CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within equilateral triangle, is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
CE Marking Information
WARNING: TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
For U.S.A.
a) Applicable electromagnetic environment: E4
b) The average half-cycle r.m.s. inrush current
1. On initial switch-on : 4.6 Arms
2. After a supply interruption of 5s : 3.6 Arms
TO THE USER
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user
will be required to correct the interference at his own
expense.
CAUTION
Changes or modifications to this equipment not expressly
approved by TEAC CORPORATION for compliance could
void the user's authority to operate this equipment.
For Canada
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN
ICES-003.
CET APPAREIL NUMERIQUE DE LA CLASSE A EST CONFORME A
LA NORME NMB-003 DU CANADA.
In North America use only on 120V supply.
DECLARATION OF CONFORMITY
We, TEAC EUROPE GmbH. Bahnstrasse 12, 65205
Wiesbaden-Erbenheim, Germany declare in own
responsibility, the TEAC product described in this
manual is in compliance with the corresponding
technical standards.
For the customers in Europe
WARNING
This is a Class A product. In a domestic environment, this
product may cause radio interference in which case the
user may be required to take adequate measures.
Pour les utilisateurs en Europe
AVERTISSEMENT
Il s'agit d'un produit de Classe A. Dans un environnement
domestique, cet appareil peut provoquer des
interférences radio, dans ce cas l'utilisateur peut être
amené à prendre des mesures appropriées.
Für Kunden in Europa
Warnung
Dies ist eine Einrichtung, welche die Funk-Entstörung
nach Klasse A besitzt. Diese Einrichtung kann im
Wohnbereich Funkstörungen versursachen; in diesem
Fall kann vom Betrieber verlang werden, angemessene
Maßnahmen durchzuführen und dafür aufzukommen.
TASCAM HS-20
2
IMPORTANT SAFETY INSTRUCTIONS
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8 Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9 Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not
t into your outlet, consult an electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11 Only use attachments/accessories specified by the
manufacturer.
12 Use only with the cart, stand, tripod, bracket, or table
specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from
tip-over.
The apparatus draws nominal non-operating power
•
from the AC outlet with its POWER or STANDBY/ON
switch not in the ON position.
The mains plug is used as the disconnect device, the
•
headphones with the product because excessive sound
pressure (volume) from earphones or headphones can
cause hearing loss.
If you are experiencing problems with this product,
•
contact TEAC for a service eferral. Do not use the
product until it has been repaired.
CAUTION
Do not expose this apparatus to drips or splashes.
•
Do not place any objects filled with liquids, such as
•
vases, on the apparatus.
Do not install this apparatus in a confined space
•
such as a book case or similar unit.
The apparatus should be located close enough to
•
the AC outlet so that you can easily grasp the power
cord plug at any time.
If the product uses batteries (including a battery
•
pack or installed batteries), they should not be
exposed to sunshine, fire or excessive heat.
CAUTION for products that use replaceable lithium
•
batteries: there is danger of explosion if a battery is
replaced with an incorrect type of battery. Replace
only with the same or equivalent type.
WARNING
Products with Class ! construction are equipped
•
with a power supply cord that has a grounding
plug. The cord of such a product must be plugged
into an AC outlet that has a protective grounding
connection.
8
RACK-MOUNTING THE UNIT
Use the supplied rack-mounting kit to mount the unit in a
standard 19-inch rack, as shown below.
Remove the feet of the unit before mounting.
13 Unplug this apparatus during lightning storms or
when unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
CAUTION
•
Leave 1U of space above the unit for ventilation.
•
Allow at least 10 cm (4 in) at the rear of the unit for ventilation.
TASCAM HS-20
3
IMPORTANT SAFETY INSTRUCTIONS
8
For European Customers
Disposal of electrical and electronic equipment
(a) All electrical and electronic equipment should be
disposed of separately from the municipal waste
stream via designated collection facilities appointed
by the government or the local authorities.
(b) By disposing of the electrical and electronic
equipment correctly, you will help save valuable
resources and prevent any potential negative effects
on human health and the environment.
(c) Improper disposal of waste equipment can have
serious effects on the environment and human health
as a result of the presence of hazardous substances in
electrical and electronic equipment.
(d) The crossed out wheeled dust bin symbol indicates
that electrical and electronic equipment must be
collected and disposed of separately from household
waste.
(e) The return and collection systems are available to
the end users. For more detailed information about
disposal of old electrical and electronic equipment,
please contact your city office, waste disposal service
or the shop where you purchased the equipment.
11 – Mark and locate functions ..................105
Mark functions ................................................................ 105
Adding marks ........................................................... 105
Using keys to locate to marks ............................. 105
Mark list screen ........................................................ 105
Locating to marks ................................................... 106
TASCAM HS-20
7
1 – Introduction
Thank you very much for purchasing the TASCAM HS-20
Two-Channel Audio Recorder.
Before connecting and using this unit, please take time to
read this manual thoroughly to ensure you understand how to
properly set it up and connect it, as well as the operation of its
many useful and convenient functions. After you have finished
reading this manual, please keep it in a safe place for future
reference.
You can also download the Owner's Manual from the TEAC
Global Site (http://teac-global.com/).
Features
•
Uses SD cards and CF cards as recording media (supports
ultra DMA)
•
Mirror recording possible using two cards in dual slots
•
Two-track simultaneous recording at resolutions up to
192kHz/24-bit
•
Three operation modes including timeline, take and playlist
•
Timeline mode is similar to a tape recorder and allows
recording and playback based on a timeline
•
Take mode allows playback in take units and flash starting
•
Playlist mode allows takes to be added to playlists and
played in order or flash started
•
File formats:BWF (Broadcast Wave Format)
WAV (Waveform Audio Format)
•
Flash starting is possible using a remote control (TASCAM
RC-HS20PD or RC-SS20 sold separately)
•
Flash starting is also possible using parallel control or a
keyboard
•
Auto cue, auto ready and incremental play functions
•
AES31 editing information can be read and written in
timeline mode
•
Playlist mode function supports reading and writing of JPPA
flash start playlist files
•
JOG/SHUTTLE functions
•
Color TFT touch panel with a graphical user interface
enables intuitive operation
•
Balanced analog XLR inputs and outputs
•
Unbalanced analog RCA inputs and outputs
•
XLR AES/EBU digital inputs and outputs
•
Coaxial S/PDIF digital inputs and outputs
•
Headphones output
•
BNC timecode input and output possible using optional
SY-2
•
BNC video reference (NTSC/PAL black burst and HDTV
Tri-level signals) and word clock input, output and thru
•
USB flash drives can be connected to copy files
•
LAN (gigabit Ethernet) function allows file transfer and
remote control over a network
•
Parallel remote control supported
•
RS-232C serial remote control supported
•
RS-422 serial remote control (based on 9-pin serial protocol)
supported using optional SY-2
•
Mounting in a rack possible (2U)
•
Can be used with TASCAM HS Editor
•
SNTP function allows time to be set using an NTP server
•
Recorded files can be automatically transmitted over a
network to designated servers
•
Automatic playback, recording and file transfer possible in
time mode using the timer event list
•
When SD cards and CF cards are inserted, folders necessary
for recording and playback are created automatically
Included items
This product includes the following items.
