TEAC CTF-6890 Service manual

SERVICE MANUAL

CTF6890

68 CM CTV

MAR03 CTF6890SERV

TEAC

SERVICE MANUAL

CT-F6890S

1. Caution……………………………………………………………2

2. Specification………………………………………………………6

3. BOM List …………………………………………………………13

4. Alignment Procedure………………………………………….…56

5. Block Diagram……………………………………………………62

6. Schematic Diagram………………………………………………63

7. PCB Layout………….……………………………………………64

8. Exploded View Diagram…………………………………………65

This manual is the latest at the time of printing, and does not
include the modifi ca tio n w hich ma y b e made after the pri nti ng, by
the consta nt improvement of product.

CAUTION:

Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.

CAUTION: TO REDUCE THE RISK OF

CAUTION

RISK RISK OF OF ELECTRIELECTRICC

SHOCK SHOCK DO DO NOT NOT OPEN.OPEN.

The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the product s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.

The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

ELECTRICAL SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

dangerous

WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

2

IMPORTANT SAFETY INSTRUCTIONS

CAUTION:

Read all of these instructions. Save these instructions for later use . Follow all Warnings and
Instructions marked on the audio equipment.

1. Read Instructions- All the safety and operating instructions should be read before the product is operated.

2. Retain Instructions- The safety and operating instructions should be retained for future reference.

3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.

4. Follow Instructions- All operating and use instructions should be followed.

FOR YOUR PERSONAL SAFETY

1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.

2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.

3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.

4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.

5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.

6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.

7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.

8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.

9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.

10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance. Use only with a car t or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.

10.2. An appliance and car t combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.

3

PROTECTION AND LOCATION OF YOUR SET

11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a

wet basement, or near a swimming pool, etc.
Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.

12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.

13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.

14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.

Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.

a built-in

PROTECTION AND LOCATION OF YOUR SET

15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some

protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONALELECTRICAL CODE

ANTENNA
LEAD- INWIRE

GROUND CLAMP

ELECTRIC SERVICE

EQUIPMENT

NEC-NATIONALELECTRICAL CODE

ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)

GROUNDING
CONDUCTORS
(NECSECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PARTH)

15.2. Note to CATV system installer : (Only for the television set with CATV reception)

This reminder is provided to call the CATV system attention to Article 820-40 of the NEC that provides

installer s
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.

16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.

4

OPERATION OF YOUR SET

18.

This television set should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.

19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.

20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.

off

IF THE SET DOES NOT OPERATE PROPERLY

21. If you are unable to restore normal operation by following the detailed procedure in your operating instructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.

22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.

23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.

FOR SERVICE AND MODIFICATION

24. Do not use attachments not recommended by the television set manufacturer as they may cause hazards.

25. When replacement parts are required, be sure the service technician has used replacement parts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.

26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.

5

SCART SOCKET(AV)

S SCART SOCKET(FULL)

SPECIFICATION SCART RCA

VIDEO INPUT 75Ω S

1V

1V

P-P

P-P

AUDIO INPUT 10kΩ (R+L)

VIDEO OUTPUT 75Ω

AUDIO OUTPUT 1kΩ (R+L)

RGB INTPUT 75Ω

AUDIO LINE OUTPUT 1kΩ

0.5V

1V

0.5V

0.7V

1V

0.5V

rmS

1V

P-P

0.5V

rmS

P-P

P-P

F： OTHERS INFORMATION

1. FLYBACK ： 37-BS2901-58BOX

2. TUNER ： 07-389VI5-NX4

3. SAW FILTER ： 45-SAWK33-50K

4. POWER CORD ：

P-P

rmS

rmS

5. FUSE ：

6. COLOUR TEMP ：

7. MAGNETIC FIELD ：

8. IC EEPROM ： 13-00M24C-08P

9. IR RECEIVER ： 11-IRR001-1X0

10. CIRCUIT DIAGRAM ： 01-29604T-MA3

11. MAIN BOARD ： 40-2916MT-MAH

12

Parent Item No. Item No. Description Quantity Designator Remarks

03-29604T-AA3 08-02918T-NIY ASS'Y - NICAM BD 1

08-02918T-NIY 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q1001

08-02918T-NIY 13-P3410G-8BP IC MSP 3410G B8 1 IC1001

08-02918T-NIY 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R1011

08-02918T-NIY 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R1014

08-02918T-NIY 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R1017

08-02918T-NIY 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R1018

08-02918T-NIY 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R1022

08-02918T-NIY 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R1023

08-02918T-NIY 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R1002

08-02918T-NIY 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R1003

08-02918T-NIY 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R1001

08-02918T-NIY 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R1019

08-02918T-NIY 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R1020

08-02918T-NIY 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R1015

08-02918T-NIY 26-ABC152-KBX CAP. CER 1500 PF 50V +/-10% B 1 C1017

08-02918T-NIY 26-ABC272-KBX CAP. CER 2700 PF 50V +/-10% B 1 C1006

08-02918T-NIY 26-ABC272-KBX CAP. CER 2700 PF 50V +/-10% B 1 C1007

08-02918T-NIY 26-ABC339-CZX CAP. CER 3.3 PF 50V +/-0.25 SL 1 C1026

08-02918T-NIY 26-ABC339-CZX CAP. CER 3.3 PF 50V +/-0.25 SL 1 C1027

08-02918T-NIY 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C1008

08-02918T-NIY 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C1009

08-02918T-NIY 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C1010

08-02918T-NIY 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C1011

08-02918T-NIY 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1002

08-02918T-NIY 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C1004

08-02918T-NIY 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C1012

08-02918T-NIY 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C1019

08-02918T-NIY 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C1021

08-02918T-NIY 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C1023

13

Parent Item No. Item No. Description Quantity Designator Remarks

08-02918T-NIY 26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH 1 C1018

08-02918T-NIY 26-EBP560-JCX CAP. CER 56PF 50V +/-5% 1 C1025

08-02918T-NIY 26-EBP560-JCX CAP. CER 56PF 50V +/-5% 1 C1024

08-02918T-NIY 26-EBP560-JCX CAP. CER 56PF 50V +/-5% 1 C1028

08-02918T-NIY 27-MBC334-J0X CAP. M.P.E 0.33UF 63V +/-5% 1 C1029

08-02918T-NIY 27-MBC334-J0X CAP. M.P.E 0.33UF 63V +/-5% 1 C1030

08-02918T-NIY 27-PBC102-J0X CAP. P.E 0.001UF 63V +/-5% 1 C1031

08-02918T-NIY 34-R100J2-0EX COIL PL - 10 UH +/-5% 1 L1001

08-02918T-NIY 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J1011

08-02918T-NIY 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J1003

08-02918T-NIY 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J1014

08-02918T-NIY 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J1001

08-02918T-NIY 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J1002

08-02918T-NIY 41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J1009

08-02918T-NIY 41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J1012

08-02918T-NIY 41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J1013

08-02918T-NIY 41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J1010

08-02918T-NIY 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J1004

08-02918T-NIY 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J1005

08-02918T-NIY 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J1006

08-02918T-NIY 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J1007

08-02918T-NIY 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J1008

08-02918T-NIY 45-OSC18M-4Y0 CRYSTAL 18.432M 1 X1001

08-02918T-NIY 46-33079W-02X PIN BASE *2 TJC3-2A 1 P1003 FOR P2 & P3

08-02918T-NIY 46-21550W-12X HEADER *12 TS12B-SQ-1 L=10MM 1 P1001 FOR M.BD P1200

08-02918T-NIY 67-257870-1T0 BRACKET IF BD 1

08-02918T-NIY 67-257870-2T0 BRACKET IF BD 1

08-02918T-NIY 40-2918NT-NIB P.C.B. NICAM BD 1

08-02918T-NIY 18-CB0224-JNX RES. C.F. 220k OHM 1/6W +/-5% 1 R1006

08-02918T-NIY 18-CB0224-JNX RES. C.F. 220k OHM 1/6W +/-5% 1 R1008

14

Parent Item No. Item No. Description Quantity Designator Remarks

08-02918T-NIY 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q1002

08-02918T-NIY 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q1003

08-02918T-NIY 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J1015

08-02918T-NIY 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1003

08-02918T-NIY 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1014

08-02918T-NIY 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1015

08-02918T-NIY 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1016

08-02918T-NIY 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1022

08-02918T-NIY 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1033

08-02918T-NIY 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1034

08-02918T-NIY 25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20% 1 C1032

08-02918T-NIY 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C1001

08-02918T-NIY 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C1013

08-02918T-NIY 25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C1005

08-02918T-NIY 25-BFB339-M1X CAP. ELEC 3.3 UF 50V +/-20% 1 C1020

03-29604T-AA3 08-02960T-AVY ASS'Y - SIDE AV BD 1

08-02960T-AVY 40-2960MT-SIA P.C.B. SIDE AV BD 1

08-02960T-AVY 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J001A

08-02960T-AVY 46-30790H-06X HS 6P24 400 TJC3-6Y/SCN-6Y 1 P003A FOR M.BD P003

08-02960T-AVY 47-RCA041-XX0 JACK RCA 3PH H=8MM YL WH RD/SW 1 P941A

08-02960T-AVY 63-B30080-BT4 S/T SCREW B 3 X 8 BT 2 MTG SIDE AV BD & F.CAB

03-29604T-AA3 08-02960T-FB3 ASS'Y - FRONT CTL & SW. BD 1

08-02960T-FB3 11-IRR001-1X0 IR RECEIVER MODULE HS0038A2 1 IR1001

08-02960T-FB3 14-LED05R-XX1 LED RED FB205 1 D1001

08-02960T-FB3 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R033A

08-02960T-FB3 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R023A

08-02960T-FB3 18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R027A

08-02960T-FB3 18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R024A

08-02960T-FB3 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R025A

08-02960T-FB3 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R070A

15

Parent Item No. Item No. Description Quantity Designator Remarks

08-02960T-FB3 18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R033B

08-02960T-FB3 18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% 1 R022A

08-02960T-FB3 18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% 1 R026A

08-02960T-FB3 40-2960MT-SWB P.C.B. SWITCH BD 1

08-02960T-FB3 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J03A

08-02960T-FB3 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J01

08-02960T-FB3 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J02

08-02960T-FB3 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J04

08-02960T-FB3 46-28559W-02X PIN BASE *2 TJC1-2A 1 P801 FOR POWER CORD

08-02960T-FB3 46-28559W-02X PIN BASE *2 TJC1-2A 1 S802

08-02960T-FB3 46-30407H-05X HS UL2468#24 5C/TS 180 TJC3-5Y 1 P001B FOR M. BD P001

08-02960T-FB3 46-35049H-02X HS 2P 1617#22 350 TJC1-2Y/TJC1-2Y 1 FOR F.CTL BD(S802) & PWR PARTS

08-02960T-FB3 48-256460-0C0 SWITCH POWER TV8(PCB MOUNTING) 1 SW801

08-02960T-FB3 48-TAC010-XX0 SWITCH TACT TSVC-2 (L=8.5 MM) 1 S003A

08-02960T-FB3 48-TAC010-XX0 SWITCH TACT TSVC-2 (L=8.5 MM) 1 S004A

08-02960T-FB3 48-TAC010-XX0 SWITCH TACT TSVC-2 (L=8.5 MM) 1 S005A

08-02960T-FB3 48-TAC010-XX0 SWITCH TACT TSVC-2 (L=8.5 MM) 1 S006A

08-02960T-FB3 48-TAC010-XX0 SWITCH TACT TSVC-2 (L=8.5 MM) 1 S001A

08-02960T-FB3 48-TAC010-XX0 SWITCH TACT TSVC-2 (L=8.5 MM) 1 S002A

08-02960T-FB3 51-JC0243-0CH01 POWER CORD SAA PLUG W/HOUSING 1

08-02960T-FB3 62-310430-0HA LED HOLDER (COMMON) 1

08-02960T-FB3 63-B30100-BT4 S/T SCREW B 3 X 10 BT 2 MTG SW. BD & M.BD BKT

08-02960T-FB3 63-W30100-AB4 S/T SCREW W 3 X 10 AB 3 MTG F. CTL BD & M.BD BKT

08-02960T-FB3 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C070A

03-29604T-AA3 08-02988T-CR2 ASS'Y - CRT BD 1

08-02988T-CR2 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D501

08-02988T-CR2 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D502

08-02988T-CR2 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 L501

08-02988T-CR2 11-A562TM-0BX TRANSISTOR 2SA562TM-0 1 Q507

08-02988T-CR2 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q502

16

Parent Item No. Item No. Description Quantity Designator Remarks

08-02988T-CR2 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q504

08-02988T-CR2 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q506

08-02988T-CR2 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R515

08-02988T-CR2 18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R514

08-02988T-CR2 18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R501

08-02988T-CR2 18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R505

08-02988T-CR2 18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R510

08-02988T-CR2 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R502

08-02988T-CR2 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R506

08-02988T-CR2 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R509

08-02988T-CR2 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R511

08-02988T-CR2 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R522

08-02988T-CR2 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R503

08-02988T-CR2 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R508

08-02988T-CR2 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R513

08-02988T-CR2 18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R519

08-02988T-CR2 18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R520

08-02988T-CR2 18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R521

08-02988T-CR2 18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R516

08-02988T-CR2 18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R517

08-02988T-CR2 18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R518

08-02988T-CR2 25-BLA100-M1X CAP. ELEC 10 UF 250V +/-20% 1 C504

08-02988T-CR2 26-AMK182-KRX CAP. CER 1800PF 2KV +/-10% R 1 C505

08-02988T-CR2 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C508

08-02988T-CR2 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C509

08-02988T-CR2 26-EBP391-JCX CAP. CER. 390PF 50V +/-5% CH 1 C501

08-02988T-CR2 26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH 1 C503

08-02988T-CR2 26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH 1 C502

08-02988T-CR2 34-R220K2-1BX COIL CHOKE 22 UH +/-10% 1 L502

08-02988T-CR2 35-237250-00X FERR. BEAD HF70 2 FOR C508 (L505 & L506)

