Supermicro X9SRi-F operation manual

X9SRi
X9SRi-F
X9SRi-3F
X9SRE
X9SRE-F
X9SRE-3F

USER’S MANUAL

Revision 1.0c

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu­mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE
USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.
SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED
WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all
claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason­able protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
manufacturer’s instruction manual, may cause interference with radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turn­ing the equipment off and on, you are encouraged to try to correct the interference by one or more
of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and the receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/television technician for help.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn­ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this prod­uct may expose you to lead, a chemical known to the State of
California to cause birth defects and other reproductive harm.

Manual Revision 1.0c

Release Date: February 22, 2013

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document. Information in this document is subject to change without notice.
Other products and companies referred to herein are trademarks or registered trademarks of their
respective companies or mark holders.

Copyright © 2013 by Super Micro Computer, Inc. All rights reserved.

Printed in the United States of America

Preface

This manual is written for system integrators, PC technicians and

knowledgeable PC users. It provides information for the installation and use of the

X9SRi/X9SRE Motherboard Series motherboard.

About This Motherboard

The X9SRi/X9SRE Motherboard Series supports a single Intel® E5-1600/

E5-2600 series processor (2011-pin, Socket R). With the Intel® C600 series chipset

built in, the X9SRi/X9SRE Motherboard series offers top-of-the-line system perfor-

mance and storage capability. Features such as eight SAS/SATA ports, support

for up to 256GB of memory, and IPMI support make the X9SRi/X9SRE series ideal

for high end server platforms.

Please refer to our website (http://www.supermicro.com/products/) for processor

and memory support updates.

*This product is intended to be installed and serviced by professional technicians.

Manual Organization

Chapter 1describesthefeatures,specicationsandperformanceofthemother-

board, and provides detailed information on the Intel Patsburg chipset.

Chapter 2 provides hardware installation instructions. Read this chapter when in-

stalling the processor, memory modules and other hardware components into the

system. If you encounter any problems, see Chapter 3, which describes trouble-

shooting procedures for video, memory and system setup stored in the CMOS.

Chapter 4 includes an introduction to the BIOS, and provides detailed information

on running the CMOS Setup utility.

Appendix A provides BIOS Error Beep Codes.

Appendix B lists software program installation instructions.

Appendix C contains the UEFI BIOS Recovery instructions.

Preface

iii

X9SRi/X9SRE Motherboard Series User’s Manual

Conventions Used in the Manual:

Special attention should be given to the following symbols for proper installation and

to prevent damage done to the components or injury to yourself:

Danger/Caution: Instructions to be strictly followed to prevent catastrophic

system failure or to avoid bodily injury

Warning: Critical information to prevent damage to the components or

data loss.

Important: Important information given to ensure proper system installa-

tion or to relay safety precautions.

Note: Additional Information given to differentiate various models or pro-

vides information for correct system setup.

iv

1-4 Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Contacting Supermicro

Asia-Pacic

Address: Super Micro Computer, Inc.

4F, No. 232-1, Liancheng Rd

Chung-Ho Dist., New Taipei City 235

Taiwan

Tel: [phone]

Fax: [phone]

Web Site: www.supermicro.com.tw

Technical Support:

Email: [e-mail]

Tel: [phone]

v

X9SRi/X9SRE Motherboard Series User’s Manual

Table of Contents

Preface

About This Motherboard ................................................................................................ iii

Manual Organization .....................................................................................................iii

Conventions Used in the Manual: .................................................................................iv

1-4 Contacting Supermicro ........................................................................................v

Chapter 1

Introduction

1-1 Overview ......................................................................................................... 1-1

Checklist .......................................................................................................... 1-1

Motherboard Features ..................................................................................... 1-7

1-2 Chipset Overview ..........................................................................................1-11

Intel C600 Chipset Series Features ...............................................................1-11

1-3 Special Features ........................................................................................... 1-12

Recovery from AC Power Loss ..................................................................... 1-12

1-4 PC Health Monitoring .................................................................................... 1-12

Fan Status Monitor with Firmware Control .................................................. 1-12

Environmental Temperature Control ............................................................. 1-12

System Resource Alert ................................................................................. 1-12

1-5 ACPI Features ............................................................................................... 1-13

Slow Blinking LED for Suspend-State Indicator ........................................... 1-13

1-6 Power Supply ................................................................................................ 1-13

1-7 Super I/O ....................................................................................................... 1-14

1-8 Overview of the Nuvoton WPCM450 Controller ........................................... 1-14

Chapter 2

Installation

2-1 Static-Sensitive Devices .................................................................................. 2-1

Precautions ..................................................................................................... 2-1

Unpacking ....................................................................................................... 2-1

2-2 Processor and Heatsink Installation................................................................ 2-2

Opening the LGA2011 Socket ....................................................................... 2-2

Installing the LGA2011 Processor .................................................................2-4

Installing a Passive CPU Heatsink ................................................................. 2-6

Removing the Heatsink ................................................................................... 2-7

2-3 Installing DDR3 Memory ................................................................................. 2-8

DIMM Installation ............................................................................................ 2-8

vi

Table of Contents

Removing Memory Modules ........................................................................... 2-8

Memory Support .............................................................................................. 2-9

Memory Population Guidelines ..................................................................... 2-10

2-4 Motherboard Installation .................................................................................2-11

Tools Needed .................................................................................................2-11

Location of Mounting Holes ...........................................................................2-11

Installing the Motherboard ............................................................................ 2-12

2-5 Connectors/IO Ports ...................................................................................... 2-13

Motherboard I/O Backpanel .......................................................................... 2-13

ATX PS/2 Keyboard/Mouse Ports ............................................................ 2-14

Universal Serial Bus (USB) ...................................................................... 2-15

Ethernet Ports .......................................................................................... 2-16

Serial Ports ............................................................................................... 2-17

Video Port ................................................................................................. 2-18

Front Control Panel ....................................................................................... 2-19

FrontControlPanelPinDenitions............................................................... 2-20

Power LED .............................................................................................. 2-20

HDD LED .................................................................................................. 2-20

Power Fail LED ........................................................................................ 2-20

NIC1/NIC2 (LAN1/LAN2) .......................................................................... 2-21

Overheat (OH)/Fan Fail / UID LED .......................................................... 2-21

NMI Button ............................................................................................... 2-22

Reset Button ........................................................................................... 2-22

Power Button ........................................................................................... 2-22

2-6 Connecting Cables & Optional Devices ........................................................ 2-23

ATX Main PWR (JPW1) & CPU PWR Connectors (JPW2) ..................... 2-23

Fan Headers (FAN1~4, FANA) ................................................................ 2-24

Chassis Intrusion (JL1) ............................................................................ 2-24

Speaker (JD1) .......................................................................................... 2-25

Internal Buzzer (SP1) ............................................................................... 2-25

Wake-On-LAN (JSTBY1) .......................................................................... 2-25

Power Supply I2C (JPI2C1) ...................................................................... 2-26

DOM PWR Connector (JSD1) .................................................................. 2-26

T-SGPIO 1/2 & 3-SGPIO 1/2 Headers ..................................................... 2-27

TPM Header (JTPM1) .............................................................................. 2-27

Unit ID Switch (UID SW) .......................................................................... 2-28

Overheat/Fan Fail LED (JOH1) ........................................................ 2-28

System Management Bus (JIPMB1) ................................................. 2-29

vii

X9SRi/X9SRE Motherboard Series User’s Manual

2-7 Jumper Settings ............................................................................................ 2-30

Explanation of Jumpers ................................................................................ 2-30

LAN Port Enable/Disable (JPL1~2) .......................................................... 2-30

CMOS Clear (JBT1) ................................................................................. 2-31

PCI-E Slot SMB Enable (JI2C1/JI2C2) .................................................... 2-31

VGA Enable (JPG1) ................................................................................. 2-32

Watch Dog Reset (JWD1) ........................................................................ 2-32

USB Wake-Up (JPUSB1) ......................................................................... 2-33

BMC Enable/Disable (JPB1) .................................................................... 2-33

BIOS Recovery (JPBIOS1) ...................................................................... 2-34

ME Recovery (JPME1) ............................................................................. 2-34

2-8 Onboard Indicators ........................................................................................ 2-35

LAN Port LEDs ......................................................................................... 2-35

IPMI Dedicated LAN LEDs ..................................................................... 2-35

Rear Unit ID LED (UID LED) ................................................................... 2-36

IPMI Heartbeat LED (DP3) ...................................................................... 2-36

Onboard Power LED (DP2)...................................................................... 2-36

2-9 SATA and SAS Connections ......................................................................... 2-37

SATA/SAS Connections .......................................................................... 2-37

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

Before Power On ............................................................................................ 3-1

No Power ........................................................................................................ 3-1

No Video ......................................................................................................... 3-2

Memory Errors ............................................................................................... 3-2

WhenYouLosetheSystem’sSetupConguration ........................................ 3-2

3-2 Technical Support Procedures ........................................................................ 3-3

3-3 Frequently Asked Questions ........................................................................... 3-4

3-4 Battery Removal and Installation .................................................................... 3-6

Battery Removal .............................................................................................. 3-6

Proper Battery Disposal .................................................................................. 3-6

Battery Installation ........................................................................................... 3-6

3-5 Returning Merchandise for Service................................................................. 3-7

viii

Table of Contents

Chapter 4

BIOS

4-1 Introduction ...................................................................................................... 4-1

Starting BIOS Setup Utility .............................................................................. 4-1

HowToChangetheCongurationData ......................................................... 4-1

How to Start the Setup Utility ......................................................................... 4-2

4-2 Main Setup ...................................................................................................... 4-2

System Overview: The following BIOS information will be displayed: ....... 4-3

System Time/System Date ........................................................................ 4-3

Supermicro X9SRE/X9SR-3F/X9SRi/X9SRi-3F ......................................... 4-3

Memory Iniformation ................................................................................... 4-3

Total Memory .............................................................................................. 4-3

4-3 AdvancedSetup Congurations...................................................................... 4-4



BOOT Feature .............................................................................................. 4-4

Quiet Boot .................................................................................................. 4-4

AddOn ROM Display Mode ........................................................................ 4-4

Bootup Num-Lock ....................................................................................... 4-4

Wait For 'F1' If Error ................................................................................... 4-4

Interrupt 19 Capture ................................................................................... 4-4

Watch Dog Function ................................................................................... 4-5

Power Button Function ............................................................................... 4-5

Restore on AC Power Loss ........................................................................ 4-5



CPUConguration ....................................................................................... 4-5



Socket 1 CPU Information ....................................................................... 4-5

Clock Spread Spectrum ............................................................................. 4-5

Hyper Threading ......................................................................................... 4-5

Active Processor Cores .............................................................................. 4-6

Limit CPUID Maximum ............................................................................... 4-6

Execute-Disable Bit .................................................................................... 4-6

Intel® AES-NI ............................................................................................. 4-6

Hardware Prefetcher .................................................................................. 4-6

Adjacent Cache Line Prefetch ................................................................... 4-6

DCU Streamer Prefetcher .......................................................................... 4-6

DCU IP Prefetcher...................................................................................... 4-6

Intel® Virtualization Technology ................................................................. 4-7



CPUPowerManagementConguration ................................................. 4-7

ix

X9SRi/X9SRE Motherboard Series User’s Manual

Power Technology ...................................................................................... 4-7

EIST ............................................................................................................ 4-7

Turbo Mode ................................................................................................ 4-7

C1E Support ............................................................................................... 4-7

CPU C3 Report, CPU C6, CPU C7 Report ............................................... 4-7

Package C State Limit ............................................................................... 4-7



ChipsetConguration ................................................................................... 4-8



NorthBridgeConguration ...................................................................... 4-8



IntegratedIOConguration ..................................................................... 4-8

Intel® VT-d .................................................................................................4-8

Intel® I/OAT ................................................................................................ 4-8

DCA Support ..............................................................................................4-8

IIO 1 PCIe Port Bifurcation Control ............................................................ 4-8

Slot 6 PCI-E 3.0 x16 Link Speed ............................................................... 4-8

Slot 4 PCI-E 3.0 x8 Link Speed ................................................................. 4-8



DIMMConguration ................................................................................. 4-9

MemoryConguration ................................................................................ 4-9



DIMM Information .................................................................................... 4-9

Memory Mode ........................................................................................... 4-9

DRAM RAPL Mode .................................................................................... 4-9

DDR Speed ................................................................................................ 4-9

Channel Interleaving .................................................................................. 4-9

Rank Interleaving ....................................................................................... 4-9

Patrol Scrub ................................................................................................ 4-9

Demand Scrub ......................................................................................... 4-10

Data Scrambling ...................................................................................... 4-10

Device Tagging ........................................................................................ 4-10

Thermal Throttling .................................................................................... 4-10



SouthBridgeConguration ................................................................... 4-10

All USB Devices ....................................................................................... 4-10

EHCI Controller 1 / EHCI Controller 2 ..................................................... 4-10

Legacy USB Support ................................................................................ 4-10

Port 60/64 Emulation .................................................................................4-11

EHCI Hand-Off ..........................................................................................4-11



SATAConguration .....................................................................................4-11

SATA Port0~Port5 .....................................................................................4-11

SATA Mode ................................................................................................4-11

IDE Mode ..................................................................................................4-11

x

Table of Contents

Serial-ATA Controller 0~1 ..........................................................................4-11

AHCI Mode ................................................................................................4-11

Aggressive Link Power Management ........................................................4-11

Port 0~5 Hot Plug..................................................................................... 4-12

Staggered Spin Up ................................................................................... 4-12

RAID Mode ............................................................................................... 4-12

Port 0~5 Hot Plug..................................................................................... 4-12



SCUConguration ..................................................................................... 4-12

Disable Storage Controller Unit (SCU) .................................................... 4-12

OnChip SCU Option PROM ..................................................................... 4-12



PCIe/PCI/PnPConguration ..................................................................... 4-12

PCI ROM Priority ...................................................................................... 4-12

PCI Latency Timer .................................................................................... 4-12

Above 4G Decoding ................................................................................. 4-13

PERR# Generation ................................................................................... 4-13

SERR# Generation ................................................................................... 4-13

Maximum Payload .................................................................................... 4-13

Maximum Read Request .......................................................................... 4-13

ASPM Support .......................................................................................... 4-13

Slot 1 PCI-X 133/100MHZ OPROM
Slot 2 PCI-X 133/100MHZ OPROM
Slot 3 PCI X 133/100MHZ OPROM
Slot 4 PCI-E 3.0 x8 OPROM
Slot 5 PCI-E 3.0 x4 OPROM

Slot 6 PCI-E 3.0 x16 OPROM.................................................................. 4-13

Onboard LAN Option ROM Select ........................................................... 4-13

Load Onboard LAN1 Option ROM / Load Onboard LAN2 Option ROM . 4-13

Load Onboard SAS Option ROM ............................................................. 4-14

VGA Priority .............................................................................................. 4-14



SuperIODeviceConguration ................................................................. 4-14



SerialPort1Conguration/Serial Port2 Conguration ...................... 4-14

Serial Port 1 / Serial Port 2 ...................................................................... 4-14

Serial Port 1 Settings / Serial Port 2 Settings.......................................... 4-14



Serial Port Console Redirection ................................................................. 4-15



ACPI Settings ............................................................................................. 4-16

High Precision Event Timer ...................................................................... 4-16



ME Subsystem ........................................................................................... 4-16

xi

X9SRi/X9SRE Motherboard Series User’s Manual

4-4 Event Logs .................................................................................................... 4-17



Change SmBIOS Event Log Settings ........................................................ 4-17

Smbios Event Log .................................................................................... 4-17

Runtime Error Logging Support ............................................................... 4-17

Memory Correction Error Threshold ......................................................... 4-17

PCI Error Logging Support ....................................................................... 4-17

Erase Event Log ....................................................................................... 4-17

When Log is Full ...................................................................................... 4-17

Log System Boot Event ........................................................................... 4-18

MECI ......................................................................................................... 4-18

METW ....................................................................................................... 4-18

View SmBIOS Event Log ......................................................................... 4-18

4-5 IPMI (X9SRi-F, X9SRi-3F, X9SRE-F, X9SRE-3F Only) ................................ 4-19

System Event Log ................................................................................. 4-19

When SEL Full ......................................................................................... 4-19

Log EFI Status Codes .............................................................................. 4-19

BMCNetwork Conguration .................................................................. 4-19

UpdateIPMILANConguration ............................................................... 4-20

CongurationSource ................................................................................ 4-20

4-6 Boot Settings ................................................................................................. 4-21

Boot Options Priorities ............................................................................. 4-21

Boot Option #1, Boot option #2, etc......................................................... 4-21

Network Devices ...................................................................................... 4-21



Delete Boot Option ................................................................................ 4-21

4-8 Security Settings ........................................................................................... 4-22

Administrator Password .......................................................................... 4-22

User Password: ........................................................................................ 4-22

4-8 Save & Exit ................................................................................................... 4-23

Discard Changes and Exit ...................................................................... 4-23

Save Changes and Reset ........................................................................ 4-23

Save Changes .......................................................................................... 4-23

Discard Changes ...................................................................................... 4-23

Restore Optimized Defaults ..................................................................... 4-24

Save As User Defaults ............................................................................. 4-24

Restore User Defaults .............................................................................. 4-24

Boot Override ........................................................................................... 4-24

xii

Table of Contents

Appendix A

BIOS Error Beep Codes

A-1 BIOS Error Beep Codes .................................................................................A-1

Appendix B

Software Installation Instructions

B-1 Installing Software Programs ..........................................................................B-1

B-2 ConguringSuperDoctorIII ............................................................................B-2

Appendix C

UEFI BIOS Recovery Instructions

An Overview to the UEFI BIOS ..................................................................................C-1

How to Recover the UEFI BIOS Image (-the Main BIOS Block) ...............................C-1

To Recover the Main BIOS Block Using a USB-Attached Device .............................C-1

xiii

X9SRi/X9SRE Motherboard Series User’s Manual

Notes

xiv

Chapter 1: Introduction

Chapter 1

Introduction

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged

leader in the industry. Supermicro boards are designed with the utmost attention to

detail to provide you with the highest standards in quality and performance.

Please check that the following items have all been included with your motherboard.

If anything listed here is damaged or missing, contact your retailer.

The following items are included in the retail box.

