TechniSat DigiCorder S1 User Manual
Operating Manual
DigiCorder S1
Digital receiver
with
integrated hard disk drive
IInntteeggrraatteedd
vviiddeeoo rreeccoorr--
ddeerr
PP VV RR
Operating Manual
WWiitthh iinntteeggrraatteedd PPrreemmiieerree ddeeccooddiinngg ssyysstteemm aanndd
PPCCMMCCIIAA iinntteerrffaaccee ffoorr iinnssttaalllliinngg aa CCII mmoodduullee..
For the reception of free-to-air and encrypted program-
mes broadcast via satellite,
(e.g.. VIACCESS, IRDETO, SECA ,etc. )
DDiiSSEEqqCC
1.2
1 Contents
1 Contents . . . . . . . . . . . . . . . . . . . . . . . . . .2
2 Illustrations . . . . . . . . . . . . . . . . . . . . . . .5
3 Please read this first . . . . . . . . . . . . . . . .8
Safety notes . . . . . . . . . . . . . . . . . . . . . . . .9
4 Connections . . . . . . . . . . . . . . . . . . . . . .11
4.1 Mains power connection . . . . . . . . . . . . . .11
4.2 External unit . . . . . . . . . . . . . . . . . . . . . . .11
4.3 Connecting to a television set . . . . . . . . . .11
4.4 Video cassette recorder (VCR) . . . . . . . . .12
4.5 HiFi amplifier . . . . . . . . . . . . . . . . . . . . . .13
4.6 Unit with S-Video input (Hosiden) . . . . . . .13
4.7 Serial interface (RS 232) . . . . . . . . . . . . .13
5 Initial installation . . . . . . . . . . . . . . . . . .13
6 Settings . . . . . . . . . . . . . . . . . . . . . . . . .17
6.1 Language for display . . . . . . . . . . . . . . . .17
6.2 Basic settings . . . . . . . . . . . . . . . . . . . . . .17
6.2.1 Time difference to GMT (hours) . . . . . . . .18
6.2.2 Country . . . . . . . . . . . . . . . . . . . . . . . . . .18
6.2.3 Remote control code . . . . . . . . . . . . . . . .18
6.2.4 Standby clock . . . . . . . . . . . . . . . . . . . . .18
6.3 Audio/Video settings . . . . . . . . . . . . . . . . .18
6.3.1 Picture format TV set . . . . . . . . . . . . . . . .19
6.3.2 Language (Audio signal) . . . . . . . . . . . . .19
6.3.3 Language (Sub-titles) . . . . . . . . . . . . . . . .19
6.3.4 TV SCART mode . . . . . . . . . . . . . . . . . . .19
6.3.5 Video system . . . . . . . . . . . . . . . . . . . . . .19
6.3.6 Dolby Digital (AC3) . . . . . . . . . . . . . . . . .19
6.3.7 UHF output channel . . . . . . . . . . . . . . . . .20
6.4 Antenna setting . . . . . . . . . . . . . . . . . . . .20
6.4.4 Rotating antenna . . . . . . . . . . . . . . . . . . .23
7 Operation . . . . . . . . . . . . . . . . . . . . . . . .24
7.1 Switching on and off . . . . . . . . . . . . . . . . .24
7.2 Programme selection . . . . . . . . . . . . . . . .24
7.3 Receiving encrypted programmes . . . . . .26
7.3.1 Multifeed options . . . . . . . . . . . . . . . . . . .27
7.3.2 Selecting a starting time . . . . . . . . . . . . . .27
7.4 Volume adjustment . . . . . . . . . . . . . . . . . .27
7.5 Selecting a different language . . . . . . . . .28
7.5.1 Dolby Digital (AC3 mode) . . . . . . . . . . . .28
7.6 TV/Radio selection/switching . . . . . . . . . .28
7.7 Return to last programme selected. . . . . .29
7.8 Display time and programme info . . . . . . .29
7.9 Additional programme information . . . . . .29
7.10 Transponder information . . . . . . . . . . . . .29
2
7.11 Freeze frame . . . . . . . . . . . . . . . . . . . . . .30
7.12 Video text . . . . . . . . . . . . . . . . . . . . . . . . .30
7.13 Sub-titles . . . . . . . . . . . . . . . . . . . . . . . .31
7.14 Electronic Programme Guide SFI . . . . . . .31
7.14.1 Downloading SFI data . . . . . . . . . . . . . . .32
7.14.2 Interrupting the download procedure . . . .32
7.14.3 Display Electronic Programme Guide . . . .32
7.14.4 Now (Table with current
programme contents) . . . . . . . . . . . . . . . .33
7.14.5 Next . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
7.14.6 More . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
7.14.7 SFI functions . . . . . . . . . . . . . . . . . . . . . .34
7.14.7.1 SFI information . . . . . . . . . . . . . . . . . . . .34
7.14.7.2 SFI timer programming . . . . . . . . . . . . . .34
7.14.7.3 SFI programme overview . . . . . . . . . . . . .35
7.14.7.4 SFI overview by programme type . . . . . . .36
7.14.8 End SFI . . . . . . . . . . . . . . . . . . . . . . . . . .36
7.15 Hard drive operation . . . . . . . . . . . . . . . . .37
7.15.1 Record . . . . . . . . . . . . . . . . . . . . . . . . . . .37
7.15.1.1 Instant Record . . . . . . . . . . . . . . . . . . . . .37
