TEFAL PRO MINUTE PLUS, PRO MINUTE Aquaplus User Manual

GB

www.tefal.com

B

9

5

4

6d

6

7

6b

8

6a

6c

6

1

3

2

12

10

11

13a

14

15

13b

16

7

click !

fig.1 fig.2 fig.4

fig.5 fig.6 fig.8

fig.9 fig.10 fig.12

fig.13 fig.14 fig.16

fig.17

fig.18

fig.19

fig.20

fig.3

fig.7

fig.11

fig.15

click !

1/4

clip !

2

Important recommendations

Safety instructions

• Please read these instructions carefully before first use. This product has been designed for domestic use only.
Any commercial use, inappropriate use or failure to comply with the instructions, the manufacturer accepts no
responsibility and the guarantee will not apply.

• For your safety, this appliance conforms to the applicable standards and regulations (Low Voltage,
Electomagnetic Compatibility, Environmental Directives, as applicable...).

• Your steam generator is an electrical appliance. It should be used under normal conditions. It is intended for
domestic use only.

• Your generator is fitted with 2 safety systems:

- a pressure release valve which, in the event of a malfunction, releases any excess steam;

- a thermal fuse to prevent the appliance from overheating.

• Always plug your steam generator into:

- an electrical installation with voltage between 220V and 240V.

- an earthed socket.
Connecting to the wrong voltage may cause irreparable damage to the appliance and will invalidate your
guarantee.
If you are using a mains extension lead, ensure that it is correctly rated (10A) with an earth, and is fully
extended.

• Completely unwind the power cord from its storage space before connecting to an earthed socket.

• If the electric power cord or the iron-unit is damaged, it must be replaced by an Approved Service Centre in
order to prevent any danger.

• Do not unplug the appliance by pulling on the cord.
Always unplug your appliance:

- before rinsing out the boiler or before filling the reservoir or rinsing the boiler,

- before cleaning your generator,

- after each use.

• The appliance must be used and placed on a stable, heat-resistant surface. When you place the iron on the
iron rest, make sure that the surface on which you place it is stable.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• Never leave the appliance unattended :

- when it is connected to the mains,

- until it has cooled down (around 1 hour).

• The soleplate and generator iron-rest can become very hot and cause burns: never touch these parts.
Never touch the electric cords with the soleplate of the iron.

• Your appliance gives off steam which can cause burns. Handle your iron carefully, particularly when using the
vertical steam function. Never direct the steam towards persons or animals.

• Before unscrewing the boiler rinse cap, wait until the generator is cold (unplugged for more than 2 hours).

• While rinsing out the boiler, never fill it directly under the tap.

• If you lose or damage the boiler rinse cap, have it replaced by an approved Service Centre.

• Never immerse your steam generator in water or any other liquid. Never hold it under the water tap.

• The appliance must not be used if it has fallen to the floor, shows evidence of damage, leaks or fails to function
correctly. Never dismantle your appliance. To avoid any danger, have it inspected in an approved service
centre.

3

Description

1. Steam control button

2. Temperature control slide for the iron

3. Iron thermostat light

4. Iron rest

5. Iron-base steam cord

6. Control panel

a - Green light: Steam ready
b - Steam output control dial
c - Red light: Water tank empty
d - Orange light: Boiler rinse

7. Illuminated on / off switch

8. Power cord storage space

9. Lock-System hoop

10. Removable water tank

11. Filling inlet of the removable water tank

12. Removable water tank handle

13. a - Boiler rinse cap cover

b - Boiler rinse cap

14. Steam generator boiler (in the base unit)

15. Cord fastener

16. Steam cord storage space

Locking system for retaining the iron on the base
(Lock-system)

• Your steam generator is equipped with a retaining clip which locks the iron on
its casing for easier transport and storage – fig.1:

- Locking – fig.2.

- Unlocking – fig.3.

• To carry your steam generator by the iron handle:

- place the iron on the iron rest of the generator and raise the retaining hoop
over the iron until it locks into place (audible click) – fig.2.

- grasp the handle of the iron to carry your steam generator – fig.1.

Preparation

Due to the powerful steam output, a mesh type ironing board must be used to allow any excess steam to escape
and to avoid steam venting sideways.

What water may be used ?

• Your iron has been designed to operate using untreated tap water.

• Heat concentrates the elements contained in water during evaporation. The
types of water listed below contain organic waste or mineral elements that can
cause spitting, brown staining or premature wear of the appliance: water from
clothes dryers, scented or softened water, water from refrigerators, batteries or
air conditioners, pure distilled or demineralised water or rain water should not be
used in your iron. Also do not use boiled, filtered or bottled water.

Filling the water tank

• Place your steam generator on a stable, horizontal heat-resistant surface.

• Grasp the handle of the removable tank and pull horizontally to remove it –

fig.4.

•

Pour in untreated tap water up to the max mark

– fig.5.

• Replace it firmly in its housing, making sure it is fully into place – fig.6.

If your water is very hard
(check with your local
water authority) it is
possible to mix tap water
with store-bought distilled
or demineralised water in
the following proportions:
50% untreated tap water,
50% distilled or
demineralised water.

GB
