may fall, causing serious accidents as well as the damage to the product.

• Please place the product on a flat surface in a well-ventilated location. Keep it away from the burning-light, direct sunlight, vibration, high-temperature and humidity.

• Do not place any vase, potted plant, cup,

Before you start

medicine and any container with water on this product. If the liquid is spilt, it may cause the fire, electric shock or breakdown.

• Do not install it at the place on the strong magnetic field or current field. It may cause break down. This equipment may be observed deterioration of the picture by electromagnetic radiation in electromagnetic environment.

• Fasten the wheel of the product or shelf with wheels when installing this product. If it moves or is tipped over, it may be damaged.

• Do not place any fire source such as candlelight close to this product or place it on this product. If it is tipped over or fallen down, it may cause damage or fire.

• Do not place the unit into closed space of TV for better ventilation; it can reduce the product lifetime. Keep a space at least 10 cm at above, left, and right of the TV.

• Please place all the signal cords behind of rear panel.

• Do not overexert or touch the panel when you convey the product. Do not transfer the LED TV up or down display direction.

• Do not transport it with the power cord or the connection cable connected. If you move this product with the power cord or the connection cable connected, damaged power cord, connection cable or connection terminal may cause fire, electric shock or breakdown.

• 2 persons or more shall transport the device, which is heavier than 18 kg. If you drop or tip over the device, it may damage it.

• The temperature of the product’s body becomes a little higher after a long period use. This phenomenon indicates that heat exchange in normal working mode, thus please do not let children or anyone who is sensitive of temperature to touch.

All images provided herein are schematic

drawings and may differ from real objects.

Installation

Base instalation

Cover a flat stable surface with a soft cloth. Place the TV unit facedown on the cloth. First align the holes on the back panel with the supports, then fix them using the screws provided.

Wall mounting

• Unscrew the 4 screws from the stand in the back of the unit. Separate the stand from the cabinet before wall mounting.

• For wall mounting the back cabinet of this unit is equipped with 4 screw holes. Spread distance between the holes is 100*100 mm. A VESA wall-mount bracket should be used for wall mounting (the bracket is not included and should be acquired separately). Manufacturer is not responsible for improper mounting resulting in damage of the unit.

Wall or ceiling mounting implements must be durable and sufficient enough to support the weight of the unit.

Connection

Before you start

Outdoor Antenna Connection

Use 75Ω coaxial cable plug or 300-75Ω impedance converter to plug in antenna input terminal on the rear of the cabinet.

Other connections

• Connect the audio sources (Including DVD, VCDR, CAMCORDER and PC) to the proper Audio input jacks ‘L’ and ‘R’.

• Connect the video source to the Video input using an RCA cable.

• Plug the power cable in the electric outlet, making sure the current voltage is supported.

• When using the LED as a computer screen, connect the PC to the VGA jack from the monitor by the relevant cable (not included).

• This unit has PC audio in jack. Connect this jack to PC main unit with related audio cable in PC mode and adjust the volume to what you want.

• If the video source has a HDMI output jack, you can connect the signal to the monitor by the HDMI cable (not included).

• Coaxial output is intended for transmitting multi-channel sound to an external decoder (e.g. in 5.1-CH format). Coaxial cable should be used for connection.

• Connect your headphones or earphones (not included) to the headphone socket of this unit. When earphones are connected, the sound output through the built-in speakers of this unit is mute.

• PCMCIA slot is used for CI modules that are obtained from your digital TV provider.

Operation

Control elements

Front panel

1. VOL+/VOL- buttons

2. CH+/CH- buttons

3. SOURCE button

4. MENU button

5. (POWER/STANDBY) button

1. Power cable

2. VGA input

3. PC audio input

4. Composite input

6. HDMI input

7. Coaxial output

8. USB port

10.

11.

Back panel

TVRF antenna input

Component video in PCMCIA slot

Earphone jack

Operation

Remote controller (RC)

4 5 6

11 12 13 14 15 16 17 18

1. POWER button

2. Number buttons

3. DTV/ATV button

4. P.MODE button

5. S.MODE button

6. MENU button

7. Cursor (UP/DOWN/LEFT/RIGHT) buttons/ ENTER button

8. EXIT button

9. MTS button

10. VOL+/VOL- buttons

26 27

28 29

30 31 32 33 34

11. FAV/LIST button

12. ASPECT/

13. GUIDE/

button

14. TIMESHIFT/ button

15. INDEX/ button

16. REVEAL button

17. SIZE button

18. RED button

19. GREEN button

20. MUTE button

21. button

22. SLEEP button

23. SOURCE button

24. DISPLAY button

25. CH+/CH- buttons

26. RECLIST button

27. REC button

28. FREEZE button

29. CANCEL/ button

30. SUB.PG/ button

31. TV/RADIO button

32. SUBTITLE button

33. TEXT button

34. HOLD button

35. CYAN button

36. YELLOW button

Changing the battery

1. Remove the battery compartment cover on the back of the RC.

2. Insert two AAA batteries into the battery compartment making sure that the correct polarity is observed.

3. Install the cover back.

• The RC should be pointed at remote sensor within 8 meters and within 30 degrees at the left or the right side.