7.15.1.2 Timer recordings . . . . . . . . . . . . . . . . . . .39
Timeshift function . . . . . . . . . . . . . . . . . . .42
7.15.2 Playback . . . . . . . . . . . . . . . . . . . . . . . . .43
7.15.2.1 Play back hard drive recordings . . . . . . . .43
7.15.2.2 Pause/freeze frame . . . . . . . . . . . . . . . . .44
7.15.2.3 Fast forward and revers . . . . . . . . . . . . . .44
7.15.2.4 End Playback . . . . . . . . . . . . . . . . . . . . . .44
7.15.3 Managing the hard drive . . . . . . . . . . . . . .44
7.15.3.1 Managing recordings . . . . . . . . . . . . . . . .45
7.15.3.2 Hard drive information . . . . . . . . . . . . . . .46
7.15.3.3 Hard drive maintenance . . . . . . . . . . . . . .46
7.16 Sleep timer . . . . . . . . . . . . . . . . . . . . . . .46
8 Changing basic programming . . . . . . . .47
8.1 Configure a Favourites list . . . . . . . . . . . .47
8.1.1 Call up programme list administration . . . .47
8.1.2 Add programmes to Favourites list . . . . . .48
8.1.3 Delete programmes . . . . . . . . . . . . . . . . .49
8.1.4 Sort programmes . . . . . . . . . . . . . . . . . . .50
8.2 Programming the electronic
programme guide . . . . . . . . . . . . . . . . . . .50
8.3 Parental control function . . . . . . . . . . . . . .53
8.4 Programme Search/Scan . . . . . . . . . . . . .55
8.5 Service settings . . . . . . . . . . . . . . . . . . . .59
8.5.1 Activating default setting . . . . . . . . . . . . .59
3
8.5.2 Delete all programmes . . . . . . . . . . . . . . .59
8.5.3 Updating software . . . . . . . . . . . . . . . . . .60
8.5.4 Copying settings . . . . . . . . . . . . . . . . . . .61
8.6 System configuration . . . . . . . . . . . . . . . .61
8.7 Encryption system . . . . . . . . . . . . . . . . . .61
9 Operating a rotating antenna
(DiSEqC 1.2) . . . . . . . . . . . . . . . . . . . . . .62
9.1 Eastern and Western limits . . . . . . . . . . . .62
9.1.1 Delete existing limit settings . . . . . . . . . . .62
9.1.2 Setting Eastern limit . . . . . . . . . . . . . . . . .63
9.1.3 Setting Western limit . . . . . . . . . . . . . . . .63
9.2 Geo-positioning . . . . . . . . . . . . . . . . . . . .63
9.3 Setting satellite position . . . . . . . . . . . . . .64
9.3.1 Selecting satellite position . . . . . . . . . . . .65
9.3.2 Adjusting the satellite antenna . . . . . . . . .66
9.3.3 Saving a satellite position . . . . . . . . . . . . .67
9.4 Current satellite liste . . . . . . . . . . . . . . . . .67
9.4.1 Go to satellite position . . . . . . . . . . . . . . .68
9.5 Delete satellite position . . . . . . . . . . . . . .68
9.6 Reference position . . . . . . . . . . . . . . . . . .68
10 Technical terms . . . . . . . . . . . . . . . . . . .69
11 Technical data . . . . . . . . . . . . . . . . . . . .71
12 Trouble-shooting guide . . . . . . . . . . . . .75
13 Annexure . . . . . . . . . . . . . . . . . . . . . . . .77
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Your unit carries the CE logo, and complies with all relevant EU standards.
Subject to change without notice, not responsible for printing errors. Correct as
TechniSat and DigiCorder S1 are registered trade-marks of
Technische Hotline (in Germany)
*Cost 0,12 EUR/Min. via the Deutsche Telekom AG network
If it should become necessary to return your unit to the manufacturer, please
use only the address below:
at 11/03
TechniSat Digital GmbH
P.O. Box 560
D-54541 Daun
Germany
www.technisat.de
0180/5005-911*
Note !
TechniSat Teledigital AG
Service-Center
Löderburger Str. 94
D-39418 Staßfurt
Germany
4
2 Illustrations
RReemmoottee ccoonnttrrooll uunniitt
Sound on/off(mute)
Numeric keys
0/AV
Record
Multi-function keys
Arrow key up
Arrow key left
Arrow key down
SFI
Programme +
Programme -
TV/Radio mode
Sleep Timer
Video text
On/Standby
Option
red Rewind
green PVR-Navi-
gator, Stop
yellow:Pause, Play
blue Fast forward
OK
Programme list on/off
Arrow key right
Back
Info
Volume +
Volume -
Menu on/off
Language select
Freeze frame
Remote control option:
In order to operate 2 TechniSat receivers with identical coding, television sets as well as
an additional future option, (e.g. VCR).
Use these keys to select the remote control option Sat 1 and use this to operate your digital receiver, if you have not set this differently as described in Point 6.2.3:
> Press the SAT1 and OK keys simultaneously!
