Suunto D6i Novo User's Guide
SUUNTO D6I
USER GUIDE
2018-05-16
Suunto D6i
1. Safety................................................................................................................................................................4
2. Getting started...............................................................................................................................................7
2.1. Display states and views................................................................................................................. 7
2.2. Icons.....................................................................................................................................................7
2.3. Set up.................................................................................................................................................. 8
2.4. Software version check.................................................................................................................. 8
2.5. Product compatibility...................................................................................................................... 9
3. Features..........................................................................................................................................................11
3.1. Activation and pre-checks..............................................................................................................11
3.1.1. Wireless Transmitter pre-check........................................................................................ 12
3.1.2. Battery indicators.................................................................................................................12
3.2. Air time.............................................................................................................................................. 12
3.3. Alarms, warnings and notifications.............................................................................................13
3.4. Apnea timer......................................................................................................................................15
3.5. Ascent rate....................................................................................................................................... 16
3.6. Backlight........................................................................................................................................... 16
3.7. Bookmarks.........................................................................................................................................17
3.8. Calendar clock.................................................................................................................................17
3.8.1. Time.........................................................................................................................................17
3.8.2. Date........................................................................................................................................ 17
3.8.3. Units........................................................................................................................................17
3.8.4. Dual time............................................................................................................................... 17
3.8.5. Alarm clock...........................................................................................................................18
3.9. Compass........................................................................................................................................... 18
3.9.1. Calibrating compass........................................................................................................... 19
3.9.2. Setting declination............................................................................................................. 19
3.9.3. Setting compass timeout..................................................................................................19
3.9.4. Setting bearing lock..........................................................................................................20
3.10. Decompression dives................................................................................................................. 20
3.11. Display contrast............................................................................................................................. 23
3.12. Depth alarm................................................................................................................................... 23
3.13. Dive history.................................................................................................................................... 24
3.14. Dive modes....................................................................................................................................26
3.14.1. Air mode.............................................................................................................................. 26
3.14.2. Nitrox mode.......................................................................................................................26
3.14.3. Gauge mode......................................................................................................................28
3.14.4. Free mode..........................................................................................................................28
3.15. Dive planning mode.................................................................................................................... 29
3.16. Dive time alarm.............................................................................................................................30
3.17. Error state (algorithm lock)......................................................................................................... 30
2
Suunto D6i
3.18. Personal and altitude adjustments........................................................................................... 31
3.19. Safety stops and deepstops......................................................................................................32
3.20. Sample rate...................................................................................................................................33
3.21. Software version...........................................................................................................................33
3.22. Stopwatch......................................................................................................................................33
3.23. Surface and
no-fly time..............................................................................................................34
3.24. Dive numbering........................................................................................................................... 35
3.25. Suunto RGBM...............................................................................................................................35
3.25.1. Diver Safety....................................................................................................................... 36
3.25.2. Altitude diving..................................................................................................................36
3.25.3. Oxygen exposure............................................................................................................36
3.26. Tank pressure...............................................................................................................................37
3.26.1. Wireless transmission..................................................................................................... 38
3.26.2. Installing and pairing transmitter................................................................................ 38
3.26.3. Transmitted data..............................................................................................................39
3.26.4. Tank pressure alarm.......................................................................................................39
3.27. Tones...............................................................................................................................................40
3.28. Water contact...............................................................................................................................40
4. Care and support........................................................................................................................................ 41
4.1. Handling guidelines........................................................................................................................ 41
4.2. Water resistance............................................................................................................................. 41
4.3. Battery replacement......................................................................................................................42
5. Reference.....................................................................................................................................................43
5.1. Technical
specifications................................................................................................................ 43
5.2. Compliance..................................................................................................................................... 45
5.2.1. CE........................................................................................................................................... 45
5.2.2. EU depth gauge standard...............................................................................................45
5.3. Trademark........................................................................................................................................45
5.4. Patent notice...................................................................................................................................45
5.5. International Limited Warranty...................................................................................................45
5.6. Copyright......................................................................................................................................... 46
5.7. Terms..................................................................................................................................................47
3
Suunto D6i
1. Safety
Types of safety precautions
WARNING: - is used in connection with a procedure or situation that may result in
serious injury or death.
CAUTION: - is used in connection with a procedure or situation that will result in
damage to the product.
NOTE: - is used to emphasize important information.