Take care when opening the package not to damage the items.
Keep the packing materials for transportation in the future.
Please contact TEAC if any of these items are missing or have
been damaged during transportation.
• Main unit ..............................................................................................× 1
• Power cord ...........................................................................................× 1
(this document including warranty at back) ...........................× 1
Conventions used in this manual
The following conventions are used in this manual.
•
When we refer to keys, connectors and other parts of this
unit and other equipment, we use a bold font like this:
MENU key.
•
“CompactFlash card” is sometimes abbreviated as “CF card”.
•
Additional information is provided as necessary as tips,
notes and cautions.
TIP
These are tips about how to use the unit.
NOTE
These provide additional explanations and describe special
cases.
CAUTION
Failure to follow these instructions could result in injury,
damage to equipment or lost recording data, for example.
TASCAM HS-20
8
1 – Introduction
Intellectual property rights
•
TASCAM is a trademark of TEAC Corporation, registered in
the U.S. and other countries.
•
CompactFlash is a US registered trademark of SanDisk
Corporation.
•
SDHC logo is a trademark of SD-3C, LLC.
•
Other company names, product names and logos in this
document are trademarks or registered trademarks of their
respective owners.
Any DATA, including, but not limited to information,
described herein are intended only as illustrations of such
DATA and/or information and not as the specifications for
such DATA and/or information. TEAC Corporation disclaims
any warranty that any use of such DATA and/or information
shall be free from infringement of any third party’s
intellectual property rights or other proprietary rights, and
further, assumes no liability of whatsoever nature in the
event of any such infringement, or arising from or connected
with or related to the use of such DATA and/or information.
This product is designed to help you record and reproduce
sound works to which you own the copyright, or where
you have obtained permission from the copyright holder or
the rightful licensor. Unless you own the copyright, or have
obtained the appropriate permission from the copyright
holder or the rightful licensor, your unauthorized recording,
reproduction or distribution thereof may result in severe
criminal penalties under copyright laws and international
copyright treaties. If you are uncertain about your rights,
contact your legal advisor. Under no circumstances will TEAC
Corporation be responsible for the consequences of any
illegal copying performed using the recorder.
Precautions for placement and use
•
The guaranteed operating temperature range of this
product is 5º - 35º C (41º- 95º F).
•
Do not install in the following types of places. Doing
so could degrade the sound quality and/or cause
malfunctions.
o Places with significant vibrations or that are
otherwise unstable
o Near windows or other places exposed to direct
sunlight
o Near heaters or other extremely hot places o Extremely cold places o Places with bad ventilation or high humidityo Dusty places
•
Make sure that the unit is mounted in a level position for
correct operation.
•
In order to promote the emission of heat, do not place
anything on top of this product.
•
Do not place this product on top of a powered amplifier or
other equipment that emits heat.
Beware of condensation
If the unit is moved from a cold to a warm place, or used
immediately after a cold room has been heated or otherwise
exposed to a sudden temperature change, condensation could
occur. Should this happen, leave the unit for one or two hours
before turning the unit on.
TASCAM HS-20
9
1 – Introduction
Cleaning the unit
Use a dry soft cloth to wipe the unit clean. Do not wipe with
chemical cleaning cloths, thinner, alcohol or other chemical
agents.
Doing so could damage the surface or cause discoloration.
Cleaning the display
Gently wipe the display with a soft dry cloth that does not shed
dust (e.g. a cleaning cloth).
Avoid wiping with a stiff cloth or rubbing with force. Doing so
will damage the surface of the LCD. Do not use benzene, thinner,
manicure remover, alcohol or similar substances.
About USB flash drives, SD cards and
CF cards
This unit uses SD cards and CF cards for recording and playback.
In addition, you can connect USB flash drives and use them to
back up data from SD/CF cards and to save files to them.
A list of USB flash drives, SD cards and CF cards that have been
confirmed to work with this unit can be found on the TEAC
Global Site (http://teac-global.com/).
SD card write protection
In order to improve operational performance, this unit writes
track information to the media. Since track information cannot
be written to write-protected SD cards, performance will be
affected, including requiring more time to write to the media.
About formats
Always format SD and CF cards with this unit before using them
in it. Media formatted by this unit will be optimized to improve
performance with it.
If media that has been formatted by a computer or another
device is used with this unit, its operation might be affected.
Precautions for use
USB flash drives, SD cards and CF cards are delicate media. In
order to avoid damaging a flash drive or card, please follow
these precautions when handling them.
•
Do not leave them in extremely hot or cold places.
•
Do not leave them in extremely humid places.
•
Do not let them get wet.
•
Do not put things on top of them or twist them.
•
Do not hit them.
•
Do not connect or disconnect USB flash drives, SD cards
and CF cards when they are being accessed, including
during recording, playback and data transfer.
•
Always cover their connectors when transporting them. Do
not leave connectors exposed.
Note about confirmed media
This unit uses SD cards and CF cards for recording and playback
and USB flash drives to back up data from SD/CF cards and to
save files to them.
We recommend using genuine TASCAM CF cards, but you can
also use commercially-available CF cards.
Micro drives cannot be used with this unit.
Moreover, older SD/CF cards as well as some newer SD/CF cards
use slow memory components and internal buffers with low
capacity. Use of such SD/CF cards could affect the recording
performance of this unit.
Moreover, some older USB flash drives use slow memory
components or internal buffers with low capacity.
Use of such USB flash drives could increase the amount of time
necessary for reading and writing data.
Please refer to the list of USB flash drives, SD cards and CF cards
that have been confirmed to work with this unit on the TEAC
Global Site (http://teac-global.com/).
TASCAM HS-20
10
Front panel
2 – Names and functions of parts
1 POWER switch
Use to turn the power on and off.
This switch has a cover to prevent misoperation.
Open the cover from below to access and operate the
switch.
2 USB connector
By connecting a USB flash drive, for example, you can back
up data from SD/CF cards and save files to them.
By connecting a USB keyboard, you can input folder names,
for example.
By default, the unit is set to use Japanese keyboards, which
have a different layout from US keyboards.
To use a US keyboard, change the setting on the PREFERENCES page of the SYSTEM SETUP screen. (See “PREFERENCES page” on page 91.)
NOTE
Do not disconnect a USB flash drive when using it to copy
files.
You can connect and disconnect a USB flash drive at all
other times.
You can connect and disconnect USB keyboards at any time.
This unit is not compatible with USB hubs and other devices
with USB hub functions.
3 SD/CF card indicators
The indicator for the currently selected card slot lights.
When recording, copying or transferring files by FTP, it blinks
rapidly.
When no card is inserted in the current slot, it blinks slowly.
CAUTION
Do not remove a card from the slot when its indicator (SD
card or CF card) is blinking rapidly.
4 SD/CF card slots
Insert and remove SD cards and CF cards here. (See
“Inserting and removing SD and CF cards” on page 21.)
