Synology DS216+II User Manual

DiskStation DS216+II

Fulll your needs for safe data storage and ultra high denition video sharing with
Synology DiskStation DS216+II. Powered by an Intel® Celeron® dual-core CPU, DS216+II comes
with hardware-accelerated data encryption and real-time transcoding of 4K Ultra HD source
content. Synology DiskStation DS216+II is backed with Synology’s 2-year limited warranty.

Highlights

● Dual-core CPU with AES-NI

hardware encryption engine

● Encryption performance at over

113.01 MB/s reading, 111.66 MB/s

1

writing

● Advanced Btrfs le system with

built-in data integrity check

● Single H.264 4K or triple Full HD

video transcoding on the y

● Hot-swappable drive tray

design for easy installation &

maintenance

● Brightness-adjustable front LED

with schedule control

● A versatile storage server for

small ofces

2

Safeguard Your Data with Great Performance

Synology DiskStation DS216+II is designed for small oces pursuing a compact yet powerful
shared storage solution. Powered by an Intel® Celeron® dual-core CPU, built-in AES-NI

hardware encryption engine and 1GB DDR3 RAM, DS216+II delivers up to an average

113.08 MB/s reading and 111.78 MB/s writing speed, and an encrypted data transmission

at over 113.01 MB/s reading and 111.66 MB/s writing1 under RAID 1 conguration in a
Windows® environment.

DS216+II comes with a front USB 3.0 port with USB copy button for fast and easy data
transmission. Hot-swappable drive tray design allows easy installation and maintenance
on 3.5-inch HDDs without additional tools. Brightness-adjustable front LED with schedule
control provides exible LED settings that best suit your environment.

Btrfs: Next Generation Storage Efciency

DS216+II introduces the Btrfs le system, bringing the most advanced storage technologies
to meet the management needs of modern businesses:

● Built-in data integrity check detects data and le system corruption with data and

meta-data checksums and improve overall stability.

● Flexible Shared Folder/User Quota System provides comprehensive quota control on

all user accounts and shared folders.

● Advanced snapshot technology with customizable backup schedule allows up to 256

copies of shared folder backups in a minimum 5-minute interval without occupying
huge storage capacity and system resources.

● File or folder level data restoration brings huge convenience and saves time for users

who wish to restore only a specic single le or folder.

● Cloud Station with le versioning reduces down to half of storage consumption when

compared with the Ext4 le system.

1 2 3 4 5 6 7 …14

1

2

3

4 5

1

2

3

1

Next Generation Storage Eciency

The Btrfs le system brings storage
management to the next level by
providing more ecient storage utilization,
scheduled shared folder snapshot, and le
/ folder-level data restoration.

Comprehensive Business Applications

Powered by the innovative Synology DiskStation Manager (DSM), DS216+II comes fully­equipped with business applications and features:

● Easy integration with existing business network environments through Windows® AD

and LDAP directory services without recreating user accounts.

● Windows ACL support provides ne-grained access control and ecient privilege

settings, allowing DS216+II to t seamlessly into current infrastructure.

● Internet le access is simplied by the encrypted FTP server and the web-based le

explorer, Synology File Station. HTTPS, rewall, and IP auto-block support ensure le
sharing over the Internet is protected with a high level of security.

● Synology Cloud Station allows users to sync les among multiple devices, including

Windows PC, Mac, Linux, iOS and Android tablets or smart phones, eortlessly keeping
everything up-to-date.

4K Ultra HD Multimedia Bank

Synology DiskStation DS216+II features real-time H.264 1-channel 4K Ultra HD or 3-channel
Full HD2 video transcoding, bringing more complete support to the latest multimedia le

formats and contents. With Video Station, you can organize personal digital video library
with comprehensive media information, watch 4K Ultra HD movies and lms, or record TV
programs with a DVB-T/DVB-S stick. Photo Station’s intuitive design allows you to eortlessly
organize photos into customized categories, smart albums and blog posts, and link them to
social networking websites within a few clicks. Audio Station comes with Internet radio and
lossless audio formats support and provides music playback via DLNA, AirPlay®, and Bluetooth
devices (a Bluetooth dongle is required).

4K Ultra HD Multimedia Bank

Real-time H.264 4K video transcoding
provides hassle-free high quality video
playback among various devices.

Easy Backup Solutions

With block-level incremental backup and cross-version deduplication, Synology Hyper
Backup provides multi-version backup with optimized storage utilization and allows multiple

backup destinations to local shared folders, external hard drives, network shared folders, rsync
server, and public cloud services. Synology High Availability Manager ensures seamless
transition between clustered servers in the event of server failure with minimal impact to
applications to decrease the risk of unexpected interruptions and costly downtime.

Energy Efcient and Easy Management Design

Synology DS216+II is designed and developed with energy eciency in mind. Compared with
the average storage server counterparts, DS216+II consumes only 17.4W in regular operation.
The support of Wake on LAN/WAN and scheduled power on and o can further reduce
power consumption and operation cost. HDD hibernation can be congured to take eect
automatically when the system has been inactive for a specied period of time. This not only
saves energy but also extends the lifespan of the hard disks.

All Synology products are produced with RoHS compliant parts and packed with recyclable
packing materials. Synology acknowledges the responsibility as a global citizen to continually
work to reduce the environmental impact of every product produced.

