Supermicro X6DH8-G2 Plus, X6DHE-G2 Plus User Manual

X6DH8-G2+
X6DHE-G2+

USER’S MANUAL

Revision 1.0c

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software, if any,
and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or
reduced to any medium or machine without prior written consent.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for
all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Manual Revision 1.0c
Release Date: Nov. 1, 2007

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.

Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2007 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

Preface

About This Manual

This manual is written for system integrators, PC technicians and

knowledgeable PC users. It provides information for the installation and use of

the

X6DHE-G2+ supports single or dual Intel

TM

Xeon

supports the Intel EM64T, the Demand-Based Switching (DBS) with Enhanced

Intel SpeedStep technology, providing the user with high effi ciency server platforms

that handle complex, simultaneous and escalating data transactions. Please refer

to the motherboard specifi cations pages on our web site (http://www.supermicro.

com/Product/motherboard) for updates on supported processors. This product is

intended to be professionally installed.

Manual Organization

X6DH8-G2+/X6DHE-G2+ motherboard. The X6DH8-G2+/

®

single-core/dual-core 64-bit 604 pin

processors at a 800 MHz front side bus. The X6DH8-G2+/X6DHE-G2+

Preface

Chapter 1 describes the features, specifi cations and performance of the mainboard

and provides detailed information about the chipset.

Chapter 2 provides hardware installation instructions. Read this chapter when

installing the processor, memory modules and other hardware components into

the system. If you encounter any problems, see Chapter 3, which describes

troubleshooting procedures for the video, the memory and the system setup stored

in CMOS.

Chapter 4 includes an introduction to BIOS and provides detailed information on

running the CMOS Setup utility.

Appendix A provides BIOS POST Messages.

Appendix B lists BIOS POST Codes.

Appendix C lists Software Installation Instructions.

Conventions Used in the Manual:

Special attention should be given to the following symbols for proper installation and
to prevent damage done to the components or injury to yourself:

Danger/Caution: Instructions to be strictly followed to prevent catastrophic

system failure or to avoid bodily injury.

Warning: Important information given to ensure proper system installation or

to prevent damage to the components.

Note: Additional Information given to differentiate various models or to ensure

correct system setup.

iii

X6DH8-G2+/X6DHE-G2+ User's Manual

Table of Contents

Preface

About This Manual ...................................................................................................... iii

Manual Organization ................................................................................................... iii

Conventions used in this Manual ................................................................................. iii

Chapter 1: Introduction

1-1 Overview ......................................................................................................... 1-1

Checklist ................................................................................................... 1-1

Contacting Supermicro ............................................................................. 1-2

X6DH8-G2+/X6DHE-G2+ Image ................................................ 1-3

X6DH8-G2+/X6DHE-G2+ Layout ............................................... 1-4

Quick Reference ...................................................................................... 1-5

Motherboard Features ................................................................................ 1-6

Intel E7520 (Lindenhurst) Chipset: System Block Diagram ................... 1-8

1-2 Chipset Overview ........................................................................................... 1-9

1-3 Special Features ........................................................................................... 1-10

Recovery from AC Power Loss .............................................................. 1-10

1-4 PC Health Monitoring ..................................................................................... 1-10

1-5 ACPI Features .............................................................................................. 1-11

1-6 Power Supply ............................................................................................... 1-12

1-7 Super I/O ........................................................................................................ 1-13

Chapter 2: Installation

2-1 Static-Sensitive Devices ................................................................................. 2-1

Precautions ................................................................................................ 2-1

Unpacking ................................................................................................ 2-1

2-2 Processor and Heatsink Installation ............................................................... 2-2

2-3 Installing DIMMs ............................................................................................. 2-6

2-4 Control Panel Connectors/I/O Ports ............................................................... 2-7

A. Back Panel Connectors/IO Ports ........................................................ 2-7

B. Front Control Panel .............................................................................. 2-8

C. Front Control Panel Pin Defi nitions ...................................................... 2-8

NMI Button .......................................................................................... 2-9

Power LED .......................................................................................... 2-9

HDD LED ......................................................................................... 2-10

NIC1/NIC2 LED Indicators ............................................................... 2-10

Overheat/Fan Fail LED .................................................................... 2-11

Power Fail LED ....................................................................................2-11

iv

Table of Contents

Reset Button .................................................................................... 2-12

Power Button ..................................................................................... 2-12

2-5 Connectors/IO Ports/Headers ......................................................................... 2-13

ATX Power Connector .......................................................................... 2-13

Processor Power Connector ................................................................. 2-13

Chassis Intrusion .................................................................................... 2-14

Universal Serial Bus (USB0/1) ................................................................ 2-14

Serial Ports ............................................................................................. 2-15