5 HOME key
Press to open the Home Screen. Press the MENU key while
pressing and holding the HOME key to open the LOCK
SETUP screen. (See “Lock function” on page 24.)
Turn the DATA dial when pressing and holding the HOME
key to adjust the brightness of the color display, the PAUSE, REC and PLAY keys and the JOG [SHUTTLE], and SD and CF
indicators.
Push and turn the DATA dial while pressing and holding the
HOME key to adjust the brightness of only the color display.
6 MENU key
Press to open the MENU screen.
Press the MENU key while pressing and holding the HOME
key to open the LOCK SETUP screen. (See “Lock function” on
page 24.)
7 Color display
This 3.5-inch TFT color display has a 320 x 240 resolution.
It shows various types of information and is used for
numerous operations.
8 DATA dial
Turn to use as a DATA dial and press to use as an ENTER
key. When setting parameter values, press while turning to
change them in large increments (coarse mode).
When the take mode Home Screen is open and neither the
Flash Page knob nor the NEXT TAKE NAME screen number
section are selected, turn this to select the take.
When a pop-up window is open, this works as the OK or
CLOSE button.
Turn the DATA dial when pressing and holding the HOME
key to adjust the brightness of the color display, the PAUSE, REC and PLAY keys and the JOG [SHUTTLE], and SD and CF
indicators.
Push and turn the DATA dial while pressing and holding the
HOME key to adjust the brightness of only the color display.
9 STOP key
Press to stop recording or playback.
0 PLAY key/indicator
When stopped or in playback standby, press this key to start
playback. This key lights during playback.
Press this key when in recording standby to start recording.
Both the PLAY and REC keys light during recording.
In timeline mode, press the PLAY key while pressing and
holding the REC key to start recording from that point. Both
the PLAY and REC keys light during recording.
q PAUSE key/indicator
Press this key when stopped or during playback to put the
unit in playback standby. This key lights when in standby.
Press this key while recording to put the unit in recording
standby. Both the PAUSE and REC keys light when in
recording standby.
w REC key/indicator
When a recordable card is installed and the unit is stopped,
press this key to put the unit into recording standby. Both
the PAUSE and REC keys light during recording standby.
TASCAM HS-20
11
2 – Names and functions of parts
In timeline mode, press the PLAY key while pressing and
holding the REC key to start recording from that point. Both
the PLAY and REC keys light during recording.
e PHONES knob/jack
Connect stereo headphones to this standard stereo phone
jack.
This jack outputs the signal from the internal monitoring
mixer.
Use the PHONES knob to adjust the headphones output
level.
CAUTION
Before connecting headphones, minimize the volume with
the PHONES knob. Failure to do so might cause sudden loud
noises, which could harm your hearing or result in other
trouble.
r KEYBOARD connector
Connect an IBM PC-compatible keyboard with a PS/2
interface here.
You can use it to input the names of folders, for example.
By default, the unit is set to use Japanese keyboards, which
have a different layout from US keyboards. To use a US
keyboard, change the setting on the PREFERENCES page of
the SYSTEM SETUP screen. (“PREFERENCES page” on page
91.)
t FILE LIST key
Touch to open the FILE LIST screen. (See “FILE LIST screen
overview” on page 30.)
y EXIT/CANCEL [PEAK CLEAR] key
Press to cancel input or item selection.
When a pull-up or pull-down menu is open, press to close it.
On the Home Screen, when no pull-up/pull-down menu
is open, this key functions as a reset button for peak hold
marks shown on the level meters
When the MENU screen or FILE LIST screen is open, press this
to return to the Home Screen.
On other screens, press this to return to the previous screen.
When a pop-up window is open, press this to cancel an
operation.
u CALL [CHASE] key
Press to locate to and pause playback at the call point, which
is where playback last started from playback standby.
Press this key while pressing and holding the SHIFT key to
turn synchronization with timecode ON/OFF.
i LCD TILT button
Press this button to unlock the color display.
To adjust the angle of the color display, press this button to
unlock it and pull the bottom of the display outward.
To put the display away, press this button to unlock it and
push the bottom inward.
o m [] and , [] (search) keys
Press one of these keys to search.
m [] key: search backward
, [] key: search forward
Press one of these keys while pressing and holding the
SHIFT key to search at high speed.
p . / /[MARK. / /] (skip) keys
Use these keys to skip between regions, takes and entries.
Press these keys while pressing and holding the SHIFT
key to move to the previous/next mark. After moving, the
same playback state resumes (stopped/playback standby/
playback).
a MARK key
Press this key to add a mark at the currently located time.
The maximum number of marks, including automatic marks,
possible in a single timeline/take is 99. (See “Mark functions”
on page 105.)
s SHIFT key
When stopped/in playback standby/during playback:
o Press the . key while pressing and holding this key
to move to the previous mark, and resume the same
playback state.
o Press the / key while pressing and holding this key to
move to the next mark, and resume the same playback
state.
o Press the m[] or ,[] key while pressing
and holding this key to search at high speed.
o Press the JOG [SHUTTLE] key while pressing and holding
this key to activate the shuttle operation mode.
o Press the CALL [CHASE] key while pressing and holding
this key to turn timecode synchronization ON/OFF.
d JOG [SHUTTLE] key and indicator
Press to enable use of the JOG/SHUTTLE functions.
Press this key to enable the jog operation mode of the JOG/
SHUTTLE dial. When this mode is enabled, this indicator
lights.
Press this key while pressing the SHIFT key to enable the
shuttle operation mode of the JOG/SHUTTLE dial. When
this is enabled, this indicator blinks.
Press this key again to disable either mode.
f JOG/SHUTTLE dial
When in jog operation mode, turn this to change the
playback position by a corresponding amount.
When in shuttle operation mode, turn this to adjust the
playback speed according to the degree of rotation.
If you return to the original position when in shuttle
operation mode, the transport status is restored to how it
was before shuttle playback was begun.
TASCAM HS-20
12
Rear panel
2 – Names and functions of parts
g ANALOG IN L/R (UNBALANCED) connectors
These RCA pin jacks are analog unbalanced inputs (L/R)
The rated input level is −10dBV.
h ANALOG IN L/R (BALANCED) connectors
These XLR connectors are balanced analog inputs (L/R)
The rated input level is +4dBu. (1: GND, 2: HOT, 3: COLD)
j DIGITAL IN (S/PDIF) connector
This connector is an unbalanced input for digital audio in
IEC60958-3(S/PDIF) and AES3-2003/IEC60958-4 (AES/EBU)
formats.
Sampling frequencies of 88.2 kHz and 96 kHz are transmitted at double speed, and 176.4 kHz and 192kHz are at
quadruple speed.
This unit is equipped with a sampling rate converter which
supports 32 kHz to 192 kHz.
k DIGITAL IN (AES/EBU) connector
This connector is an XLR balanced input for digital audio in
AES3-2003 / IEC60958-4 (AES/EBU) and IEC60958-3 (S/PDIF)
format.