TIP: - is used for extra tips on how to utilize the features and functions of the device.
Before you dive
Make sure that you fully understand the use, displays and limitations of your dive instruments.
If you have any questions about this manual or dive computer, contact your Suunto dealer
before diving. Always remember that YOU ARE RESPONSIBLE FOR YOUR OWN SAFETY!
This dive computer is intended for use with compressed air only.
Safety precautions
WARNING: ONLY TRAINED DIVERS SHOULD USE A DIVE COMPUTER! Insucient
training for any kind of diving, including freediving, may cause a diver to commit errors, such
as incorrect use of gas mixtures or improper decompression, that may lead to serious injury
or death.
WARNING: You must read the printed quick guide and online user guide for your dive
computer. Failure to do so may lead to improper use, serious injury or death.
WARNING: THERE IS ALWAYS A RISK OF DECOMPRESSION SICKNESS (DCS) FOR ANY
DIVE PROFILE EVEN IF YOU FOLLOW THE DIVE PLAN PRESCRIBED BY DIVE TABLES OR A
DIVE COMPUTER. NO PROCEDURE, DIVE COMPUTER OR DIVE TABLE WILL PREVENT THE
POSSIBILITY OF DCS OR OXYGEN TOXICITY! An individual’s physiological makeup can vary
from day to day. The dive computer cannot account for these variations. You are strongly
advised to remain well within the exposure limits provided by the instrument to minimize the
risk of DCS. As an added measure of safety, you should consult a physician regarding your
fitness before diving.
WARNING: If you have a pacemaker, we recommend you do not scuba dive. Scuba
diving creates physical stresses on the body which may not be suitable for pacemakers.
WARNING: If you have a pacemaker, consult a doctor before using this device. The
inductive frequency used by the device may interfere with pacemakers.
4
Suunto D6i
WARNING: Allergic reactions or skin irritations may occur when product is in contact with
skin, even though our products comply with industry standards. In such event, stop use
immediately and consult a doctor.
WARNING: Not for professional use! Suunto dive computers are intended for recreational
use only. The demands of commercial or professional diving may expose the diver to depths
and conditions that tend to increase the risk of decompression sickness (DCS). Therefore,
Suunto strongly recommends that the device not be used for any commercial or professional
diving activities.
WARNING: USE BACKUP INSTRUMENTS! Ensure that you use backup instrumentation,
including a depth gauge, submersible pressure gauge, timer or watch, and have access to
decompression tables whenever diving with a dive computer.
WARNING: For safety reasons, you should never dive alone. Dive with a designated
buddy. You should also stay with others for an extended time after a dive as the onset of
possible DCS may be delayed or triggered by surface activities.
WARNING: PERFORM PRE-CHECKS! Always check that your dive computer is functioning
properly and has the correct settings before diving. Check that the display is working, the
battery level is OK, tank pressure is correct, and so forth.
WARNING: Check your dive computer regularly during a dive. If you believe or conclude
that there is any problem with any computer function, abort the dive immediately and safely
return to the surface. Call Suunto Customer Support and return your computer to an
authorized Suunto Service Center for inspection.
WARNING: THE DIVE COMPUTER SHOULD NEVER BE TRADED OR SHARED BETWEEN
USERS WHILE IT IS IN OPERATION! Its information will not apply to someone who has not
been wearing it throughout a dive, or sequence of repetitive dives. Its dive profiles must
match that of the user. If it is left on the surface during any dive, the dive computer will give
inaccurate information for subsequent dives. No dive computer can take into account dives
made without the computer. Thus, any diving activity up to four days prior to initial use of the
computer may cause misleading information and must be avoided.
WARNING: DO NOT EXPOSE ANY PART OF YOUR DIVE COMPUTER TO ANY GAS MIX
CONTAINING MORE THAN 40% OXYGEN! Enriched air with greater oxygen content presents
a risk of fire or explosion and serious injury or death.
WARNING: DO NOT DIVE WITH A GAS IF YOU HAVE NOT PERSONALLY VERIFIED ITS
CONTENTS AND ENTERED THE ANALYZED VALUE INTO YOUR DIVE COMPUTER! Failure to
verify tank contents and enter the appropriate gas values where applicable into your dive
computer will result in incorrect dive planning information.