17

Parent Item No. Item No. Description Quantity Designator Remarks

08-02988T-CR2 40-2980UA-CRA P.C.B. CRT BD 1

08-02988T-CR2 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 L504

08-02988T-CR2 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 L503

08-02988T-CR2 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R504

08-02988T-CR2 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R507

08-02988T-CR2 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R512

08-02988T-CR2 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J503

08-02988T-CR2 46-10967W-01X PIN BASE *1 TJC1-1A 1 P501 FOR CRT GROUNDING HOUS.

08-02988T-CR2 46-30615H-04X HS 4P24 460 F/W TJC3-4Y/SCN-4 1 P502 FOR M.BD P421

08-02988T-CR2 46-37030H-05X HS 5P 2468#24 450 TJC3-5Y/SCN 1 P503 FOR M.BD P201

08-02988T-CR2 47-316380-007 CRT SOCKET GZS10-301H 1 S501

08-02988T-CR2 11-SC4544-0AX TRANSISTOR 2SC4544 1 Q501

08-02988T-CR2 11-SC4544-0AX TRANSISTOR 2SC4544 1 Q503

08-02988T-CR2 11-SC4544-0AX TRANSISTOR 2SC4544 1 Q505

08-02988T-CR2 25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% 1 C506

03-29604T-AA3 08-02988T-DFY ASS'Y - DYNAMIC FOCUS 1

08-02988T-DFY 18-FG0120-JHX RES. M.O. 12 OHM 2W +/-5% 1 R1501

08-02988T-DFY 18-FG0120-JHX RES. M.O. 12 OHM 2W +/-5% 1 R1502

08-02988T-DFY 27-AGQ224-J0X CAP. M.PP 0.22 UF 250V +/-5% 1 C1504

08-02988T-DFY 27-AGQ824-J0X CAP. M.PP 0.82 UF 250V +/-5% 1 C1506

08-02988T-DFY 36-DFC001-XX0 FOCALIZING TRANS. 1 T1501

08-02988T-DFY 40-2980UA-DPC P.C.B. DPC BD 1

08-02988T-DFY 46-20598W-04X PIN BASE *4 TJC1-4A 1 P1501 FOR M.BD A1'&A2&A5&A6

08-02988T-DFY 64-B30080-104 M/C SCREW B 3 X 8 2 MTG D.F BD & IC301(H.SINK)