Sampling frequencies of 88.2 kHz and 96 kHz are transmitted at double speed, and 176.4 kHz and 192kHz are at
quadruple speed.
This unit is equipped with a sampling rate converter which
supports 32 kHz to 192 kHz.
l REMOTE connector
Connect a TASCAM RC-HS20PD remote control (sold
separately) here.
NOTE
A protective cover is attached to this connector when
shipped from the factory. Remove the cover to use the
connector.
CAUTION
This is not an Ethernet connector (LAN, etc.). Never connect
this to a network using an Ethernet cable.
Doing so could damage this unit or equipment in the
network.
; RS-232C connector
This is a 9-pin D-sub connector for RS-232C serial control.
Connect an external controller, for example, here.
NOTE
It cannot be used at the same time as the RS-422 connector.
(See “RS–232C page” on page 85.)
z PARALLEL connector
This is a 25-pin D-sub connector for parallel control.
Connect a TASCAM RC-SS20 or another external controller
here.
x AC IN connector
Connect the included power cord here.
c ANALOG OUT L/R (UNBALANCED) connectors
These RCA pin jacks are analog unbalanced outputs (L/R).
Their rated output level is −10 dBV.
v ANALOG OUT L/R (BALANCED) connectors
These XLR connectors are balanced analog outputs (L/R).
Their rated output level is +6 dBu when Digital Ref. Level is
set to −9dBFs and +4dBu in other cases. (1: GND, 2: HOT, 3:
COLD)
b DIGITAL OUT (S/PDIF) connector
This connector is an unbalanced output for digital audio in
IEC60958-3(S/PDIF) format.
Sampling frequencies of 88.2 kHz and 96 kHz are transmitted at double speed, and 176.4 kHz and 192kHz are at
quadruple speed.
n DIGITAL OUT (AES/EBU) connectors
This connector is an XLR balanced output for digital audio in
AES3-2003/IEC60958-4 (AES/EBU) format.
Sampling frequencies of 88.2 kHz and 96 kHz are transmitted at double speed, and 176.4 kHz and 192kHz are at
quadruple speed.
m RS-422 connector (attached to optional SY-2 board)
This is a 9-pin D-sub connector for RS-422 serial control.
Connect an external controller, for example, here.
NOTE
This cannot be used at the same time as the RS-232C
connector. (See “RS–422 page” on page 86.)
, TIME CODE IN/OUT connectors (attached to optional
SY-2 board)
These BNC connectors are for SMPTE timecode input and
output.
. WORD/VIDEO IN connector
This BNC connector is for input of word clock and video
reference signals. Use this to input a word clock signal
(44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz or 192 kHz)
or a video reference signal (NTSC/PAL black burst or HDTV
Tri-Level).
Use the switch to set whether or not to terminate with 75Ω.
/ WORD/VIDEO THRU/WORD OUT connector
TASCAM HS-20
13
2 – Names and functions of parts
This BNC connector is for output of word clock thru/out and
video reference thru signals.
Use this to output a word clock signal (thru, 44.1 kHz, 48 kHz,
88.2 kHz, 96 kHz, 176.4 kHz or 192 kHz) or a video reference
signal (IN connector signal thru only).
Use the THRU/WORD OUT switch to set the signal output.
! 75Ω OFF/ON and THRU/WORD OUT switch
Use this switch to make the following settings.
o Whether or not the WORD/VIDEO IN connector has a
terminator (75Ω)
o The WORD/VIDEO output THRU/OUT setting (OUT is only
for WORD)
@ ETHERNET connector
Use this Ethernet connector to connect to a network for file
transfer and to control this unit from an external source.
PARALLEL connector
The PARALLEL connector on the rear panel allows external
control of this unit. (A TASCAM RC-SS20 can also be connected.)
H or Open
15PAUSEFLASH 6I
16(Reserved)FLASH 7I
17AUX1, FFFLASH 8I
18AUX2, REWFLASH 9I
19AUX3, MARKFLASH 10I
20(Reserved)FLASH_PAGEI
21(Reserved)(Reserved)O
22TALLY_SDTALLY_SD
23(Reserved)(Reserved)O
24TALLY_CFTALLY_CF
25+5V
I: Command input for transport control
O: Command output, for tally output
1For RC-SS20, assigned to CF indicator
2For RC-SS20, assigned to CD indicator
3
Internal circuit, +5V pull-up
Triggers from a low input level of 50 msec or more
The internal circuit is open collector
(10Ω output impedance)
Low command output when operating
20V dielectric strength, 35mA maximum current
RC-SS20 PonMode
REMOTE_SELECT, LI
1
2
3
+5V
I/O
O
O
3+5V: maximum supplied current is 50 mA
When REMOTE Select (pin 14) is set to high, it can be used as an
ordinary parallel controller.
When set to low, flash start mode is enabled.
In addition, depending on the high/low setting of the Flash
Page (pin 20), the key assignments are as follows.
Pin 14Pin 20Flash start take
Low
LowLow11–20
The following example is of a connection that uses a fader to
start and stop playback of this unit.
For information about the assignment of AUX 1–3 (pins 17–19)
functions, see “PARALLEL page” on page 85.
High1–10
NOTE
When controlling this unit with an external device that
is connected to the PARALLEL connector, if the unit is
stopped, you can start recording immediately by simultaneously inputing PLAY and RECORD signals. In addition, by
simultaneously inputting PLAY and RECORD signals
during playback in timeline mode, you can start overwrite
recording.
RS-232C connector
The RS-232C connector on the rear panel can be connected to
an RS-232C connector on a computer to allow control of this
unit from that computer.
Make settings related to communication on the RS–232C page
of the REMOTE SETUP screen. (See “RS–232C page” on page
85.)
NOTE
Please contact TASCAM customer support for information
about this unit’s RS-232C command protocol.
RS-422 connector (attached to optional SY-2
board)
The optional SY-2 board is equipped with an RS-422 connector.
You can control this unit remotely by installing an SY-2 board in
this unit and connecting the RS-422 connector to a controller or
editor compatible with the SONY P2 protocol (RS-422).
Make settings related to operation on the REMOTE SETUP screen
RS–422 page. (See “RS–422 page” on page 86.)
NOTE
Please contact TASCAM customer support for information
about this unit’s protocol compatibility.
TASCAM HS-20
14
2 – Names and functions of parts
Home Screen
Press the HOME key to open the Home Screen.
In timeline mode
23 4561
7
8
9
0
q
w
e
opas df
1 NTP server time synchronization status
If an error occurs during synchronization with an NTP server,
an error icon will blink like this: § .
2 Repeat status
When repeat playback is on, the icon lights green.
When repeat playback is off, the icon appears unlit.
r
t
y
u
i
6 Audio synchronization status button/indicator
When synchronized to a Master clock, the
SYNC indicator appears green.
§
Touch this area to open the SYNC T/C screen. (See “Sync and
timecode settings (SYNC T/C)” on page 81.)
The SYNC indicator blinks when not synchronized to a Master clock.
7 Transport status indicator
This icon shows the current transport status.
