Dimensions of Tacx trainer axles
T1707, T1708, T1709, T1710, T1711, T2835 & T2840
Last updated February 2016
Trainer axle for E-Thru 10 mm T1706
Suitable for Tacx trainers with rear wheel drive: Genius, IRONMAN, Bushido, Vortex, Flow, Satori, Booster, Blue Motion, Blue Matic and Blue Twist
162,5 Max
M10x1
10,5
All sizes are shown in millimeters (mm)
© Tacx B.V. All rights reserved | Dimensions Tacx trainer axles, last updated February 2016
183,50
8 4 4
10,5
23
Trainer axle for E-Thru 12 mm T1707
Suitable for Tacx trainers with rear wheel drive: Genius, IRONMAN, Bushido, Vortex, Flow, Satori, Booster, Blue Motion, Blue Matic and Blue Twist
162,5 Max
M12x1
10,5
All sizes are shown in millimeters (mm)
© Tacx B.V. All rights reserved | Dimensions Tacx trainer axles, last updated February 2016
183,50
8 4
4
10,5
23
Trainer axle M12x1.75 for E-Thru T1708
Suitable for Tacx trainers with rear wheel drive: Genius, IRONMAN, Bushido, Vortex, Flow, Satori, Booster, Blue Motion, Blue Matic and Blue Twist
179,5 Max
M12x1.75
10,5 4
8 4
200,5
All sizes are shown in millimeters (mm)
© Tacx B.V. All rights reserved | Dimensions Tacx trainer axles, last updated February 2016
10,5
31
Trainer adapter for X-12 axle T1709
Suitable for Tacx trainers with rear wheel drive: Genius, IRONMAN, Bushido, Vortex, Flow, Satori, Booster, Blue Motion, Blue Matic and Blue Twist
Bike frame
Ø 6,8
Ø 21,8
4,5
All sizes are shown in millimeters (mm)
© Tacx B.V. All rights reserved | Dimensions Tacx trainer axles, last updated February 2016
16,5
Trainer axle M12x1.5 for E-Thru T1710
Suitable for Tacx trainers with rear wheel drive: Genius, IRONMAN, Bushido, Vortex, Flow, Satori, Booster, Blue Motion, Blue Matic and Blue Twist
162,5 Max
M12x1.5
10,5
All sizes are shown in millimeters (mm)
© Tacx B.V. All rights reserved | Dimensions Tacx trainer axles, last updated February 2016
191
8
4
4
10,5
31
Trainer axle M12x1 for E-Thru T1711
Suitable for Tacx trainers with rear wheel drive: Genius, IRONMAN, Bushido, Vortex, Flow, Satori, Booster, Blue Motion, Blue Matic and Blue Twist
175 Max
M12x1
10,5 4
8 4
196
All sizes are shown in millimeters (mm)
© Tacx B.V. All rights reserved | Dimensions Tacx trainer axles, last updated February 2016
10,5
36
Direct drive quick release with adapter set 142x12mm T2835
Suitable for Tacx trainers with direct drive: NEO
182 Max
Ø 12
All sizes are shown in millimeters (mm)
© Tacx B.V. All rights reserved | Dimensions Tacx trainer axles, last updated February 2016
Direct drive quick release with adapter set 135x10mm T2840
Suitable for Tacx trainers with direct drive: NEO
161,5 Max
Ø 10
All sizes are shown in millimeters (mm)
© Tacx B.V. All rights reserved | Dimensions Tacx trainer axles, last updated February 2016
