Tektronix TPS2012,TPS2014,TPS2024 Service

Service Manual

TPS2000 Series Digital Storage Oscilloscopes

077-0306-00

This document supports firmware version 10.00 and above.

Warning

The servicing instructions are for use by qualified personnel only. To avoid personal injury, do not perform any servicing unless you are qualified to do so. Refer to all safety summaries prior to performing service.

www.tektronix.com

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc. 14200 SW Karl Braun Drive P.O. Box 500 Beaverton, OR 97077 USA

For product information, sales, service, and technical support:

H In North America, call 1-800-833-9200.

H Worldwide, visit www.tektronix.com to find contacts in your area.

Warranty 16

TPS2000 Series Oscilloscopes

Tektronix warrants that the product will be free from defects in materials and workmanship for a period of three (3) years from the date of original purchase from an authorized Tektronix distributor. If the product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product. Batteries are excluded from this warranty. Parts, modules and replacement products used by Tektronix for warranty work may be new or reconditioned to like new performance. All replaced parts, modules and products become the property of Tektronix.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible for packaging and shipping the defective product to the service center designated by Tektronix, shipping charges prepaid, and with a copy of customer proof of purchase. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product; b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or integrated with other products when the effect of such modification or integration increases the time or difficulty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

Warranty 2

P2220 Probe

Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty work may be new or reconditioned to like new performance. All replaced parts, modules and products become the property of Tektronix.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible for packaging and shipping the defective product to the service center designated by Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product; b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or integrated with other products when the effect of such modification or integration increases the time or difficulty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

WARRANTY

TPSBAT Battery Pack

Tektronix warrants that the product listed above will be free from defects in materials and workmanship for a period of three (3) months from the date of original purchase from an authorized Tektronix distributor. If any such product proves defect ive during this warranty period, Tektronix, at its option, either will repair t he defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty work may be new or reconditioned to like new performance. All replaced parts, modules and product s become the property of Tektronix.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible for packaging and shipping the defective product to the service center designated by Tektronix, shipping charges prepaid, and with a copy of customer proof of purchase. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product; b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or integrated with other products when the effect of such modification or integration increases the time or difficulty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

General Safety Summary

Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it.

To avoid potential hazards, use this product only as specified.

Only qualified personnel should perform service procedures.

ToAvoidFireor

Personal Injury

Use Proper Power Cord. Use only the power cord specified for this product and certified for the country of use.

Connect and Disconnect Properly. Do not connect or disconnect probes or test leads while they are connected to a voltage source.

Connect and Disconnect Properly. Connect the probe output to the measurement instrument before connecting the probe to the circuit under test. Connect the probe reference lead to the circuit under test before connecting the probe input. Disconnect the probe input and the probe reference lead from the circuit under test before disconnecting the probe from the measurement instrument.

Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings and markings on the product. Consult the product manual for further ratings information before making connections to the product.

Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal.

Power Disconnect. The power cord disconnects the product from the power source. Do not block the power cord; it must remain accessible to the user at all times.

Do Not Operate Without Covers. Do not operate this product with covers or panels removed.

Do Not Operate With Suspected Failures. If you suspect there is damage to this product, have it inspected by qualified service personnel.

Avoid Exposed Circuitry. Do not touch exposed connections and components when power is present.

Replace Batteries Properly. Replace batteries only with the specified type and rating.

Recharge Batteries Properly. Recharge batteries for the recommended charge cycle only.

Use Proper AC Adapter. Use only the AC adapter specified for this product.

Do Not Operate in Wet/Damp Conditions.

Do Not Operate in an Explosive Atmosphere.

TPS2000 Series Digital Storage Oscilloscopes Service Manual

vii

General Safety Summary

Keep Product Surfaces Clean and Dry.

Provide Proper Ventilation. Refer to the manual’s installation instructions for

details on installing the product so it has proper ventilation.

Terms in this Manual

Symbols and Terms

on the Product

These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property.

These terms may appear on the product:

H DANGER indicates an injury hazard immediately accessible as you read the

marking.

H WARNING indicates an injury hazard not immediately accessible as you

read the marking.

H CAUTION indicates a hazard to property including the product.

The following symbol(s) may appear on the product:

viii

CAUTION

Refer to Manual

Chassis Ground

Standby

TPS2000 Series Digital Storage Oscilloscopes Service Manual

General Safety Summary

Probe Safety

A guard around the probe body provides a finger barrier for protection from electric shock.