Playing back or jogging playback (forward)
Jogging playback (reverse)
Playback standby
Stopped
Searching backward
Searching forward
Searching backward (high-speed)
Searching forward (high-speed)
The number shown when searching backward
(shuttle operation) changes with the current
speed: x2, x4, x8, x16, x32.
The number shown when searching forward
(shuttle operation) changes with the current
speed: x2, x4, x8, x16, x32.
Recording
Recording standby
3 Time counter (button)
The time displayed is the elapsed time or the timecode time.
Touch this area to change the time display mode.
4 Time mode (button)
This icon shows the current time display mode.
Touch this area to change the time display mode.
The time elapsed from the beginning of the
timeline is shown.
The timecode for the timeline is shown.
5 Timecode status button/indicator
When accurate timecode is input and recognized correctly, the TC indicator appears green.
When timecode is not recognized correctly, the
TC indicator appears unlit.
This shows the status when operation is synchronized to
timecode.
The CHASE indicator appears green only
when operation is synchronized with
external timecode or the built-in timecode
generator (selectable).
The CHASE indicator blinks when not
§
Touch this area to open the SYNC T/C screen. (See “Sync and
timecode settings (SYNC T/C)” on page 81.)
operating with timecode synchronization
and when synchronization is lost during
synchronized operation.
Touch this area to open the PLAY SETUP screen.
8 AES31 File name (button)
This shows the current active AES31 file name (AES31
editing information file).
A * appears when the timeline has not been saved after
editing (including the addition and removal of folder editing
marks)
Touch this area to open a pull-down menu.
START TIME EDIT button
This opens the START TIME screen where you can set the
timeline mode starting time. This can only be selected
when stopped.
REBUILD button
This rebuilds if files have been deleted or modified using
FTP.
This can only be selected when stopped.
SAVE button
Save the contents of the timeline.
This can only be selected when stopped.
TASCAM HS-20
15
2 – Names and functions of parts
SAVE AS button
This name and saves the content of the timeline.
This can only be selected when stopped.
(See “Saving AES31 editing information” on page 42.)
CREATE AES31 button
This opens the AES31 NAME screen where you can
create new AES31 files.
This can only be selected when stopped.
(See “Creating new AES31 editing information” on page
43.)
IMPORT ALL TAKES button
This imports all takes in the current folder.
This can only be selected when stopped. (See “Importing
all takes” on page 43.)
9 Input monitoring indicators
The indicators at the left end of the level meters show the
status of input monitoring. The indicator background colors
show the input monitoring status.
Playlist Mode
MON OFF
MON ON
Timeline mode
Take mode
0 Level meters
The input signal levels are shown when input monitoring is
on, during recording standby and when recording.
Each channel also has an overload indicator at its right end
that appears red when the input overloads.
During playback, track playback levels are shown when
input monitoring is off.
When the input source is set to a digital input, but there is
no input signal or if the input signal differs from the internal
setting, the channel meter display area appears gray and
one of the following messages appears.
MessageMeaning
D-IN NO SIGNAL No input signal
D-IN UNLOCK
D-IN NOT AUDIO
D-IN Cbit ERROR
Input signal is not synchronized with
system
Cbit information of input signal is
not audio
Other Cbit information of input
signal differs from actual operation
mode
o Release timeo Overload indicator peak levelo Reference level line display on/off
q Time display area
This area shows 4 equal divisions of the timeline for the set
time display mode.
This area scrolls horizontally to correspond with the time
counter.
w Mark display area
Timeline marks appear here.
This area scrolls horizontally to correspond with the time
counter.
IN mark
OUT mark
Other types of marks
e Track display area
This shows the track regions.
The left track is on the top and the right track is on the
bottom.
Region fade-ins, fade-outs and cross-fades are shown in
light blue.
The status of each region is shown by color as shown below.
NormalWhite
Being recordedRed
Fade-in
Fade-out
Cross-fade area
Selected regionMedium blue
Selected silent part Dark blue
This area scrolls horizontally along with the time counter.
Light blue
r EDIT MODE button
Touch this to turn editing mode on/off. In this mode you can
divide, erase, and trim regions, for example. (See “Editing the
timeline” on page 45.)
D–IN NO SIGNAL shown
The following settings can be made for the display of the
level meters on the METER SETUP screen from the MENU
screen.
o Metering pointo Peak hold time
TASCAM HS-20
16
t Recording media info button
This shows which of the card slots is being used and its
remaining recording time.
The background color is green during playback and red
while recording.
If there is no media in the card slot, No Media appears on a
light gray background.
If the card has no folders, "No Project"appears. When an
unformatted card is inserted, UNFORMAT appears.
When a card is inserted in the card slot that is not being
used for recording, UNMOUNT appears. When recording
stops, this will change to its ordinary appearance.
2 – Names and functions of parts
If the total number of entries, including files and subfolders,
inside a folder exceeds about 20,000, recording becomes
impossible and "Rec Limit" appears. For details, see
“Recording operation limitations” on page 29.
Press this area to open the MEDIA SELECT screen. (See “Card
selection” on page 26.)
Media status indicators
These indicators show whether media recording is possible,
not possible or not selected for recording.
The status will be displayed in timeline and take modes.
(Status is not displayed in playlist mode.)
o Indicators
Recording
possible
o Remaining media button examples
1 REC MODE set to Single
RecordingNot recording
2 REC MODE set to Mirror
RecordingNot recording
Recording not
possible
Not selected
for recording
Recording not
possible*
o INPUT MONITOR button
Touch this button to open a pull-up menu where you can
turn input monitoring ON/OFF.
When ON, sound input through the assigned input
connector is always output from this unit.
p BOUNCE I/O button
Touch this button to open a pull-up menu for bouncing.
3 REC MODE set to Mirror when mirroring not possible*
RecordingNot recording
*See “Setting button appearance” on page 77 for more
information about when recording is not possible or
mirroring is not possible.
Recording not
possible*
y Zoom rate
This shows the track area zoom ratio and the amount of time
displayed.
Turn the DATA dial to the right to zoom in (reduce the
amount of time displayed) and turn it to the left to zoom out
(increase the amount of time displayed).
u Timeline cursor
This cursor shows the position of recording or playback. It is
always shown in the middle of the screen.
i Mark name
This is the name of the mark at the current time or the
nearest preceding mark.
Touch this part while a mark name other than the auto mark
is shown to open the mark name editing screen.
Bounce button
Touch this button to bounce. In the following circumstances, this button appears gray and cannot be used.
o When both starting (IN) and ending (OUT) points have not
been set
o During playback or recording
SET IN button
Touch to set the current position as the bounce starting
(IN) point.
SET OUT button
Touch to set the current position as the bounce ending
(OUT) point.
CLEAR button
Touch to discard the currently set bounce starting (IN)
and ending (OUT) points.
For details about this button, see “Bouncing” on page 55.
a NEXT TAKE NAME button
Touch this button to open the NEXT TAKE NAME page where
you can set the name that will be given to takes or files
recorded in the future.
o First half of take names
The first half of the take name can be set to either the
User Word, Folder Name or Date/Time.
