Tait TM9400 P25 User Manual

Download

TM9400 P25 Mobile Radios

Specifications Manual

MMB-00009-05 · Issue 5· November 2016

Contact Information

Tait Communications Corporate Head Office

Tait Limited P.O. Box 1645 Christchurch New Zealand

For the address and telephone number of regional offices, refer to our website: www.taitradio.com

All information contained in this document is the property of Tait Limited. All rights reserved. This document may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-readable form, without prior written permission from Tait Limited.

The word TAIT and the TAIT logo are trademarks of Tait Limited.

All trade names referenced are the service mark, trademark or registered trademark of the respective manufacturers.

Disclaimer

There are no warranties extended or granted by this document. Tait Limited accepts no responsibility for damage arising from use of the information contained in the document or of the equipment and software it describes. It is the responsibility of the user to ensure that use of such information, equipment and software complies with the laws, rules and regulations of the applicable jurisdictions.

Enquiries and Comments

If you have any enquiries regarding this document, or any comments, suggestions and notifications of errors, please contact your regional Tait office.

Updates of Manual and Equipment

In the interests of improving the performance, reliability or servicing of the equipment, Tait Limited reserves the right to update the equipment or this document or both without prior notice.

US640974, US640977, US698339, US702666, US7758996, US7937661, US8902804, US9107231.

This product may also be made under license under one or more of the following U.S. Patents: 5,146,497, 5,148,482, 5,164,986, 5,185,795, 5,185,796, 5,271,017, 5,377,229 and 5,502,767. The AMBE+2™ voice coding Technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding Technology is licensed solely for use within this Communications Equipment. The user of this Technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into a human-readable form. Protected by U.S. Patents 5,870,405, 5,826,222, 5,754,974, 5,701,390, 5,715,365, 5,649,050, 5,630,011, 5,581,656, 5,517,511, 5,491,772, 5,247,579, 5,226,084 and 5,195,166.

Environmental Responsibilities

Tait Limited is an environmentally responsible company which supports waste minimization, material recovery and restrictions in the use of hazardous materials.

The European Union’s Waste Electrical and Electronic Equipment (WEEE) Directive requires that this product be disposed of separately from the general waste stream when its service life is over. For more information about how to dispose of your unwanted Tait product, visit the Tait WEEE website at

www.taitradio.com/weee. Please be environmentally

responsible and dispose through the original supplier, or contact Tait Limited.

Tait Limited also complies with the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive in the European Union.

In China, we comply with the Measures for Administration of the Pollution Control of Electronic Information Products. We will comply with environmental requirements in other markets as they are introduced.

Intellectual Property Rights

This product may be protected by one or more patents or designs of Tait Limited together with their international equivalents, pending patent or design applications, and registered trade marks: NZ409837, NZ409838, NZ415277, NZ415278, NZ508806, NZ519742/NZ516280, NZ524369, NZ524378, NZ524509, NZ530819, NZ534475, NZ547713, NZ569985, NZ577009, NZ579051, NZ579364, NZ584534, NZ586889, NZ592624, NZ593888, NZ600346, NZ610563, NZ615954, NZ629167, NZ630718, NZ700387, NZ700908, NZ708662, NZ710766, NZ711325, NZ714188, AU 2004216984, AU2015215962, AU339127, AU339391, AU2015904806, EU000915475-0001, EU 0009154750002, UK1518031.8, US 8301682, US13/542147, US14/032876, US14/495334, US14/725922, US14/ 818712, US14/832420, US62/128101, US62/128129,

2 TM9400 Specifications Manual

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Regulatory Requirements and Industry Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Performance Figures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Definition of NB and WB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Frequency Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Australia and New Zealand Citizens Band. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

FCC Narrowbanding Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

RF Output Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Product Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Associated Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Publication Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2 Receiver Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Analog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Digital. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3 Transmitter Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Analog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Digital. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4 General Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Radio Controls, Connectors and Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Control Head. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Radio Body . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Radio Size, Weight, and Finish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Frequencies and Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Number of Networks, Zones, Channels and Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Operational Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

P25 Phase 1 and Phase 2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Current Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Radio Body When Off or Receiving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Radio Body When Transmitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Control Head Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

TM9400 Specifications Manual Contents 3 © Tait Limited November 2016

1Introduction

This manual lists some of the regulatory requirements and industry standards that the TM9400 series of mobile radios satisfy, and explains how the radio specifications were derived. Separate chapters compare the performance of the receiver (Section 2) and of the transmitter (Section 3) with requirements specified by the European Telecommunications Standards Institute (ETSI) and the Telecommunications Industry Association (TIA). Section 4 provides general radio specifications.

Notice The TM9400 specifications in this manual are typical performance figures and are intended only to provide guidance. They are subject to change without notice and shall not form part of any contract. To establish whether the radio meets the regulatory requirements that apply to you, please contact your regional Tait office.

