xx
TPS2000B Series
ZZZ
Digital Storage Oscilloscope
User Manual
*P077137901*
077-1379-01
xx
TPS2000B Series
ZZZ
Digital Storage Oscilloscope
User Manual
www.tek.com
077-1379-01
Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
OpenChoice and Wavestar are registered trademarks of Tektronix, Inc.
Tektronix is an authorized licensee of the CompactFlash® trademark.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Bo x 50 0
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tek.com to find contacts in your area.
TPS2000B Series Oscilloscope
Warranty
Tektronix war
years from the date of original purchase from an authorized Tektronix distributor. If the product proves defective
during this warranty period, Tektronix, at its option, either will repair the defective product without charge for
parts and labor, or will provide a replacement in exchange for the defective product. Batteries are excluded from
this warranty. Parts, modules and replacement products used by Tektronix for warranty work may be new or
reconditioned to like new performance. All replaced parts, modules and products become the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration
of the warranty period and make suitable arrangements for the performance of service. Customer shall be
responsib
shipping charges prepaid, and with a copy of customer proof of purchase. Tektronix shall pay for the return of the
product to Customer if the shipment is to a location within the country in which the Tektronix service center is
located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for
products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
epair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
b) to r
or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE
D EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
AN
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
rants that the product will be free from defects in materials and workmanship for a period of three (3)
le for packaging and shipping the defective product to the service center designated by Tektronix,
[W16 – 15AUG04]
TPP0101 and TPP0201 Probes
Warranty
Tektronix wa r
year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its
option, either will repair the defective product without charge for parts and labor, or will provide a replacement
in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty
work may be new or reconditioned to like new performance. All replaced parts, modules and products become
the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of
the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible
for packag
charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within
the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping
charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
function caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
or mal
integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE
AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
KTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
TE
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
rants that this product will be free from defects in materials and workmanship for a period of one (1)
ing and shipping the defective product to the service center designated by Tektronix, with shipping
[W2 – 15AUG04]
TPSBAT Battery Pack
Warranty
Tektronix war
months from the date of original purchase from an authorized Tektronix distributor. If the product proves defective
during this warranty period, Tektronix, at its option, either will repair the defective product without charge for
parts and labor, or will provide a replacement in exchange for the defective product. Batteries are excluded from
this warranty. Parts, modules and replacement products used by Tektronix for warranty work may be new or
reconditioned to like new performance. All replaced parts, modules and products become the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration
of the warranty period and make suitable arrangements for the performance of service. Customer shall be
responsib
shipping charges prepaid, and with a copy of customer proof of purchase. Tektronix shall pay for the return of the
product to Customer if the shipment is to a location within the country in which the Tektronix service center is
located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for
products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
epair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
b) to r
or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE
D EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
AN
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
rants that the product will be free from defects in materials and workmanship for a period of three (3)
le for packaging and shipping the defective product to the service center designated by Tektronix,
[W14 – 15AUG04]
Table of Contents
Important safety information..................................................................................... iv
General safety summary ..................................................................................... iv
Service safety summary..................................................................................... vii
Terms in thismanual ........................................................................................ viii
Symbols and terms on the product......................................................................... viii
Compliance information.......................................................................................... ix
EMC compliance ............................................................................................. ix
Safety compliance ............................................................................................. x
Environmental considerations.............................................................................. xiii
Preface.............................................................................................................. xv
Help System.................................................................................................. xvi
Conventions................................................................................................. xvii
Getting Started ..... . ..... . ..... ..... . ..... . ..... . ..... . ..... . ....................................................... 1
General Features............................................................................................... 1
Taking FloatingMeasurements............................................................................... 3
Installation...................................................................................................... 6
Probes.......................................................................................................... 10
Functional Check ............................................................................................. 10
Probe Safety................................................................................................... 11
Voltage Probe Check Wizard................................................................................ 12
Manual Probe Compensation................................................................................ 13
Voltage Probe Attenuation Setting ..... . ..... . ..... . ..... . ..... . ............................................ 14
Current Probe Scaling........................................................................................ 14
SelfCalibration ............................................................................................... 14
Operating Basics................................................................................................... 15
Display Area .................................................................................................. 16
Using the Menu System...................................................................................... 19
Vertical Controls.............................................................................................. 20
Horizontal Controls........................................................................................... 21
Trigger Controls............................................................................................... 22
Menu and Control Buttons................................................................................... 23
Input Connectors.............................................................................................. 25
Other Front-Panel Items...................................................................................... 26
Understanding Oscilloscope Functions .... . ..... . .... . . .... . . .... . . ............................................ 27
Setting Up the Oscilloscope . .... . . .... . ..... . ..... . ..... . ..... . ............................................. 28