(Default: DATE/TIME)
CAUTION
The first half of the take name can only be changed when
the unit is stopped.
o User Word mode button
Use the user word for the first half of the take name.
Touch the EDIT button to open the screen where you
can change the user word. (This works the same as the
screen for editing the names of folders in the root folder.)
TASCAM HS-20
17
2 – Names and functions of parts
s INFO button
o Folder Name mode button
Use the folder name as the first half of the take name.
o Date/Time mode button
Use the date/time for the first half of the take name. (The
format is “y yyymmdd-hhmmss”.)
Example: If it was created at 3:10:20 PM on July 1,
2014, the first half of the take name will be
“20140701-151020”.
d Mark List button
f Manual Locate button
NOTE
If the first half of the take name or the letter in the second
half is different, a take that has the same three-digit number
in the second half can be created.
Touch this button to open an information display that shows
the file name of the region at the timeline cursor and the
current unit settings beneath the track display area.
The upper section shows the file name of the region at the
timeline cursor.
The lower section shows the current sampling frequency,
recording bit length and frame type settings.
Touch this button to open the mark list. (See “Mark list
screen” on page 105.)
Touch this button to open the MANUAL LOCATE screen. (See
“Manual locate function” on page 108.)
o Second half of take names
The second half of the take name is comprised of one
alphabetical letter and a three-digit number. Touch the
EDIT button to open the screen where you can change
the letter.
You can change the three-digit number with the +
and – buttons. You can also touch the numerical part to
highlight it in yellow and use the DATA dial to change
the number.
In the following cases, “---” appears and the value cannot
be changed.
o The current folder is not loaded.o The selected card is unavailableo When the numerical part of the file name of the
current take is 999
CAUTION
•
The Next Take Name setting is saved to the SC/CF card. If
you change cards, the setting on that card will be used.
(Even when using a card created on another HS series unit,
the setting will change when you change the folder.)
•
The numerical part of the second half of the take name can
be changed even during playback and recording.
(The first half of the take name and the letter in the second
half can only be changed when stopped.)
In take and playlist modes
g
hj
k
l
;
z
bn
In take mode
NOTE
When in playlist mode, the INPUT MONITOR, EDIT and NEXT
TAKE NAME buttons are not shown.
g Timer event function status button
This shows timer event function status. (Take mode only)
: Timer event function on
: Timer event function off
: Timer event has been edited, but not saved
m
x
c
v
TASCAM HS-20
18
2 – Names and functions of parts
Press this button to open the TIMER EVENT LIST screen. (See
“TIMER EVENT LIST screen” on page 99.)
h Take/entry number
The number of the currently selected take or entry is shown.
In recording standby, the file name of the take to be
recorded next will be shown. Take numbers are assigned in
the order that they are recorded within a folder.
j Time mode button
This icon shows the current time display mode.
Touch this area to change the time display mode.
ModeDetails
The elapsed time from the beginning of the take
is shown.
Unless recording, the time remaining until the
end of the take is shown. When recording, the
time remaining until the maximum file size is
shown.
The elapsed time from the beginning of the
folder is shown.
Unless recording, the time remaining until the
end of the folder is shown. When recording,
the remaining recordable time on the currently
selected card using the current recording
settings is shown.
The timecode time of the file being recorded or
played is shown.
In take mode
TAKE List button
This opens the take selection screen (TAKE screen). On
the take selection screen displayed by using this button,
the folder selection screen will not open even if you
press the folder name display area.
(See “FILE LIST screen overview” on page 30.)
CIRCLE @ TAKE button
Touch this to add or remove “@” at the beginning of the
current take name.
(See “Deleting a take” on page 60.)
REBUILD button
This rebuilds if files have been deleted or modified using
FTP.
In playlist mode
k Time bar
This shows the current playback position. The appearance
depends on the time display mode.
ModeDetailsBar display
The current playback
position relative to the
length of the take or
entry is shown.
The current playback
position relative to the
length of all the takes in
the folder or the entire
playlist is shown.
(White vertical lines
show the boundaries
between takes and
entries.)
Elongates from left end
to right end
Shortens from left end
to right end
Elongates from left end
to right end
Shortens from left end
to right end
Elongates from left end
to right end
NOTE
A red progress bar that extends from the left end to the
right end with a frequency of approximately five seconds is
shown during recording.
l Take/entry name button
This shows the name and icon of the currently active take or
entry.
In recording standby, the file name of the take to be
recorded next will be shown.
When in playlist mode, a “*” appears in the icon if the playlist
has not been saved after editing (including the addition and
removal of entries).
Touch this area to open a pull-down menu.
ASSIGN FILE button
This shows the ASSIGN screen where you can assign files.
(See “ASSIGN File screen” on page 69.)
ENTRY LIST button
This shows the entry list (ENTRY) screen. (See “ENTRY list
screen” on page 68.)
ADJUST ENTRY button
This opens the ADJUST ENTRY *** screen where you can
edit an entry.
(See “Editing entry titles” on page 71, “Editing the
playback starting and ending points” on page 72,
“Editing the playback starting time” on page 73 and
“Editing fade-in/fade-out length and level” on page
74.)
REBUILD button
This rebuilds if files have been deleted or modified using
FTP.
SAVE button
This saves the current playlist. This can only be selected
when stopped.
(See “Saving playlists” on page 75.)
SAVE AS button
This adds a name to the current playlist and saves it. This
can only be selected when stopped.
(See “Saving playlists” on page 75.)
TASCAM HS-20
19
2 – Names and functions of parts
CREATE PLAYLIST button
This opens the PLAYLIST NAME screen where you can
create a new playlist.
(See “Creating a new playlist” on page 65.)
; Level meters
These are the same as on the Home Screen in timeline
mode.
z Time display area
The appearance depends on the time display mode.
ModeLeft endRight end
00:00:00:00
Total take or entry
length
00:00:00:00
Total folder or playlist
length
Starting time of folder
or playlist
When recording and in recording standby, however, the time
bar and division lines are not shown.
Total take or entry
length
00:00:00:00
Total folder or playlist
length
00:00:00:00
Ending time of folder
or playlist
x Flash Page number and knob
This shows the Flash Page number. Touch this area to enable
selection (yellow background), and turn the DATA dial to
change the page number (turn right to increase and turn left
to decrease).
Flash start screen
1. Press the HOME key when the Home Screen is already open
to open the flash start screen.
2. Use the DATA dial to select the page that contains the
takes or entries that you want to play after touching and
highlighting (yellow background) the operation/display
knob on the flash page.
NOTE
The flash start screen has five pages (PAGE 1–5) that can
each show 20 takes.
3. Touch a take or entry button that has a flash start indicator
lit orange on the display to use flash start playback. Flash
starting is also possible using a connected PS/2 keyboard
and devices connected to this unit’s remote connectors
(REMOTE, RS-232C and PARALLEL).