Notice For known issues and limitations that may cause a radio to perform outside the specifications listed here, see the software release notes for the TM9400. Software release notes are on the Tait support website, http://support.taitradio.com.

4 Introduction TM9400 Specifications Manual

Regulatory Requirements and Industry Standards

Regulatory Requirements

TM9400 radios meet and exceed the following regulatory requirements (where applicable):

■ CFR 47

■ AS4295-2004

■ EN 300 086-1

■ EN 300 113-1

■ EN 300 219-1

■ EN 301 489-1

■ EN 60950-1

■ RSS-119

A regulatory requirement issued by ETSI. ETSI requirements do not

apply to radios operating in the 700/800/900MHz frequency bands.

Industry Standards TM9400 radios also meet and exceed industry standards that include:

■ Relevant sections of TIA-102-CAAB-D (Land Mobile Radio

Transceiver Performance Recommendations, Project 25 - Digital Radio Technology, C4FM/CQPSK Modulation)

■ Relevant sections of TIA-102.CCAB-A (Project 25 Two-Slot Time

Division Multiple Access Transceiver Performance Recommendations)

■ Relevant sections of TIA-102.BCAF (Project 25 Trunked TDMA Voice

Channel Conformance Profiles)

■ Relevant sections of TIA-603-D (Land Mobile FM or PM

Communications Equipment Measurement and Performance Standards)

■ P25-CAB-CAI_TEST_REQ (Project 25 Compliance Assessment

Program, Baseline Common Air Interface Testing Requirements)

■ MIL-STD 810 G (Environmental Engineering Considerations and

Laboratory Tests, see also "Environmental" on page 30)

TIA standards are adopted by TIA in accordance with the American National Standards Institute (ANSI) patent policy.

For applicable Ingress Protection (IP) ratings and military standards, as well as details of the applicable Electrostatic Discharge (ESD) standard, see "Environmental" on page 30.

Quality Assurance Tait is an ISO9001: 2000 and ISO14001: 2004 certified supplier.

Voco der TM9400 radios use AMBE+2™ voice coding technology.

TM9400 Specifications Manual Introduction 5 © Tait Limited November 2016

Performance Figures

TM9400 specifications were derived by measuring typical performance and then averaging that measurement across multiple points in each RF band.

In contrast, all figures quoted as regulatory requirements are guaranteed minimum performance figures for equipment operated at standard room temperature, +71.6 °F to + 82.4°F (+22 °C to +28°C) and standard test voltage (13.8VDC).

Performance figures quoted as ‘typical’ are generally better than performance figures quoted as ‘guaranteed minimum’.

Definition of NB and WB

The terms ‘narrow bandwidth’ and ‘wide bandwidth’ are used as follows:

Term Abbreviation

Narrow bandwidth NB 12.5kHz/15kHz ±2.5kHz

Wide bandwidth WB 25kHz/30kHz ±5kHz

Frequency Bands

Tait uses a unique alpha-numeric code to represent each frequency band. The frequency codes currently used with the TM9400 series of radios are listed below. These codes are used throughout this manual.

Frequency code Frequency band

Channel

spacing

B1 136MHz to 174MHz

H5 400MHz to 470MHz

H7 450MHz to 520MHz

K5 757MHz to 870MHz (Tx)

757MHz to 776MHz (Rx) 850MHz to 870MHz (Rx)

100% deviation

Modulation

a. H5- and H7-band radios are also approved for operation on the Australia

and New Zealand Citizens Band frequencies (476.425 to 477.4125MHz). Citizens Band performance limits apply to radios used in this band.

6 Introduction TM9400 Specifications Manual

Australia and New Zealand Citizens Band

AS/NZS 4365 deals with the use of frequencies in the 476.425 to

477.4125MHz band. Products capable of operating in this band have been approved for operation in the UHF Citizens Band Radio Service which is licensed in Australia by the ACMA Radiocommunications (Citizens Band Radio Stations) Class Licence and in New Zealand by the MBIE General User Radio Licence for Citizens Band Radio. Operation is subject to conditions contained within those licences.

Repeaters operate by receiving a transmission on one channel and retransmitting it on another. Operators are required to avoid using local repeater input channels, which will be in the range of 31 to 38 (and 71 to 78 when authorized), unless it is intended to use the repeater facility, and to avoid using local repeater output channels, which will be in the range 1 to 8 (and 41 to 48 when authorized), at any time. Operators must always listen in on a channel (or observe a channel-busy indicator) to ensure it is not already being used before transmitting.

No voice transmissions are permitted on data channels 22 and 23. Equipment meeting this standard will inhibit voice operation on channels 22 and 23.