5
On/Standby
Alpha-numeric
display
LED display
Programme select
up/down
Input terrestrial
LNC
input
antenna
module
Slot for CI moduleEject button for CI
Inserting the CI module:
> Please note the manufacturer’s instructions for both the CI
module and card.
> Insert the appropriate smart card into the corresponding CI
module.
> Now insert the CI module carefully in the slot provided.
Video
output
SCART socket
TV
S-Video
output
Audio outputs
digital
LNC out-
put
HF
output
SCART socket
VCR
RS 232
interface
6
Power socket
Audio outputs
analogue
Sehr geehrte Kundin, sehr geehrter Kunde,
herzlichen Glückwunsch, dass Sie sich für den DigitalReceiver DIGITAL CIP entschieden haben.
Die vorliegende Betriebsanleitung soll Ihnen helfen, die umfangreichen Funktionen Ihres neuen Digital-Receivers optimal zu
nutzen.
Wir haben die Bedienungshinweise so verständlich wie
möglich verfasst und so knapp wie nötig gehalten.
Der Funktionsumfang Ihres Gerätes wird durch SoftwareUpdates ständig erweitert. Dadurch kommen gegebenenfalls
einige Bedienschritte hinzu, die in dieser
Bedienungsanleitung nicht erklärt sind, bzw. es kann sich die
Bedienung schon vorhandener Funktionen verändern. Aus
diesem Grund sollten Sie von Zeit zu Zeit die techniSat
Hompage besuchen, um sich die jeweils aktuelle
Bedienungsanleitung herunterzuladen.
Wir wünschen Ihnen viel Freude mit Ihrem TechniSat
DigiCorder S1!
Ihr
TechniSat Team
7
3 Please read this first
> Before operating your unit for the first time, please
check that you have received all the components. The
package should contain:
1 digital receiver, 1 mains power cable, 1 remote
control, 1 operating manual, 1 guarantee card, 2
batteries (1,5V microcell).
> Insert the batteries supplied in the battery
compartment of the remote control unit, taking care to
observe the correct polarity.
> Before connecting you digital receiver, please first read
the safety notes in Chapter 3.
> Chapters 4, 5 and 6 describe how you should connect
and adjust the digital receiver to the external unit
(antenna dish, LNC, ...), to the television set, VCR,
etc. These settings need only be made once, and
would only have to be updated if there is any change
in your external unit, or if additional pieces of
equipment are to be connected.
> Chapter 7 describes all the functions important in
everyday use, e.g. programme selection or operating
the hard drive.
> In Chapter 8 you will find information on how to set
new programmes, or how to change the order of
programmes in the list.
> Chapter 9 describes the settings to be made when
operating a rotating antenna.
>Technical terms used in the operating manual are
explained in Chapter 10.
>Technical data is set out in Chapter 11.
>Abrief troubleshooting guide can be found in
Chapter 12.
Important notes on operating the unit
The implementation of an "On Screen Display" (text shown on
screen) helps to simplify thed operation of the digital receiver,
and also helps to reduce the number of kews required on the
remote control unit. All functions are indicated on the screen,
and can be implemented with a few keys. Related functions
are combined in a "MENU". The function selected will be
marked and highlighted in a different colour. The bottom line
of the display shows colour bars in green, red, yellow and
blue, corrresponding to the function keys in these colours. In
the various menus these colour bars represent different
functions which can be accessed by pressing the
multi-function key of the appropriate colour on the remote
control unit. The function keys are only active if a brief
description appears in the appropriate field.
Key descriptions and other terms appearing in the OSD menu
are shown in emphasized letters in this operating manual.
8
Help:
Where available, press the blue function key to display help
texts, press again to disable the text display.
Disposal information
The packaging of this product consists entirely of recyclable
materials. Please separate the components accordingly, and
dispose of them via the “Dual System” or other local recycling
programmes.
Please ensure that discarded batteries from the remote control, as well as any other discarded electronic components,
are not disposed of in your regular household waste, but are
dsiposed of through the appropriate channels, either trough
your specialist retailer, or via the appropriate system of your
local authority).
Safety notes
For your own protection you should read the safety notes
carefully before operating your new unit for the first time.
The manufacturer accepts no responsibility for damage caused by inappropriate handling, or by ignoring the safety precautions in this manual.
>To ensure adequate ventilation, place the unit on a
smooth, even surface, and do not place any objects
on top of the unit. Ventilation slots located in the housing are essential to conduct heat from the interior of
the unit.
> Do not place any burning objects, such as burning
candles, on the unit.
> Do not expose the unit to water (spray, drops), and do
not place any objects filled with liquid, e.g. vases, on
top of the unit.
> The unit should be operated only in a temperate cli-
mate.
> Do not open the unit! You are in danger of experien-
cing an electrical shock. If it becomes necessary to
open the unit, this should be done only by trained per-
sonnel.
Disconnect the unit from the mains power supply and call an
authorised repair specialist if:
> the mains plug or the mains power cable are dama-
ged
> the unit has been exposed to humidity, or liquid has
entered the unit
> in case of significant malfunction
> in case of signficant external damage
Temporary disconnection
In case of an electrical storm, or when you are away for an
extended period of time,e.g. while on holiday, you should
disconnect the unit from the mains power supply.