•One (1) Supermicro Mainboard

•Six (6) SATA cables

•One (1) I/O shield

•One (1) Supermicro CD containing drivers and utilities

•One (1) User's Manual

Note: For your system to work properly, please follow the links below to

download all necessary drivers/utilities and the user's manual for your

motherboard.

•SMCI product manuals: http://www.supermicro.com/support/manuals/

•Product Drivers and utilities: ftp://ftp.supermicro.com/

Warning: For safety considerations, please refer to the complete list of

safety warnings posted on the Supermicro website at http://www.supermi-

cro.com/about/policies/safety_information.cfm.

If you have any questions, please contact our support team at support@supermicro.

com.

1-1

X9SRi/X9SRE Motherboard Series User’s Manual

X9SRE Motherboard Series Image

Note: All graphics shown in this manual were based upon the latest PCB

Revision available at the time of publishing of the manual. The motherboard

you've received may or may not look exactly the same as the graphics

shown in this manual.

1-2

Chapter 1: Introduction

X9SRi Motherboard Series Image

Note: All graphics shown in this manual were based upon the latest PCB

Revision available at the time of publishing of the manual. The motherboard

you've received may or may not look exactly the same as the graphics

shown in this manual.

1-3

X9SRi/X9SRE Motherboard Series User’s Manual

Motherboard Layout

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

USB4/5

JUSB45

2

7

10
+
2

USB6/7

1

JUSB67

7

1

2

USB8/9

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

SAS1/SAS3

SAS0/SAS2

4

41

FANA

PCIX2

1

JPG1

Connect to IPMI

1-2 Enable

2-3 Disable

JPG1: VGA

JIPMB1

JIPMB1

JI2C2

JI2C1

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

SLOT3 PCI-X 133/100MHZ

1

DESIGNED IN USA

X9SRi

REV:1.01

SAS5 SAS6

SAS7 I-SATA2I-SATA3

SAS4

JPBIOS_RCV1

JPME_RCV1

3

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

OFF: SLAVE

ON: MASTER

I-Button Header 1

I-SATA5

I-SATA5

JCF1:Compact Flash

PCIX3

3

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

1

3

JPB: BMC
1-2 Enable
2-3 Disable

FOR HOME OR OFFICE USE

ON:RECOVER BIOS
OFF:NORMAL

R625

JBT1

1

JWF1

JCF1

Tested to Comply

With FCC Standards

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

1

Power

Flash

Compact

U8

PCIE5

I-SATA3 I-SATA2

I-SATA4

I-SATA4

SLOT5 PCI-E 2.0 X4 (IN X16)

X_BT1

I-SATA0

I-SATA0

I-SATA1

I-SATA1

CHASSIS

INTRUSION

UID_SW

1

2

LAN1

JPL11JPL2

CLOSE 1st

JLAN2

LAN2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

P1-DIMM2B

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JVR2

1 3

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

FAN3

JF1

20

2

19

1

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable
2-3 Disable

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

OPEN 1st

12

JPW1

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN1

FAN2

A

C

JWD1

JL1

JD1

41

41

1

1

3

1

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

JPI2C1

PWRI2C

SP1

Available on the X9SRE series only.

Important Notes to the User

•See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front

panel connections.

•" " indicates the location of "Pin 1".

•Jumpers not indicated are for testing only.

1-4

Chapter 1: Introduction

X9SRi/X9SRE Motherboard Series Quick Reference

JLAN_USB12

USB0/1

P1-DIMM4A

P1-DIMM4B

12

JPW1

FAN1

FAN2

41

41

1

FAN1

JKBMS1JCOM1

1

JPUSB1

DIMM_C1

JTAG1

24

JPW2

JPW2

3

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

+

SP1

JCOM2

JPB1

JIPMB1

JTPM1

JUSB4/5

JOH1

JUSB6/7

JUSB8/9

3-SGPIO1
3-SGPIO2

JUSB2

SCU1
SCU0

SCU3
SCU2

FAN A

JSTBY1

COM2

JCOM2

6

1

9

5

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

4

41

FANA

JVGA

4

FAN3

JLAN1

JLAN2

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

LAN1

JPL2

2-3 Disable

JPL1

JLAN2

LAN2

FAN4

1

3

JVR1

CLOSE 1st

JF1

20

19

JVR2

1 3

JTAG1

JWD1:Watch Dog
1-2:RST
2-3:NMI

1

JWD1

OPEN 1st

JPW1

JD1:

PWR LED

1-3:

SPEAKER

4-7:

DP2

A

C

JWD1

JL1

JD1

1
3

7

JD1

FAN2

JL1

P1-DIMM2B

FAIL
PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JF1

2

FAN3

1

JF1

UID LED

JI2C1

DP3

PCIX1

JIPMB1

JIPMB1

JI2C1

SLOT1 PCI-X 133/100MHZ

1

SCU4

SAS4

SCU5

JPG1

Connect to IPMI

JI2C2

JOH1

SAS5 SAS6

JI2C2

PCIX2

1

JPG1

1-2 Enable

2-3 Disable

JPG1: VGA

SLOT2 PCI-X 133/100MHZ

SLOT3 PCI-X 133/100MHZ

DESIGNED IN USA

X9SRi

REV:1.01

JPME_RCV1

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

SCU6

SAS7 I-SATA2I-SATA3

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

1

3

3

R625

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

Compact

JWF1

1

3

JCF1

I-SATA5

I-SATA5

I-SATA3 I-SATA2

I-SATA4

I-SATA4

I-SATA 2.0

5 4 3 2

U8

PCIE5

OFF:DISABLE

ON: ENABLE

SLOT5 PCI-E 2.0 X4 (IN X16)

PCIE4

X_BT1

MAC CODE

JPBIOS1

JPME1
JSD1
JBT1

I-SATA0

I-SATA0

I-SATA1

I-SATA1

CHASSIS

INTRUSION

I-SATA 3.0

JI2C1/JI2C2

I2C Bus for PCI slot

SLOT6 PCI-E 3.0 X16

SAS CODE

1

A

C

UID_LED

UID

UID_SW

1

2

UID SW

PCIE6

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

T-SGPIO2 T-SGPIO1

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

0

DP3

MH1

JSTBY

3

JSTBY : Wake on Lan

USB4/5

JUSB45

USB6/7

JUSB67

USB8/9

SAS1/SAS3

SAS0/SAS2

SCU7

X9SRi/X9SRE Motherboard Series Jumpers

Jumper Description Default

JPB1 BMC Enable (for "F" models only) Pins 1-2 (Enabled)

JWD1 Watch Dog Reset Pins 1-2 (Reset)

JPUSB1 USB Power Select Pins 1-2 (Dual Power)

JPG1 Onboard VGA Enable Pins 1-2 (Enabled)

JSTBY1 Wake on LAN Enable Pins 1-3 (Enabled)

JI2C1/JI2C2 SMB to PCI-E Slots On (Enabled)

JPL1/JPL2 LAN1/LAN2 Enable Pins 1-2 (Enabled)

JPBIOS1 BIOS Recovery Pins 1-2 (Normal)

JPME1 Intel ME Mode Select Pins 1-2 (Normal)

JBT1 CMOS Clear See Chapter 2

KB/MOUSE

JKBMS1

JPUSB1

2-3 ENable
1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

JPW2

5

JPI2C1

1

JPI2C1

PWRI2C

X9SRi/X9SRE Motherboard Series LED Indicators

LED Description Color/State Status

DP3 IPMI Heartbeat Green/Blinking BMC/IPMI Normal

UID LED UID (Unit ID) LED Blue: Solid On UID: On

DP2 Power On LED Green: Solid On System is On

1-5

X9SRi/X9SRE Motherboard Series User’s Manual

X9SRi/X9SRE Motherboard Series Headers/Connectors

Connector Description

JCOM1, JCOM2 COM1 Backpanel Serial Port, COM2 Serial Port Header

JIPMB1 System Management Bus Header for the IPMI Slot

JTPM1 Trusted Platform Module (TPM) Header

JUSB 4/5, 6/7, 8/9 Front Accessible USB Connections (via 3 Headers)

JOH1 Overheat LED/Fan Fail

3-SGPIO1, 3-SGPIO2 Serial General Purpose I/O Headers for SAS

JUSB2 Internal Type A USB port

SCU0~7 Internal Serial-Attached SCSI (SAS) ports

FAN A, FAN 1~4 Internal Fan headers

I-SATA 0/1 SATA 3.0 ports (6Gb/s)

I-SATA 2~5 SATA 2.0 ports (3Gb/s)

T-SGPIO1, T-SGPIO2 Serial Link General Purpose I/O 1/2 Headers (5V Gen1/Gen 2)

JF1 Front Panel Control Header

JD1 Power LED / Speaker Header (Pins 4~7: External Speaker)

JL1 Chassis Intrusion Header

JPI2C1 Power Supply SMBus I2C Header

JPW2 8-pin Secondary Power Connector

JPW1 24-pin Main ATX Power Connector

JKBMS1 Backpanel Keyboard and Mouse Port

JLAN_USB12 IPMI LAN Port ("F" models only) / Backpanel USB 2.0 Port

JVGA Backpanel VGA Port

JLAN1, JLAN2 Backpanel Gbit LAN Ports 1, 2

UID_SW Unit ID Switch

JSD1 Disk On Module (DOM) Power

1-6

Chapter 1: Introduction

Motherboard Features

CPU Single Intel® E5-1600/E5-2600 series processor (LGA

2011 pin, Socket-R)

Memory Eight (8) DIMM slots support up to 256GB of DDR3, ECC

RDIMM memory or 64GB of DDR3 Unbuffered, non-ECC

UDIMM memory, up to 1600MHz..

Supports dual-channel memory bus

DIMM sizes

UDIMM 1GB, 2GB, 4GB, 8GB

RDIMM/LRDIMM 2GB, 4GB, 8GB, 16GB, 32GB

Chipset Intel® C606 or C602

Expansion Slots X9SRE Series Only (optimized for 3U/4U chassis)

Three (3) PCI-X 64-bit Slots

One (1) PCI-Express 3.0 x16 Slot

One (1) PCI-Express 3.0 x8 in x16 Slot

One (1) PCI-Express 2.0 x4 in x16 Slot

X9SRi Series Only (optimized for 1U/2U chassis)

One (1) PCI-Express 3.0 x16 Slot

One (1) PCI-Express 3.0 x8 in x16 Slot

One (1) PCI-Express 2.0 x4 in x16 Slot

Integrated Graphics Matrox® G200eW (on BMC controller)

Network Connections Two (2) Intel Powervill Gbit LAN Ports

I/O Devices SAS/SATA Connections

SAS Ports Eight (8)

3 Gb/s

(on "3F" models only) RAID 0, 1, 10, 5 (option)

SATA 3.0 Ports Two (2)

6 Gb/s RAID 0, 1, 5, 10

SATA 2.0 Ports Four (4)

3 Gb/s

Integrated IPMI 2.0 (X9SRi-F, X9SRi-3F, X9SRE-F, and
X9SRE-3F Only)

IPMI 2.0 supported by the WPCM450 Server BMC

USB Devices

Two (2) USB ports on the rear I/O panel

Six (6) USB headers for front access

One (1) Type A internal connectors

1-7

X9SRi/X9SRE Motherboard Series User’s Manual

Keyboard/Mouse

One (1) PS/2 KB/Mouse combo port on the I/O backpanel

Serial (COM) Ports

Two (2) Fast UART 16550 connections: one 9-pin RS-232
port (Backpanel COM1 port) and one header (COM2)

Super I/O

Winbond Super I/O NCT6776F

BIOS 64 Mb SPI AMI BIOS® SM Flash BIOS

Play and Plug APM 1.2, DMI 2.3, PCI 2.2, ACPI 1.0/2.0,
USB Keyboard and SMBIOS 2.3

Power Conguration ACPI/ACPM Power Management

Wake On LAN (WOL) Header

Keyboard Wake-up from Soft-Off

CPU Fan Auto-off in Sleep Mode

Power-on mode for AC power recovery

PC Health Monitoring CPU Monitoring

Onboard voltage monitors for CPU core, +3.3V, VDIMM,
CPU VTT, +5V, +3.3V Stdby, VBAT

CPU 6-phase switching voltage regulator

CPU/System overheat LED and control

CPU Thermal Trip support

CPU & Chassis Environment

Fan Control

Fan status monitoring with rmware 4-pin (Pulse Width

Modulation) fan speed control

Low noise fan speed control

System Management PECI (Platform Environment Conguration Interface) 2.0

CD Utilities BIOS ash upgrade utility

Other ROHS 6/6 (Full Compliance, Lead Free)

Dimensions ATX form factor (12" x 9.6")

support

System resource alert via Supero Doctor III

SuperDoctor® III, Watch Dog, NMI

Chassis Intrusion header and detection

Drivers and software for Intel® C204 chipset utilities

Note: For IPMI Conguration Instructions, please refer to the Embedded

IPMI Conguration User's Guide available @ http://www.supermicro.com/

support/manuals/.

1-8

Chapter 1: Introduction

X9SRi/X9SRE Motherboard Features Comparison

Model SAS SATA

(2.0/3.0)

X9SRi-3F 8 (3Gb/s) 4/2 Yes 2 1 1 1

X9SRE-3F 8 (3Gb/s) 4/2 Ye s 2 3 1 1 1

X9SRi-F No 4/2 Yes 2 1 1 1

X9SRE-F No 4/2 Yes 2 3 1 1 1

X9SRi No 4/2 No 2 1 1 1

X9SRE No 4/2 No 2 3 1 1 1

IPMI 1Gb

LAN

PCI-X

Slots

PCI-E

x16

PCI-E

x8 on x16

PCI-E

x4 on x16

1-9

X9SRi/X9SRE Motherboard Series User’s Manual

X9SRi/X9SRE Motherboard Series Block Diagram

SLOT 6

SLOT 4

SLOT 5

SLOT 1/2/3

FRONT PANEL

SYSTEM POWER

PCI-E X16

PCI-E X16

PCI-E X16

DEBUG

FAN SPEED

CTRL

PCI-X

PORT

PCI-E X16 G3

PCI-E X8 G3

PCI-E X4 G2

PCI-X

#0-5

#0-6

DDRIII

#0-8

#0-7

800/1066/1333

LAN#1/2

i350/x540

#4

#3

#2

#1

PCI-E X8 G3

PCI-E X4

#0

3.0 Gb/S

RJ45

RJ45

PXH

#7

#6

#5

SAS

VR12

6 PHASE

Intel® E5-1600/E52600 Series

Processor

8 SNB CORE
DDR-III
MAX 130W

#2 #3C/D #1B #1A

#3A/B

#1/2/3/4

PCH

#5/6/7/8

SPI

BIOS

COM1
Rear

PCI-E X4 G3

SIO

NCT6776F

PS/2
KB/MS

DMI2

DMI2 4GB/s

LPC

COM2
Header

3.0 Gb/S

6.0 Gb/S

USB 2.0

PCI

TPM

HEADER

#0-4

#0-3

#0-2

#0-1

DDRIII

800/1066/1333

#5

#4

#3

#2

SATA

#1

#0

SATA

#5

#4

#2

#9

#8

#7

#6

USB

VGA

BMC

WPCM450

#1

#0

#12
#13

DDR2

RMII

PHY

RJ45

Rev. 1.2

System Block Diagram

Note: This is a general block diagram and may not exactly represent

the features on your motherboard. See the Motherboard Features

pages for the actual specications of each motherboard.

1-10

Chapter 1: Introduction

1-2 Chipset Overview

The Intel® C600 series is a single chip solution that is designed for dedicated

servers and workstations. It supports high-speed SAS, SATA and advanced

requirements for Intel Xeon platforms.

Intel C600 Chipset Series Features

•Direct Media Interface (up 20 Gb/s each direction, Full Duplex)

•Intel® Matrix Storage Technology and Intel Rapid Storage Technology

•Intel I/O Virtualization (VT-d) Support

•Intel Trusted Execution Technology Support

•PCI Express 2.0 Interface (up to 5.0 GT/s)

•PCI Express 3.0 Interface (up to 8.0 GT/s)

•Eight SAS ports (up to 3 Gb/s)

•4 SATA 2.0 ports, 2 SATA 3.0 ports (up to 6 Gb/s)

•Advanced Host Controller Interface (AHCI)

1-11

X9SRi/X9SRE Motherboard Series User’s Manual

1-3 Special Features

Recovery from AC Power Loss

Basic I/O System (BIOS) provides a setting for you to determine how the system

will respond when AC power is lost and then restored to the system. You can

choose for the system to remain powered off (in which case you must press the

power switch to turn it back on), or for it to automatically return to a power-on state.

See the Advanced BIOS Setup section to change this setting. The default setting

is Last State.

1-4 PC Health Monitoring

This section describes the PC health monitoring features of the board. All have an

onboard System Hardware Monitoring chip that supports PC health monitoring. An

onboard voltage monitor will scan these onboard voltages continuously: CPU Vcore,

12V Scale, DIMM, 1.5V, 3.3V Vcc(V), Vcc5V, CPU VTT, 3.3VSB, and Battery Volt-

age. Once a voltage becomes unstable, a warning is given, or an error message

is sent to the screen. The user can adjust the voltage thresholds to dene the

sensitivity of the voltage monitor.

Fan Status Monitor with Firmware Control

PC health monitoring in the BIOS can check the RPM status of the cooling fans. The

onboard CPU and chassis fans are controlled by Thermal Management via BIOS

(under the Hardware Monitoring section in the Advanced Setting).

Environmental Temperature Control

The thermal control sensor monitors the CPU temperature in real time and will turn

on the thermal control fan whenever the CPU temperature exceeds a user-dened

threshold. The overheat circuitry runs independently from the CPU. Once the ther-

mal sensor detects that the CPU temperature is too high, it will automatically turn

on the thermal fans to prevent the CPU from overheating. The onboard chassis

thermal circuitry can monitor the overall system temperature and alert the user when

the chassis temperature is too high.

Note: To avoid possible system overheating, please be sure to provide

adequate airow to your system.

System Resource Alert

This feature is available when the system is used with Supero Doctor III in

1-12

Chapter 1: Introduction

the Windows OS environment or used with Supero Doctor II in Linux. Supero

Doctor is used to notify the user of certain system events. For example, you can

also congure Supero Doctor to provide you with warnings when the system

temperature, CPU temperatures, voltages and fan speeds go beyond predened

thresholds.