Operators must be aware of the consequences of narrowband (2.5 kHz deviation) transmissions being received on older wideband equipment, and wideband (5.0kHz deviation) transmissions being received on newer narrowband equipment. They should also be aware of the possibility of interference due to older equipment being operated on channels adjacent to new narrowband channels. The list of currently authorized channels can be obtained from the ACMA website in Australia and the MBIE website in New Zealand.

In Australia:

■ Except in an emergency, a CB transmitter must not be operated on UHF

channels 5 and 35.

■ Channel 11 is the customary calling channel for establishing

communications.

■ Channel 40 is the customary road vehicle channel.

TM9400 Specifications Manual Introduction 7 © Tait Limited November 2016

FCC Narrowbanding Regulations

The following information applies to all radios, not just to those sold in countries where FCC regulations apply.

From 1 January 2013 it is an FCC requirement that land mobile radio systems must not operate channels with a bandwidth greater than 12.5kHz in the 150–174MHz and 421 – 470MHz frequency bands. From this date all radios will be supplied with firmware that requires a software feature license to operate a medium or wide bandwidth channel in these frequency bands.

The 20/25kHz Unrestricted Wideband feature license is available to any customer who is not subject to the relevant FCC regulations, or who has an FCC waiver. Note that this feature license is not required to operate a medium or wide bandwidth channel on the spot frequencies which are exempt from the FCC requirement:

■ 152.0075, 157.450, 152.480, 157.740 and 158.460MHz in the

150–174 MHz frequency band

■ 462.750, 462.775, 462.800, 462.825, 462.850, 462.875, 462.900,

462.925, and 465MHz in the 421– 470MHz frequency band.

To obtain the feature license, or for more information about it, contact your regional Tait office.

If your network is in the 700MHz band and falls under the jurisdiction of the FCC, you may be required to move to P25 Phase 2 operation so as to obtain a spectrum efficiency equivalent to 6.25kHz per channel.

8 Introduction TM9400 Specifications Manual

RF Output Power

TM9400 mobile radios are available with > 25 W and 25W RF output power. These RF output power options are implemented by different main boards in the radio body and mechanically different radio bodies. For information on which control head is currently available with each radio model, contact your regional Tait office.

The >25W radio is available in the following frequency bands:

■ B1 (50W)

■ H5 (40W)

■ H7 (40W)

■ K5 (30W for 757– 806 MHz, 35W for 806– 870MHz)

The 25W radio is available in the following frequency bands:

■ B1

■ H5

■ H7

Product Codes

The product code (T02-xxxxx-xxxx) printed on a radio label identifies both the radio model and the configuration of that particular radio. For a detailed explanation of product codes and how to interpret them, please refer to the TM9300/TM9400 Service Manual (MMB-00004-xx).

1. Radios approved for operation on the Australia and New Zealand Citizens Band have a maximum RF output power of 5W.

TM9400 Specifications Manual Introduction 9 © Tait Limited November 2016

Associated Documentation

Safety and Compliance Information MTA-00011-xx

TM9400 User’s Guide MMB-00003-xx

TM9300/TM9400 Installation Guide MMB-00002-xx

TM9300/TM9400 Service Manual MMB-00004-xx

Always get the latest issue of a manual from the Tait support website. Also available on the website are software release notes, and technical notes (TNs) which provide technical details not yet in the manuals, or solve any problems that may have arisen.

Document Conventions

Title IPN/Item code

Please follow exactly any instruction that appears in the text as an ‘alert’. An alert provides necessary safety information as well as instruction in the proper use of the product. This manual uses the following types of alert:

Notice This alert is used to highlight information that is required to ensure procedures are performed correctly. Incorrectly performed procedures could result in equipment damage or malfunction.

This icon is used to draw your attention to information that may improve your understanding of the equipment or procedure.

10 Introduction TM9400 Specifications Manual

Publication Record

Issue Date Description

1 January 2014 First release

2 October 2014 Information added for:

3 June 2015 Information added for:

4 May 2016 Information added for supply voltage ripple and

■ H7 band

■ P25 Phase 2 operation

■ emission designators.

Minor corrections and additions.

■ updated power levels for K5-band radios

■ updated power levels for B- and H-band 25W

radios

Minor corrections and additions.

noise.

5 November 2016 Information added regarding the transmit band

receiver frequency ranges. These have been updated: Transmit frequency range: 757-870MHz Receiver frequency range: 757-776MHz; 850870MHz.

TM9400 Specifications Manual Introduction 11 © Tait Limited November 2016

2 Receiver Specifications

This chapter compares the performance of the receiver in a TM9400 radio with receiver requirements specified by ETSI and TIA.

Where an ANSI/TIA or ETSI EN 300 113 test method was used to measure TM9400 performance, this is indicated in parentheses. Where the ETSI test method EN 300 086-1 was used, no test method is named. Please see also the footnotes to the tables.