9
Connecting the DVB receiver to a satellite
installation
a. Mains power connection
b. Connection from the LNC to the LNC input (LNB IN) of
the DVB receiver.
c. Connection from the LNC output to the LNC input of an
analogue receiver.
d. Scart connection of the DVB receiver with the television
set.
e. Connection from the HF output mto the antenna input
socket of the television set.
f. Connection from a terrestrial antenna to the terrest. ante-
nna input of the DVB receiver.
g. Scart connection from a video recorder to the VCR Scart
socket of the DVB receiver.
h. Connection from the S-Video output to the S-Video input
of another unit (e.g. beamer).
f
e
b
c
AAnnaalloogguuee RReecceeiivveerr
d
h
e.g.
Beamer
a
g
VVCCRR
10
4 Connections
The items a b c etc. mentioned below refer to the illustration
on page 10.
4.1 Mains power connection
The digital receiver should be connected to the mains power
supply only once all the other connections with other items of
equipment have been made. This will prevent damage to the
digital receiver or to other components.
a When you have made all the other connections. use
the mains power cable supplied to connect the recei-
ver to a mains power supply providing 230 V/50-60 Hz.
4.2 External unit
4.2.1 Single unit operation
b Using a suitable co-axial cable, connect the LNC input
of the digital receiver with the LNC of your external
unit. Please also note Point 6 under “Settings”.
4.2.2 Operating an additional receiver in a single-
receiver installation
c If you wish to operate an additional unit in a single-
receiver installation (e.g. an analogue receiver or an
ADR receiver), you can connect the LNC input of the
additional receiver with the LNC output of the DVB
receiver by means of a suitable co-axial cable. In
order for the satellite signal to be provided to the
additional receiver, your DVB receiver must be oper-
ated in Standby mode. If your DVB receiver is switc-
ched on, it will take over priority in controlling the LNC.
4.3 Connection to a television set
When you have connected your digital receiver with
the television set as described in this chapter, it may be
necessary to adjust the digital receiver to the television standard of your television set.
To do this, please note Point 6.3.5 (Video system).
4.3.1 Via SCART cable
To ensure the best possible picture quality, use a SCART
cable to connect the digital receiver with the television set.
Proceed as follows:
d Connect the receiver (SCART socket TV) and the
television set (SCART socket) by means of a SCART
cable. If your television set is appropriately equipped,
it will switch automatically to AV when the digital recei-
ver is switched on, and will provide satelliote recep-
tion.
11
4.3.2 Via HF cable
If your television set is not equipped with a SCART socket,
the digital receiver will have to be connected to the antenna
input socket of the television set. If this connection is used,
only mono sound reproduction is possible.
To make the connection, proceed as follows:
e Use a suitable TV connection cable to connect the
receiver (HF output) to the antenna input socket of
the television set.
f Connect the cable coming from the terrestrial antenna
to the Terrestrial antenna input of the digital receiver.
You must now set your television set to the transmission (output) channel of the digital receiver. Select a free programme
slot on your television set, and tune it to Channel 38 (if
necessary, consult the operating manual of your television
set).
If you do not receive a clear picture on Channel 38, either this
channel or a neighbouring channel may already be tuned to a
programme being received via the antenna. You can check on
this by temporarily removing the antenna cable from the Input
terrestrial antenna socket of the digital receiver. If you then
temporarily receive a clear picture, you should select a different channel on the digital receiver, in the range 21 to 69.
Setting the UHF output channel
To set an optimum UHF output channel, please proceed as
described in 6.3, and go to the menu Audio/Video Settings
and mark the field UHF output channel. Then proceed as
described in 6.3.7.
4.4 Video cassette recorder (VCR)
g Connect the video recorder to the SCART socket
marked VCR. In Playback mode, the video recorder
will supply a switching signal to the digital receiver.
The video recorder signal will be sent automatically to
the TV set.
If your video recorder does not supply the required
switching current, use the 0/AV key to switch your digi-
tal receiver to the external input AV. Press this key
again to return to normal operation.
4.5 HiFi Amplifier
4.5.1 Analogue
To achieve the best possible sound quality, you may connect
the digital receiver to a HiFi amplifier. To do this, use a suitable cable to connect the cinch sockets Audio R and Audio L
of the digital receiver with an input on your HiFi amplifier (e.g.
CD or AUX; please note that the Phono input is not suitable!).
12
4.5.2 Digital
Should your amplifier be equipped with an appropriate electrical or optical input, you may connect the sockets AUDIO
OUT DIGITAL elektrical resp.. AUDIO OUT DIGITAL optical
with the electrical resp. the optical input of your amplifier.
Depending on the channel selected, sampling rates of 32,
44,1 and 48 kHz are available.
Where broadcast, the Dolby Digital-Signal (AC3) is also available at this output.
4.6 Unit with S-Video input (Hosiden)
h To connect the S-Video output with a unit equipped
with an S-Video input (e.g. beamer etc.).
4.7 Serial Interface (RS 232)
The RS 232 interface serves to carry out pre-programming
via a PC, and to update the operating software.