WARNING: Using a dive planner software such as in Suunto DM5 is not a substitute for
proper dive training. Diving with mixed gases has dangers that are not familiar to divers
diving with air. To dive with Trimix, Triox, Heliox and Nitrox or all of them, divers must have
specialized training for the type of diving they are doing.
5
Suunto D6i
WARNING: Do not use Suunto USB Cable in areas where flammable gases are present.
Doing so may cause an explosion.
WARNING: Do not disassemble or remodel Suunto USB Cable in any way. Doing so may
cause an electric shock or fire.
WARNING: Do not use Suunto USB cable if cable or parts are damaged.
CAUTION: DO NOT allow the connector pins of the USB cable to touch any conductive
surface. This may short circuit the cable, making it unusable.
Emergency ascents
In the unlikely event that the dive computer malfunctions during a dive, follow the emergency
procedures provided by your certified dive training agency to immediately and safely ascend.
6
DIVE PLAN MEM
12:00
1.12
TH
12:00
1.12
TH
4.
3.
9.
10.
2.
1.
7.
5.
6.
8.
Suunto D6i
2. Getting started
2.1. Display states and views
Suunto D6i has four main modes: TIME, DIVE, PLANNING and MEMORY. Change modes by
pressing [MODE] .
Unless DIVE mode is turned o, Suunto D6i automatically switches to DIVE mode if you are
more than 1.2 m (4 ft) under water.
Time and dive modes have dierent views in the bottom row which you can scroll through
with [DOWN] and [UP] .
2.2. Icons
Suunto D6i uses the following icons:
Icon
Description
1 Daily alarm
2 Dive alarm
3 No-fly
7
Suunto D6i
Icon Description
4 Safety stop
5 Tank pressure (if available)
6 Wireless transmission (if available)
7 Low battery
8 Active water contact
9 Diver attention symbol
10 Ascent rate
2.3. Set up
To get the most out of your Suunto D6i, take some time to read this manual and familiarize
yourself with the modes and settings. Make absolutely sure you have it set up as you want
before getting into the water.
To get started:
1. Wake up the device by keeping any button pressed until the display turns on.
2. Keep [DOWN] pressed to enter General Settings.
3. Set time. See 3.8.1. Time.
4. Set date. See 3.8.2. Date.
5. Set units. See 3.8.3. Units.
6. Press [MODE] to exit settings.
The default dive mode is Air. For more information on dive modes, see 3.14. Dive modes.
2.4. Software version check
Please note that this user guide is for the latest software version of Suunto D6i. If you have an
older version, some features operate
To check the software version:
1. Keep [DOWN] pressed to enter settings.
2. Press [DOWN] to scroll to Version and enter with [SELECT] .
3. The
4. If the version number is V1.5.x or higher, you can skip the rest of this section and read the
5. If the version number is V1.2.x please read the sections below regarding how to use
6. Press [MODE] twice to exit settings.
first line of information indicates the software version.
user guide as normal.
specific features.
dierently.
NOTE: When you send your watch to an authorized Suunto service center for a battery
change or other servicing, the software will be updated to the latest version.
8
Suunto D6i
Dive modes
Each time you enter dive mode, you have the option of selecting which mode to use.
To change dive modes:
1. While in time mode, press [MODE] to enter dive mode.
2. Scroll to the dive mode you want to use with [UP] or [DOWN] .
3. Wait for the pre-checks to complete.
To change settings for a dive mode, keep [DOWN] pressed while in that mode. For further
information about dive mode settings, please refer to the respective dive mode section of this
user guide.
Stopwatch
Access the stopwatch in time or dive mode as explained in 3.23. Surface and no-fly time.
To use the stopwatch:
1. Press [DOWN] to start the stopwatch.
2. While the stopwatch is running, press [DOWN] to take split times.
3. Press [UP] to stop the stopwatch.
4. Keep [UP] pressed to reset the stopwatch.
Apnea timer
Access the apnea timer and adjust settings as explained in 3.4. Apnea timer.
To use the apnea timer:
1. Press [DOWN] to start the
2. Press [DOWN] to start the apnea cycle.
3. Press [DOWN] again to start the next ventilation cycle.
4. Repeat until the end of the
5. Keep [UP] pressed to reset the timer and press [MODE] to exit.
fist interval.
defined number of intervals. Press [UP] to pause the timer.
Compass calibration
When you
To calibrate the compass:
1. When you see the text Rotate 360°, hold the watch level and slowly rotate the watch in a
complete circle, keeping display facing up the whole time.