Triggering...................................................................................................... 29
Acquiring Signals............................................................................................. 31
Scaling and Positioning Waveforms.... . ..... . ..... ..... . ..... . ..... ....................................... 31
Taking Measurements........................................................................................ 35
TPS2000B Series Digital Oscilloscope User Manual i
Table of Contents
Application Ex
Taking SimpleMeasurements............................................................................... 38
Using Autorangeto Examine a Series of Test Points..................................................... 43
Using an Isolated Channel to Analyze a Differential Co
Viewing a Math Instantaneous Power Waveform......................................................... 45
Taking Cursor Measurements ............................................................................... 46
Analyzing Signal Detail...................................................................................... 50
Capturing a Single-Shot Signal ............................................................................. 51
Measuring Propagation Delay............................................................................... 53
Triggering on a Specific Pulse Width....................................................................... 54
Triggering on a Video Signal................................................................................ 55
Viewing Impedance Changes in a Network................................................................ 59
Math FFT........................................................................................................... 61
Setting Up the Time-Domain Waveform... . ..... ..... . ..... . ..... . ..... ................................... 62
Displaying the FFT Spectrum ............................................................................... 64
Selecting an FFT Window ................................................................................... 65
Magnifying and Positioning an FFT Spectrum . . ..... . ..... . .... . . .... . ................................... 68
Measuring anFFTSpectrum Using Cursors............................................................... 69
Communications (RS-232, Centronics,and RS-232/USB)................................................... 71
Sending a Screen Image to an External Device ........................................................... 71
Setting Up and Testing the RS-232 Interface . ..... . ..... . ..... . ..... . ..................................... 74
Command Entry............................................................................................... 79
Setting Up and Using the RS-232/USB Cable.. . ..... . .... . . .... . ..... . ................................... 79
Removable Mass Storage......................................................................................... 81
Installing and Removing a CompactFlash (CF) Card.. . ..... . ..... . ..... . ................................ 81
FileManagementConventions.............................................................................. 82
Using the Save functionof the Print Button............................................................... 83
Managing TPSBAT Battery Packs ..... . ..... . ..... . ..... . ..... . ..... . ........................................... 85
Maintaining Battery Packs................................................................................... 86
General Charging Guidelines................................................................................ 86
Checking the Charge and Calibration Status............................................................... 87
Charging TPSBAT Battery Packs . .... . . .... . . .... . . ..... . ..... . ..... . ...................................... 88
CalibratingBattery Packs.................................................................................... 90
Handling Battery Packs ...................................................................................... 91
Storing and Transporting Battery Packs.................................................................... 91
Replacing Battery Packs ..................................................................................... 92
Reference........................................................................................................... 93
Acquire......................................................................................................... 93
Application.................................................................................................... 95
Autorange...................................................................................................... 95
Autoset......................................................................................................... 98
amples............................................................................................. 37
mmunication Signal ......................... 44
ii TPS2000B Series Digital Oscilloscope User Manual
Table of Contents
Cursor........................................................................................................ 101
Default Setup................................................................................................ 102
Display....................................................................................................... 102
Help .......................................................................................................... 105
Horizontal.................................................................................................... 105
Math.......................................................................................................... 106
Measure...................................................................................................... 108
Print .......................................................................................................... 109
Probe Check................................................................................................. 109
Save/Recall.................................................................................................. 109
Trigger Controls............................................................................................. 114
Utility . . ..... . ..... . ...... ...... ...... ...... ...... ...... ...... ................................................ 120
Vertica
Appendix A:TPS2000B Specifications....................................................................... 125
Oscilloscope Specifications... . .... . . .... . . .... . . .... . ..... . ..... .......................................... 125
Appendix B: TPP0101 and TPP0201 Series 10X Passive Probes Information . .......................... 133
Connecting the Probe to the Oscilloscope . ..... . ..... . ..... . ..... . ...................................... 133
Compensating the Probe .................................................................................. 134
Conn
Standard Accessories....................................................................................... 135
Optional Accessories....................................................................................... 136
Specifications................................................................................................ 136
Performance Graphs........................................................................................ 137
Safety Summary ............................................................................................ 138
pendix C: Accessories....................................................................................... 141
Ap
Appendix D: Cleaning .......................................................................................... 145
General Care ................................................................................................ 145
Cleaning ..................................................................................................... 145
Appendix E:Default Setup ..................................................................................... 147
Appendix F:Font Licenses..................................................................................... 149
Appendix G:TPS2000B Compatible Probe Maximum Voltages .......................................... 151
Index
l Controls............................................................................................ 123
ecting the Probe to the Circuit ...................................................................... 134
TPS2000B Series Digital Oscilloscope User Manual iii
Important safety information
Important saf
ety information
This manual c
for safe operation and to keep the product in a safe condition.
