Tait TPAB1A, TPAH5A Users Guide

TP9100 portables
User’s Guide
Version 0.1
July 2004

For your safety

Please read the following safety and compliance information before using your radio.

Radio frequency exposure information

For your own safety and to ensure you comply with the Federal Communication Commission’s (FCC) radio frequency (RF) exposure guidelines, please read the following information before using this radio.

Using this radio

You should use this radio only for work-related purposes (it is not authorized for any other use) and if you are fully aware of, and can exercise control over, your exposure to RF energy. To prevent exceeding FCC RF exposure limits, you must control the amount and duration of RF that you and other people are exposed to.
It is also important that you:
Do not remove the RF Exposure label from the
radio.
Ensure this RF exposure information accompanies
the radio when it is transferred to other users.
For your safety
Do not use the radio if you do not adhere to the
guidelines on controlling your exposure to RF.

Controlling your exposure to RF energy

This radio emits radio frequency (RF) energy or radio waves primarily when calls are made. RF is a form of electromagnetic energy (as is sunlight), and there are recommended levels of maximum RF exposure.
To control your exposure to RF and comply with the maximum exposure limits for occupational/controlled environments, follow these guidelines:
Do not talk (transmit) on the radio more than the
rated transmit duty cycle. This is important because
For your safety i
For your safety
the radio radiates more energy when it is transmit­ting than when it is receiving.
When listening and talking on the radio, hold it
upright in front of your face so that it is at least one inch (2.5 cm) away from any part of your face. Keeping the radio at the recommended distance is important because exposure to RF decreases rapidly the further away the antenna is from your body.
Keep the antenna at least one inch (2.5 cm) from
your face at all times.
If you wear your radio, you must always put it in a
carrying accessory that has been specifically approved by Tait for this radio. Using non-approved body-worn accessories may mean you expose your­self to higher levels of RF than recommended by the FCC’s occupational/controlled environment RF expo­sure limits.
Ensure you only use Tait-approved antennas, batter-
ies, and accessories.
For more information on what RF energy is and how to control your exposure to it, visit the FCC website at http://www.fcc.gov/oet/rfsafety/rf-faqs.html.

Compliance with RF energy exposure standards

This two-way radio complies with these RF energy exposure standards and guidelines:
ii For your safety
United States Federal Communications Commis-
sion, Code of Federal Regulations; 47 CFR §§
1.1307, 1.1310, and 2.1093.
American National Standards Institute (ANSI) / Insti-
tute of Electrical and Electronic Engineers (IEEE) C95.1-1992
Institute of Electrical and Electronic Engineers (IEEE)
C95.1-1999 Edition.
This radio complies with the IEEE (FCC) and ICNIRP exposure limits for occupational/controlled RF exposure environments at operating duty factors of up to 50% transmitting (even though the approved batteries for this radio are rated for a 5-5-90 duty factor (5% talk­5% listen-90% standby)).

Radio frequency emissions limits in the USA

Part 15 of the FCC Rules imposes RF emission limits on electronic equipment to prevent interference to reception of broadcast services.
This radio complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.

Unapproved modifications or changes to radio

The radio is designed to satisfy the applicable compliance regulations. Do not make modifications or changes to the radio that are not expressly approved by Tait Electronics Ltd. Failure to do so could invalidate compliance requirements and void the user’s authority to operate the radio.
For your safety

Interference to radio communications

This radio complies with Part 15 of the FCC Rules which specifies the limits for a Class B digital device.
This radio generates, uses, and can radiate RF energy. This energy may cause harmful interference to radio communications if the radio is not installed and used according to the instructions in the user guide. If this radio does cause harmful interference, you should contact your radio provider for assistance.
For your safety iii
For your safety

Frequency band reserved for distress beacons

Frequency band 406 to 406.1 MHz is reserved for use by distress beacons. Transmissions should not be made within this frequency band.

Safe radio operation

Switch off the radio:
at petrol filling stations or near flammable liquids
or gases
in the vicinity of explosive devices and blasting
zones
before boarding an aircraft. Using your radio
while in the air is not permitted.
Using a handheld microphone or a radio while driving a vehicle may violate the laws and legislation that apply in your country or state. Please check the vehicle regulations in your area.

