Suprema BEWHOC User manaual

BioEntry W

Compact Outdoor Fingerprint Reader/Controller

Installation Guide

Version V1.0

www.supremainc.com

BioEntry W

heat registers, and stoves.

the outer environment.

Important Safety Information

Carefully review the information within the user manual before installing/operating the device. Pay careful attention to the warning and cautions below as they are here to prevent any risk/damage to

any person(s) or property associated with the device.

Warning

Failure to heed these warnings may lead to serious injury or even death!

Installation

 Do not install the device near heat sources such as radiators,

 Do not install the device near areas of large electromagnetic

interference.

Usage

 Do not disassemble, repair or reconstruct the device.

Contact your nearest Suprema dealer for technical support.

 Only use the device its intended use.

Caution

Failure to heed these cautions may lead to minor injury or damage the device.

Installation

 Do not leave cables (especially power cables) exposed to

 Do not install the device near objects with a strong magnetic

field such as magnets, computer monitors (especially CRT), TV screens and speakers.

Usage

 Do not drop or apply any physical shock/impact to the device.  Regularly clean the product with a soft dry cloth; avoid

benzene or alcohol.

Ⓒ

BioEntry W

Installation

About Fingerprint Recognition 4

Contents

How to Enroll a Fingerprint on the Device 5

Components 7

Product Description 9

Dimensions 11

Cable Specifications 12

System Configurations 14

Connections 17

Resetting Network Settings 28

Electrical Specifications 29

Product Specifications 30

Troubleshooting 31

Precautions for Device cleaning 32

FCC Rules 33

Ⓒ

BioEntry W

Fingerprint sensors generate 2

dimentional fingerprint images using various technologies: optical, capacitive, or

About Fingerprint Recognition

What is a fingerprint?

Fingerprints are individual’s own biometric information and do not change throughout one’s life. Fingerprint recognition is a technology that verifies or identifies an individual using such fingerprint information. Free from the risk of theft or loss, fingerprint recognition technology is being widely used in security systems replacing PIN or cards.

What is fingerprint recognition?

Fingerprints consist of ridges and valleys. Ridge is a flow of protruding skin in a fingerprint while valley is the hollow between two ridges. Each individual has unique patterns of ridges and valleys; fingerprint recognition makes use of these differences to differentiate between individuals.

thermal. Fingerprint template is a collection of numeric data representing the features of a fingerprint. Fingerprint templates are saved inside the memory of BioEntry W, and used for identification.

Suprema’s Personal Information Protection Technology

To avoid privacy concern, Suprema’s fingerprint products do not save fingerprint images itself. It is impossible to reconstruct a fingerprint image from a fingerprint template which is just numeric data of the features of a fingerprint.

Ⓒ

BioEntry W

How to place a finger on a sensor

How to Enroll a Fingerprint on the Device

Suprema's fingerprint products have outstanding recognition performance regardless of the user's fingerprint condition or positioning. However pay careful attention to the following instructions to maximize the performance of the device.

Fingerprint Enrollment

 It is recommended to enroll the index or middle finger.

The thumb, ring or little finger are generally more difficult to position properly.

 Fully cover or provide maximum contact to the surface of the sensor with the desired finger. People tend to

place the tip of a finger on the sensor; this will only provide a small area of the finger to be captured and will result in poor performance.

 Place the core of the fingerprint near the center of the sensor. This will ensure a good template will be

created. The core of a fingerprint is a center where the spiral of ridges is most dense.

Ⓒ

BioEntry W



Enroll the same finger multiple times.

How to Enroll a Fingerprint on the Device

Fingerprint Enrollment Precautions

Operational Warnings

 If a finger is wet or too moist, wipe off the moisture then try the scan again.  If a finger is covered with dust or impurities, clean the finger then try the scan again.  If a finger is dry, breathe warm air onto the finger then try the scan again.

Solving Authentication Difficulties

 Delete then Re-enroll the finger.

 Try a different finger with a more vivid fingerprint.  Enroll various fingers for each user.

Ⓒ

BioEntry W

Components

 Basic Components

Wall Mount Screws (2) Main Unit Mounting

Screws (2)

BioEntry W

Wall Mounting bracket (1)

Software CD (1)

Ⓒ

BioEntry W

Components

 Optional Accessories

12VDC Power Adaptor Plastic StandSecure I/O

Ⓒ

USB Fingerprint

Scanner

BioEntry W

Standard Operation



Place an RFID card over the

Color per 2sec

Standard Operation

Product Description

 Front

LED

 Displays the current status with

various colors.

RFID Scanner

scanner.

Fingerprint Sensor

 Place a finger on the surface of the

sensor.

LED Device Status

Green Successful Authentication

Red Failed Authentication

Pink Processing

Flicker Blue/Sky-Blue

Flicker Red/Pink

Color per 2sec

Flicker Blue/Red

Color per 2sec

Flicker Blue/Yellow

Color per 2sec

Flicker Red Color per

2sec

Flicker Yellow Color

per 2sec

Device Locked

Discharged Internal Battery

Unable to Acquire an IP Address from the DHCP Server.

Unit Malfunction. Contact Your Suprema Dealer/Distributor.

Waiting for an Input

Flicker Yellow Color

per 1sec

Requesting IP Address from the DHCP Server.

Ⓒ

BioEntry W



Relay Cables

Product Description

 Rear and Bottom

Cables

 Wiegand Input/Output Cables  Power Cables  RS485 Cables  Ethernet Connector  Input Cables

LED

 Network Status LED

Network Reset Switch

 See "Resetting Network Settings (page 28)" for more details.

Star-shaped screw hole for fixing a body to a metal bracket

Ⓒ

BioEntry W

Dimensions

 BioEntry W

172 mm

50 mm

172 mm

 Wall Mounting Bracket

40 mm44 mm

157 mm

Ⓒ