To safely perform service on this product, additional information is provided at
the end of this section. (See page vii, Service safety summary.)
General safety summary
Use the product only as specified. Review the following safety precautions to
avoid injury and prevent damage to this product or any products connected to it.
Carefully read all instructions. Retain these instructions for future reference.
This product shall be used in accordance with local and national codes.
For correct and safe operation of the product, it is essential that you follow
generally accepted safety procedures in addition to the safety precautions specified
in this manual.
The product is designed to be used by trained personnel only.
Only qualified personnel who are aware of the hazards involved should remove
the cover for repair, maintenance, or adjustment.
ontains information and warnings that must be followed by the user
To avoid fire or personal
injury
Before use, always check the product with a known source to be sure it is
operating correctly.
This product is not intended for detection of hazardous voltages.
Use personal protective equipment to prevent shock and arc blast injury where
hazardous live conductors are exposed.
While using this product, you may need to access other parts of a larger system.
Read the safety sections of the other component manuals for warnings and
cautions related to operating the system.
When incorporating this equipment into a system, the safety of that system is the
responsibility of the assembler of the system.
Use proper power cord. Use only the power cord specified for this product and
certified for the country of use.
Do not use the provided power cord for other products.
Power disconnect. The power cord disconnects the product from the power
source. See instructions for the location. Do not position the equipment sothat
it is difficult to operate the power cord; it must remain accessible to the user at
all times to allow for quick disconnection if needed.
iv TPS2000B Series Digital Oscilloscope User Manual
Important safety information
Use proper AC ad
Observe and follow the ratings marked on the AC adapter.
Connect and disconnect properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
Use only insulated voltage probes, test leads, and adapters supplied with the
product, or indicated by Tektronix to be suitable for the product.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product. Do not exceed the
Measurement Category (CAT) rating and voltage or current rating of the lowest
rated individual component of a product, probe, or accessory. Use caution when
using 1:1 test leads because the probe tip voltage is directly transmitted to the
product.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Do not float the common terminal above the rated voltage for that terminal.
Do not operate without covers. Do not operate this product with covers or panels
removed, or with the case open. Hazardous voltage exposure is possible.
apter. Use only the AC adapter specified for this product.
Avoid exposed circuitry. Do not touch exposed connections and components
when power is present.
Do not operate with suspected failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.
Disable the product if it is damaged. Do not use the product if it is damaged
or operates incorrectly. If in doubt about safety of the product, turn it offand
disconnect the power cord. Clearly mark the product to prevent its further
operation.
Before use, inspect voltage probes, test leads, and accessories for mechanical
damage and replace when damaged. Do not use probes or test leads if they are
damaged, if there is exposed metal, or if a wear indicator shows.
Examine the exterior of the product before you use it. Look for cracks or missing
pieces.
Use only specified replacement parts.
Replace batteries properly. Replace batteries only with the specified type and
rating.
Recharge batteries properly. Recharge batteries for the recommended charge
cycle only.
TPS2000B Series Digital Oscilloscope User Manual v
Important safety information
Wear eye protec
laser radiation exists.
