Suprema BIOSTATIONRHOC User Manual

www.supremainc.com

Innovative Fingerprint Terminal

User Guide (Ver 1.3)

CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment

WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

INFORMATION TO USER: This equipment has been tested and found to comply with the limit of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation; if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient / Relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit difference from that to which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help

Innovative Fingerprint Terminal for Access Control and Time Attendance

 Fingerprint recognition, now look and feel!

z Features 2.5" 16M color LCD to display multimedia contents including animation and photos.

 Invincible speed and capacity

z Delivers fingerprint identification speed to perform 3,000 matches in 1 second and internal memory

storing up to 50,000 fingerprints and 500,000 event logs.

 No more wiring!

z Provides various external interfaces including Wi-Fi wireless LAN for easy access to the internal

user info and event log from a remote PC. (Optional)

 Data into your USB drive

z Using USB memory, copies and backs up user info and event log data very easily.

 World’s best fingerprint recognition algorithm

z World’s most reliable fingerprint solution that ranked No. 1 in an international fingerprint algorithm

contest (FVC2004) with the lowest error rate.

 Various fingerprint sensors

z Supports various fingerprint sensors, including optical, capacitive, and thermal swipe, so users can

choose the most suitable fingerprint sensor for their application.

 RF Card Support!

z RF module is built in a Terminal itself. Fingerprint, card, and password can be selected as the

authentication method for each user.

 Real Time Network operation through Server!

z Connected to the BioAdmin Server, terminals can be managed in real time.

Innovative Fingerprint Terminal for Access Control and Time Attendance

 RF Card Support!

z RF module is built in a Terminal itself. Fingerprint data and card data can be compatibly used.

 Real Time Network operation through Server!

z Terminals can be managed in real time by connecting each other through server.

Before start

z Safety precautions 6 z Glossary 8 z Basics of fingerprint recognition 9 z How to place a finger 10 z Product contents 12 z Name of each part 14 z Installation and cable spec. 16

For administrators (Basic functions)

z Enter Admin menu 19 z Using Admin menu 20 z Operation mode setting 21 z Network setup

–TCP/IP 22 – Wireless LAN 23 – Server 24 –Serial 25 –USB 26

z User management

– Enroll new user 27 – Check user info 31 – Edit user info 32 – Delete user 33 – Delete all users 34 – Check User DB 35

For Administrators (Advanced functions)

z Display & sound setting 37 z Device setup

– Fingerprint setting 39 – I/O setting 41 – Door relay setting 42 – Change master Password 43 – View device info 44 – Device reset 45 – Factory default 46

z Log

– Check log 47 – Filter log 48 – Delete entire log 49

z USB memory 50

For General Users

z Open door

– Access using 1:N mode 53 – Access using 1:1 mode 54

z Using T&A event

– T&A event using 1:N mode 56 – T&A event using 1:1 mode 57 – Using extended T&A events 58

z View user’s Access/T&A event records 59 z Authentication procedure as per operation mode 60 z Authentication procedure for T&A event 61

Appendix

z List of Admin menu 62 z Specifications 63 z Troubleshooting 64 z Device cleaning 65

Safety precautions

 The list below is to keep user’s safety and prevent any loss. Please read carefully before

use.

Before Start

Do not install the device in a place subject to direct sun light, humidity, dust or soot.

Be careful not to let liquid like water, drinks or chemicals leak inside the device.

Do not place a magnet near the product. Magnetic objects such a s magnet, CRT, TV, monitor or

speaker may damage the device .

Clean the device often to remove dust on it.

Do not place the device next to heating equipments.

In cleaning, do not splash water on the device but wipe it out with smooth cloth or towel.

Safety precautions

 The list below is to keep user’s safety and prevent any loss. Please read carefully before

use.

Before Start

Do not drop or damage the device.

Do not let children touch the device without supervision.

Do not press two buttons at the same time.

Do not use the device for any other purpose than specified.

Do not disassemble, repair or alter the device.

Contact your nearest dealer in case of a trouble or problem.

Glossary

 Administrator

z A special user who are authorized to manage the settings and user information of a device.

Administrators can enroll or delete users and change settings of the device.

 1:1 Mode

z In 1:1 mode, a user should enter his/her user ID first. After then, the user is requested to place a

finger or enter a PIN. In this mode, user’s scanned fingerprint is matched against only one fingerprint specified by the user ID.

 1:N Mode

z In 1:N mode, a user places his/her finger without entering any ID. Then the device compares the

user’s scanned fingerprint with the whole enrolled fingerprints in its internal database.

 Fingerprint Enrollment

z A process of extracting features of a fingerprint image obtained from a fingerprint sensor and

saving them into the internal memory of a device. The fingerprint data is called a fingerprint template.

Before Start

Basics of fingerprint recognition

 What is fingerprint recognition?

z Fingerprint is an individual’s own biometric information and does not change throughout his/her life.

Fingerprint recognition is a technology that verifies or identifies an individual using such fingerprint information.

z Free from the risk of theft or loss, fingerprint recognition technology is being widely used in security

systems replacing PIN or cards.

 Process of fingerprint recognition

z Fingerprint consists of ridges and valleys. Ridge is a flow of protruding skin in a fingerprint while

valley is a hollow between two ridges. Each individual has different pattern of ridges and valleys and finger recognition makes use of such originality and uniqueness of these patterns.

z Fingerprint sensor generates 2-dimentional fingerprint image using different technology. According

to the sensing technology, fingerprint sensors are classified into optical, capacitive, or thermal.

z Fingerprint template is a collection of numeric data representing the features of a fingerprint.

Fingerprint templates are saved inside the memory of BioStation and used for identification.

 Secure way to protect personal information

z To avoid privacy concern, Suprema’s fingerprint products do not save fingerprint images itself. It is

impossible to reconstruct a fingerprint image from a fingerprint template which is just numeric data of the features of a fingerprint.

Before Start

How to place a finger

Suprema’s fingerprint products show an outstanding recognition performance regardless of the user’s fingerprint skin condition or the way of fingerprint positioning. However, following tips are recommended to get more optimal

fingerprint recognition performance.

 Select a finger to enroll

z It is recommended to use an index finger or a middle finger. z Thumb, ring or little finger is relatively more difficult to place in a correct position.

 How to place a finger on a sensor

z Place a finger such that it completely covers the sensor area with maximum contact. z Place core part of a fingerprint to the center of a sensor.

