Read This First
TLA 7UP Options 01 & 04
Hard Disk Drive Installation for
TLA 704 and TLA 711 Mainframes
071-0845-00
www.tektronix.com
*P071084500*
071084500
Hard Disk Drive Installation Instructions
If you are upgrading a TLA704 or TLA 711 Logic Analyzer to an
8.0 GB hard disk driver or higher, you need to install third-party
driver software for proper operation.
Complete the following steps to install the hard disk drivers on your
logic analyzer. If you already tried installing a high-capacity drive
without using an appropriate disk manager driver, you may not be
able to access the floppy disk drive. T o recover from this condition,
follow the steps under Recovering from Boot Problems at the end of
this document.
Installing the High-Capacity Hard Disk Drive in a TLA 704 or TLA 711 Logic Analyzer
1. Download the proper driver (dc25029.exe) to a PC from the
following URL:
http://www.storage.ibm.com/techsup/hddtech/welcome.htm
NOTE. To comply with the software license agreement, you must
download and create a floppy disk with the Disk Manager software
for each instrument on which you will install the software drivers.
For more information, refer to the license agreement that comes with
the Disk Manager software.
2. Insert a blank formatted floppy disk into your PC.
3. Launch the dc25029.exe application and follow the on-screen
instructions to copy the Disk Manager software and drivers onto
the floppy disk.
4. Install the hard disk:
H For TLA 704 Mainframes, follow the instructions in the
TLA 7UP Mainframe Field Upgrade Kit Instruction Manual
1
(071-0572-02) beginning on page 4–5 to replace the hard disk
and to set up the controller BIOS.
H For TLA 711 Mainframes, follow the instructions in the TLA
7UP Mainframe Field Upgrade Kit Instruction Manual
(071-0572-02) beginning on page 4–17 to replace the hard
disk and to set up the controller BIOS.
5. Insert the Windows 95 Start-up disk and reboot the logic analyzer
from the floppy disk.
6. Remove the Windows Start-up disk and insert the floppy disk that
you created in step 3. T ype dm at the A:\> prompt to start the
Disk Manager program.
7. Follow the on-screen instructions to install the new drivers. When
you are asked to format the hard drive, select Yes and follow the
remaining on-screen instructions.
NOTE. After installing the new drivers pay attention to the Important
Information dialog box that displays at the end of the procedure and
follow the three steps in the dialog box.
8. Refer to the TLA 700 Series Installation Manual (070-9774-02) to
perform the software installation procedures beginning with
Reinstalling the Windows 95 Software on page 58. Then complete
the remaining procedures in Appendix B.
NOTE. While running W indows Setup, the program will detect an
operating system on the hard disk and will recommend that you exit
the Setup program. Do not exit the program; instead, select Continue
Setup to continue with the installation procedure.
This completes the Windows 95 Installation and the Version 2.0
application software installation. T o upgrade the operating system to
Windows 98 SE and the Version 3.2 application software, continue
with the following steps (these procedures assume that you have
purchased TLA 7UP Option 07 and Option 08):
2
9. Refer to External CD ROM Drive Installation in the TLA 7UP
Mainframe Field Upgrade Kit Instruction Manual (071-0572-02)
to install an external CD ROM drive and the software drivers so
that you can upgrade to the Windows 98 SE software.
10.Follow the instructions under Windows 98 SE Upgrade
Instructions in the TLA 7UP Mainframe Field Upgrade Kit to
install the Windows 98 SE operating system.
11. Follow the instructions under TLA Application Software Version
3.2 Upgrade in the TLA 7UP Mainframe Field Upgrade Kit to
install the TLA application software and the QA+Win32
diagnostic software.
Recovering from Boot Problems
If you already tried installing a high-capacity drive without using an
appropriate disk manager driver, you may not be able to access the
floppy disk drive. Use the following procedures to restore the proper
boot conditions for your floppy and hard disk drives.
1. Power on the logic analyzer and enter the BIOS setup by holding
down the F2 key during the boot process.
2. Set the BIOS configuration type (IDE Adapter 0 Master) to
T ype 1.
3. Save the settings and reboot the logic analyzer using the
emergency startup disk.
4. At the A:\ > prompt type fdisk and delete any existing partitions
from the new hard disk drive.
5. Reboot the logic analyzer and enter the BIOS setup by holding
down the F2 key during the boot process.
6. Set the BIOS configuration type (IDE Adapter 0 Master) to User.
7. Save the settings and reboot the logic analyzer using the
emergency startup disk.
8. Refer to step 5 on page 2 of this document to install the new
drivers and to reinstall the software on the hard disk.
3