Finger guard

WARNING. To avoid electric shock when using the probe, keep fingers behind the guard on the probe body, and do not touch metallic portions of the probe head while it is connected to a voltage source.

Connect the probe output to the oscilloscope before connecting the probe to the circuit under test. Disconnect the probe input and the probe reference lead from the circuit under test before disconnecting the probe from the measurement instrument.

TPS2000 Series Digital Storage Oscilloscopes Service Manual

ix

General Safety Summary

x

TPS2000 Series Digital Storage Oscilloscopes Service Manual

Service Safety Summary

Only qualified personnel should perform service procedures. Read this Service Safety Summary and the General Safety Summary before performing any service

procedures.

Do Not Service Alone. Do not perform internal service or adjustments of this product unless another person capable of rendering first aid and resuscitation is present.

Disconnect Power. To avoid electric shock, disconnect the main power by means of the power cord or, if provided, the power switch.

Use Care When Servicing With Power On. Dangerous voltages or currents may exist in this product. Disconnect power, remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components.

To aviod electrical shock, do not touch conductive parts.

TPS2000 Series Digital Storage Oscilloscopes Service Manual

xi

Service Safety Summary

xii

TPS2000 Series Digital Storage Oscilloscopes Service Manual

Environmental Considerations

This section provides information about the environmental impact of the product.

Product End-of-Life

Handling

Observe the following guidelines when recycling an instrument or component:

Equipment Recycling. Production of this equipment required the extraction and use of natural resources. The equipment may contain substances that could be harmful to the environment or human health if improperly handled at the product’s end of life. In order to avoid release of such substances into the environment and to reduce the use of natural resources, we encourage you to recycle this product in an appropriate system that will ensure that most of the materials are reused or recycled appropriately.

This symbol indicates that this product complies with the applicable European Union requirements according to Directives 2002/96/EC and 2006/66/EC on waste electrical and electronic equipment (WEEE) and batteries. For information about recycling options, check the Support/Service section of the Tektronix Web site (www.tektronix.com).

Battery Recycling. This product contains a lithium ion (Li--ion) rechargeable battery, which must be recycled or disposed of properly.

H Lithium--Ion batteries are subject to disposal and recycling

regulations that vary by country and region. Always check

and follow your applicable regulations before disposing of any

battery. Contact Rechargeable Battery Recycling Corporation

(www.rbrc.org) for U.S.A. and Canada, or your local battery

recycling organization.

H Many countries prohibit the disposal of waste electronic equipment

in standard waste receptacles.

H Place only discharged batteries in a battery collection container.

Use electrical tape or other approved covering over the battery

connection points to prevent short circuits.

Mercury Notification. This product uses an LCD backlight lamp that contains mercury. Disposal may be regulated due to environmental considerations. Please contact your local authorities or, within the United States, refer to the E--cycling Central Web page (www.eiae.org) for disposal or recycling information.

TPS2000 Series Digital Storage Oscilloscopes Service Manual

xiii

Environmental Considerations

Transporting Batteries

Restriction of Hazardous

Substances

The capacity of the lithium ion rechargeable battery pack in this product is under 100 Wh. The lithium--equivalent content, as defined by the UN Manual of Tests and Criteria Part III Section 38.3, is under 8 g per pack and 1.5 g per individual cell.

H Always check all applicable local, national, and international regulations

before transporting a Lithium--Ion battery.

H Transporting an end--of--life, damaged, or recalled battery may, in certain

cases, be specifically limited or prohibited.

This product has been classified as Monitoring and Control equipment, and is outside the scope of the 2002/95/EC RoHS Directive.

xiv

TPS2000 Series Digital Storage Oscilloscopes Service Manual

Preface

Related Manuals

This service manual for the TPS2000-Series Digital Storage Oscilloscopes provides instructions to verify the performance of, calibrate, troubleshoot, and repair the oscilloscopes to the module level.

Unless noted otherwise, the term “oscilloscope” refers to all of the models in the TPS2000-series.