Notice The TM9400 specifications in this manual are typical performance figures that are intended only to provide guidance. They are subject to change without notice and shall not form part of any contract. To establish whether the radio meets the regulatory requirements that apply to you, please contact your regional Tait office.

For important information about how radio performance figures were derived, see Chapter 1 Introduction.

12 Receiver Specifications TM9400 Specifications Manual

Analog

Compliance

limit Measured performance

Parameter

Adjacent channel selectivity

NB channel WB channel

Adjacent channel selectivity (TIA/EIA603 one-tone test method)

NB channel WB channel

Audio distortion at rated audio

Audio bandwidth

Audio response

All bands

>60dB >70dB

< 5% 0.6% 0.9%

65dB 74dB

intentionally

left blank

H5 H7 K5

64dB 73dB

64dB 72dB

300–3000Hz

(flat or with de-emphasis)

n/a

63dB 72dB

+1dB, –3dB +0.5dB, –2.5dB

Blocking

Co-channel rejection

NB channel WB channel

Frequency stability (TIA-603-D)

> 84dB > 110dB n/a

> –12 dB

> –8dB

±2.5ppm ±0.5ppm

>–7dB

>–2.5dB

n/a

TM9400 Specifications Manual Receiver Specifications 13 © Tait Limited November 2016

Compliance

limit Measured performance (continued)

Parameter

All bands

Intermodulation rejection

NB channel WB channel

>65dB >65dB

Intermodulation rejection (TIA-603-D)

NB channel WB channel

>75dB >75dB

Mute opening point (Noise mute)

Country City Hard

Rated audio

Speaker rating

72dB

81dB

intentionally

left blank

intentionally

left blank

intentionally

left blank

H5 H7 K5

67dB 72dB n/a

76dB 79dB 79dB

8dB SINAD 12dB SINAD 20dB SINAD

3W into 16Ω load

Hum and noise (TIA-603-D)

NB channel 34dB 45dB

Sensitivity

(TIA-603-D)

NB channel

WB channel

NB channel WB channel

<–116dBm

(0.35μV)

<–116dBm

(0.35μV)

< –107dBm < –107dBm

–120dBm

(0.22μV)

–116dBm –118dBm

Signal displacement bandwidth (TIA-603-D)

NB channel WB channel

>40% >40%

120%

90%

–121dBm

(0.20μV)

–118dBm –119dBm

–––

–122dBm

(0.18μV)

n/a

14 Receiver Specifications TM9400 Specifications Manual

Compliance

limit Measured performance (continued)

Parameter

Spurious response rejection

NB channel WB channel

Spurious response rejection (TIA-603-D)

NB channel WB channel

a. See "Frequency Bands" on page 6.

b. See "Definition of NB and WB" on page 6.

c. Not applicable.

d. EN 300 086-1, TIA-603-D and TIA-102 test methods.

e. 12dB SINAD.

f. 20dB SINAD phosphometric weighting.

g. Unavailable at time of publication.

h. 1/2-IF spurious response degrades at the edges of the band.

All bands

>70dB >70dB

>75dB >75dB

73dB 76dB

82dB 84dB

Sensitivity, distortion, and signal-to-noise figures are for standard operating conditions that include audio de-emphasis.

intentionally

left blank

75dB 75dB

85dB 85dB

H5 H7 K5

72dB 72dB

82dB 82dB

n/a

84dB 84dB

TM9400 Specifications Manual Receiver Specifications 15 © Tait Limited November 2016

Digital

Compliance

limit Measured performance

Parameter All bands

Sensitivity

(TIA-102)

<–116dBm

(0.35μV)

Selectivity

(TIA-102)

> 60dB 62dB

Selectivity (EN 300 113)

> 60dB 62dB 61dB 60dB

Residual audio noise ratio (TIA-102)

45dB 65dB –––

Intermodulation rejection (TIA-102)

> 75dB 79dB

–121dBm

(0.20μV)

intentionally

left blank

intentionally

left blank

H5 H7 K5

–122dBm

(0.18μV)

–123dBm

(0.16μV)

76dB 78dB 78dB

n/a

Spurious response rejection (TIA-102)

> 80dB 82dB

Co-channel rejection (EN 300 113)

–12dB –9dB

Blocking (EN 300 113)

> 84dB > 105dB > 100dB

a. See "Frequency Bands" on page 6.

b. P25 Phase 1 C4FM receiver and Phase 2 H-DQPSK receiver.

c. Unavailable at time of publication.

d. Not applicable.

e. 1/2-IF spurious response degrades at the edges of the band.

intentionally

left blank

84dB 82dB 85dB

16 Receiver Specifications TM9400 Specifications Manual

3 Transmitter Specifications

This chapter compares the performance of the transmitter in a TM9400 radio with transmitter requirements specified by ETSI and TIA.

This equipment is compatible with the emissions listed in the following table.