08-02988T-DFY 65-Z30050-23M NUT M 3 2

03-29604T-AA3 08-02988T-PW1 ASS'Y - POWER PARTS "AUST" 1

08-02988T-PW1 10-0RU4YX-F0X DIODE RU4YX (FAST RECOVERY) 1 D830

08-02988T-PW1 10-0TEU1Z-FBX DIODE TEU1Z (FAST RECOVERY) 1 D804

08-02988T-PW1 10-0TEU1Z-FBX DIODE TEU1Z (FAST RECOVERY) 1 D805

08-02988T-PW1 10-0TEU1Z-FBX DIODE TEU1Z (FAST RECOVERY) 1 D806

18

Parent Item No. Item No. Description Quantity Designator Remarks

08-02988T-PW1 10-1N4004-EBX DIODE IN4004 (RECTIFIER) 1 D843

08-02988T-PW1 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D842

08-02988T-PW1 10-T3SB60-H7X DIODE ZENER T3SB60 4.0A 600V 1 DB801

08-02988T-PW1 11-0BF422-0BX TRANSISTOR BF422 (NPN) 1 Q831

08-02988T-PW1 11-SB649A-0AX TRANSISTOR 2SB649A 1 Q830

08-02988T-PW1 11-SC4793-0AX STANSISTOR 2SC4793 1 Q801

08-02988T-PW1 13-00SE14-0NS IC SE140N 1 IC831

08-02988T-PW1 13-SFH615-A3P PHOTO COUPLER SFH615A3C 1 IC802

08-02988T-PW1 13-STRF66-56P IC STR-F6656 1 IC801

08-02988T-PW1 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R833

08-02988T-PW1 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R840

08-02988T-PW1 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R838

08-02988T-PW1 18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R841

08-02988T-PW1 18-CD0102-JNX RES. C.F. 1k OHM 1/4W +/-5% 1 R805

08-02988T-PW1 18-CD0102-JNX RES. C.F. 1k OHM 1/4W +/-5% 1 R808

08-02988T-PW1 18-CD0272-JNX RES. C.F. 2.7K OHM 1/4W +/-5% 1 R813

08-02988T-PW1 18-CD0470-JNX RES. C.F. 47 OHM 1/4W +/-5% 1 R809

08-02988T-PW1 18-CD0479-JNX RES. C.F. 4.7 OHM 1/4W +/-5% 1 R811

08-02988T-PW1 18-CD0560-JNX RES. C.F. 56 OHM 1/4W +/-5% 1 R837

08-02988T-PW1 18-CD0829-JNX RES. C.F. 8.2 OHM 1/4W +/-5% 1 R842

08-02988T-PW1 18-CE0105-JNX RES. C.F. 1M OHM 1/2W +/-5% 1 R806

08-02988T-PW1 18-CE0105-JNX RES. C.F. 1M OHM 1/2W +/-5% 1 R806A

08-02988T-PW1 18-CE0563-JNX RES. C.F. 56k OHM 1/2W +/-5% 1 R803

08-02988T-PW1 18-CE0563-JNX RES. C.F. 56k OHM 1/2W +/-5% 1 R804

08-02988T-PW1 18-FG0223-JHX RES. M.O. 22K OHM 2W +/-5% 1 R836

08-02988T-PW1 18-FG0333-JHX RES. M.O. 33K OHM 2W +/-5% 1 R810

08-02988T-PW1 18-FG0333-JHX RES. M.O. 33K OHM 2W +/-5% 1 R839

08-02988T-PW1 18-GG0158-JHX RES WIRE ROUND 0.15 OHM 2W 5% 1 R807

08-02988T-PW1 18-GG0228-JHX RES WIRE ROUND 0.22 OHM 2W 5% 1 R830

08-02988T-PW1 22-NTC479-XX0 NTC 4.7 OHM +/-18% NTC4.7D2-14 1 R802

19

Parent Item No. Item No. Description Quantity Designator Remarks

08-02988T-PW1 22-PTC140-XX0 POSISTOR 14 OHM 1 RT801

08-02988T-PW1 25-BKA100-M1X CAP. ELEC 10 UF 200V +/-20% 1 C808

08-02988T-PW1 25-BKA100-M1X CAP. ELEC 10 UF 200V +/-20% 1 C838

08-02988T-PW1 25-BKJ221-M1X CAP. ELEC 220 UF 200V +/-20% 1 C835

08-02988T-PW1 25-BMJ221-M1X CAP. ELEC 220 UF 400V +/-20% 1 C806

08-02988T-PW1 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C830

08-02988T-PW1 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C833

08-02988T-PW1 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C836

08-02988T-PW1 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C841

08-02988T-PW1 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C844

08-02988T-PW1 26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B 1 C805

08-02988T-PW1 26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B 1 C834

08-02988T-PW1 26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B 1 C837

08-02988T-PW1 26-AKK222-KRX CAP. CER 2200 PF 1KV +/-10% R 1 C814

08-02988T-PW1 26-AMK221-JZX CAP. CER 220pF 2KV +/-5% SL 1 FOR P2 - P3 OF IC801

08-02988T-PW1 26-AMK221-JZX CAP. CER 220pF 2KV +/-5% SL 1 C807

08-02988T-PW1 26-APK222-ME4 CAP. CER 2200PF 400VAC+/-20% E 1 C839

08-02988T-PW1 26-APK471-KB4 CAP. CER 470 pF 400VAC +/-10% 1 C812

08-02988T-PW1 26-APK471-KB4 CAP. CER 470 pF 400VAC +/-10% 1 C813

08-02988T-PW1 26-AQK472-ZFX CAP. CER 4700PF 250VAC+80-20%F 1 C803

08-02988T-PW1 26-AQK472-ZFX CAP. CER 4700PF 250VAC+80-20%F 1 C804

08-02988T-PW1 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C811

08-02988T-PW1 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C815

08-02988T-PW1 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C847

08-02988T-PW1 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C848

08-02988T-PW1 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C854

08-02988T-PW1 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C856

08-02988T-PW1 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C831

08-02988T-PW1 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C842

08-02988T-PW1 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C845

20

Parent Item No. Item No. Description Quantity Designator Remarks

08-02988T-PW1 26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C810

08-02988T-PW1 27-MHM104-K0X CAP. METAL P.E. 0.1UF 400V 10% 1 C802A

08-02988T-PW1 34-A608K6-1BX COIL CHOKE 0.6 UH +/-10% 1 L801

08-02988T-PW1 34-R220K2-1BX COIL CHOKE 22 UH +/-10% 1 L838

08-02988T-PW1 35-237250-00X FERR. BEAD HF70 2 FOR D804

08-02988T-PW1 35-237250-00X FERR. BEAD HF70 2 FOR D831

08-02988T-PW1 35-237250-00X FERR. BEAD HF70 2 FOR D832

08-02988T-PW1 35-237250-00X FERR. BEAD HF70 2 FOR D833

08-02988T-PW1 35-237250-00X FERR. BEAD HF70 2 FOR D834

08-02988T-PW1 35-237250-00X FERR. BEAD HF70 2 FOR D830

08-02988T-PW1 36-LIF002-XX0 LINE FILTER 20mH 1 T803

08-02988T-PW1 36-LIF005-XX0 LINE FILTER 1 T801

08-02988T-PW1 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J802

08-02988T-PW1 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J804

08-02988T-PW1 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J805

08-02988T-PW1 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J806

08-02988T-PW1 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J807

08-02988T-PW1 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J808

08-02988T-PW1 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J451

08-02988T-PW1 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J471

08-02988T-PW1 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J371

08-02988T-PW1 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J654

08-02988T-PW1 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J655

08-02988T-PW1 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J361

08-02988T-PW1 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J492

08-02988T-PW1 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 R831

08-02988T-PW1 41-WJ0145-B00 WIRE BARE JUMPER 14.5MM 1 J491

08-02988T-PW1 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 R812

08-02988T-PW1 41-WJ0155-B00 WIRE BARE JUMPER 15.5MM 1 J561

08-02988T-PW1 41-WJ0155-B00 WIRE BARE JUMPER 15.5MM 1 J562

21

Parent Item No. Item No. Description Quantity Designator Remarks

08-02988T-PW1 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J281

08-02988T-PW1 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J271

08-02988T-PW1 41-WJ0180-B00 WIRE BARE JUMPER 18MM 1 J353

08-02988T-PW1 41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J354

08-02988T-PW1 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J381

08-02988T-PW1 46-10962W-02X PIN BASE *2 TJC2-2A 1 P801 FOR DEGAUSSING COIL

08-02988T-PW1 46-28559W-02X PIN BASE *2 TJC1-2A 1 P802A FOR F.CTL BD

08-02988T-PW1 64-B30120-104 M/C SCREW B 3 X 12 1 FOR IC 801

08-02988T-PW1 64-P30080-104 M/C SCREW P 3 X 8 1 FOR IC841

08-02988T-PW1 64-P30080-104 M/C SCREW P 3 X 8 1 FOR IC851

08-02988T-PW1 64-P30080-104 M/C SCREW P 3 X 8 2 FOR IC 801

08-02988T-PW1 65-Z30050-23M NUT M 3 1 FOR IC801

08-02988T-PW1 66-20516X-0B0 FUSE HOLDER 2 FOR F801

08-02988T-PW1 66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 4 FOR T802

08-02988T-PW1 66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR DB801

08-02988T-PW1 67-H10918-4M2 HEAT SINK 2 FOR IC841 & IC851

08-02988T-PW1 67-H29550-8A0 HEAT SINK 1 FOR IC801

08-02988T-PW1 67-H34692-0A0 HEAT SINK 1 FOR IC801

08-02988T-PW1 10-79C10V-DBX DIODE ZENER 10V 1/2W 5% 1 D840

08-02988T-PW1 10-79C16V-DBX DIODE ZENER 16V 1/2W 5% 1 D807

08-02988T-PW1 10-79C2V4-DBX DIODE ZENER 2V4 1/2W 5% 1 D841

08-02988T-PW1 10-79C3V9-DBX DIODE ZENER 3V9 1/2W 5% 1 D839

08-02988T-PW1 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D832

08-02988T-PW1 36-TRF001-AX2 TRANSFORMER CONV. BCK-4901-77 1 T802

08-02988T-PW1 18-KE0105-JN3 RES. H.VOLT. CC 1M OHM 1/2W +/-5% 1 R801

08-02988T-PW1 18-KF0825-JH3 RES. H.VOLT.CC 8.2M OHM 1W +/-5% 1 R835

08-02988T-PW1 27-AQT224-MVH CAP. M.PP 0.22 UF 250VAC 20% 1 C801

08-02988T-PW1 27-AQT224-MVH CAP. M.PP 0.22 UF 250VAC 20% 1 C802

08-02988T-PW1 66-343740-0B0 HOLLOW RIVET (2.3mmx4.0mmx3.5mm) 2 FOR D830

08-02988T-PW1 25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20% 1 C846

22

Parent Item No. Item No. Description Quantity Designator Remarks

08-02988T-PW1 25-BCB331-M1X CAP. ELEC 330 UF 16V +/-20% 1 C843

08-02988T-PW1 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C849

08-02988T-PW1 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C855

08-02988T-PW1 25-BDB470-M1X CAP. ELEC 47 UF 25V +/-20% 1 C809

08-02988T-PW1 25-BEA102-M1X CAP. ELEC 1000 UF 35V +/-20% 1 C832

08-02988T-PW1 50-03150D-1US7 FUSE 250V/3.15A 1 F801

08-02988T-PW1 10-0EU2YX-FBX DIODE EU2YX (FAST RECOVERY) 1 D833

08-02988T-PW1 10-0EU2YX-FBX DIODE EU2YX (FAST RECOVERY) 1 D834

08-02988T-PW1 10-0RU3AM-F0X DIODE RU3AM (FAST RECOVERY) 1 D831

08-02988T-PW1 10-HER108-FBX DIODE HER108 1 D803

08-02988T-PW1 13-UA7805-C0S IC UA7805C 1 IC841

08-02988T-PW1 13-L7809C-VAP IC L7809CV 1 IC851

03-29604T-AA3 08-02988T-VMY ASS'Y - VM BD 1

08-02988T-VMY 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D556

08-02988T-VMY 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D557

08-02988T-VMY 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D554

08-02988T-VMY 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D555

08-02988T-VMY 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D552

08-02988T-VMY 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D553

08-02988T-VMY 11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q551

08-02988T-VMY 11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q556

08-02988T-VMY 11-SA1837-0AX TRANSISTOR 2SA1837 1 Q560

08-02988T-VMY 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q553

08-02988T-VMY 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q554

08-02988T-VMY 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q555

08-02988T-VMY 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q557

08-02988T-VMY 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q558

08-02988T-VMY 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q559

08-02988T-VMY 11-SC4793-0AX STANSISTOR 2SC4793 1 Q561

08-02988T-VMY 11-SK2541-0BX TRANSISTOR 2SK2541 (N-CHANNEL) 1 Q552

23

Parent Item No. Item No. Description Quantity Designator Remarks

08-02988T-VMY 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R552

08-02988T-VMY 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R551

08-02988T-VMY 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R564

08-02988T-VMY 18-CB0122-JNX RES. C.F. 1.2k OHM 1/6W +/-5% 1 R585

08-02988T-VMY 18-CB0122-JNX RES. C.F. 1.2k OHM 1/6W +/-5% 1 R590

08-02988T-VMY 18-CB0122-JNX RES. C.F. 1.2k OHM 1/6W +/-5% 1 R582

08-02988T-VMY 18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R563

08-02988T-VMY 18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R589

08-02988T-VMY 18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R578

08-02988T-VMY 18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R574

08-02988T-VMY 18-CB0124-JNX RES. C.F. 120K OHM 1/6W +/-5% 1 R577

08-02988T-VMY 18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R568

08-02988T-VMY 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R586

08-02988T-VMY 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R591

08-02988T-VMY 18-CB0181-JNX RES. C.F. 180 OHM 1/6W +/-5% 1 R556

08-02988T-VMY 18-CB0181-JNX RES. C.F. 180 OHM 1/6W +/-5% 1 R558

08-02988T-VMY 18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R554

08-02988T-VMY 18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R557

08-02988T-VMY 18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R555

08-02988T-VMY 18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R581

08-02988T-VMY 18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R575

08-02988T-VMY 18-CB0203-JNX RES. C.F. 20k OHM 1/6W +/-5% 1 R572

08-02988T-VMY 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R583

08-02988T-VMY 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R553

08-02988T-VMY 18-CB0271-JNX RES. C.F. 270 OHM 1/6W +/-5% 1 R562

08-02988T-VMY 18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R565

08-02988T-VMY 18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R576

08-02988T-VMY 18-CB0563-JNX RES. C.F. 56K OHM 1/6W +/-5% 1 R573

08-02988T-VMY 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R561

08-02988T-VMY 18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R566

24

Parent Item No. Item No. Description Quantity Designator Remarks

08-02988T-VMY 18-CB0683-JNX RES. C.F. 68K OHM 1/6W +/-5% 1 R587

08-02988T-VMY 18-CB0683-JNX RES. C.F. 68K OHM 1/6W +/-5% 1 R588

08-02988T-VMY 18-CB0821-JNX RES. C.F. 820 OHM 1/6W +/-5% 1 R567

08-02988T-VMY 18-CD0122-JNX RES. C.F. 1.2K OHM 1/4W +/-5% 1 R571

08-02988T-VMY 18-CD0279-JNX RES. C.F. 2.7 OHM 1/4W +/-5% 1 R593

08-02988T-VMY 18-CD0279-JNX RES. C.F. 2.7 OHM 1/4W +/-5% 1 R594

08-02988T-VMY 18-CE0470-JNX RES. C.F. 47 OHM 1/2W +/-5% 1 R592

08-02988T-VMY 18-CE0470-JNX RES. C.F. 47 OHM 1/2W +/-5% 1 R595

08-02988T-VMY 18-FE0121-JNX RES. M.O. 120 OHM 1/2W +/-5% 1 R584

08-02988T-VMY 18-FG0221-JHX RES. M.O. 220 OHM 2W +/-5% 1 R596

08-02988T-VMY 25-BJA330-M1X CAP. ELEC 33 UF 160V +/-20% 1 C568

08-02988T-VMY 26-AIC472-KBX CAP. CER 4700 PF 500V +/-10% B 1 C565

08-02988T-VMY 26-AIC472-KBX CAP. CER 4700 PF 500V +/-10% B 1 C566

08-02988T-VMY 26-AIC560-JZX CAP. CER 56 PF 500V +/-5% SL 1 C571

08-02988T-VMY 26-EBP680-JZX CAP. CER 68PF 50V +/-5% SL TUBE 1 C555

08-02988T-VMY 26-EBP680-JZX CAP. CER 68PF 50V +/-5% SL TUBE 1 C564

08-02988T-VMY 26-EBP680-JZX CAP. CER 68PF 50V +/-5% SL TUBE 1 C562

08-02988T-VMY 27-AGQ104-J0X CAP. M.PP 0.1 UF 250V +/-5% 1 C570

08-02988T-VMY 34-A608K6-1BX COIL CHOKE 0.6 UH +/-10% 1 L554

08-02988T-VMY 34-R101J2-0EX COIL PL - 100 UH +/-5% 1 L551

08-02988T-VMY 34-R101J2-0EX COIL PL - 100 UH +/-5% 1 L555

08-02988T-VMY 34-R390J2-0EX COIL PL - 39 UH +/-5% 1 L553

08-02988T-VMY 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J701

08-02988T-VMY 43-YBL25E-180 LUMINANCE DELAY LINE YBL25E18 1 T551

08-02988T-VMY 46-32274H-03X HS 3P24 380 TJC3-3Y/SCN-3Y 1 P504 FOR M.BD P401

08-02988T-VMY 46-33079W-03X PIN BASE *3 TJC3-3A 1 P506 FOR CRT VM

08-02988T-VMY 63-W26080-OB4 S/T SCREW W 2.6 X 8 OB 2 MTG VM BD TO CRT

08-02988T-VMY 64-B30080-104 M/C SCREW B 3 X 8 2 FOR Q561 & Q560

08-02988T-VMY 67-H34464-1A0 HEAT SINK (H=40MM) 2 FOR Q560 & Q561

08-02988T-VMY 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D558

25

Parent Item No. Item No. Description Quantity Designator Remarks

08-02988T-VMY 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D559

08-02988T-VMY 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C567

08-02988T-VMY 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C569

08-02988T-VMY 25-BDB100-M1X CAP. ELEC 10 UF 25V +/-20% 1 C551

08-02988T-VMY 25-BDB100-M1X CAP. ELEC 10 UF 25V +/-20% 1 C563

08-02988T-VMY 25-BDB100-M1X CAP. ELEC 10 UF 25V +/-20% 1 C558

08-02988T-VMY 25-BDB100-M1X CAP. ELEC 10 UF 25V +/-20% 1 C561

08-02988T-VMY 25-BDB101-M1X CAP. ELEC 100 UF 25V +/-20% 1 C557

08-02988T-VMY 25-BDB220-M1X CAP. ELEC 22 UF 25V +/-20% 1 C553

08-02988T-VMY 25-BDB221-M1X CAP. ELEC 220 UF 25V +/-20% 1 C552

08-02988T-VMY 25-BFB470-M1X CAP. ELEC 47 UF 50V +/-20% 1 C556

08-02988T-VMY 40-2980UA-VMC P.C.B. VM BD 1

08-02988T-VMY 34-A240K0-1IX COIL CHOKE 24 UH +/-10% 1 L552

08-02988T-VMY 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C559

08-02988T-VMY 46-30780H-04X HS 4P 2468#24 390 TJC3-4Y/SCN-4Y 1 P505 FOR M.BD P202

03-29604T-AA3 08-29604T-FCN ASS'Y - FRONT CABINET 1

08-29604T-FCN 02-GND029-XX0 ASS'Y-CRT GND WIRE & HOUS.(29) 1

08-29604T-FCN 25-DFB478-M1X CAP. ELEC 0.47 UF 50V +/-20%NP 1 C1

08-29604T-FCN 25-DFB478-M1X CAP. ELEC 0.47 UF 50V +/-20%NP 1 C2

08-29604T-FCN 36-DEG290-XX1 DEGAUSSING COIL 3100MM 1

08-29604T-FCN 42-G3508D-XX0 SPEAKER 8 OHM 5W 1 SP601A

08-29604T-FCN 42-G3508D-XX0 SPEAKER 8 OHM 5W 1 SP602A

08-29604T-FCN 44-29RFLS-OR3A CRT A68QDL082X012(B)(AUST) 1 CRT01

08-29604T-FCN 46-27264H-02X HS 2P24 700/5 F/W S11-02H 1 P601H FOR RED TO C1, WHITE TO SP601A"-"