Extra Universal Serial Bus Headers ....................................................... 2-15

Fan Headers .......................................................................................... 2-16

ATX PS/2 Keyboard and Mouse Ports ..................................................... 2-16

Power LED/Speaker Header (JD1) ........................................................ 2-17

GLAN (Ethernet Port) ............................................................................... 2-17

Wake-On-Ring .......................................................................................... 2-18

Wake-On-LAN .......................................................................................... 2-18

SMB .......................................................................................................... 2-19

SMB Power .............................................................................................. 2-19

Power Fault .............................................................................................. 2-20

Alarm Reset .............................................................................................. 2-20

Overheat LED ........................................................................................... 2-21

3rd Power Supply Power Fault Detect ..................................................... 2-21

2-6 Jumper Settings ............................................................................................ 2-22

Explanation of Jumpers .......................................................................... 2-22

GLAN Enable/Disable ............................................................................ 2-22

CMOS Clear ........................................................................................... 2-23

Watch Dog ................................................................................................ 2-23

SCSI Enable/Disable ............................................................................... 2-24

SCSI Channel A/B Termination ................................................................ 2-24

VGA Enable .............................................................................................. 2-25

2-7 Onboard Indicators ....................................................................................... 2-26

GLAN LEDs .............................................................................................. 2-26

SCSI Channel Activity LED Indicators ..................................................... 2-26

2-8 Parallel Port, Floppy/Hard Disk Drive and SCSI Connections ..................... 2-27

Parallel Port Connector ........................................................................... 2-27

Floppy Connector .................................................................................... 2-28

IPMI 2.0 Socket ....................................................................................... 2-28

IDE Connectors ....................................................................................... 2-29

SCSI Connectors ..................................................................................... 2-30

v

X6DH8-G2+/X6DHE-G2+ User's Manual

Chapter 3: Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

Before Power On ....................................................................................... 3-1

No Power ................................................................................................... 3-1

No Video .................................................................................................. 3-1

Memory Errors ........................................................................................... 3-2

Losing the System’s Setup Confi guration ................................................ 3-2

3-2 Technical Support Procedures ....................................................................... 3-2

3-3 Frequently Asked Questions .......................................................................... 3-3

3-4 Returning Merchandise for Service ................................................................. 3-4

Chapter 4: BIOS

4-1 Introduction ....................................................................................................... 4-1

4-2 Running Setup ................................................................................................. 4-2

4-3 Main BIOS Setup ............................................................................................. 4-2

4-4 Advanced Setup ............................................................................................... 4-6

4-5 Security Setup ............................................................................................... 4-18

4-6 Boot Setup ...................................................................................................... 4-20

4-7 Exit .................................................................................................................. 4-21

Appendices:

Appendix A: BIOS POST Messages ..........................................................................A-1

Appendix B: BIOS POST Codes ................................................................................B-1

Appendix C: Installing Software Drivers and the Operating System .........................C-1

vi

Chapter 1: Introduction

Chapter 1

Introduction

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged

leader in the industry. Supermicro boards are designed with the utmost attention to

detail to provide you with the highest standards in quality and performance. Check

that the following items have all been included with your motherboard. If anything

listed here is damaged or missing, contact your retailer.

The following items are included in the Retail Box.

One (1) Supermicro Mainboard

One (1) ribbon cable for IDE devices

One (1) fl oppy ribbon cable

One (1) Ultra 320 SCSI cable (X6DH8-G2+ only)

One (1) COM2 cable

One (1) USB (2-port) cable

One (1) SATA cable

One (1) I/O backpanel shield

One (1) Supermicro CD containing drivers and utilities

One (1) User's/BIOS Manual

One (1) Ultra 320 SCSI User's Manual (X6DH8-G2+ only)

1-1

X6DH8-G2+/X6DHE-G2+ User's Manual

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Asia-Pacifi c

Address: Super Micro, Taiwan

4F, No. 232-1 Liancheng Road

Chung-Ho 235, Taipei Hsien, Taiwan, R.O.C.

Tel: [phone]

Fax: [phone]

Web Site: www.supermicro.com.tw

Technical Support:

Email: [e-mail]

Tel: [phone], ext.132 or 139

1-2

Chapter 1: Introduction

Figure 1-1. X6DH8-G2+/X6DHE-G2+ Image

Note: The drawings and pictures shown in this manual were based on the latest

PCB Revision available at the time of publishing of the manual. The motherboard

you’ve received may or may not look exactly the same as the graphics shown

in the manual.

