Suunto 9 2.0 User Manual

SUUNTO 9 2.0
USER GUIDE
2019-02-15
1. SAFETY............................................................................................................................................................ 5
2. Getting started...............................................................................................................................................7
2.1. SuuntoLink.......................................................................................................................................... 7
2.2. Suunto app.........................................................................................................................................7
2.3. Touch screen and buttons............................................................................................................. 8
2.4. Optical heart rate............................................................................................................................. 8
2.5. Icons.................................................................................................................................................... 9
2.6. Adjusting settings............................................................................................................................ 11
3. Features.........................................................................................................................................................13
3.1. Activity monitoring...........................................................................................................................13
3.1.1. Instant HR................................................................................................................................14
3.1.2. Daily HR..................................................................................................................................14
3.2. Airplane mode................................................................................................................................. 15
3.3. Autopause........................................................................................................................................ 15
3.4. Backlight............................................................................................................................................16
3.5. Battery power management........................................................................................................ 16
3.6. Bluetooth connectivity...................................................................................................................17
3.7. Button and screen lock.................................................................................................................. 18
3.8. Chest heart rate sensor.................................................................................................................18
3.9. Compass........................................................................................................................................... 18
3.9.1. Calibrating compass........................................................................................................... 19
3.9.2. Setting declination............................................................................................................. 19
3.10. Device info.....................................................................................................................................20
3.11. Display theme................................................................................................................................ 20
3.12. Do Not Disturb mode.................................................................................................................. 20
3.13. Feeling............................................................................................................................................ 20
3.14. Find back......................................................................................................................................... 21
3.15. FusedSpeed.................................................................................................................................. 22
3.16. FusedTrack.....................................................................................................................................23
3.17. Intensity zones...............................................................................................................................23
3.17.1. Heart rate zones.................................................................................................................24
3.17.2. Pace zones......................................................................................................................... 26
3.18. Interval training............................................................................................................................. 27
3.19. Language and unit system.........................................................................................................28
3.20. Logbook.........................................................................................................................................28
3.21. Moon phases.................................................................................................................................28
3.22.
Notifications..................................................................................................................................29
3.23. Pairing PODs and sensors........................................................................................................ 29
3.23.1. Calibrating bike POD.......................................................................................................30
3.23.2. Calibrating foot POD...................................................................................................... 30
2
3.23.3. Calibrating power POD..................................................................................................30
3.24. Points of interest...........................................................................................................................31
3.24.1. Adding and deleting POIs...............................................................................................31
3.24.2. Navigating to a POI.........................................................................................................32
3.24.3. POI types........................................................................................................................... 32
3.25. Position formats........................................................................................................................... 34
3.26. Power saving................................................................................................................................35
3.27. Recording an exercise................................................................................................................ 35
3.27.1. Using targets when exercising......................................................................................36
3.27.2. Navigating during exercise............................................................................................37
3.28. Recovery........................................................................................................................................38
3.29. Routes.............................................................................................................................................38
3.30. Sleep tracking.............................................................................................................................. 39
3.31. Sport modes....................................................................................................................................41
3.31.1. Swimming............................................................................................................................. 41
3.32. Sunrise and sunset alarms.........................................................................................................41
3.33. Timers.............................................................................................................................................42
3.34. Time and date...............................................................................................................................43
3.34.1. Alarm clock.........................................................................................................................43
3.35. Tones and vibration.....................................................................................................................44
3.36. Training insight............................................................................................................................. 44
3.37. Watch faces................................................................................................................................... 45
4. Valid for barometer version only............................................................................................................46
4.1. Altimeter............................................................................................................................................46
4.2. FusedAlti.......................................................................................................................................... 46
4.3. Altitude navigation.........................................................................................................................46
4.4. Outdoor insight...............................................................................................................................46
4.5. Storm alarm..................................................................................................................................... 48
5. Care and support....................................................................................................................................... 49
5.1. Handling guidelines....................................................................................................................... 49
5.2. Battery.............................................................................................................................................. 49
5.3. Disposal............................................................................................................................................49
6. Reference.................................................................................................................................................... 50
6.1. Technical
specifications................................................................................................................50
6.2. Compliance...................................................................................................................................... 51
6.2.1. CE............................................................................................................................................ 51
6.2.2. FCC compliance................................................................................................................. 51
6.2.3. IC.............................................................................................................................................51
6.2.4. NOM-121-SCT1-2009........................................................................................................ 52
6.2.5. NCC.......................................................................................................................................52
3
6.3. Trademark........................................................................................................................................52
6.4. Patent notice...................................................................................................................................52
6.5. International Limited Warranty...................................................................................................52
6.6. Copyright......................................................................................................................................... 54
4