1-5 ACPI Features

ACPI stands for Advanced Conguration and Power Interface. The ACPI specica-

tion denes a exible and abstract hardware interface that provides a standard

way to integrate power management features throughout a PC system, including

its hardware, operating system and application software. This enables the system

to automatically turn on and off peripherals such as CD-ROMs, network cards, hard

disk drives and printers.

In addition to enabling operating system-directed power management, ACPI also

provides a generic system event mechanism for Plug and Play, and an operating

system-independent interface for conguration control. ACPI leverages the Plug and

Play BIOS data structures, while providing a processor architecture-independent

implementation that is compatible with Windows XP, Windows Vista and Windows

2008 Operating Systems.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start to blink

to indicate that the CPU is in suspend mode. When the user presses any key, the

CPU will "wake up", and the LED will automatically stop blinking and remain on.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and

reliable operation. It is even more important for processors that have high CPU

clock rates.

This motherboard accommodates 24-pin ATX power supplies. Although most

power supplies generally meet the specications required by the CPU, some are

inadequate. In addition, the 12V 8-pin power connector located at JPW2 is also

required to ensure adequate power supply to the system. Also your power supply

must supply 1.5A for the Ethernet ports.

Warning! 1. To prevent damage to the power supply or motherboard,

please use a power supply that contains a 24-pin and a 8-pin power con-

nectors. Be sure to connect these connectors to the 24-pin (JPW1) and the

1-13

X9SRi/X9SRE Motherboard Series User’s Manual

8-pin (JPW2) power connectors on the motherboard. Failure in doing so will

void the manufacturer warranty on your power supply and motherboard.

2. To provide adequate power to SATA devices, please connect the SATA

DOM PWR connector (JWF1) to the power supply.

It is strongly recommended that you use a high quality power supply that meets ATX

power supply Specication 2.02 or above. It must also be SSI compliant. (For more

information, please refer to the web site at http://www.ssiforum.org/). Additionally, in

areas where noisy power transmission is present, you may choose to install a line

lter to shield the computer from noise. It is recommended that you also install a

power surge protector to help avoid problems caused by power surges.

1-7 Super I/O

The Super I/O supports two high-speed, 16550 compatible serial communication

ports (UARTs). Each UART includes a 16-byte send/receive FIFO, a programmable

baud rate generator, complete modem control capability and a processor interrupt

system. Both UARTs provide legacy speed with baud rate of up to 115.2 Kbps

as well as an advanced speed with baud rates of 250 K, 500 K, or 1 Mb/s, which

support higher speed modems.

The Super I/O provides functions that comply with ACPI (Advanced Conguration

and Power Interface), which includes support of legacy and ACPI power manage-

ment through an SMI or SCI function pin. It also features auto power management

to reduce power consumption.

1-8 Overview of the Nuvoton WPCM450 Controller

The Nuvoton WPCM450R Controller is a Baseboard Management Controller (BMC)

that supports 2D/VGA-compatible Graphics cores, Virtual Media, and Keyboard/

Video/Mouse Redirection (KVMR) modules. With blade-oriented Super I/O capabil-

ity built in, the WPCM450R Controller is ideal for legacy-reduced server platforms.

The WPCM450R interfaces with a host system via PCI interface to communicate

with the Graphics core. It supports USB 2.0 and 1.1 for remote keyboard/mouse/

virtual media emulation. It also provides LPC interface to control Super IO functions.

The WPCM450R is connected to the network via an external Ethernet PHY module.

The WPCM450R communicates with onboard components via six SMBus inter-

faces, fan control, and Platform Environment Control Interface (PECI) buses.

Note: For more information on IPMI conguration, please refer to the

Embedded IPMI User's Guide posted on our Website @ http://www.su-

permicro.com/support/manuals/.

1-14

Chapter 2: Installation

Chapter 2

Installation

2-1 Static-Sensitive Devices

Electrostatic-Discharge (ESD) can damage electronic com ponents. To avoid dam-

aging your system board, it is important to handle it very carefully. The following

measures are generally sufcient to protect your equipment from ESD.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing the board from the antistatic

bag.

• Handle the board by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the motherboard and peripherals back into their antistatic bags when not in

use.

• For grounding purposes, make sure your computer chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

• Use only the correct type of onboard CMOS battery. Do not install the onboard

battery upside down to avoid possible explosion.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static damage. When

unpacking the board, make sure that the person handling it is static protected.

2-1

X9SRi/X9SRE Motherboard Series User’s Manual

2-2 Processor and Heatsink Installation

Warning: When handling the processor package, avoid placing direct

pressure on the label area.

Important:

Always connect the power cord last, and always remove it before adding,

removing or changing any hardware components. Make sure that you in-

stall the processor into the CPU socket before you install the CPU heatsink.

If you buy a CPU separately, make sure that you use an Intel-certied

multi-directional heatsink only.

Make sure to install the system board into the chassis before you install

the CPU heatsink.

When receiving a server board without a processor pre-installed, make

sure that the plastic CPU socket cap is in place and none of the socket

pins are bent; otherwise, contact your retailer immediately.

Refer to the Supermicro website for updates on CPU support.

Opening the LGA2011 Socket

1. There are two load levers on the LGA2011 socket. To open the socket cover,

rst press and release the load lever labeled 'Open 1st'.

WARNING!

OPEN 1st

1

Press down on

Lever 'Open 1st'

2-2

WARNING!

OPEN 1st

2

Load

Chapter 2: Installation

2. Press the second load lever labeled 'Close 1st' to release the load plate

which covers the CPU socket from its locking position.

Press down on

1

OPEN 1st

3. With the 'Close 1st' lever fully retracted, gently push down on the 'Open 1st'

lever to open the load plate. Lift the load plate to open it completely.

Lever 'Close 1st'

WARNING!

Load

Pull lever away from

2

the socket

WARNING!

OPEN 1st

WARNING!

OPEN 1st

1

Gently push down to pop

the load plate open

2

WARNING!

2-3

X9SRi/X9SRE Motherboard Series User’s Manual

Installing the LGA2011 Processor

WARNING!

1. With the LGA 2011 socket open, remove the 'WARNING' plastic cap using

your ngers.

Socket Keys

2. Use your thumb and index nger to hold the CPU on its edges. Align the CPU

keys (semi-circle cutouts) against the socket keys.

CPU Keys

Warning: You can only in-

stall the CPU inside the

socket in one direction.

Make sure that it is properly

inserted into the CPU socket

before closing the load plate.

If it doesn't close properly,

do not force it as it may

damage your CPU. Instead,

open the load plate again

and double-check that the

CPU is aligned properly.

2-4

Chapter 2: Installation

3. Once it is aligned, carefully lower the CPU straight down into the socket. (Do

not drop the CPU on the socket. Do not move the CPU horizontally or verti-

cally.

4. Do not rub the CPU against the surface or against any pins of the socket to

avoid damaging the CPU or the socket.)

5. With the CPU inside the socket, inspect the four corners of the CPU to make

sure that the CPU is properly installed.

6. To close and lock the socket, close the load plate with the CPU. Lock the

'Close 1st' lever rst, then lock the 'Open 1st' lever second. Use your thumb

to gently push the load levers down to the lever locks.

Push down and lock

'Close 1st' lever

2

Gently close

the load plate

1

Lever Lock

Push down and lock

'Open 1st' lever

OPEN 1st

3

OPEN 1st

4

OPEN 1st

Lever Lock

2-5

X9SRi/X9SRE Motherboard Series User’s Manual

Installing a Passive CPU Heatsink

1. Do not apply any thermal grease to the heatsink or the CPU die -- the re-

quired amount has already been applied.

2. Place the heatsink on top of the CPU so that the four mounting holes are

aligned with those on the Motherboard's and the Heatsink Bracket under-

neath.

3. Screw in two diagonal screws (i.e., the #1 and the #2 screws) until just snug

(-do not over-tighten the screws to avoid possible damage to the CPU.)

4. Finish the installation by fully tightening all four screws.

Screw#1

Motherboard

Screw#2

OPEN 1st

Mounting Holes

2-6

Chapter 2: Installation

Removing the Heatsink

Warning: We do not recommend that the CPU or the heatsink be removed.

However, if you do need to uninstall the heatsink, please follow the instruc-

tions below to uninstall the heatsink to prevent damage done to the CPU

or the CPU socket.

1. Unscrew the heatsink screws from the motherboard in the sequence as shown

in the illustration below.

2. Gently wriggle the heatsink to loosen it from the CPU. (Do not use excessive

force when wriggling the heatsink!!)

3. Once the heatsink is loosened, remove the heatsink from the CPU socket.

4. Clean the surface of the CPU and the heatsink, removing the used thermal

grease. Re-apply the proper amount of thermal grease on the surface before

re-installing the CPU and the heatsink.

Loosen screws in
sequence as shown.

Screw#1

Motherboard

Screw#4

Screw#2

Screw#3

2-7

X9SRi/X9SRE Motherboard Series User’s Manual

2-3 Installing DDR3 Memory

Note: Check the Supermicro website for recommended memory modules.

CAUTION

Exercise extreme care when installing or removing DIMM

modules to prevent any possible damage.

DIMM Installation

1. Insert the desired number of DIMMs

into the memory slots, starting with

DIMMA1 (see the next page for the

location). For best performance,

please use the memory modules

of the same type and speed in the

same bank.

2. Push the release tabs outwards

on both ends of the DIMM slot to

unlock it.

3. Align the key of the DIMM mod-

ule with the receptive point on the

memory slot.

4. Align the notches on both ends of

the module against the receptive

points on the ends of the slot.

5. Use two thumbs together to press

the notches on both ends of the

module straight down into the slot

until the module snaps into place.

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JPB1

3

TPM/PORT80

JTPM1

20

2

7

1

7

1

7

2

8

2

8

JPB: BMC
1-2 Enable

JSTBY : Wake on Lan

PCIX1

2-3 Disable

PCIX3

1

PCIX2

1

JPG1

Connect to IPMI

1-2 Enable

2-3 Disable

JPG1: VGA

JIPMB1

JIPMB1

19

1

2

10
+
2

2

10

JUSB89

1

3-SGPIO1

7

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

USB2

With FCC Standards

FOR HOME OR OFFICE USE

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

SLOT3 PCI-X 133/100MHZ

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

X9SRi

REV:1.01

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

3

JPME_RCV1

JUSB2

3

R625

SAS1/SAS3
SAS0/SAS2

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

4

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS5 SAS6

SAS7 I-SATA2I-SATA3

SAS4

41

FANA

UID_SW

1

2

JLAN2

U8

Tested to Comply

PCIE5

SLOT4 PCI-E 3.0 X8 (IN X16)

SLOT5 PCI-E 2.0 X4 (IN X16)

X_BT1

MH5

1

Flash

Compact

I-SATA1

I-SATA1

I-SATA3 I-SATA2

CHASSIS

INTRUSION

I-SATA4

I-SATA4

LAN2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

P1-DIMM2B

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

2

4

FAN3

1

VGA

JVGA

41

FAN4

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

2-3 Disable

LAN1

1

3

JVR1

CLOSE 1st

OPEN 1st

JF1

FAIL
PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

JF1

A

20

C

1

19

1

3

KB/MOUSE

JCOM1

COM1

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable
1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM4A

P1-DIMM4B

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

JPI2C1

FAN1

FAN2

PWRI2C

JWD1

JL1

JD1

41

41

1

SP1

7

Notches

6. Press the release tabs to the lock

positions to secure the DIMM module

into the slot.

Removing Memory Modules

Reverse the steps above to remove the

DIMM modules from the motherboard.

2-8

Release Tabs

Press both notches

straight down into

the memory slot.

Chapter 2: Installation

Memory Support

The X9SRi/X9SRE motherboard series supports up to 256GB of

1600/1066/1333/1600 MHz ECC/Non-ECC DDR3 DIMMs in eight (8) memory

slots (UDIMM/RDIMM). Populating these DIMM modules with a pair of memory

modules of the same type and same size will result in interleaved memory, which

will improve memory performance. Please refer to the table below:

Edge of the motherboard

DIMMC1 (Blue Slot)

DIMMC2

DIMMD1 (Blue Slot)

DIMMD2

CLOSE 1st

OPEN 1st

DIMMB2

DIMMB1 (Blue Slot)

DIMMA2
DIMMA1 (Blue Slot)

JKBMS1

JPUSB1:USB Wake Up

KB/MOUSE

1-2 Disable
2-3 ENable

JPUSB1

1

USB0/1

P1-DIMM4A
P1-DIMM4B

COM1

JCOM1

VGA

JVR1

41

3

FAN4

FAN4

1

JVGA

JPL1/2: LAN

2-3 Disable

1-2 Enable

1

JPL1

JPL2

UID

UID_SW

1

UID_LED

A

C

2

DP3

MH1

JCOM2

COM2

CLOSE 1st

LAN1

JLAN2

LAN2

PCIE6

JI2C1/JI2C2
I2C Bus for PCI slot

ON: ENABLE
OFF:DISABLE

U8

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

2-3 Disable

JPB: BMC

1-2 Enable

PCIX3

JPG1: VGA
1-2 Enable

1

2-3 Disable

JPG1

PCIX2

Connect to IPMI

JI2C2

JI2C1
JIPMB1

JIPMB1

PCIX1

JSTBY : Wake on Lan

JSTBY

3

6

9

19

1

20

5

3

1

JTPM1

JPB1

TPM/PORT80

5

JPI2C1

P1-DIMM3A
P1-DIMM3B

OPEN 1st

P1-DIMM2B

P1-DIMM2A
P1-DIMM1B
P1-DIMM1A

SLOT6 PCI-E 3.0 X16

PCIE4

SLOT5 PCI-E 2.0 X4 (IN X16)

PCIE5

SLOT4 PCI-E 3.0 X8 (IN X16)

USB4/5

1

2

MAC CODE

SAS CODE

MAC CODE

X_BT1

MH5

OFF:NORMAL

ON:RECOVER BIOS

SLOT3 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

SLOT1 PCI-X 133/100MHZ

JUSB45

2

JPBIOS_RCV1

X9SRi

REV:1.01

DESIGNED IN USA

1

USB6/7

USB8/9

JUSB67

USB2

JUSB89

3-SGPIO2

3-SGPIO1

3-SGPIO23-SGPIO1
1

2

10

+

10

1

2

7

7

7

1

1

278

278

PWRI2C

1

JPW2

JVR6

JVR4

JVR313

JVR5

JPW2

DIMM_C1

3

3

+

3

JTAG1

1

1

SP1

24

1

12

JPW1

41

FAN1

41

FAN2

JL1
JD1
JWD1

7

A

PWR LED

SPEAKER

C

1-3:

4-7:

JD1:

1
3

1

2-3:NMI

JWD1:Watch Dog

1-2:RST

JVR2

1 3

19

20

JF1

JF1

NMI
X
PWR
LED
HDD
NIC
1
NIC
2
OH
FF
PWR
FAIL
RST
PWR
ON

1

2

FAN3

4

1

MH7

T-SGPIO1
T-SGPIO2

7

8
2

1

7

8

2

I-SATA0

I-SATA0

I-SATA1

I-SATA1

CHASSIS

INTRUSION

I-SATA4

I-SATA4

I-SATA3 I-SATA2

1

Compact
Flash
Power

JWF1

1

R625

JCF1

JBT1

1

3

JRK1

Pin3:PCH_DYN_SKU

Pin2:Ground

Pin1:RAID_KEY_PCH

3

JCF1:Compact Flash

I-Button Header 1

ON: MASTER

3

OFF: SLAVE

I-SATA5

I-SATA5

JPME_RCV1

ON:ME IN FORCE UPDATA MODE

OFF:NORMAL

SAS7 I-SATA2I-SATA3

SAS5 SAS6

SAS4

SAS1/SAS3
SAS0/SAS2

JUSB2

FANA

4

41

2-9

X9SRi/X9SRE Motherboard Series User’s Manual

Memory Population Guidelines

When installing memory modules, the DIMM slots should be populated in the follow-

ing order: DIMMA1, DIMMB1, DIMMC1, DIMMD1 then DIMMA2, DIMMB2, DIMMC2,

DIMMD2.

• Always use DDR3 DIMM modules of the same size, type and speed.

• Mixed DIMM speeds can be installed. However, all DIMMs will run at the speed

of the slowest DIMM.

• The motherboard will support 1 ,3 ,5 ,or 7 modules. However, for best memory

performance, install DIMM modules in pairs (2, 4, 6, 8, as below).

Recommended Population (Balanced)

DIMMA1 DIMMB1 DIMMC1 DIMMD1 DIMMA2 DIMMB2 DIMMC2 DIMMD2 Total

2GB 2GB 4GB

2GB 2GB 2GB 2GB 8GB

2GB 2GB 2GB 2GB 2GB 2GB 12GB

2GB 2GB 2GB 2GB 2GB 2GB 2GB 2GB 16GB

4GB 4GB 8GB

4GB 4GB 4GB 4GB 16GB

4GB 4GB 4GB 4GB 4GB 4GB 24GB

4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 32GB

8GB 8GB 16GB

8GB 8GB 8GB 8GB 32GB

8GB 8GB 8GB 8GB 8GB 8GB 48GB

8GB 8GB 8GB 8GB 8GB 8GB 8GB 8GB 64GB

16GB 16GB 32GB

16GB 16GB 16GB 16GB 64GB

16GB 16GB 16GB 16GB 16GB 16GB 96GB

16GB 16GB 16GB 16GB 16GB 16GB 16GB 16GB 128GB

32GB 32GB 64GB

32GB 32GB 32GB 32GB 128GB

32GB 32GB 32GB 32GB 32GB 32GB 192GB

32GB 32GB 32GB 32GB 32GB 32GB 32GB 32GB 256GB

System
Memory

Note: Up to 256GB of memory are supported using ECC QR (Quad

Rank or 4-Rank) registered DIMM technology at 1600/1333/1066/800

MHz. Up to 64GB of memory are supported using non-ECC

UDIMMs.

2-10

Chapter 2: Installation

2-4 Motherboard Installation

All motherboards have standard mounting holes to t different types of chassis.

Make sure that the locations of all the mounting holes for both motherboard and

chassis match. Although a chassis may have both plastic and metal mounting fas-

teners, metal ones are highly recommended because they ground the motherboard

to the chassis. Make sure that the metal standoffs click in or are screwed in tightly.