 People tend to place upper part of a finger.  The core of a fingerprint is a center where the spiral of ridges is dense.  Usually core of fingerprint is the opposite side of the lower part of a nail.  Place a finger such that the bottom end of a nail is located at the center of a sensor.

z If a finger is placed as in the right picture, only a small area of a finger is captured. So it is

recommended to place a finger as shown in the left picture.

Before Start

How to place a finger

 Tips for different fingerprint conditions

z Suprema’s fingerprint products are designed to scan fingerprint smoothly regardless of the

conditions of a finger skin. However, in case a fingerprint is not read well on the sensor, please refer to the followings tips.

 If a finger is stained with sweat or water, scan after wiping moisture off.  If a finger is covered with dust or impurities, scan after wiping them off.  If a finger is way too dry, place after blowing warm breath on the finger tip.

 Tips for fingerprint enrollment

z In fingerprint recognition, enrollment process is very important. When enrolling a fingerprint, please

try to place a finger correctly with care.

z In case of low acceptance ratio, the following actions are recommended.

 Delete the enrolled fingerprint and re-enroll the finger.  Enroll the same fingerprint additionally.  Try another finger if a finger is not easy to enroll due to scar or worn-out.

z For the case when an enrolled fingerprint cannot be used due to injury or holding a baggage, it is

recommended to enroll more than two fingers per user.

Before Start

Product Contents

 Basic Contents

Product Contents

BioStation fingerprint terminal Wall mounting metal bracket

5pin, 3pin, 6pin, 4pin, 7pin cable – 1 ea Software CD

Wall mounting

screws and hol ders - 3 ea

USB cable

Star-shape screw for fixing

main body

Star-shape small wrench

Before Start

Product Contents

 Optional accessories

Before Start

12V power adaptor Plastic stand type A

Plastic stand type B USB fingerprint scanner

for enrollment on PC

InterphoneUSB memory Wireless LAN Access Point

Name of each part

 Front

Microphone

Used when connected to interphone.

Color LCD

Displays terminal status (T&A mode, notice, etc.) and current time.

Navigation key

▼ : Move down in Admin menu or view detailed T&A function key ▲ : Move up in Admin menu or hide detailed T&A function key ► : Show the next setting value in Admin menu or input a dot (.) when

entering IP address ◄ : Show the previous setting value in Admin menu or delete a numeric

when entering user ID or PIN OK : Confirm the selected setting or initiate a fingerprint scanning

manually.

LED

Blue LED is turned on with power supplied and flickers when waiting for fingerprint scanning.

Speaker

Outputs various sound effects, music, and voices.

Fingerprint sensor

Place a finger here to scan fingerprint.

Numeric key 0~9

Used to enter user ID or PIN.

Function key

Used to input a T&A event and initiate fingerprint scanning.

ESC key

Used to enter Admin menu from initial display or return to the previous menu from Admin menu.

CALL key

When connected to interphone, press this button to ring the interphone.

RF card reading part (RF model only)

Place RF card here to read

Before Start

Name of each part

 Bottom

 Rear

Slot for USB memory device : USB type A

Slot for PC USB connection : Mini USB

Ethernet cable connector : RJ45

3pin cable connector - Door

6pin cable connector – Input/Output or Wiegand

Before Start

4pin cable connector - RS485

7pin cable connector - RS232 or BEACon

5pin cable connector – Power and doorphone

12V power adaptor

Installation

 Installation example

Network hub

6pin cable

Ethernet

RS232

 Product dimension (mm)

135

128

7pin cable

USBUSB

128

3pin cable

Door Lock

108

Exit Button

112

BracketFront Side

Before Start

Cable spec.

Power & Doorphone

Relay

PIN PIN DESCRIPTION WIRE

1 POWER + (12Vdc) RED 2 POWER - BLACK 3 DATA ORANGE 4 AUDIO BLUE 5 SHIELD GND GRAY

PIN PIN DESCRIPTION WIRE

1 NORMAL OPEN WHITE 2 COMMON BLUE 3 NORMAL CLOSE ORANGE

Before Start

TTL I/O or Wiegand

RS485

RS232

PIN PIN DESCRIPTION WIRE

1 TTL IN0 BLUE 2 TTL IN1 YELLOW 3 TTL OUT0 GREEN 4 TTL OUT1 WHITE 5 GND BLACK 6 SHIELD GND GRAY

PIN PIN DESCRIPTION WIRE

1 TRX - YELLOW 2TRX + BLUE 3 GND BLACK 4 SHIELD GND GRAY

PIN PIN DESCRIPTION WIRE

1 GND BLACK 2 RS-232 TX BLUE 3 RS-232 RX YELLOW 4 TTL OUT1 WHITE 7 SHIELD GND GRAY

For Administrators - Basic Functions

Basic information for the

device administrators. It

includes key items such as

basic menu usage,

operation mode setting,

network connection, and

user management.

Enter Admin Menu

 Press ESC key to enter Admin menu from the initial display.

 Enter master password and press OK key.

z [Note] As there’s no master password enrolled in a device by factory

default, you can enter Admin menu just by pressing OK key. For security reason, set a master password right after the product installation. Please refer to <Change master PW> to see how to set a master password.

 Instead of entering master password, administrator can place

his/her finger to enter Admin menu.

z [Note] “Master password” is a unique password of the device,

different from the PIN (user password) of an administrator. It is necessary to enter master PW or place a finger. It is not possible to enter Admin menu by entering his/her PIN.

 If the master password is entered successfully, initial Admin

menu appears on display.

▼ T&A

Admin fingerprint or

master password

OK ESC

User

Mode

Log

Device

For Administrators - Basic Functions

Display

Network

Using Admin Menu

 Main functions of initial Admin menu are as follows. For the entire Admin menu list, refer to

<List of Admin menu>.

z User : user management such as user enroll/delete/edit. z Mode : set device’s operating mode. z Display : set device’s language, background, sound volume, etc. z Log : check the access and attendance event records. z Device: set various settings for finger scan, I/O ports, door relay, etc. z Network : set interface such as TCP/IP, serial communications, USB.

 To enter a desired submenu from initial Admin menu, move to the desired menu using a

navigation key and press OK key.

 In a submenu, you can move to desired item using up/down navigation key. To change

settings of each item, use left/right navigation key.

z If you press OK key, changed setting is applied and move to the previous menu. If you press ESC

key, changed setting is not applied and move to the previous menu.

 Press F4 key anytime in Admin menu to exit from Admin menu and move to initial display.

z [Note] For security reasons, the display will automatically return to the initial display after a certain

time period without any key input in Admin menu. If you do not want this function or want to change the time period, refer to <Display and sound setting>.