08-29604T-FCN 46-35009H-02X HS 2P22 320/5 SM-2Y 1 FOR RED TO C1, WHITE TO SP601A"-",

08-29604T-FCN 46-35009H-02X HS 2P22 320/5 SM-2Y 1 FOR RED TO C2, WHITE TO SP602A"-"

08-29604T-FCN 46-35102H-03X HS 2P 2468#22 200/5 TJC3-3Y 1 FOR VM BD P506

08-29604T-FCN 46-35197H-02X HS 2P22 700/7 TJC3-2Y 1 P602H FOR RED TO C2, WHITE TO SP602A"-"

08-29604T-FCN 54-113970-0U0 PVC TUBE #5 L=ROLL 0.32 FOR P601H & P602H

08-29604T-FCN 54-205130-000 SPACER CRT MOUNTING T=3MM 2

26

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-FCN 54-205140-000 SPACER CRT MOUNTING T=2MM 4 MTG CRT TO F.CAB

08-29604T-FCN 54-314740-0X0 CRT FIBRE SHEET (22mmX22mmX0.8mm) 10 MTG CRT TO F.CAB

08-29604T-FCN 55-2960FC-1AN FRONT CABINET 1

08-29604T-FCN 56-2960FB-0HA PUSH BUTTON 1

08-29604T-FCN 56-2960LE-0HC LNES 1

08-29604T-FCN 56-2960PK-0HA POWER KNOB 1

08-29604T-FCN 59-130460-00X RUBBER PAD (25mmX7mm) 2 STICK ON F.CAB(FOOTING)

08-29604T-FCN 62-10654X-00F UNI-TIE (2.5mmX95mm) 13

08-29604T-FCN 62-216340-0UA HOLDER POWER CORD 1

08-29604T-FCN 62-216780-00D PLATIC TAPE 12" 1

08-29604T-FCN 62-262660-0HA POWER SW. ADAPTER 1

08-29604T-FCN 63-B30080-BT4 S/T SCREW B 3 X 8 BT 4 MTG HI - SPK & FRONT CAB.

08-29604T-FCN 63-B30100-BT4 S/T SCREW B 3 X 10 BT 1 MTG LEN & FRONT CAB.

08-29604T-FCN 63-B30100-BT4 S/T SCREW B 3 X 10 BT 3 MTG PUSH BUTTON & FRONT CAB.

08-29604T-FCN 63-H60300-BT4 S/T SCREW H 6 X 30 BT 4 MTG CRT & FRONT CAB.

08-29604T-FCN 65-A75200-20E WASHER 7.5mmX20mmX2mm MTG CRT 4 FOR CRT & FRONT CAB.

08-29604T-FCN 67-216790-0E0 SPRING CRT 6MMX50MMX0.6MM 2

08-29604T-FCN 67-249700-0E0 SPRING PWR KNOB 1

03-29604T-AA3 08-29604T-MAN ASS'Y - MAIN BD 1

08-29604T-MAN 07-389VI5-NX4 TUNER UV1355-BK2(BG/HB/IEC/5V 1 TU101

08-29604T-MAN 10-0BY228-F0X DIODE BY228 1 D411

08-29604T-MAN 10-1N4001-EBX DIODE 1N4001 (RECTIFIER) 1 D301

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D041

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D042

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D043

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D044

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D211

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D212

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D213

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D221

27

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D223

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D280

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D632

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D711

08-29604T-MAN 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D721

08-29604T-MAN 10-79C12V-DBX DIODE ZENER 12V 1/2W 5% 1 D731

08-29604T-MAN 10-79C12V-DBX DIODE ZENER 12V 1/2W 5% 1 D732

08-29604T-MAN 10-79C4V7-DBX DIODE ZENER 4V7 1/2W 5% 1 D222

08-29604T-MAN 10-79C5V1-DBX DIODE ZENER 5V1 1/2W 5% 1 D061

08-29604T-MAN 10-79C5V1-DBX DIODE ZENER 5V1 1/2W 5% 1 D101

08-29604T-MAN 10-79C8V2-DBX DIODE ZENER 8V2 1/2W 5% 1 D471

08-29604T-MAN 10-79C8V2-DBX DIODE ZENER 8V2 1/2W 5% 1 D240

08-29604T-MAN 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D412

08-29604T-MAN 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D421

08-29604T-MAN 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D431

08-29604T-MAN 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D441

08-29604T-MAN 11-0BC337-0BX TRANSISTOR (NPN) BC337-40 1 Q062

08-29604T-MAN 11-2N3904-0BX TRANSISTOR 2N3904 (NPN) 1 Q091

08-29604T-MAN 11-DD2553-0AX TRANSISTOR (HORIZ) 3DD2553 1 Q412

08-29604T-MAN 11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q061

08-29604T-MAN 11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q211

08-29604T-MAN 11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q633

08-29604T-MAN 11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q721

08-29604T-MAN 11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q934

08-29604T-MAN 11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q242

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q001

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q002

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q031

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q051

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q251

28

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q252

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q261

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q451

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q631

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q711

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q911

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q912

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q913

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q921

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q922

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q923

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q931

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q932

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q933

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q963

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q964

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q971

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q981

08-29604T-MAN 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q991

08-29604T-MAN 11-SC3779-DBX TRANSISTOR 2SC3779D (RF AMPL) 1 Q121

08-29604T-MAN 11-SC4544-0AX TRANSISTOR 2SC4544 1 Q401

08-29604T-MAN 11-SD1499-QAX TRANSISTOR 2SD1499Q (POWER) 1 Q722

08-29604T-MAN 11-SK2541-0BX TRANSISTOR 2SK2541 (N-CHANNEL) 1 Q052

08-29604T-MAN 13-000040-52P IC 4052 1 IC961

08-29604T-MAN 13-000040-52P IC 4052 1 IC962

08-29604T-MAN 13-00M24C-08P IC EEPROM 8K M24C08 1 IC002

08-29604T-MAN 13-0TA842-7KS IC TA8427K 1 IC301

08-29604T-MAN 13-0TDA26-16S IC TDA2616 (AUDIO O/P) 1 IC601

08-29604T-MAN 13-A18V01-TOP IC TCL-A18V01-TO 1 IC001

08-29604T-MAN 13-TB1240-ANP IC TB1240AN 1 IC201

29

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R003

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R006

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R007

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R008

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R015

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R016

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R038

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R065

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R073

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R075

08-29604T-MAN 18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R253

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R062

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R067

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R071

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R091

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R124

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R220

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R269

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R271

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R301

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R304

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R451

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R911

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R912

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R921

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R922

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R936

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R938

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R939

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R945

30

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R946

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R947

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R948

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R966

08-29604T-MAN 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R968

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R005

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R012A

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R017

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R029

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R031

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R040

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R051

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R054

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R055

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R061

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R101

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R102

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R225

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R237

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R633

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R716

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R722

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R757

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R960

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R961

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R962

08-29604T-MAN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R989

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R053

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R206

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R917

31

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R918

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R919

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R926

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R927

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R928

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R929

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R973

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R983

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R056

08-29604T-MAN 18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R205

08-29604T-MAN 18-CB0106-JNX RES. C.F. 10M OHM 1/6W +/-5% 1 R116

08-29604T-MAN 18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R244

08-29604T-MAN 18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R951

08-29604T-MAN 18-CB0124-JNX RES. C.F. 120K OHM 1/6W +/-5% 1 R287

08-29604T-MAN 18-CB0133-JNX RES. C.F. 13k OHM 1/6W +/-5% 1 R452

08-29604T-MAN 18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R127

08-29604T-MAN 18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R934

08-29604T-MAN 18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R935

08-29604T-MAN 18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R994

08-29604T-MAN 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R204

08-29604T-MAN 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R212

08-29604T-MAN 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R213

08-29604T-MAN 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R214

08-29604T-MAN 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R063

08-29604T-MAN 18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R057

08-29604T-MAN 18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R072

08-29604T-MAN 18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R112

08-29604T-MAN 18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R113

08-29604T-MAN 18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R288

08-29604T-MAN 18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R987

32

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R632A

08-29604T-MAN 18-CB0181-JNX RES. C.F. 180 OHM 1/6W +/-5% 1 R123

08-29604T-MAN 18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R715

08-29604T-MAN 18-CB0201-JNX RES. C.F. 200 OHM 1/6W +/-5% 1 R993

08-29604T-MAN 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R203

08-29604T-MAN 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R215

08-29604T-MAN 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R216

08-29604T-MAN 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R217

08-29604T-MAN 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R255

08-29604T-MAN 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R261

08-29604T-MAN 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R401

08-29604T-MAN 18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R012

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 D215

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 D631

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R041

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R042

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R043

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R044

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R242

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R713

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R914

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R924

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R972

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R982

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R988

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R991

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R953

08-29604T-MAN 18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5% 1 R954

08-29604T-MAN 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R092

08-29604T-MAN 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R631

33

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R915

08-29604T-MAN 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R916

08-29604T-MAN 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R920

08-29604T-MAN 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R925

08-29604T-MAN 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R952

08-29604T-MAN 18-CB0224-JNX RES. C.F. 220k OHM 1/6W +/-5% 1 R251

08-29604T-MAN 18-CB0271-JNX RES. C.F. 270 OHM 1/6W +/-5% 1 R711

08-29604T-MAN 18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R227

08-29604T-MAN 18-CB0302-JNX RES. C.F. 3K OHM 1/6W +/-5% 1 R601

08-29604T-MAN 18-CB0302-JNX RES. C.F. 3K OHM 1/6W +/-5% 1 R602

08-29604T-MAN 18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R222

08-29604T-MAN 18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R223

08-29604T-MAN 18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R229

08-29604T-MAN 18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R259

08-29604T-MAN 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R013

08-29604T-MAN 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R014

08-29604T-MAN 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R074

08-29604T-MAN 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R076

08-29604T-MAN 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R111

08-29604T-MAN 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R254

08-29604T-MAN 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R302

08-29604T-MAN 18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R472

08-29604T-MAN 18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R114

08-29604T-MAN 18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R208

08-29604T-MAN 18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R289

08-29604T-MAN 18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R714

08-29604T-MAN 18-CB0393-JNX RES. C.F. 39K OHM 1/6W +/-5% 1 R314

08-29604T-MAN 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R021

08-29604T-MAN 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R077

08-29604T-MAN 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R084

34

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R085

08-29604T-MAN 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R940

08-29604T-MAN 18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R125

08-29604T-MAN 18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R252

08-29604T-MAN 18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R931

08-29604T-MAN 18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R932

08-29604T-MAN 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R066

08-29604T-MAN 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R211

08-29604T-MAN 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R965

08-29604T-MAN 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R967

08-29604T-MAN 18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R052

08-29604T-MAN 18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R115

08-29604T-MAN 18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R262

08-29604T-MAN 18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R263

08-29604T-MAN 18-CB0473-JNX RES. C.F. 47K OHM 1/6W +/-5% 1 R284

08-29604T-MAN 18-CB0560-JNX RES. C.F. 56 OHM 1/6W +/-5% 1 R122

08-29604T-MAN 18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R228

08-29604T-MAN 18-CB0622-JNX RES. C.F. 6.2k OHM 1/6W +/-5% 1 R231

08-29604T-MAN 18-CB0750-JNX RES. C.F. 75 OHM 1/6W +/-5% 1 R933

08-29604T-MAN 18-CB0752-JNX RES. C.F. 7.5K OHM 1/6W +/-5% 1 R221

08-29604T-MAN 18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R913

08-29604T-MAN 18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R923

08-29604T-MAN 18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R971

08-29604T-MAN 18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R981

08-29604T-MAN 18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% 1 R286

08-29604T-MAN 18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% 1 R232

08-29604T-MAN 18-CD0100-JNX RES. C.F. 10 OHM 1/4W +/-5% 1 R064

08-29604T-MAN 18-CD0101-JNX RES. C.F. 100 OHM 1/4W +/-5% 1 R226

08-29604T-MAN 18-CD0182-JNX RES. C.F. 1.8K OHM 1/4W +/-5% 1 R313

08-29604T-MAN 18-CD0222-JNX RES. C.F. 2.2K OHM 1/4W +/-5% 1 R723

35

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 18-CD0272-JNX RES. C.F. 2.7K OHM 1/4W +/-5% 1 J691