Then use a screwdriver to secure the motherboard onto the motherboard tray.

Tools Needed

Philips Screwdriver

Location of Mounting Holes

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

USB4/5

JUSB45

2

7

10
+
2

USB6/7

1

JUSB67

7

1

2

USB8/9

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

SAS1/SAS3

SAS0/SAS2

4

41

FANA

SAS4

JIPMB1

JIPMB1

JI2C1

SLOT1 PCI-X 133/100MHZ

1

Connect to IPMI

JI2C2

JOH1

SAS5 SAS6

PCIX2

1

JPG1

1-2 Enable

2-3 Disable

JPG1: VGA

SLOT2 PCI-X 133/100MHZ

SLOT3 PCI-X 133/100MHZ

DESIGNED IN USA

X9SRi

REV:1.01

SAS7 I-SATA2I-SATA3

Caution: 1) To prevent damage to the motherboard and its components,

please do not use a force greater than 8 lb/inch on each mounting screw

during motherboard installation. 2) Some components are very close to the

mounting holes. Please take precautionary measures to avoid damaging

these components when installing the motherboard to the chassis.

JPBIOS_RCV1

JPME_RCV1

3

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

OFF: SLAVE

ON: MASTER

I-Button Header 1

I-SATA5

I-SATA5

U8

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

PCIE5

SLOT4 PCI-E 3.0 X8 (IN X16)

SLOT5 PCI-E 2.0 X4 (IN X16)

X_BT1

MH5

ON:RECOVER BIOS
OFF:NORMAL

1

3

R625

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

JCF1:Compact Flash

JBT1

1

Power

Flash

Compact

JWF1

1
3

JCF1

I-SATA3 I-SATA2

I-SATA4

I-SATA4

I-SATA0

I-SATA0

I-SATA1

I-SATA1

CHASSIS

INTRUSION

Philips Screws

A

C

UID_LED

UID

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

1

2

2

T-SGPIO1

T-SGPIO2

8

8

7

7

Standoffs

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

JLAN2

LAN2

2-3 Disable

LAN1

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

CLOSE 1st

P1-DIMM2B

JF1

FAIL
PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

1

MH7

4

FAN3

JF1

20

2

19

1

OPEN 1st

12

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:

1-2:RST

2-3:NMI

A

C

1

1

3

JPW1

FAN1

FAN2

JWD1

JL1

JD1

41

41

1

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

JPW2

JPW2

3

5

JVR6

JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

JPI2C1

PWRI2C

SP1

2-11

X9SRi/X9SRE Motherboard Series User’s Manual

Installing the Motherboard

1. Install the I/O shield into the chassis.

2. Locate the mounting holes on the motherboard.

3. Locate the matching mounting holes on the chassis. Align the mounting holes

on the motherboard against the mounting holes on the chassis.

4. Install standoffs in the chassis as needed.

5. Install the motherboard into the chassis carefully to avoid damaging mother-

board components.

6. Using the Philips screwdriver, insert a Pan head #6 screw into a mounting

hole on the motherboard and its matching mounting hole on the chassis.

7. Repeat Step 5 to insert #6 screws into all mounting holes.

8. Make sure that the motherboard is securely placed in the chassis.

Note: Images displayed are is for illustration only. Your chassis or compo-

nents might look different from those shown in this manual.

2-12

Chapter 2: Installation

2-5 Connectors/IO Ports

The I/O ports are color coded in conformance with the PC 99 specication. See the

gure below for the colors and locations of the various I/O ports.

Motherboard I/O Backpanel

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

4

41

PCIX2

JPG1

Connect to IPMI

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

REV:1.01

JUSB2

SAS1/SAS3

SAS0/SAS2

SAS5 SAS6

SAS4

FANA

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

2-3 Disable

JPG1: VGA

FOR HOME OR OFFICE USE

SLOT3 PCI-X 133/100MHZ

X9SRi

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

Tested to Comply

With FCC Standards

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

1

Power

Flash
Compact

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

2

UID_SW

1

2

JLAN2

LAN2

LAN1

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

CHASSIS

T-SGPIO1

T-SGPIO2

INTRUSION

1

8

8

7

7

MH7

4

FAN3

CLOSE 1st

P1-DIMM2B

JF1

FAIL
PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

1 3

JF1

20

2

19

1

5

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

2-3 Disable

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

OPEN 1st

JVR2

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN2

A

C

JWD1

JL1

JD1

41

1

1

3

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable
JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

JPI2C1

FAN1

PWRI2C

41

1

SP1

1

4

6

3

Motherboard I/O Backpanel

1. Keyboard (Purple) 7. VGA

2. PS/2 Mouse (Green) 8. LAN1

3. USB Port 0 9. LAN2

4. USB Port 1

5. IPMI LAN (X9SRi-3F/X9SRE-3F only)

6. COM1

2-13

7 8 9

X9SRi/X9SRE Motherboard Series User’s Manual

ATX PS/2 Keyboard/Mouse

Ports

The ATX PS/2 keyboard and

PS/2 mouse are located next to

the Back Panel USB Ports 0/1 on

the motherboard. See the table at

right for pin denitions.

Mouse

PS/2 Keyboard/Mouse Pin

Denitions

PS2 Keyboard PS2 Mouse

Pin# Denition Pin# Denition

1 KBDAT_R 7 MSDAT_R

2 No Connection 8 No Connection

3 Ground 9 Ground

4 P5V_DUAL 10 P5V_DUAL

5 KBCLK_R 11 MSCLK_R

6 No Connection 12 No Connection

13 Ground 17 Ground

14 Ground

15 Ground

16 Ground

1. Keyboard (Purple)

2. Mouse (Green)

Keyboard

2-14

Chapter 2: Installation

4

3

5

1

2

6

Universal Serial Bus (USB)

Two Universal Serial Bus ports (USB

0/1) are located on the I/O back panel.

In addition, six USB headers (USB

4/5, USB 6/7, USB 8/9) are used to

provide front chassis access. There

is also one Type A internal USB port

located on USB 2. (USB Cables are

not included). See the tables on the

right for pin denitions.

1. Backpanel USB 0

2. Backpanel USB 1

3. Front Panel USB 4/5

4. Front Panel USB 6/7

5. Front Panel USB 8/9

6. Type A USB 2

Back Panel USB Ports

Pin Denitions

Pin# Denition Pin# Denition

1 +5V 5 +5V

2 USB_PN0 6 USB_PN1

3 USB_PP0 7 USB_PP1

4 Ground 8 Ground

Front Panel USB Headers

Pin Denitions

Pin# Denition Pin# Denition

1 +5V 6 USB_PP5

2 +5V 7 Ground

3 USB_PN4 8 Ground

4 USB_PN5 9 Key

5 USB_PP4 10 No Connection

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

PCIX2

JPG1

Connect to IPMI

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

JUSB2

SAS1/SAS3

SAS0/SAS2

4

SAS5 SAS6

SAS4

41

FANA

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

2-3 Disable

JPG1: VGA

FOR HOME OR OFFICE USE

SLOT3 PCI-X 133/100MHZ

X9SRi

REV:1.01

JPBIOS_RCV1

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

Tested to Comply

With FCC Standards

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

ON:RECOVER BIOS
OFF:NORMAL

1

Power

Flash

Compact

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

UID_SW

1

2

JLAN2

LAN2

LAN1

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

CHASSIS

T-SGPIO1

T-SGPIO2

INTRUSION

1

8

8

7

7

MH7

4

FAN3

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JVR2

1 3

JF1

20

2

19

1

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

2-3 Disable

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

OPEN 1st

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN2

A

C

JWD1

JL1

JD1

41

1

1

3

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

JPI2C1

FAN1

PWRI2C

41

1

SP1

2-15

X9SRi/X9SRE Motherboard Series User’s Manual

1

2

3

Ethernet Ports

Two Ethernet ports (LAN1/LAN2) are

located next to the VGA port on the

I/O Backpanel. In addition, an IPMI

Dedicated LAN port is also located

above USB 0/1 to provide a dedicated

network connection for IPMI 2.0 on

the X9SRi-3F and X9SRE-3F moth-

erboard.

LAN Ports

Pin Denition

Pin# Denition Pin# Denition

1 TRCT2 13 IETCT

2 TRD2+ 14 IET+

3 TRD2- 15 IET-

4 TRD3+

5 TRD3- 17 L1-COMMON

6 TRCT3 18 L1-GRE-

7 TRCT1 19 L2-YEL

8 TRD1+ 20 L2-COMMON

9 TRD1- 21 L2-GRE-

10 TRD4+ 22 CG1

11 TRD4- 23 CG2

12 TRCT4 24

(NC: No Connection)

1. LAN1

2. LAN2

3.IPMI Dedicated LAN

2-16

Chapter 2: Installation

1

2

Serial Ports

A COM Port (COM1) is located on

the I/O bac kpan el, and anoth er Ser ial

header (COM2) is located towards

the rear of Slot 1 to provide front se-

rial access. See the table on the right

for pin denitions.

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

41

PCIX2

JPG1

Connect to IPMI

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

JUSB2

SAS1/SAS3

SAS0/SAS2

4

SAS5 SAS6

SAS4

FANA

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

2-3 Disable

JPG1: VGA

SLOT3 PCI-X 133/100MHZ

X9SRi

REV:1.01

JPBIOS_RCV1

3

JPME_RCV1

3

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

I-Button Header 1

1

3

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

With FCC Standards

FOR HOME OR OFFICE USE

ON:RECOVER BIOS
OFF:NORMAL

R625

JBT1

1

Power

JWF1

JCF1

Tested to Comply

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

1

Flash

Compact

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

X_BT1

I-SATA1

I-SATA1

CHASSIS

INTRUSION

OFF:DISABLE

ON: ENABLE

PCIE4

MAC CODE

I-SATA0

I-SATA0

Serial Port Pin Denitions

(COM1/COM2)

Pin # Denition Pin # Denition

1 DCD 6 DSR

2 RXD 7 RTS

3 TXD 8 CTS

4 DTR 9 RI

5 Ground 10 Ground

1. COM1

2. COM2

A

C

UID_LED

UID

UID_SW

1

2

JLAN2

LAN2

LAN1

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

SLOT6 PCI-E 3.0 X16

SAS CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

FAN3

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JVR2

1 3

JF1

20

2

19

1

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

2-3 Disable

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

OPEN 1st

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN2

A

C

JWD1

JL1

JD1

41

1

1

3

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

JPI2C1

FAN1

PWRI2C

41

1

SP1

2-17

X9SRi/X9SRE Motherboard Series User’s Manual

1

Video Port

A Video (VGA) port is located next to

the COM Port on the I/O backpanel.

This port is used to provide a connec-

tion for video and graphics display.

Refer to the board layout below for

the location.

VGA Pin

Denitions

Pin# Denition Pin# Denition

1 Red 10 Ground

2 Green 11 NC

3 Blue 12 MS1: SDA (DDC Data)

4 NC 13 HSYNC

5 Ground 14 VSYSNC

6 Ground 15 MS3: SCL (DDC CLK)

7 Ground 16 Case

8 Ground 17 Case

9 5V

NC= No Connection

1. VGA

2-18

Chapter 2: Installation

1

2

Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally lo-

cated on a control panel at the front of the chassis. These connectors are designed

specically for use with Supermicro server chassis. See the gure below for the

descriptions of the various control panel buttons and LED indicators. Refer to the

following section for descriptions and pin denitions.

1920

Ground

X

Power LED

NMI

X

Vcc

Pin 19Pin 20

OH/Fan Fail LED

Power Fail LED

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

Connect to IPMI

TPM/PORT80

JTPM1

JIPMB1

JIPMB1

20

19

JI2C2

JI2C1

1

2

USB4/5

JUSB45

2

SLOT1 PCI-X 133/100MHZ

JOH1

7

10
+

1

2

USB6/7

1

JUSB67

7

1

2

USB8/9

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

SAS1/SAS3

SAS0/SAS2

4

SAS5 SAS6

SAS4

41

FANA

HDD LED

NIC1 LED

NIC2 LED

PCIX3

PCIX2

1

JPG1

1-2 Enable

2-3 Disable

JPG1: VGA

SLOT2 PCI-X 133/100MHZ

SLOT3 PCI-X 133/100MHZ

DESIGNED IN USA

X9SRi

REV:1.01

JPBIOS_RCV1

3

JPME_RCV1

3

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

I-Button Header 1

3

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

JPB: BMC
1-2 Enable
2-3 Disable

1

FOR HOME OR OFFICE USE

R625

JBT1

1

JWF1

JCF1

Tested to Comply

With FCC Standards

MH5

ON:RECOVER BIOS
OFF:NORMAL

1

Power

Flash

Compact

SLOT4 PCI-E 3.0 X8 (IN X16)

Ground

Ground

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

I-SATA3 I-SATA2

CHASSIS

INTRUSION

I-SATA4

I-SATA4

Vcc/UID Switch

Vcc

Vcc

Vcc/Blue UID LED

Vcc

#3~4

#1~2

Pin 2

Reset Button

Power Button

Pin 1

JF1 Header Pins

A

C

UID_LED

UID

UID_SW

1

2

JLAN2

LAN2

LAN1

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JVR2

1 3

JF1

20

2

FAN3

19

1

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

2-3 Disable

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

OPEN 1st

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN2

A

C

JWD1

JL1

JD1

41

1

1

3

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable
1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

FAN1

JPI2C1

PWRI2C

41

1

SP1

2-19

X9SRi/X9SRE Motherboard Series User’s Manual

1

2

Front Control Panel Pin Denitions

Power LED

The Power LED connection is located

on pins 15 and 16 of JF1. Refer to the

table on the right for pin denitions.

HDD LED

The HDD LED connection is located

on pins 13 and 14 of JF1. Attach a

cable here to indicate the status of

HDD-related activities, including IDE,

SATA activities. See the table on the

right for pin denitions.

Power Fail LED

The Power Fail LED connection is

located on pins 5 and 6 of JF1. Refer

to the table on the right for pin deni-

tions.

Ground

X

Power LED

Pin Denitions (JF1)

Pin# Denition

15 +3.3V

16 Ground

HDD LED

Pin Denitions (JF1)

Pin# Denition

13 +3.3V

14 HD Active

PWR Fail LED

Pin Denitions (JF1)

Pin# Denition

5 Vcc

6 Ground

A. PWR LED

B. HDD LED

1920

NMI

X

C. PWR Fail LED

A

Power LED

B

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

C

Power Fail LED

Ground

Ground

#3~4

2-20

Vcc

Vcc/UID Switch

Vcc

Vcc

Vcc/Blue UID LED

Vcc

Reset Button

Power Button

#1~2

Chapter 2: Installation

1

2

NIC1/NIC2 (LAN1/LAN2)

The NIC (Network Interface Controller)

LED connection for LAN port 1 is located

on pins 11 and 12 of JF1, and the LED

connection for LAN Port 2 is on Pins 9

and 10. NIC1 LED and NIC2 LED are

2-pin NIC LED headers. Attach NIC LED

cables to NIC1 and NIC2 LED indicators

to display network activities. Refer to the

table on the right for pin denitions.

Overheat (OH)/Fan Fail / UID LED

Connect an LED cable to the OH/Fan

Fail connections on pins 7 and 8 of JF1

to display signals or to provide advanced

warnings for chassis overheat/fan failure.

Refer to the table on the right for pin de

nitions. The UID LED is used togther with

the UID Switch (see 2-32).

1920

Ground

X

NMI

X

LAN1/LAN2 LED

Pin Denitions (JF1)

Pin# Denition

9/11 Vcc

10/12 LAN Active

OH/Fan Fail LED

Pin Denitions (JF1)

Pin# Denition

7 Vcc/Blue UID LED

8 OH/Fan Fail LED

OH/Fan Fail Indicator

Status

State Denition

Off Normal

On Overheat

Flash-

Fan Fail

ing

A. NIC1 LED

B. NIC2 LED

C. OH/Fan Fail / UID LED

B

C

OH/Fan Fail LED

Power Fail LED

Power LED

HDD LED

A

NIC1 LED

NIC2 LED

Ground

Ground

2-21

Vcc

Vcc/UID Switch

Vcc

Vcc

Vcc/Blue UID LED

Vcc

#3~4

Reset Button

Power Button

#1~2

X9SRi/X9SRE Motherboard Series User’s Manual

1

2

NMI Button

The non-maskable interrupt button

header is located on pins 19 and 20

of JF1. Refer to the table on the right

for pin denitions.

Reset Button

The Reset Button connection is located

on pins 3 and 4 of JF1. Attach it to a

hardware reset switch on the computer

case to reset the system. Refer to the

table on the right for pin denitions.

Power Button

The Power Button connection is located

on pins1 and 2 of JF1. Momentarily con-

tacting both pins will power on/off the sys-

tem. This button can also be congured

to function as a suspend button (with a

setting in the BIOS - see Chapter 4). To

turn off the power in the suspend mode,

press the button for at least 4 seconds.

Refer to the table on the right for pin

denitions.

NMI Button

Pin Denitions (JF1)

Pin# Denition

19 Control

20 Ground

Reset Button

Pin Denitions (JF1)

Pin# Denition

3 Reset

4 Ground

Power Button

Pin Denitions (JF1)

Pin# Denition

1 Signal

2 Ground

A. NMI Button

B. Reset Button

C. PWR Button

Ground

Power LED

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

Power Fail LED

X

Ground

Ground

1920

#3~4

#1~2

2-22

A

NMI

X

Vcc

Vcc/UID Switch

Vcc

Vcc

Vcc/Blue UID LED

Vcc

Reset Button

Power Button

B

C

Chapter 2: Installation

2-6 Connecting Cables & Optional Devices

This section provides brief descriptions and pin-out denitions for onboard headers

and connectors. Be sure to use the correct cable for each header or connector.

ATX Main PWR (JPW1) & CPU PWR Connectors (JPW2)

The 24-pin main power connector

(JPW1) is used to provide power to

the motherboard. The 8-pin CPU PWR

connector (JPW2) is also required for

the processor. These power connectors

me et th e SSI EPS 12V spec ica tio n. Se e

the table on the right for pin denitions.