For Administrators - Basic Functions

Operation mode setting

After installation, it is necessary to select an operation mode suitable for its usage.

 If you select Mode on initial Admin menu, following menus

appear on the display.

1:1 Mode

1:N Mode

T&A

z Setting : Finger or PIN / Finger Only / Pin Only / Card Only z After entering ID on 1:1 mode, set whether you will use fingerprint,

PIN, or either for authentication. In case of card, using card only enables users to access just by placing the card.

z Setting: Auto / OK/T&A Key / Disabled z Auto : Fingerprint sensor is always on standby. So, if a finger is

placed, identification starts automatically.

z OK/T&A key : After pressing OK key or T&A function key,

fingerprint sensor is turned on to scan a fingerprint.

z Disabled : 1:N identification is not used. In order to enhance the

security level of your system, you can use 1:1 mode in which users should enter their ID first.

z Setting : enabled/disabled z Decide whether or not to use T&A function. In case of using T&A,

user can input T&A events using basic function keys F1~F4. Also, after pressing ▼ key on initial display, user can enter extended T&A events.

z In case of using the device for access control only, you don’t need

to use T&A functions.

1:1 Mode 1:N Mode T&A T&A key

Mode

◁Finger or PIN▷

◀ Auto ▶ ◀ Enabled ▶ ◀ F1 ▶ ◀ In ▶

◀ Use Relay ▶

T&A key

For Administrators - Basic Functions

z Shows T&A event set on each function key. z In order to set extended T&A events for a specific application, use

BioAdmin program on PC.

TCP/IP

To use the device connected to PC, you need to set up the network according to your connection type.

 If you select Network on initial Admin menu, Network Setup

menus appear on the display.

 If you select TCP/IP on network menu, following menus appear

on the display.

LAN Type

Max conn

SSL

DHCP

z Setting : Disable/Ethernet/Wireless LAN (Optional) z Used when connected to PC via Ethernet using RJ45 connector on

the rear of the device.

z Setting : 1/4/8/16 z Shows figures of BioAdmin that are accessible to terminal.

z Setting : Use/not use. z It sets Use or Not Use of SSL between the BioAdmin and BioStation.

z Setting : Use/not use z Using DHCP, you can receive IP address and other necessary

setting from server automatically.

z Check whether an appropriate DHCP server is av ailable in your

network environment before use.

Network Setup

USB Memory

LAN Type Port Max Conn. SSL DHCP IP Address Gateway Subnet

TCP/IP

Serial

USB

TCP/IP

◁ Ethernet ▷

◀ 1 ▶ ◀ Not Use ▶ ◀ Use ▶

1470

IP Address, gateway,

subnet

For Administrators - Basic Functions

z Without using DHCP, IP address, gateway, and subnet need to be

entered manually. Inquire necessary settings to network administrator.

Wireless LAN

To set up the wireless LAN, select the wireless LAN AP.

 If you press F2 key on TCP/IP menu, following menus appear on

the display.

Preset

Mode

ESSID

Authentication

Encryption

Link Quality

z Select a wireless LAN AP among the preset AP devices. z If there is no preset wireless LAN AP, add the wireless LAN AP

using BioAdmin program on PC. You can add up to 4 wireless LAN AP.

z Shows the operation mode of the wireless LAN AP.

z Shows the ESSID of the wireless LAN AP.

z Shows the authentication mode of wireless LAN AP.

z Shows the encryption method of the wireless LAN AP.

z Shows the network condition of the currently used wireless LAN AP.

Wireless LAN

Preset Mode ESSID Authentication Encryption Link Quality

◁ WPA ▷

Infrastructure

BioStation_wep

Open

WEP64/128/256

For Administrators - Basic Functions

Server

To set up the network to the Server.

 If you press F3 key on Server menu, following menus appear on

the display.

Server

Server IP

Port

z Set SSL Mode as “Not Use” and Server mode to “Use”(Put server IP and Port

information) if sever access is executed for the first time and another server DB rather than previously is accessed.

z After the previous process, BioStation with unauthorized certificate in BioAdmin client

program will be shown and issuing certificate is needed.

z After issuing certificate, system will be rebooted and accessed to server automatically. z After rebooting, SSL mode will be automatically change to “USE”, z After issuing certificate, SSL Mode and server mode will be set to “USE” and there is no

need to set up configurations of server and BioStation.

z To use previous version of BioAdmin or access to BioStation directly using BioAdmin 4.1

without accessing to server (3.* version), SSL and server mode are set on “Not Use”

z For more information on server setup, please refer to BioAdmin manual.

z Set Use or Not use of server.

z Set Server IP

z Set Server port

Server Server IP Port

Server

◁ Not Use ▷

For Administrators - Basic Functions

Serial

To connect BioStation to the serial port of PC, you need to select the buadrate of the serial communication.

 To connect the BioStation to the serial port of host PC,

designate the buadrate of the serial communication.

RS485

RS232

z Setting :Disable/9600/19200/38400/57600/115200 z Used when connecting to the serial port of PC using 7pin

connector on the rear of the device.

z In the serial communication, the speed represents the frequency of

carrier wave’s changing status per sec, called baudrate.

z Default is 115200 bps. z If you have communication error in serial communication, setting a

lower baudrate may solve the problem.

z Setting : Disabled/9600/19200/38400/57600/115200 z Used when connecting to the serial port of PC using 4pin

connector on the rear of the device.

RS485 RS232

Serial

◁ 115200 ▷ ◀ 115200 ▶

For Administrators - Basic Functions

USB

To connect the BioStation to the USB port of host PC, enable the USB communication.

 If you select USB on network submenu, USB setting menu

appears on the display.

USB

z Setting : Enable/Disable z Used to connect the mini USB port on the bottom of the device to

the USB port of PC.

z [Note] For security reasons, USB is set as Disable by the factory

default. When you connect device to PC using USB, the setting should be changed to Enable in advance.

USB Port

USB

◁ Disable ▷

For Administrators - Basic Functions

Enroll New User

How to enroll the user information and fingerprint.

 If you select User on initial Admin menu, User Management

menus appear on the display.

 If you select Enroll User on user menu, following menus appear

on the display.

User ID

Admin Level

Password

z By default, the lowest available ID is displayed on the ID part of the

menu. Enter your desired ID.

z User ID can be set between 1 and 4,294,967,295.

z Setting : Normal/Admin z Decide user level as normal user or administrator. z Administrator is authorized to manage user info, ie. enroll user,

delete user, and change various settings of the device.

z It is recommended to enroll at least 1 or 2 users as administrator.

z Enter password used in 1:1 mode. If you want to use fingerprint only,

leave password as blank.