08-29604T-MAN 18-CD0392-JNX RES. C.F. 3.9K OHM 1/4W +/-5% 1 R725

08-29604T-MAN 18-CD0392-JNX RES. C.F. 3.9K OHM 1/4W +/-5% 1 R312

08-29604T-MAN 18-CD0681-JNX RES. C.F. 680 OHM 1/4W +/-5% 1 R724

08-29604T-MAN 18-CD0829-JNX RES. C.F. 8.2 OHM 1/4W +/-5% 1 R607

08-29604T-MAN 18-CD0829-JNX RES. C.F. 8.2 OHM 1/4W +/-5% 1 R608

08-29604T-MAN 18-CE0121-JNX RES. C.F. 120 OHM 1/2W +/-5% 1 R731

08-29604T-MAN 18-CE0229-JNX RES. C.F. 2.2 OHM 1/2W +/-5% 1 R305

08-29604T-MAN 18-CE0470-JNX RES. C.F. 47 OHM 1/2W +/-5% 1 R103

08-29604T-MAN 18-EG0109-JHX RES. FUS. 1 OHM 2W +/-5% 1 R431

08-29604T-MAN 18-EG0689-JHX RES. FUSE 6.8 OHM 2W +/-5% 1 R461

08-29604T-MAN 18-FE0121-JNX RES. M.O. 120 OHM 1/2W +/-5% 1 R306

08-29604T-MAN 18-FE0472-JNX RES. M.O. 4.7K OHM 1/2W +/-5% 1 R471

08-29604T-MAN 18-FF0103-JGX RES. M.O. 10K OHM 1W +/-5% 1 R421

08-29604T-MAN 18-FF0221-JGX RES. M.O.F 220 OHM 1W +/-5% 1 R307

08-29604T-MAN 18-FF0242-JGX RES. M.O. 2.4K OHM 1W +/-5% 1 R402

08-29604T-MAN 18-FF0681-JGX RES. M.O. 680 OHM 1W +/-5% 1 R411

08-29604T-MAN 18-FG0100-JHX RES. M.O. 10 OHM 2W +/-5% 1 J211

08-29604T-MAN 18-FG0399-JHX RES. M.O. 3.9 OHM 2W +/-5% 1 R726

08-29604T-MAN 18-FG0479-JHX RES. M.O.F 4.7 OHM 2W +/-5% 1 R303

08-29604T-MAN 18-GF0109-JGX RES WIRE ROUND 1 OHM 1W +/-5% 1 R311

08-29604T-MAN 18-GG0109-JHX RES WIRE ROUND 1 OHM 2W +/-5% 1 R422

08-29604T-MAN 18-GM0302-KTX RES. CEMENT 3K OHM 7W +/-10% 1 R404

08-29604T-MAN 25-264610-M1X 1 C417

08-29604T-MAN 25-BKA100-M1X CAP. ELEC 10 UF 200V +/-20% 1 C421

08-29604T-MAN 25-BKG101-M1X CAP. ELEC 100 UF 200V +/-20% 1 C422

08-29604T-MAN 25-BLA100-M1X CAP. ELEC 10 UF 250V +/-20% 1 C442

08-29604T-MAN 25-GFB109-K1X CAP. ELEC 1UF 50V +/-10% 1 C223

08-29604T-MAN 26-ABC104-ZFX CAP. CER 0.1 UF 50V +80-20% F 1 FOR R038(R040) TO R036(GND)

08-29604T-MAN 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C431

36

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C441

08-29604T-MAN 26-AIC332-KBX CAP. CER 3300 PF 500V +/-10% B 1 C402

08-29604T-MAN 26-AIC391-KBX CAP. CER 390 PF 500V +/-10% B 1 C403

08-29604T-MAN 26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B 1 C401

08-29604T-MAN 26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C032

08-29604T-MAN 26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C071

08-29604T-MAN 26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C254

08-29604T-MAN 26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C255

08-29604T-MAN 26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C272

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C001

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C002

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C013

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C061

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C062

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C127

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C224

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C305

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C312

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C411

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C602

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C606

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C942

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C971

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C936

08-29604T-MAN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C937

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C075

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C083

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C111

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C121

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C125

37

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C126

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C203

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C205

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C215

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C226

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C229

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C256

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C273

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C275

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C732

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C935

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C961

08-29604T-MAN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C962

08-29604T-MAN 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C107

08-29604T-MAN 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C114

08-29604T-MAN 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C204

08-29604T-MAN 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C609

08-29604T-MAN 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C635

08-29604T-MAN 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C745

08-29604T-MAN 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C945

08-29604T-MAN 26-EBP120-JCX CAP. CER 12PF 50V +/-5% CH 1 C209

08-29604T-MAN 26-EBP150-JCX CAP. CER 15PF 50V +/-5% CH 1 C041

08-29604T-MAN 26-EBP150-JCX CAP. CER 15PF 50V +/-5% CH 1 C042

08-29604T-MAN 26-EBP150-JCX CAP. CER 15PF 50V +/-5% CH 1 C043

08-29604T-MAN 26-EBP150-JCX CAP. CER 15PF 50V +/-5% CH 1 C044

08-29604T-MAN 26-EBP220-JCX CAP. CER 22PF 50V +/-5% CH 1 C053

08-29604T-MAN 26-EBP220-JCX CAP. CER 22PF 50V +/-5% CH 1 C054

08-29604T-MAN 26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C011

08-29604T-MAN 26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C021

08-29604T-MAN 26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C092

38

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C112

08-29604T-MAN 26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C228A

08-29604T-MAN 26-EBP222-KBX CAP. CER 2200PF 50V +/-10% B 1 C452

08-29604T-MAN 26-EBP300-JZX CAP. CER 30PF 50V +/-5% SL 1 C055

08-29604T-MAN 26-EBP300-JZX CAP. CER 30PF 50V +/-5% SL 1 C056

08-29604T-MAN 26-EBP330-JZX CAP. CER 33PF 50V +/-5% SL TU 1 C128

08-29604T-MAN 26-EBP330-JZX CAP. CER 33PF 50V +/-5% SL TU 1 C953

08-29604T-MAN 26-EBP331-JCX CAP. CER 330PF 50V +/-5% CH 1 C004

08-29604T-MAN 26-EBP331-JCX CAP. CER 330PF 50V +/-5% CH 1 C063

08-29604T-MAN 26-EBP331-JCX CAP. CER 330PF 50V +/-5% CH 1 C084

08-29604T-MAN 26-EBP331-JCX CAP. CER 330PF 50V +/-5% CH 1 C085

08-29604T-MAN 26-EBP331-JCX CAP. CER 330PF 50V +/-5% CH 1 C091

08-29604T-MAN 26-EBP331-JCX CAP. CER 330PF 50V +/-5% CH 1 C301

08-29604T-MAN 26-EBP390-JCX CAP. CER 39PF 50V +/-5% CH 1 C051

08-29604T-MAN 26-EBP470-JZX CAP. CER 47PF 50V +/-5% SL 1 C072

08-29604T-MAN 26-EBP470-JZX CAP. CER 47PF 50V +/-5% SL 1 C073

08-29604T-MAN 26-EBP470-JZX CAP. CER 47PF 50V +/-5% SL 1 C261

08-29604T-MAN 26-EBP470-JZX CAP. CER 47PF 50V +/-5% SL 1 T141

08-29604T-MAN 27-AGR624-J0X CAP. M.PP 0.62UF 250V +/-5% 1 C418

08-29604T-MAN 27-ALQ272-J0X CAP. M.PP 0.0027UF 1.6KV +/-5% 1 C413

08-29604T-MAN 27-ALQ432-J0X CAP. M.PP 4300 PF 1.6KV +/-5% 1 C414

08-29604T-MAN 27-ALR822-J0X CAP. M.PP 8200 PF 1.6KV +/-5% 1 C415

08-29604T-MAN 27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C102

08-29604T-MAN 27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C211

08-29604T-MAN 27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C212

08-29604T-MAN 27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C213

08-29604T-MAN 27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C242

08-29604T-MAN 27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C252

08-29604T-MAN 27-MBC224-J0X CAP. M.P.E 0.22UF 63V +/-5% 1 C113

08-29604T-MAN 27-MBC224-J0X CAP. M.P.E 0.22UF 63V +/-5% 1 C307

39

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 27-MBC474-J0X CAP. M.P.E 0.47UF 63V +/-5% 1 C225

08-29604T-MAN 27-MBC474-J0X CAP. M.P.E 0.47UF 63V +/-5% 1 C243

08-29604T-MAN 27-MBC474-J0X CAP. M.P.E 0.47UF 63V +/-5% 1 C603

08-29604T-MAN 27-MBC474-J0X CAP. M.P.E 0.47UF 63V +/-5% 1 C604

08-29604T-MAN 27-MCC562-J0X CAP. M.P.E 5600PF 100V +/-5% 1 C471

08-29604T-MAN 27-PBC103-J0X CAP. P.E. 0.01UF 63V +/-5% 1 C052

08-29604T-MAN 27-PBC222-J0X CAP. P.E 0.0022UF 63V +/-5% 1 C207

08-29604T-MAN 27-PBC222-J0X CAP. P.E 0.0022UF 63V +/-5% 1 C221

08-29604T-MAN 27-PBC223-J0X CAP. P.E 0.022 UF 63V +/-5% 1 C611

08-29604T-MAN 27-PBC223-J0X CAP. P.E 0.022 UF 63V +/-5% 1 C612

08-29604T-MAN 27-PBC333-J0X CAP. P.E 0.033UF 63V +/-5% 1 C302

08-29604T-MAN 27-PBC393-J0X CAP. P.E 0.039UF 63V +/-5% 1 C308

08-29604T-MAN 27-PBC472-J0X CAP. P.E 0.0047UF 63V +/-5% 1 C244

08-29604T-MAN 27-PBC563-J0X CAP. P.E 0.056 UF 63V +/-5% 1 C304

08-29604T-MAN 27-RHQ223-J0X CAP. PP 0.022 UF 400V +/-5% 1 C416

08-29604T-MAN 27-RHQ563-J0X CAP. PP 0.056 UF 400V +/-5% 1 C451

08-29604T-MAN 34-A608K6-1BX COIL CHOKE 0.6 UH +/-10% 1 L412

08-29604T-MAN 34-R100J2-0EX COIL PL - 10 UH +/-5% 1 L252

08-29604T-MAN 34-R101J2-0EX COIL PL - 100 UH +/-5% 1 L201

08-29604T-MAN 34-R101J2-0EX COIL PL - 100 UH +/-5% 1 L211

08-29604T-MAN 34-R101J2-0EX COIL PL - 100 UH +/-5% 1 L271

08-29604T-MAN 34-R120J2-0EX COIL PL - 12 UH +/-5% 1 L256

08-29604T-MAN 34-R220J2-0EX COIL PL - 22 UH +/-5% 1 L051

08-29604T-MAN 34-R220J2-0EX COIL PL - 22 UH +/-5% 1 L081

08-29604T-MAN 34-R220J2-0EX COIL PL - 22 UH +/-5% 1 L251

08-29604T-MAN 34-R229J2-0EX COIL PL - 2.2 UH +/-5% 1 L053

08-29604T-MAN 36-HDR001-XX1 TRANSFORMER HORIZ DRIVE 1 T401

08-29604T-MAN 36-LIN240-XX1 COIL LINEARITY 24 UH 1 L413

08-29604T-MAN 36-WID601-XX1 COIL CHOKE 600 UH 1 L414

08-29604T-MAN 37-SC2901-58B0X FLYBACK BSC29-0158B 1 T461

40

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 38-236560-00X COIL I.F.T. 236560 FOR VCO 1 T271

08-29604T-MAN 40-2916MT-MAH P.C.B. MAIN BD 1

08-29604T-MAN 41-BF0100-3BB WIRE UL 1007 #24 100MM ORG 1 FOR P1 - P1

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 FOR Q241 (B - E)