A

24-Pin Main PWR

A. 24-Pin ATX Main PWR

B. 8-Pin Processor PWR

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

PCIX2

JPB1

3

TPM/PORT80

JTPM1

20

2

7

1

7

1

7

2

8

2

8

1

JPG1

Connect to IPMI

1-2 Enable

2-3 Disable

JPG1: VGA

JIPMB1

JIPMB1

19

JI2C2

JI2C1

1

USB4/5

JUSB45

2

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

10
+
2

2

10

JUSB89

1

3-SGPIO1

7

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

USB2

SLOT3 PCI-X 133/100MHZ

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

X9SRi

REV:1.01

JUSB2

4

41

FANA

JPME_RCV1

SAS1/SAS3

SAS0/SAS2

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

SAS5 SAS6

SAS7 I-SATA2I-SATA3

SAS4

8-Pin Processor PWR

U8

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

OFF:DISABLE

ON: ENABLE

PCIE5

SLOT4 PCI-E 3.0 X8 (IN X16)

SLOT5 PCI-E 2.0 X4 (IN X16)

PCIE4

X_BT1

MH5

MAC CODE

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

1

3

3

R625

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

Compact

JWF1

1

3

JCF1

I-SATA0

I-SATA0

I-SATA1

I-SATA1

I-SATA5

I-SATA5

I-SATA3 I-SATA2

CHASSIS

INTRUSION

I-SATA4

I-SATA4

B

A

C

UID_LED

UID

UID_SW

1

2

JLAN2

LAN2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

SLOT6 PCI-E 3.0 X16

SAS CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

1

2

2

T-SGPIO1

T-SGPIO2

8

8

7

7

LAN1

P1-DIMM2B

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

1

MH7

JF1

2

4

FAN3

1

CLOSE 1st

JF1

ATX Power 24-pin Connector

Pin Denitions (JPW1)

Pin# Denition Pin # Denition

13 +3.3V 1 +3.3V

14 -12V 2 +3.3V

15 Ground 3 Ground

16 PS_ON 4 +5V

17 Ground 5 Ground

18 Ground 6 +5V

19 Ground 7 Ground

20 -5V 8 PWR_OK

21 +5V 9 5VSB

22 +5V 10 +12V

23 +5V 11 +12V

24 Ground 12 +3.3V

12V 8-pin Power Connec-

tor Pin Denitions

Pins Denition

1 through 4 Ground

5 through 8 +12V

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

2-3 Disable

1

3

JVR1

OPEN 1st

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

A

20

C

1

19

1

3

1

JPUSB1

USB0/1

P1-DIMM4A

P1-DIMM4B

DIMM_C1

JTAG1

24

12

A

JPW1

JPW2

JPW2

3

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

FAN1

FAN2

JWD1

JL1

JD1

41

41

1

SP1

7

(Required)

KB/MOUSE

JKBMS1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

B

5

JPI2C1

PWRI2C

2-23

X9SRi/X9SRE Motherboard Series User’s Manual

F

Fan Headers (FAN1~4, FANA)

The X9SRi/X9SRE series has ve fan headers

(Fan 1~Fan 4 and Fan A). These fans are 4-pin

fan headers. Pins 1-3 of these fan headers are

backward compatible with the traditional 3-pin

fans. However, the fan speed control setting

in the BIOS Hardware Monitoring section will

only work with 4-pin fans. This allows the BIOS

to automatically set fan speeds based on the

system temperature. Refer to the table on the

right for pin denitions and fan usage.

Note: We recommend that 4-pin fans

are used on the motherboard.

Chassis Intrusion (JL1)

A Chassis Intrusion header is located at JL1 on

the motherboard. Attach the appropriate cable

from the chassis to inform you of a chassis intru-

sion when the chassis is opened.

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

Connect to IPMI

TPM/PORT80

JTPM1

JIPMB1

JIPMB1

20

19

JI2C2

JI2C1

1

2

USB4/5

JUSB45

2

SLOT1 PCI-X 133/100MHZ

JOH1

7

10
+

1

2

USB6/7

1

JUSB67

7

1

2

USB8/9

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

SAS1/SAS3

SAS0/SAS2

4

SAS5 SAS6

SAS4

41

FANA

PCIX2

1

JPG1

1-2 Enable

2-3 Disable

JPG1: VGA

SLOT2 PCI-X 133/100MHZ

SLOT3 PCI-X 133/100MHZ

DESIGNED IN USA

X9SRi

REV:1.01

JPME_RCV1

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

OFF: SLAVE

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

U8

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

PCIE5

SLOT4 PCI-E 3.0 X8 (IN X16)

SLOT5 PCI-E 2.0 X4 (IN X16)

MH5

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

1

3

3

R625

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

Compact

JWF1

1

3

JCF1

I-SATA3 I-SATA2

I-SATA4

I-SATA4

E

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

CHASSIS

T-SGPIO1

T-SGPIO2

INTRUSION

1

8

8

7

7

MH7

4

FAN3

JPL11JPL2

JLAN2

LAN2

LAN1

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JVR2

1 3

JF1

20

2

19

1

C

Fan Header

Pin Denitions

Pin# Denition

1 Ground (Black)

2 +12V (Red)

3 Tachometer

4 PWM_Control

Fan Usage

FAN# Use for

1~4 System/CPU

A I/O Cards

Chassis Intrusion

Pin Denitions (JL1)

Pin# Denition

1 Intrusion Input

2 Ground

A. Fan 1

D

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable
2-3 Disable

1

3

JVR1

USB0/1

P1-DIMM4A

P1-DIMM4B

OPEN 1st

24

12

JPW1

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

B

FAN1

FAN2

A

C

JWD1

JL1

JD1

41

41

1

1

3

1

7

SP1

A

KB/MOUSE

JKBMS1

1

JPUSB1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

JPI2C1

PWRI2C

B. Fan 2

C. Fan 3

D. Fan 4

E. Fan A

F. Chassis Intrusion

2-24

Chapter 2: Installation

Speaker (JD1)

On the JD1 header, Pins 6~7 are used for

the internal speaker. Close Pins 6~7 with a

jumper or cap to use the onboard speaker.

If you wish to use an external speaker, at-

tach the external speaker's cable to Pins

1~4. See the table on the right for pin

denitions.

Internal Buzzer (SP1)

The Internal Buzzer (SP1) can be used

to provide audible indications for various

beep codes. See the table on the right for

pin denitions.

Wake-On-LAN (JSTBY1)

The Wake-On-LAN header is located at

JSTBY1 on the motherboard. See the

table on the right for pin denitions. (You

must also have a LAN card with a Wake-

On-LAN connector and cable to use this

feature.)

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

C

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

SAS0/SAS2

4

41

FANA

PCIX2

1

JPG1

Connect to IPMI

1-2 Enable

2-3 Disable

JPG1: VGA

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

X9SRi

REV:1.01

SAS1/SAS3

SAS5 SAS6

SAS7 I-SATA2I-SATA3

SAS4

SLOT3 PCI-X 133/100MHZ

JPME_RCV1

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

U8

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

PCIE5

SLOT4 PCI-E 3.0 X8 (IN X16)

SLOT5 PCI-E 2.0 X4 (IN X16)

X_BT1

MH5

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

1

3

3

R625

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

Compact

JWF1

1

3

JCF1

I-SATA1

I-SATA3 I-SATA2

I-SATA4

I-SATA4

I-SATA1

CHASSIS

INTRUSION

I-SATA5

I-SATA5

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

FAN3

Speaker Connector

Pin Denitions

Pin Setting Denition

Pins 6~7 Internal Speaker

Pins 1~3 PWR LED

Pins 4~7 External Speaker

Internal Buzzer

Pin Denition

Pin# Denitions

Pin 1 Pos. (+) Beep In

Pin 2 Neg. (-) Alarm

Wake-On-LAN

Pin Denitions

Pin# Denition

1 +5V Standby

2 Ground

3 Wake-up

A. Internal Buzzer

B. Speaker Header

C. Wake On LAN

JVGA

41

FAN4

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

JLAN2

LAN2

2-3 Disable

LAN1

1

3

JVR1

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JF1

2

1

OPEN 1st

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

20

19

A

C

1

1

3

A

Speaker

VGA

JCOM1

COM1

P1-DIMM4A

P1-DIMM4B

FAN1

FAN2

JWD1

JL1

JD1

41

41

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

JPI2C1

PWRI2C

1

SP1

B

2-25

X9SRi/X9SRE Motherboard Series User’s Manual

Power Supply I2C (JPI2C1)

The Power Supply I2C Connector,

located at JPI2C, monitors the status

of the power supply, fan and system

temperature. See the table on the right

for pin denitions.

DOM PWR Connector (JSD1)

The Disk-On-Module (DOM) power

connector, located at JSD1, provides

5V (Gen1/Gen) power to a solid_state

DOM storage device connected to one

of the SATA ports. See the table on the

right for pin denitions.

A

C

UID_LED

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

4

41

FANA

PCIX2

JPG1

Connect to IPMI

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

REV:1.01

SAS1/SAS3

SAS0/SAS2

SAS5 SAS6

SAS4

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

2-3 Disable

JPG1: VGA

With FCC Standards

FOR HOME OR OFFICE USE

SLOT3 PCI-X 133/100MHZ

X9SRi

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

Tested to Comply

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

1

Compact

B

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

X_BT1

CHASSIS

INTRUSION

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

T-SGPIO1

T-SGPIO2

8

8

7

7

PWR Supply I2C

Pin Denitions

Pin# Denition

1 Clock

2 Data

3 PWR Fail

4 Ground

5 3.3V

DOM PWR

Pin Denitions

Pin# Denition

1 5V

2 Ground

3 Ground/NC*

A. Power Supply I2C

B. DOM Power

UID

JLAN2

LAN2

LAN1

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN

1-2 Enable

JPL11JPL2

2-3 Disable

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

1

MH7

4

FAN3

JF1

2

1

OPEN 1st

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN2

20

19

A

C

JWD1

JL1

JD1

1

1

3

41

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable
1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

A

1

1

+

FAN1

41

JPI2C1

PWRI2C

1

SP1

2-26

Chapter 2: Installation

T-SGPIO 1/2 & 3-SGPIO 1/2 Headers

Two T-SGPIO (Serial-Link General Pur-

pose Input/Output) headers are located

next to the I-SATA Ports on the mother-

board. Additionally, two 3-SGPIO ports

(for SAS) are also located next to JUSB

8/9 . These headers are used to com-

municate with the enclosure manage-

ment chip in the system. See the table

on the right for pin denitions. Refer to

the board layout below for the locations

of the headers.

TPM Header (JTPM1)

This header is used to connect a

Trusted Platform Module (TPM), which

is available from a third-party vendor.

A TPM is a security device that sup-

ports encryption and authentication

in hard drives. It enables the moth-

erboard to deny access if the TPM

associated with the hard drive is not

installed in the system. See the table

on the right for pin denitions.

Serial_Link-SGPIO

Pin Denitions

Pin# Denition Pin Denition

1 NC 2 NC

3 Ground 4 DATA Out

5 Load 6 Ground

7 Clock 8 NC

NC: No Connections

Trusted Platform Module Header

Pin Denitions

Pin # Denition Pin # Denition

1 LCLK 2 GND

3 LFRAME 4 No Pin

5 LRESET 6 VCC5

7 LAD3 8 LAD2

9 VCC3 10 LAD1

11 LAD0 12 GND

13 SMBCLK 14 SMBDAT

15 SB3V 16 SERIRQ

17 GND 18 CLKRUN

19 LPCPD 20 LDRQ1

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

Connect to IPMI

TPM/PORT80

JTPM1

JIPMB1

JIPMB1

20

19

JI2C2

E

C

D

JI2C1

1

2

USB4/5

JUSB45

2

SLOT1 PCI-X 133/100MHZ

JOH1

7

10
+

1

2

USB6/7

1

JUSB67

7

1

2

USB8/9

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

SAS1/SAS3

SAS0/SAS2

4

SAS5 SAS6

SAS4

41

FANA

PCIX2

1

JPG1

1-2 Enable

2-3 Disable

JPG1: VGA

SLOT2 PCI-X 133/100MHZ

SLOT3 PCI-X 133/100MHZ

DESIGNED IN USA

X9SRi

REV:1.01

JPME_RCV1

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

OFF: SLAVE

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

U8

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

PCIE5

SLOT4 PCI-E 3.0 X8 (IN X16)

SLOT5 PCI-E 2.0 X4 (IN X16)

MH5

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

1

3

3

R625

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash
Compact

JWF1

1

3

JCF1

I-SATA3 I-SATA2

I-SATA4

I-SATA4

UID_SW

1

2

JLAN2

LAN2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

CHASSIS

T-SGPIO1

T-SGPIO2

INTRUSION

8

8

7

7

MH7

B

LAN1

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

1

4

JF1

20

2

19

FAN3

1

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

2-3 Disable

1

3

JVR1

1

USB0/1

P1-DIMM4A

P1-DIMM4B

OPEN 1st

24

12

JVR2

1 3

JWD1:Watch Dog
1-2:RST
2-3:NMI

1

1

3

JPW1

JD1:

PWR LED

1-3:

SPEAKER

4-7:

FAN1

FAN2

A

C

JWD1

JL1

JD1

41

41

1

7

SP1

KB/MOUSE

JPUSB1

2-3 ENable

1-2 Disable

P1-DIMM3B

DIMM_C1

JTAG1

JPW2

JPW2

3

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

A. T-SGPIO 1

B. T-SGPIO 2

JKBMS1

C. 3-SGPIO 1

JPUSB1:USB Wake Up

D. 3-SGPIO 2

E. TPM Header

P1-DIMM3A

5

JPI2C1

PWRI2C

2-27

X9SRi/X9SRE Motherboard Series User’s Manual

Unit ID Switch (UID SW)

The rear UID switch, the rear UID LED and

front UID LED on JF1 are designed to work

together. When the user pushes the rear

UID switch, the blue backpanel UID LED

and front UID LED will turn on. Push the

rear UID switch again to turn off UID LED

and the front UID LED. This provides easy

identication of a system unit that may be

in need of service.

Overheat/Fan Fail LED (JOH1)

The JOH1 header is used to connect an

LED to provide warnings of chassis over-

heat. This LED will also blink to indicate a

fan failure. Refer to the table on right for

pin denitions.

A

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

4

41

FANA

PCIX2

JPG1

Connect to IPMI

2-3 Disable

JIPMB1

JIPMB1

JI2C2

JI2C1

B

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

REV:1.01

SAS1/SAS3

SAS0/SAS2

SAS5 SAS6

SAS4

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

JPG1: VGA

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

SLOT4 PCI-E 3.0 X8 (IN X16)

SLOT3 PCI-X 133/100MHZ

X9SRi

MH5

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

1

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

Compact

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

CHASSIS

INTRUSION

UID_SW

1

2

LAN2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

FAN3

UID Switch

Pin# Denition

1 Button In

2 Ground

3 Ground

4 Ground

Overheat LED

Pin Denitions

Pin# Denition

1 P3V3

2 OH Active

OH/Fan Fail LED

Pin Denitions

State Message

Solid Overheat

Blinking Fan Fail

A. UID Switch

B. Overheat/Fan Fail LED

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

JLAN2

2-3 Disable

LAN1

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JF1

2

1

OPEN 1st

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN1

FAN2

20

19

A

C

JWD1

JL1

JD1

41

1

1

3

41

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

JPI2C1

PWRI2C

1

SP1

2-28

Chapter 2: Installation

System Management Bus (JIPMB1)

A System Management Bus header for the

IPMI slot is located at IPMB. Connect the

appropriate cable here to use the IPMB I2C

connection on your system.

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

4

41

FANA

PCIX2

A

JPG1

Connect to IPMI

2-3 Disable

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

REV:1.01

SAS1/SAS3

SAS0/SAS2

SAS5 SAS6

SAS4

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

JPG1: VGA

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

SLOT4 PCI-E 3.0 X8 (IN X16)

SLOT3 PCI-X 133/100MHZ

X9SRi

MH5

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

1

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

Compact

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

CHASSIS

INTRUSION

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

FAN3

System Management

Bus

Pin# Denition

1 Clock

2 Ground

3 Data

4 No Connection

A. System Management Bus

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

JLAN2

LAN2

2-3 Disable

LAN1

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JF1

2

1

OPEN 1st

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN1

FAN2

20

19

A

C

JWD1

JL1

JD1

1

1

3

41

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

JPI2C1

41

PWRI2C

1

SP1

2-29

X9SRi/X9SRE Motherboard Series User’s Manual

2-7 Jumper Settings

Explanation of Jumpers

To modify the operation of the mother-

board, jumpers can be used to choose

between optional settings. Jumpers create

shorts between two pins to change the

function of the connector. Pin 1 is identied

with a square solder pad on the printed

circuit board.

Note: On two pin jumpers,

"Closed" means the jumper is

on, and "Open" means the jumper

is off the pins.

LAN Port Enable/Disable (JPL1~2)

Jumpers JPL1/JPL2 enable or disable

LAN Port 1/LAN Port 2 on the moth-

erboard. See the table on the right for

jumper settings. The default setting is

enabled.

A

C

UID_LED

UID

SLOT5 PCI-E 2.0 X4 (IN X16)

INTRUSION

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

I-SATA0

I-SATA0

I-SATA1

I-SATA1

CHASSIS

LAN2

P1-DIMM2B

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

2

4

FAN3

1

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

Connect to IPMI

TPM/PORT80

JTPM1

JIPMB1

JIPMB1

20

19

JI2C2

JI2C1

1

2

USB4/5

JUSB45

2

SLOT1 PCI-X 133/100MHZ

JOH1

7

10
+

1

2

USB6/7

1

JUSB67

7

1

2

USB8/9

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

SAS1/SAS3

SAS0/SAS2

4

SAS5 SAS6

SAS4

41

FANA

PCIX2

1

JPG1

1-2 Enable

2-3 Disable

JPG1: VGA

SLOT2 PCI-X 133/100MHZ

SLOT3 PCI-X 133/100MHZ

DESIGNED IN USA

X9SRi

REV:1.01

JPBIOS_RCV1

JPME_RCV1

3

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

OFF: SLAVE

ON: MASTER

I-Button Header 1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

U8

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

PCIE5

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

ON:RECOVER BIOS
OFF:NORMAL

1

3

R625

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

JCF1:Compact Flash

JBT1

1

Power

Flash

Compact

JWF1

1

3

JCF1

I-SATA3 I-SATA2

I-SATA4

I-SATA4

GLAN Enable

Jumper Settings

Pin# Denition

1-2 Enabled (default)

2-3 Disabled

A. LAN Port 1 Enable

B. LAN Port 2 Enable

A

B

JLAN2

LAN1

CLOSE 1st

JF1

FAIL
PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JF1

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

2-3 Disable

1

3

JVR1

OPEN 1st

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN2

A

20

C

JWD1

JL1

JD1

41

1

19

1

3

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable
1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM4A

P1-DIMM4B

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4

JVR3

1

3

1

3

1

1

+

JPI2C1

FAN1

PWRI2C

41

1

SP1

2-30

Chapter 2: Installation

CMOS Clear (JBT1)

JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads

to prevent accidental clearing of CMOS. To clear CMOS, use a metal object such

as a small screwdriver to touch both pads at the same time to short the connection.

