TEAC CTM-4828 Service manual

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

155-R63303-12-02 HANDSET ASS'Y RC:R633 W/FINE TUNE W/O TT
{BATTERY DOOR- TEAC DESIGN (CT-M4828)}
180-820B00-00-MP COMMON PART FOR 820B MECH PART ASS'Y
®®FOR 1 LED¯¯
180-820BT0-27-05 NON-COM PART ASS'Y PAL BG W/FRONT AV-ST.

-IN./SCART (PHILIPS 40P)"TEAC"
180-820BT0-27-CP COMMON PART ASS'Y PAL BG W/FRONT AV-ST.­ IN/SCART (PHILIPS 40P)

1201

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

155-R63303-12-02 HANDSET ASS'Y RC:R633 W/FINE TUNE W/O TT

{BATTERY DOOR- TEAC DESIGN (CT-M4828)}
107-800455-46 455K HZ RESONATOR "KYOCERA" 1
CF701
113-101005-17 CARBON FILM RESISTOR 100 OHM 1/16W +-5% 2
R704,706
113-102005-17 CARBON FILM RESISTOR 1K OHM 1/16W +-5% 1
R705
113-103005-17 CARBON FILM RESISTOR 10K OHM 1/16W +-5% 1
R702
113-109005-17 CARBON FILM RESISTOR 1 OHM 1/16W +-5% 1
R709
113-473005-17 CARBON FILM RESISTOR 47K OHM 1/16W +-5% 1
R703
113-682005-17 CARBON FILM RESISTOR 6.8K OHM 1/16W +-5% 1
R701
127-476042-03 ELECT. CAP. 47 MFD 16V +-20% 1
C701
130-600101-00 INFRARED EMITTER EL-1L1 KODENSHI 1
LED701
131-210719-29 TRANSISTOR 2SA719R/S MATSUSHITA 1
Q702
131-230945-00 TRANSISTOR 2SC945 NEC 1
Q701
133-803010-33 I.C. SAA3010T PHILIPS 1
IC701
172-726000-99 BARE WIRE 54MM 0
W701
190-R63301-P2 REMOTE P.C.B. (050896) 1
516-260408-10 SELF-TAPPING SCREW 2.6 X 8 P/T (HARDEN) 2
FOR HANDSET
774-R63301-00 BATTERY SPRING (+VE) 1
774-R63302-00 BATTERY SPRING (-VE) 1
774-R63303-00 BATTERY SPRING (+-VE) 1
810-041104-13 POLYBAG 4" X 11" X 0.04MM W/RE-CYCLING MARK 1
FOR HANDSET
849-R63301-00 KEY PAD {FULL 40 KEYS} 1
892-R63323-01 DIAL KEY PLATE - ENG STD W/FINE TUNE W/O TXT 1
900-R63302-03 HANDSET TOP CABINET -MATT BLK. SPRAYED W/SILVER 1
{MATCH W/902-R63302-03}}
8001C S.S.
902-R63302-03 HANDSET BOTTOM CABINET - MATT BLACK SPRAYED 1
{MATCH W/900-R63302-03}
910-R63301-78 BATTERY DOOR - TEAC DESIGN (CT-M4828)(RC-693) MATT 1
BLACK
973-R63301-00 VOLUME/CHANNEL KNOB - MOULDED BLACK 1

2202

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

180-820B00-00-MP COMMON PART FOR 820B MECH PART ASS'Y
®®FOR 1 LED¯¯
514-400312-10 SELF-TAPPING SCREW 4 X 12 B/A (HARDEN) 1
FOR FBT MTG
514-400425-10 SELF-TAPPING SCREW 4 X 25 B/T (HARDEN) 2
FOR CABINET MTG.
515-303408-10 SELF-TAPPING SCREW 3 X 8 W/B/T (HARDEN) 11
8-SPK MTG.,3-LENS TO F.CAB.
515-303410-10 SELF-TAPPING SCREW 3 X 10 W/B/T (HARDEN) 4
FOR FUNCTION KNOB
516-300415-10 SELF-TAPPING SCREW 3 X 15 P/T (HARDEN) 1
FOR LENS TO F.CAB.
516-500435-10 SEIF-TAPPING SCREW 5X35 P/T (HARDEN) HEAD DIA. 4
FOR CABINET MTG.

9.5MM MAX
524-932901-01 CRT MOUNTING SCREW 7 X 40 VP (HARDEN) 4
FOR CRT MTG
622-882802-00 FELT L240 X W17 X T0.5MM W/TAPE 8
FOR FRONT CABINET & BACK CABINET
777-921301-00 POWER KNOB SPRING (ID=9MM,L=10MM) 1
FOR POWER KNOB
810-052204-14 POLYBAG 5" X 22" X 0.04MM W/RE-CYCLING MARK {P/O 1
FOR AC LINE CORD
MAT}
810-091504-13 POLYBAG 9" X 15" X 0.04MM W/ RE-CYCLING P.E.MARK 1
FOR I/MANUAL
834-230801-00 RUBBER WASHER OD=23 , ID=8 , T=1.0 2
FOR CRT MTG.(LOWER)
834-230802-00 RUBBER WASHER OD=23, ID=8, T=2 6
4 FOR CRT MTG.(UP),2 FOR CRT MTG.(LOWER)
834-230805-00 RUBBER WASHER OD=23 ID=8 T=0.5 2
FOR CRT MTG.(UP)
840-011024-21 PAD CORD L240 X W10 X T1 MM W/TAPE 6
6 FOR BETWEEN CRT AND FRONT CAB.
840-051020-11 RUBBER PAD (UL 94VO) 3
1 FBT.,1 TRANSFORMER,1 BETWEEN FBT & HEAT SINK
929-881301-00 LED HOLDER BKT 1
FOR LED601
939-942101-00 POWER KNOB ADAPTOR 1
FOR POWER SWITCH
954-882100-00 AC LINE CORD CLIP 1
954-882804-00 HIGH VOLTAGE CABLE SPACER 2
FOR FBT.