5 Initial installation
Once you have read the safety notes, and have connected
the unit as described in Chapter 4, you may switch on the
unit as described in Chapter 7. When the unit is switched on
for the first time, the start window of the installation assistant
is displayed: AutoInstall. (Fig. 5-1) The installation assistant
will help you to make the most important settings on your
digital receivers quickly and simply.
You can exit from the initial installation procedure at any time
by pressing the red function key. Press the green function
key to return to the previous step of the installation. You can
thus correct any mistakes made at any time.
If the initial installation is not carried out, or is aborted before
completion, the unit will commence operation with a standard
pre-programmed configuration.
(Fig. 5-1)
The initial installation described here serves only as an
example. The exact procedure of the intial installation will
depend on the settings you choose to make.
Please follow closely the instructions given on the screen.
Operating language:
> Press OK to move to the selection window for the
operating (menu) language (Fig. 5-2)
> Use the up/down arrow keys to select the desired
operating language.
> Confirm by pressing OK.
Audio language
> Use the up/down arrow keys to select the preferred
13
(Fig. 5-2)
(Fig. 5-3)
(Fig. 5-4)
audio language. (Fig. 5-3)
When the installation assistant has been completed,
the programmes in the Favourites list will be sorted
accordingly.
> Confirm by pressing OK, to accept this selection into
memory.
Country setting
> Use the up/down arrow keys to select the time zone
corresponding to your location. (Fig. 5-4)
The automatic clock setting will be made in accordance with your selection.
> Confirm by pressing OK, to accept the setting into
memory, and to move on to the antenna configuration.
Antenna configuration
This step of the installation procedure serves to adjust the
setting of your digital receiver to the configuration of your
antenna.
> If you wish to accept the standard antenna setting,
use the up/down arrow keys to mark the entry
Standard and confirm by pressing OK. (Fig. 5-5)
In this case you can proceed to the Point “Software
Updates”.
> If the configuration of your reception installation does
not correspond to the standard setting, mark the entry
Manual and confirm by pressing OK.
(Fig. 5-5)
(Fig. 5-6)
(Fig. 5-7)
DiSEqC
> If your reception installation is equipped with DiSEqC
components, mark the field Activate and confirm by
pressing OK (Fig. 5-6).
(Additional information on DiSEqC can be found in
Chapter10, Technical Terms.)
Position A/Option A
> Use the arrow up/down keys to mark the satellite
you wish to receive at the DiSEqC setting Position
A/Option A, and confirm by pressing OK. (Fig. 5-7)
Position B/Option A
> Use the arrow up/down keys to mark the satellite
you wish to receive at the DiSEqC setting Position
B/Option A, and confirm by pressing OK. (Fig. 5-8)
Position A/Option B
> Use the arrow up/down keys to mark the satellite you
wish to receive at the DiSEqC setting Position
A/Option B, and confirm by pressing OK. (Fig. 5-9)
14
Position B/Option B
> Use the arrow up/down keys to mark the satellite
you wish to receive at the DiSEqC setting Position
B/Option B, and confirm by pressing OK. (Fig. 5-10)
As your next step, check again on the configuration of your
antenna.
> If you wish to accept this setting, use the arrow
up/down keys to mark the field Yes, and confirm by
pressing OK. (Fig. 5-11)
Updating software
When you have confirmed the antenna settings, the digital
receiver will automatically check whether a more up-to-date
version of the software for your unit is available via satellite. If
a new version of the software is available, you can perform
an automatic software update.
> Use the right/left arrow keys to select the field
Update, and confirm by pressing OK. (Fig. 5-12) The
new software for your unit will now be downloaded.
This procedure may take several minutes.
Scanning for programmes
Once you have checked on the software version, and possibly downloaded an updated version, you can proceed to
searching for programmes.
> Use the up/down arrow keys to mark the field All
Channels, if you wish to scan for both encrypted and
free-to-air programmes, or select All Free-to-air
Channels if you wish to scan for only this type of pro-
gramme. (Fig. 5-13)
(Fig. 5-8)
(Fig. 5-9)
(Fig. 5-10)
> Confirm your selection by pressing OK, the unit will
perform an automatic programme search. All the satel-
lites selected during the antenna configuration prove-
dure will be scanned for programmes. This procedure
may take several minutes. Please note any messages
displayed on screen.
15
(Fig. 5-11)
(Fig. 5-12)
(Fig. 5-13)
(Fig. 5-14)
When the scan is completed
When the scan has been completed, the number of transponders found, the number of programmes as well as the number
of new programmes found will be displayed. In addition, you
will be prompted (Fig. 5-14) to decide whether you want to
automatically include the programmes found in the TV or
Radio lists. If you decide to include the programmes automatically, you can then decide whether they should be included in
the Favourites list in sorted or unsorted form.
If the programmes found are accepted in sorted form,these
are sorted into the Favourites list in accordance with a preprogrammed system. This means that the order in which the
programmes are included is primarily based on the audio
language, as selected in the installation step Audio language.
If German has been selected as the audio language, the
sorting order can be further differentiated in terms of the country seleced in the installation step Country (Germany, Austria
or Switzerland).
If the new programmes are accepted in unsorted form, then
the newly found programmes are simply added in unsorted
order at the end of the Favourites list.
> Use the right/left arrow to select the type of sorting
you prefer, and confirm by pressing OK.