• Take the battery out of the RC if it is not used for a long time.

• Do not mix new and used batteries or different types of batteries. Weak batteries can leak and severely damage the RC.

• Do not expose the RC to shock, liquids, and do not place it in an area with high humidity.

Operation

General operations

• Press button on the unit or on the RC to switch on the power. Press POWER button again to switch the unit off and go the the stand-by mode. To completely power off the unit unplug the power cable from the outlet.

• Press VOL- button repeatedly to decrease the volume; press VOL+ button repeatedly to increase the volume.

• Press SLEEP button repeatedly to set the sleep time.

• Press ATV/DTV button to switch between analog and digital TV.

• Press GUIDE to launch the Electronic Program Guide (EPG) or for a fast reverse in recording (PVR) or Media Player mode.

• Press TIMESHIFT to enable the Time Shift function for digital TV or to play in PVR or Media Player mode

• Press SUBTITLE to show and set the language of a current DTV channel.

• Press REC to begin recording of current playback in PVR mode. Press RECLIST to show the list of recorded files.

• Press button on the RC to select from the present channel and the previously displayed channel.

• Press ASPECT button repeatedly to select a screen display size from the available list: 4:3/16:9/Zoom1/Zoom2/Panorama. Available aspects may differ for different signal sources.

• Press MUTE button to cut off sound, press this button again or adjust volume to resume sound.

• Press TV/RADIO button to switch between TV and radio modes when watching channels.

• Select the TV function mode. Press CH-/CH+ buttons to select previous or next channels; or press number buttons to enter a channel number directly.

• Press P.MODE button repeatedly to cycle through the available video picture modes.

• Press S.MODE button repeatedly to cycle through the available sound modes.

• Press DISPLAY button to display the

preset TV channel play information.

• Press FREEZE/

picture on or off.

• Press FAV button to show the favourite channel list. Press FAV+/FAV- buttons to select next or previous favorite channel.

• Press MTS button in TV mode repeatedly to switch between various Nicam sound modes (can be unavailable for some channels).

button to freeze the

Signal sources

Press SOURCE button, then press DOWN/ UP cursor buttons on the RC or CH+/CHbuttons on the panel to select a source from available source list: DTV - ATV - AV - HDMI PC - MEDIA. Press ENTER button on the RC or MENU button on the panel to confirm. Press EXIT to exit.

TELETEXT operations (option)

• Select the TV source mode. Then press CH-/CH+ buttons to select TV channel in order to pick up the picture signal of Teletext.

• Press CH-/CH+ buttons to select the previous page or the next page.

• Teletext button functions are as follows:

ON/OFF: Press TEXT button to enter into TEXT mode. Press this button again to return to the channel you are watching.

HOLD: Press this button to stop the move to the next page. Press this button again to cancel operation.

INDEX: Press this button to go to the index page.

SIZE: Press this button to enlarge the text shown on the teletext screen, and one half of page could be shown. Press this button again to view the second half of this page. Press this button third time to normal size text page view.

REVEAL: Press this button to reveal the cancelled information. Press this button again to cancel the information.

SUB.PG: Press this button to select sub page, and the sub-page symbol will appear in the left top hand corner of the screen. Enter the number of sub page and use numeric buttons in the format 0001 for sub page 1. The teletext

Operation

will search for the sub page.

CANCEL: When a text page is selected, it may take some time before it becomes available; press this button to return to TV mode. When the required page is found, its number will be displayed at the top of the screen; press this button to return to the teletext mode and browse the page.

RED/GREEN/YELLOW/CYAN buttons: Press these 4 color buttons to access directly to corresponding color page displayed at the lower parts of teletext screen.

OSD operation

1. Press MENU button to enter the setting

menu displayed on the screen.

2. Press LEFT/RIGHT cursor buttons on the RC or VOL+/- buttons on the panel to select setting page.

3. Press DOWN cursor button or ENTER button on the RC or CH+ button on the panel to go to the parameter list.

4. Press UP/DOWN cursor buttons on the RC or CH+/- buttons on the panel to select a parameter to adjust.

5. Press cursor buttons on the RC or VOL+/or CH+/- buttons on the panel to adjust the selected parameter.

6. Press EXIT button to quit the menu.

Some menu items may be in grey color, in this case they are not adjustable. Pictures of OSD menu are for reference only; they may differ from the real screens.