3203

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

180-820BT0-27-05 NON-COM PART ASS'Y PAL BG W/FRONT AV-ST. –

IN/SCART (PHILIPS 40P)"TEAC"
107-105500-66 SOUND TRAP CERAMIC FILTER 5.5MHZ WEI HAW 1
CF103
107-305500-16 SOUND BYPASS CERAMIC FILTER 5.5MHZ WEI HAW 1
CF102
107-731500-00 SAW FILTER TSB-5308U (SANYO) 1
SA102
107-738916-00 SAW FILTER TSF-5316 SANYO 1
SA101
113-153105-17 CARBON FILM RESISTOR 15K OHM 1/4W +-5% 2
R116,610
113-223101-67 METAL FILM RESISTOR 22K OHM 1/4W +-1% 1
R606
133-102411-31 I.C. ST24C01B1 SGS 1
IC602
172-726000-99 BARE WIRE 54MM 0
CN206 `1' TO `2',`4' TO `5'
186-624500-11 HI-WATT SUPER HEAVY DUTY 1.5V 0% MERCURY 3A ER03X 2
ALUM.CASE
515-303408-10 SELF-TAPPING SCREW 3 X 8 W/B/T (HARDEN) 1
AV BOARD TO FRONT CABINET(WHEN LENS W/AV HOLES)
610-942101-0W GIFT BOX - TEAC DESIGN (CT-M4828) 1
663-230296-98 SERIAL NO.LABEL - OC:GT-296/98 2
1-STUCK ON CTN.,1-STUCK ON RATING LABEL
669-820B01-06 RATING LABEL - TEAC (B) DESIGN (CT-M4828) 1
670-820B00-08 I/MANUAL - TEAC (A) DESIGN (CT-M4828) 1
678-820B01-01 SCREEN STICKER - TEAC DESIGN (CT-M4828) 1
678-821B02-02 CB NO.LABEL(I)-TEAC (A) DESIGN (CT-M5128TXT)(LARGE 2
STUCK ON EACH CARTON
SIZE)
678-825B02-01 EASY TUNE CARD (A1) - TEAC DESIGN 1
678-931315-07 TOTAL CARE LAEBL - TEAC (B) DESIGN 1
690-942039-02 WARRANTY CARD -TEAC (C) DESIGN 1
693-820B01-01 EAN CODE LABEL - 9313060009458 1
703-821B11-03 SPK.GRILLE - METALLIC GREY (8403C) 0.5MM THK í1.0 2
HOLE
710-942102-01 NAME PLATE - TEAC (B) DESIGN (ELECTROFORMED) 1
800-821B11-00 POLYFOAM (B) - TOP LEFT 1
800-821B12-00 POLYFOAM (B) - TOP RIGHT 1
800-821B13-00 POLYFOAM (B) - BOTTOM LEFT 1
800-821B14-00 POLYFOAM (B) - BOTTOM RIGHT 1
810-404004-62 POLYBAG 40"X40"X0.04MM W/PUNCH [TEAC DESIGN 1
TEAC REQUEST
(CT-M4895)]
826-302005-00 FOAM SHEET 30" X 20" X 0.5MM THK. 1
FOR TOP UNIT
884-882020-02 JACK COVER-TEAC DESIGN WHI SS. W/21 PIN SOCKET 1
(HIGH JACK)

4204

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

900-820B01-02 FRONT CABINET (B) - METALLIC GREY (8403C) 1
917-821B11-08 FUNCTION LENS -TEAC (A) DESIGN (CT-M4828) W/CLEAR 1
FUNCTION
977-821B01-00 FUNCTION KNOB (FOR AUTO TUNNING FUNCTION) 1
977-821B02-00 FUNCTION KNOB (FOR VOLUME CHANNEL FUNCTION) 1
991-821B01-01 POWER KNOB - METALLIC GREY (8403C) 1
002-120001-46 CRT20" A48KRD82X09/A48KRD89X09 (SOUTH HEMISPHERE 1
#CRT
CRT) SAMSUNG
002-120006-48 20" CRT #A48QAD220X06(S) S/H (AUSTRALIA) 0
#CRT REF:(GTVM96-021)
"GOLDSTAR"
002-120027-42 20" CRT (S/H) DY # ODY-M2038 (ORION) "A48JLL92X27" 0
#CRT REF:(GTVM96-021)
003-131372-07 TUNER OSCAR 2900KKC 3X1 772 "TELEFUNKEN" (HIGH 1
#TUNER
JACK)
003-131769-07 TUNER HYPER BAND (3300 KHC 3 X 5 569)"TELEFUNKEN" 0
#TUNER REF:(GTSS-772)
(HIGH JACK)
171-550084-00 7' AC LINE CORD W/7.5A PLUG (DOUB.INSULATION)2 PIN 0
#
SAA APP
171-550084-B0 7" SAA APP LINE CORD 2-PIN PLUG 0
171-550084-D0 84" AC LINE CORD W/SAA APP. 10A 250V 1
171-550084-D1 7' SAA APP. LINE CORD W/PLUG E-CUTTING 45MM,15MM 0
PVC HOLDER
902-942111-U4 BACK CABINET - METALLIC GREY (8403C) (UL) 1

5205

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

180-820BT0-27-CP COMMON PART ASS'Y PAL BG W/FRONT AV-ST.-

IN/SCART (PHILIPS 40P)
012-102340-06 SEMI-FIXED RESISTOR EVND8AA 03B13 1KB 2
VR401,901
012-103340-06 SEMI-FIXED RESISTOR EVND8AA 03B14 10KB 1
VR103
012-104340-06 SEMI-FIXED RESISTOR EVND8AA 03B15 100KB 1
VR101
012-301330-06 SEMI-FIXED RESISTOR EVND2AA 03B32 300B 2
VR503,505
012-501340-06 SEMI-FIXED RESISTOR EVND 8AA 03B52 500B 1
VR302
012-502330-06 SEMI-FIXED RESISTOR EVND2AA 03B53 5KB 3
VR502,504,501
012-503340-06 SEMI-FIXED RESISTOR EVND8AA 03B54 50KB 2
VR102,301
013-100001-03 GLASS DELAY LINE YTS-8B WITTIS 1
DLY302
013-200005-00 Y-DELAY LINE YBL50F18X 1
DLY301
101-191005-96 HORIZONTAL DRIVE TRANSFORMER R1005 1
T401
101-288820-95 LINE FILTER 70MH 1
L901
102-370600-02 TANK COIL / AFC COIL COILS 707851 2
T101,103
102-671300-02 SOUND IF COIL. COILS 710256 1
T104
102-770200-02 SECAM COLOR PAL DELAY LINE MATCHING COILS 707850 1
T301
105-100103-08 FIXED INDUCTOR COIL 10 UH +-10% AXIAL 1
L601
105-100103-08 FIXED INDUCTOR COIL 10 UH +-10% AXIAL 1
L102
105-150103-08 FIXED INDUCTOR COIL 15 UH +-5% AXIAL 1
L104
105-181103-08 FIXED INDUCTOR COIL 180 UH +-10% AXIAL 1
L501
105-201106-06 CHOKE COIL 200UH HIGHLIGHT 1
L903
105-479103-08 FIXED INDUCTIVE COIL 4.7 UH 1
L60A
105-560103-08 FIXED INDUCTIVE COIL 56 UH +-10% AXIAL 1
L305
105-650152-13 LINEARITY COIL 65UH "LI TONE" 1
L401
105-689103-08 FIXED INDUCTOR COIL 6.8 UH +-10% AXIAL 1
L103