Always remove the AC power cord from the system before clearing CMOS.

Important: For an ATX power supply, you must completely shut down the

system, remove the AC power cord and then short JBT1 to clear CMOS.

PCI-E Slot SMB Enable (JI2C1/JI2C2)

Use Jumpers JI2C1/JI2C2 to enable PCI-E

SMB (System Management Bus) support

to improve system management for the

PCI-E slots. See the table on the right for

jumper settings.

B

C

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

4

41

FANA

PCIX2

JPG1

Connect to IPMI

2-3 Disable

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

REV:1.01

JUSB2

SAS1/SAS3

SAS0/SAS2

SAS5 SAS6

SAS4

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

JPG1: VGA

With FCC Standards

FOR HOME OR OFFICE USE

SLOT3 PCI-X 133/100MHZ

X9SRi

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

Tested to Comply

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

1

A

Compact

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

INTRUSION

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

CHASSIS

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

FAN3

PCI-E Slot SMB Enable

Jumper Settings

Jumper Setting Denition

Short Enabled

Open (Default) Disabled

A. Clear CMOS

B. JI2C1

C. JI2C2

JVGA

41

FAN4

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

JLAN2

LAN2

P1-DIMM2B

FAIL

PWR

RSTONPWR

2

1

2-3 Disable

LAN1

1

3

JVR1

CLOSE 1st

OPEN 1st

JF1

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

JF1

20

19

A

C

1

1

3

VGA

JCOM1

COM1

P1-DIMM4A

P1-DIMM4B

FAN2

JWD1

JL1

JD1

41

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

FAN1

41

JPI2C1

PWRI2C

1

SP1

2-31

X9SRi/X9SRE Motherboard Series User’s Manual

VGA Enable (JPG1)

JPG1 allows you to enable or disable the

onboard VGA connector. The default posi-

tion is on pins 1 and 2 to enable VGA. See

the table on the right for jumper settings.

Watch Dog Reset (JWD1)

Watch Dog (JWD1) is a system moni-

tor that can reboot the system when a

software application hangs. Close Pins

1-2 to reset the system if an applica-

tion hangs. Close Pins 2-3 to generate a

non-maskable interrupt signal for the ap-

plication that hangs. See the table on the

right for jumper settings. Watch Dog must

also be enabled in the BIOS.

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

JUSB45

2

7

10
+
2

1

JUSB67

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

SAS0/SAS2

4

41

FANA

A

PCIX2

JPG1

Connect to IPMI

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

USB8/9

DESIGNED IN USA

REV:1.01

SAS1/SAS3

SAS5 SAS6

SAS4

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

2-3 Disable

JPG1: VGA

With FCC Standards

FOR HOME OR OFFICE USE

SLOT3 PCI-X 133/100MHZ

X9SRi

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

Tested to Comply

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

1

Flash

Compact

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

CHASSIS

INTRUSION

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

FAN3

VGA Enable/Disable

Jumper Settings (JPG1)

Both Jumpers Denition

Pins 1-2 Enabled (Default)

Pins 2-3 Disabled

Watchdog Enable/Disable

Jumper Settings (JWD1)

Jumpers Denition

Pins 1-2 Reset (Default)

Pins 2-3 NMI

A. VGA Enable

B. Watch Dog Reset

VGA

JVGA

41

FAN4

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

JLAN2

LAN2

2-3 Disable

LAN1

1

3

JVR1

CLOSE 1st

P1-DIMM2B

JF1

FAIL
PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JF1

2

1

OPEN 1st

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

20

19

A

C

1

1

3

B

JCOM1

COM1

P1-DIMM4A

P1-DIMM4B

FAN2

JWD1

JL1

JD1

41

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6

JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

FAN1

41

JPI2C1

PWRI2C

1

SP1

2-32

Chapter 2: Installation

USB Wake-Up (JPUSB1)

Use the jumper JPUSB1 to "wake-up"

your system by pressing a key on a USB

keyboard or clicking the USB mouse con-

nected to the backpanel USB Ports 0/1.

JPUSB1 is used together with a USB

Wake-Up feature in the BIOS. Enable this

jumper and the USB support in the BIOS to

wake up your system via USB devices.

Note: When the USB is set to Enabled

in the BIOS, and JPUSB1 is set to Dis-

abled, remove the USB devices from

Backplane USB Ports 0/1 before the

system goes into the standby mode.

BMC Enable/Disable (JPB1)

JPB1 is used to enable or disable the

BMC (Baseboard Management Control)

chip and the onboard IPMI connection.

This jumper is used together with the IPMI

settings in the BIOS. See the table on the

right for jumper settings. Supported on the

X9SRi-3F and X9SRE-3F only.

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

B

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

4

41

FANA

PCIX2

JPG1

Connect to IPMI

2-3 Disable

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

REV:1.01

SAS1/SAS3

SAS0/SAS2

SAS5 SAS6

SAS4

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

JPG1: VGA

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

SLOT3 PCI-X 133/100MHZ

X9SRi

MH5

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

1

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

Compact

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

SLOT4 PCI-E 3.0 X8 (IN X16)

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

CHASSIS

INTRUSION

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

USB 0/1 Wake-up Enable

Jumper Settings

Pin# Denition

1-2 Enabled (Default)

2-3 Disabled

BMC IPMI Enable/Disable

Jumper Settings

Settings Denition

Pins 1-2 Enabled (Default)

Pins 2-3 Disabled

A. USB 0/1 Wake-up

B. BMC Enable/Disable

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

JLAN2

LAN2

2-3 Disable

LAN1

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JF1

2

FAN3

1

OPEN 1st

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN2

20

19

A

C

JWD1

JL1

JD1

1

1

3

41

7

KB/MOUSE

JKBMS1

A

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

FAN1

41

JPI2C1

PWRI2C

1

SP1

2-33

X9SRi/X9SRE Motherboard Series User’s Manual

BIOS Recovery (JPBIOS1)

The BIOS Recovery (JPBIOS1) is used to

enable or disable the BIOS Recovery fea-

ture of the motherboard. Install the jumper

on pins 1-2 to begin the recovery process.

ME Recovery (JPME1)

ME Recovery (JPME1) is used to enable

or disable the ME Recovery feature of the

motherboard. This jumper will reset Intel

ME values back to their default settings.

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

JUSB2

4

41

FANA

PCIX2

JPG1

Connect to IPMI

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

REV:1.01

SAS1/SAS3

SAS0/SAS2

B

SAS5 SAS6

SAS4

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

2-3 Disable

JPG1: VGA

With FCC Standards

FOR HOME OR OFFICE USE

SLOT3 PCI-X 133/100MHZ

X9SRi

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

Tested to Comply

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

1

Compact

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

A

INTRUSION

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

CHASSIS

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

FAN3

BIOS Recovery

Jumper Settings

Pin# Denition

1-2 Normal (Default)

2-3 Recover

ME Recovery

Jumper Settings

Pin# Denition

1-2 Normal (Default)

2-3 Force Update

A. BIOS Recovery

B. ME Recovery

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

JLAN2

LAN2

2-3 Disable

LAN1

1

3

JVR1

P1-DIMM4A

P1-DIMM4B

CLOSE 1st

P1-DIMM2B

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JF1

2

1

OPEN 1st

JF1

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN2

20

19

A

C

JWD1

JL1

JD1

41

1

1

3

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

FAN1

41

JPI2C1

PWRI2C

1

SP1

2-34

Chapter 2: Installation

LAN 1/LAN 2

2-8 Onboard Indicators

LAN Port LEDs

The LAN ports are located on the I/O

backpanel of the motherboard. Each Eth-

ernet LAN port has two LEDs. A blinking

Activity LED indicates there is data passing

th rou gh the po r t, wh ile the Link LED may be

green, amber, or off to indicate the speed of

the connection. See the tables at right for

more information.

IPMI Dedicated LAN LEDs

In addition to the LAN ports, an IPMI Dedi-

cated LAN port is also located on X9SRi/

X9SRE series. The yellow LED on the right

indicates activity, while the green LED on

the left indicates the speed of the con-

nection. See the tables at right for more

information.

A. LAN1

B. LAN2

C.IPMI Dedicated LAN (See table on page 1-10 for information)

LAN

Link LED

Link LEDs (Green/Amber/Off)

LED Color Denition

Off 100 Mbps

Amber 1 Gbps

Green 10 Gbps (if supported)

Note: 10 Mbps is not supported.

10Gbps is only supported on

some motherboards.

IPMI LAN Link LED (Left) &

Activity LED (Right)

Status Color Denition

Link (Left) Green: Solid 100 Mbps

Activity
(Right)

Yellow: Blink­ing

Activity LED

LAN

IPMI LAN

Link LED

Activity LED

Active

C

Motherboard I/O Backpanel

A

B

2-35

X9SRi/X9SRE Motherboard Series User’s Manual

Rear Unit ID LED (UID LED)

The rear Unit ID LED is located at UID

LED on the backpanel. This LED is used

in conjunction with the rear UID switch to

provide easy identication of a system that

might be in need of service.

IPMI Heartbeat LED (DP3)

The IPMI Heartbeat LED is located at DP3.

When DP3 blinks, the IPMI feature is func-

tioning properly. Refer to the table on the

right for details. Also see the layout below

for the LED location. This is supported on

the X9SRi-3F/X9SRE-3F only.

Onboard Power LED (DP2)

An Onboard Power LED is located at

PWR LED on the motherboard. When

PWR LED is on, it means that the AC

power cable is connected, the power

supply switch and soft switch are on, and

the system is running.

A

A

C

B

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+
2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

4

41

FANA

PCIX2

JPG1

Connect to IPMI

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

REV:1.01

JUSB2

SAS1/SAS3

SAS0/SAS2

SAS5 SAS6

SAS4

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

2-3 Disable

JPG1: VGA

With FCC Standards

FOR HOME OR OFFICE USE

SLOT3 PCI-X 133/100MHZ

X9SRi

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

JWF1

1
3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

Tested to Comply

SLOT4 PCI-E 3.0 X8 (IN X16)

MH5

1

Flash

Compact

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

CHASSIS

INTRUSION

UID_LED

UID

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

X_BT1

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

FAN3

Rear UID LED

LED Settings

Blue: Solid UID Toggled On

IPMI Heartbeat LED Indicator

LED Settings

Green: Blinking IPMI is ready for use

Onboard PWR LED (DP2)

LED Status

Status Denition

Off System Off (Soft Switch)

On System is Running

A. Rear Unit ID LED

B. IPMI Heartbeat LED

C. Power LED

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable

JPL11JPL2

JLAN2

LAN2

2-3 Disable

LAN1

1

3

JVR1

CLOSE 1st

P1-DIMM2B

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JF1

2

1

OPEN 1st

JF1

JVR2

1 3

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:
1-2:RST
2-3:NMI

FAN2

20

19

A

C

JWD1

JL1

JD1

1

1

3

41

7

C

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM4A

P1-DIMM4B

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

FAN1

41

JPI2C1

PWRI2C

1

SP1

2-36

2-9 SATA and SAS Connections

Chapter 2: Installation

SATA/SAS Connections

Six Serial ATA (SATA) connectors (I-SATA

0~5) are located on the motherboard. I-SATA

0/1 supports data transfer rates of up to

6Gb/s (SATA 3.0), while I-SATA 2~5 supports

data transfer rates of up to 3Gb/s (SATA

2.0). Please see the pin denitions on the

right table.

In addition to these six SATA ports, eight

3Gb/s SAS connections (Serial-Attached

SCSI) are also located on the X9SRi-3F/

X9SRE-3F series (SCU0~7).

A

C

UID_LED

UID

MH1

COM2

JCOM2

DP3

6

1

JSTBY

9

3

5

JSTBY : Wake on Lan

PCIX1

1

JPB1

3

TPM/PORT80

JTPM1

20

19

1

2

2

7

10
+

2

1

7

1

2

7

10

JUSB89

2

1

3-SGPIO1

8

7

2

1

3-SGPIO2

3-SGPIO23-SGPIO1

7

8

USB2

1

2

JUSB2

4

3

4

41

FANA

PCIX2

JPG1

Connect to IPMI

2-3 Disable

JIPMB1

JIPMB1

JI2C2

JI2C1

USB4/5

JUSB45

SLOT1 PCI-X 133/100MHZ

SLOT2 PCI-X 133/100MHZ

JOH1

1

USB6/7

JUSB67

USB8/9

DESIGNED IN USA

REV:1.01

SAS1/SAS3

SAS0/SAS2

SAS5 SAS6

SAS4

JPB: BMC
1-2 Enable
2-3 Disable

PCIX3

1

1-2 Enable

JPG1: VGA

With FCC Standards

FOR HOME OR OFFICE USE

SLOT3 PCI-X 133/100MHZ

X9SRi

MH5

ON:RECOVER BIOS

JPBIOS_RCV1

OFF:NORMAL

3

JPME_RCV1

3

R625

ON:ME IN FORCE UPDATA MODE
OFF:NORMAL

JRK1
Pin1:RAID_KEY_PCH
Pin2:Ground
Pin3:PCH_DYN_SKU

OFF: SLAVE

ON: MASTER

JCF1:Compact Flash

JBT1

1

I-Button Header 1

Power

Flash

Compact

JWF1

1

3

JCF1

I-SATA5

I-SATA5

SAS7 I-SATA2I-SATA3

Tested to Comply

SLOT4 PCI-E 3.0 X8 (IN X16)

1

I-SATA3 I-SATA2

I-SATA4

I-SATA4

U8

PCIE5

SLOT5 PCI-E 2.0 X4 (IN X16)

X_BT1

CHASSIS

INTRUSION

UID_SW

1

2

PCIE6

JI2C1/JI2C2

I2C Bus for PCI slot

OFF:DISABLE

ON: ENABLE

SLOT6 PCI-E 3.0 X16

PCIE4

SAS CODE

MAC CODE

MAC CODE

P1-DIMM2A

P1-DIMM1B

P1-DIMM1A

I-SATA0

I-SATA0

I-SATA1

I-SATA1

1

2

2

T-SGPIO1

T-SGPIO2

1

8

8

7

7

MH7

4

SATA/SAS Connectors

Pin# Signal

1 Ground

2 SATA_TXP

3 SATA_TXN

4 Ground

5 SATA_RXN

6 SATA_RXP

7 Ground

A. I-SATA 0 (3.0)

B. I-SATA 1 (3.0)

C. I-SATA 2 (2.0)

D. I-SATA 3 (2.0)

E. I-SATA 4 (2.0)

F. I-SATA 5 (2.0)

JPL11JPL2

JLAN2

LAN2

LAN1

CLOSE 1st

P1-DIMM2B

JF1

FAIL

PWR

RSTONPWR

HDD

NIC

NICOHLED

PWR

NMI

FF

1

2

X

JVR2

1 3

JF1

20

2

FAN3

19

1

Pin Denitions

G. SCU0

H. SCU1

I. SCU2

J. SCU3

K. SCU4

L. SCU5

M. SCU6

N. SCU7

VGA

JVGA

JCOM1

41

FAN4

COM1

FAN4

JPL1/2: LAN
1-2 Enable
2-3 Disable

1

3

JVR1

OPEN 1st

JD1:

PWR LED

1-3:

JWD1:Watch Dog

SPEAKER

4-7:

1-2:RST

2-3:NMI

A

C

JWD1

JD1

1

1

3

7

KB/MOUSE

JKBMS1

1

JPUSB1

USB0/1

2-3 ENable

1-2 Disable

JPUSB1:USB Wake Up

P1-DIMM4A

P1-DIMM4B

P1-DIMM3A

P1-DIMM3B

DIMM_C1

JTAG1

24

12

JPW1

JPW2

JPW2

3

5

JVR6
JVR5

3

JVR4
JVR3

1

3

1

3

1

1

+

FAN1

FAN2

JL1

41

41

JPI2C1

PWRI2C

1

SP1

5

6

7

F

8

E

D

A

B

C

2-37

X9SRi/X9SRE Motherboard Series User’s Manual

Notes

2-38

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all

of the procedures below and still need assistance, refer to the ‘Technical Support

Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.

Always disconnect the AC power cord before adding, changing or installing any

hardware components.

Before Power On

1. Make sure that the Standby is not on. (Note: If it is on, the onboard power

is on. Be sure to unplug the power cable before installing or removing the

components.)

2. Make sure that there are no short circuits between the motherboard and

chassis.

3. Disconnect all ribbon/wire cables from the motherboard, including those for

the keyboard and mouse. Also, be sure to remove all add-on cards.

4. Install a CPU and heatsink (-be sure that it is fully seated) and then connect

the chassis speaker and the power LED to the motherboard. Check all jumper

settings as well.

No Power

1. Make sure that there are no short circuits between the motherboard and

chassis.

2. Make sure that all jumpers are set to their default positions.

3. Check if the 115V/230V switch on the power supply is properly set.

4. Turn the power switch on and off to test the system.

5. The battery on your motherboard may be old. Check to make sure that it still

supplies ~3VDC. If it does not, replace it with a new one.

3-1

X9SRi/X9SRE Motherboard Series User’s Manual

No Video

1. If the power is on, but you have no video--in this case, you will need to re-

move all the add-on cards and cables rst.

2. Use the speaker to determine if any beep codes exist. (Refer to Appendix A

for details on beep codes.)

3. Remove all memory modules and turn on the system. (If the alarm is on,

check the specs of memory modules, reset the memory or try a different one.)

Memory Errors

1. Make sure that the DIMM modules are properly installed and fully seated in

the slots.