These manuals contain additional documentation for the oscilloscopes:

User manual

Language

English 071-1441-XX 071-1075-XX

French 071-1442-XX*

Italian 071-1443-XX*

German 071-1444-XX*

Spanish 071-1445-XX*

Japanese 071-1446-XX*

Portuguese 071-1447-XX*

Simplified Chinese 071-1448-XX*

Traditional Chinese 071-1449-XX*

Korean 071-1450-XX*

Russian 071-1451-XX*

*These manuals contain a language overlay for the front-panel controls.

part number

Programmer manual part number

TPS2000 Series Digital Storage Oscilloscopes Service Manual

xv

Preface

xvi

TPS2000 Series Digital Storage Oscilloscopes Service Manual

Specifications

g

q

g

BNC

1

These specifications apply to all TPS2000 Series oscilloscopes. To verify that an oscilloscope meets specifications, it must first meet the following conditions:

H The oscilloscope must have been operating continuously for twenty minutes

within the specified operating temperature range. See page 1--8.

H You must perform the Do Self Cal operation, accessible through the Utility

menu, if the operating temperature changes by more than 5 °C.

H The oscilloscope must be within the factory calibration interval of one year.

H The V/div specifications apply with the probe calibration is set to 1X probe

mode.

Specifications begin in Table 1--1. All specifications are guaranteed unless noted “typical.” Specifications that are marked with the n symbol are checked in the Performance Verification section.

Table 1- 1: Oscilloscope general characteristics

Acquisition

Acquisition Modes Sample, Peak Detect, and Average

Acquisition Rate, typical Up to 180 waveforms per second, per channel (Sample acquisition mode, no measurements)

Single Sequence Acquisition Mode Acquisition Stops After

Sample, Peak Detect Single acquisition, all channels simultaneously.

Average N acquisitions, all channels simultaneously. N is selectable from 4,

16, 64, and 128.

Inputs

Input Coupling DC, AC, or GND

Input Impedance, DC Coupled

Maximum Voltage Between Overvoltage Category Maximum Voltage Signal and Reference at input

1

1MΩ ±2% in parallel with 20 pF ±3pF

CAT I and CAT II 300 V

CAT III 150 V

Derate at 20 dB/decade above 100 kHz to 13 V peak AC at 3 MHz and above. For nonsinusoidal waveforms, peak value must be less than 450 V. Excursion above 300 V should be less than 100 ms duration. RMS signal level, including any DC component removed through AC coupling, must be limited to 300 V. If these values are exceeded, damage to the oscilloscope may result. Refer to the Overvoltage Category description on page NO TAG.

rms

TPS2000 Series Digital Storage Oscilloscopes Service Manual

1- 1

Specifications

g

atBNCorwithP2220probe

D

/di

v

,yp

Table 1- 1: Oscilloscope general characteristics (Cont.)

Inputs

Maximum Voltage Between BNC Reference and Earth

1

Ground

600 V

CAT II or 300 V

rms

CAT III, using rated connectors or accessories.

rms

Single Channel Common Greater than 1000:1 up to 50 MHz, derated to 400:1 at 200 MHz Mode Rejection, typical

Sine wave with VOLTS/DIV setting at 5 mV. Signal applied between the channel (signal and signal reference) and chassis. Ratio of the acquired signal amplitude to the amplitude of the signal.

Channel-to-Channel Crosstalk TPS2012 and TPS2014 TPS2024

50 MHz: ≥100:1 100 MHz: ≥100:1

Measured on one channel, with test signal applied between signal and common of the other channel, and with the same VOLTS/DIV and coupling settings on each channel.

1

The maximum peak- to- peak voltage that can be displayed is 40 V

with 1x attenuation. See Vertical specifica-

p- p

tions for available VOLTS/DIV and probe attenuation settings.

Vertical

Digitizers 8-bit resolution (except when set to 2 mV/div), each channel sampled simultaneously.