6206

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

105-828103-08 FIXED INDUCTIVE COIL 0.82 UH +-10% AXIAL 1
L101
105-829103-08 FIXED CONDUCTOR COIL 8.2 UH +-10% AXIAL 3
L301,302,303
105-829103-08 FIXED CONDUCTOR COIL 8.2 UH +-10% AXIAL 1
L304
113-100105-17 CARBON FILM RESISTOR 10 OHM 1/4W +-5% 4
R601,119,108,140
113-101105-17 CARBON FILM RESISTOR 100 OHM 1/4W +-5% 6
R624,625,650,643,644,638
113-101105-17 CARBON FILM RESISTOR 100 OHM 1/4W +-5% 8
R317,318,319,322,326,336,337,338
113-101305-75 METAL OXIDE FILM RESISTOR 100 OHM 1W +-5% 1
R130
113-102105-17 CARBON FILM RESISTOR 1K OHM 1/4W +-5% 9
R921,329,352,331,402,107,126,325,330
113-102105-17 CARBON FILM RESISTOR 1K OHM 1/4W +-5% 10
R619,617,607,608,618,620,621,634,637,641
113-102105-17 CARBON FILM RESISTOR 1K OHM 1/4W +-5% 7
R109,143,153,320,302,328,157
113-102305-75 METAL OXIDE FILM RESISTOR 1K OHM 1W +-5% 1
R414
113-103101-67 METAL FILM RESISTOR 10K OHM 1/4W +-1% 1
R609
113-103105-17 CARBON FILM RESISTOR 10K OHM 1/4W +-5% 11
R612,623,635,649,632,103,110,113,104,339,154
113-103105-17 CARBON FILM RESISTOR 10K OHM 1/4W +-5% 11
R303,304,315,354,407,908,403,321,927
113-103405-75 METAL OXIDE FILM RESISTOR 10K OHM 2W +-5% 1
R137
113-104105-17 CARBON FILM RESISTOR 100K OHM 1/4W +-5% 3
R136,355,202
113-104205-12 CARBON FILM RESISTOR 100K OHM 1/2W +-5% 1
R920
113-104305-75 METAL OXIDE FILM RESISTOR 100K OHM 1W +-5% 1
R925
113-105105-17 CARBON FILM RESISTOR 1M OHM 1/4W +-5% 1
R138
113-120305-75 METAL OXIDE FILM RESISTOR 12 OHM 1W +-5% 1
R911
113-120405-75 METAL OXIDE FILM RESISTOR 12 OHM 2W +-5% 1
R924
113-122105-17 CARBON FILM RESISTOR 1.2K OHM 1/4W +-5% 6
R122,323,602,205,207,372
113-123105-17 CARBON FILM RESISTOR 12K OHM 1/4W +-5% 3
R132,616,605
113-152105-17 CARBON FILM RESISTOR 1.5K OHM 1/4W +-5% 2
R150,152

7207

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

113-153105-17 CARBON FILM RESISTOR 15K OHM 1/4W +-5% 2
R604,401
113-153405-75 METAL OXIDE FILM RESISTOR 15K OHM 2W +-5% 3
R510,511,505
113-154105-17 CARBON FILM RESISTOR 150K OHM 1/4W +-5% 1
R133
113-154205-12 CARBON FILM RESISTOR 150K OHM 1/2W +-5% 1
R421
113-158405-75 METAL OXIDE FILM RESISTOR 0.15 OHM 2W +-5% 1
R914
113-159305-75 METAL OXIDE FILM RESISTOR 1.5 OHM 1W +-5% 1
R410
113-159405-42 NON-FLAMMABLE FUSE RESISTOR 1.5 OHM 2W +-5% 1
R501
113-181105-17 CARBON FILM RESISTOR 180 OHM 1/4W +-5% 2
R135,340
113-182105-17 CARBON FILM RESISTOR 1.8K OHM 1/4W +-5% 8
R907,628,629,630,631,148,335,334
113-182105-17 CARBON FILM RESISTOR 1.8K OHM 1/4W +-5% 1
R425
113-183105-17 CARBON FILM RESISTOR 18K OHM 1/4W +-5% 2
R408,615
113-184105-17 CARBON FILM RESISTOR 180K OHM 1/4W +-5% 2
R151,156
113-202605-75 METAL OXIDE FILM RESISTOR 2K OHM 5W +-5% 1
R416
113-221105-17 CARBON FILM RESISTOR 220 OHM 1/4W +-5% 3
R411,112,106
113-221305-75 METAL OXIDE FILM RESISTOR 220 OHM 1W +-5% 1
R413
113-222101-67 METAL FILM RESISTOR 2.2K OHM 1/4W +-1% 1
R146
113-222105-17 CARBON FILM RESISTOR 2.2K OHM 1/4W +-5% 7
R507,509,513,141,652,332,201
113-223105-17 CARBON FILM RESISTOR 22K OHM 1/4W +-5% 9
R646,129,417,655,406,208,209,346,111
113-224105-17 CARBON FILM RESISTOR 220K OHM 1/4W +-5% 1
R653
113-229105-17 CARBON FILM RESISTOR 2.2 OHM 1/4W +-5% 3
R125,342,327
113-229205-12 CARBON FILM RESISTOR 2.2 OHM 1/2W +-5% 2
R139,351
113-229405-75 METAL OXIDE FILM RESISTOR 2.2 OHM 2W +-5% 1
R902
113-229605-51 WIRE WOUND CEMENT RESISTOR 2.2 OHM 5W +-5% 1
R901
113-270105-17 CARBON FILM RESISTOR 27 OHM 1/4W +-5% 1
R115