Notice Some emission designators may not apply in all regions. Not all models support all emission designators. Contact your regional Tait office for details.

Emission

Designator Common Name

11K0F3E analog voice analog FM NB voice

16K0F3E analog voice analog FM WB voice

6K60F2D FFSK data FFSK NB data - 1200 bps

7K80F2D FFSK data FFSK NB data - 2400 bps

9K60F2D FFSK data FFSK WB data - 1200 bps

10K8F2D FFSK data FFSK WB data - 2400 bps

8K10F1E P25 Phase 1 C4FM digital voice

8K10F1D P25 Phase 1 C4FM data/control channel

8K10F7W P25 Phase 1 C4FM digital voice/data/

8K10F1W P25 Phase 2 H-CPM digital voice /data

Modulation

Scheme Operating Modes

control channel

For important information about how radio performance figures were derived, see Chapter 1 Introduction.

TM9400 Specifications Manual Transmitter Specifications 17 © Tait Limited November 2016

Analog

Compliance

limit Measured performance

Parameter

All bands

25W 50W 25W 40W 30/35W

Audio distortion at 1kHz with 60% modulation

<2% 0.6%

Audio response

+1dB, –3dB +0.5dB, –2.5dB +0.6dB, –2dB

Conducted emissions

<1GHz >1GHz

< –36dBm < –30dBm

–38dBm –40dBm

Conducted emissions (TIA-603-D)

25W radios >25W radios

>64dBc >67dBc

75dBc

FM hum and noise (TIA-603-D)

n/a

87dBc

intentionally

left blank

H5, H7 K5

0.6% 1.4%

–38dBm –36dBm

84dBc

n/a n/a

94dBc > 75dBc

NB channel WB channel

>34dB >40dB

Adjacent channel power (TIA-603-D)

NB channel WB channel

Wideband noise

60dBc 70dBc

100kHz offset 1MHz offset

1.5MHz offset 4MHz offset 12MHz offset

n/a

(Tait in-house

test only)

10MHz offset 45MHz offset

Modulation

47dB 48dB

65dBc 74dBc

66dBc 76dBc

– 130dBc/Hz – 145dBc/Hz

– 149dBc/Hz

n/a n/a

– 154dBc/Hz

n/a

47dB 48dB

intentionally

left blank

intentionally

left blank

intentionally

left blank

51dB 52dB

64dBc 73dBc

– 135dBc/Hz – 142dBc/Hz

– 147dBc/Hz

– 148dBc/Hz

Analog FM

n/a

50dB 55dB

65dBc 74dBc

40dB 48dB

65dBc 73dBc

– 126dBc/Hz – 138dBc/Hz

n/a

– 145dBc/Hz

n/a

– 146dBc/Hz

n/a

18 Transmitter Specifications TM9400 Specifications Manual

Compliance

limit Measured performance (continued)

Parameter

Modulation limiting

NB channel WB channel

RF power output

High Medium Low Ver y low

Transmit timer

Duty cycle

25W radios at 25W

(+60°C ambient temperature)

All bands

±2.5kHz ±5.0kHz

25W 50W 25 W 40W 30/35 W

intentionally

left blank

H5, H7 K5

±2.2kHz ±4.4kHz

25W 10W

5W 1W

50W 25W 15W 10W

intentionally

left blank

25W 10W

5W 1W

40W 25W 15W 10W

Programmable. 1 to 250 seconds, or 0 (no timer)

33%

n/a

intentionally

left blank

33%

n/a n/a

30/35W

25W 10W

25W radios at 5W (+40°C ambient temperature)

> 25W radios at rated output

power (+60°C ambient temperature)

a. See "Frequency Bands" on page 6.

b. EN 300 086-1 and TIA-603-D test methods.

c. Not applicable.

d. See "Definition of NB and WB" on page 6.

e. These figures are typical across the frequency band and can vary ±6 dB with frequency.

f. 30W for 757–806MHz, 35W for 806–870MHz.

g. At 16V.

h. 2min Tx, 4min Rx.

i. At 13.8 V.

j. Continuous Tx.

k. 1min Tx, 4min Rx.

100%

n/a

n/a 20%

intentionally

left blank

intentionally

left blank

100%jn/a n/a

n/a 20%

20%

TM9400 Specifications Manual Transmitter Specifications 19 © Tait Limited November 2016

Digital

Compliance

limit Measured performance

Parameter

All bands

25W 50 W 25W 40W 30/35 W

Modulation

Adjacent channel power ratio (TIA-102)

P25 Phase 1 P25 Phase 2

67dBc 65dBc

Adjacent channel power ratio (EN 300 113)

60dBc 60 dBc n/a

Transient adjacent channel power ratio (EN 300 113)

50dBc 58 dBc n/a

intentionall y left blank H5, H7

FFSK, C4FM, H-CPM

67dBc 65dBc

intentionally

left blank

intentionally

left blank

60dBc n/a n/a

56dBc n/a n/a

Transmitter power attack time (TIA-102)