4. Touch the INFO button to open the information screen.
The contents of this screen are the same as the information
screen that opens by pressing the INFO button when the
Home Screen is open.
c Current time cursor
This cursor shows the playback position. This scrolls horizontally in correspondence with the time counter.
It is not shown when recording (take mode only).
v Mark name
This is the name of the mark at the current time or the
nearest preceding mark.
Touch this part while a mark name other than the auto mark
is shown to open the mark name editing screen.
b INPUT MONITOR button
These are the same as on the Home Screen in timeline
mode.
n EDIT button
Touch this button to open a pull-up menu for take editing.
m NEXT TAKE NAME button
These are the same as on the Home Screen in timeline
mode.
TASCAM HS-20
20
3 – Preparation
Inserting and removing SD and CF
cards
Inserting SD/CF cards
Insert an SD/CF card into the SD card slot or CF card slot on the
front of the unit in order to use it for recording and playback.
NOTE
SD/CF cards can be inserted whether the unit is ON or OFF.
1. Pull the card slot cover forward to open it.
2. Insert the SD/CF card with the correct orientation.
With the labeled side up, insert the end with the connector
completely.
Removing SD/CF cards
Turn the unit OFF or stop operations before removing an SD/CF
card.
CAUTION
Never remove an SD/CF card during recording, playback or
any other operation that accesses the card. Doing so could,
for example, cause recording errors, loss of recorded data,
and sudden loud noises to be output through monitoring
equipment, which could result in damaged equipment and
hearing loss.
1. Pull the card slot cover forward to open it.
2. If using an SD card, press the card into the slot slightly and
release it to bring the card out.
If using a CF card, press the square button to the right of the
CF card slot to bring the button out. Press the square button
in again to partially eject the CF card.
3. Close the cover.
3. Pull the SD/CF card out by hand.
NOTE
If you cannot close the cover of the card slot, remove the SD/
CF card and then reinsert the card.
If using a CF card, remove the CF card, press the square
button to the right of the slot and then reinsert the card.
TASCAM HS-20
21
3 – Preparation
Security screws
The included security screws can be used to lock the CF card
slot covers.
Use a Phillips head screwdriver to install or remove the
screws.
Protect switch for SD cards
SD cards have write-protection switches.
About the display
Adjusting the display angle
Push the LCD TILT button to unlock the display, and then pull
the bottom of the display forward to adjust the angle.
Pull the bottom of the display until you hear a clicking sound.
To restore it to its flat position, push the LCD TILT button again
to unlock the display, and push the bottom of the display.
Push the bottom of the display until you hear a clicking sound.
CAUTION
Do not push the display screen itself.
Writable
If you slide the protection switch to the “LOCK” position, you
cannot record or edit files on it. Unlock the write-protection if
you want to record or delete files on it, for example.
Not writable
CAUTION
The unit will check all audio files on a write-protected SD
card every time the device is switched. As a result, it takes
longer to switch the device. Editing the timeline is not
possible, either.
Adjusting display and indicator brightness
Turn the DATA dial while pressing and holding the HOME key to
adjust the brightness of the color display, the PAUSE, REC and PLAY keys, and the JOG [SHUTTLE], SD and CF indicators. Push
and turn the DATA dial while pressing and holding the HOME
key to adjust only the brightness of the color display.
Cautions related to display use
o The display can easily be scratched, so do not use pointed
objects, including fingernail tips, to touch it. Always touch
it with your fingers.
o Do not press the display forcefully with a finger or poke
it with a pen, toothpick or other pointed object. Doing so
could scratch the display or cause malfunction.
o The touch screen is made of film and glass. Do not apply
strong force to its surface. Doing so could break the glass.
o When using the display, do not put a hand on the panel or
push around the display forcefully. Doing so could prevent
accurate position detection.
o Do not place anything on top of the display or otherwise
put weight on the same place for a long time. Doing so
could cause the panel to warp or result in inaccurate
position detection.
TASCAM HS-20
22
3 – Preparation
o Do not apply a commercially-available screen protection
film to the display. Doing so could prevent normal
operation.
o Gently wipe the display with a soft dry cloth that does not
shed dust (e.g. a cleaning cloth). Avoid wiping with a stiff
cloth or rubbing with force. Doing so could damage the
surface of the LCD. Do not use benzene, thinner, manicure
remover, alcohol or similar substances.
NOTE
The display is produced with extremely high-precision
manufacturing technologies, and 99.99% or more of
the pixels are effective, but sometimes pixels might not
appear or might appear as red or black dots. This is not a
malfunction.
Turning the power ON and OFF
Open the front panel POWER switch cover and press the
POWER switch.
Start-Up Screen
Home Screen
To turn the power OFF, push the POWER switch on the front
panel again.
CAUTION
Never turn the power OFF during recording, playback,
or any other operation that accesses an SD or CF card.
Doing so could, for example, cause recording errors, loss
of recorded DATA, and sudden loud noises to be output
through monitoring equipment, which could result in
damaged equipment and hearing loss.
TASCAM HS-20
23
3 – Preparation
Setting the time of the built-in clock
1. Press the MENU key on the front panel to open the MENU
screen.
2. Touch the SYSTEM SETUP button to open the SYSTEM SETUP
screen.
Lock function
Press the MENU key while pressing and holding the HOME key
on the front of the unit to open the LOCK SETUP screen. On
this screen you can turn on/off the lock function that disables
operation from the front panel and external devices.
3. Touch the CLOCK ADJUST tab to open the CLOCK ADJUST
page where you can set the built-in clock.
4. Touch the item that you want to change, and use the DATA
dial on the front panel to change the value.
The front panel is divided into two sections, which can be locked
and unlocked separately.
Types of external devices are also divided into two categories,
which can be locked and unlocked separately.
If you press the button for a section, it changes from UNLOCK to
LOCK (with a yellow background) and the locked area appears
dimmed.
Locked on LOCK SETUP screen
•
When the LCD section is set to LOCK:
o If the display is touched, the following pop-up message
appears when the display panel is locked.
5. Touch the SET button or push the DATA dial to confirm the
setting.
NOTE
After purchasing this unit, set the clock before making your
first recording. If you do not set the clock, the time stamps
on recorded files will be incorrect.
TASCAM HS-20
24
Display panel locked
3 – Preparation
o If one of the keys around the display is pressed, the
following pop-up message appears when the display keys
are locked.
Display keys locked
•
When Transport is set to LOCK, if one of the transport keys is
pressed, the following pop-up message appears.
Transport locked
•
When REMOTE/KEYBOARD is set to LOCK, if a remote
control or keyboard connected to a remote connector is
used, the following pop-up message appears.
Recording times
This table below shows the total amount of recording time (in
hours and minutes) possible on SD/CF cards of various capacities for each recording format.
File recording
format
16-bit, 44.1kHz12:3425:1050:21
16-bit, 48kHz11:3223:0746:16
24-bit, 44.1kHz8:2216:4633:34
24-bit, 48kHz7:4115:2430:50
24-bit, 88.2kHz4:118:2316:47
24-bit, 96kHz3:507:4215:25
24-bit, 176.4kHz2:054:118:23
24-bit, 192kHz1:553:517:42
o The recording times shown above are estimates. They
might differ depending on the card in use.
o The recording times shown above are not continuous
recording times, but rather they are the total possible
recording times for the card.