1-3

X6DH8-G2+/X6DHE-G2+ User's Manual

Figure 1-2. X6DH8-G2+/X6DHE-G2+ Motherboard Layout

(not drawn to scale)

KB/
Mouse

USB0/1

COM1

Parrallel

VGA

J5

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN
Enable

J9

J8

J6

Port

JLAN1

J23

JLAN1

JLAN2

JPG1

JPL1

Fan6

VGA
Enable

J14

J13

J15

J16

J17

X8 PCI-Epx #6

X8 PC

X4 PCI-Epx #4

Fan5

J32
4-Pin
PWR

J1B4

24-Pin

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM

2B

(Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM

4B (Bank 4)

DIMM 4A (Bank 4)

SEPC

Super

I/O

USB4

J11

®

J33

UPER X6DH8-G2+

S

I-Epx #5

PCI-X #3 133 MHz

PCI-X #2 100 MHz

ATX PWR

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Force PWR ON

Clr
CMOS

JWD

JBT1

WD Ena.

J27

J7

COM2

BIOS

PXH

J20

JPA1

CPU 1

CPU 2

IPMI

SCSI
Enable

7902

SCSI

Fan7

SI/O

CTRL

PWR
SMBus

JP13

Fa

n8

PW

J24

Fault

3rd PS
Alarm

JP8

JL1

Fan3

Floppy

8-pin
PWR

JP12

CH Intru

IDE2

J4

J1D1

Fan1

JF1

FP Control

JD1

SPK

PW LED

JP15

LE1

Fan2

OH

JOH1

JP14

Alrm

Reset

IDE1

J3

SCSI CH A

Battery

PCI-X #1 100 MHz ZCR

J12

WOR

JWOR

JWOL

WOL

Speaker

SMBUS

J22

USB2/3

JD2

SATA0

JS1

SATA1

JS2

DA2

JPA2
JPA3

DA1

SCSI CHA Term.

SCSI CHB Term.

SCSI CH B

Ultra 320

JA2

JA1

Notes:

1. Jumpers not indicated are for test purposes only.

2. See Chapter 2 for detailed information on jumpers, I/O ports and

JF1 front panel connections.

3. " " indicates the location of Pin 1.

4. SCSI is for the X6DH8-G2+ only

5. SEPC: Supermicro Enhanced Power Connector, specially designed to support

Supermicro 2U Riser Card (CSE-RR2UE-AX) only.

6. When the LE1 LED is on, the 5V Standby PWR is on. Maker sure to unplug
the power cord before installing or removing components.

7. Be sure to install the Zero Channel RAID card (ZCR) in the Green Slot.

1-4

Ultra 320

Fan4

Chapter 1: Introduction

Quick Reference ( X6DH8-G2+/X6DHE-G2+)
(Refer to Chapter 2 for detailed information)

Jumper Description Default Setting

JBT1 CMOS Clear See Chapter 2

JP12 PWR Fault See Chapter 2

JP13 3rd PW Supply Fail Alarm Enable Off (Disabled)

JP14 Alarm Reset Off (Disabled)

JPA1 SCSI Controller Enable Pins 1-2 (Enabled)(Note)

JPA2, JPA3 SCSI CHA(JPA2),CHB(JPA3)Term.En Off (Enabled)(Note)

JPF Force PWR On Off (Normal)

JPG1 VGA Enable Pins 1-2 (Enabled)

JPL1 GLAN Enable/Disable Pins 1-2 (Enabled)

JWD Watch Dog Pins 1-2 (Reset)

Connector Description

ATX PWR (J1B4) Primary ATX PWR Connector

Aux. PWR (J32) +12V 4-pin Auxiliary System PWR (Required)

CPU PWR(J1D1) +12 V 8-pin CPU PWR Connector (Required)

COM1 (J6)/COM2 (J7) COM1/COM2 Serial Port Connectors

FAN 1-8 Fans 1-6 system fans,Fan7:CPU1Fan, Fan8:CPU2 Fan

DIMM#1A-DIMM#4B Memory DDRII Slots

GLAN 1/2 (JLAN1/2) G-bit Ethernet Ports

J3/J4 IDE1/2 Hard Disk Drive Connectors

J5 VGA Connector

J9 Keyboard/Mouse

J20 IPMI 2.0 Socket

J22 System Management Bus Header

J23 Parallel (Printer) Port

J24 Power System Management Header

JA1/JA2 SCSI Channel A/Channel B Connectors(Note)

JD1 PWR LED(pins1-3)/Speaker Header (pins 4-7)

JF1 Front Control Panel Connector

JL1 Chassis Intrusion Header

JOH1 Overheat LED

JP8 Floppy Disk Drive Connector

JS1/JS2 Intel SATA 0/1 Connectors

JWOL Wake-on-LAN Header

JWOR Wake-on-Ring Header

USB 0/1 (J8) Back Panel USB Ports 0-1

USB 2/3(JD2)/USB 4(J11)Front Panel Universal Serial Bus Headers

Indicator Description

LE1 Power LED

DA1/DA2 SCSI CH A LED (DA1)/SCSI CH B LED(DA2) (Note)

(Note: for X6DH8-G2+ only)

1-5

X6DH8-G2+/X6DHE-G2+ User's Manual

Motherboard Features

CPU

• Single or dual Intel

®

Xeon single-core/dual-core 64-bit 604-pin processors at a

front side (system) bus speed of 800 MHz.

