Technika AEDTR160S7 User Manual
USER MANUAL
DIGITAL TV RECORDER
AEDTR160S7
1
INDEX
IMPORTANT SAFEGUARDS...............................................................................................................................................2
WIRING THE PLUG.............................................................................................................................................................5
GENERAL PROPERTIES....................................................................................................................................................6
REMOTE CONTROL............................................................................................................................................................6
GETTING STARTED............................................................................................................................................................7
FRONT AND BACK PANEL.................................................................................................................................................7
CONNECTION DIAGRAMS.................................................................................................................................................8
REMOTE CONTROL & FUNCTIONS..................................................................................................................................9
MENU INTERFACE............................................................................................................................................................11
FIRST TIME INSTALLATION.............................................................................................................................................11
MAIN MENU.......................................................................................................................................................................11
1. CHANNEL LIST..............................................................................................................................................................11
1.1. NAVIGATING CHANNEL LIST....................................................................................................................................12
1.2. DELETING CHANNEL................................................................................................................................................12
1.3. EDIT CHANNELS........................................................................................................................................................12
1.4. ADDING LOCKS TO CHANNELS...............................................................................................................................12
1.5. SETTING FAVOURITE LIST.......................................................................................................................................12
2. PROGRAMME GUIDE (7 DAYS EPG)..........................................................................................................................13
3. TIMERS..........................................................................................................................................................................13
4. RECORDINGS LIBRARY...............................................................................................................................................14
4.1. PLAY OPTIONS..........................................................................................................................................................15
4.1.1. PLAY FROM START................................................................................................................................................15
4.1.2. RESUME..................................................................................................................................................................15
4.1.3. PLAY FROM OFFSET..............................................................................................................................................15
4.1.4. MANAGE CHAPTERS.............................................................................................................................................15
4.1.5. CREATE ARCHIVE (ARCHIVE MANAGEMENT)....................................................................................................15
EDIT RECORDINGS..........................................................................................................................................................15
MAIN TITLE........................................................................................................................................................................16
RECORDING TITLE...........................................................................................................................................................16
4.2. CHAPTER OPTIONS..................................................................................................................................................17
4.2.1. CREATE NEW CHAPTER MARK............................................................................................................................17
4.2.2. FORWARDS TO NEXT CHAPTER..........................................................................................................................17
4.2.3. BACK TO START OF CHAPTER.............................................................................................................................17
4.2.4. BACK TO PREVIOUS CHAPTER............................................................................................................................17
5.1. RECORDINGS............................................................................................................................................................18
5.1.1. MAX TIMESHIFT......................................................................................................................................................18
5.1.2. AUTO DISCARD.......................................................................................................................................................18
5.1.3. FORMAT DISK.........................................................................................................................................................18
5.1.4. HARD DISK INFO.....................................................................................................................................................19
Recording Format...............................................................................................................................................................20
Unrecordable Material........................................................................................................................................................20
Hard Disk Operation (Recording / Playback / Time Shift Recording).................................................................................20
5.2. CONFIGURATION.......................................................................................................................................................21
5.2.1. TV TYPE...................................................................................................................................................................21
5.2.2. TV OUT.....................................................................................................................................................................21
5.2.3. VCR OUT..................................................................................................................................................................21
5.2.4. FAVOURITE MODE.................................................................................................................................................21
5.2.5. CHANNEL LIST........................................................................................................................................................21
5.2.6. SCAN ENCRYPTED CHANNELS............................................................................................................................21
5.2.7. RECEIVER UPGRADE - OAD.................................................................................................................................22
5.2.8. PARENTAL LOCKING.............................................................................................................................................22
5.2.8.i. MENU LOCK...........................................................................................................................................................22
5.2.8.ii. SET PIN.................................................................................................................................................................22
5.3. LANGUAGE.................................................................................................................................................................23
5.4. INSTALLATION...........................................................................................................................................................23
5.4.1. AUTOMATIC CHANNEL SCAN...............................................................................................................................23
5.4.2. MANUAL CHANNEL SCAN.....................................................................................................................................23
5.4.3. FIRST TIME INSTALLATION...................................................................................................................................24
6. MESSAGES....................................................................................................................................................................24
7. SPECIFIC FUNCTIONS OF REMOTE CONTROL........................................................................................................24
TIME SHIFTING (PAUSE LIVE RECORDING)..................................................................................................................26
8. SOFTWARE UPGRADE THROUGH RS232................................................................................................................28
9. NOTES...........................................................................................................................................................................29
10. TROUBLE SHOOTING GUIDE....................................................................................................................................30
11. TECHNICAL SPECIFICATIONS..................................................................................................................................31
12. IMPORTANT NOTICE:.................................................................................................................................................33
DIGITAL SWITCHOVER AND YOUR TV EQUIPMENT....................................................................................................33
2
IMPORTANT SAFEGUARDS
CAUTION: Please read all of these instructions before you operate this product and save these
instructions for later use.