8208

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

113-270405-75 METAL OXIDE FILM RESISTOR 27 OHM 2W +-5% 1
R912
113-271105-17 CARBON FILM RESISTOR 270 OHM 1/4W +-5% 4
R147,636,639,642
113-272105-17 CARBON FILM RESISTOR 2.7K OHM 1/4W +-5% 1
R142
113-272205-12 CARBON FILM RESISTOR 2.7K OHM 1/2W +-5% 6
R502,503,504,922,415,409
113-273105-17 CARBON FILM RESISTOR 27K OHM 1/4W +-5% 2
R155,603
113-279405-49 FUSING RESISTOR 2.7 OHM 2W +-5% "KOA" 1
R422
113-330105-17 CARBON FILM RESISTOR 33 OHM 1/4W +-5% 1
R928
113-331105-17 CARBON FILM RESISTOR 330 OHM 1/4W +-5% 4
R905,343,344,353
113-332102-17 CARBON FILM RESISTOR 3.3K OHM 1/4W +-2% 1
R904
113-332105-17 CARBON FILM RESISTOR 3.3K OHM 1/4W +-5% 3
R611,645,647
113-333105-17 CARBON FILM RESISTOR 33K OHM 1/4W +-5% 5
R118,127,114,117,144
113-334105-17 CARBON FILM RESISTOR 330K OHM 1/4W +-5% 1
R131
113-334305-75 METAL OXIDE FILM RESISTOR 330K OHM 1W +-5% 1
R913
113-390505-75 METAL OXIDE FILM RESISTOR 39 OHM 3W +-5% 1
R926
113-390605-75 METAL OXIDE FILM RESISTOR 39 OHM 5W +-5% 1
R915
113-391105-17 CARBON FILM RESISTOR 390 OHM 1/4W +-5% 4
R506,508,347,934
113-392105-17 CARBON FILM RESISTOR 3.9K OHM 1/4W +-5% 2
R404,633
113-393105-17 CARBON FILM RESISTOR 39K OHM 1/4W +-5% 2
R316,614
113-470105-17 CARBON FILM RESISTOR 47 OHM 1/4W +-5% 4
R933,204,206,613
113-471105-17 CARBON FILM RESISTOR 470 OHM 1/4W +-5% 2
R412,123
113-472105-17 CARBON FILM RESISTOR 4.7K OHM 1/4W +-5% 5
R910,149,120,158,159
113-473105-17 CARBON FILM RESISTOR 47K OHM 1/4W +-5% 6
R622,648,651,301,405,R603A
113-475105-17 CARBON FILM RESISTOR 4.7M OHM 1/4W +-5% 1
FOR IC305 10 PIN TO GND
113-479105-17 CARBON FILM RESISTOR 4.7 OHM 1/4W +-5% 2
R210,211

9209

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

113-511105-17 CARBON FILM RESISTOR 510 OHM 1/4W +-5% 1
R512
113-562105-17 CARBON FILM RESISTOR 5.6K OHM 1/4W +-5% 3
R105,324,357
113-629505-75 METAL OXIDE FILM RESISTOR 6.2 OHM 3W +-5% 1
R203
113-681105-17 CARBON FILM RESISTOR 680 OHM 1/4W +-5% 1
R654
113-682102-17 CARBON FILM RESISTOR 6.8K OHM 1/4W +-2% 1
R903
113-682105-17 CARBON FILM RESISTOR 6.8K OHM 1/4W +-5% 3
R909,419,349
113-750105-17 CARBON FILM RESISTOR 75 OHM 1/4W +-5% 4
R929,930,931,932
113-820105-17 CARBON FILM RESISTOR 82 OHM 1/4W +-5% 2
R418,101
113-821105-17 CARBON FILM RESISTOR 820 OHM 1/4W +-5% 1
R350
113-822105-17 CARBON FILM RESISTOR 8.2K OHM 1/4W +-5% 4
R906,923,420,626
113-823105-17 CARBON FILM RESISTOR 82K OHM 1/4W +-5% 2
R145,341
113-824105-17 CARBON FILM RESISTOR 820K OHM 1/4W +-5% 1
R180
123-101350-60 CERAMIC CAP. 100 PF 50V +-10% (SL TYPE) "SMART 1
C612
GOOD"
123-102350-90 CERAMIC CAP. 0.001 MFD 50V +-10% (B TYPE) 3
C138,614,103
123-102850-10 CERAMIC CAP. 0.001 MFD 2KV +-10% MATSUSHITA 1
C501
123-103370-90 CERAMIC CAP. 0.01 MFD 50V +80 -20% 8
C102,117,126,333,334,330,147,118
123-103370-90 CERAMIC CAP. 0.01 MFD 50V +80 -20% 1
C352
123-104270-90 CERAMIC CAP. 0.1 MFD 25V +80 -20% 8
C623,123,139,306,309,307,101,338
123-122551-90 CERAMIC CAP. 0.0012 MFD 500V +-10% (B TYPE) 1
C415
MATSUSHITA
123-150340-93 CERAMIC CAP. 15 PF 50V +-5% (NPO) 1
CT301
123-151350-60 CERAMIC CAP 150 PF 50V +-10% (SL TYPE) 1
C137
123-182850-10 CERAMIC CAP. 0.0018 MFD 2KV +-10% MATSUSHITA 1
C419
123-200340-93 CERAMIC CAP. 20PF 50V +-5% (NPO) 1
C345