Do not operate in wet/damp conditions. Be aware that condensation may occur if
a unit is moved from a cold to a warm environment.
Do not opera
Keep product surfaces clean and dry. Remove the input signals before you clean
the product.
Provide proper ventilation. The cooling fan forces the air through the vents on
the bottom inside of the oscilloscope. To allow air to flow freely through the
oscilloscope, do not block these vents. Do not push objects into any of the
openings.
e a safe working environment. Always place the product in a location
Provid
convenient for viewing the display and indicators.
improper or prolonged use of keyboards, pointers, and button pads.
Avoid
Improper or prolonged keyboard or pointer use may result in serious injury.
e your work area meets applicable ergonomic standards. Consult with an
Be sur
ergonomics professional to avoid stress injuries.
tion. Wear eye protection if exposure to high-intensity rays or
te in an explosive atmosphere.
Probes and test leads
Before connecting probes or test leads, connect the power cord from the power
nector to a properly grounded power outlet.
con
Keep fingers behind the finger guards on the probes. Do not touch metallic portion
the probe head while it is connected to a voltage source and ensure the reference
of
lead or spring are fully mated before connecting the probe to the circuit under test.
emove all probes, test leads and accessories that are not in use.
R
Use only correct Measurement Category (CAT), voltage, temperature, altitude,
nd amperage rated probes, test leads, and adapters for any measurement.
a
Beware of high voltages. Understand the voltage ratings for the probe you are
using and do not exceed those ratings. Two ratings are important to know and
understand:
The maximum measurement voltage from the probe tip to the probe reference
lead.
The maximum floating voltage from the probe reference lead to earth ground
vi TPS2000B Series Digital Oscilloscope User Manual
Important safety information
These two volta
Specifications section of the manual for more information.
WAR NI NG . To prevent electrical shock, do not exceed the maximum measurement
or maximum floating voltage for the oscilloscope input BNC connector, probe
tip, or probe reference lead.
Connect and disconnect properly. Connect the probe output to the measurement
product before connecting the probe to the circuit under test. Connect the
probe reference lead to the circuit under test before connecting the probe input.
Disconne
before disconnecting the probe from the measurement product.
Inspect the probe and accessories. Before each use, inspect probe and accessories
for damage (cuts, tears, or defects in the probe body, accessories, or cable jacket).
Do not use if damaged.
Servicesafetysummary
The Service safety summary section contains additional information required to
safel
service procedures. Read this Service safety summary and the General safety
summary before performing any service procedures.
ge ratings depend on the probe and your application. Refer to the
ct the probe input and the probe reference lead from the circuit under test
y perform service on the product. Only qualified personnel should perform
To avoid electric shock. Do not touch exposed connections.
ot service alone. Do not perform internal service or adjustments of this
Do n
product unless another person capable of rendering first aid and resuscitation is
present.
Disconnect power. To avoid electric shock, switch off the product power and
disconnect the power cord from the mains power before removing any covers or
anels, or opening the case for servicing.
p
Use care when servicing with power on. Dangerous voltages or currents may exist
in this product. Disconnect power, remove battery (if applicable), and disconnect
test leads before removing protective panels, soldering, or replacing components.
Verify safety after repair. Always recheck ground continuity and mains dielectric
strength after performing a repair.
TPS2000B Series Digital Oscilloscope User Manual vii
Important safety information
Termsinthismanual
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and terms on the product
These ter
The following symbol(s) may appear on the product:
ms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the mark
WARNING indicates an injury hazard not immediately accessible as you
read th
CAUTION indicates a hazard to property including the product.
ing.
e marking.
When this symbol is marked on the product, be sure to consult the manual
to find out the nature of the potential hazards and any actions which have to
betakentoavoidthem. (Thissymbolmayalsobeusedtorefertheuserto
ratings in the m anual.)
viii TPS2000B Series Digital Oscilloscope User Manual
Compliance information
This section lists the EMC (electromagnetic compliance), safety, and
environmental standards with which the instrument complies.
Questions about the compliance information below may be directed to the
following address:
Tektronix, Inc. PO Box 500, MS 19‐045
Beaverton, OR 97077, USA
www.tek.com
EMC compliance
EU EMC D irective
Meets intent of Directive 2014/30/EU for Electromagnetic Compatibility.