2. You should be using memory recommended by Supermicro (see Section 2-3).

Also, it is recommended that you use the memory modules of the same type

and speed for all DIMMs in the system. Do not use memory modules of differ-

ent sizes, different speeds and different types on the same motherboard.

3. Check for bad DIMM modules or slots by swapping modules between slots to

see if you can locate the faulty ones.

4. Check the switch of 115V/230V power supply.

When You Lose the System’s Setup Conguration

1. Please be sure to use a high quality power supply. A poor quality power sup-

ply may cause the system to lose CMOS setup information. Refer to Section

1-5 for details on recommended power supplies.

2. The battery on your motherboard may be old. Check to verify that it still sup-

plies ~3VDC. If it does not, replace it with a new one.

3. If the above steps do not x the Setup Conguration problem, contact your

vendor for repairs.

3-2

Chapter 3: Troubleshooting

3-2 Technical Support Procedures

Before contacting Technical Support, please make sure that you have followed all

the steps listed below. Also, Note that as a motherboard manufacturer, Supermicro

does not sell directly to end users, so it is best to rst check with your distributor or

reseller for troubleshooting services. They should know of any possible problem(s)

with the specic system conguration that was sold to you.

1. Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked

Question' (FAQ) sections in this chapter or see the FAQs on our website

(http://www.supermicro.com/support/faqs/) before contacting Technical Sup-

port.

2. BIOS upgrades can be downloaded from our website at (http://www.supermi-

cro.com/support/bios/).

Note: Not all BIOS can be ashed. Some cannot be ashed; it depends

on the boot block code of the BIOS.

3. If you've followed the instructions above to troubleshoot your system, and still

cannot resolve the problem, then contact Supermicro's technical support and

provide them with the following information:

• Motherboard model and PCB revision number

• BIOS release date/version (this can be seen on the initial display when your

system rst boots up)

•System conguration

•An example of a Technical Support form is on our website at (http://www.su-

permicro.com/support/contact.cfm).

4. Distributors: For immediate assistance, please have your account number

ready when placing a call to our technical support department. We can be

reached by e-mail at [e-mail], by phone at: (408) 503-

8000, option 2, or by fax at [phone].

3-3

X9SRi/X9SRE Motherboard Series User’s Manual

3-3 Frequently Asked Questions

Question: What type of memory does my motherboard support?

Answer: Please see Section 2-3 for a comprehensive answer.

Question: How do I update my BIOS?

Answer: It is recommended that you do not upgrade your BIOS if you are not

experiencing any problems with your system. Updated BIOS les are located on

our website at http://www.supermicro.com/support/bios/. Please check our BIOS

warning message and the information on how to update your BIOS on our web

site. Select your motherboard model and download the BIOS ROM le to your

computer. Also, check the current BIOS revision to make sure that it is newer than

your BIOS before downloading. Please unzip the BIOS le onto a bootable device

or a USB pen/thumb drive. To ash the BIOS, run the batch le named "ami.bat"

with the new BIOS ROM le from your bootable device or USB pen/thumb drive.

Use the following format:

F:\> ami.bat BIOS-ROM-lename.xxx <Enter>

Important: Always use the le named “ami.bat” to update the BIOS, and

insert a space between "ami.bat" and the lename. The BIOS-ROM-

lename will bear the motherboard name (i.e., X9SCi) and build date as

the extension. For example, "X9SRE1.218". When completed, your system

will automatically reboot.

When the BIOS ashing screen is completed, the system will reboot and

will show “Press F1 or F2”. At this point, you will need to load the BIOS

defaults. Press <F1> to go to the BIOS setup screen, and press <F9> to

load the default settings. Next, press <F10> to save and exit. The system

will then reboot.

Warning: Do not shut down or reset the system while updating the BIOS

to prevent possible system boot failure!

Note: The SPI BIOS chip installed on this motherboard is not removable.

To repair or replace a damaged BIOS chip, please send your motherboard

to RMA at Supermicro for service.

Question: I think my BIOS is corrupted. How can I recover my BIOS?

Answer: Please see Appendix C-BIOS Recovery for detailed instructions.

Question: What's on the CD that came with my motherboard?

Answer: The supplied compact disc has quite a few drivers and programs that will

greatly enhance your system. We recommend that you review the CD and install the

applications you need. Applications on the CD include chipset drivers for Windows,

security programs, and audio drivers.

3-4

Chapter 3: Troubleshooting

Question: Why do I get an error message “IASTOR.SYS read error” and "press F6

to install Intel RAID driver" when installing Windows on my motherboard?

Answer: To solve this issue, disable the IPMI jumper. Another solution is to use a

USB oppy drive instead of the onboard oppy drive. For the IPMI jumper location,

please check Chapter 1.

Question: What is the heatsink part number for my X9SRi/X9SRE Series moth-

erboard?

Answer: The heatsink part numbers are as follows:

1U Passive Heatsink: SNK-P0047P

2U Passive Heatsink: SNK-P0048P

4U Active Heatsink: SNK-P0050AP4

Question: Why can't I recover the BIOS even when I’ve followed the instructions

in the user’s manual for the motherboard?

Answer: Please disable the IPMI jumper and try it again. For the jumper location,

please check Chapter 1.

3-5

X9SRi/X9SRE Motherboard Series User’s Manual

3-4 Battery Removal and Installation

Battery Removal

To remove the onboard battery, follow the steps below:

1. Power off your system and unplug your power

cable.

2. Locate the onboard battery as shown below.

3. Using a tool such as a pen or a small screwdriver,

push the battery lock outwards to unlock it. Once

unlocked, the battery will pop out from the holder.

4. Remove the battery.

Proper Battery Disposal

Warning! Please handle used batteries

carefully. Do not damage the battery in any

way; a damaged battery may release hazard-

ous materials into the environment. Do not

discard a used battery in the garbage or a

public landll. Please comply with the regula-

tions set up by your local hazardous waste

management agency to dispose of your used

battery properly.

Battery
Lock

Battery

Battery Holder

This side up

Battery Installation

1. To install an onboard battery, follow the steps 1&

2 above and continue below:

2. Identify the battery's polarity. The positive (+) side

should be facing up.

3. Insert the battery into the battery holder and push

it down until you hear a click to ensure that the

battery is securely locked.

Warning: When replacing a battery, be sure

to only replace it with the same type.

3-6

1

Press down until
you hear a click.

2

Chapter 3: Troubleshooting

3-5 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required

before any warranty service will be rendered. You can obtain service by calling

your vendor for a Returned Merchandise Authorization (RMA) number. For faster

service, you may also obtain RMA authorizations online (http://www.supermicro.

com/support/rma/). When you return the motherboard to the manufacturer, the

RMA number should be prominently displayed on the outside of the shipping

carton, and mailed prepaid or hand-carried. Shipping and handling charges will

be applied for all orders that must be mailed when service is complete.

This warranty only covers normal consumer use and does not cover damages

incurred in shipping or from failure due to the alteration, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor rst for any product prob-

lems.

3-7

X9SRi/X9SRE Motherboard Series User’s Manual

Notes

3-8

Chapter 4: AMI BIOS

Chapter 4

BIOS

4-1 Introduction

This chapter describes the AMI BIOS Setup Utility for the X9SRi/X9SRE Mother-

board Series. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily

updated. This chapter describes the basic navigation of the AMI BIOS Setup Utility

setup screens.

Note: For instructions on BIOS recovery, please refer to the instruction

guide posted at http://www.supermicro.com/support/manuals/.

Starting BIOS Setup Utility

To enter the AMI BIOS Setup Utility screens, press the <Delete> key while the

system is booting up.

Note: In most cases, the <Delete> key is used to invoke the AMI BIOS

setup screen. There are a few cases when other keys are used, such as

<F1>, <F2>, etc.

Each main BIOS menu option is described in this manual. The Main BIOS setup

menu screen has two main frames. The left frame displays all the options that can

be congured. Grayed-out options cannot be congured. Options in blue can be

congured by the user. The right frame displays the key legend. Above the key

legend is an area reserved for a text message. When an option is selected in the

left frame, it is highlighted in white. Often a text message will accompany it. (Note:

the AMI BIOS has default text messages built in. Supermicro retains the option to

include, omit, or change any of these text messages.)

The AMI BIOS Setup Utility uses a key-based navigation system called "hot keys".

Most of the AMI BIOS setup utility "hot keys" can be used at any time during the

setup navigation process. These keys include <F1>, <F10>, <Enter>, <ESC>, ar-

row keys, etc.

Note: Options printed in Bold are default settings.

How To Change the Conguration Data

The conguration data that determines the system parameters may be changed by

entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing

<Del> at the appropriate time during system boot.

4-1

X9SRi/X9SRE Motherboard Series User’s Manual

How to Start the Setup Utility

Normally, the only visible Power-On Self-Test (POST) routine is the memory test.

As the memory is being tested, press the <Delete> key to enter the main menu of

the AMI BIOS Setup Utility. From the main menu, you can access the other setup

screens. An AMI BIOS identication string is displayed at the left bottom corner of

the screen, below the copyright message.

Warning! Do not upgrade the BIOS unless your system has a BIOS-related

issue. Flashing the wrong BIOS can cause irreparable damage to the

system. In no event shall Supermicro be liable for direct, indirect, special,

incidental, or consequential damages arising from a BIOS update. If you

have to update the BIOS, do not shut down or reset the system while the

BIOS is updating. This is to avoid possible boot failure.

4-2 Main Setup

When you rst enter the AMI BIOS Setup Utility, you will enter the Main setup screen.

You can always return to the Main setup screen by selecting the Main tab on the

top of the screen. The Main BIOS Setup screen is shown below.

4-2

Chapter 4: AMI BIOS

System Overview: The following BIOS information will be displayed:

System Time/System Date

Use this option to change the system time and date. Highlight System Time or Sys-

tem Date using the arrow keys. Enter new values through the keyboard. Press the

<Tab> key or the arrow keys to move between elds. The date must be entered in

Day MM/DD/YY format. The time is entered in HH:MM:SS format. (Note: The time

is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00.)

Supermicro X9SRE/X9SR-3F/X9SRi/X9SRi-3F

Version: This item displays the version of the BIOS used in the system.

Build Date: This item displays the day this version of BIOS was built.

Memory Iniformation

Total Memory

This displays the size of memory available in the system:

4-3

X9SRi/X9SRE Motherboard Series User’s Manual

4-3 Advanced Setup Congurations

Use the arrow keys to select Boot Setup and hit <Enter> to access the submenu

items:



BOOT Feature

Quiet Boot

This option allows the bootup screen options to be modied between POST mes-

sages or the OEM logo. Select Disabled to display the POST messages. Select

Enabled to display the OEM logo instead of the normal POST messages. The op-

tions are Enabled and Disabled.

AddOn ROM Display Mode

This sets the display mode for Option ROM. The options are Force BIOS and

Keep Current.

Bootup Num-Lock

This feature selects the Power-on state for Numlock key. The options are Off

and On.

Wait For 'F1' If Error

This forces the system to wait until the 'F1' key is pressed if an error occurs. The

options are Disabled and Enabled.

Interrupt 19 Capture

Interrupt 19 is the software interrupt that handles the boot disk function. When this

item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt

4-4

Chapter 4: AMI BIOS

19 at boot and allow the drives that are attached to these host adaptors to function

as bootable disks. If this item is set to Disabled, the ROM BIOS of the host adap-

tors will not capture Interrupt 19, and the drives attached to these adaptors will not

function as bootable devices. The options are Enabled and Disabled.

Watch Dog Function

If enabled, the Watch Dog Timer will allow the system to reboot when it is inactive

for more than 5 minutes. The options are Enabled and Disabled.

Power Button Function

This feature controls how the system shuts down when the power button is pressed.

Select 4-Second Override to force the user to press and hold the Power Button for

4 seconds before the system turns off. Select Instant Off if you want the system to

instanty power off when the Power Button is pressed. The options are 4 Second

Override and Instant Off.

Restore on AC Power Loss

Use this feature to set the power state after a power outage. Select Power-Off for

the system power to remain off after a power loss. Select Power-On for the system

power to be turned on after a power loss. Select Last State to allow the system

to resume its last state before a power loss. The options are Power-On, Stay-Off

and Last State.



CPU Conguration

Warning: Take Caution when changing the Advanced settings. An incorrect

value, a very high DRAM frequency or incorrect DRAM timing may cause

system to become unstable. When this occurs, revert to the default setting.



Socket 1 CPU Information

This item is for informational purposes only and displays CPU information

including type, speed, number of cores, etc.

Clock Spread Spectrum

Select Enable to use the feature of Clock Spectrum, which will allow the BIOS to

monitor and attempt to reduce the level of Electromagnetic Interference caused by

the components whenever needed. Select Disabled to enhance system stability.

The options are Disabled and Enabled.

Hyper Threading

Set to Enabled to use the processor's Hyper Threading Technology feature. The

options are Enabled and Disabled.

4-5

X9SRi/X9SRE Motherboard Series User’s Manual

Active Processor Cores

Set to Enabled to use a processor's Second Core and beyond. (Please refer to

Intel's web site for more information.) The options are All and 1.

Limit CPUID Maximum

This feature allows the user to set the maximum CPU ID value. Enable this function

to boot the legacy operating systems that cannot support processors with extended

CPUID functions. The options are Enabled and Disabled (for the Windows OS.).

Execute-Disable Bit (Available when supported by the OS and the CPU)

Set to Enabled to enable the Execute Disable Bit which will allow the processor

to designate areas in the system memory where an application code can execute

and where it cannot, thus preventing a worm or a virus from ooding illegal codes

to overwhelm the processor or damage the system during an attack. The default is

Enabled. (Refer to Intel and Microsoft Web Sites for more information.)

Intel® AES-NI

Set to Enabled to use the processor's Advanced Encryption Standard (AES) feature.

The options are Enabled and Disabled.

Hardware Prefetcher (Available when supported by the CPU)

If set to Enabled, the hardware pre fetcher will pre fetch streams of data and instruc-

tions from the main memory to the L2 cache in the forward or backward manner to

improve CPU performance. The options are Disabled and Enabled.

Adjacent Cache Line Prefetch (Available when supported by the CPU)

The CPU fetches the cache line for 64 bytes if this option is set to Disabled. The

CPU fetches both cache lines for 128 bytes as comprised if Enabled.

DCU Streamer Prefetcher

This feature enables prefetch of the next L1 data line based on multiple loads in

the same cache line. The options are Enabled and Disabled.

DCU IP Prefetcher

Set this feature to Enabled to activate the L1 Data Prefetcher based on sequential

load history. The options are Enabled and Disabled.

4-6

Chapter 4: AMI BIOS

Intel® Virtualization Technology (Available when supported by the CPU)

Select Enabled to use the feature of Virtualization Technology to allow one plat-

form to run multiple operating systems and applications in independent partitions,

creating multiple "virtual" systems in one physical computer. The options are

Enabled and Disabled.

Note: If there is any change to this setting, you will need to power off and

restart the system for the change to take effect. Please refer to Intel’s

web site for detailed information.



CPU Power Management Conguration

Power Technology

This feature determines what power-saving scheme the motherboard uses. The

options are Disabled, Energy Efcient and Custom. If Custom is selected, the

following options become available:

EIST

EIST (Enhanced Intel SpeedStep Technology) allows the system to automati-

cally adjust processor voltage and core frequency in an effort to reduce

power consumption and heat dissipation. Please refer to Intel’s web site for

detailed information. The options are Disabled and Enabled.

Turbo Mode

This feature allows processor cores to run faster than marked frequency in

specic conditions. The options are Disabled and Enabled.

C1E Support

Select Enabled to use the "Enhanced Halt State" feature. C1E signicantly

reduces the CPU's power consumption by reducing the CPU's clock cycle

and voltage during a "Halt State." The options are Disabled and Enabled.

CPU C3 Report, CPU C6, CPU C7 Report

This BIOS feature enables or disables C3 (ACPI C2), C6 (ACPI C3). C7 (ACPI

C3) reporting to the operating system. The options for C3 are Disabled and

Enabled. The options for C6 and C7 are Disabled and Enabled.

Package C State Limit

If set to Auto, the AMI BIOS will automatically set the limit on the C-State
package register. The options are C0, C2, C6, and No Limit.

Long duration power limit - this is the processor power consumption limit (in

Watts) during a long duration time window.

4-7

X9SRi/X9SRE Motherboard Series User’s Manual

Long duration maintained - this is the time in milliseconds where the Long Dura-

tion Power Limit is maintained.

Short duration power limit - During Turbo Mode, the system may exceed the

processor's default power setting and exceed the Short Duration Power limit. By

increasing this value, the processor can provide better performance for a short

duration.



Chipset Conguration

WARNING: Setting the wrong values in the following sections may cause

the system to malfunction.



North Bridge Conguration

This item displays the current IO chipset Revision.



Integrated IO Conguration

Intel® VT-d

Select Enabled to enable Intel's Virtualization Technology support for
Direct I/O VT-d by reporting the I/O device assignments to VMM through

the DMAR ACPI Tables. This feature offers fully-protected I/O resource-

sharing across the Intel platforms, providing the user with greater reliabil-

ity, security and availability in networking and data-sharing. The settings

are Enabled and Disabled.

Intel® I/OAT

The Intel I/OAT (I/O Acceleration Technology) significantly reduces

CPU overhead by leveraging CPU architectural improvements, freeing

resources for more other tasks. The options are Disabled and Enabled.

DCA Support

This feature accelerates the performance of I/O devices using Direct
Cache Access. The options are Enabled and Disabled.

IIO 1 PCIe Port Bifurcation Control

Slot 6 PCI-E 3.0 x16 Link Speed

This feature enables the user to select the target link speed for this slot.
The options are GEN1, GEN2 and GEN3.

Slot 4 PCI-E 3.0 x8 Link Speed

This feature enables the user to select the target link speed for this slot.
The options are GEN1, GEN2 and GEN3.

4-8

Chapter 4: AMI BIOS



DIMM Conguration

Memory Conguration

This section displays memory status such as Current Memory Mode,

Memory Speed, Mirroring and Sparing information.



DIMM Information

This feature displays information regarding the installed memory.

Memory Mode

The only option is Independent, a feature that allows for all DIMMs to be

available to the operating system.