Exiting from the installation assistant
> The installation assistant will display a final message
(Fig. 5-15) Confirm this by pressing OK, to return to
normal operation.
(Fig. 5-15)
(Fig. 6-1)
6 Settings
You have now connected your digital receiver, and commenced operating it. You can, if you wish, still optimize the settings of the digital receiver in accordance with your preferences.
6.1 Operating language
This menu item allows you to set the menu language in
accordance with your preferences.
To change the operating language, proceed as follows:
> Press the Menu key to display the Main Menu.
(Fig. 6-1)
> Now use the up/down arrow keys to mark the menu
line Operating language.
> Confirm by pressing OK.
The sub-menu Operating language will be displayed.
> Use the up/down arrow keys to mark the preferred
language.
> Press OK to store this selection in memory.
> Press Back to return to the Main Menu.
16
6.2 Basic settings
To gain optimum enjoyment from your DVB receiver, you
should still make some settings related to your individual preferences.
> Press the Menu key to call up the Main Menu.
> Use the up/down arrow keys to mark the entry
Settings.
> Confirm by pressing OK. The sub-menu Settings will
be displayed. (Fig. 6-2)
> Now use the up/down arrow keys to mark the entry
Basic Settings.
> Confrim by pressing OK. The menu Basic Settings will
be displayed. (Fig. 6-3)
> Use the up/down arrow keys to move the marker
around within the menu, and to change any of the
individual positions. When selecting a menu item, ple-
ase note any additional messages displayed on
screen.
The following settings may be made:
(Fig. 6-2)
6.2.1 Time difference GMT (hours)
Your unit is equipped with a clock. This is synchronized via
satellite with Greenwich Mean Time.
If you have selected the entry None under the heading
Country (Point 6.2.3), you can simply set the unit clock to the
correct local time by means of the right/left arrow keys. For
Germany, this difference is +1 hour on standard time, and +2
hours during daylight savings time.
6.2.2 Country
This function provides for an automatic switch-over from
standard to daylight savings time.
> Go to the entry Country and use the left/right arrow
keys to select you country of residence.
6.2.3 Remote control code
In this line you must decide whether your receiver should be
allocated the remote control option SAT1 or SAT2.
>To make the selection, press the SAT1 resp. SAT2
key and the OK key simultaneously.
Press the Back key to return to the menu Settings, or
press Menu to return to normal operation. The settings
will be automatically stored in memory.
6.2.4 Standby clock
In this line you must decide whether the clock time should be
displayed when the unit is in standby mode.
> In this line, you can use the left/right arrow keys to
set the standby clock mode to on or off.
(Fig. 6-3)
17
(Fig. 6-4)
> Press Back to return to the menu Settings, or press
Menu to return to normal operation. The settings will
be automatically stored in memory.
6.3 Audio/Video settings
To optimize your digital receiver in conjunction with your television set, you can make further settings in the menu Audio
/Video settings.
> Press the Menu key to display the Main Menu.
> Use the up/down arrow keys to mark the line
Settings.
> Confirm by pressing OK. The sub-menu Settings will
be displayed. (Fig. 6-4)
> Now use the up/down arrow keys to mark the line
Audio/Video settings.
> Confirm by pressing OK. The menu Audio/Video set-
tings will be displayed. (Fig. 6-5)
> Use the up/down arrow keys to move the marker
around within the menu, in order to change the settings as indicated. Please also note the messages
displayed on screen in some cases.
The following adjustments may be made:
(Fig. 6-5)
6.3.1 Picture format TV set
> Use the left/right arrow keys to select the picture for-
mat appropriate for your TV set, 4:3 or 16:9. This function automatically adjusts the picture format for your
television set.
6.3.2 Language (Audio signal)
> In this line, use the left/right arrow keys to select your
preferred language. This function will automatically
select the preferred language, where available, after a
programme scan.
6.3.3 Language (Sub-titles)
The DVB receiver is equipped to display sub-titles on screen.
These will be displayed automatically if the function Sub-titles
has been activated, and if the sub-titles are being broadcast
in the language selected.
If the function has not been activated, sub-titles can be activated manually. Sub-titles are indicated by the symbol in
the information box. Please also note Point 7.13 of the operating manual.
6.3.4 TV SCART mode
In this line, use the left/right arrow keys to select the appropriate mode for your TV set, either CVBS or RGB. The setting
for standard sets is FBAS.
18
6.3.5 Video system
In this line you must set the appropriate television broadcast
standard for your television set. Use the left/right arrow
keys to select PALBG, PAL I, PAL DK, SECAM BG or
SECAM DK.
6.3.6 Dolby Digital (AC3)
A number of movie films are broadcast in the Dolby Digital
format. This will be indicated by the dolby symbol ( ) in the
information window once you have saelected the programme.
If you have a Dolby Digital 5.1 channel amplifier, you can
enjoy the appropriate films in 5.1 channel Dolby-Digital
sound, where broadcast. The only pre-requisite is that the
Audio Out Digital output of your DVB receiver (see Point
4.5.2) must be connected to the digital input of your Dolby
Digital 5.1 channel amplifier.