< 50ms 35ms

Transmitter encoder attack time (TIA-102)

< 100ms 57ms

Throughput delay (TIA-102)

< 125ms 55ms 50ms

Modulation fidelity (TIA-102)

<5% 0.5%

a. See "Frequency Bands" on page 6.

b. Not applicable.

intentionally

left blank

intentionally

left blank

intentionally

left blank

intentionally

left blank

43ms 38ms

67ms 62ms

55ms

39ms

61ms

47ms

0.5% 0.6% 0.6%

20 Transmitter Specifications TM9400 Specifications Manual

4 General Specifications

This chapter provides general specifications for the TM9400 mobile radios.

■ For radio compliance specifications, see "Regulatory Requirements and

Industry Standards" on page 5.

■ For receiver performance specifications, see Chapter 2 Receiver

Specifications.

■ For transmitter performance specifications, see Chapter 3 Transmitter

Specifications.

The product code printed on the radio label identifies both the radio model and the configuration of that particular radio. For an explanation of product codes, please refer to the TM9300/TM9400 Service Manual (MMB-00004-xx).

TM9400 Specifications Manual General Specifications 21 © Tait Limited November 2016

Radio Controls, Connectors and Dimensions

Figure 4.1 User interfaces

press-to-talk (PTT) key

microphone

display

on/off key

volume control

microphone socket

radio status LEDs

red

Graphical control head

green

amber

speaker

function keys 1 to 4

function key 1

function key 2

function key 3

press-to-talk (PTT) key

left selection key

volume up

volume down

scroll keys

left selection key right selection key

on/off key

status LEDs

microphone

display

right selection key

scroll keys

function keys 4to6

alphanumeric keys

Hand-held control head

22 General Specifications TM9400 Specifications Manual

Figure 4.2 Connectors of the radio body (25W radio shown)

front view

control-head

connector

provision for

external options

connector

auxiliary

connector

provision for

additional connector

power

connector

rear view

connector

internal options

connector

top view

TM9400 Specifications Manual General Specifications 23 © Tait Limited November 2016

Figure 4.3 Connectors of the graphical control head

microphone

connector

rear view with adapter flange

front view

control-head

connector

Figure 4.4 Dimensions of radio with remote body interface (25 W radio shown)

*Mobile radios >25 W are

0.79 in. (20 mm) longer due to a larger heatsink

7.48 in. (190 mm) / 8.27 in (210 mm)*

7.08 in. (179.8 mm) / 7.87 in (199.8 mm)*

2.07 in. (52.61 mm)

Other dimensions are as shown in Figure 4.5 on page 25

24 General Specifications TM9400 Specifications Manual

Figure 4.5 Dimensions of U-bracket installation of radio with graphical control head

(25W radio shown)

7.20 in. (184 mm)

2.8 in. (71 mm)

llow clearance around radio if tilting of radio on bracket is desired

2.87 in. (73 mm)

7.64 in. (194 mm) / 8.43 in (214 mm)*

5.42 in. (137.7 mm) / 6.2 in (157.7 mm)*

1.12 in. (28.5 mm)

7.17 in. (182 mm) / 7.95 in (202 mm)*

3.21 in. (81.5 mm)

3.99 in. (101.5 mm)*

Mobile radios >25 W are

1.90 in. (48.42 mm) thick

Allow space at rear for cable routing and air movement around fins

1.77 in. (45 mm)

1.90 in. (48.42 mm)

*Mobile radios >25 W are

0.79 in. (20 mm) longer due to a larger heatsink

2.36 in. (60 mm)

0.2 in. (5 mm)

1.48 in. (37.5 mm)

3.65 in. (100.3 mm) / 4.73 in (120.3 mm)* (dimension varies when radio is tilted)

3.62 in. (92 mm)

(tabs unbent)

3.74 in. (95 mm)

4.72 in. (120 mm)

6.3 in. (160 mm)

6.42 in. (163 mm) (U-bracket width)

7.20 in. (183 mm)

(allow access to thumb screws)

TM9400 Specifications Manual General Specifications 25 © Tait Limited November 2016

Figure 4.6 Dimensions of remote graphical control head installation

8.21 in (208.5 mm)

3.03 in (77.0 mm)

2.4 in (61 mm)

1.38 in. (34.0 mm)

3.15 in. (80.0 mm)

5.35 in. (136.0 mm)

Figure 4.7 Dimensions of hand-held control head

2.59 in (65.7 mm)

1.04 in (26.5 mm)

2.22 in (56.3 mm) 1.39 in (35.2 mm)

1.43 in (36.4 mm)

8.13 in (206.5 mm)

0.28 in.