Memory

• Eight 240-pin DIMM sockets supporting up to 16 GB Registered ECC DDR2-400

(PC3200) Memory

Chipset

• Intel E7520 (North Bridge) + ICH5R + PXH (PCI Bus Hub)

Expansion Slots

• Two PCI-E slots at x8@4GB/sec (one with SEPC-Supermicro)

• One PCI-E at slot x4@2GB sec

• One PCI-X-133 slot

• Two PCI-X-100 slots (The Green Slot supports Zero Channel RAID (ZCR).

BIOS

• 8 Mb Phoenix

®

Flash ROM

• DMI 2.1, PCI 2.2, ACPI 1.0, Plug and Play (PnP), SMBIOS 2.3, PCI-X 1.0.

PC Health Monitoring

• Onboard voltage monitors for CPU cores, chipset voltage, 3.3V, +5V, +12V and

3.3V standby

• Fan status monitor

• CPU/chassis temperature monitors

• Environmental temperature monitor and control

• CPU slow-down on temperature overheat

• CPU thermal trip support for processor protection

• Power-up mode control for recovery from AC power loss

• Auto-switching voltage regulator for CPU core

• System overheat LED and control

• Chassis intrusion detection

• System resource alert

1-6

Chapter 1: Introduction

ACPI Features

• Microsoft OnNow

• ACPI/ACPM Power Management

• Wake-On Ring (WOR) Header

• Internal/External Modem Ring On

• Wake-On LAN (WOL) Header

• Slow blinking LED for suspend state indicator

• Main switch override mechanism

Onboard I/O

• Adaptec 7902 dual-channel Ultra 320 SCSI (X6DH8-G2+ only)

• One IPMI 2.0 socket

• Intel Gigabit 82546GB dual-port Ethernet controller (PCI-X-133)

• 2 EIDE Ultra DMA/100 bus master interfaces

• 2 SATA ports (w/RAID0, RAID1, JBOD support)

• 1 fl oppy port interface

• 2 serial ports

• 1 EPP/ECP Parallel Port

• PS/2 mouse and PS/2 keyboard ports

• Up to 5 USB 2.0 (Universal Serial Bus) (2 ports, 3 Headers)

• Super I/O: Winbond W83627HF w/Hardware Monitor support: W83792D

Other

• External modem ring-on

• Wake-on-LAN (WOL)

• Console redirection

• Onboard Fan Speed Control by Thermal Management via BIOS

CD/Diskette Utilities

• BIOS fl ash upgrade utility and device drivers

Dimensions

• ATX Ext. 12" x 13.05" (304.8 x 331.5 mm)

1-7

X6DH8-G2+/X6DHE-G2+ User's Manual

MCH

CPU 2

CPU 1

ICH5

HUB

DDRII-400

PCI (32-BIT)

A

PXH

B

PCI E. A (X8)

1 PCI-X

SLOT
ZCR

SCSI

SLOT

7902

1 PCI-X

PCI-X(133MHz)

Gbit LAN

SLOT

1 PCI-X

J13

PCI-X(100MHz)

J14

J12

ANVIK

1 PCI-EXP

SLOT
J17

PCI-E B (X8

)

PCI-E C (X8 )

J15

1 PCI-E

SLOT

1 PCI-E

J16

SLOT

4 DIMMs

IDE

PRI/SEC

UDMA/100

VGA

X4

X4

4 DIMMs

0, 1

SATA

SATA

LPC BUS

USB

USB PORT

0,1,2,3,4,5

BMC CON.

LPCS I/O

FWH

LPCS I/O

MS.

FDD.

H/W

SER.1
SER.2

KB.

MONITOR

4 DDR II -

4 DDR II -

DDRII-400

Parallel
Port

1 PCI-X

SLOT
J13

SCSI
7902

1 PCI-X

SLOT
ZCR
J12

1 PCI-X

SLOT
J14

Gbit LAN

ANVIK

PCI-X(100MHz)

PCI-X(133MHz)

1 PCI-E

SLOT
J15

1 PCI-E

SLOT
J16

1 PCI-EXP

PRI/SEC

USB PORT

0,1,2,3,4,5

PXH

SLOT
J17

IDE

SATA

0, 1

X4

PCI E. A (X8)

X4

PCI-E B (X8

PCI-E C (X8 )

UDMA/100

SATA

USB

CPU 1

)

CPU 2

MCH

HUB

ICH5

LPCS I/O

DDRII-400

DDRII-400

PCI (32-BIT)

LPC BUS

BMC CON.