Electrical energy can perform many useful functions. This product has been engineered and
manufactured to assure your personal safety. BUT IMPROPER USE CAN RESULT IN POTENTIAL
ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the safeguards incorporated in this
product, observe the following basic rules for its installation, use and servicing.
1. Read Instructions
All the safety and operating instructions should
be read before the product is operated.
2. Retain Instructions
The safety and operating instructions should be retained for future reference.
3. Heed Warnings
All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions
All operating and use instructions should be
followed.
5. Cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
6. Attachments
Do not use attachments not recommended by the product manufacturer as they may cause hazards.
7. Water and Moisture
Do not use this product near water–for example, near a bath tub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming pool; and the like.
8. Accessories
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall,
causing serious injury to a child or adult, and serious damage to the product. Use only with a cart,
stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any
mounting of the product should follow the manufacturer’s instructions, and should use a mounting
accessory recommended by the manufacturer.
9. Transportation
A product and cart combination should be moved with care. Quick stops, excessive force,
and uneven surfaces may cause the product and cart combination to overturn.
10. Ventilation
Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the
product and to protect it from overheating, and these openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instructions have been adhered to.
11. Power Sources
This product should be operated only from the type of power source indicated on the marking label. If
you are not sure of the type of power supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other sources, refer to the operating
instructions.
3
12. Grounding or Polarization
This product is provided with one of the following types of plugs. If the plug should fail to fit into the
power outlet, please contact your electrician. Do not defeat the safety purpose of the plug.
a. Two-wire type (mains) plug.
b. Three-wire grounding type (mains) plug with a grounding terminal. This plug will only fit into a
grounding type power outlet.
13. Power-Cord Protection
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the product.
14. Lightning
For added protection for this product during a lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and disconnect the cable system. This will
prevent damage to the product due to lightning and power-line surges.
15. Overloading
Do not overload wall outlets, extension cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.
16. Object and Liquid Entry
Never push objects of any kind into this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any
kind on the product.
17. Servicing
Do not attempt to service this product yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
18. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the
following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions. Adjust only
those controls that are covered by the operating instructions, as an improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician to restore
the product to normal operation.
e. If the product has been dropped or damaged
in any way.
f. When the product exhibits a distinct change in performance, this indicates a need for service.
• DLP\ (Digital Light Processing) and DMD\ (Digital Micromirror Device) are trademarks of Texas
Instruments, Inc.
• Microsoft® and Windows® are registered rademarks of Microsoft Corporation in the United States
and/or other countries.
• PC/AT is a registered trademark of International Business Machines Corporation in the United
States.
• Macintosh® is a registered trademark of Apple Computer, Inc. in the United States and/or other
countries.
• All other company or product names are trademarks or registered trademarks of their respective
companies.
• Some IC chips in this product include confidential and/or trade secret property belonging to Texas
Instruments. Therefore you may not copy, modify, adapt, translate, distribute, reverse engineer,
reverse assemble or discompile the contents thereof.
4
19. Replacement Parts
When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer or have the
same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock,
or other hazards.
20. Safety Check
Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating condition.
21. Wall or Ceiling Mounting
This product should be mounted to a wall or ceiling only as recommended by the manufacturer.
22. Heat
This product should be situated away from heat sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.
WARNING
5
WIRING THE PLUG
Do not place the product where a piece of furniture or other heavy object could trap the power cord
(mains lead). Handle the power cord by the plug. Do not pull out the plug by tugging the cord and
never touch the power cord when your hands are wet as this could cause a short circuit or electric
shock. Never make a knot in the cord or tie it with other cords. The power cords should be routed in
such a way that they are not likely to be stepped on. A damaged power cord can cause fire or give you
an electrical shock. Check the power cord periodically to see if it is damaged. If it is damaged, please
ask an approved service agent to replace it.