Picture Menu


Picture mode Brightness Contrast Sharpness

Colour Tint

Colour temperature Aspect Ratio PC Setup Screen Mode

Move

Adjust

• Picture Mode: Press UP and DOWN buttons to select Picture Mode, then press LEFT/RIGHT button to select one of the picture modes: Standard, Mild, Personal, Dynamic).

Press P.MODE to change the picture mode directly.

• Brightness/Contrast/Sharpness/ Saturation/Hue: Press UP/DOWN to select the option, LEFT/RIGHT to adjust.

Brightness: adjust the picture brightness. Contrast: adjust the highlight intensity of the

picture.

Sharpness: adjust the peak level of detail in

the picture.

Saturation: adjust color intensity. Hue: use to compensate color in NTSC

transmission.

• Color Temp: change the overall color temperature of the picture:

Standard: Default vivid color temp. Cool: gentle blue-hued image. Warm: bright red-hued image.

• Aspect Ratio: select the screen aspect ratio: Auto/Full/4:3/16:9/Zoom1/Zoom2.

• PC Setup: adjust the screen parameters when using PC as a source.

Auto adjust: automatical setting of the

parameters.

Horizontal Position: adjust horizontal position

of the image.

Vertical Position: adjust vertical position of

the image.

Phase: adjust the phase manually. Clock: adjust the image frequency manually.

• Screen Mode: select the screen mode.

EXIT: ExitMENU: Return

Operation

• Advanced Settings: allows a more

detailed picture setup for advanced users.

Sound Menu

Sound

Sound mode Treble Bass Balance

AVL SPDIF

Move

Adjust

• Sound Mode: Press UP and DOWN buttons to select Sound Mode, then press LEFT/RIGHT button to select one of the sound modes: Standard, Мusic, Personal, Movie). Press S.MODE to change the picture mode directly.

• Treble/Bass/Balance: Press UP/DOWN to select the option, LEFT/RIGHT to adjust.

Treble: adjust the treble effect to increase or

decrease high-pitched sounds.

Bass: adjust the bass effect to increase or

decrease low-pitched sounds.

Balance: adjust the balance between left and right speakers to adapt to your listening position.

• Surround Sound: toggle the surround

effect on/off.

• EQ Setting: adjust the 7 band equalizer or choose among presets: Off, Rock, Pop, Jazz, User.

• AVL: toggle auto-volume control on/off. Volume automatically remains on the same level of volume if you change programmes. Because each broadcasting station has its own signal conditions, volume adjustment may be needed every time when the channel is changed. This feature allows users to enjoy stable volume levels by making automatic adjustments for each program

• SPDIF: toggle digital sound via coaxial cable on/off or set it to auto.

• Audio Description: view the information on the current sound channel.

• Sound Type: Stereo/Dual I/Dual II/Mixed

EXIT: ExitMENU: Return

Channel setting

Channel

Tuner Type Auto Scan Manual Scan Auto Channel Update Channel Edit Common Interface Signal Information

Move

Adjust

• Tuner Type: Antenna/Cable.

• Auto Scan: select this option to auto scan

for available channels.

Country: select your country. Mode: select the scan mode: DTV+ATV,

DTV, ATV.

Scan Type: select scan type: Advanced/

Quick/Full.

Network ID: Auto/Manual enter. Frequency: Auto/Manual enter. Symbol Rate: Auto/Manual enter.

Start: start the auto search. Digital channels will be searched first, then analog channels. Make sure you select either Antenna or Cable as your tuner type.

• Manual Scan: select this option to scan

for available channels manually.

Digital Manual Scan: manually search for digital channels. If you select Antenna as your Tuner Type simply select the channel number and press Start to initiate scanning. If your Tuner Type is Cable then following options become available:

Network ID: Auto/Manual enter.

Frequency: Auto/Manual enter.

Symbol Rate: Auto/Manual enter.

Modulation: Auto/16QAM/32QAM/64QAM/1 28QAM/256QAM.

Start: start the manual search.

Analog Manual Scan: manually search for analog channels.

Analog Scan: select scanning frequency.

Color System: Auto/PAL/SECAM.

Sound System: Auto/DK/BG/I/L.

Modulation: Auto/16QAM/32QAM/64QAM/1

EXIT: ExitMENU: Return

Operation

28QAM/256QAM.

AFC: automatic fine tuning on/off. Start: start the manual search.

• Auto Channel Update: enable/disable

automatic update of channel information.

• Channel Edit: enter the channel editing menu. RED, GREEN and CYAN (blue) buttons are used as shortcuts. Select the channel you want to edit with the UP/DOWN buttons and then press:

RED button to delete the channel. GREEN button to skip the channel when

browsing with CH+/- buttons.

BLUE button to make the channel movable

in the list with cursor buttons.