4 DDR II -

4 DIMMs

4 DDR II -

4 DIMMs

VGA

FWH

LPCS I/O

Note: This is a general block diagram. Please see the previous Motherboard Features
pages for details on the features of each motherboard.

KB.
MS.

Figure 1-3. Block Diagram of the E7520 Lindenhurst Chipset

FDD.

SER.1
SER.2

H/W

MONITOR

Parallel
Port

1-8

Chapter 1: Introduction

1-2 Chipset Overview

Built upon the functionality and the capability of the E7520 Lindenhurst chipset,

The X6DH8-G2+/X6DHE-G2+ motherboard provides the performance and feature

set required for dual processor-based servers, with confi guration options optimized

for communications, presentation, storage, computation or database applications.

The Intel E7520 Lindenhurst chipset consists of the following components: the

Lindenhurst Memory Controller Hub (MCH), the 82801ER I/O Controller Hub 5-R

(ICH5-R), and the Intel PCI-X Hub.

The E7520 Lindenhurst MCH supports single or dual Xeon processors with Front

Side Bus speeds of up to 800 MHz. Its memory controller provides direct connec-

tion to two channels of registered DDRII- 400 with a marched system bus address

and data bandwidths of up to 6.4GB/s. The Lindenhurst also supports the new

PCI Express high speed serial I/O interface for superior I/O bandwidth. The MCH

provides three confi gurable x8 PCI Express interfaces which may alternatively be

confi gured as two independent x4 PCI Express interfaces. These interfaces support

connection of the MCH to a variety of other bridges that are compliant with the PCI

Express Interface Specifi cation, Rev. 1.0a. The MCH interfaces with the 82801ER

I/O Controller Hub 5-R (ICH5R) via a dedicated Hub Interface supporting a peak

bandwidth of 266 MB/s using a x4 base clock of 66 MHz. The PXH provide con-

nection between a PCI Express interface and two independent PCI bus interfaces

that can be confi gured for standard PCI 2.2 protocol, as well as the enhanced high-

frequency PCI-X protocol. The PXH can be confi gured to support for 32- or 64-bit

PCI devices running at 33 MHz, 66 MHz, 100 MHz, and 133 MHz.

The ICH5R I/O Controller Hub provides legacy support similar to that of previous

ICH-family devices, but with extensions in RAID 0,1 support, Serial ATA Technology,

and an integrated ASF Controller. In addition, the ICH5R also provides various inte-

grated functions, including a two-channel Ultra ATA/100 bus master IDE controller,

USB 2.0 host controllers, an integrated 10/100 LAN controller, an LPC fi rmware hub

(FWH) and Super IO interface, a System Management Interface, a power manage-

ment interface, integrated IOxAPIC and 8259 interrupt controllers.

1-9

X6DH8-G2+/X6DHE-G2+ User's Manual

1-3 Special Features

Recovery from AC Power Loss

BIOS provides a setting for you to determine how the system will respond when AC

power is lost and then restored to the system. You can choose for the system to

remain powered off (in which case you must hit the power switch to turn it back on)

or for it to automatically return to a power- on state. See the Power Lost Control

setting in the Advanced BIOS Setup section (Peripheral Device Confi guration) to

change this setting. The default setting is Last State.

1-4 PC Health Monitoring

This section describes the PC health monitoring features of the X6DH8-G2+/

X6DHE-G2+. All have an onboard System Hardware Monitor chip that supports

PC health monitoring.

Onboard Voltage Monitors for the CPU Cores, +3.3V, +5V, +12V,

-12V and +3.3V Standby

An onboard voltage monitor will scan these voltages continuously. Once a voltage

becomes unstable, a warning is given or an error message is sent to the screen.

Users can adjust the voltage thresholds to defi ne the sensitivity of the voltage

monitor.

Fan Status Monitor via BIOS and SDIII

The PC health monitor can check the RPM status of the cooling fans. The onboard

CPU and chassis fans are controlled by Thermal Management via BIOS and Supero

Doctor III.

Environmental Temperature Control

The thermal control sensor monitors the CPU temperature in real time and will turn

on the thermal control fan whenever the CPU temperature exceeds a user-defi ned

threshold. The overheat circuitry runs independently from the CPU. It can continue

to monitor for overheat conditions even when the CPU is in sleep mode. Once it

detects that the CPU temperature is too high, it will automatically turn on the ther-

mal control fan to prevent any overheat damage to the CPU. The onboard chassis

thermal circuitry can monitor the overall system temperature and alert users when

the chassis temperature is too high.