102010

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

123-220340-60 CERAMIC CAP. 22 PF 50V +-5% (SL TYPE) 4
C616,617,618,620
123-221350-60 CERAMIC CAP. 220 PF 50V +-10% (SL TYPE) 3
C503,504,502
123-221551-90 CERAMIC CAP. 220 PF 500V +-10% MATSUSHITA 1
C916
123-222850-10 CERAMIC CAP. 0.0022 MFD 2KV +-10% MATSUSHITA 1
C911
123-223370-90 CERAMIC CAP. 0.022 MFD 50V +80 -20% 11
C109,131,124,122,128,129,135,331,332,343,335
123-223370-90 CERAMIC CAP. 0.022 MFD 50V +80 -20% 3
C344,105,127
123-270340-60 CERAMIC CAP. 27 PF 50V +-5% (SL-TYPE) 1
C114
123-270340-93 CERAMIC CAP. 27PF 50V +-5% (NPO) 2
C613,628
123-390340-93 CERAMIC CAP. 39PF 50V +-5% (NPO) 2
C630,C1
123-470340-60 CERAMIC CAP. 47 PF 50V +-5% (SL TYPE) 1
C347
123-472350-90 CERAMIC CAP. 0.0047 MFD 50V +-10% (B TYPE) 2
C918,920
123-472550-90 CERAMIC CAP. 0.0047 MFD 500V +-10% (B TYPE) 3
C913,413,423
123-472552-90 CERAMIC CAP. 0.0047 MFD 500V +-10% (B TYPE) SMALL 3
C903,904,907
SIZE
123-681350-90 CERAMIC CAP. 680 PF 50V +-10% (B TYPE) 1
C407
123-821850-10 CERAMIC CAP. 820 PF 2KV +-10% (SL TYPE) MATSUSHITA 1
C914
125-391120-11 POLYSTYRENE CAP. 390 PF 125V +-5% 1
C149
126-102071-01 MYLAR CAP. 0.001 MFD 50V +-10% 3
C130,402,412
126-104071-01 MYLAR CAP. 0.1 MFD 50V +-10% 10
C602,908,304,305,308,310,324,325,326,133
126-104071-01 MYLAR CAP. 0.1 MFD 50V +-10% 3
C409,214,216
126-104101-31 POLYPROPYLENE CAP. 0.1 MFD 100V +-10% 1
C425
126-222071-01 MYLAR CAP. 0.0022 MFD 50V +-10% 2
C610,624
126-222161-41 METALIZED POLYROPLENE CAP. 0.0022 MFD 1600V +-10% 1
C420
126-223071-01 MYLAR CAP. 0.022 MFD 50V +-10% 5
C321,322,323,207,208
126-224071-01 MYLAR CAP 0.22 MFD 50V +-10% 2
C140,348

112011

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

126-224071-01 MYLAR CAP 0.22 MFD 50V +-10% 2
C603,115
126-272070-31 POLYPROPYLENE CAP. 0.0027 MFD 50V +-5% 1
C141
126-332161-41 METALIZED POLYPROPYLENE CAP. 0.0033 MFD 1600V 1
C418
+-10%
126-333071-01 MYLAR CAP. 0.033 MFD 50V +-10% 1
C906
126-334071-01 MYLAR CAP. 0.33 MFD 50V +-10% 2
C143,145
126-472071-01 MYLAR CAP. 0.0047 MFD 50V +-10% 2
C403,405
126-473071-01 MYLAR CAP. 0.047 MFD 50V +-10% 2
C134,346
126-474201-31 POLYPROPYLENE CAP 0.47 MFD 200V +-10% 1
C414
126-563071-01 MYLAR CAP. 0.056 MFD 50V +-10% 1
C148
127-105072-03 ELECT. CAP. 1 MFD 50V +-20% 5
C107,142,341,350,132
127-105072-23 ELECT. CAP. BIPOLAR 1 MFD 50V +-20% 2
FOR R348,R345
127-105132-03 ELECT. CAP. 1 MFD 160V +-20% 1
C416
127-106042-03 ELECT. CAP. 10 MFD 16V +-20% 9
C202,627,621,601,615,619,626,622,351
127-106042-03 ELECT. CAP. 10 MFD 16V +-20% 11
C203,312,328,329,327,316,317,315,340,314,318
127-106104-03 ELECT CAP. 10 MFD 100V +-20% 105øC 1
C910
127-107042-03 ELECT. CAP. 100 MFD 16V +-20% 6
C125,119,625,209,210,311
127-107062-03 ELECT. CAP. 100 MFD 35V +-20% 2
C201,408
127-107132-03 ELECT. CAP. 100 MFD 160V +-20% "NICHICON" 1
C417
127-108042-03 ELECT. CAP. 1000 MFD 16V +-20% 1
C421
127-108052-03 ELECT. CAP. 1000 MFD 25V +-20% 1
C217
127-157402-03 ELECT. CAP. 150 MFD 400V +-20% (25 x 30MM) 1
C905
127-225072-03 ELECT. CAP 2.2 MFD 50V +-20% 5
C106,108,111,113,116
127-226042-03 ELECT. CAP. 22 MFD 16V +-20% 1
C609
127-227042-03 ELECT. CAP. 220 MFD 16V +-20% 3
C320,121,205

122012

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

127-227062-03 ELECT. CAP. 220 MFD 35V +-20% 3
C917,410,411
127-228052-03 ELECT. CAP. 2200 MFD 25V +-20% 1
C406
127-228052-03 ELECT. CAP. 2200 MFD 25V +-20% 1
C422
127-335071-05 ELECT CAP. 3.3UF 50V +-10% (TIME CONSTANT) 1
C404
127-336042-03 ELECT. CAP. 33 MFD 16V +-20% 2
C144,921
127-336252-03 ELECT CAP. 33 MFD 250V +-20% 1
C424
127-474072-03 ELECT. CAP. 0.47 MFD 50V +-20% 1
C342
127-475072-03 ELECT CAP 4.7 MFD 50V 7
C607,608,604,136,337,211,212
127-476042-03 ELECT. CAP. 47 MFD 16V +-20% 3
C401,204,206
127-476094-07 ELECT CAP. 47 MFD 63V +-20% 105øC "NICHICON" 1
C909
127-476132-03 ELECT. CAP. 47 MFD 160V +-20% 1
C915
127-477042-03 ELECT. CAP. 470 MFD 16V +-20% 6
C146,922,120,313,336,919
127-477042-03 ELECT. CAP. 470 MFD 16V +-20% 2
C213,215
130-134148-01 SILICON DIODE IN4148 6
D406,301,302,303,604,60A
130-134148-01 SILICON DIODE IN4148 12
D601,602,606,607,608,609,610,611,603,103,104,105
130-240809-50 VERIABLE CAPACITANCE DIODE BB809 2
D102,101
130-310206-04 BRIDGE RECIFIER KBP206 "HIGHLAND" 1
BR901
130-311541-60 RECTIFIER DOIDE 1R5JU41 1
D904
130-311545-60 RECTIFIER DIODE 1R5JH45 1
D404
130-311545-60 RECTIFIER DIODE 1R5JH45 1
D905
130-315295-00 RECTIFIER DIODE S5295G TOSHIBA 9
D902,903,901,401,402,403,405,D90A,90B
130-410051-01 ZENER DIODE 5.1V 1/2W +-5% 1
ZD102
130-410082-01 ZENER DIODE 8.2V 1
ZD901
130-410100-01 ZENER DIODE 10V 1/2W 1
ZD401