Interference with electronic devices

Some electronic devices may be prone to malfunction due to the lack of protection from RF energy that is present when your radio is transmitting.
iv For your safety
Examples of electronic devices that may be affected by RF energy are:
vehicular electronic systems such as fuel injection,
anti-skid brakes, and cruise control
medical devices such as hearing aids and pacemak-
ers
medical equipment in hospitals or health care facili-
ties.
Consult the manufacturer (or its representative) of the equipment to determine whether these electronic circuits will perform normally when the radio is transmitting.
For your safety v
For your safety
For your safety
vi For your safety

Contents

For your safety ................................................................ i
Radio frequency exposure information ......................... i
Using this radio........................................................ i
Controlling your exposure to RF energy ................... i
Compliance with RF energy exposure standards ...... ii
Radio frequency emissions limits in the USA ............... iii
Unapproved modifications or changes to radio .......... iii
Interference to radio communications ........................ iii
Frequency band reserved for distress beacons ............ iv
Safe radio operation .................................................. iv
Interference with electronic devices............................ iv
1 About this guide.......................................... 1
Document conventions ............................................... 1
Safety symbols used in this guide ............................ 1
Feedback about this manual ....................................... 1
Copyright information ................................................ 2
Disclaimer ................................................................... 2
2 Charging the battery before first use........ 3
Contents
3 About your radio ......................................... 5
About your digital radio .................................................6
Lack of static noise...................................................... 6
Coverage .................................................................... 6
Basic operation ...............................................................7
Turning your radio on/off ............................................ 7
Adjusting the volume .................................................. 7
About the channel selector ......................................... 7
Making calls................................................................ 7
Using keys to access commonly used features ................9
Three-way selector control .......................................... 9
Emergency key............................................................ 9
Viewing your function key settings.............................. 9
Understanding the radio display ...................................10
Display symbols......................................................... 10
Using the menus to access settings ...............................11
Contents vii
Selection keys........................................................... 11
Scroll keys ................................................................ 11
Accessing menus ...................................................... 11
Accessing frequently used menus ............................. 12
Using the scroll key Quick Access menu................ 12
Using the left selection key Quick Access menu .... 12
Understanding the radio indicators .............................. 14
Alert tones ............................................................... 14
Status indicators ....................................................... 15
Contents
viii Contents

1 About this guide

This user’s guide provides information about the TP9155 and TP9160 portable radios.

Document conventions

The following conventions are used in this guide:
Convention Explanation
Bold text Indicates text that appears on the
radio display.
Note:
Tip:
Indicates additional information that you may find useful to know.
Provides a helpful hint.

Safety symbols used in this guide

Within this guide, the following symbols are used to alert you to important safety information:
Warning: There is a potential risk of death or serious
injury.
Caution: There is the risk of minor or moderate injury
to people.
Important: There is a risk of equipment damage or
malfunction.

Feedback about this manual

Any enquiries regarding this manual as well as any comments, suggestions and notifications of errors, should be addressed to support@taitworld.com or to the Support Group Manager, Tait Electronics Limited, PO Box 1645, Christchurch, New Zealand.
About this guide
About this guide 1

Copyright information

All information contained in this manual is the property of Tait Electronics Limited. All rights are reserved. These manuals may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-readable form, without prior written permission from Tait Electronics Limited. All trade names referenced are the service mark, trademark, or registered trademark of the respective manufacturers.

Disclaimer

In the interests of improving the performance, reliability or servicing of the equipment, Tait Electronics Ltd reserves the right to update both the equipment or this user’s guide, without prior notice.
About this guide
2 About this guide
2 Charging the battery before
first use
Once you have unpacked your battery, you’ll need to charge it for the first time. This first charge is important because it prepares the battery for use. You should allow 12 hours for this first charge.
1 Put the battery in the charger.
2 Leave the battery to charge. Allow 12 hours.
3 When the battery is fully charged (as indicated by the
charger's LED), remove it from the charger.
Charging the battery before first use 3

Charging the battery before first use

Charging the battery before first use
4 Charging the battery before first use

3 About your radio

This section describes all the various buttons and keys on your radio.
This section covers:
About your digital radio
Basic operation
Using keys to access commonly used features
Understanding the radio display
Using the menus to access settings
Understanding the radio indicators
About your radio 5
About your radio

About your digital radio

You may notice some differences in the way digital and analog radios perform: the lack of static in low signal areas and consequently where you notice that coverage is poor.

Lack of static noise

You may notice the lack of static noise on digital channels. This lack of static is because your digital radio removes the “noise” from the transmission so that you hear only clear voice.

Coverage

With analog radios, a transmission gets progressively worse when you are in fringe areas or even slightly outside normal coverage areas. In these circumstances, you are probably able to still understand the transmission despite the amount of static because the human brain can interpret speech even when it is not perfectly clear.
With digital radios, the signal remains clear and then
About your radio
drops off quite quickly at the border of a transmission area. The reason for this is that a digital transmission is either received or it isn't.
Because of this difference you may notice that digital radios have different coverage patterns to analog radios. However, the actual coverage area between an analog and a digital voice system is very similar.
6 About your digital radio

Basic operation

The radio controls are the PTT key, power/volume control, channel selector, three-way selector control, scroll keys, selection keys, and function keys. Some keys have functions assigned to both short and long key presses:
a short key press is less than one second, and
a long key press is more than one second
The radio controls and their functions are described in the following sections.

Turning your radio on/off

Turn the power/volume control switch clockwise to turn on the radio. Turn the switch counterclockwise to turn the radio off.
Note: Your radio will automatically power-down if
there is insufficient charge in the battery.