1. SAFETY

Types of safety precautions
WARNING: - is used in connection with a procedure or situation that may result in
serious injury or death.
CAUTION: - is used in connection with a procedure or situation that will result in
damage to the product.
NOTE: - is used to emphasize important information.
TIP: - is used for extra tips on how to utilize the features and functions of the device.
Safety precautions
WARNING: Keep the USB cable away from medical devices such as pacemakers, as well as key cards, credit cards and similar items. The USB cable device connector includes a strong magnet which may interfere with the operation of medical or other electronic devices and items with magnetically stored data.
WARNING: Allergic reactions or skin irritations may occur when the product is in contact with skin, even though our products comply with industry standards. In such event, stop use immediately and consult a doctor.
WARNING: Always consult your doctor before beginning an exercise program. Overexertion may cause serious injury.
WARNING: Only for recreational use.
WARNING: Do not entirely rely on the GPS or battery lifetime of the product. Always use maps and other backup material to ensure your safety.
CAUTION: Do not apply solvent of any kind to the product, as it may damage the surface.
CAUTION: Do not apply insect repellent on the product, as it may damage the surface.
CAUTION: Do not throw the product away, but treat it as electronic waste to preserve the environment.
CAUTION: Do not knock or drop the product, as it may get damaged.
5
NOTE: At Suunto we use advanced sensors and algorithms to generate metrics that can help you in your activities and adventures. We strive to be as accurate as possible. However, none of the data our products and services collect is perfectly reliable, nor are the metrics they generate absolutely precise. Calories, heart rate, location, movement detection, shot recognition, physical stress indicators and other measurements may not match the real world. Suunto products and services are intended for recreational use only and are not meant for medical purposes of any kind.
6

2. Getting started

Starting your Suunto 9 for the first time is quick and simple.
1. Keep the upper button pressed to wake up the watch.
2. Tap the screen to begin the setup wizard.
3. Select your language by swiping up or down and tapping on the language.
4. Follow the wizard to complete initial settings. Swipe up or down to select values. Tap the
screen or press the middle button to accept a value and go to the next step.

2.1. SuuntoLink

Download and install SuuntoLink on your PC or Mac to update your watch software.
We strongly recommend updating your watch when a new software release is available. If an update is available, you are
Visit www.suunto.com/SuuntoLink for further information.
To update your watch software:
1. Plug your watch into the computer with the supplied USB cable.
2. Start SuuntoLink if it is not already running.
3. Click the update button in SuuntoLink.
notified via SuuntoLink as well as the Suunto app.

2.2. Suunto app

With the Suunto app, you can further enrich your Suunto 9 experience. Pair your watch with the mobile app to sync your activities, get mobile
NOTE: You cannot pair anything if airplane mode is on. Turn o airplane mode before pairing.
notifications, insights and more.
To pair your watch with Suunto app:
1. Ensure your watch Bluetooth is on. Under the settings menu, go to Connectivity »
Discovery and enable it if it is not already.
2. Download and install Suunto app on your compatible mobile device from the iTunes App
Store, Google Play in addition to several popular app stores in China.
3. Start Suunto app and turn on Bluetooth if it is not on already.
4. Tap the watch icon in the upper-left of the app screen and then tap “PAIR” to pair your
watch.
7
5. Verify the pairing by typing the code that are displayed on your watch in the app.
NOTE: Some features require an internet connection over Wi-Fi or mobile network. Carrier data connection fees may apply.

2.3. Touch screen and buttons

Suunto 9 has a touch screen and three buttons you can use to navigate through displays and features.
Swipe and tap
•
swipe up or down to move in displays and menus
•
swipe right and left to backwards and forwards in displays
•
swipe left or right to see additional displays and details
•
tap to select an item
•
tap the display to view alternate information
•
tap and hold to open in-context options menu
•
double-tap to return to time display from other displays
Upper button
•
press to move up in views and menus
Middle button
•
press to select an item
•
press to press to change displays
•
keep pressed to got back in settings menu
•
keep pressed to open in-context options menu
Lower button
•
press to move down in views and menus
While recording an exercise:
Upper button
•
press to pause or resume recording
•
keep pressed to change activity
Middle button
•
press to change displays
•
keep pressed to open in-context options menu
Lower button
•
press to mark a lap
•
keep pressed to lock and unlock buttons