User Management

Enroll User

Edit User

Delete All Users

Check User DB

Enroll User

User ID Admin Level Password Group 1 Group 2 Group 3 Group 4

◀ Normal ▶

◀ None ▶ ◀ None ▶ ◀ None ▶ ◀ None ▶

123456

Group 1 ~ Group 4

For Administrators - Basic Functions

z Select access group in which the user belongs to. To edit access

group, use BioAdmin program on PC.

Enroll New User

 If you enter all the necessary items for enrollment and press OK

key, the following fingerprint menus appear on the display.

Finger No

Duress

z Setting : 1/…/5/None z 1-5 fingers can be enrolled for each ID. z Enrolling more than two fingers per user can be useful in a case of

injury of a finger.

z For a user whose fingerprint is weak or worn-out, enrolling the same

finger twice or more can reduce failure rate.

z If you want to use PIN only instead of fingerprint, select None.

z Setting : None/Last Finger z Duress is of vital importance in a situation when user is threatened

to open a door by an intruder. If a duress finger is entered, a door opens normally but the device can send a duress signal to ring an emergency call or alarm.

z If you select Last Finger on the duress menu, the last fingerprint

enrolled is assigned as a duress finger. For example, if you enroll three fingers and select Last Finger for duress, the first and second fingers are enrolled as normal fingers and the third finger as a duress finger.

z To use duress finger, more than two fingerprints should be enrolled,

ie., Finger No. should be more than 2.

z Duress finger should be different from normal finger enrolled in

advance.

Enroll Finger

Finger No Duress Daily Limit Time Limit Card Bypass Card Input Type Card ID

◁ None ▶ ◀ None ▶

0 0

◀ Wiegand ▶

◀ Use ▶ ◀ Read Card ID▶

For Administrators - Basic Functions

Enroll New User

 If you enter all the necessary items for enrollment and press OK

key, the following fingerprint menus appear on the display.

Daily Limit

Time Limit

Card

Bypass Card

Input Type

z It sets the limit to the number of access for a user in a day.

If this is set as 0, user can access many times without limit.

z It sets the minimum interval between the accesses of a user.

If it is set as 0, there will be no minimum interval between the accesses for that user.

z Setting : Not Use/RF Card/Wiegand z It sets Use or Not use of card and the type of card.

z Setting : Use/Not Use z It sets authentication with card only, not with any additional

procedure.

z Setting : Direct Input/Use ID/Read Card ID. z It sets Card ID Input type.

Enroll Finger

Finger No Duress Daily Limit Time Limit Card Bypass Card Input Type Card ID

◁ None ▶ ◀ None ▶

0 0

◀ Wiegand ▶

◀ Use ▶ ◀ Read Card ID▶

Card ID

For Administrators - Basic Functions

z In case of Manual Input, users enter card ID directly. In case of User

ID, users set card ID as user ID. In case of Read Card ID, it will be read from card.

Enroll New User

 After selecting Finger No. and Duress and pressing OK, now

you should place a finger on a sensor for enrollment.

z For enrollment, the same finger should be placed twice according to the

messages shown in the display.

z If Finger No. is set more than 2, the device asks for the scan of the next

fingerprint continously.

z After placing a finger on a sensor, user can see the captured fingerprint image on

the display. If you do not want to display fingerprint images on display, you can change settings at “Device – Fingerprint – View Image” menu.

z If the two fingerprints are different from each other, enrollment process stops with

a message “Two fingerprints do not match”.

z If duress finger is same as normal finger enrolled beforehand, enrollment

process also stops with a message “Duress not allowed for the same finger”.

 Please place a finger correctly referring to <How to place a

finger>.

 If all the fingerprints are entered correctly, Enroll Success

message appears on the display together with a user ID and the fingerprint enrollment process is completed.

 After enrolling fingerprints of one user, the display shows the

next user ID to enroll the next user. If you do not want to enroll more users, press F4 to exit to initial display.

Enroll Finger

Finger 1

Place the First

Finger

Enroll Finger

Enroll Success

123456

For Administrators - Basic Functions

Check User Info

Check user info of currently enrolled users.

 If you select Edit User on User Management menu, user info of

each users are displayed.

 You can change user ID using a left/right navigation key.  If you enter user ID with the numeric key, you can directly move

to the user info the entered user ID.

z If there is no user with the selected ID, “None” message is

indicated on the Name field of the display. In that case, if you press left/right navigation key, you can go to the closest valid user ID.

 Additional info such as user name, department and company

name can be entered using BioAdmin software on PC.

 If you press F1 key, active function keys at this menu are

displayed, OK, F2 and F3.

User ID Name Dept. Admin Level Password No of Finger Group 1

Edit User

◀ 123456 ▶

Admin

Registered

Edit User

123456

Admin

Registered

None

F2 F3

None

Edit User Finger Delete

For Administrators - Basic Functions

Edit User Info

User info can be changed and fingerprints can be re-enrolled.

 If you press OK key at Edit User menu, the selected user info is

displayed and can be edited in the same way as in the Enroll User process. You can change admin level, password and groups.

 If you want to re-enroll fingerprints of the user, press F2 key at

Edit User menu.

 You can select the number of fingerprints and duress and then

re-enroll fingerprints.

Edit User : 123456

Admin Level Password Group 1 Group 2 Group 3 Group 4

◁ Normal ▷

◀ None ▶

◀ None ▶ ◀ None ▶

◀ None ▶

Enroll Finger

Finger No Duress

◀ Last Finger ▶

*******

For Administrators - Basic Functions

Delete User

Delete user from device while checking currently enrolled user info.

 If you want to delete the user, press F3 key at Edit User menu.

 Press OK key to confirm the deletion of the user.

z [Note] Deleted user info can’t be retrieved unless the info remains

in BioAdmin software on PC.

Edit User

Do you want to delete

this user?

OK ESC

For Administrators - Basic Functions

Delete All Users

Delete all user currently enrolled in device.

 Back to User Management menu, select Delete All User to delete

all users in the device.

 Press OK key to confirm the deletion of all users.

z [Note] Once all users are deleted, deleted user info cannot be

retrieved unless the info remains in BioAdm in software on PC.

z [Note] The data of administrators who is operating the menu is also

deleted by this operation. Therefore, in order to enter Admin menu again, you should remember the master password before deleting all users.