Connections & Buttons

123

4

5

8

976

11

10

LED indicator

1

Drive tray cover

5

Power port

9

USB 3.0 port

2

USB 2.0 port

6

LAN (RJ-45) port

10

Technical Specications

Hardware

CPU

Hardware encryption engine

Floating point unit

Hardware transcoding engine

RAM size

Compatible drive type

Maximum internal raw capacity

External ports

Size (HxWxD)

Weight

LAN

Wireless support

Wake on LAN/WAN

Scheduled power on/o

AC input power voltage

Power frequency

Operating temperature

Storage temperature

Relative humidity

Intel Celeron N3060 dual-core 1.6GHz, burst up to 2.48GHz

Yes (AES-NI)

Yes

Supported codec: H.264 (AVC), MPEG-2 and VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30

DDR3 1GB

3.5”/2.5” SATA III/II x 2 (hard drives not included)

16TB (8TB HDD x 2) (actual capacity dependent on volume types)

USB 3.0 port x 1, USB 2.0 port x 2, eSATA port x 1

165 mm x 108 mm x 233.2 mm

1.25 kg

Gigabit (RJ-45) x 1

Yes (wireless dongles not included)

Yes

Yes

100V to 240V

50Hz to 60Hz, single phase

5°C to 40°C (40°F to 104°F)

-20°C to 60°C (-5°F to 140°F)

5% to 95% RH

USB copy button

3

Reset button

7

Kensington Security Slot

11

Power button

4

eSATA port

8

General

Networking protocols

File system

Storage management

Supported RAID type

File sharing capability

Privilege

Directory service

Security

Utilities

CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN™ , L2TP)

Internal: Btrfs, ext4
External: Btrfs, ext4, ext3, FAT, NTFS, HFS+

Maximum single volume size: 108TB, Maximum internal volume: 256, Maximum iSCSI Target: 32, Maximum iSCSI LUN: 256

Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1

Maximum user account: 2048, Maximum group: 256, Maximum shared folder: 256,
Maximum concurrent CIFS/AFP/FTP/File Station connection: 256

Windows Access Control List (ACL)

Windows AD Integration: Domain Users login via Samba (CIFS)/AFP/FTP/File Station, LDAP integration

FTP over SSL/TLS, IP auto-block, rewall, encrypted network backup over Rsync, HTTPS connection

Synology Web Assistant, Cloud Station Drive, Cloud Station Backup, Cloud Sync Decryption Tool, Evidence Integrity Authenticator, Photo Station Uploader,
Snapshot Manager for VMware, Snapshot Manager for Windows, NFS Plug-in for VMware VAAI

Supported clients

Supported browsers

Language

Applications

File Station

Backup solutions

FTP Server

Printer Server

Security Advisor

iOS/Android™ applications

Windows Phone® applications

Add-on Packages

Antivirus Essential

Cloud Station Server

Cloud Sync

DLNA/UPnP® Media Server

Download Station

Log Center

Mail Station

Mail Server

Note Station

Storage Analyzer

Surveillance Station

VPN Server

Web Station

Other packages

Windows 7 onwards and Mac OS X® 10.10 onwards

Chrome™, Firefox®, Internet Explorer® 9 onwards, Safari® 8 onwards, Safari (iOS® 7 onwards on iPad®), Chrome (Android 4.0 onwards on tablets)

English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svensk, Nederlands, Русский, Polski, Magyar,
Português do Brasil, Português Europeu, Türkçe, Český,

Virtual drive, remote folder, Windows ACL editor, compress/extract archived les, bandwidth control for specic users or groups, create sharing links, transfer
logs

Network backup; local backup; desktop backup; conguration backup; OS X Time Machine; backup data to public cloud;
shared folder sync - maximum task number: 4

Bandwidth control for TCP connections, custom FTP passive port range, anonymous FTP, FTP SSL/TLS and SFTP protocols, boot over the network with TFTP
and PXE support, transfer logs

Maximum printer: 2, printing protocols: LPR, CIFS, IPP, iOS printing, Google Cloud Print™, multi functional print server (MFP functions are for Windows PC
only)

Malware detection/removal, user account/password, network, system-related security scan

DS cloud, DS le, DS nder, DS cam, DS note, DS audio, DS download, DS photo, DS video

DS le, DS nder, DS audio, DS download, DS photo, DS video

Full system scan, scheduled scan, white list customization, virus denition auto update

Maximum concurrent le transfers: 256, retain historical and deleted le versions

One or two-way synchronization with public cloud storage providers including Amazon Cloud Drive, Amazon S3-compatible storage, Baiduyun, Box,
Dropbox, Google Cloud Storage, Google Drive, hubiC, Megafon Disk, Microsoft OneDrive, OpenStack Swift-compatible storage, WebDAV servers, Yandex Disk

DLNA certied, PS3®/PS4®/Xbox 360®/Xbox One® support

Supported download protocols: BT/HTTP/FTP/NZB/eMule
Maximum concurrent download task: 80

SSL connection, log rotation: 6 months, 1 year, 2 years, 3 years, email notication

Webmail interface for Mail Server; receiving mails from multiple POP3 mailboxes, customizable SMTP server

Supported Mail Server protocols: POP3, SMTP, IMAP, support LDAP/AD account

Rich-text note organization with versioning, encryption, sharing, media embedding and attachments

Volume and quota usage, total size of les, volume usage and trends based on past usage, size of shared folders, largest/most/least frequently modied les

Maximum IP camera: 25 (total of 750 FPS at 720p, H.264) (Including two free camera licenses. Procurement of additional licenses is required.)

Maximum connections: 20; supported VPN protocols: PPTP, OpenVPN™, L2TP

Virtual host (up to 30 websites), PHP/MariaDB®, 3rd-party applications support

Photo Station, Audio Station, iTunes® Server, 3rd-party packages

Environment and Packaging

Environment

Package content

Optional accessories

Warranty

*Model specications are subject to change without notice. Please refer to www.synology.com for the latest information.

1. Tested with four dierent client computers. Performance gures could vary on dierent environments.

2. DS216+II can transcode 4K video to 1080p or lower. The concurrent channels of Full HD video transcoding may vary depending on the video codec, resolution, bitrate and FPS.