Compliance was demonstrated to the following specifications as listed in the
Official Journal of the European Communities:
EN 6132
measurement, control, and laboratory use.
6-1, EN 61326-2-1. EMC requirements for electrical equipment for
1234
CISPR
11. Radiated and conducted emissions, Group 1, Class A
IEC 61000-4-2. Electrostatic discharge immunity
IEC 61000-4-3. RF electromagnetic field immunity
5
IEC 61000-4-4. Electrical fast transient/burst immunity
IEC 61000-4-5. Power line surge immunity
IEC 61000-4-6. Conducted RF immunity
C 61000-4-8. Power frequency magnetic field immunity test
IE
6
IEC 61000-4-11. Voltage dips and interruptions immunity
EN 61000-3-2. AC power line harmonic emissions
EN 61000-3-3. Voltage changes, fluctuations, and flicker
1
This product is intended for use in nonresidential areas only. Use in residential areas may cause electromagnetic
interference.
2
Emissions which exceed the levels required by this standard may occur when this equipment is connected to a
test object.
3
Equipment may not meet the immunity requirements of applicable listed standards when test leads and/or test
probes are connected due to coupling of electromagnetic interference onto those leads/probes. To minimize
the influence of electromagnetic interference, minimize the loop a rea between the unshielded portions of signal
and associated return leads, and keep leads as far away as possible from electromagnetic disturbance sources.
Twisting unshielded test leads together is an effective way to reduce loop area. For probes, keep the ground
TPS2000B Series Digital Oscilloscope User Manual ix
Compliance information
Australia / New Zealand
Declaration of
Conformity – EMC
Safety compliance
EU low voltage directive
return lead as s
accomplish this most effectively. In all cases, observe all safety instructions for the probes or leads used.
4
For compliance with the EMC standards listed here, high quality shielded interface cables that incorporate low
impedance connection between the cable shield and the connector shell should be used.
5
≤1.0 division waveform displacement or ≤2.0 division increase in peak-to-peak noise is allowed when the
instrument is subjected to fields and signals as defined in the IEC 61000-4-3 test.
6
≤0.5 division waveform displacement or ≤1.0 division increase in peak-to-peak noise is allowed when the
instrument is subjected to fields and signals as defined in the IEC 61000-4-6 test.
hort as possible and close to the probe body. Some probes have accessory probe tip adapters to
Complies with the EMC provision of the Radiocommunications Act per the
following standard, in accordance with ACMA:
CISPR 11. Radiated and Conducted Emissions, Group 1, Class A, in
accordance with EN 61326-1 and EN 61326-2-1.
This section lists the safety standards with which the product complies andother
safety compliance information.
Compliance was demonstrated to the following specification as listed in the
Official Journal of the European Union:
U.S. nationally recognized
testing laboratory listing
Canadian certification
Low Voltage Directive 2014/35/CE
EN 61010-1. Safety Requirements for Electrical Equipment for Measurement,
Control, and Laboratory Use – Part 1: General Requirements.
EN 61010-2-030. Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use – Part 2-030: Particular
requirements for testing and measuring circuits.
UL 61010-1. Safety Requirements for Electrical Equipment for Measurement,
Control, and Laboratory Use – Part 1: General Requirements.
UL 61010-2-030. Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use – Part 2-030: Particular
requirements for testing and measuring circuits.
CAN/CSA-C22.2 No. 61010-1. Safety Requirements for Electrical
Equipment for Measurement, Control, and Laboratory Use – Part 1: General
Requirements.
CAN/CSA-C22.2 No. 61010-2-030. Safety Requirements for Electrical
Equipment for Measurement, Control, and Laboratory Use – Part 2-030:
Particular requirements for testing and measuring circuits.
x TPS2000B Series Digital Oscilloscope User Manual
Compliance information
Additional compliances
Equipment type
Pollution degree
descriptions
IEC 61010-1. Sa
Measurement, Control, and Laboratory Use – Part 1: General Requirements.
IEC 61010-2-0
Measurement, Control, and Laboratory Use – Part 2-030: Particular
requirements for testing and measuring circuits.