User Management

Do you want to delete

all users?

OK ESC

For Administrators - Basic Functions

Check User DB

Check and correct errors in the user information stored on device.

 If you press Check User DB on User menu, following menus

appear on the display.

 Press OK key to check the user DB.

z If there is an error on the user DB, it will be automatically corrected

by this procedure. If it fails to correct, an error message appear on display.

User Management

Do you want to check

user DB errors?

OK ESC

For Administrators - Basic Functions

For Administrators - Advanced Functions

Detailed information for

device administrators. It

includes specific items such

as display and sound setting,

fingerprint authenticatio n

setting, and log check.

Display & Sound Setting

Change device’s display and sound settings.

 If you select Display on initial Amin menu, following menus will

appear on the display.

z Setting :Korean/English/Custom

Language

Background

Sub Info

Timeout

Msg Time

z Select a language to be used z To use custom language, appropriate language config. file needs

to be downloaded to the device using BioAdmin program on PC. Please contact Suprema for de t ails.

z Setting : Logo/Slide Show/Notice z Decide background of initial display. In case of Logo, one photo

assigned as logo is displayed all the time. In case of Slide Show, multiple photos are displayed at the interval of 5 seconds in turn. In case of Notice, one photo is displayed as a background and a notice is scrolled down over the background.

z In order to change background images, use BioAdmin program on

PC.

z Setting : Time/None z Sub Info is a display area in the bottom side of the display. Current

date and time will be shown with a selection of Time. Or the area can be left blank with the selection of None.

z Setting : Infinite/10 sec/20 sec/30 sec z If there’s no key input during this time out period on Admin menu,

the device automatically returns to initial display for security reason.

z Setting : 0.5sec/1sec/2sec/3sec/4sec/5sec z It sets message time in display upon the fingerprint matching.

Language Background Sub Info Timeout Msg Time Volume

Display

◁ English ▷

◀ Logo ▶ ◀ Time ▶

◀ Infinite ▶ ◀ 2 sec ▶

20%

Time

Volume

z Setting : 0%/10%/20%/…/100% z Set output volume of the device sounds. 100% is the maximum. At

For Administrators - Advanced Functions

setting 0%, sound is turned off.

Display & Sound Setting

Change device’s display and sound settings.

 If you select Display on initial Amin menu, following menus will

appear on the display.

z Date : YYYYMMDD

Time

z Tim

z Time synchronization : Terminal time will be synchronized with

z Date format : MM/DD or DD/MM

: hhmmss

server time.

Language Background Sub Info Timeout Msg Time Volume

Display

◁ English ▷

◀ Logo ▶ ◀ Time ▶

◀ Infinite ▶ ◀ 2 sec ▶

20%

Time

For Administrators - Advanced Functions

Fingerprint Setting

Change various settings for fingerprint authentication.

 If you select Device on initial Admin menu, Device Setup menus

appear on the display.

 If you select Fingerprint, following menus appear on the display.  In this manual, the default setting is in bold font.

Security

z Setting : Normal/Secure/Most Secure z Security level is determined by FAR (False Acceptance Ratio).

FAR refers to the percentage of acceptance by unregistered fingerprints. Therefore, the lower the percentage is, the higher the security level is. However, as the FAR and FRR (False Reject Rate) are in reverse proportion to each other, the higher security level will indue bigger FRR, ie., more failure for registered fingers.

z For general T&A applications, normal level is recommended.

However, in case of an access control application requiring a higher security level, it is recommended to apply the security level as secure or most secure.

Device Setup

Fingerprint

Door Relay

Master Password

Device Info

Device Reset

Factory Default

Fingerprint

Security Fast Mode Quality View Image Sensitivity Timeout(Sec) Encryption

I/O

◀ Normal ▶ ◀ Normal ▶ ◀ Normal ▶ ◀ Visible ▶

◀ 7 (Max) ▶ ◀ 10 ▶

Not Use

For Administrators - Advanced Functions

Fingerprint Setting

Fast Mode

Quality

View Image

Sensitivity

Timeout(Sec)

z Setting : Normal/Fast/Fastest z Using 1:N mode with more than hundreds of users, identification may take somewhat longer. In this

case, you can change the fast mode to Fast or Fastest. By doing so, identification speed becomes faster in sacrifice of a little highe r FRR.

z Setting: Weak/Normal/Strict z Quality level decides the strictness of quality check of the input images. With a strict quality level, the

device may reject a low quality input fingerprint more.

z Setting : Visible/Invisible z Proper enrollment can be induced by showing the image of the entered fingerprint on LCD screen upon

enrollment.

z Setting : 0(min)/1/2/3/4/5/6/7(max) z Set sensitivity of fingerprint sensor in a capture of a fingerprint. At a high sensitivity level, it is easier

and faster to capture a fingerprint. On the other hand, at a low sensitivity level, the image quality of the captured fingerprint can be more stable.

z In normal applications, maximum level is recommended. If the recognition is not satisfactory for wet

fingerprints, reducing sensitivity may solve the problem.

z Setting : 1/2/…/10/…/19/20 z Set standby time for fingerprint enrollment. If a user does not place a finger within the time, a timeout

message appears on the display.

1:N Delay

Encryption

For Administrators - Advanced Functions

z Setting : 0/1/2/…./10 z It means the time of delay from 1:N authentication to next stand-by authentication

z Setting : Not Use / Use z Shows whether the BioStation is currently using the template encryption or not. Encryption can not be

set on the device itself, but should be set using BioAdmin program on PC.

I/O Setting

Change various settings for I/O.

 If you select I/O on device menu, following menus appear on

display.

Input 0 & Input 1

Output 0 & Output 1

Duration(ms)

Tamper S/W

z Setting : Disabled/Exit/Wiegand z In case of using the input port for RTE(exit button), select Exit. z In case of using input as Wiegand, input 0 and input 1 are set as

Wiegand.

z Setting: Disabled/Duress/Tamper SW/Auth Success/Auth

Fail/Wiegand

z Can send outputs for various events. z In case of using output as Wiegand, output 0 and output 1 are set

as Wiegand.

z Set the cycle of output signal. Default is 1sec (1000ms).

z Setting : None/Lock System z Tamper switch is turned on when a housing(case) of BioStation is

opened.

z If the setting is in “Lock System”, the device is automatically locked

when a tamper switch is on.

z This can be useful in security when an intruder opens the housing

of BioStation to enter a building.

z [Note] Once BioStation is locked, lock can be released only when

the master password is entered. It cannot be released by administrator’s fingerprint.