(7.0 mm)

5.31 in (135.0 mm)

6.57 in (167.0 mm)

14.9 in (378 mm)

10.76 in (273.3 mm)

26 General Specifications TM9400 Specifications Manual

User Interface

Control Head

Graphical control head Hand-held control head

Display 4-line graphical

(160x64 pixels)

Connectors one 8-way RJ45

(microphone/programming)

Function keys 4 6

Keypad

Function keys Scroll keys Selection keys Volume keys

Alphanumeric keys Via keypad microphone

LED status indicators

Status LED Function key LED

Push-to-talk (PTT) button Via connected microphone On left side

✔ ✔ ✔

(if connected)

3 2

4-line graphical

(96x62 pixels)

one 8-way RJ45

(programming)

✔ ✔ ✔ ✔

✔

None

Hookswitch and hanger plate Included with microphone Included with control head

Speaker Internal, 16 Ω impedance, >3W None

Microphone Via connected microphone;

covert microphone (internal)

Volume Rotary control Volume keys

On-off On-off key On-off key

Internal

Radio Body

Connectors

RF Power

Auxiliary Internal options

Speaker Optional external (using power connector), maximum power 10 W into 4 Ω,

Microphone Optional auxiliary (e.g. handsfree)

On-off Optional external (e.g. ignition sense)

a. Includes 1 serial, 3 input, 4 I/O, 1 audio tap in, 1 audio tap out.

b. Includes 1 serial, 7 I/O, 1 audio tap in, 1 audio tap out.

50Ω BNC or mini-UHF Between 10.8 and 16V DC, negative ground

- supply voltage ripple: <10mV

- noise: <500mV 15-way D-range 18-pin Micro-MaTch connector

balanced load configuration

(800Hz to 8kHz) or 100mVpp if connected directly to a battery

(8kHz to 200kHz)

28 General Specifications TM9400 Specifications Manual

Radio Size, Weight, and Finish

Graphical

Body

(25W)

Dimensions

Depth

Width

Height

Weight (radio body and control heads)

Weight (accessories)

Rugged microphone Keypad microphone Control head bracket

Finish Plastic: black, with coarse texture.

5.9in

(150mm)

6.3in

(160 mm)

1.8in

(45mm)

37.1oz

(1050g)

Body

(>25W)

6.7in

(170mm)

6.3in

(160mm)

1.9in

(48.5mm)

44.9oz

(1270g)

Keys and keypads: silicone rubber.

control

head

1.97in

(50mm)

7.2in

(184mm)

2.8in

(71mm)

12oz

(340g)

7oz (200g)

7.5oz (212 g)

4.6oz (130 g)

Aluminium: diecast

Remote

control head

with backing

2.4in

(61mm)

7.2in

(184mm)

2.8in

(71mm)

14.1oz (400g)

Hand-held

control

head

1.38in

(35mm)

2.56in

(65mm)

5.31in

(135mm)

10.2oz (289g)

a. 2in (52 mm) across the chassis flange.

b. Including the control knob.

c. Height measured to top of curly cord connector.

Environmental

Operating temperature –22°F to +140°F (–30 °C to +60°C)

Ingress Protection (IP) rating The radio body and control head, when installed correctly with

seals and socket bungs, is IP54 rated. This includes the standard and keypad microphones, and hand-held control head.

Electrostatic Discharge (ESD) standard International Electrotechnical Commission (IEC) 61000-4-2

Military standard (MIL-STD) MIL-STD-810G

Method Procedure

Low pressure 500.5 2

High temperature 501.5 1 and 2

Low temperature 502.5 1 and 2

Temperature shock 503.5 1

Solar radiation 505.5 1

Rain 506.5 1 and 3

Humidity 507.5 2

Salt fog 509.5 1

Dust 510.5 1 and 2

Vibration 514.6 1

Shock 516.6 1, 5 and 6

a. The TM9400 also meets the equivalent superseded standards MIL-STD-810C, D, E, and F.

See also "Regulatory Requirements and Industry Standards" on page 5.

30 General Specifications TM9400 Specifications Manual

Frequencies and Channels

25W 50 W 25 W 40 W 25W 40W 30/35W

Frequency increments

Channel spacing

NB channel WB channel

Frequency range (MHz), see "Frequency Bands" on page 6

Frequency stability, see Chapter 2 Receiver Specifications

IF bandwidth

NB channel WB channel

RF power output

intentionally

left blank

2.5kHz, 3.125kHz, 5kHz, 6.25 kHz

12.5 kHz/15kHz

H5 H7 K5

25kHz/30kHz

7.5kHz 15kHz

High Medium Low Ver y low

a. 30W for 757 – 870 MHz, 35 W for 806 – 870 MHz.

