Technics SA-EX700 User Manual
Specifications and Main Features
- Device Model: SA-EX700 und SA-EX500
- Leistungsabgabe ( SA-EX700 ):
- DIN 1 KHZ (T.H.D. 1%)- 2X 100 W(8 Ω)
- Dauerleistungsabgabe (20 HZ – 20 KHZ, beide Kanäle angesteuert): 2X 90 W (8 Ω)
- Totale Harmonische Verzerrung:
- Rated-power at 20 Hz-20 kHz: 0,05% 8 Ω
- Half-power: (1 Professor 8Ω): 0.03% (8Ω)
- Lastenimpedanz:
- Frontlautsprecher: A oder B 8-16 Ohm; A und B: 8-16 Ohm
- Centerlautsprecher: 8-16 Ohm
- Surroundlautsprecher: 4-16 Ohm
- Subwoofer (nur SA-EX700): 8-16 Ohm
- Anlage Frequenzgänge:
- Phono (Weighting curve RIAA 30Hz – 15 kHz): + 0.8 dB
- CD, Tape, VDP, Fernseher, Vidoeoreocoder 1, Vidoeoreocoder 2 (SA-EX700): 10Hz – 40kHz +3dB
- CD, Tape VCR 1, TV/ VCR 2 (SA-EX500): 10Hz – 40kHz +3dB
- Eingänge:
- Phono: 3 mV/ 47 kΩ
- Others SA-EX700: 200 mV/ 22 kΩ
- SA-EX500:220 mV/ 22KΩ
- FM Tuner Abschnitte:
- Frequenzband: 87.50 – 108.00 MHz
- Totale Harmonische Verzerrung: MONO 0,2% STEREO 03%
- Empfindlichkeit: S/N: dB: 30 dB: 1.5μv/75Ω
- AM Tuner Abschnitt:
- Frequenzbereich: AM 522-1611 kHz 9 kHz Schritte
- Empfindlichkeit: AM 20μv: 330μv/m
- Dimensions (SA-EX700): 430 х 158 х 358 мм:
- Weight (SA-EX700): 10.3 kilograms
Frequently Asked Questions
Q: What is the power output of the SA-EX700 stereo receiver?
A: The SA-EX700 offers 2X 100 W (8 Ω) power output at a threshold of T.H.D. 1% at a frequency of 1 kHz per DIN specification.
Q: Am I able to view AM stereo on the device?
A: This device receives AM stereo broadcasts. However, they will be played back in AM mono format.
Q: Is there a frequency range available for the FM tuner?
A: The FM tuner is able to receive signals in a 87.50 to 108.00 MHz frequency range.
Q: What is the impedance load for the surround speakers?
A: The surround speakers are rated to have an impedance load that ranges from 4 to 16 Ω.
Q: Does SA-EX500 vary from SA-EX700 with regards to its specifications?
A: However, the SA-EX 500 has similar specifications, just that it has a lower output power rating and different physical dimensions.
Q: Is it possible to attach a subwoofer to the receiver?
A: A subwoofer can be attached to the SA-EX700. Additionally, it can handle a subwoofer impedance in the 8-16 Ω range.
Q: What can I do in the event that the sound output goes off abruptly without my intention?
A: During the setup, verify that the positive and negative speaker connections are not shorted, and check the speaker impedance as well. If there is, then amend the connections and turn the receiver on again.