Test and mea
A measure of the contaminants that could occur in the environment around
and within a product. Typically the internal environment inside a product is
considered to be the same as the external. Products should be used only in the
environment for which they are rated.
Pollution degree 1. No pollution or only dry, nonconductive pollution occurs.
Products in this category are generally encapsulated, hermetically sealed, or
located in clean rooms.
Pollution degree 2. Normally only dry, nonconductive pollution occurs.
Occasionally a temporary conductivity that is caused by condensation must
be exp
condensation occurs only when the product is out of service.
suring equipment.
ected. This location is a typical office/home environment. Temporary
fety Requirements for Electrical Equipment for
30. Safety Requirements for Electrical Equipment for
Pollution degree rating
ution degree 3. Conductive pollution, or dry, nonconductive pollution
Poll
that becomes conductive due to condensation. These are sheltered locations
where neither temperature nor humidity is controlled. The area is protected
from direct sunshine, rain, or direct wind.
Pollution degree 4. Pollution that generates persistent conductivity through
conductive dust, rain, or snow. Typical outdoor locations.
Pollution degree 2 (as defined in IEC 61010-1). Rated for indoor, dry location
use only.
TPS2000B Series Digital Oscilloscope User Manual xi
Compliance information
Measurement and
overvoltage category
descriptions
Mains overvoltage
category rating
Measurement te
from one or more of the following categories (see specific ratings marked on
the product and in the manual).
Category II. Circuits directly connected to the building wiring at utilization
points (socket outlets and similar points).
Category III. In the building wiring and distribution system.
Category IV
NOTE. Only mains power supply circuits have an overv oltage category rating.
Only measurement circuits have a measurement category rating. Other circuits
within the product do not have either rating.
Overvoltage category II (as defined in IEC 61010-1).
rminals on this product may be rated for measuring mains voltages
. At the source of the electrical supply to the building.
xii TPS2000B Series Digital Oscilloscope User Manual
Environmental considerations
This section provides information about the environmental impact of the product.
Compliance information
Product end-of-life
handling
Observe the following guidelines when recycli
Equipment recycling. Production of this equipment required the extraction and
use of natural resources. The equipment may contain substances that could be
harmful to the environment or human health if improperly handled at the product’s
end of life. To avoid release of such substances into the environment and to
reduce the use of natural resources, we encourage you to recycle this product in
an appropriate system that will ensure that most of the materials are reusedor
recycled appropriately.
This symbol indicates that this product complies with the applicable European
Union requirements according to Directives 2012/19/EU and 2006/66/EC
on waste electrical and electronic equipment (WEEE) and batteries. For
information about recycling options, check the Support/Service section of the
Tektronix Web site (www.tek.com).
Battery recycling. This product may contain a rechargeable battery, which must
be recycled or disposed of properly. Please properly dispose of or recycle the
battery according to local government regulations.
Lithium-Ion batteries are subject to disposal and recycling regulations that
vary by country and region. Always check and follow your applicable
regulations before disposing of any battery. Contact Rechargeable Battery
Recycling Corporation (www.rbrc.org) for U.S.A. and Canada, or your local
battery recycling organization.
ng an instrument or component:
Many countries prohibit the disposal of waste electronic equipment in
standard waste receptacles.
Place only discharged batteries in a battery collection container. Use electrical
tape or other approved covering over the battery connection points to prevent
short circuits.
Transporting batteries
TPS2000B Series Digital Oscilloscope User Manual xiii
The capacity of the lithium ion rechargeable battery pack in this product isunder
100 Wh. The lithium-equivalent content, as defined by the UN Manual of Tests
andCriteriaPartIIISection38.3,isunder8gperpackand1.5gperindividual
cell. Consult your air carrier for applicability and determination of any special
lithium ion battery transportation requirements.
Always check all applicable local, national, and international regulations
before transporting a Lithium-Ion battery.
Transporting an end-of-life, damaged, or recalled battery may, in certain
cases, be specifically limited or prohibited.
Compliance information
xiv TPS2000B Series Digital Oscilloscope User Manual
Preface
This manual contains operating information for the TPS2000B Series Digital
Storage Oscilloscopes. The manual consists of the following chapters:
The Getting Started chapter briefly describes features of the oscilloscope
and provides installation instructions.