VOLTS/DIV Range 2 mV/div to 5 V/div at input BNC

Position Range 2 mV/div to 200 mV/div, 1.8 V

>200 mV/div to 5 V/div, 45 V

P2220 Probe

1X, 10X

Attenuation

Supported Voltage Probe

1X, 10X, 20X, 50X, 100X, 500X, 1000X

Attenuation Factors

Supported Current Probe

1 mV/A, 10 mV/A, 20 mV/A, 50 mV/A, 100mV/A, 200 mV/A, 1 V/A, 5 V/A

Scales

n Analog Bandwidth in

Sample and Average modes

TPS2012 and TPS2014 TPS2024

100 MHz

1

200 MHz1from 0 °Cto40°C, 180 MHz from 40 °Cto50°C

set to 10X, DC Coupled

Analog Bandwidth in Peak

etectmode(50 s

2

5 s/div

), typical

to

Selectable Analog Bandwidth

20 MHz when vertical scale is set to less than 5 mV.

1

75 MHz

20 MHz when vertical scale is set to less than 5 mV

20 MHz

Limit, typical

Lower Frequency Limit, AC Coupled

≤10 Hz at BNC

≤1 Hz when using a 10X passive probe

Rise Time at BNC, typical TPS 2012 and TPS2014 TPS2024

<3.5ns <2.1ns

1- 2

TPS2000 Series Digital Storage Oscilloscopes Service Manual

Table 1- 1: Oscilloscope general characteristics (Cont.)

n

DCGainAccurac

y

n

DCMeasurement

Vertical

Peak Detect Response

n DC Gain Accuracy

n DC Measurement

Accuracy, Average Acquisition Mode

2

Captures 50% or greater amplitude of pulses ≥12 ns wide typical (50 s/div to 5 s/div) in the center 8 vertical divisions

±3% for Sample or Average acquisition mode, 5 V/div to 10 mV/div

±4% for Sample or Average acquisition mode, 5 mV/div and 2 mV/div

Measurement Type Accuracy

Average of ≥16 waveforms with vertical position at zero

±(3% × reading + 0.1 div + 1 mV) when 10 mV/div or greater is selected

Specifications

Average of ≥16 waveforms with vertical position not at zero

Volts Measurement Repeatability, Average Acquisition Mode

1

For 5 mV/div, the vertical scale setting bandwidth specification is typical.

2

The oscilloscope reverts to Sample mode when the SEC/DIV (horizontal scale) is set from 2.5 s/div to 5 ns/div

on 100 MHz models, or from 2.5 s/div to 2.5 ns/div on a TPS2024 model. The Sample mode can still capture 12ns glitches.

Delta volts between any two averages of ≥16 waveforms acquired under same setup and ambient conditions

±[3% × (reading + vertical position) + 1% of vertical position + 0.2 div]

Add 2 mV for settings from 2 mV/div to 200 mV/div Add 50 mV for settings from >200 mV/div to 5 V/div

±(3% × reading + 0.05 div)

TPS2000 Series Digital Storage Oscilloscopes Service Manual

1- 3

Specifications

p

g

/

g

n

TriggerSensitivity,

ggy,g

Table 1- 1: Oscilloscope general characteristics (Cont.)

Horizontal

Sample Rate Range TPS2012 and TPS2014 TPS2024

5S/sto1GS/s 5S/sto2GS/s

Waveform Interpolation (sin x)/x

Record Length 2500 samples for each channel

SEC/DIV Range TPS2012 and TPS2014 TPS2024

5ns/divto50s/div,ina 1, 2.5, 5 sequence

n Sample Rate and Delay

±50 ppm over any ≥1 ms time interval

Time Accuracy

Delta Time Measurement

Conditions Accuracy

Accuracy (Full Bandwidth)

Single-shot, sample mode

>16 averages ±(1 sample interval + 50 ppm × reading + 0.4 ns)

Sample interval = s/div ÷ 250

Position Range 2.5 ns/div to 10 ns/div: (--4 div × s/div) to 20 ms

25 ns/div to 100 s/div: (--4 div × s/div) to 50 ms

250 s/divto10s/div:(--4div× s/div) to 50 s

25 s/div to 50s/div: (--4 div × s/div) to 250 s

2.5 ns/div to 50 s/div, in a 1, 2.5, 5 sequence

±(1 sample interval + 50 ppm × reading + 0.6 ns)

Trigger

n Trigger Sensitivity,

Edge Trigger Type

Coupling Sensitivity

DC

CH1, CH2, CH31, CH4

EXT 1V

EXT/5 5X the value of EXT

EXT/10 10X the value of EXT

1

2

Available only on 4-channel oscilloscopes. TPS2024 only.