2. When you see the text Tilt 90°, slowly tilt the watch up to a vertical position so that the
display is facing you.
first use the compass, you are prompted to calibrate the compass.
2.5. Product compatibility
Suunto D6i can be used together with Suunto Wireless Tank Pressure Transmitter for wireless
transmission of tank pressure to the dive computer.
You may also connect this dive computer to a PC or Mac with the supplied USB cable and use
Suunto DM5 to modify device settings, plan dives, as well as update the dive computer
software.
9
Suunto D6i
Do not use this dive computer with any unauthorized accessories or equipment not
authorized or ocially supported by Suunto.
10
12:00
1.12
TH
DIVE
Air
66.2m
PO
AO
21 1.6
Battery
OK
66.2m
PO
AO
21
1.6
Suunto D6i
3. Features
3.1. Activation and pre-checks
Unless the dive mode turned
deeper than 1.2 m (4 ft). However, you should switch to dive mode before diving to check
altitude and personal settings, battery condition and so on.
Each time your Suunto D6i enters dive mode, a series of automatic checks are performed. All
graphical display elements are turned ON, and the backlight and the beep are activated. After
this, your altitude and personal settings are displayed along with the maximum operating
depth (MOD), gas content, and PO2 values. Then the battery level is checked.
o, the dive mode activates automatically when you dive
Between consecutive dives, the automatic checks also show current tissue saturation.
Before leaving on a dive trip, it is highly recommended that you switch to dive mode to make
sure everything is functioning properly.
After the automatic checks, Suunto D6i enters surface mode. At this point, you should
perform your manual checks before entering the water.
Ensure that:
1. Suunto D6i is in the correct mode and provides complete displays.
2. Altitude setting is correct.
3. Personal setting is correct.
4. Deepstops are set correctly.
5. Unit system is correct.
6. Correct temperature and depth are shown.
7. The alarm beeps.
11
Replace
Battery
Battery
Low
12:00
1.12
TH
Replace
Battery
Battery
Low
12:00
1.12
TH
Suunto D6i
3.1.1. Wireless Transmitter pre-check
If the optional wireless tank pressure transmitter is used, check that:
1. Tank gas and O2 settings are correct.
2. The transmitter is properly installed and the tank valve is open.
3. The transmitter and Suunto D6i are paired.
4. The transmitter is sending data (wireless transmission icon blinks, tank pressure is
displayed).
5. There is no transmitter low battery warning.
6. There is enough gas for your planned dive. Check the pressure reading against your back-
up pressure gauge.
3.1.2. Battery indicators
Temperature or internal oxidation can aect the battery voltage. If you store your Suunto D6i
for a long period or use it in cold temperatures, the low battery warning may appear even
though the battery has enough capacity.
In these cases, re-enter dive mode and check the battery power. If the battery is low, the Low
Battery warning comes on.
If the low battery icon appears in surface mode, or if the display looks faded, the battery may
be too low. Battery replacement is recommended.
NOTE: For safety reasons, the backlight and buzzer (sound) cannot be activated when
the low battery warning is displayed.
3.2. Air time
Air time can only be displayed when a wireless tank pressure transmitter is installed and in
use.
To activate air time:
1. While in a dive mode, keep [DOWN] pressed.
2. Press [DOWN] to scroll to Air Time.
3. Press [UP] to turn on the air time reading.
4. Press [SELECT] .
5. Press [MODE] to exit.
12
Suunto D6i
3.3. Alarms, warnings and notifications
Suunto D6i has audible and visual alarms designed to let you know when important limits or
presets are being reached.
The two audible alarm types indicating high or low priority:
Alarm type Sound pattern Duration
High priority 2.4 s sound + 2.4 s break
Low priority 0.8 s sound + 3.2 s break
In addition, there are three audible guidance notifications:
Instructional beep
Ascending Start ascending
Descending Start descending
Descending-ascending Change gas
Suunto D6i displays information during the alarm breaks in order to save battery life.
High priority alarms:
Alarm
High priority alarm followed by 'Start
ascending' beep, repeated for
maximum three minutes
PO2 value blinks
High priority alarm followed by 'Start
descending' beep, repeated for
maximum three minutes Er blinks and
an arrow points downwards.
