SuperOx

SuperOX Applications

Glass furnaces (side-fired, end-fired, float, container,

and fiberglas)

Power generation - boilers (gas-fired and coal-fired)

Ceramic and brick kilns

Petrochemical - after-burners, incinerators, package

SuperOX Specifications

Temperature range: 1150 - 3000 F (650 - 1650 C)

Sensor impedance: less than 20 K ohms @ 1700 F

Sensor output: 0 to 1250 mVDC

Response time: less than 1 second

Sheath material: 99% Alumina or Silicon Carbide

'Explosive Mixture

SuperOX Benefits

 Field performance can be

Present' Alarm

collaborated using external

"verification" port

 Cooling air maintains positive

pressure to ensure the integrity of

electrical connections in harsh

environments

 Outer electrode is not "painted"

Fuel or Process

Gas Train

on the zirconia electrolyte,

eliminating the antiquated

"boot" design

 Available in a number of standard

lengths - 18"(457mm), 26"(660mm),

30"(762mm), and 36" (915 mm)

 "B", "S", and "R" thermocouples are

available

I n si t u hi g h te m p e ra t u re ox y g e n s e n s or

m o ni t o rs / co n t ro l s co m b us t i o n e f f ic i e n c y

Direct-fired furnaces (reheat, annealing, tunnel)

boilers, sulfur burners

Process variable range: 8.77 E - 23 to 20.9%

Fuel Trim Control Signal

Air Trim Control

Signal

By Pass Line Size:

20% Flow Volume

of Main Train

Monitor/Controller

VF Trim

VA Trim

Pack

Pack

o

Umbilical Cable

'In-situ'

Oxygen Probe

o

o

I N N O VA T I V E S O L U T I O N S W O R L D W I D E

S06-12200829-003

Super

Systems

in corp ora ted

Combustion Efficiency Solutions

9120 PVT (P/N 13454)

Color

Display

4-20mA

to PLC

ETHERNET

TCP/IP

Control

Output

Reference Air System

Chart Recorder

Description Sheath Material Insertion Length Part Number

SuperOX - "B" T/C

SuperOX - "B" T/C

SuperOX - "B" T/C

SuperOX - "B" T/C

SuperOX - "B" T/C

SuperOX - "B" T/C

SuperOX - "B" T/C

SuperOX - "B" T/C

Alumina

Silicon Carbide

Alumina

Silicon Carbide

Alumina

Silicon Carbide

Alumina

Silicon Carbide

18"

18"

26"

26"

30"

30"

36"

36"

9120 PVT & Controller

24 Vdc Power Supply

Digital Display

AC20 Oxygen Controller

Ref Air / Cooling Air

Ref Air / Cooling Air

Ref Air Only

Single Zone

Dual Zone

Dual Zone

RS485

Modbus

Built-In

1827200

1837200

1825200

1835200

1828200

1838200

1826200

1836200

13518

31135

31286

31069

13017

13368

1301710