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 C262

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 C946

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J022

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J410A

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J415

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J416

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J417

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J418

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J419

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J420

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J435

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J436

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J437

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J636

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J637

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J773

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J871

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J954

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 J955

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 C661

08-29604T-MAN 41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 C662

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J022A

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J044

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J123

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J132

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J141

41

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J229

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J230

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J232

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J242

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J261

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J301

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J338

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J401

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J421

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J512

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J523

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J543

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J601

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J633

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J732

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J733

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J825

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J826

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J832

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J834

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J836

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J837

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J838

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J911

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J921

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R023

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R024

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R025

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R026

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R027

42

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R028A

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R028B

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R028C

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R126

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R224

08-29604T-MAN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R241

08-29604T-MAN 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J511

08-29604T-MAN 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J514

08-29604T-MAN 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J615

08-29604T-MAN 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J632

08-29604T-MAN 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J725

08-29604T-MAN 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J729

08-29604T-MAN 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J410

08-29604T-MAN 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 R238

08-29604T-MAN 41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J023

08-29604T-MAN 41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J426

08-29604T-MAN 41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J513

08-29604T-MAN 41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J671

08-29604T-MAN 41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J672

08-29604T-MAN 41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J726

08-29604T-MAN 41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J741

08-29604T-MAN 41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J233A

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 D046

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 D141

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J041

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J043

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J124

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J151

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J152

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J154

43

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J207

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J208

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J217

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J241

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J331

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J351

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J405

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J406

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J407

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J408

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J412

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J414

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J541

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J551

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J642

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J651

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J656

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J693

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J712

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J734

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J812

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J821

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J833

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J851

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J915

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J941

08-29604T-MAN 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J544

08-29604T-MAN 41-WJ0080-B00 WIRE BARE JUMPER 8 MM 1 J425

08-29604T-MAN 41-WJ0080-B00 WIRE BARE JUMPER 8 MM 1 J443

08-29604T-MAN 41-WJ0080-B00 WIRE BARE JUMPER 8 MM 1 J453

44

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 41-WJ0080-B00 WIRE BARE JUMPER 8 MM 1 J201

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J122

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J204

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J205

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J409

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J424

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J441

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J502

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J503

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J553

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J554

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J621

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J723

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J822

08-29604T-MAN 41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 J348

08-29604T-MAN 41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J031

08-29604T-MAN 41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J634

08-29604T-MAN 41-WJ0095-B00 WIRE BARE JUMPER 9.5MM 1 J226

08-29604T-MAN 41-WJ0095-B00 WIRE BARE JUMPER 9.5MM 1 J343

08-29604T-MAN 41-WJ0095-B00 WIRE BARE JUMPER 9.5MM 1 J344

08-29604T-MAN 41-WJ0095-B00 WIRE BARE JUMPER 9.5MM 1 J713

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J001

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J002

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J061

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J134

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J203

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J402

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J423

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J432

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J501

45

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J611

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J631

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J652

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J653

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J692

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J728

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J735

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J916

08-29604T-MAN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J135

08-29604T-MAN 41-WJ0105-B00 WIRE BARE JUMPER 10.5MM 1 J442

08-29604T-MAN 41-WJ0105-B00 WIRE BARE JUMPER 10.5MM 1 J622

08-29604T-MAN 41-WJ0105-B00 WIRE BARE JUMPER 10.5MM 1 J333

08-29604T-MAN 41-WJ0105-B00 WIRE BARE JUMPER 10.5MM 1 J311

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J227

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J228

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J244

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J302

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J313

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J322

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J612

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J614

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J625

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 JP213

08-29604T-MAN 41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J324

08-29604T-MAN 41-WJ0115-B00 WIRE BARE JUMPER 11.5MM 1 J052

08-29604T-MAN 41-WJ0115-B00 WIRE BARE JUMPER 11.5MM 1 J627

08-29604T-MAN 41-WJ0115-B00 WIRE BARE JUMPER 11.5MM 1 J628

08-29604T-MAN 41-WJ0115-B00 WIRE BARE JUMPER 11.5MM 1 J246

08-29604T-MAN 41-WJ0115-B00 WIRE BARE JUMPER 11.5MM 1 J522

08-29604T-MAN 41-WJ0115-B00 WIRE BARE JUMPER 11.5MM 1 J342

46

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 41-WJ0120-B00 WIRE BARE JUMPER 12MM 1 J051

08-29604T-MAN 41-WJ0120-B00 WIRE BARE JUMPER 12MM 1 J250

08-29604T-MAN 41-WJ0120-B00 WIRE BARE JUMPER 12MM 1 J253

08-29604T-MAN 41-WJ0120-B00 WIRE BARE JUMPER 12MM 1 J254

08-29604T-MAN 41-WJ0120-B00 WIRE BARE JUMPER 12MM 1 J434

08-29604T-MAN 41-WJ0120-B00 WIRE BARE JUMPER 12MM 1 J711

08-29604T-MAN 41-WJ0120-B00 WIRE BARE JUMPER 12MM 1 J644

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J131

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J206

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J218

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J222

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J225

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J233

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J263

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J352

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J643

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J813

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J951

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J981

08-29604T-MAN 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J772

08-29604T-MAN 41-WJ0130-B00 WIRE BARE JUMPER 13MM 1 J239

08-29604T-MAN 41-WJ0130-B00 WIRE BARE JUMPER 13MM 1 J413

08-29604T-MAN 41-WJ0130-B00 WIRE BARE JUMPER 13MM 1 J346

08-29604T-MAN 41-WJ0135-B00 WIRE BARE JUMPER 13.5MM 1 J224

08-29604T-MAN 41-WJ0135-B00 WIRE BARE JUMPER 13.5MM 1 J236

08-29604T-MAN 41-WJ0135-B00 WIRE BARE JUMPER 13.5MM 1 J247

08-29604T-MAN 41-WJ0135-B00 WIRE BARE JUMPER 13.5MM 1 J248A

08-29604T-MAN 41-WJ0135-B00 WIRE BARE JUMPER 13.5MM 1 J411

08-29604T-MAN 41-WJ0135-B00 WIRE BARE JUMPER 13.5MM 1 R228A

08-29604T-MAN 41-WJ0135-B00 WIRE BARE JUMPER 13.5MM 1 J345

47

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 41-WJ0140-B00 WIRE BARE JUMPER 14MM 1 J335

08-29604T-MAN 41-WJ0140-B00 WIRE BARE JUMPER 14MM 1 J336

08-29604T-MAN 41-WJ0140-B00 WIRE BARE JUMPER 14MM 1 J337

08-29604T-MAN 41-WJ0140-B00 WIRE BARE JUMPER 14MM 1 J742

08-29604T-MAN 41-WJ0140-B00 WIRE BARE JUMPER 14MM 1 J321

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J032

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J133

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J153

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J235

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J237

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J243

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J245

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J255

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J262

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J347

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J461

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J542

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J714

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J761

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J782

08-29604T-MAN 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J931

08-29604T-MAN 41-WJ0160-B00 WIRE BARE JUMPER 16MM 1 J238

08-29604T-MAN 41-WJ0160-B00 WIRE BARE JUMPER 16MM 1 J325

08-29604T-MAN 41-WJ0160-B00 WIRE BARE JUMPER 16MM 1 J334

08-29604T-MAN 41-WJ0160-B00 WIRE BARE JUMPER 16MM 1 J431

08-29604T-MAN 41-WJ0160-B00 WIRE BARE JUMPER 16MM 1 J645

08-29604T-MAN 41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 J221

08-29604T-MAN 41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 J314

08-29604T-MAN 41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 J234

08-29604T-MAN 41-WJ0170-B00 WIRE BARE JUMPER 17MM 1 J231

48

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 41-WJ0170-B00 WIRE BARE JUMPER 17MM 1 J240

08-29604T-MAN 41-WJ0170-B00 WIRE BARE JUMPER 17MM 1 J835

08-29604T-MAN 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J223

08-29604T-MAN 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J249A

08-29604T-MAN 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J251

08-29604T-MAN 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J661

08-29604T-MAN 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J811

08-29604T-MAN 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J912

08-29604T-MAN 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM 1 J913

08-29604T-MAN 41-WJ0180-B00 WIRE BARE JUMPER 18MM 1 J214

08-29604T-MAN 41-WJ0180-B00 WIRE BARE JUMPER 18MM 1 J623

08-29604T-MAN 41-WJ0190-B00 WIRE BARE JUMPER 19MM 1 J823

08-29604T-MAN 41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J323

08-29604T-MAN 41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J355

08-29604T-MAN 41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J641

08-29604T-MAN 41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J731

08-29604T-MAN 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J312

08-29604T-MAN 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J332

08-29604T-MAN 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J427

08-29604T-MAN 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J624

08-29604T-MAN 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J626

08-29604T-MAN 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J727

08-29604T-MAN 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J824

08-29604T-MAN 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J831

08-29604T-MAN 45-OSC4M4-3Y0 CRYSTAL 4.43MHz (CL=16pF) 1 X201

08-29604T-MAN 45-OSC8M0-0Y0 CRYSTAL 8.0MHZ 1 X051

08-29604T-MAN 45-SAWK33-50K SAW FILTER K3350K (38.9MHZ) 1 Z141

08-29604T-MAN 45-TRA5M5-0Y0 CER TRAP TPS 5.5MHZ 1 Z254

08-29604T-MAN 46-12866W-02X PIN BASE *2 S11-02Y 1 P601 FOR FRONT CAB.(SPK)

08-29604T-MAN 46-20598W-04X PIN BASE *4 TJC1-4A 1 P411 FOR DY CONNECT.

49

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 46-20600H-04X HS 4P A/B 360/13 RBGW TJC1-4Y 1 FOR D.F BD (A1' & A2 & A5 & A6)

08-29604T-MAN 46-27306H-02X HS 2P24 150/5 F/W TJC3-2Y 1 P1003 "2" TO Q932(B),"3" TO Q931(B)

08-29604T-MAN 46-33079W-02X PIN BASE *2 TJC3-2A 1 P602 FOR FRONT CAB.(SPK)

08-29604T-MAN 46-33079W-03X PIN BASE *3 TJC3-3A 1 P401 FOR VM BD P504

08-29604T-MAN 46-33079W-04X PIN BASE *4 TJC3-4A 1 P202 FOR VM BD P505

08-29604T-MAN 46-33079W-04X PIN BASE *4 TJC3-4A 1 P421 FOR CRT BD P502

08-29604T-MAN 46-33079W-05X PIN BASE *5 TJC3-5A 1 P001 FOR F. CTL BD P001B

08-29604T-MAN 46-33079W-05X PIN BASE *5 TJC3-5A 1 P201 FOR CRT BD P503

08-29604T-MAN 46-33079W-06X PIN BASE *6 TJC3-6A 1 P002 FOR W.BAL. ADJUST

08-29604T-MAN 46-33079W-06X PIN BASE *6 TJC3-6A 1 P003 FOR SIDE AV BD

08-29604T-MAN 47-RCA023-XX1 RCA JACK 3PV YEL WHI RED/SW 1 P911

08-29604T-MAN 47-RCA023-XX1 RCA JACK 3PV YEL WHI RED/SW 1 P931

08-29604T-MAN 47-SVI002-XX0 Y/C SOCKET VERTICAL TYPE 1 P981

08-29604T-MAN 54-128700-0X0 FIBRE WASHER 3.3 X 10 X 0.8 2 MTG M.BD & FBT

08-29604T-MAN 62-10654X-00F UNI-TIE (2.5mmX95mm) 12

08-29604T-MAN 62-227680-0UA HOLDER CABLE FOR FBT (2) 1

08-29604T-MAN 62-354440-0UN MAIN BD BRACKET 1

08-29604T-MAN 63-B30100-BT4 S/T SCREW B 3 X 10 BT 2 MTG M.BD & FBT

08-29604T-MAN 63-W30100-AB4 S/T SCREW W 3 X 10 AB 8 MTG M.BD & BKT

08-29604T-MAN 64-P30080-104 M/C SCREW P 3 X 8 1 FOR IC301

08-29604T-MAN 64-P30080-104 M/C SCREW P 3 X 8 1 FOR Q412

08-29604T-MAN 64-P30080-104 M/C SCREW P 3 X 8 1 FOR Q722

08-29604T-MAN 64-P30100-104 M/C SCREW P 3 X 10 2 FOR IC601

08-29604T-MAN 65-Z30050-23M NUT M 3 2 FOR IC301 & Q412

08-29604T-MAN 65-Z30050-23M NUT M 3 2 FOR IC601

08-29604T-MAN 66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 5 FOR T461

08-29604T-MAN 66-343740-0B0 HOLLOW RIVET (2.3mmx4.0mmx3.5mm) 2 FOR R404

08-29604T-MAN 67-H27292-1A0 HEAT SINK-REGULATOR & DPC A=60 1 FOR Q722

08-29604T-MAN 67-H30147-1A0 HEAT SINK FOR HORIZ 1 FOR Q412

08-29604T-MAN 67-H30179-5A0 HEAT SINK 1 FOR IC301

50

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 67-H30705-3A0 HEAT SINK 1 FOR IC601