Input 0 Input 1 Output 0 Output 1 Duration(ms) Tamper SW

I/O

◁ Disabled ▷ ◀ Disabled ▶ ◀ Disabled ▶ ◀ Disabled ▶

1000

◀ None ▶

For Administrators - Advanced Functions

Door Relay Setting

Change various settings for door relay.

 If you select Door Relay on device menu, following menus

appear on the display.

Driven by

Duration (sec)

Lock time

Unlock time

z Setting: All events / Authentication +T&A event/T&A

event/Verification/Disabled

z In case of All events, door opens for all authentication success(1:1 PIN

auth.,1:1 fingerprint auth.,1:1 fingerprint verification)

z In case of authentication with T&A event, door opens only b y the specific

events for which door use is allowed and also door opens only by authentication.

z In case of selected T&A, door opens only by the specific events for which

door use is allowed.

z In case of authentication, door opens only by authentication without T&A

event

z In case of disabled, BioStation will not drive an internal rel ay to open a

door by any of events or authentication.

z Once a door is open, the door can be locked again after this duration.

z Decide time to lock(close) the door by force. z During lock time, general users cannot open door while only

administrators are allowed.

z The lock time can be set by BioAdmin program on PC.

z Decide time to open the door by force z The unlock time can be set by BioAdmin program on PC.

Door Relay

Driven by Duration(sec) Lock Time Unlock Time Interphone

◁ All Event ▷

◀ None ▶ ◀ None ▶

◀ Disable ▶

Interphone

For Administrators - Advanced Functions

z Setting : Disable / Enable z To connect and use an optional interphone with BioStation, enable

interphone on this menu. CALL button and interphone communication of BioStation will operate only when this menu is set as Enable.

Change Master Password

Change master PW.

 If you select Master Password on device menu, Master

Password menus appear on the display.

 Enter current master password to “Current” and a new master

password to “New” & “New (again)”. Then press OK key to confirm.

z Default password is blank (no need to type). z [Note] With this master password, one can enroll or delete users

and change settings of BioStation. Please be careful not to disclose master password except Administrators.

 When you forget master password

z If there is a user enrolled as administrator : you can enter Admin

menu using administrator’s fingerprint and return the password as blank by selecting the Factory Default on Device menu. However, in this case, other settings of the device also return to defaults.

Master Password

Current New New(Again)

z If there’s no user enrolled as administrator : contact the dealer you

purchased the device.

For Administrators - Advanced Functions

View Device Info

View device’s basic info such as model name and version.

 If you select Device Info on device menu, following menus

appear on the display.

Model

Device ID

MAC

HW Version

FW Version

Kernel Ver.

z Model name is displayed according to types of fingerprint sensor. z Optical sensor : BST-OC z Capacitive sensor : BST-TC z Thermal swipe sensor : BST-FC

z Device ID number is displayed.

z Device’s Ethernet MAC address is displayed.

z Device’s hardware version is displayed.

z Device’s firmware version is displayed. z Firmware and kernel can be upgraded using BioAdmin program

when new firmware is released.

z Device’s Kernel ver. Info is displayed.

Device Info

Model Device ID MAC HW Version FW Version Kernel Ver. Memory

Standard

1301

00:17:fc:10:05:15

Rev. E

V1.0

7/19 MB

Memory

For Administrators - Advanced Functions

z Overall available storage and currently used storage are displayed. z In the internal memory of BioStation, various information like user

info, log, background and sounds are stored, so used memory changes by the size of these information.

Device Reset

Reset system.

 If you select Device Reset on device menu, a message to restart

BioStation appears on the display.

 Press OK key to reset device. Device reset takes normally 20-30

seconds and it may take a bit longer for network connection.

 If you change language of BioStation, you should reset

BioStation to apply the new language.

 If device becomes unstable for any reason, in most of cases,

device reset can solve the problem.

Device Setup

Do you want to restart

BioStation?

OK ESC

For Administrators - Advanced Functions

Factory Default

Restore device’s all settings to factory defaults.

 If you select Factory Default on device menu, a message to

reset to default appears on the display.

 Press OK key to change system’s various settings as factory

defaults.

z [Note] Be sure that various settings, background, sounds and

notice will be deleted.

 User info and log data are not deleted. To delete user info, refer

to <Delete All Users>. To delete log data, refer to <Delete Entire Log>.

Device Setup

Do you want to reset

to default?

OK ESC

For Administrators - Advanced Functions

Check Log

Check logs for various events accumulated in device.

 If you select Log on initial Admin menu, log events appear on

the display. You can check logs from the latest one.

 Press up/down navigation key to scroll a log one by one.  Press left/right navigation key to scroll a log by page (8 logs).  Press F1 key to display available additional function key.

z OK : Latest z F2 : Filter z F3 : Delete

 Press OK key to display the latest log.

Log List

9/14 13:39 Duress (Menu) 123456 9/14 13:30 Identify OK (Menu) 1111 9/14 13:25 Duress (Menu) 123456 9/14 12:51 Identify OK (Menu) 1111 9/14 12:45 Duress (Menu) 123456 9/14 12:43 Identify OK (Menu) 1111 9/14 12:39 Duress (Menu) 123456 9/14 12:26 Identify OK (Menu) 1111

For Administrators - Advanced Functions

Filter Log

Check specific log events by filtering the log events stored on device.

 If you press F2 key on Log menu, following menus appear on

the display.

Filter ID

Time

Event

T&A Event

User

z Select the filter ID. z Device can store up to 4 filters.

z Setting : All/Today/Yesterday/Last 3 days/Last 1 week/Last 1

month

z Designate the time to filter.

z Setting : All/Success/Fail/IO/Duress/Tamper/System z Select the events to be shown on the log list.

z Select the T&A events to be shown on the log list.

z To check the log events of a specific user, enter the user’s ID. If

you press 0, log events of all users are displayed.

Filter ID Time Event T&A Event User

Filter

◁ 1 ▷ ◀ All ▶ ◀ All ▶ ◀ All ▶

For Administrators - Advanced Functions

Delete Entire Log

Delete entire event logs accumulated in device.

 If you press F3 on log list screen, a message to delete all logs

appears on the display.

 Press OK key to delete all logs.

z [Note] Be sure that a deleted log can not be retrieved unless it

remains in BioAdmin program on PC.

Log List

Do you want to delete

all logs?

OK ESC

For Administrators - Advanced Functions

USB Memory

How to use USB memory to transfer user information, log data, and various settings of device.