Sound pattern Interpretation
Explanation
PO2 value greater than the adjusted value. Current
depth is too deep for the gas in use. You should
immediately ascend or change to a lower O2% gas.
Decompression ceiling depth exceeded. You should
immediately descend to, or below, the ceiling.
High priority alarm, repeated three
times.
SLOW blinks.
Low priority alarms:
Alarm type
Low priority alarm followed by 'Change gas'
beep.
Gas mix O2% value blinks.
Maximum ascent rate of 10 m/min (33 ft/min) exceeded.
Slow down your ascent rate.
Alarm reason
Gas change recommended (Nitrox dive
mode only). You should change to a gas
more favorable to decompression. ASC
TIME assumes that the gas is changed
13
Suunto D6i
Alarm type Alarm reason
and is accurate only if you change the
gas accordingly.
Low priority alarm followed by 'Start ascending'
beep, sounded two times.
ASC TIME blinks and an arrow points upwards.
Low priority alarm followed by 'Start
descending' beep.
DEEPSTOP blinks and an arrow points
downwards.
Low priority alarm followed by 'Start
descending' beep, repeated for three minutes.
An arrow points downwards.
Low priority alarm followed by two short
beeps.
DEEPSTOP and timer displayed.
Low priority alarm, repeated twice.
Tank pressure value blinks.
No-decompression dive becomes a
decompression stop dive. Depth is below
the decompression floor level. You
should ascend to, or above, the floor.
Mandatory deepstop violated. You should
descend to complete the deepstop.
Mandatory safety stop violated. You
should descend to complete the safety
stop.
Deepstop depth reached. Make the
mandatory deepstop for the duration
shown by the timer.
Tank pressure reaches the defined alarm
pressure or the fixed alarm pressure, 50
bar (700 psi). Acknowledge the alarm by
pressing any button.
Low priority alarm, repeated twice.
OLF% value blinks if PO2 value is greater than
0.5 bar.
Low priority alarm, repeated twice.
Maximum depth value blinks
Low priority alarm, repeated twice; dive time
value blinks
Low priority alarm. Maximum depth value
blinks.
Low priority alarm,
Surface time value blinks.
Visual alarms
OLF value at 80% or 100% (Nitrox dive
mode only). Acknowledge the alarm by
pressing any button.
Defined maximum depth or the maximum
depth of the device exceeded.
Acknowledge the alarm by pressing any
button.
Defined dive time exceeded.
Acknowledge the alarm by pressing any
button.
Defined depth reached (Free dive mode
only). Acknowledge the alarm by pressing
any button.
Duration of surface time until next dive
(Free dive mode only). Acknowledge the
alarm by pressing any button.
14
2s
12:00
1.12
TH
TIMER
Apena
1:00
15:00
TIME
START
Suunto D6i
Symbol on display Indication
Attention - extend surface interval
ER Violated decompression ceiling or bottom time is too
long
Do not fly
3.4. Apnea timer
You can use the apnea timer for interval training when freediving. You can adjust the following
settings:
•
Vent.: ventilation time; this is the starting duration of the time your breathing time. The
time is increased by the increment time for each interval.
•
Incr: increment time; this is added to the ventilation time for each interval. For example, if
your ventilation time is 1:00 minute and your increment time is 0:30 seconds, the first
interval ventilation is 1:00, the second is 1:30, the third is 2:00, and so on.
•
Repeats: number of intervals
To adjust apnea timer settings:
1. While in time mode, keep [UP] pressed to enter the apnea timer view.
2. Keep [DOWN] pressed to enter apnea timer settings.
3. Adjust the ventilation time with [UP] or [DOWN] and
confirm with [SELECT] .
4. Adjust the increment time with [UP] or [DOWN] and confirm with [SELECT] .
5. Adjust the number of intervals with [UP] or [DOWN] and
confirm with [SELECT] .
To use the apnea timer:
1. Press [SELECT] to start the first interval. The timer counts down the ventilation time. The
countdown continues up to -0:30 seconds beyond the defined ventilation time.
2. Press [SELECT] to start the apnea cycle. You can start this at any time during the
ventilation countdown. The apnea time is not
defined in the watch. It is as long or short as
you choose.
3. Press [SELECT] again to start the next ventilation cycle.
4. Repeat until the end of the defined number of intervals.
5. Press [MODE] to exit the apnea timer.
You can reset the apnea timer by keeping [SELECT] pressed.
15
Loading...