132013

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

130-410574-00 ZENER DIODE UPC 574J NEC 1
ZD101
130-411091-01 ZENER DIODE 9.1V 1
ZD902
130-422120-00 ZENER DIODE 1W 12V 1
ZD402
130-512044-00 LED 3MM RED 204HDC 1
LED601
131-211013-18 TRANSISTOR 2SA1013 (R) TOSHIBA 1
Q906
131-211015-00 TRANSISTOR 2SA1015 TOSHIBA 4
Q101,102,108,303
131-220774-0A TRANSISTOR 2SB774/Q/R/S MATSUSHITA 1
Q902
131-231809-0A TRANSISTOR 2SC1809 ROHM 1
Q105
131-231815-0A TRANSISTOR 2SC1815 TOSHIBA 6
Q103,107,901,903,602,302
131-231815-0A TRANSISTOR 2SC1815 TOSHIBA 5
Q603,604,605,106,109
131-232230-00 NPN-TR 2SC2230A-Y (TOSHI) TO92 VCE=180V IC=.1A 1
Q905
HFE=120-240
131-232335-30 TRANSISTOR 2SC2335 L/K NEC 1
Q907
131-232482-0A TRANSISTOR 2SC2482 TOSHIBA 4
Q401,501,502,503
131-241761-00 TRANSISTOR 2SD1761(E) ROHM 1
Q201
131-242498-13 TRANSISTOR 2SD2498(M) TOSHIBA 1
Q904
131-242499-13 TRANSISTOR 2SD2499(M) TOSHIBA 1
Q402
131-462369-0A TRANSISTOR PH2369 PHILIPS 1
Q601
133-103221-33 IC CTV322SV2.0/PCA84C641P/068 PHILIPS 1
IC601
133-103504-33 I.C. TDA3504 PHILIPS 1
IC304
133-103857-33 IC TDA3857 PHILIPS 1
IC101
133-104505-33 I.C. TDA4505E PHILIPS 1
IC102
133-104510-33 PHILIPS IC TDA4510 1
IC305
133-108628-14 IC TA8628N TOSHIBA 1
IC303
133-203653-33 I.C. TDA3653B PHILIPS 1
IC401

142014

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

133-204445-16 I.C. LA4445 (SANYO) 1
IC201
133-207812-31 IC L7812CV SGS-THOMSON 1
IC103
133-305114-31 I.C. TEA5114A SGS 1
IC302
133-517805-61 I.C. KA7805 SAMSUNG 1
IC901
136-504231-00 REMOTE CONTROL RECEIVER SPS-423-1G SANYO 1
OPT601
137-100000-31 CRYSTAL 10 MHZ HOORAY 1
X601
137-886723-20 CRYSTAL 8.86 MHz KDS 1
X301
146-104112-01 TACT SWITCH 4 PIN L=8.35 100G #1102VC-4 4
S610,611,613,614
"PROMOTION"
146-104112-03 TACT SWITCH 4 PIN L=3.85MM 100G #1102VA-4 3
S601,606,607
"PROMOTION"
160-101001-08 PIN CONNECTOR 1 PIN PLUG STRAIGHT 3
1-FOR CN501,2-FOR (X),(Y)
160-102255-27 PIN CONNECTOR 2 PINS PLUG STRAIGHT (UL) (S.H.S) 3
CN201,905,906
160-102805-08 PIN CONNECTOR 2 PIN PLUG STRAIGHT 1
CN903
160-103255-27 PIN CONNECTOR 3 PINS PLUG 3
CN202,904,907
160-103805-08 PIN CONNECTOR 3 PIN PLUG STRAIGHT 1
CN402
160-104805-08 PIN CONNECTOR 4 PIN PLUG STRAIGHT 1
CN401
160-105255-27 PIN CONNECTOR 5 PINS WAFER 2.5 PITCH 1
CN203
161-471002-02 RAC JACK 3 PIN BLACK #UIC-032-04AB "CHINA 1
J009
LANDMARK"
161-473003-00 RCA JACK 3 PIN YELLOW SC-8.4-6A "HONG YIP" 1
J007
161-473204-00 RCA JACK 3 PIN UIC-032-04AR RED "UNITRONIC" 1
J008
161-682102-22 21 PIN SCART SOCKET 1
J901
166-463023-4E SPEAKER 2" X 3-1/2" 16 OHM 3W K.T. 2
172-620007-40 UL 1007 TOP COAT WIRE #20 70MM BLACK 5 X 5 MM 2
1 FOR MAIN PCB `Q' TO `Q',1 FOR IC401 GND TO GND
172-620012-40 UL 1007 TOP COAT WIRE AWG 20 120MM BLACK 10 X 10 1
MIAN P.C.B. `J' TO `J'
MM

