Taylor BiGGEST LOSER, 1037BL Instruction Manual

Thank you for purchasing a Taylor® Kitchen Scale.
Your Taylor® scale is an example of superior design
and craftsmanship. Please read this instruction manual
carefully before use. Keep these instructions handy for
future reference.

For more information on NBC’s The Biggest Loser, or to join
The Biggest Loser Club, please visit the official Biggest Loser
website at www.nbc.com/The_Biggest_Loser.com
or www.biggestloserclub.com. Get a free diet profile at
www.biggestloserclub.com.

Stainless Steel Platform Scale

Plateau De Balance en Acier Inoxydable

Báscula con Plataforma de Acero Inoxidable

Instruction Manual

Manuel d’instructions

Manual de instrucciones

1037BL

1

Leading the Way in Accuracy®

Merci de votre achat d’une balance de cuisine Taylor®.
Votre balance Taylor® est un exemple de design et de
travail supérieurs. Veuillez lire attentivement votre manuel
d’instructions avant d’utiliser l’appareil. Conservez ces
instructions à portée de la main à titre de référence.

Pour obtenir plus d’information sur l’émission de NBC,
«The Biggest Loser», ou pour adhérer au club
«The Biggest Loser Club», veuillez visiter le site Web officiel
à www.nbc.com/The_Biggest_Loser.com ou
www.biggestloserclub.com. Vous pouvez obtenir un profil
de régime gratuit à www.biggestloserclub.com.

Gracias por comprar una báscula de cocina Taylor®. Su
báscula Taylor® es un ejemplo de diseño y mano de obra
superiores. Antes de usarla, sírvase leer con atención este
manual de instrucciones. Guarde estas instrucciones en un
lugar de fácil acceso para referencia futura.

Para obtener más información sobre “The Biggest Loser”
de NBC, o para afiliarse al The Biggest Loser Club, entre en
el sitio Web oficial del Biggest Loser en
www.nbc.com/The_Biggest_Loser.com
o www.biggestloserclub.com. Obtenga un perfil de dieta
gratuito en www.biggestloserclub.com.

2

3

BATTERIES

TO ADD AND WEIGH

AUTO SWITCH OFF

MANUAL SWITCH OFF

TO SWITCH ON

TO MEASURE LIQUIDS AND SOLIDS

2 x AAA (1.5v). Ensure +/- terminals are the correct way
round.

1) If using, place bowl on scale before switching on.

2) Touch ON/ZERO until 8888 appears on display.

3) Wait until display shows 0.

To switch between units press UNIT to scroll through until the
desired unit is reached.
The liquid measure feature is suitable for all water based
liquids, including wine, milk, stock, cream etc.

Note: Oils have a lower specic gravity, which will result in a

volume reading of approx +10%.
If measuring oils by volume on this scale, please adjust for
this accordingly.

To weigh several different ingredients in one bowl, touch
ON/ZERO to reset the display between each ingredient.

Auto switch-off occurs if display shows 0 for 1 minute or
shows the same weight reading for 3 minutes.

To maximize battery life press ON/ZERO for two seconds
after use to switch off.

4

WARNING INDICATORS

Replace batteries Weight Overload Negative Load.
Press ON/ZERO to
return display to zero.

CLEANING AND CARE

1. Clean exposed parts with a soft, slightly damp cloth. To
remove stains, use a mild soap. Never use detergents,
excess water, treated cloths, harsh cleaning agents, or
sprays. Avoid contact with acids, such as citrus juices.

2. Do not tamper with the scale’s internal components. Doing
so will invalidate the warranty on this unit and may cause
damage. The scale contains no user-serviceable parts.

3. Although your scale is designed to be maintenance-free,
it contains sensitive electronic parts. Avoid rough treatment.
Treat it with care to ensure the best performance.

4. This scale is intended for home/consumer use only. It is
not intended for commercial or medical use.

5. This scale is designed to read weights up to 11 lbs/5 kgs.
To prevent damage, do not place more than 11 lbs/5 kgs on it.

6. Do not store scale where you store cleaning chemicals.
The vapors from some household products may affect the
electronic components of your scale. Do not store scale
on its side.