2.4. Optical heart rate

Optical heart rate measurement from the wrist is an easy and convenient way to track your heart rate. To get the best results, please keep in mind factors that may measurement:
8
aect heart rate
•
The watch must be worn directly against your skin. No clothing, however thin, can be between the sensor and your skin.
•
The watch may need to be higher on your arm than where watches are normally worn. The sensor reads blood
•
Arm movements and
flow through tissue. The more tissue it can read, the better.
flexing muscles, such as gripping a tennis racket, can change the
accuracy of the sensor readings.
•
When your heart rate is low, the sensor may not be able to provide stable readings. A short warm up of a few minutes before you start the recording helps.
•
Skin pigmentation and tattoos may block light and prevent reliable readings from the optical sensor.
•
The optical sensor may not provide accurate heart rate readings for swimming activities.
•
For highest accuracy and quickest responses to changes in your heart rate, we recommend using a compatible chest heart rate sensor such as Suunto Smart Sensor.
WARNING: Optical heart rate sensor technology is currently not as accurate or reliable as measuring heart rate from the chest. Your actual heart rate may be higher or lower than the optical sensor reading.

2.5. Icons

Suunto 9 uses the following icons:
Airplane mode
Altitude (valid for barometer version only)
Altitude dierence (valid for barometer version only)
Ascent (valid for barometer version only)
Back; go back in menu
Battery status
Button lock
Cadence
Calibrate (compass)
Calories
Current location (navigation)
Charging
Descent (valid for barometer version only)
9
Distance
Duration
EPOC
Estimated VO2
Exercise
Failure
Flat time
GPS acquired
Heading (navigation)
Heart rate
Wrist HR signal acquired
Chest HR signal acquired
Incoming call
Logbook
Low battery
Message/notification
Missed call
Navigation
Pace
POD signal acquired
Power POD signal acquired
Peak Training Eect
Recovery time
Steps
10
Stopwatch
Stroke rate (swimming)
Success
SWOLF
Syncing
Settings
Training
Temperature
Storm alarm (valid for barometer version only)
Barometer (valid for barometer version only)

2.6. Adjusting settings

You can adjust all watch settings directly in the watch.
To adjust a setting:
1. Swipe down until you see the settings icon and tap the icon.
2. Scroll through the settings menu by swiping up or down or by pressing the upper or lower
buttons.
3. Select a setting by tapping the setting name or pressing the middle button when the
setting is highlighted. Go back in the menu by swiping right or selecting Back.
4. For settings with a value range, change the value by swiping up or down or by pressing
the upper or lower button.
11
5. For settings with just two values, such as on or o, change the value by tapping the setting
or pressing the middle button.
TIP: You can also access general settings from the watch face by keeping the middle button pressed to open the shortcuts menu.
12

3. Features

3.1. Activity monitoring

Your watch keeps track of your overall activity level throughout the day. This is an important factor whether you just aim to be fit and healthy or you are training for an upcoming competition.
It is good to be active, but when training hard, you need to have proper rest days with low activity.
The activity counter automatically resets at midnight every day. At the end of the week (Sunday), the watch provides a summary of your activity showing your average for the week and daily totals.
From the watch face display, swipe up or press the lower button to see your total steps for the day.
Your watch counts steps using an accelerometer. The total step count accumulates 24/7, also while recording training sessions and other activities. However, with some specific sports, such as swimming and cycling, steps are not counted.
In addition to steps, you can tap on the display to see estimated calories for the day.
The large number in the center of the display is the estimated amount of active calories you have burned so far during the day. Below this you see the total calories burned. The total includes both active calories and your Basal Metabolic Rate (see below).
The ring in both displays indicates how close you are to your daily activity goals. These targets can be adjusted to your personal preferences (see below)
You can also check your steps over the last seven days with a swipe to the left. Swipe left or press the middle button again to see calories consumption.
Swipe up to check your activity over the last seven days in numbers instead of a graph.
13
Activity goals
You can adjust your daily goals for both steps and calories. While in the activity display, tap and hold your finger on the screen or keep the middle button pressed to open the activity goal settings.
When setting your steps goal, you define the total number of steps for the day.
The total calories you burn per day is based on two factors: your Basal Metabolic Rate (BMR) and your physical activity.
Your BMR is the amount of calories your body burns while at rest. These are the calories your body needs to stay warm and perform basic function like blink your eyes or beat your heart. This number is based on your personal profile, including factors such as age and gender.
When you set a calorie goal, you your BMR. These are your so-called active calories. The ring around the activity display advances according to how many active calories you burn during the day compared to your goal.
define how many calories you want to burn in addition to

3.1.1. Instant HR

The instant heart rate (HR) display provides a quick snapshot of your heart rate.
From the watch face view, swipe up or press the lower button to scroll to the HR display.
Swipe down or press the upper button to exit the display and return to the watch face view.