CPU Fan Auto-Off in Sleep Mode

The CPU fan activates when the power is turned on. It continues to operate when

the system enters Standby mode. When in sleep mode, the CPU will not run at

full power, thereby generating less heat.

1-10

Chapter 1: Introduction

CPU Overheat LED and Fan Fail Control

This feature is available when the user enables the CPU overheat/Fan Fail warn-

ing function in the BIOS. This allows the user to defi ne an overheat temperature.

When this temperature is exceeded, both the overheat fan and the warning LED

are triggered.

System Resource Alert

This feature is available when used with Supero Doctor III in the Windows OS

environment or used with Supero Doctor II in Linux. Supero Doctor is used to

notify the user of certain system events. For example, if the system is running

low on virtual memory and there is insuffi cient hard drive space for saving the

data, you can be alerted of the potential problem. You can also confi gure Supero

Doctor to provide you with warnings when the system temperature goes beyond

a pre-defi ned range.

1-5 ACPI Features

ACPI stands for Advanced Confi guration and Power Interface. The ACPI specifi -

cation defi nes a fl exible and abstract hardware interface that provides a standard

way to integrate power management features throughout a PC system, including its

hardware, operating system and application software. This enables the system to

automatically turn on and off peripherals such as CD-ROMs, network cards, hard

disk drives and printers. This also includes consumer devices connected to the PC

such as VCRs, TVs, telephones and stereos.

In addition to enabling operating system-directed power management, ACPI

provides a generic system event mechanism for Plug and Play and an operating

system-independent interface for confi guration control. ACPI leverages the Plug

and Play BIOS data structures while providing a processor architecture-independent

implementation that is compatible with Windows 2000, Windows XP and Windows

Server 2003.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start blinking

to indicate that the CPU is in suspend mode. When the user presses any key, the

CPU will wake-up and the LED will automatically stop blinking and remain on.

Main Switch Override Mechanism

When an ATX power supply is used, the power button can function as a system

suspend button to make the system enter a SoftOff state. The monitor will be

suspended and the hard drive will spin down. Pressing the power button again

will cause the whole system to wake-up. During the SoftOff state, the ATX power

supply provides power to keep the required circuitry in the system alive. In case

the system malfunctions and you want to turn off the power, just press and hold

1-11

X6DH8-G2+/X6DHE-G2+ User's Manual

the power button for 4 seconds. This option can be set in the Power section of

the BIOS Setup routine.

External Modem Ring-On

Wake-up events can be triggered by a device such as the external modem ringing

when the system is in the SoftOff state. Note that external modem ring-on can only

be used with an ATX 2.01 (or above) compliant power supply.

Wake-On-LAN (WOL)

Wake-On-LAN is defi ned as the ability of a management application to remotely

power up a computer that is powered off. Remote PC setup, up-dates and asset

tracking can occur after hours and on weekends so that daily LAN traffi c is kept to

a minimum and users are not interrupted. The motherboard has a 3-pin header

(WOL) to connect to the 3-pin header on a Network Interface Card (NIC) that has

WOL capability. In addition, an onboard LAN controller can also support WOL

without any connection to the WOL header. The 3-pin WOL header is to be used

with a LAN add-on card only.

Note: Wake-On-LAN requires an ATX 2.01 (or above) compliant power supply.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and

reliable operation. It is even more important for processors that have high CPU

clock rates.

The SUPER X6DH8-G2+/X6DHE-G2+ accommodates ATX 24-pin power supplies.

Although most power supplies generally meet the specifi cations required by the

CPU, some are inadequate. You should use one that will supply at least 400W of

power. Your power supply must supply 1.5A for the Ethernet ports. The +12V, 4-pin

power connector (J32) is required to provide adequate power supply to the system.

Additionally, you should also use the onboard 12V 8-pin power connector (J1D1)

to support Intel Xeon CPUs. Failure to provide this extra power will result in CPU

instability. See Section 2-5 for details on connecting the power supply.

It is strongly recommended that you use a high quality power supply that meets ATX

power supply Specifi cation 2.02 or above. It must also be SSI compliant (info at

http://www.ssiforum.org/). Additionally, in areas where noisy power transmission is

present, you may choose to install a line fi lter to shield the computer from noise. It

is recommended that you also install a power surge protector to help avoid problems

caused by power surges.