Where a programme is being broadcast in Dolby Digital
sound, the Dolby logo will appear in the information window
when the programme is selected. If the function Dolby Digital
(AC3) has been activated (on), therse broadcasts will automatically be presented in Dolby Digital format.
If the function has not been activated (off), Dolby Digital
sound can also be selected manually. Please also note Point
7.5.1 of the operating manual.
6.3.7 UHF output channel
To set a suitable UHF channel, proceed as follows:
> On your television set, select a free (unallocated) UHF
channel in the range of 21 to 69.
> Now use the left/right arrow keys to set the new out-
put channel of your digital receiver. The digital recei-
ver is now sending data on the UHF channel shown in
the display. Should reception not be satisfactory on
this channel, repeat the procedure until you find a
satisfactory channel.
> When you have found an optimal UHF channel, plea-
se remember to store this in the memory of your tele-
vision set.
> If your television set is equipped only with an automa-
tic scan function, simply set any UHF channel on your
digital receiver, then start the automatic scan of your
television set. You may have to repeat this procedure
until you find a suitable output channel, which you
should then store in the memory of your television set.
> It may then be necessary to perform fine tuning on
your television set.
19
(Fig. 6-6)
(Fig. 6-7)
(Fig. 6-8)
6.4 Antenna settings
When you have completed adjusting the settings of your digital receiver to your individual preferences, you can then, if
you like, adjust the antenna settings of your digital receiver.
The satellites selected by means of the installation assistant
will be displayed in the menu Antenna settings. If the installation assistant was prematurely aborted, the satellite positions
ASTRA and EUTELSAT are pre-programmed ex factory.
If you would also like to receive other satellites, or if you are
using a different type of LNC, you can make the appropriate
settings on your digital receiver as follows:
> Press Menu to call up the Main Menu. (Fig. 6-6)
> Use the up/down arrow keys to mark the item
Settings.
> Confirm by pressing OK.
The menu Settings will be displayed. (Fig. 6-7)
> Now use the up/down arrow keys to mark the item
Antenna settings.
> Confirm by pressing OK. The menu Antenna settings
will be displayed. (Fig. 6-8)
The following settings may be made in this sub-menu:
6.4.1 Switching DiSEqC on and off
DiSEqC (Digital Satelliten Equipment Control) is a digital switching system used to control DiSEqC-compatible components
via the antenna connection. If your external unit is equipped
with DiSEqC components, you must activate the DiSEqC control function:
> In this line, use the OK key to switch DiSEqC on or
off.
As only a single LNC can be controlled when the
DiSEqC control function is switched off, the menu is
limited to the configuration of a single LNC.
6.4.2 Setting the switching matrix
The menu lists the four switching criteria of the DiSEqC control function. Your unit has been pre-programmed at the factory to receive ASTRA at the switching position A/A and
Eutelsat at the position B/A of a multi-switch. If the switching
matrix of your reception installation be set up differently, or if
it is set up to receive other satellites, you can adjust the settings of your digital receiver in accordance with the requirements of your reception installation as follows.
> Use the arrow keys to select the DiSEqC switch posi-
tion (1-4) to which you wish to allocate a satellite (e.g..
A/B 3 No Satellite), by marking this line.
> Confirm by pressing OK.
A table showing a number of different satellites will be
displayed.
20
> Use the up/down arrow keys to mark the satellite
required.
Use the up/down arrow keys to move the marker up
or down one line at a time. Use the left/right arrow
keys to move forward or back one page at a time.
If the satellite you are looking for is not shown in the
list, please select one of the reserve slots, marked
User 1 to User 14.
> Confirm by pressing OK. The selected satellite will
now be inserted at the previously selected position in
the menu Antenna settings.
Continue to work in the menu Antenna settings in this manner until the settings in this menu correspond fully with those
of your reception installation. Select the option No Satellite
for any switching criteria not required.
6.4.3 Additional settings/LNC characteristics
When you have completed adjsuting the switching matrix of
your DVB receiver to match the reception installation, you
should check the additional settings for your reception installation, and adjust them where necessary.
> Use the left/right arrow keys to move the marker to
the column Configuration.
> Now use the up/down arrow keys in the line in which
you want to check or adjust the settings, and press
Next.
> Confirm by pressing OK.
A sub-menu will be displayed in which you can adjust
LNC settings, and set up a test transponder.
(Fig. 6-9)
The following adjustments may be made:
LNC type
> In this line use the left/right arrow keys to enter the
type of LNC you are using. You can choose from
Single LNC, Quatro LNC, DisiCon 1 LNC, DisiCon
2 LNC, DisiCon 4 LNC, C-Band LNC and a User
LNC for manual entry of LNC data.
> Press OK to accept the setting into memory.
Test Transponder
The following points of this menu need only be entered if you
wish to check the satellite signal of a particular satellite.
Transponder frequency
In this line, use the numeric keys to enter a frequency on
which digital programmes are broadcast.
Polarisation
Use the up/down arrow keys to select the appropriate polarisation plane (horizontal or vertical).
Example:
A B
PPoossiittiioonn
Output
(Fig. 6-9)
A B
PPoossiittiioonn
Output
A B
OOppttiioonn
Output
21
Symbol rate
The symbol rate indicates the volume of data transmitted per
second. This could be, for instance, 27500 (27500 symbols
per second). Use the numeric keys to enter the appropriate
symbol rate.