152015

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

172-620014-40 UL 1007 TOP COAT WIRE AWG 20 140MM BLACK 10 X 10 1
MAIN P.C.B. `E' TO `E'
MM
172-620016-40 UL 1007 TOP COAT WIRE AWG 20 160MM BLACK 10 X 10 1
MAIN P.C.B. `9B' TO `9B'
MM
172-622004-40 UL 1007 TOP COAT WIRE #22 40MM BLACK 5 X 5 MM 1
FOR CRT SOCKET PIN 12 TO GND
172-626006-42 UL 1007 TOP COAT WIRE AWG 26 60MM RED 10 X 10 MM 1
MAIN PCB `9A' TO `9A'
172-626008-40 UL 1007 TOP COAT WIRE AWG 26 80MM BLACK 10 X 10 MM 3
Q904 LUG TO MAIN PCB `L',IC401 LUG TO MAIN PCB `M'
172-626008-40 UL 1007 TOP COAT WIRE AWG 26 80MM BLACK 10 X 10 MM 0
Q402 LUG TO MAIN P.C.B. `K'
172-626012-44 UL 1007 TOP COAT WIRE AWG 26 120MM YELLOW 10 X 10 1
MAIN P.C.B. `F' TO `F'
MM
172-626014-40 UL 1007 TOP COAT WIRE AWG 26 140MM BLACK 10 X 10 1
`A2' TO `A2'
MM
172-626014-42 UL 1007 TOP COAT WIRE AWG 26 140MM RED 10 X 10 MM 3
`2'TO`2',C110 `+' TO CN303`1',R134`R' TO CN303 `3'
172-626022-45 UL 1007 TOP COAT WIRE AWG 26 220MM PINK 10 X 10 MM 1
MAIN P.C.B. `N' TO `N'
172-626022-46 UL 1007 TOP COAT WIRE AWG 26 220MM BLUE 10 X 10 MM 2
MAIN P.C.B. `P' TO `P',`I' TO `I'
172-726000-99 BARE WIRE 54MM 5
W001-005,007-035,037-072,074-076,079-083,085-087
172-726000-99 BARE WIRE 54MM 0
W901,091-093,096,CN306`1' TO `3',CN304`2' TO `3'
172-726000-99 BARE WIRE 54MM 0
FOR TH902,IC301 PIN (2-3,4-5,6-7,8-9)
172-726000-99 BARE WIRE 54MM 0
W1,W2,R306,R308,R309,R311,CN302 PIN 1-3
172-726000-99 BARE WIRE 54MM 0
W077-078,WA01,W00B(ON AV P.C.B.),`H4' TO `H5'
172-830120-99 FLAT BRIDED WIRE 1
CRT GROUND
173-622014-30 SINGLE SHIELD WIRE AWG 26 140MM BLACK 1
MAIN P.C.B. `O' TO `O'
174-611017-50 DOUBLE SHIELD WIRE AWG 26 180MM BLACK 1
MAIN P.C.B. `A.B' TO `A.B'
177-655053-02 2 PIN FLAT CABLE WIRE AWG 26 50MM 1
MAIN P.C.B. `C.D' TO `C.D.'
179-001010-00 OIL SLEEVING 1 mm DIA. 0
50MM FOR `N' TO `N',20MM FOR R926,10MM FOR C404
179-001010-00 OIL SLEEVING 1 mm DIA. 0
L=90MM,20MM FOR D904,20MM FOR BR901,10MM FOR C149

162016

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

179-001010-00 OIL SLEEVING 1 mm DIA. 0
20MM FOR R349,10MM FOR C425,10MM FOR C120
179-001010-00 OIL SLEEVING 1 mm DIA. 0
10MM FOR C1,20MM FOR R501
179-001020-00 OIL SLEEVING 2MM DIA. 0
60MM FOR `9A' TO `9A'
179-105000-00 UL PVC TUBE 5mm DIA 0
120MM FOR AC LINE CORD,120MM FOR PW.SW.(X)(Y)
179-105000-00 UL PVC TUBE 5mm DIA 0
L=950mm, 400mm FOR SPK `L', 550mm FOR SPK `R'
179-107300-00 UL PVC TUBE 7.3MM DIA. 0
250MM FOR (X)(Y),300MM FOR CN904-CN907
179-110500-00 UL PVC TUBE 11MM DIA. 0
L=50MM FOR AC LINE CORD
179-405030-00 5 mm DIA SHRINKABLE TUBE 0
60MM FOR AC LINE CORD,60MM FOR PW.SW.(X)(Y) WIRE
190-821B01-08 FRONT AV STEREO IN P.C.B. (081297) 1
190-882004-00 P.C. BOARD CRT (150395) 1
190-942002-01 MAIN P.C.B. BOARD (300798) L/SENSOR,R/LED 1
191-100030-09 1 PIN SOCKET ASSM'Y L=300MM 1
CRT GND TO CN501
191-200044-09 2 PIN SOCKET ASSM'Y L=440MM 1
CN201 `2' TO SPEAKER L `-', `1' TO SPEAKER L `+'
191-201011-07 2 PIN SOCKET ASSM'Y L=440MM 1
CN905 `1' TO FRONT AV P.C.B. `A',`2' TO `B'
191-201040-07 2 PIN SOCKET ASS'Y L=450MM #26 UL1185 W/SHIELDING 1
CN906 `1' TO FRONT AV P.C.B.`D',`2' TO `C'
CABLE
191-300040-09 3 PIN SOCKET ASSM'Y (PIN 1 L= 460MM, PIN 2,3 1
CN402 `1' TO CRT PCB `J'
L=400MM)
191-300040-09 3 PIN SOCKET ASSM'Y (PIN 1 L= 460MM, PIN 2,3 0
CN402 `2' TO CRT PCB `I'
L=400MM)
191-300040-09 3 PIN SOCKET ASSM'Y (PIN 1 L= 460MM, PIN 2,3 0
CN402 `3' TO CRT PCB `H'
L=400MM)
191-301005-07 3 PINS SOCKET ASS'Y (2 WIRE) L=560MM 1
CN202 `2' TO SPEAKER R `-',`1' TO SPEAKER R `+'
191-301052-07 3 PIN L=450MM W/SHIELD CABLE #26 UL1007 (GND,WHITE, 1
CN907 `1' TO FRONT AV P.C.B.`J',`2'TO`I',`3'TO`F'
RED)
191-301053-07 3 PIN L=450MM W/SHIELD CABLE #26 UL2547 (RED,WHITE 1
CN904`1' TO FRONT AV P.C.B.`E',`2'TO`H',`3'TO`G'
GND)
191-500048-09 5 PIN SOCKET ASSM'Y L=480MM 1
CN203 `1' TO CRT PCB `A'
191-500048-09 5 PIN SOCKET ASSM'Y L=480MM 0
CN203 `2' TO CRT PCB `B'