• Common Interface: select this option to enter the common interface submenu. Only available when a CI card inserted in the PCMCIA slot in DTV mode.

• Signal Information: view the detailed information about the current signal. Only available in DTV mode.

Lock System menu

Lock System

Enter Password Enable Channel Locks Parental Rating Lock Keypad New Password Hotel Mode Clear Lock

Move

Adjust

• Enter Password: to access this sub-menu you must first enter the system password. Default password is 0000.

• Enable: enable/disable the the lock system. Channel locks, Parental Rating and Lock Keypad option are available when the Lock System is enabled.

• Channel Locks: access the channel locks sub-menu.

• Parental Rating: access the parental ratings sub-menu. This feature can prevent

EXIT: ExitMENU: Return

children watching adult’s TV programmes, according to the rating limit set. This function appearance according the information from broadcasting station. Therefore if the signal has incorrect information, this function does not operate.

• Lock Keypad: on/off. Lock the buttons on the TV to prevent from being pushed by young children or other unexpected usage.

• New Password: enter a 4-digit system password. If you forget it, contact a service center.

• Hotel Mode: toggle the hotel mode on/off.

• Clear Lock: select this option to clear all locks.

Setup menu

Setup

OSD Language Audio Languages Subtitle Teletext Blue Screen Mode Setting Time Settings PVR Settings First Time Setup Reset

Move

Adjust

• OSD Language: select the language of the on-screen display menu.

• Audio Languages: select primary and secondary audio languages.

• Subtitle: toggle subtitles on/off and select their language.

• Teletext: adjust teletext settings. Only available in DTV and ATV modes.

• Blue Screen: toggle Blue screen on/off.

• Mode Setting: select the Home mode or the Store mode.

• Time Settings: access the time & date setup sub-menu.

• PVR Settings: this option is intended for adjusting the PVR (recording) settins. Requires a USB flash drive.

• First Time Setup: initiate the first-time setup.

• Reset: go back to factory default settings.

EXIT: ExitMENU: Return

Operation

USB operation

General playback information

• Insert a USB drive into the USB port. Select Media source and press ENTER button. The screen will show a USB playback window, in which you can select Music, Photo, Movie and Text contents to play by pressing LEFT/ RIGHT cursor buttons and ENTER button.

• USB file systems supported: FAT16, FAT32, NTFS. 2.0 USB version is supported; maximum capacity 2 TB (NTFS). For correct and satisfactory operation, licensed USB devices of well-known brands should be used. Avoid using USB devices of unknown brands. Playback of some file formats cannot be supported.

• This unit supports playback of video files with ASF, AVI, MKV, MPG extensions, with video codecs WMV9, DIVX, H263, MPEG-4, MPEGII, XVID and audio codecs WMA, MP3, DD(AC3).

The above list of extensions and codecs is for information only and is not a guarantee that all files having the above extensions and codecs should be read by this unit.

• Some AVI files cannot be played due to their parameters and recording conditions. Video files with AVI extension exceeding 2 GB in size may be played partially.

According to the USB 1.1/2.0 Standard, usage of a USB device with power current consumption exceeding 500 mA is not recommended without supplementary power supply. Failure to use supplementary power for connected USB drives with power consumption exceeding this value as well as defective USB drives may cause mechanical or thermal changes of elements of this unit as well as failure of internal elements of the USB port. Such damages are not warranty cases.

Warning: usage of external USB drives containing BIN files in the root directory may cause malfunction of the unit or damage to the software.

Operations of file playback

• Insert a USB into the USB port. Press the SOURCE button or select USB source and press ENTER button on the RC or VOL+/VOLbutton on the unit. The screen will show a USB playback window, in which you can select Music, Photo, Movie and Text contents to play by pressing LEFT/RIGHT cursor buttons and ENTER button.

• In the content menu, press cursor buttons to select folder, press ENTER button or button to enter it, then press cursor buttons to select the file you want to watch or to listen to. When highlighting the file, the file information will appear on the right (not available for text files) and picture will be previewed in the center (not available for music and text files). Press ENTER button or button to play the selected file.

• While playback, press ENTER button; the bottom of the screen will show playback menu in which you can select an operation by LEFT/ RIGHT cursor buttons or perform this operation by pressing ENTER button.

• While playback, press button to pause or resume playback. Press button to stop playback.

• When playing music files you can press / buttons to fast reverse or forward. You can press / buttons to select the desired files manually in normal condition.

• When playing photo files, you can press

/ buttons to page up or page down the file. Press LEFT/RIGHT cursor buttons to rotate the image.

• Press EXIT button to stop playback and return to the previous menu screen. corner, the list of the current available channels on the left, and the name of each programme starting in scheduled time periods on the right. Select the channel by pressing UP/DOWN and the programme by pressing LEFT/RIGHT.

+ 26 hidden pages