User LNC
If you have entered User LNC as the DiSEqC type, you can
make additional settings:
LOF low band
LOF (Local oscillator frequency) is the frequency at which the
LNC converts the frequency received into the so-called 1.
interim frequency, which can then be received by the digital
receiver. So-called Universal LNCs employ 2 LOFs to cover
the entire reception range from 10,7 to 11,8 GHz (low-band)
and 11,7 to 12,75 GHz (high-band).
> In this line, use the numeric keys to enter the LOF of
the low band of your LNC.
LOF high band
> In this line, use the numeric keys to enter the LOF of
the high band of your LNC.
Transition LOF low/high
> In this line, use the numeric keys to enter the freque-
ncy at which your LNC switches from the low band to
the high band.
> Press OK to accept the settings into memory.
Signal/Quality
If you have entered the parameters of the test transponder
correctly, you will see in these lines indicators showing signal
strength and signal quality.
6.4.4 Rotary antenna
When operating the digital receiver in conjunction with a
rotary antenna equipped with a DiSEqC compatible motor
(Level 1.2), activate the DiSEqC control (Point 6.4.1) by
setting it to on and please note Point 9 of the operating
manual.
7 Operation
7.1 Switching on and off
> Switch the digital receiver on by pressing the
On/Standby key either on the unit or on the remote
control.
> Press the same key again, either on the unit or on the
remote control, to switch the receiver off.
> The receiver is now in standby mode. If this feature
has been activated (as described in Point 6.2.4) the
current time will be shown in the display.
If the current time is not shown, this must still be
22
downloaded to the receiver. To do this, switch the unit
on and switch to reception of a major channel, such
as ZDF, that broadcasts a time signal, for about 30
seconds, to acquire the current time automatically.
7.2 Programme selection
7.2.1 Using the programme up/down keys
> Use the programme up/down keys either on the unit
or on the remote control to move up or down by one
programme slot at a time.
7.2.2 Using the numeric keys
> Use the numeric keys to enter the desired program-
me number.
For example:
1 for programme slot 1
1, then 4 for programme slot 14
2, then 3, then 4 for programme slot 234
When entering programme numbers of more than one digit,
you have approx. 3 seconds time after pressing a key to
complete the entry.
If you wish to enter a number consisting of only one or two
digits, you can speed up the switching procedure by holding
down the key a little longer on the last digit.
7.2.3 Using the Navigator (Programme list)
> Press OK.
The programme list navigator will be displayed. In TV
mode, only TV programmes will be shown, while only
radio programmes will be shown while in Radio mode.
The currently selected programme will be highlighted.
(Fig. 7-1)
> Now, use the up/down arrow keys to mark the selec-
ted programme.
> Press OK to switch reception to the desired program-
me.
> Use the up/down arrow keys to move around the list
one programme slot at a time.
> Use the left/right arrow keys to move around the list
one page at a time.
(Fig. 7-1)
7.2.3.1 Selecting a list
To facilitate the finding of programmes, your receiver is
equipped with several programme lists. You have the choice
of selecting your Favourites list (see Point 8.1), or you can
use the alphabetically sorted Total list, or you can view a list
sorted by Providers.
23
(Fig. 7-2)
(Fig. 7-3)
(Fig. 7-4)
> Press OK. The active programme list will be displayed.
> Now use the red function key Category to open a win-
dow displaying the programme list types (Favourites
list, Providers list and Total list). The active type of
programme list will be highlighted. (Fig. 7-2)
In addition, the entry Hard drive recordings will be
shown, allowing you to access the hard drive navigator
(Point 7.15.2).
> Use the up/down arrow keys to select a programme
list type, e.g. Total list.
> Confirm by pressing OK.
The alphabetically sorted total list will be displayed,
containing all programmes. (Fig. 7-3)
> Use the up/down arrow keys to select the program-
me you wish to view or listen to.
> Confirm by pressing OK.
or
> Press the green function key PVR to go directly to the
hard drive navigator.
7.2.4 Accessing blocked programmes
If a programme is selected that is blocked by the parental
control function, the message Unit PIN will be displayed on
screen. (Fig. 7-4)
> Use the numeric keys to enter your PIN code. The
selected programme can now be viewed.
or
> Switch to a programme whose access is not blocked.
If you have selected the option on under Point 8.3.2, you will
always be prompted to enter the PIN code when switching to
a blocked programme. However, in order to make matters
more convenient for you, you need enter the PIN code only
once in each operating phase.
(Fig. 7-5)
7.2.5 Information box
Each time you switch programmes, an information box (Fig.
7-5) will be displayed briefly, showing the programme number
and name of the selected programme. In addition, some programme characteristics will be indicated, for example for
teletext, for a 16/9 broadcast, for sub-titles, for
encrypted programmes. Also, where provided, the EPG category and the FSK age restriction in Germany (Freiwillige
Selbstkontrolle der Filmwirtschaft) will be indicated.
7.3 Reception of encrypted programmes
Your receiver is equipped with a “Common Interface”. This
enables you to receive encrypted programmes. To do this,
you must first insert a CI module together with a valid smart
card into the slot provided:
24