Card capacity
8 GB16 GB32 GB
Remote/Keyboard locked
•
When EXTERNAL CONTROL is set to LOCK, if an operation is
attempted using RS-232C, RS-422, PARALLEL or NETWORK
control, the following pop-up message appears.
External control locked
TASCAM HS-20
25
4 – Basic operation
In this chapter, we explain the basic operation procedures that
are the same in each operation mode.
The display on this unit functions as a touchscreen.
Operate the unit using its keys, switches and touchscreen
display buttons.
On every screen except the Home Screen, a
at the top left. Touch this button to return to the previous
screen.
button appears
NOTE
You can also return to the previous screen by pressing the
EXIT/CANCEL [PEAK CLEAR] key.
SD/CF card preparation
Card selection
1. Press the MENU key on the front panel to open the MENU
screen.
2. Touch the MEDIA MANAGE button to open the MEDIA
MANAGE screen.
3 Touch the SELECT button from the MEDIA SELECT item to
open the MEDIA SELECT screen.
NOTE
You can also open the MEDIA SELECT screen by touching the
recording media info button on the Home screen.
4 Touch the button for the card that you want to use to select
it.
The background of the selected card appears yellow.
5 Touch the SET button to return to the MEDIA MANAGE
screen.
6. If you also want to format the card now, follow the
procedure starting with step 3 in “Formatting SD/CF cards”
next.
TASCAM HS-20
26
4 – Basic operation
Formatting SD/CF cards
CAUTION
•
Formatting an SD/CF card erases all the data on it.
•
Always format SD and CF cards with this unit before using
them in it. If an SD/CF card that has been formatted by
another device or PC is used, operation might be affected.
1 Press the MENU key on the front panel to open the MENU
screen.
4. Click the OK button in the pop-up window. A reconfirmation
pop-up window appears.
5. Click the OK button in the pop-up window.
During formatting, the following pop-up message appears.
When formatting ends, the Home Screen opens.
2 Touch the MEDIA MANAGE button to open the MEDIA
MANAGE screen.
3 Touch the QUICK button next to the SD FORMAT or CF
FORMAT item, the following message appears on the
pop-up window.
NOTE
If no card is inserted in that slot, the following pop-up
message appears.
TASCAM HS-20
27
4 – Basic operation
Setting the master clock
1 Press the HOME key on the front panel to open the Home
Screen.
2 Touch the SYNC button to open the SYNC T/C screen.
Setting inputs and outputs
Setting the inputs
1. Press the MENU key on the front panel to open the MENU
screen.
2. Touch the AUDIO I/O button to open the AUDIO I/O screen.
NOTE
You can also open the SYNC T/C screen by touching the
SYNC T/C button on the MENU screen.
3 Select the master clock that you want to use from the
MASTER item. (See “Sync and timecode settings (SYNC T/C)”
on page 81.)
On the INPUT page, make settings for input source. For
details, see “INPUT page” on page 90.
Setting reference levels
1. Press the MENU key on the front panel to open the MENU
screen.
TASCAM HS-20
28
4 – Basic operation
2 Touch the SYSTEM SETUP button to open the SYSTEM SETUP
screen.
On the PREFERENCES page, set the digital reference level
(Digital Ref. Level).
(You can also select the type of keyboard.)
For details, see “PREFERENCES page” on page 91.
Connecting headphones
Connect headphones to the PHONES jack on the front panel.
Keep the headphones knob turned all the way to the left
(volume minimized) when connecting headphones.
Recording operation limitations
With this unit, recording in a folder becomes impossible when
the total number of files, subfolders and other items in that
folder becomes large. For this reason, the following things might
occur.
o When the total number of items in one folder
exceeds about 20000
Recording of a new take might not be possible even when
starting recording from a stopped state. When a folder is
loaded, recording to that folder might not be possible. In
these cases, the following pop-up message appears.
o When recording/editing is repeated in timeline
mode and the available memory runs short
Repeating recording/editing may greatly consume memory
to manage regions or editing history. In this case, recording
cannot be performed, and the following pop-up message
appears:
Headphones
CAUTION
Before connecting headphones, turn the PHONES knob to
the minimum volume. Failure to do so might cause sudden
loud noises, which could harm your hearing or result in
other trouble.
In this case, the remaining recording time indicator for the
currently selected card on the Home Screen shows Rec Limit.
CAUTION
The total number of items inside one folder includes files
and folders not created by this unit.
Management files, system files and other files and folders
that are not ordinarily visible are also included in the total.
TASCAM HS-20
29
5 – FILE LIST
Explanation of folder structure
This unit manages audio files in audio folders.
Each SD/CF card has an "HS Files" folder that holds audio folders
that contain audio files (which are called "takes") in groups.
Folder structure
The folder structure is as shown below.
You can check the SD/CF card folder and file structure by
accessing it from a computer using a card reader, for example.
Be aware, however, if you change or erase files inside a folder,
or change any names, the unit might not be able to play the
contents of that folder.
NOTE
Other management files and folders are also created.
File names
The format used in naming files is as follows.
[Take name first half]-[letter][take number].wav
This unit can record and play files with the following types of
formats.
File formats:BWF/WAV*
Sampling frequencies: 44.1/48/88.2/96/176.4/192 kHz
Quantization bit depth: 16/24 bits
Number of tracks:2
*This unit cannot record ordinary WAV files.
(It can only play them.)
FILE LIST screen overview
Press the FILE LIST key on the front of the unit to open the
AES31 file selection, take selection or playlist selection screen
according to the operation mode.
When one of these screens is open, press the FILE LIST key to
open the audio folder selection screen.
When the audio folder selection screen is open, press the FILE
LIST key to open the root folder selection screen.
Root folder selection screen
o Directory display
The current directory level and number of subfolders
within the root folder are shown.
(In the example above, the root directory of the SD card
contains two folders.)
o NUM OF FOLDER column
Shows the total number of folders in the root directory.
o Fs
Shows the sampling frequency setting used when
recording for each folder. The sampling frequency values
are abbreviated as follows.
Sampling frequencies:Fs abbreviation
44.1kHz44k
47.952 kHz (48 kHz –0.1% pull-down)*48k–
48.048 kHz (48 kHz +0.1% pull-up)*48k+
88.2kHz88k
176.4kHz176k
*This unit is not compatible with 47.952/48.048kHz
recording/playback. When loaded, "Unsupported Fs."
appears in a pop-up and recording and playback are
disabled.
o ENTER button
Touch the e button for the current folder (the letter
“C” appears in the icon, which is also highlighted
yellow) to view its contents.
If you touch the e button for any folder other than the
current folder, a pop-up window will appear confirming
that you want to load that folder. Touch the OK button
to show the contents of that folder after it completes
loading.
o Folder Name button
TASCAM HS-20
30
Loading...
+ 98 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