172017

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

191-500048-09 5 PIN SOCKET ASSM'Y L=480MM 0
CN203 `3' TO CRT PCB `C'
191-500048-09 5 PIN SOCKET ASSM'Y L=480MM 0
CN203 `4' TO CRT PCB `D'
191-500048-09 5 PIN SOCKET ASSM'Y L=480MM 0
CN203 `5' TO CRT PCB `E'
504-305006-10 MACHINE SCREW 3 X 6 B/M (WHITE) 4
1 FOR IC901,2 FOR IC201, 1 FOR IC103
517-303312-10 SELF-TAPPING SCREW 3 X 12 W/A W/H=7MM (HARDEN) 3
FOR HEAT SINK (A) , (B) & (C)
540-020030-01 EYELET 2 X 3 MM 14
2-L401,2-R414
540-020030-01 EYELET 2 X 3 MM 0
2-R416,1-Q402`C',2-FBT`1',`2',1-Q904`C',4-L901
580-101004-00 STAND OFF TWIST TIE #ST-3 1
FOR 2 DOUBLE INSULATION WIRE
580-101261-01 CABLE TIE L=100MM 21
5-CRT BOARD,2-DY,2-SPK.WIRE,2-FBT,3-PW.SW.
580-101261-01 CABLE TIE L=100MM 0
3-MAIN PCB WIRE,2-CN301,CN302,2-FRONT AV P.C.B.
580-102261-00 CABLE TIE L=200MM W=3.5MM 4
FOR DEGAUSSING COIL MTG.
580-103261-00 CABLE TIE L=300MM W=3.5MM 4
FOR DEGAUSSING COIL MTG.
744-881301-00 SPRING FOR C.R.T. MOUNTING 5.2 X 42 X 0.6MM 1
746-063101-00 TEST PIN:TOTAL LENGTH 18.6mm THK:0.8mm 2
TP104,103
746-063101-01 AC LINE CORD PIN 4
2-AC LINE CORD,2-POWER SWITCH (X)(Y)
750-063101-00 SOLDERING LUG LEG:8X4MM 3
FOR IC401,Q402,Q904
762-932001-00 MOUNTING CLIP 2
FOR TELETEXT BOARD MTG.
766-686801-00 FUSE HOLDER 2
779-921301-00 HEAT SINK FOR NICAM 1
FOR IC901,IC103
779-932902-02 IRON HEAT SINK 1
FOR IC201
781-882001-02 ALUMINIUM HEAT SINK (B) 1
FOR Q402
781-942101-03 HEAT SINK (A) 1
FOR Q904
781-942105-00 HEAT SINK (C) ASS'Y 1
FOR IC401
783-881306-02 SHIELD CAN COVER (OUT DATE) 1
783-881313-01 SHIELD CAN 1
889-942101-00 AV COVER PLATE (UL) 1
FOR FRONT AV PCB

182018

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

001-220027-07 FLYBACK TRANSFORMER FCM20B027 SAMSUNG 1
#T402
001-220501-10 FLYBACK TRANSFORMER JF0501-0502A 0
#T402 REF:(GTVM96-021)
001-220728-05 FLYBACK TRANSFORMER F27728-1/ 154-277V LG=GOLDSTAR 0
#T402 REF:(GTVM96-021)
008-550201-05 DEGAUSSING COIL 60T 44MM X 34 MM (W/FIVE LAYERS OF 1
#L902
TAPE)
101-410214-94 SWITCHING POWER TRANSFORMER KB40C214D (HIGHLIGHT) 1
#T901
113-565210-92 CARBON COMPOSITION RESISTOR 5.6M OHM 1/2W +-10% 2
#R916,917
113-565210-92 CARBON COMPOSITION RESISTOR 5.6M OHM 1/2W +-10% 0
#R916,917
113-688305-42 FUSING RESISTOR 0.68 OHM 1W +-5% 4
#R918,423,424,919
113-688305-49 FUSING RESISTOR 0.68 OHM 1W +-5% "KOA" 0
#R918,919,423,424
114-210200-01 THERMISTOR (NICHICON ZPB53 BL 200C) 1
#TH901
123-222466-41 CERAMIC CAP. 0.0022 MFD 400V +-20% ECK-DNS222MEX 0
#C912
MATSUSHITA
123-222466-45 CERAMIC CAP. 0.0022 MFD 400V +-20% 0
#C912
123-222466-47 CERAMIC CAP. 0.0022 MFD 400VAC +-20% W/IEC384-14 0
#C912
APP. "TDK"
123-222466-50 CERAMIC CAP. 0.0022 MFD 400VAC +-20% ECKDNA222ME 1
#C912
"MATSUSHITA"
123-222466-51 CERAMIC CAP. 0.0022 MFD 400V +-20% W/IEC 384-14 0
#C912
APP. MURATA
126-473222-41 METALIZED POLYPROPYLENE CAP. 0.047 MFD 275V +-20% 1
#C902
"OKAYA"
126-473222-42 METALIZED POLYPROPYLENE CAP. 0.047 MFD 275V +-20% 0
#C902
"TEAPO"
126-474222-41 METALIZED POLYPROPYLENE CAP. 0.47 MFD 275VAC +-20% 1
#C901
"OKAYA"
126-474222-42 METALIZED POLYPROPYLENE CAP. 0.47 MFD 275V +-20% 0
#C901
"TEAPO"
146-100001-14 POWER SWITCH (ESB-99957S COST COST REDUCTION) 0
#S612

192019

MODEL NO: CT-M4828
SYSTEM: PAL BG/FRONT AV-ST. IN/SC.GR(8403C) 240V
SAA(40P)

PART NUMBER DESCRIPTION QTY.

146-100006-14 POWER SWITCH PS5E-B "CHINA LANDMARK" 1
#S612
161-540004-01 CRT SOCKET ISH-01 IN CHANG 1
161-540004-01 CRT SOCKET ISH-01 IN CHANG 0
161-540105-01 CRT SOCKET HPS0199-01-020 (HOSIDEN) 29MM THICK 0
182-223150-13 CERAMIC FUSE 3.15T/250V 5X20MM TIME-LAG 0
#F901
#TDS5053153"BUSSMANN"
182-233150-03 FUSE T3.15A 250V 1
#F901
182-233150-13 FUSE 3.15A/250V 5 X 20MM SLO- BLO #21803.15 0
#F901
LITTELFUSE
191-101016-07 1 PIN DOUBLE INSOLATION WIRE AWG 18 L=340MM BLUE 1
#MAIN P.C.B. `X' TO `X'
191-101016-10 1 PIN DOUBLE INSOLATION WIRE AWG 18 L=340MM BLUE 0
#MAIN P.C.B. `X' TO `X'
191-101017-07 1 PIN DOUBLE INSOLATION WIRE AWG 18 L=340MM BROWN 1
#MAIN P.C.B. `Y' TO `Y'
191-101017-10 1 PIN DOUBLE INSOLATION WIRE AWG 18 L=340MM BROWN 0
#MAIN P.C.B. `Y' TO `Y'

202020