08-29604T-MAN 70-271510-00A SERVICE CARD 1 FOR PRODUCTION USE

08-29604T-MAN 71-270870-0A9 LABEL 2

08-29604T-MAN 90-209770-SR1 SILICONE GREASE G-746 0.0009 FOR IC601 & Q412 & Q722

08-29604T-MAN 90-269080-ZU0 CLEAN COATING TC-131L 14KG/桶 0.0001

08-29604T-MAN 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C074

08-29604T-MAN 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C106

08-29604T-MAN 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C214

08-29604T-MAN 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C227

08-29604T-MAN 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C276

08-29604T-MAN 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C651

08-29604T-MAN 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C655

08-29604T-MAN 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C952

08-29604T-MAN 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C278

08-29604T-MAN 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C064

08-29604T-MAN 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C217

08-29604T-MAN 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C228

08-29604T-MAN 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C257

08-29604T-MAN 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C934

08-29604T-MAN 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C944

08-29604T-MAN 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C969

08-29604T-MAN 25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C933

08-29604T-MAN 25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C634

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C202

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C274

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C911

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C912

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C913

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C921

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C922

51

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C923

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C931

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C932

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C943

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C981

08-29604T-MAN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C991

08-29604T-MAN 25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% 1 C082

08-29604T-MAN 25-BEA102-M1X CAP. ELEC 1000 UF 35V +/-20% 1 C432

08-29604T-MAN 25-BEA102-M1X CAP. ELEC 1000 UF 35V +/-20% 1 C610

08-29604T-MAN 25-BEA221-M1X CAP. ELEC 220 UF 35V +/-20% 1 C306

08-29604T-MAN 25-BEA471-M1X CAP. ELEC 470 UF 35V +/-20% 1 C607

08-29604T-MAN 25-BEA471-M1X CAP. ELEC 470 UF 35V +/-20% 1 C608

08-29604T-MAN 25-BEB101-M1X CAP. ELEC 100 UF 35V +/-20% 1 C731

08-29604T-MAN 25-BEG222-M1X CAP. ELEC 2200 UF 35V +/-20% 1 C303

08-29604T-MAN 25-BEG222-M1X CAP. ELEC 2200 UF 35V +/-20% 1 C309

08-29604T-MAN 25-BFB100-M1X CAP. ELEC 10 UF 50V +/-20% 1 C311

08-29604T-MAN 25-BFB100-M1X CAP. ELEC 10 UF 50V +/-20% 1 C222

08-29604T-MAN 25-BFB101-M1X CAP. ELEC 100 UF 50V +/-20% 1 C605

08-29604T-MAN 25-BFB108-M1X CAP. ELEC 0.1 UF 50V +/-20% 1 C271

08-29604T-MAN 25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C206

08-29604T-MAN 25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C253

08-29604T-MAN 25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C631

08-29604T-MAN 25-BFB478-M1X CAP. ELEC 0.47 UF 50V +/-20% 1 C208

08-29604T-MAN 25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C101

08-29604T-MAN 25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C124

08-29604T-MAN 34-A109K0-1IX COIL CHOKE 1 UH +/-10% 1 L121

08-29604T-MAN 34-A109K0-1IX COIL CHOKE 1 UH +/-10% 1 L141

08-29604T-MAN 27-MBC474-J0X CAP. M.P.E 0.47UF 63V +/-5% 1 C251

08-29604T-MAN 10-PC574J-DJX DIODE ZENER UPC 574J 1 D111

03-29604T-AA3 08-29604T-PAN ASS'Y - PACKING 1

52

Parent Item No. Item No. Description Quantity Designator Remarks

08-29604T-PAN 49-341790-BAT BATT. R6P AA SUM3 5# 2

08-29604T-PAN 72-29604T-E03 OPERATION MANUAL 1

08-29604T-PAN 74-022032-6WE POLYBAG (22cmX32cmX0.06mm) 1 FOR OPERATION MANUAL

08-29604T-PAN 74-130130-80HAA POLYBAG W/SUFFOCATION WARNING 1

08-29604T-PAN 75-2960LL-CC1 POLYFOAM "LL" 1

08-29604T-PAN 75-2960LR-CC1 POLYFOAM "LR" 1

08-29604T-PAN 75-2960UL-CC1 POLYFOAM "UL" 1

08-29604T-PAN 75-2960UR-CC1 POLYFOAM "UR" 1

08-29604T-PAN 76-H2960P-0AT CARTON BOX 1

08-29604T-PAN 62-275340-0HD CARTON BOX HOLDER (3,4) 4

03-29604T-AA3 08-29604T-RCN ASS'Y - REAR CABINET 1

08-29604T-RCN 42-07808G-XX0 SPEAKER 8 OHM 10W 1 SP601

08-29604T-RCN 42-07808G-XX0 SPEAKER 8 OHM 10W 1 SP602

08-29604T-RCN 46-27322H-02X HS 2P24 360/7 F/W SM-2P WH 1 FOR RED TO SP601"+", WHITE TO SP601"-",

08-29604T-RCN 46-27322H-02X HS 2P24 360/7 F/W SM-2P WH 1 FOR RED TO SP602"+", WHITE TO SP602"-"

08-29604T-RCN 54-114000-00X FELT TAPE (150mmX19mmX0.3mm) 10 STICK ON REAR CAB.

08-29604T-RCN 54-114000-00X FELT TAPE (150mmX19mmX0.3mm) 8 STICK ON SPK BKT

08-29604T-RCN 55-2960RC-0AN REAR CABINET 1

08-29604T-RCN 58-2960MP-0UI PLATE MODEL NO. 1

08-29604T-RCN 58-2960RI-4UI INLAY REAR AV 1

08-29604T-RCN 58-2960SI-0UI INLAY SIDE AV (II) 1

08-29604T-RCN 58-354450-1UI INLAY SIDE AV 1

08-29604T-RCN 59-130460-00X RUBBER PAD (25mmX7mm) 2 STICK ON FOOTING

08-29604T-RCN 62-360360-0HN SPEAKER BRACKET 2 MTG TO R.CAB

08-29604T-RCN 63-B40200-AB2 S/T SCREW B 4 X 20 AB 10 MTG FRONT & REAR CAB.

08-29604T-RCN 63-F30100-BT3 S/T SCREW F 3 X 10 BT (BLACK) 2 MTG RCA JACK & REAR CAB.

08-29604T-RCN 63-W30100-AB4 S/T SCREW W 3 X 10 AB 8 MTG SPK & SPK BKT

08-29604T-RCN 63-W30120-BT4 S/T SCREW W 3 X 12 BT 4 MTG SPK BKT & REAR CAB.

03-29604T-AA3 08-29884T-CFN ASS'Y - COMB FILTER BD 1

08-29884T-CFN 11-SK2541-0BX TRANSISTOR 2SK2541 (N-CHANNEL) 1 Q1111

53

Parent Item No. Item No. Description Quantity Designator Remarks

08-29884T-CFN 11-SK2541-0BX TRANSISTOR 2SK2541 (N-CHANNEL) 1 Q1112

08-29884T-CFN 13-0TDA91-81P IC TDA9181 (COMB FILTER) 1 IC1101

08-29884T-CFN 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R1112

08-29884T-CFN 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R1111

08-29884T-CFN 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R1115

08-29884T-CFN 18-CB0512-JNX RES. C.F. 5.1k OHM 1/6W +/-5% 1 R1113

08-29884T-CFN 18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R1116

08-29884T-CFN 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C1123

08-29884T-CFN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1114

08-29884T-CFN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1116

08-29884T-CFN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1117

08-29884T-CFN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1118

08-29884T-CFN 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1119

08-29884T-CFN 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C1112

08-29884T-CFN 26-EBP150-JZX CAP. CER 15PF 50V +/-5% SL TUBU 1 C1120

08-29884T-CFN 26-EBP150-JZX CAP. CER 15PF 50V +/-5% SL TUBU 1 C1122

08-29884T-CFN 26-EBP222-KBX CAP. CER 2200PF 50V +/-10% B 1 C1111

08-29884T-CFN 34-R100J2-0EX COIL PL - 10 UH +/-5% 1 L1111

08-29884T-CFN 34-R100J2-0EX COIL PL - 10 UH +/-5% 1 L1112

08-29884T-CFN 40-2900NT-CSB P.C.B. COMB FILTER & SECAM BD 1

08-29884T-CFN 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J1121

08-29884T-CFN 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J1111

08-29884T-CFN 41-WJ0070-B00 WIRE BARE JUMPER 7MM 1 J1117

08-29884T-CFN 41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J1118

08-29884T-CFN 41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J1115

08-29884T-CFN 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J1120

08-29884T-CFN 46-21550W-14X HEADER *14 TS14B-SQ-1 1 P1111 FOR M.BD P230

08-29884T-CFN 67-257870-1T0 BRACKET IF BD 1

08-29884T-CFN 67-257870-2T0 BRACKET IF BD 1

08-29884T-CFN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C1113

54

Parent Item No. Item No. Description Quantity Designator Remarks

08-29884T-CFN 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C1115

08-29884T-CFN 25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C1121

03-29604T-AA3 08-HS46F0-M13C ASS'Y - REMOTE HANDSET 1

08-HS46F0-M13C 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D1502

08-HS46F0-M13C 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D1503

08-HS46F0-M13C 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D1504

08-HS46F0-M13C 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D1505

08-HS46F0-M13C 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D1507

08-HS46F0-M13C 11-0BC337-0BX TRANSISTOR (NPN) BC337-40 1 Q1501

08-HS46F0-M13C 14-IRE05B-XX0 IR EMITTING DIODE BT-7085N-30 1 D1501

08-HS46F0-M13C 18-CB0229-JNX RES. C.F. 2.2 OHM 1/6W +/-5% 1 R1502

08-HS46F0-M13C 18-CB0682-JNX RES. C.F. 6.8K OHM 1/6W +/-5% 1 R1501

08-HS46F0-M13C 26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C1501

08-HS46F0-M13C 26-EBP101-JCX CAP. CER 100PF 50V +/-5% CH 1 C1502

08-HS46F0-M13C 40-2909NT-RMB P.C.B. REMOTE HANDSET 1

08-HS46F0-M13C 45-COS455-KY0 CERAMIC RESONATOR 455KHZ 1 X1501

08-HS46F0-M13C 49-HS46F0-00X RUBBER PAD KEYS 1

08-HS46F0-M13C 55-HS46FB-0HA CASE LOWER - REMOTE HANDSET 1

08-HS46F0-M13C 55-HS46FD-0HA DOOR BATT. - REMOTE HANDSET 1

08-HS46F0-M13C 55-HS46FT-0HA CASE UPPER - REMOTE HANDSET 1

08-HS46F0-M13C 58-HS46F2-MUI INLAY REMOTE HANDSET 1

08-HS46F0-M13C 63-B26060-BT2 S/T SCREW B 2.6 X 6 BT 1

08-HS46F0-M13C 67-26968X-0E2 BATT. TERMINAL (+/-) 1

08-HS46F0-M13C 67-310280-0E2 SPRING - BATTERY (-) 1

08-HS46F0-M13C 67-310290-0E2 SPRING - BATTERY (+) 1

08-HS46F0-M13C 74-009022-60C POLYBAG HANDSET (9CMX22CM) 1

08-HS46F0-M13C 25-HBB470-M1X CAP. ELEC 47UF 10V +/-20% 1 C1503

08-HS46F0-M13C 13-SC9028-23B IC SC9028-023 1 IC1501

55

TB1240 + TCLM13 chassis alignment instruction

f

Enter factory mode in productio n line

Simply press the D-mode key on the factory remote handset.