25W 10W

5W 1W

50W 25W 15W 10W

intentionally

left blank

25W 10W

5W 1W

40W 25W 15W 10W

25W 10W

5W 1W

40W 25W 15W 10W

30/35W

25W 10W

Number of Networks, Zones, Channels and Groups

Maximum

With optional

Minimum

Conventional networks 1 26 26

Zones 1 50 100

Channels (simplex or semi-duplex) 1 1000 2000

Standard

software license

Talk groups Total talk group members

Scan/vote groups Members per group Total scan/vote group members

1 1

0 2 0

1000

300

2000

300

2000

32 General Specifications TM9400 Specifications Manual

Operational Features

Analog operation P25 digital operation

Channels: simplex or semi duplex, with repeater talkaround option

Voting/scanning ✔✔

Predefined status messaging ✔✔

GPS Direct connect (send and

receive position reports),

2-tone signaling format Decode only ✘

5-tone Selcall ✔✘

CTCSS signaling format ✔✘

DCS signaling format ✔✘

DTMF signaling format Encode only ✘

MDC1200 signaling format ✔✘

Security/Encryption voice inversion scrambler

✔✔

Direct connect (send and

receive position reports),

GPS display

DES (optional)

(standard)

FIPS certified AES

GPS display

(optional)

Emergency: Lone Worker inactivity detection ✔✔

a. P25 conventional only.

P25 Phase 1 and Phase 2 Features

P25 Phase 2 is an extension of P25 Phase 1. A Phase 2 radio can still use the less spectrally-efficient Phase 1 features.

P25 Phase 1 P25 Phase 2

Standard Unit-to-unit call ✔✔

PSTN calls ✔✔

Supplementary messages ✔✔

Group call ✔✔

Emergency ✔✔

Pre-emption limited ✔

Encryption ✔✔

Motorola-specific Dynamic regrouping ✔✔

Supergroup ✔✔

a. Available but not field-tested at the time of publication.

34 General Specifications TM9400 Specifications Manual

Current Consumption

Current consumption was tested using radios in conventional mode with current radio hardware. All measurements were made in the middle frequencies of each band. Battery voltage was 13.8V, and radios transmitted into a 50Ω load.

Radio Body When Off or Receiving

Radio off (no links fitted) 3mA

Radio off (links LK1, LK2, LK3 fitted) (using ignition control to switch radio on and off)

Radio on stand-by (links LK1, LK2, LK3 fitted) (using ON/OFF key on control head to switch radio on and off)

Receiver idle (not scanning) 120mA

Receiver active, mute on 120mA

Receiver active, 3W audio into 16 Ω 680mA

Receiver active, 10W audio into 4Ω 2A

4mA

60mA

Radio Body When Transmitting

B1 G1 H5/H7 K5

25W 50 W 25 W 25 W 40W 30/35W

Power output

High Medium Low Ver y low

4.7A

3.2A

2.3A

1.5A

5.5A

4.5A

3.6A

4.0A

2.7A

1.9A

1.1A

5.5A

3.2A

2.2A

1.7A

7.2A

4.8A

4.1A

3.3A

8.8A

6.6A

4.2A 2A

Control Head Only

Graphical Control Head - Local Configuration

Notice The standard control head configurations assume the use of a

standard microphone. If the keypad microphone is used, add 60mA to the figures listed below.

Backlighting off, standby, LCD heater off 25mA

Backlighting on high, standby, LCD heater off 50 mA

Backlighting on high, standby, LCD heater on 295mA

Graphical Control Head - Remote Configuration

Hand-held Control Head - Remote Configuration

The remote configuration comprises the remote body interface, control head interface box (radio powered), remote control head interface, and the control head itself.

Backlighting on high, standby, LCD heater off 75 mA

Backlighting on high, standby, LCD heater on 320mA

Backlighting on high, full speaker audio, LCD heater off 540mA

Backlighting on high, full speaker audio, LCD heater on 785mA

The remote configuration has the hand-held control head connected directly to the remote body interface. The remote interface kit is not used.

Backlighting off 30mA

Backlighting on high 50mA

36 General Specifications TM9400 Specifications Manual

Tait TM9400 P25 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Specifications Manual

Contents

1Introduction

Regulatory Requirements and Industry Standards

Performance Figures

Definition of NB and WB

Frequency Bands

Australia and New Zealand Citizens Band

FCC Narrowbanding Regulations

RF Output Power

Product Codes

Associated Documentation

Document Conventions

Publication Record

2 Receiver Specifications

Analog

Digital

3 Transmitter Specifications

Analog

Digital

4 General Specifications

Radio Controls, Connectors and Dimensions

User Interface

Control Head

Radio Body

Radio Size, Weight, and Finish

Environmental

Frequencies and Channels

Number of Networks, Zones, Channels and Groups

Operational Features

P25 Phase 1 and Phase 2 Features

Current Consumption

Radio Body When Off or Receiving

Radio Body When Transmitting

Control Head Only