For your own safety read following instructions carefully before attempting to connect this device to the
mains.
This unit is designed to operate on a 220V-240V AC - 50Hz supply only. Connecting it to other power
sources may damage it. Ensure that the supply corresponds to the informationon the rating label on
the bottom of the unit. This component system may be fitted with a non-rewireable plug. If it is
necessary to change the fuse in a non-rewireable plug, the fuse cover must be refitted. If the fuse
cover becomes lost or damaged, the plug most not be used until a replacement, available from the
manufacturer, is obtained. It is important that the colour of the replacement fuse cover corresponds
with the colour marking on the base of the plug. If the plug needs to be changed because it is not
suitable for your socket, or it becomes damaged, it should be cut off and the fuse removed
immediately. Please dispose of the plug safely and out of reach from children. Under no circumstance
should the cut-off plug be inserted into a mains socket outlet due to high risk of electric shock.
Then fit an appropriate plug carefully following the wiring instructions shown below.
IMPORTANT
The wires in the mains plug should be connected
as shown in the diagram.
The colours of the wires in the mains lead of the unit
may not correspond with the coloured markings
identifying the terminals in your plug. Connect them
as follows:
The wire which is coloured blue must be connected
to the terminal which is marked with the letter ‘N’ or
coloured black.
The wire which is coloured brown must be connected
to the terminal which is marked with the letter ‘L’ or
coloured red.
There should be no connection to earth terminal of
your plug. If you use a 13 Amp (BS1363) plug, you will
need a 5 Amp fuse.
How to replace the fuse
Open the fuse compartment with a blade screwdriver and replace the fuse. When replacing the fuse in
the plug, use ASTA or BSI approved 5 AMP fuse and be sure to re-fit the fuse cover. If the plug
supplied with this equipment has a detachable fuse cover, be sure attach the fuse cover after you
change the fuse. Never use the plug without the fuse cover.
If you should lose the fuse cover, please contact an electrical goods retailer.
If in doubt, consult a competent electrician how to replace the fuse
This symbol means that this unit is double insulated. An earth connection is not required.
CAUTION
To prevent electric shock, disconnect from the mains before removing cover. No user servicable parts
inside. Refer servicing to qualified service personnel. Disconnect from the mains supply before
cleaning.
BLUE
(NEUTRAL)
BROWN
(LIVE)
FUSE
CORD GRIP
OUTER
SLEEVE
6
GENERAL PROPERTIES
1. Menu Language: English
2. Channel lock, Menu lock
3. Channel list sorted by D-book logical channel numbers.
4. Channel list name editing option.
5. BBC UK Compliant Over Air Download.
6. PIP (Picture in picture)
7. Time shift – pause live TV.
8. One button record (Instant recording of channels).
9. Dual recordings at the same time.
10. Once, daily, weekly programmed event recordings.
11. Ability to record one channel while watching another channel.
12. X1/4, X1/2, X1, X2, X4, X8, X16, X32 forward and backward play options.
13. Play list shows available recordings (Event name, Start time, Duration, delete/playback
permission)
14. Timers list shows scheduled recordings (Event name, Start time, Duration, once/daily/weekly
repeat, change/delete/playback permission)
15. Record timer via 7 day EPG
16. Records DVB subtitles (If any are broadcasted by the broadcaster).
17. Automatic/Manual channel search.
18. Guided first time installation.
19. 200 channels.
20. Favourite channel lists.
21. Automatic day light saving time updating.
22. MHEG-5 Engine
REMOTE CONTROL
1. Press the ^ mark on the cover and slide it in the direction of the arrow.
2. Insert the batteries making sure the polarities correctly match the + and - marks inside the battery
compartment.
3. Attach the cover and slide it until it clicks into place.
Incorrect use of the batteries may cause them to leak or explode. Please
follow the precautions below.
•Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• Insert the batteries making sure the polarities correctly match the + and - marks inside the battery
compartment.
• Batteries of different types have different properties, therefore do not mix batteries of different types.
• Do not mix new and old batteries.
This may shorten the life of new batteries or may cause old batteries to leak.
• Remove the batteries from the remote control once they have run out, as leaving them in can cause
them to leak.