The Operating Basics chapter covers operating principles of the oscilloscopes.
The Understanding Oscilloscope Functions chapter describes basic operations
and functions of an oscilloscope: setting up the oscilloscope, triggering,
acquiring data, scaling and positioning waveforms, and taking measurements.
The Application Examples chapter provides examples on how to solve a
variety of measurement problems.
The Math FFT chapter describes how to use the Math Fast Fourier Transform
function to convert a time-domain signal into its frequency components
rum).
(spect
The Communications chapter describes how to set up the RS-232 and
onics ports to use the oscilloscope with external devices, such as printers
Centr
and computers.
emovable Mass Storage chapter describes how to use a CompactFlash
The R
card and oscilloscope functions available when a card is in use.
Managing TPSBAT Battery Packs chapter describes how to use, charge,
The
calibrate, and replace battery packs.
Reference chapter describes the selections or available range of values
The
for each option.
e Appendix A: TPS2000B Specifications chapter includes electrical,
Th
environmental, and physical specifications for the oscilloscope.
he Appendix B: TPP0101 and TPP0201 Series Probes Information chapter
T
includes information on and specifications for the TPP0101 and TPP0201
probes.
The Appendix C: Accessories chapter briefly describes standard and optional
accessories.
The Appendix D: Cleaning chapter describes how to take care of the
oscilloscope.
The Appendix E: Default Setup chapter contains a list of the menus and
controls with the default (factory) settings that are recalled when you push
the Default Setup front-panel button.
TPS2000B Series Digital Oscilloscope User Manual xv
Preface
Help System
The Appendix F:
Asian fonts.
The Appendix G
lists the maximum voltages of compatible probes.
The oscilloscope has a Help system with topics that cover all the features ofthe
oscilloscope. You can use the Help system to display several kinds of information:
General information about understanding and using the oscilloscope, such
as Using the Menu System.
Information about specific menus and controls, such as the Vertical Position
Control.
Advice about problems you may face while using an oscilloscope, such as
Reducing Noise.
The Help system provides several ways to find the information you need:
context-sensitive help, hyperlinks, and an index.
Font Licenses chapter provides the licenses to use specific
: TPS2000B Compatible Probe Maximum Voltages chapter
Context-Sensitive Help
Hyperlinks
Index
cilloscope displays information about the last menu displayed on the
The os
screen when you push the Help front-panel button. When viewing help topics,
an LED lights next to the multipurpose knob to indicate that the knob is active.
If the topic uses more than one page, turn the multipurpose knob to move from
page to page within the topic.
Most of the help topics contain phrases marked with angle brackets, such as
<Autoset>. These are links to other topics. Turn the multipurpose knob to move
the highlight from one link to another. Push the Show Topic option button to
display the topic corresponding to the highlighted link. Push the Back option
utton to return to the previous topic.
b
Push the front-panel Help button, then push the Index option button. Push the
Page Up or Page Down option buttons until you find the index page that contains
the topic you want to view. Turn the multipurpose knob to highlight a help topic.
Push the Show Topic option button to display the topic.
NOTE. Push the Exit option button or any menu button to remove the Help text
from the screen and return to displaying waveforms.
xvi TPS2000B Series Digital Oscilloscope User Manual
Conventions
Preface
This manual uses the following conventions:
Front-panel buttons, knobs and connectors appear as displayed. For example:
Help.
Menu options appear with the first letter of each word in upper case. For
example: Peak Detect, Window Zone.
Multipurp
Option buttons - First letter of each word on screen is upper case
ose knob
Front-pan
el buttons and knob labels - As displayed
NOTE. Option buttons may also be called screen b uttons, side-menu buttons,
bezel buttons, or soft keys.
The ► delimiter separates a series of button pushes. For example, Utility
► Options ► RS232 Setup means that you push the Utility front-panel
ton, then push the Options option button, and then push the RS232 Setup
but
option button. Multiple pushes of an option button may be required to select
the desired option.
TPS2000B Series Digital Oscilloscope User Manual xvii
Preface
xviii TPS2000B Series Digital Oscilloscope User Manual
Getting Started
TPS2000B Series Digital Storage Oscilloscopes are small, lightweight, benchtop
instruments, which you can use to take ground-referenced measurements.
