LED
65EP680
Speci cations of 65EP680
Resolution : 3840x2160
Brightness (cd/m2): 320
Dynamic contrast : Mega
Sound power: 2x10 W
Tuner : DVB-T2/C/S2
Digital connectors : 3 x 2.0b
USB Multimedia Port (HD & SD Video, photo, music) : 2 x 2.0
65EP680
DISPLAY CONTROL
Screen size (inches/cm) 65 / 165.1
Visible screen size : diagonal(inches/cm) 65 / 164
Panel resolution UHD
Wide color Technology Wide Color Gamut
Brightness (cd/m²) 320
HDR (High Dynamic Range) Yes
HDR brightness Picture Performance Index* 1700
Resolution 3840x2160
Curved / Curvature 10 bit panel Yes
Dynamic contrast Mega
Picture processing IPQ 2.0 Engine
Dimming Pro
Ultra AR coating UHD upscaling UHD
Color management UHD Premium Color Extender
Digital Noise Reduction Yes
Film Mode Yes
* Picture performance Index
AUDIO
Sound power 2x10 W
Music sound power 2x20 W
Dolby Dolby AC4
Sound Processing Dolby Atmos
Equaliser Yes
Speaker type Down Firing
Audio quality by Speakers Full range
Digital Pure Sound Woofer Auto volume control Yes
SMART CONTENT
Processor Quad Core
SmartTV AndroidTV & TV+ (29 languages)
Android OS Android P (9.0)
GuideOn (Internet EPG) 4K Netix, YouTube & more
Applications Google Play Store & TV+
Social Yes
Web browser Ye s
HbbTV 2,0
Voice search Built-in
Internal memory 16GB / 10 GB
3D
3D Technology 2D to 3D coversion 3D depth adjustment 3D resolution -
CONVENIENCE
Smartphone / Tablet remote support Yes
USB multimedia* Yes
Caption(Subtitle) Yes
Divx compatibility Clock & On/Off timer Game mode Yes
Sports mode Yes
Picture in Picture Sleep timer Yes
Hotel mode OSD Languages 29
HDMI CEC (T-link) Full
HDMI quick switch Yes
* USB key not included
CONVERGENCE
Bluetooth A2DP, HID
DLNA 1.5 Ye s
Wi display (Miracast) Chromecast & T-cast
USB HID support Yes
Remote control batteries Yes
Remote Control RC802N6+RC802V4
TUNER/BROADCASTING
DTV Tuner DVB-T2/C/S2
Video decoding H.265 UHD, H.264, MPEG-2
Analogue tuner Yes
Analogue tuner systems
CI+ Yes (1.4 ECP)
EPG (DVB EIT/SI) up to 8 days
Auto channel search Yes
Teletext Yes
CONNECTIVITY
HDMI 3 x 2.0b
HDCP 2.2 All HDMIs
USB 2 x 2.0
YPbPr CVBS
DVI-in (video) via HDMI3
Ethernet (LAN RJ-45) Yes
Wi Built-in b/g/n
Digital Audio Out Optical
Headphone Yes
RF in (IEC Terrestial/Cable) 1
RF in (F Sat) 1
Sat: Diseq / SCD Yes v.2.2 / Yes
CI slot 1
HDMI ARC via HDMI 1
HDMI max resolution 2160P/60Hz 12bit
MHL Yes (3.0) via HDMI1
Power cable Detachable, 1.5 m
DESIGN
Color Brushed titanium metal front
Vesa size 600 x 200 mm
Stand type Fixed
POWER
Energy efcency class* A+
Auto power off Yes
Power supply 220-240V~50Hz
Power consumption (standby)* 0,29 W
Power consumption (network standby)* - W
Power consumption (on mode IEC62087 Ed.2)* 120 W
Annual power consumption (EU standard)* 128 kWh
Peak luminance ratio 65%
Power consumption (maximum)* 170 W
Mercury content 0,0 mg
Presence of Lead Yes
*estimation
DIMENSIONS & WEIGHT
Product Size 1445 / 893 / 275 mm
Product size w/o stand 1445 / 838 / 10-34-65-77 mm
Packaging size 1640 / 990 / 190 mm
Product / packaging 20,00 / 26,00 kg
Without stand 18,70 kg
EAN 5901292513085
Manual 29
Incl. 3D glasses -
PAL/SECAM/NTSC (AV) BG/DK/I/LL’
Specications are subject to change without notice. Photos are not contractual.
TCL is a registered trademark.
www.tcl.eu
28/05/2019