DRAM RAPL Mode

RAPL which stands for Running Average Power Limit is a feature that

provides mechanisms to enforce power consumption limits on supported

processors The options are DRAM RAPL MODE0 , DRAM RAPL MODE1,

and Disabled.

DDR Speed

Use this option to force the system memory to run at a different frequency

than the default frequency. The available options are Auto, Force DDR-

800, Force DDR-1066, Force DDR-1333, Force DDR3-1600 and Force

SPD.

Channel Interleaving

This feature selects from the different channel memory interleaving meth-

ods. The options are Auto, 1 Way, 2 Way, 3 Way and 4 Way.

Rank Interleaving

This feature selects from the different rank memory interleaving methods.

The options are Auto, 1 Way, 2 Way, 3 Way, 4 Way and 8 Way.

Patrol Scrub

Patrol Scrubbing is a process that allows the CPU to correct correctable

memory errors detected on a memory module and send the correction to

the requestor (the original source). When this item is set to Enabled, the

North Bridge will read and write back one cache line every 16K cycles,

if there is no delay caused by internal processing. By using this method,

roughly 64 GB of memory behind the North Bridge will be scrubbed every

day. The options are Enabled and Disabled.

4-9

X9SRi/X9SRE Motherboard Series User’s Manual

Demand Scrub

Demand Scrubbing is a process that allows the CPU to correct correctable

memory errors found on a memory module. When the CPU or I/O issues

a demand-read command, and the read data from memory turns out to

be a correctable error, the error is corrected and sent to the requestor

(the original source). Memory is updated as well. Select Enabled to use

Demand Scrubbing for ECC memory correction. The options are Enabled

and Disabled.

Data Scrambling

This feature enables Data Scrambling. The options are Enabled and

Disabled.

Device Tagging

This feature enables Device Tagging. The options are Enabled and

Disabled.

Thermal Throttling

This feature selects from the different throttling methods. The options

are Disabled and CLTT.

CLTT - Closed Loop Thermal Throttling.



South Bridge Conguration

This item displays the current South Bridge Revision.

All USB Devices

This feature enables all USB ports/devices. The options are Enabled

and Disabled.

EHCI Controller 1 / EHCI Controller 2

This feature enables the Enhanced Host Controller Interface (EHCI). The

options are Enabled and Disabled.

Legacy USB Support

This feature enables support for legacy USB devices. Select Auto to dis-

able legacy support if USB devices are not present. Select Disable to

have USB devices available only for EFI applicatioins. The options are

Enabled, Disabled and Auto.

4-10

Chapter 4: AMI BIOS

Port 60/64 Emulation

This feature enables I/O port 60h/64h emulation support. This should be

enabled for complete USB keyboard legacy support for non-USB aware

Operating Systems. The options are Enabled, and Disabled.

EHCI Hand-Off

This item is for Operating Systems that does not support Enhanced Host

Controller Interface (EHCI) hand-off. When enabled, EHCI ownership

change will be claimed by the EHCI driver. The settings are Enabled

and Disabled.



SATA Conguration

When this submenu is selected, the AMI BIOS automatically detects the presence

of the IDE Devices and displays the following items:

SATA Port0~Port5

This item displays the information detected on the installed SATA drives on the

particular SATA port.

SATA Mode

This item selects the mode for the installed drives. The options are Disabled, IDE

Mode, AHCI Mode and RAID Mode. The following are displayed depending on

your selection:

IDE Mode

The following items are displayed when IDE Mode is selected:

Serial-ATA Controller 0~1

This feature is used to activate/deactivate the SATA controller, and sets the

compatibility mode. The options are Disabled, Enhanced and Compat-

ible. The default of Serial-ATA Controller 1 is Enhanced.

AHCI Mode

The following items are displayed when AHCI Mode is selected:

Aggressive Link Power Management

This feature Enables or Disables Agressive Link Power Management

support for Cougar Point B0 stepping and later. The options are Enabled

and Disabled.

4-11

X9SRi/X9SRE Motherboard Series User’s Manual

Port 0~5 Hot Plug

Set this item to Enabled to enable hot-plugging for the particular port.

The options are Enabled and Disabled.

Staggered Spin Up

Set this item to Enabled to enable Staggered Spin-up support. The

options are Enabled and Disabled.

RAID Mode

The following items are displayed when RAID Mode is selected:

Port 0~5 Hot Plug

Set this item to Enabled to enable hot-plugging for the particular port.

The options are Enabled and Disabled.



SCU Conguration

When this submenu is selected, the AMI BIOS automatically detects the presence

of the SAS SCU Devices and displays the following items:

Disable Storage Controller Unit (SCU)

Set this item to Enabled to activate the chipset's SCU devices. The options are

Enabled and Disabled.

OnChip SCU Option PROM

Set this item to Enabled to activate the onboard SAS option ROM. The options are

Enabled and Disabled.



PCIe/PCI/PnP Conguration

This feature allows the user to set the PCI/PnP congurations for the following items:

PCI ROM Priority

In case of multiple Option ROMs (Legacy and EFI-compatible), this feature speci-

es what ROM to launch. The options are Legacy ROM and EFI Compatible ROM.

PCI Latency Timer

This feature sets the latency Timer of each PCI device installed on a PCI bus. Se-

lect 64 to set the PCI latency to 64 PCI clock cycles. The options are 32 PCI Bus

Clocks, 64 PCI Bus Clocks, 96 PCI Bus Clocks, 128 PCI Bus Clocks, 160 PCI

Bus Clocks, 192 PCI Bus Clocks, 224 PCI Bus Clocks and 248 PCI Bus Clocks.

4-12

Chapter 4: AMI BIOS

Above 4G Decoding

Set this item to Enabled to activate 64-bit capable devices to be decoded above

the 4G address space. This works only if the system supports 64-bit PCI decoding.

The options are Enabled and Disabled.

PERR# Generation

Set this item to Enabled to allow PCI devices to generate PERR# error codes. The

options are Enabled and Disabled.

SERR# Generation

Set this item to Enabled to allow PCI devices to generate SERR# error codes. The

options are Enabled and Disabled.

Maximum Payload

This feature selects the setting for the PCIE maximum payload size. The options

are Auto, 128 Bytes, and 256 Bytes.

Maximum Read Request

This feature selects the setting for the PCIE maximum Read Request size. The

options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and

4096 Bytes.

ASPM Support

Set this item to the desired ASPM (Active State Power Management) level. The

options are Disabled, Auto and Force L0s.

Slot 1 PCI-X 133/100MHZ OPROM Slot 2 PCI-X 133/100MHZ OPROM Slot 3 PCI X 133/100MHZ OPROM Slot 4 PCI-E 3.0 x8 OPROM Slot 5 PCI-E 3.0 x4 OPROM Slot 6 PCI-E 3.0 x16 OPROM

Use this feature to enable or disable PCI-E or PCI-X slot Option ROMs. The options

are Disabled and Enabled.

Onboard LAN Option ROM Select

This feature selects whether to load the iSCSI or PXE onboard LAN option ROM.

The options are iSCSI and PXE.

Load Onboard LAN1 Option ROM / Load Onboard LAN2 Option ROM

This feature is to enable or disable the onboard option ROMs. The options are Dis-

abled and Enabled. The default for LAN 1 is Enabled. Default for LAN 2 is Disabled.

4-13

X9SRi/X9SRE Motherboard Series User’s Manual

Load Onboard SAS Option ROM

This feature selects whether to load the SAS option ROM. The options Enabled

and Disabled.

VGA Priority

This option allows the user to specify which graphics controller to be used as the

primary boot device. The options are Onboard and Offboard.



Super IO Device Conguration



Serial Port 1 Conguration / Serial Port 2 Conguration

Serial Port 1 / Serial Port 2

Select Enabled to enable the onboard serial port. The options are Enabled

and Disabled.

Serial Port 1 Settings / Serial Port 2 Settings

This option species the base I/O port address and the Interrupt Request

address of Serial Port 1 and Serial Port 2. Select Disabled to prevent the

serial port from accessing any system resources. When this option is set to

Disabled, the serial port becomes unavailable.

The options for Serial Port 1 are:

Auto,

IO=3F8h; IRQ=4;

IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;

IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;

IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;

IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;

The options for Serial Port 2 are:

Auto,

IO=2F8h; IRQ=3;

IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;

IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;

IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;

IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;

4-14

Chapter 4: AMI BIOS



Serial Port Console Redirection

COM1, COM2, SOL Console Redirection

Use this feature to enable console redirection for COM1, COM2, and SOL ports. The

options are Enabled and Disabled. The default for COM1 and COM2 is Disabled.

The default for SOL is Enabled.



Console Redirection Settings

Congure the following options for the Console Redirection Settings. The

most common settings are set as default:

Terminal Type : Select ANSI, VT100, VT100+, or VT-UTF8

Bits per Second (BPS): 9600, 19200, 38400, 57600, or 115200

Data Bits: 8 or 7

Parity: None, Even, Odd, Mark, or Space

Stop Bits: 1 or 2

Flow Control: None or Hardware RTS/CTS

VT-UTF8 Combo Key Support: Enabled or Disabled

Recorder Mode: Disabled or Enabled

Resolution 100x31: Disabled or Enabled

Legacy OS Redirection Resolution: 80x24 or 80x25

PuTTY Keypad: VT100, Linux, XTerm86, SCO, ESCN, VT400

Serial Port for Out-of-Band Management / Windows Emergency

Management Services (EMS)

Use this feature to enable console redirection.

Console Redirection

Use this feature to enable console redirection for Serial Port Out-of-Band Manage-

ment / Windows Emergency Management Services (EMS) ports. The options are

Enabled and Disabled.



Console Redirection Settings

Congure the following options for the Console Redirection Settings. The

most common settings are set as default:

Out-of-Band Mgmt Port: COM1, COM2, and SOL

Terminal Type: Select ANSI, VT100, VT100+, or VT-UTF8

4-15

X9SRi/X9SRE Motherboard Series User’s Manual

Bits per Second (BPS): 9600, 19200, 57600, or 115200

Flow Control: None, Hardware RTS/CTS, Software Xon/Xoff

Data Bits: 8 or 7

Parity: None, Even, Odd, Mark, or Space

Stop Bits: 1 or 2



ACPI Settings

Use this feature to congure Advanced Conguration and Power Interface (ACPI)

power management settings for your system.

ACPI Sleep State

This setting allows you to congure the ACPI (Advanced Conguration and Power

Interface) sleep state for your system when it is in the Suspend mode. The options

are Suspend Disabled, S1 (CPU Stop Clock).

High Precision Event Timer

Select Enabled to activate the High Performance Event Timer (HPET) that produces

periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in

synchronizing multimedia streams, providing smooth playback and reducing the de-

pendency on other timestamp calculation devices, such as an x86 RDTSC Instruc-

tion embedded in the CPU. The High Performance Event Timer is used to replace

the 8254 Programmable Interval Timer. The options are Enabled and Disabled.



ME Subsystem

This item displays the ME Subsystem information.

4-16

Chapter 4: AMI BIOS

4-4 Event Logs



Change SmBIOS Event Log Settings

Smbios Event Log

Change this item to enable or disable all features of the Smbios Event Logging

during boot. The options are Enabled and Disabled.

Runtime Error Logging Support

Change this item to enable or disable runtime error logging. The options are En-

abled and Disabled.

Memory Correction Error Threshold

Change this item to dene the system's memory correction error threshold. Directly

enter a numeric value, default is 10.

PCI Error Logging Support

Change this item to enable or disable runtime error logging. The options are En-

abled and Disabled.

Erase Event Log

This option erases all logged events. The options are No, Yes, Next reset and

Yes, Every reset.

When Log is Full

This option automatically clears the Event Log memory of all messages when it is

full. The options are Do Nothing and Erase Immediately.

4-17

X9SRi/X9SRE Motherboard Series User’s Manual

Log System Boot Event

This option toggles the System Boot Event logging to enabled or disabled. The

options are Disabled and Enabled.

MECI

The Multiple Event Count Increment (MECI) counter counts the number of oc-

curences a duplicate event must happen before the MECI counter is incremented.

This is a numeric value. The default value is 1.

METW

The Multiple Event Time Window (METW) denes number of minutes must pass

between duplicate log events before MECI is incremented. This is in minutes, from

0 to 99. The default value is 60.

View SmBIOS Event Log

This feature displays the contents of the SmBIOS Event Log.

4-18

Chapter 4: AMI BIOS

4-5 IPMI (X9SRi-F, X9SRi-3F, X9SRE-F, X9SRE-3F Only)

Intelligent Platform Management Interface (IPMI) is a set of common interfaces that

IT administrators can use to monitor system health and to manage the system as a

whole. For more information on the IPMI specications, please visit Intel's website

at www.intel.com.

System Event Log

This feature is used to change the Sytem Event Log (SEL) conguration.

SEL Components - Change this item to enable or disable all features of System

Event Logging. The options are Enabled and Disabled. When Enabled, the

following can be congured:

Erase SEL - This option erases all logged SEL events. The options are No, Yes,

On Next reset and Yes, On Every reset.

When SEL Full

This option automatically clears the System Event Log memory of all messages

when it is full. The options are Do Nothing and Erase Immediately.

Log EFI Status Codes

This option enables or disables the logging of Extensible Firmware Interface

(EFI) status codes. The options are Enabled and Disabled.

BMC Network Conguration

Set this feature to congure the IPMI LAN adapter with a network address.

4-19

X9SRi/X9SRE Motherboard Series User’s Manual

Update IPMI LAN Conguration

This feature allows the user to decide if the BIOS should congure the IPMI setting

at next system boot. The options are No and Yes. If the option is set to Yes, the

user is allowed to congure the IPMI settings at next system boot.

Conguration Source

This feature selects whether the IP address, Subnet Mask and Gateway Address

are automatically assigned by the network's DHCP server (Dynamic Host and Con-

guration Protocol) "Dynamic" or manually entered by the user "Static". If Static is

selected, the IP Address, Subnet Mask and Gateway Address must be manually

entered below. When Dynamic is selected, all the options below are automatically

assigned to the system by itself or by an external DHCP server.

The options are Static and DHCP. The following items are displayed when Static

is selected:

Station IP Address - Enter the IP address for this machine. This should be in

decimal and in dotted quad form (i.e., 192.168.10.253). The value of each three-

digit number separated by dots should not exceed 255.

Subnet Mask - Subnet masks tell the network which subnet this machine be-

longs to. The value of each three-digit number separated by dots should not

exceed 255.

Station MAC Address - MAC addresses are 6 two-digit hexadecimal numbers

(Base 16, 0 ~ 9, A, B, C, D, E, F) separated by dots (i.e., 00.30.48.D0.D4.60).

Gateway IP Address - Enter the Gateway or Router address this machine will

use (i.e., 192.168.10.1).

4-20

Chapter 4: AMI BIOS

4-6 Boot Settings

Use this feature to congure Boot Settings:

Boot Options Priorities

This feature allows the user to specify which devices are boot devices and the order

of priority from which the systems boots during startup.

Boot Option #1, Boot option #2, etc.

The settings are Built-in EFI Shell, [any detected boot device] and Disabled.

Network Devices

This option sets the order of the legacy network devices detected by the motherboard.



Delete Boot Option

This feature allows the user to delete a previously dened boot device from which

the systems boots during startup.

The settings are Built-in EFI Shell, and [any pre dened boot device]

4-21

X9SRi/X9SRE Motherboard Series User’s Manual

4-8 Security Settings

• If the Administrator password is dened ONLY - this controls access to the

BIOS setup ONLY.

• If the User's password is dened ONLY - this password will need to be entered

during each system startup or boot, and will also have Administrator rights in

the setup.

• Passwords must be at least 3 and up to 20 characters long.

Administrator Password

Press Enter to create a new, or change an existing Administrator password.

User Password:

Press Enter to create a new, or change an existing User password.

4-22

Chapter 4: AMI BIOS

4-8 Save & Exit

Select the Exit tab from the BIOS Setup Utility screen to enter the Exit BIOS Setup

screen.

Discard Changes and Exit

Select this option to quit the BIOS Setup without making any permanent changes

to the system conguration, and reboot the computer. Select Discard Changes and

Exit from the Exit menu and press <Enter>.

Save Changes and Reset

When you have completed the system conguration changes, select this option

to leave the BIOS Setup Utility and reboot the computer, so the new system con-

guration parameters can take effect. Select Save Changes and Exit from the Exit

menu and press <Enter>.

Save Changes

When you have completed the system conguration changes, select this option to

save any changes made. This will not reset (reboot) the system.

Discard Changes

Select this option and press <Enter> to discard all the changes and return to the

AMI BIOS Utility Program.

4-23

X9SRi/X9SRE Motherboard Series User’s Manual

Restore Optimized Defaults

To set this feature, select Restore Defaults from the Exit menu and press <Enter>.

These are factory settings designed for maximum system stability, but not for

maximum performance.

Save As User Defaults

To set this feature, select Save as User Defaults from the Exit menu and press <En-

ter>. This enables the user to save any changes to the BIOS setup for future use.

Restore User Defaults

To set this feature, select Restore User Defaults from the Exit menu and press <En-

ter>. Use this feature to retrieve user-dened settings that were saved previously.

Boot Override

Listed on this section are other boot options for the system (i.e., Built-in EFI shell).

Select an option and press <Enter>. Your system will boot to the selected boot

option.

4-24

Appendix A: POST Error Beep Codes

Appendix A

BIOS Error Beep Codes

During the POST (Power-On Self-Test) routines, which are performed each time

the system is powered on, errors may occur.

Non-fatal errors are those which, in most cases, allow the system to continue

with bootup. The error messages normally appear on the screen.

Fatal errors will not allow the system to continue to bootup. If a fatal error oc-

curs, you should consult with your system manufacturer for possible repairs.

These fatal errors are usually communicated through a series of audible beeps.

The numbers on the fatal error list correspond to the number of beeps for the

corresponding error.

A-1 BIOS Error Beep Codes

BIOS Error Beep Codes

Beep Code/LED Error Message Description

1 beep Refresh Circuits have been reset.

5 short beeps + 1 long
beep

8 beeps Display memory

OH LED On System OH System Overheat

Memory error No memory detected in the

read/write error

(Ready to power up)

system

Video adapter missing or with
faulty memory

A-1

X9SRi/X9SRE Motherboard Series User’s Manual

Notes

A-2