This chapter describes how to do the following tasks:
Take floating measurements
Install your product
General Features
Charge battery pack
Perform a brief functional check
Perform a probe check and compensate probes
Match your probe attenuation factor
Use the self calibration routine
NOTE. You can select a language to display on the screen when you power on the
oscilloscope. At any time, you can also access the Utility ► Language option to
select a language.
The next table and list d
Model Channels Bandwidth Sample r ate
TPS2012B
TPS2014B
TPS2024B
s
escribe the general features.
2 100 MHz
4 100 MHz
4 200 MHz
1.0 GS/s
1.0 GS/s
2.0 GS/s
Battery powered or line powered
Two rechargeable battery packs (second battery pack optional)
Independently isolated channels with no shared common ground
TPS2PWR1 Power Analysis application (optional)
Support for compatible voltage probes and current probes
Context-sensitive help system
Color LCD display
Selectable 20 MHz bandwidth limit
2500 point record length for each channel
Autoset
TPS2000B Series Digital Oscilloscope User Manual 1
Getting Started
Autoranging fo
Probe Check Wizard
Cursors with readouts
Trigger frequency readout
Eleven automatic measurements
Waveform averaging and peak detection
Dual time b
Math functions: +, -, and × operations
Math Fast Fourier Transform (FFT)
Pulse Width trigger capability
Video trigger capability with line-selectable triggering
External trigger
Setup a
Removable mass storage
Variable persistence display
nd waveform storage
r quick set up and hands-free operation
ase
RS-232 and Centronics ports
OpenChoice PC Communications software
User interface and help topics in ten languages
2 TPS2000B Series Digital Oscilloscope User Manual
Taking Floating Measurements
For taking floating measurements, the oscilloscope channel and Ext Trig inputs (3
MΩ ) are isolated from the oscilloscope chassis and from each other. This allows
independent floating measurements with channel 1, channel 2, and Ext Trig (and
with channel 3 and channel 4 on four channel models).
Getting Started
The osc
grounded power supply, a grounded printer, or a grounded computer.
Most o
and Ext Trig inputs. This reference is typically connected to earth ground through
the power cord. With common-referenced oscilloscopes, all input signals must
have the same common reference when you take any multi-channel measurements.
Without differential preamplifiers or external signal isolators, common-referenced
oscilloscopes are not suitable for taking floating measurements.
illoscope inputs float even when the oscilloscope is connected to a
ther oscilloscopes share a common reference for the oscilloscope channel
TPS2000B Series Digital Oscilloscope User Manual 3
Getting Started
Probe Connecti
on
WARNING. To prevent electrical shock, do not exceed the measurement or floating
voltage ratings for the oscilloscope input BNC connector, probe tip, or probe
reference lead.
Understand the voltage ratings for the probes you are using and do not exceed
those ratings. The following voltage ratings are important to know and understand:
The maximum measurement voltage from the probe tip and BNC signal to the
probe reference lead
The maximum measurement voltage from the probe tip and BNC shell to
earth ground
The maximum floating voltage from the probe reference lead to earth ground
WARNING. To avoid an electric shock, do not use probes that require a ground
connection, such as the Tektronix P5200A High Voltage Differential Probe, with
the TPS2000B series oscilloscopes. The P5200A High Voltage Differential
requires an oscilloscope with grounded inputs and the TPS2000B series
Probe
oscilloscopes have floating inputs (isolated inputs).
ING. Do not float the TPP0101 or TPP0201 probe reference lead to >
WARN
30 V
. Use the P5120 probe (floatable to 600 V
RMS
CAT II or 300 V
RMS
RMS
CAT III)
or similarly rated, passive, high voltage probe (not the ground referenced P5100
probe), or an appropriately rated, high voltage, differential probe when floating
the reference lead above 30 V
, s ubject to the ratings of such high voltage probe.
RMS
To avoid electric shock when using probes with exposed metal parts, do not
connect the reference lead to voltages above 30 V
RMS
.
These voltage ratings depend on the probe and your application. (See page 125,
TPS2000B Specifications.)
This manual contains more information on probe safety. (See page 11, Probe
Safety.)
4 TPS2000B Series Digital Oscilloscope User Manual
Loading...