Trigger Sensitivity, Edge Coupling Sensitivity Trigger Type, typical

AC

Same as DC-coupled limits from 50 Hz and above

NOISE REJ Reduces the DC-coupled trigger sensitivity by 2 times for greater

than 10 mv/div to 5 V/div

HF REJ Same as the DC-coupled limit from DC to 7 kHz, attenuates

signals above 80 kHz

LF REJ Same as the DC-coupled limits for frequencies above 300 kHz,

attenuates signals below 300 kHz

1

1 div from DC to 10 MHz,

1.5 div from 10 MHz to100 MHz 2 div from 100 MHz to 200 MHz

from 50 Hz to 100 MHz

p-p

2V

from 100 MHz to 200 MHz

p-p

2

1- 4

TPS2000 Series Digital Storage Oscilloscopes Service Manual

Table 1- 1: Oscilloscope general characteristics (Cont.)

ggg

Trigger

Trigger Level Range Source Range

CH1, CH2, CH31, CH41±8 divisions from center of screen

EXT ±4V

EXT/5 ±20 V

EXT/10 ±35 V

Trigger Level Accuracy, typical

SET LEVEL TO 50%, typical Operates with input signals equal to or greater than 50 Hz

Default Settings, Video Trigger

Sensitivity, Video Trigger Type, typical

Signal Formats and Field Rates, Video Trigger Type

Holdoff Range 500 ns to 10 s

1

Available only on 4-channel oscilloscopes.

Accuracies are for signals having rise and fall times ≥20 ns

Source Accuracy

Internal ±(0.2 div + 5 mV) within ±4 divisions from center screen

EXT ±(6% of setting + 250 mV) for signals less than ±2V

EXT/5 ±(6% of setting + 500 mV) for signals less than ±10 V

EXT/10 ±(6% of setting + 1 V) for signals less than ±20 V

Coupling is AC and Auto except for a single sequence acquisition

Composite video signal

Source Range

Internal Pk-pk amplitude of 2 divisions

EXT ±1V

EXT/5 ±5V

EXT/10 ±10 V

Supports NTSC, PAL, and SECAM broadcast systems for any field or any line

Specifications

TPS2000 Series Digital Storage Oscilloscopes Service Manual

1- 5

Specifications

Table 1- 1: Oscilloscope general characteristics (Cont.)

Pulse Width Trigger

Pulse Width Trigger modes Trigger when < (Less than), > (Greater than), = (Equal), or ≠ (Not Equal);

Positive pulse or Negative pulse.

Pulse Width Trigger Point Equal: The oscilloscope triggers when the trailing edge of the pulse crosses the trigger level.

Not Equal: If the pulse is narrower than the specified width, the trigger point is the trailing edge. Otherwise, the oscilloscope triggers when a pulse continues longer than the time specified as the Pulse Width.

Less than: The trigger point is the trailing edge.

Greater than (also called time-out trigger): The oscilloscope triggers when a pulse continues

longer than the time specified as the Pulse Width.

Pulse Width Range Selectablefrom33nsto10s

Pulse Width Resolution 16.5 ns or 1 part per thousand, whichever is larger

Equal Guard Band t > 330 ns: ±5% ≤ guard band < ±(5.1% + 16.5 ns)

t ≤ 330 ns: guard band = ±16.5 ns

Not Equal Guard Band t > 330 ns: ±5% ≤ guard band < ±(5.1% + 16.5 ns)

165 ns < t ≤ 330 ns: guard band = --16.5 ns/+33 ns

t ≤165 ns: guard band = ±16.5 ns

Trigger Frequency Counter

Readout Resolution 6 digits

Accuracy, typical ±51 ppm including all frequency reference errors and ±1 count errors

Frequency Range AC coupled, 10 Hz minimum to rated bandwidth.

Signal Source Pulse Width/ Edge Trigger: all available trigger sources.

Frequency Counter measures trigger source at all times, including when the oscilloscope acquisition is halted due to changes in the run status, or acquisition of a single shot event has completed.

Pulse Width Trigger: The oscilloscope counts pul ses of significant magnitude inside the 250 ms measurement window that qualify as triggerable events, such as narrow pulses in a PWM pulse train if set to < mode and the width is set to a relat ively small time.

Edge Trigger: The oscilloscope counts all edges of sufficient magnitude and correct polarity.

Video Trigger: The Frequency Counter does not operate.

1- 6

TPS2000 Series Digital Storage Oscilloscopes Service Manual

Tektronix TPS2012,TPS2014,TPS2024 Service

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

List of Figures

List of Tables

General Safety Summary

Service Safety Summary

Environmental Considerations

Preface

Specifications