Enter service mode

Press and hold the VOLUME DOWN key tightly on the unit until minimum level and don’t release the
VOLUMN DOWN key, then press the DISPLAY key on the remote handset three times.

“D” letter on the screen indicated that the factory mode was entered. Now you can use the shortcut key
to access the factory menu. All change in factory data will save in EEPROM automatically

Note:

1. You can disable th e D-Mode key (on factory remote hands et) by change “BIT-0” of “MODE2” to

“0”. If the D-Mode key was disabled, you can’t enter D-Mode by the D-mode key on the factory
remote (but you can still enter service mode). It is suggested to disable the D-Mod e key b efore the
set leave the factory.

2. On the factory remote handset, you can find the “BUS OFF” key. It can cut off the I2C control from

the CPU to other IC. This is only useful when automatic adjustment of white balance.

3. All system data in menu of “key 7” must keep unchanged when servicing. Othe rwise, the set may not

work properly.

Setting method:

No Adjustment

Items

1 Screen

voltage

2 Focus voltage ------------ Cross hatch

3 VCO ------------ Apply an IF

Data Name (default

value inside blanket)

------------ “IRGB cut off”

Conditions and

input signal

must set to 80 (all

signal (see tuner

frequency) to the

pattern)

pattern.

spec. For

IF input.

Setting method (need enter D-mode)

 Press “MUTE” key on the remote handset

and the screen will become a horizontal
line. Then adjust the “screen” VR on the
flyback until the horizontal line can just be
seen (minimum visible intensity).

 Adjust the “focus” VR on the flyback until

the screen becomes clear.

 Monitor the DC voltage at pin 48 o

IC201, then adjust T271 until the voltage at
pin 48 become 4.62 +/- 0.02 V.

 Press the AFT button on the factory remote

and AFT adjustment will be done
automatically.

4 Vertical

f

f

geometry for

PAL system

(Key 2)

VPOS50 (04)
HIGH50 (25)

VLIN50 (04)

VSC50 (05)
OSD50 (20)

Input a PAL cross

hatch pattern.

 Adjust VPOS50 for vertical position.
 Adjust HIGH50 for vertical amplitude.
 Adjust VLIN50 for vertical linearity.
 Adjust VSC50 for vertical S-correction
 Adjust OSD50 for OSD position (normally

use default value).

5 Vertical

geometry for

NTSC system

(Key 3)

6 Horizontal

geometry for

PAL system

(Key 4)

7 Horizontal

geometry for

NTSC system

(Key 5)

VPOS60 (00)

HIGH60 (2E)

VLIN60 (05)

VSC60 (0A)

OSD60 (89)

HPOS50 (0D)

HSIZE50 (2A)

PARA50 (14)

TRAP50 (0E)

CORN50 (0A)

VEHT50 (03)
HEHT50 (02)

HPOS60 (11)

HSIZE60 (2A)

PARA60 (18)

TRAP60 (0D)

CORN60 (0D)

VEHT60 (03)
HEHT60 (02)

Input a NTSC

cross hatch

pattern.

Input a PAL cross
hatch pattern with

black and white

background.

Input a NTSC

cross hatch

pattern with black

and white

background.

 Adjust VPOS60 for vertical position.
 Adjust HIGH60 for vertical amplitude.
 Adjust VLIN60 for vertical linearity.
 Adjust VSC60 for vertical S-correction
 Adjust OSD60 for OSD position (normally

use default value).

 Adjust HPOS50 for horizontal position.
 Adjust HSIZE50 for horizontal width.
 Adjust PARA50, TRAP50 and CORN50

until the vertical line at left and right side
of the picture become straight.

 VEHT and HENT is for the picture size

stability when changing the brightness o
the screen. Receive pattern of cross hatch
with black background and then change to
white background, then compare the
vertical and horizontal size between black
and white background. Adjust VEHT and
HEHT until you get the minimum
difference of screen size. After you adjust
VEHT and HEHT, you must re-adjust
vertical and horizontal amplitude.

 Adjust HPOS60 for horizontal position.
 Adjust HSIZE60 for horizontal width.
 Adjust PARA60, TRAP60 and CORN60

until the vertical line at left and right side
of the picture become straight.

 Adjust VEHT and HEHT using same

method of PAL system. Also need re­adjustment of vertical and horizontal
amplitude.

1

2

adjustment)

Key 6

(Status

RFAGC (25)
PIFAFT (44)

HAFC (00)
S-B-Y (08)

S-R-Y (08)
VOL 05 (48)
VOL 25 (65)
VOL OUT(73)

Receive a 60dB

grey scale + color

bar signal

 RFAGC – monitor the voltage at AGC pin

of the tuner. Then increase the setting o
RFAGC until the tuner AGC voltage reach
maximum (about 5V). Then decrease the
RFAGC setting until the AGC voltage just
drop.

 Adjust S-B-Y and S-R-Y to get the optimal

color for SECAM system.

 Please keep the PIFAFT value after auto

AFT adjustment.

 HAFC item must use the default value.

(curve of

volume
control)

---------  VOL05 is the volume output level at 5%
 VOL25 is the volume output level at 25%

Remark: The value of VOL05 and VOL25 was
not suggested to vary in every set. It is
suggested to use the default value.

13 White balance

adjustment

(key 1)

R CUT (6B)
G CUT (9E)
B CUT (7C)
G DRV (39)
B DRV (35)

Black and white

pattern (PAL)

1. Measure the dark side of the picture with a

color analyzer and set RCUT to 80. Then
adjust BCUT and GCUT until the data on
the analyzer become x = 284, y = 299.

2. Measure the bright side of the picture,

Then adjust BDRV and GDRV until the
data on the analyzer become x = 284, y =

299.

3. Repeat step 1 and 2 until you get right

color on both dark and bright side of the
screen.

Other adjustment (default value was suggested, except BRTC)

8Key 0 OSD (0A)

TXCX (30)

RGCN (20)

TNTX (25)
TNTN (32)

FMMODE (13)

DKFMMD (20)

9Key 8 SCNT (0F)

CNTX (3F)
CNTN (00)

BRTX (20)

BRTN (25)
COLX (35)
COLN (00)

10 Key 9 CNTC (22)

BRTC (37)

COLC (50)

TNTC (35)

COLP (00)

COLS (54)

BRTS (00)

---------- OSD – OSD position
TXCX – OSD intensity when maximum

contrast

RGCN – OSD intensity when minimum

contrast
TNTX – maximum tint level
TNTN – minimum tint level
FMMODE – frequency shift for FM (mono)

mode, only useful for NICAM

model
DKFMMD - frequency shift for DK NICAM

mode

---------- SCNT – sub contrast for luminance signal
CNTX – maximum contrast
CNTN – minimum contrast
BRTX – maximum brightness
BRTN – minimum brightness
COLX – maximum color
COLN – minimum color

---------- CNTC – 50% contrast
BRTC – 50% brightness
COLC – 50% color
TNTC – 50% tint
COLP – color level for PAL
COLS – color level for SECAM
BRTS – sub brightness for SECAM

 For the adjustment of BRTC, receive an 8

step grey scale pattern and adjust all
picture settings to 50%. Then adjust B RTC
until the first and second step on the screen
can just be distinguished.

11 Two digit key

-/--

(sharpness

adjustment)

13 KEY CALL DBE STR 50

SHPTV3 (1A)

SHPAV3 (1A)
SHPTV4 (18)

SHPAV4 (18)

SHPX (1A)

SHPN (1F)

DBE HMC 0D
DBE HP 07
DBE LP 00
DBE LIM FO
SUB FRE 15
SUB HP 02
VOLMAI 03

System data:

Item Adjust item Default value

---------- SHPTV3 – 50% sharpness in 3.58 system
(TV)
SHP AV3 – 50% sharpness in 3.58 system (AV)
SHPTV4 – 50% sharpness in 4.43 system
(TV)
SHP AV4 – 50% sharpness in 4.43 system (AV)
SHPX – maximum sharpness
SHPN – minimum sharpness

Richly Music

Signal

Effect Strength
Harmonic Content
High Pass Corner Frequency
Low Pass Corner Frequency
Amplitude Limit
Subwoofer Corner Frequency
Subwoofer Complementary High Pass Filter
Volume Loudspeaker

12 Key 7 VCDM0

VCDM1
VCDM2
MODE0
MODE1
MODE2

OPTION

It is subject to the current ODF.
Please check the sample to get the value.

System setting of M13

VCDM0 (default value: 28)

BIT Item

0 System switch: 0 : normal identify mode 1 : weak signal identify mode
1 White peak suppress: 0: on 1: off

ABL gain

2,3

00: -0.74v 01: -0.64v 10: -0.37v 11: -0.12v
ABL start point

4,5

00: -0.01v 01: -0.11v 10: -0.3v 11: -0.45v

6 CW-SW: TB1238N, pin 29 Fsc CW output 0 : AUTO, 1 : 4.43M

In force system mode, the status of color killer when weak signal

7

0: on 1: off

VCDM1 (default value: 00)

BIT Item

0 Blanking: 0: on 1: off

1,2,3,4,5 V-Mute timing: = 200ms + 8ms ×Data

6 Base band filter in NTSC system: 0: on, 1: off
7VMOD

VCDM2 (default value: 40 for 38MHz IF, 30 for 38.9MHz IF)
BIT Item

0 AFT-mute: 0: off, 1: on (brightness off)
1 SECAM-ADJ: 0: SECAM correction off, 1: SECAM correction on
2 TB1238N_VMOD

3 PIF VCO ADJ
6,5,4 IF frequency:

111: 33.9MHz 110: 33.95MHz 101: 34.47MHz 100: 38MHz
011: 38.9MHz 010: 39.5MHz 001: 45.75MHz 000: 58.75MHz

7 No use

MODE0

BIT Item
0 0: normal AV 1: SCART (CATV)

1 SRS: 0: OFF 1:ON
2 SECAM system: 0: off, 1: on

3 High Sensibility: 0: off 1: on
4, 5 STANDBY status after switch on : 00 or 10: force STANDBY

01: force on. 11: status before switch off

6,7 Mode0.6, Mode0.7: 0X: English 10: English + Russia 11: English + Vietnamese

MODE1

BIT Item
0 BG : 0 : off 1 : on
1 I : 0 : off 1 : on
2 DK : 0 : off 1 : on
3 M : 0 : off 1 : on
4, 5 SSIF1, SSIFO Default sound system after auto search:

00 : BG 01 : I 10 : DK 11 : M

6 AV/TV: 0: TV/AV 1: TV AV1/AV2
7 Number of channels: 0: 50 1: 100

MODE2

BIT Item
0 D-MODE : 0: off 1: on
1 Teletext 0: off 1: on
2 COMB Filter 0: off 1: on
3 BBE 0: off 1: on
4 NICAM & IGR 0: off 1: on
5 WOOFER 0: off 1: on
6 DBE 0: off 1: on
7 VM 0: off 1: on

OPTION (default value: 10)

BIT Item
0 When blue background off (mute pin of CPU):

0: audio mute on 1: audio mute off

1 When blue background off (external mute pin of CPU):

0: audio mute on 1: audio mute off

2 When change channel:

0: picture mute on 1: picture mute off

3 Audio demodulation gain setting:

0: 50KHz 1: 25KHz

4 When no signal:

0: search channel by changing VT 1: use memorized VT

5 Logo: 0: off 1: on
6 OSD black background: 0: off 1: on
7 Display on Sound Mode Changing:

0: on 1: off

M13 Block Diagram By XiaoCM2002/8/8

Audio, Video out

9V

AV In/Out AV Selector

IC 961

AV1/AV2 Select

Video In

9V

Tunner
TU101

SAW Filter

Z101

IF

5V

CPU

IC001

AV/TV Select

Audio Selector

IC962

Audio

5V 9V

TB1240

IC201

I2C

Speakers

Amplifier

IC601

RGB

23V

AC

12V

CRT
board

V. Drive

T401, Q401, Q402

9V

IC301

H. Drive

Power Supply

T802

RGB

28V

140V

140V,23V,5V,9V

12V

CRT

Deflection

Yoke

140V

FBT

T402

HV

28V

5V

EEPROM

IC002

KEY IR Sensor

TEXT Board Comb Flitter

Optional Optional

5V