1-12

Chapter 1: Introduction

1-7 Super I/O

The disk drive adapter functions of the Super I/O chip include a fl oppy disk drive

controller that is compatible with industry standard 82077/765, a data separator,

write pre-compensation circuitry, decode logic, data rate selection, a clock genera-

tor, drive interface control logic and interrupt and DMA logic. The wide range of

functions integrated onto the Super I/O greatly reduces the number of components

required for interfacing with fl oppy disk drives. The Super I/O supports 360 K, 720

K, 1.2 M, 1.44 M or 2.88 M disk drives and data transfer rates of 250 Kb/s, 500 Kb/s

or 1 Mb/s.It also provides two high-speed, 16550 compatible serial communication

ports (UARTs). Each UART includes a 16-byte send/receive FIFO, a programmable

baud rate generator, complete modem control capability and a processor interrupt

system. Both UARTs provide legacy speed with baud rate of up to 115.2 Kbps

as well as an advanced speed with baud rates of 250 K, 500 K, or 1 Mb/s, which

support higher speed modems.

The Super I/O supports one PC-compatible printer port (SPP), Bi-directional Printer

Port (BPP) , Enhanced Parallel Port (EPP) or Extended Capabilities Port (ECP).

The Super I/O provides functions that comply with ACPI (Advanced Confi guration

and Power Interface), which includes support of legacy and ACPI power manage-

ment through an SMI or SCI function pin. It also features auto power management

to reduce power consumption.

1-13

X6DH8-G2+/X6DHE-G2+ User's Manual

Notes

1-14

Chapter 2: Installation

Chapter 2

Installation

2-1 Static-Sensitive Devices

Electrostatic-Discharge (ESD) can damage electronic com ponents. To prevent dam-

age to your system board, it is important to handle it very carefully. The following

measures are generally suffi cient to protect your equipment from ESD.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing the board from the antistatic

bag.

• Handle the board by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the motherboard and peripherals back into their antistatic bags when not in

use.

• For grounding purposes, make sure your computer chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

• Use only the correct type of onboard CMOS battery. Do not install the onboard

upside down battery to avoid possible explosion.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static damage. When

unpacking the board, make sure the person handling it is static protected.

2-1

X6DH8-G2+/X6DHE-G2+ User's Manual

2-2 Processor and Heatsink Installation

When handling the processor package, avoid placing direct pressure
on the label area of the fan. Also, do not place the motherboard on a

!

IMPORTANT: Always connect the power cord last and always remove it before add-

ing, removing or changing any hardware components. Make sure that you install

the processor into the CPU socket before you install the CPU (CEK) heat sink. To

adequately support the weight of CPU heat sinks, please install the X6DH8-G2+/

in a chassis that is compliant with the SSI EEB 3.5 Specifi cation.

CPU Installation

1. Lift the lever on the CPU socket: lift

the lever completely as shown on the

picture on the right; otherwise, you will

damage the CPU socket when power is

applied. (Install CPU1 fi rst.)

conductive surface, which can damage the BIOS battery and prevent the
system from booting up.

2. Insert the CPU in the socket, making

sure that pin 1 of the CPU aligns with

pin 1 of the socket (both corners are

marked with a triangle). When using

only one CPU, install it into CPU socket

#1 (socket #2 is automatically disabled

if only one CPU is used).

3. Press the lever down until you hear

the click so you can be sure that the

CPU is securely installed in the CPU

socket.

Socket lever

Pin1

Socket lever in the

locking Position

2-2

Chapter 2: Installation

CEK Heatsink Installation

IMPORTANT: Due to the weight of the CEK Passive Heatsink (which weights about

1KG), you need to have Heatsink Mounting plate installed on the chassis to prevent

damage to the CPU and the motherboard)

1. Do not apply any thermal compound to

the heatsink or the CPU die-the required

amount has already been applied.

2. Place the heatsink on top of the CPU so

that the four mounting holes are aligned with

those on the retention mechanism.

3. Screw in two diagonal screws (ie the #1

and the #2 screws) until just snug (-do not

fully tighten the screws to avoid possible

damage to the CPU.)

4. Finish the installation by fully tightening

all four screws.

CEK Passive Heat-

sink

Screw#1

Screw#2

2-3

X6DH8-G2+/X6DHE-G2+ User's Manual

To Un-install the Heatsink

(Caution! We do not recommend that the CPU or the heatsink be removed.

However, if you do need to un-install the heatsink, please follow the instruc­tions below to uninstall the heatsink to prevent damage done to the CPU or
the CPU socket.)

1. Unscrew and remove the heatsink screws

from the motherboard in the sequence as

show

in the picture on the right.

2. Hold the heatsink as shown

ture on the right and gently wriggle the

heatsink to loosen it from the CPU. (Do

not use excessive force when wriggling the

heatsink!!)

3. Once the CPU is loosened, remove the

heatsink from the CPU socket.