 If you select USB Memory on Network menu, following menus

appear on the display.

 When you are using wireless LAN, the wireless LAN is

automatically disconnected in this menu. When you go out of this menu, wireless LAN is reconnected.

Synchronize

Export Virtual Terminal

z Transfer the user information and various settings from the virtual

terminal of USB memory to the connected BioStation. At the same time, transfer the log data from the connected BioStation to the virtual terminal of USB memory.

z [Note] Synchronize menu erases the current user information and

various settings of the device and overwrite with the information and settings on USB memory.

z Useful in transferring the data from BioAdmin program to device. z Enabled only when the USB memory has a virtual terminal with the

same device ID as that of the connected BioStation.

z Create a virtual terminal on USB memory with the same device ID.

Export the user information, log data, and various settings of the connected device to the virtual terminal on USB memory.

z It may take a few minutes depending on the size of the user

information and log dat a t o exp ort.

z To synchronize or import virtual terminal, you need to create a

virtual terminal first on the USB memory by using Export Virtual Terminal menu.

z This menu is enabled only when a USB memory is connected to

BioStation.

USB Memory

Synchronize Export Virtual Terminal Import Virtual Terminal

Firmware Upgrade

Initialize Refresh

For Administrators - Advanced Functions

USB Memory

How to use USB memory to transfer user information, log data, and various settings of device.

Import Virtual Terminal

Firmware Upgrade

Initialize

z Apply the user information and various settings in USB memory to

the connected device.

z Import starts by selecting the an ID of the virtual terminals on USB

memory.

z [Note] This menu erases the current user information and various

settings of the device and overwrite with the information and settings on USB memory.

z Used to transfer the user information and various settings from one

device to another.

z Useful in periodical back up and restoration of device information. z This menu is enabled only when the connected USB memory has

a virtual terminal.

z Upgrade the firmware of the connected device with the firmware

file stored on USB memory.

z Firmware upgrade starts by selecting one of the firmware files

stored on the root directory of USB memory.

z Upon finishing the firmware upgrade, device automatically restarts. z This menu is enabled only when a firmware file exists in the root

directory of USB memory.

z Delete all virtual terminals on USB memory. z This menu is enabled only when a USB memory is connected to

BioStation.

USB Memory

Synchronize Export Virtual Terminal Import Virtual Terminal

Firmware Upgrade

Initialize Refresh

Refresh

For Administrators - Advanced Functions

z Refresh the connection of the USB memory and the stored

information on the connected USB memory.

For General Users

Describes directions for

general users. It explains

how to open a door in each

operation mode and to enter

T&A events.

Access using 1:N mode

How to open a door using fingerprint when 1:N mode is set as Auto or OK/T&A key.

 When 1:N mode is set as Auto

z If you enter a fingerprint without pressing any key, a message

showing the identification result appears and door is opened.

 When 1:N mode is set as OK/T&A key

z If you press OK or T/A key, blue LED flickers and a message

requesting user’s fingerprint appears on the display.

z Place a finger to open the door.

 Use of personal info

z When personal info image and message are set, the set image and

message by successful authentication will be shown.

▼ T&A

Welcome! Tommy

▼ T&A

Authentication Place your finger

For General Users

Access using 1:1 mode

How to open a door by entering ID first and then entering fingerprint or password.

 If you press a numeric key, ID input window appears.

 Enter your ID and press OK key.  In case 1:1 mode is set as Fingerprint Only

z Enter a fingerprint to open the door.

 In case 1:1 mode is PIN Only

z Enter your password and press OK key to open the door.

 In case 1:1 mode is set as Fingerprint or PIN

z You can either enter a fingerprint or enter password and press OK

key.

 In case 1:1 mode is set as RF Card

z If the 1:1 mode is set as Card Only, user can access just by placing

the card to BioStation without any additional procedure.

z If the 1:1 mode is not set as Card Only, card is used to suggest the

user’s ID. After putting the card, user should verify himself with fingerprint or password.

▼ T&A

User ID

1234

For General Users

Access using 1:1 mode

How to open a door by entering ID first and then entering fingerprint or password.

▼ T&A

User ID

1:1 verification How to suggest user ID How to authorize

Fingerprint or password Enter user ID or

put the card

Fingerprint Only Enter user ID or

Put finger or

enter password

Put finger

put the card

Password Only Enter user ID or

Enter password

put the card

Card Only Put the Card

1234

For General Users

T&A event using 1:N mode

How to enter T&A events with fingerprint when 1:N mode is set as Auto or OK/T&A key, and T&A is set as Enabled.

 If you press F1~F4 key, blue LED flickers and a message

requesting user’s fingerprint appears on the display.

 If you place a finger, designated T/A event appears on the

display and applies to the user.

 In case that ‘Driven by’ on the door relay menu is set as

‘Selected T&A’ and that ‘Activate Relay by this Event’ is checked on the BioAdmin program, a door opens upon the occurrence of the T&A events.

 You can check on ‘Activate Relay by this Event’ in T&A event

with BioAdmin program on your PC.

▼ T&A

T&A: In

Place your finger

▼ T&A

In: Tommy

8/1(Tue) AM 8:00

For General Users

T&A event using 1:1 mode

How to enter T&A event by first entering ID and then entering fingerprint or password when T&A is set as enabled.

 If you press a numeric key, ID input window appears on the

display.

 Enter your ID and press F1~F4.  In case 1:1 mode is set as Fingerprint Only

z Enter fingerprint to apply applicable T&A event.

 In case 1:1 mode is set as PIN Only

z Enter your PW and press OK key to apply applicable T&A event.

 In case 1:1 mode is set as Fingerprint or PIN

z You can either enter fingerprint or enter password and press OK

key.

▼ T&A

User ID

1234

For General Users

Using extended T&A events

In case of using 4 or more T&A events, you can use extended T&A events.

 If you press down navigation key, extended T&A events info

appears on the display.

 If you press one of 16keys corresponding to the desired T&A

event, next operation starts for the extended T&A event.

 Factory default T&A events are defined as below.

z F1 (In), F2 (Out), F3 (In duty), F4 (Out duty)

 You can edit the default T&A events and extended T&A events

with BioAdmin program on your PC.

1 2 3 F1 4 5 6 F2 7 8 9 F3 CALL 0 ESC F4

Out

In duty

Out duty

For General Users

View user’s Access/T&A event records

General users can check their own access and T&A event records.

 If you press ESC key on initial screen, a message requesting

user fingerprint or password appears on the display.