3.1.2. Daily HR

The daily HR display provides a 12-hour view of your heart rate. This is a helpful source of information about, for example, your recovery after a hard training session.
The display shows your heart rate over 12 hours as a graph. The graph is plotted using your average heart rate based on 24-minute time slots. In addition, by swiping up or pressing the lower button, you get an estimation of your average hourly calorie consumption rate and your lowest heart rate during the 12-hour period.
Your minimum heart rate from the last 12 hours is a good indicator of your recovery state. If it is higher than normal, you probably are not yet fully recovered from your last training session.
14
If you record an exercise, the daily HR values reflect the elevated heart rate and calorie consumption from your training. But keep in mind that the graph and consumption rates are averages. If your heart rate peaks at 200 bpm while exercising, the graph does not show that maximum value, but rather the average from the 24 minutes during which you hit that peak rate.
Before you can see the daily HR display values, you need to activate the daily HR feature. You can toggle the feature on or o from the settings under Activity. If you are in the daily HR display, you can also access the activity settings by keeping the middle button pressed.
With the daily HR feature on, your watch activates the optical heart rate sensor on a regular basis to check your heart rate. This slightly increases battery power consumption.
Once activated, your watch needs 24 minutes before it can start display daily HR information.
To view daily HR:
1. From the watch face view, swipe up or press the lower button to scroll to the HR display.
2. Swipe left to enter the daily HR display.
3. Swipe up or press the lower button to see your calorie consumption.

3.2. Airplane mode

Activate airplane mode when needed to turn deactivate airplane mode from the settings under Connectivity.
NOTE: To pair anything with your device, you need to first turn o airplane mode if you
have it on.
o wireless transmissions. You can activate or

3.3. Autopause

Autopause pauses the recording of your exercise when your speed is less than 2 km/h (1.2 mph). When your speed increases to more than 3 km/h (1.9 mph), the recording continues automatically.
You can turn autopause on/o for each sport mode the sport mode settings in the watch before you start your exercise recording.
15
If autopause is on during a recording, a pop-up notifies you when the recording is paused automatically.
Tap the resume pop-up to check the current time and battery level.
You can let the recording resume automatically when you start moving again, or manually resume from the pop-up screen by pressing the upper button.

3.4. Backlight

The backlight has two modes: automatic and toggle. In automatic mode, the backlight comes on with any screen touch or button press.
In toggle mode, you turn the backlight on with a you tap with two fingers again.
By default, the backlight is in automatic mode. You can change the backlight mode as well as the backlight brightness from the settings under General » Backlight.
NOTE: Backlight brightness aects battery life. The brighter the backlight is, the quicker
the battery drains.
two-finger tap. The backlight stays on until
Standby backlight
When you are not actively using the watch by touching the screen or pressing buttons, the watch goes into a standby mode after one minute. The display is on, but in some low-light conditions, the screen might not be easily readable.
To improve readability in low-light conditions, you can use the standby backlight. This is a low­brightness backlight that is on all the time.
You can toggle the standby backlight on or Standby.
Even though the standby backlight brightness is quite low, it decreases overall battery life because it is on all the time.
o from the settings under General » Backlight »

3.5. Battery power management

Your Suunto 9 has a battery power management system uses intelligent battery technology to help ensure you watch does not run out of power when you need it most.
Before you start recording an exercise (see 3.27. Recording an exercise) you see an estimate of how much battery life you have left in the current battery mode.
16
There are three predefined battery modes; Performance (default), Endurance and Ultra. Changing between these modes will change the lifetime of the battery but also change the performance of the watch.
NOTE: By default, Ultra mode turns o all HR tracking (both wrist and chest). To activate
the HR tracking (in Ultra mode) go to Options under the start indicator.
In start display, tap Options » Battery mode to change battery modes and see how each mode aects the performance of the watch.
TIP: You can also quickly change the battery mode in the start display by pressing the upper button.
In addition to these three predefined battery modes, you can also create a custom battery mode with your own desired settings. The custom mode is making it possible to create a custom battery mode for every sport mode.
NOTE: If while exercising you start navigating or use navigation data like estimated time
of arrival (ETA), the GPS goes to Best, regardless of the battery mode.
specific for that sport mode,
Battery notifications
In addition to the battery modes, your watch uses smart reminders to help you ensure you have enough battery life for your next adventure. Some reminders are preemptive based on, for example, your activity history. You also get you are running low on battery while recording an activity. It will automatically suggest changing to a dierent battery mode.
notified, for example, when the watch notices
Your watch will alert you once when the battery is at 20% and again at 10%.

3.6. Bluetooth connectivity

Suunto 9 uses Bluetooth technology to send and receive information from your mobile device when you have paired your watch with the Suunto App. Same technology is also used when pairing PODs and sensors.
17
Loading...
+ 39 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