Battery fluid from leaked batteries is harmful to skin, therefore ensure that you wipe them first and then
remove them using a cloth.
• Remove the batteries from the remote control if you will not be using the remote control for a long
time.
• Comply with the rules (ordinance) of each local government when disposing of worn-out batteries.
Replacement batteries for this unit are 1.5 Volt (R03/AAA).
7
GETTING STARTED
Before connecting, ensure that the power cord of the unit is unplugged from the AC outlet and turn off
the devices to be connected. After making all connections (Diagrams on page 6), turn on the unit first
and then the other devices.
After plugging in the mains cord, wait until a blue light is viewable on the front panel (Standby Mode).
"NOTE" - When the unit is first powered up, please wait a short while before activating the receiver as
the unit's software needs to be initialised and the hard disk checked.
You can turn on your unit by pressing the Standby button on the remote control. Notice that the blue
light on the front panel will turn blue.
The unit is equipped with output terminals that support RGB, S-video and CVBS video signals.The
image quality is highest in the order of the RGB signal, the S-video signal and the CVBS video signal.
FRONT AND BACK PANEL
FRONT PANEL:
MENU RECOKPAUSE
ON / OFF
MENU
RECORD
PAUSE
OK
MENU
UP / DOWN
MENU
LEFT / RIGHT
BACK PANEL
TV SCARTVCR SCART
ANTENNA 1 OUTANTENNA 1 IN
RS 232
CVBS
LEFT
RIGHT
OPTICAL OUT
ANTENNA 2 OUTANTENNA 2 IN
AC IN
1
34
2
5
67
8
9
DO NOT REMOVE
10
11
1. AERIAL 2 OUT : To watch analogue channels on the TV
2. AERIAL 2 IN : Loop through
3. AERIAL 1 OUT : Loop through
4. AERIAL 1 IN : Aerial input
5. RS232 : Software Upgrade
6. OPTICAL SPDIF : Optical Digital Audio Output
7. VCR SCART : Output for other equipment such as DVD, VCR...etc.
8. TV SCART : TV Scart connection
9. ANALOGUE AUDIO LEFT/RIGHT : Analogue Audio output
10. CVBS : Video Output
11. POWER SUPPLY : 220-240V AC, 50 Hz
8
CONNECTION DIAGRAMS
TV SCARTVCR SCART
ANTENNA 1
OUT
ANTENNA 1
IN
RS 232
CVBS
LEFT
RIGHT
OPTICAL OUT
ANTENNA 2
OUT
ANTENNA 2
IN
AC IN
3502015 7
TV Aerial
LOOP THROUGH
AC3 DIGITAL
AMPLIFIER
VCR
VCR SCART
VCR
VCR SCART
TV Aerial
DO NOT REMOVE
Aux
HI-FI
Aux
HI-FI
NOTE: This set top box supports Free To View only. There is no provision for a CAM or Pay To View
card.
9
REMOTE CONTROL & FUNCTIONS
USING THE CONTROLS ON THE FRONT PANEL
You can enter the main menu by pressing the menu button on the front of the unit. Then navigate
through the menu's with the four Arrow buttons on the front of the unit.and make a selection with the
OK button.
10
BUTTON
FUNCTION
1. STAND BY Standby ON/OFF
2. 8 Fast Forward
3. LIB. Library of records
4. TIMERS Schedule recording
5. Record key
6. INFO Displays Info window
7. Arrow buttons/OK Menu Navigation
8. BACK Exit from menu (Without saving)
9. PR+/- Next/Previous channel
10. YELLOW Teletext Function key
11. BLUE Teletext Function key
12. 0,1,2,3.....9 Numeric keys
13. P3P Previous channel
14. WIDE TV Mode
15. SUBT. Enables Subtitles
16. SWAP
Normal screen and PIP window change
their places
17. PIP + Next channel in PIP window
18. MUTE Mute
19. 4 Play the records
20. 7 Fast backward
21. < Stop the records
22. ; Pause
23. GUIDE Electronic Program Guide
24. TEXT Teletext key
25. V+/ V - Volume UP/DOWN
26. GREEN Teletext Function key
27. RED Teletext Function key
28. AUX VCR Switch
29. MENU Enter menu/ Exit menu (With saving)
30. FAV Favourite list
31. PIP Opens PIP window
32. PIP- Previous Channel in PIP window
Loading...