 If user enter his/her fingerprint or password, access and T&A

event records displays as below.

 Press up/down navigation key to scroll a log one by one.  Press left/right navigation key to scroll a log page by page

(8 logs).

 Press OK key to display the latest log.

▼ T&A

Admin fingerprint or

master password

OK ESC

User Log: 123456

For General Users

Authentication procedure as per operation mode

1:N Mode

1:1 Mode

ID (Key)

Card

(skip in case of Auto setting)

fingerprint

(finger scan)

PW+OK

(auth. PW)

fingerprint

(finger scan)

PW+OK

(auth. PW)

(skip in case of card only)

For General Users

Authentication procedure for T&A event

1:N Mode

F1~F4

(default T&A event)

Down key+16key

(extended T&A event)

fingerprint

For General Users

1:1 Mode

ID (Key)

F1~F4

(default T&A event)

Down key+16key

(extended T&A event)

fingerprint

(finger scan)

PW+OK

(auth. PW)

List of Admin Menu

User

Mode

Display

Log

Enroll User

Edit User

Delete All users Check User DB

1:1 Mode 1:N Mode

T&A

T&A key

Language

Background

Sub Info

Timeout

Date Time

Volume

OK: Latest

F2: Filter Log

F3: Delete

User ID

Admin Level

Password

Group 1 Group 2 Group 3 Group 4

Finger No

duress

OK: Edit User

F2: Finger

F3: Delete

Filter ID

Time

Event

T&A Event

User

Device

Network

Fingerprint

I/O

Door Relay

Master

Password

Device info

Device Reset

Factory default

USB Memory

TCP/IP

Serial

USB

Security

Fast Mode

Quality

View Image

Sensitivity

Timeout

Encryption

Input 0, Input 1

Output 0, Output 1

Duration(ms)

Tamper SW

Driven by

Duration(sec)

Lock Time

Unlock Time

Interphone

Synchronize Export Virtual Terminal Import Virtual Terminal

Firmware Upgrade

Initialize

Refresh

LAN Type

Port

Server IP

DHCP

IP Address

gateway

Subnet

RS485 RS232

USB

Appendix

Specifications

 CPU : Dual CPU (32 bit RISC + 400MHz DSP)  Memory : 72MB flash + 34MB RAM  Display : 2.5 inch QVGA 16 million color LCD  Identification speed : 3,000 fingerprints in 1 second  Fingerprint capacity : 50,000 fingerprint templates  Log capacity : 500,000 events  Host interface : Wireless LAN (optional), TCP/IP, RS485  PC interface : USB, RS232  USB memory slot : USB host  1 relay for deadbolt, EM lock, door strike, or automatic door  Wiegand input/output, 4 TTL input/output  Built-in microphone and speaker supporting door phone  Convenient menu navigation key  4 function keys for user defined functions

Appendix

 Operation mode : Fingerprint, PIN, PIN+Fingerprint,  Card only*, Card+Fingerprint*, Card+PIN* (*RF model only)  RF Card : 125KHz proximity (RF model only)  RTC with backup battery (CR2032)**  Product size : 135 x 128 x 50 mm (width x length x depth)

** CAUTION

: RISK OF EXPLOSION IF BATTERY IS REPL AC ED B Y AN INCORRECT T YPE . DIS P OSE OF USED BATTERY ACCORDING TO THE INSTRUCTIONS

Troubleshooting

 Fingerprint can not be read well or it takes too long.

z Check whether a finger or fingerprint sensor is stained with sweat, water, or dust z Retry after wiping off finger and fingerprint sensor with dry towel. z If a fingerprint is way too dry, blow on the finger and retry.

 Fingerprint is entered but authorization keeps failing.

z Check whether the user is restricted by door zone or time zone. z Inquire of administrator whether the enrolled fingerprint has been deleted frin the device for some

reason.

z If message ‘not enrolled ID’ appears after ID is entered and OK is pressed, it means that the

fingerprint has not been enrolled.

 Authorized but door is not opened.

z Check whether the time is set as lock time. z Check ‘driven by’ on Admin menu. z In case it is set as disabled or selected T/A events, door may not open.

 Partial key can’t be entered or device is unstable.

Appendix

z In case device is unstable for any reason, enter Admin menu and reset device.

 All keys are not entered

z If LCD display and blue LED are off, it is possible that power is off. Check power condition such as

blackout.

z If LCD display and blue LED are on, something is wrong with machine. In such a case, contact A/S

center.

Device cleaning

 Wipe out machine surface with dry towel or cloth.  In case there is dust or impurities on the sensor of the BioStation, wipe off the surface with

dry towel.

 Note that if the sensor is cleaned by detergent, benzene or thinner, surface is damaged and

fingerprint can’t be entered.

Appendix

16F Parkview Office Tower, Jeongja-dong, Bundang-gu,

Technical Support & Inquiry

Functions and specifications of the product are subject to changes without notice due to quality enhancement or function update. For any inquiry on the product, please contact Suprema Inc.

Suprema Inc.

Seongnam, Gyeonggi, 463-863 Korea

E-mail : support@supremainc.com

Website : www.supremainc.com

Suprema BIOSTATIONRHOC User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Innovative Fingerprint Terminal for Access Control and Time Attendance

Innovative Fingerprint Terminal for Access Control and Time Attendance

Contents

Contents

Safety precautions

Safety precautions

Glossary

Basics of fingerprint recognition

How to place a finger

How to place a finger

Product Contents

Product Contents

Name of each part

Name of each part

Installation

Cable spec.

For Administrators - Basic Functions

Enter Admin Menu

Using Admin Menu

Operation mode setting

TCP/IP

Wireless LAN

Server

Serial

Enroll New User

Enroll New User

Enroll New User

Enroll New User

Check User Info

Edit User Info

Delete User

Delete All Users

Check User DB

For Administrators - Advanced Functions

Display & Sound Setting

Display & Sound Setting

Fingerprint Setting

Fingerprint Setting

I/O Setting

Door Relay Setting

Change Master Password

View Device Info

Device Reset

Factory Default

Check Log

Filter Log

Delete Entire Log

USB Memory

USB Memory

For General Users

Access using 1:N mode

Access using 1:1 mode

Access using 1:1 mode

T&A event using 1:N mode

T&A event using 1:1 mode

Using extended T&A events

View user’s Access/T&A event records

Authentication procedure as per operation mode

Authentication procedure for T&A event

List of Admin Menu

Specifications

Troubleshooting

Device cleaning