Adjusting the volume

Rotate the power/volume control clockwise to increase the speaker volume and counterclockwise to decrease the volume.
Note: The volume control also changes the volume
level of the radio’s audible indicators.

About the channel selector

The channel selector allows you to select and change channels. When the radio is first switched on, the channel that is acquired is the one indicated by the current position of the channel selector switch.

Making calls

1 Select the required channel, scan group, zone or
preset call.
About your radio
Basic operation 7
2 Hold the radio so that the microphone is about 2.5
cm (1 inch) from your mouth and press the PTT key to transmit.
Note: If the channel is busy, you will not be able to
transmit. Wait until the red status LED has stopped flashing, and then try again.
3 Speak clearly into the microphone and release the
PTT key when you have finished talking.
About your radio
8 Basic operation

Using keys to access commonly used features

The function keys and three-way selector control provide quick access to the features you will use most often. The action that they perform (when pressed or turned) will depend on how your radio has been programmed.

Three-way selector control

You may be able to change zones using the three-way selector control (if your radio has been programmed in this way).

Emergency key

You may be able to activate emergency mode by pressing the emergency key (if your radio has been programmed in this way).

Viewing your function key settings

You can easily check which functions are assigned to the function keys, if you have forgotten.
About your radio
1 Press Menu, scroll to Radio Information and press
Select.
2 Scroll to Key Settings and press Select.
3 In the menu list, scroll to a function key and press
Select to view the function assigned to it.
Using keys to access commonly used features 9

Understanding the radio display

The messages and symbols you see on your radio display depends on the mode in which your radio is operating and the way it has been programmed.

Display symbols

These are the various symbols you may see on your radio display.
Symbol Meaning
RSSI (received signal strength indicator): the more bars, the stronger the signal being received by your radio
Network available: your radio has access to a digital network
Transmit: your radio is transmitting
Low-power transmit: your radio is transmitting on low power
About your radio
10 Understanding the radio display
Zone symbol: your radio is operating in this zone (the example shown is zone 3)
Scanning: your radio is monitoring a group of channels for activity
Monitor or squelch override: monitor or squelch override is active
Scrolling: you can use the scroll keys or
to move through a list

Using the menus to access settings

You can access settings and features for your radio using the menu. The menus available will depend on the way your radio has been programmed.
The selection and scroll keys enable you to select and move around the menus.

Selection keys

There are two selection keys beneath the display screen. How these keys work depends on the word that appears above them on the screen.

Scroll keys

The up and down scroll keys allow you to:
access the quick access menu
scroll up and down through a list, and select items.
Tip: If you press and hold the scroll keys, the scroll
speed increases.
display the previous or next part of a message that
is too long to be displayed on the screen.
About your radio

Accessing menus

1 To access the main menu, press the right selection
key whenever Menu appears above it.
Using the menus to access settings 11
2 Use the scroll keys to move through the list of
menus.
3 When the menu you want is highlighted, press
Select to enter the menu you have chosen.

Accessing frequently used menus

Depending on how your radio has been programmed, you may have two different ‘quick access’ menus. One quick access menu is displayed when you press a scroll key, and the other when you press the left selection key. These give you easy access to the menus you use most often.
Using the scroll key Quick Access menu
To use this Quick Access menu:
Press a scroll key or , and the Quick Access
About your radio
menu appears.
In this example, the Channels menu is the Quick Access menu. You can press a scroll key
to go directly to the
Channels menu.
or
The Channels menu, with a list of your available channels and scan groups, is now displayed.
Using the left selection key Quick Access menu
The text above the left selection key corresponds to the Quick Access menu, for example, Channels.
To use this Quick Access menu:
12 Using the menus to access settings
Press your left selection key , and the associated
menu appears.
Using the menus to access settings 13
About your radio

Understanding the radio indicators

The status LED indicator and the radio’s audible tones— together with the radio display—all combine to give you information about the state of your radio.
The most common operation of the indicators are described in the following sections.

Alert tones

Note: If quiet or silent mode has been turned on, you
will not hear any alert tones.
Tone Meaning
Two short beeps
One short beep
Radio turned on: the radio is powered on and ready to use
Radio turned off: the radio is powered off, or
Valid keypress: the action you have attempted is permitted
About your radio
One long, low­pitched beep
Invalid keypress: the action you have attempted is not permitted, or
Transmission inhibited: you have attempted to transmit but for some reason transmission is not permitted at this time
14 Understanding the radio indicators

Status indicators

Note: The way these indicators behave may be affected
by the way your radio is programmed.
Colour Meaning
Red (transmit)
Green (receive)
Amber (scanning)
Glowing: your radio is transmitting
Flashing: your transmit timer is about to expire, or your radio is stunned.
Glowing: you are receiving
Flashing: you have received a call
Glowing: your radio is scanning a group of channels for activity
Flashing: your radio has detected activity on a channel, and has halted on this channel
About your radio
Understanding the radio indicators 15
About your radio
16 Understanding the radio indicators
Loading...
