Tecumseh AJA7480ZNADA, AJA7480ZNADG, AJA7480ZNADC, AJA7480ZNADH, AJA7480ZNADK Performance Data Sheet
...
January 25, 2013
Revision: REL
Celseon® Air Cooled Condensing Unit
Model: AJA7480ZNAD* |
|
|
BoM: 2G1010-** |
R-404a |
1 HP |
|
|
Model |
|
|
Dimensions, inches |
|
|
|
Line Connection* |
|
Pumpdown |
|
Air |
|
Oil Ch |
|
Gr. Wt. |
|||||||||||||||
|
|
L |
|
W |
|
|
|
H |
|
|
CH |
|
Suction |
|
Liquid |
|
90 F 90% |
|
SCFM |
|
Oz. |
|
Lbs. |
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||
|
AJA7480ZNADA |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3/8” S |
|
3/8” S |
|
|
N/A |
|
|
|
|
76 |
||||||
|
AJA7480ZNADG |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3/8” S |
|
3/8” S |
|
6.1 lbs |
|
|
|
|
77 |
|||||||
|
AJA7480ZNADH |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3/8” S |
|
3/8” S |
|
|
N/A |
|
|
|
|
76 |
||||||
|
AJA7480ZNADK |
24.0 |
|
17.5 |
|
13.4 |
|
11.8 |
|
3/8” S |
|
3/8” S |
|
|
270 |
26 |
76 |
|||||||||||||||
|
|
|
|
|
|
|
|
|
|
|||||||||||||||||||||||
|
AJA7480ZNADC |
|
|
|
|
3/8” S |
|
3/8” S |
|
6.1 lbs |
77 |
|||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
AJA7480ZNADS |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3/8” S |
|
3/8” S |
|
|
N/A |
|
|
|
|
76 |
||||||
|
AJA7480ZNADJ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3/8” S |
|
3/8” S |
|
6.1 lbs |
|
|
|
|
78 |
|||||||
|
AJA7480ZNADP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3/8” S |
|
3/8” S |
|
6.1 lbs |
|
|
|
|
78 |
|||||||
|
* F = Flare, S = Solder, RF or RS = Rotolock with Flare or Solder Connections, C = Compression Fitting |
|
|
|
|
|||||||||||||||||||||||||||
|
Factory charge: 20 PSIG Nitrogen – MUST BE EVACUATED |
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Ambient Temperatures |
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
Evaporator T, |
|
|
|
80°F |
|
|
|
|
|
|
|
90°F |
|
|
|
|
|
100°F |
|
|
|
|
|
110°F |
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
°F |
|
PSIG |
|
BTUH |
|
Watts |
|
Cond T |
|
BTUH |
|
Watts |
|
Cond T |
BTUH |
|
Watts |
|
Cond T |
|
BTUH |
|
Watts |
|
Cond T |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
-10 |
|
24.3 |
|
5243 |
|
1291 |
|
|
104 |
|
4586 |
|
1293 |
|
112 |
3921 |
|
1265 |
|
120 |
|
3284 |
|
1244 |
|
128 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
-5 |
|
28.9 |
|
5892 |
|
1406 |
|
|
107 |
|
5181 |
|
1415 |
|
115 |
4449 |
|
1389 |
|
123 |
|
3779 |
|
1357 |
|
131 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
0 |
|
33.4 |
|
6524 |
|
1519 |
|
|
111 |
|
5762 |
|
1539 |
|
118 |
4963 |
|
1518 |
|
126 |
|
4251 |
|
1487 |
|
133 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
5 |
|
39.0 |
|
7140 |
|
1637 |
|
|
114 |
|
6328 |
|
1667 |
|
121 |
5463 |
|
1651 |
|
129 |
|
4701 |
|
1636 |
|
136 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
10 |
|
43.9 |
|
7739 |
|
1759 |
|
|
117 |
|
6880 |
|
1798 |
|
125 |
5950 |
|
1788 |
|
132 |
|
5129 |
|
1803 |
|
139 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
15 |
|
49.8 |
|
8322 |
|
1886 |
|
|
121 |
|
7417 |
|
1932 |
|
128 |
6424 |
|
1930 |
|
135 |
|
5535 |
|
1988 |
|
142 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
20 |
|
56.1 |
|
8888 |
|
2018 |
|
|
124 |
|
7940 |
|
2070 |
|
131 |
6883 |
|
2076 |
|
138 |
|
5918 |
|
2191 |
|
144 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
25 |
|
62.9 |
|
9439 |
|
2155 |
|
|
127 |
|
8448 |
|
2210 |
|
134 |
7329 |
|
2226 |
|
141 |
|
6279 |
|
2413 |
|
147 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
32 |
|
72.5 |
|
10181 |
|
2354 |
|
|
132 |
|
9136 |
|
2412 |
|
139 |
7931 |
|
2443 |
|
145 |
|
6748 |
|
2753 |
|
151 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
35 |
|
77.9 |
|
10490 |
|
2443 |
|
|
134 |
|
9422 |
|
2501 |
|
141 |
8181 |
|
2538 |
|
147 |
|
6935 |
|
2910 |
|
152 |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
60 Hz Performance
Return gas temp. 40 F, 5 F sub cooling