4. Clean the surface of the CPU and the

heatsink to get rid of the old thermal grease.

Reapply the proper amount of thermal

grease on the surface before you re-install

the CPU and the heatsink.

in the pic-

2-4

Figure 2-1. PGA604 Socket: Empty and with Processor Installed

!

Warning! Make

sure you lift the lever

completely when

installing the CPU;

otherwise, damage

to the socket or CPU

may occur.

Empty socket

Lever

Triangle

Processor

(installed)

Chapter 2: Installation

Mounting the Motherboard in the Chassis

All motherboards have standard mounting holes to fi t different types of chassis.

Make sure that the locations of all the mounting holes for both the motherboard

and the chassis match. Make sure that the metal standoffs click in or are screwed

in tightly. Then use a screwdriver to secure the motherboard onto the motherboard

tray. Please note that some components are very close to the mounting holes. Take

caution when installing or removing these components to prevent damage done to

the components.

Triangle

2-5

X6DH8-G2+/X6DHE-G2+ User's Manual

2-3 Installing DIMMs

Warning! Exercise extreme care when installing or removing

!

DIMM Installation (See Figure 2-2)

1. Insert the desired number of DIMMs into the memory slots, starting with Bank

1. The memory scheme is interleaved, so you must install two modules at a

time, beginning with Bank 1, then Bank 2, and so on.

2. Insert each DIMM module vertically into its slot. Pay attention to the notch along

the bottom of the module to prevent inserting the DIMM module incorrectly.

3. Gently press down on the DIMM module until it snaps into place in the slot.

Repeat for all modules (see step 1 above).

Memory Support

The X6DH8-G2+/X6DHE-G2+ supports up to 16 GB of Registered ECC DDR2-400

(PC3200) memory.

DIMM modules to prevent any possible damage. Please note that

the memory interleaved to improve performance.

1
N
A

JL

®

UPER X6DH8-G2+

S

Figure 2-2. Installing and Removing DIMMs

2

To Install: Insert module vertically and press down until it snaps
into place. Pay attention to the notch at the bottom.

To Remove:

Use your thumbs
to gently push
near the edge of
both ends of the
module. This
should release it
from the slot.

Release Tab

o ® i ®o ®DDRII®S ot

Release Tab

2-6

Chapter 2: Installation

2-4 Control Panel Connectors/IO Ports

The I/O ports are color coded in conformance with the PC 99 specifi cation. See
Figure 2-3 below for the colors and locations of the Back Panel I/O Connectors.

A. Back Panel Connectors/IO Ports

Figure 2-3. I/O Port Locations and Defi nitions

1
N
A

JL

®

UPER X6DH8-G2+

S

Back Panel Connectors

1. PS/2 Mouse (Green)

2. Keyboard (Purple)

3. Back Panel USB Port 0

4. Back Panel USB Port 1

5. Parallel Port (Printer)

6. COM Port 1 (Turquoise)

7. Video Port (Blue)

8. Gigabit LAN 1

9. Gigabit LAN 2

(See Section 2-5 for details.)

1

2

3

4

6 7

5

9

8

2-7

X6DH8-G2+/X6DHE-G2+ User's Manual

n

n

B. Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally located

on a control panel at the front of the chassis. These connectors are designed specifi -

cally for use with Supermicro server chassis. See Figure 2-4 for the descriptions of

the various control panel buttons and LED indicators. Refer to the following section

for descriptions and pin defi nitions.

Figure 2-4. JF1 Header Pins

1920

Ground

1
N

JLA

®

X6DH8-G2+

UPER

S

X

PWR LED

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

Power Supply Fail

Ground

Ground

1

2

Pwr

NMI

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset Butto

Power Butto

2-8

n

n

C. Front Control Panel Pin Defi nitions

NMI Button

The non-maskable interrupt button

header is located on pins 19 and 20

of JF1. Refer to the table on the right

for pin defi nitions.

Chapter 2: Installation

NMI Button

Pin Defi nitions (JF1)

Pin# Defi nition

19 Control

20 Ground

Power LED

The Power LED connection is located

on pins 15 and 16 of JF1. Refer to the

table on the right for pin defi nitions.

A. NMI LED

B. PWR LED

ATX PWR

Fan6

Port

JLAN1

JLAN1

JLAN2

JPL1

JPG1

Fan5

S

X8 PCI-Epx #6

I-Epx #5

X8 PC

X4 PCI-Epx #4

PCI-X #3 133 MHz

PCI-X

PCI-X #1 100 MHz ZCR

WOR

WOL

#2 100 MHz

KB/
Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

82546

GLAN
Enable

Parrallel

GLAN
CTLR

Battery

24-Pin
4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

UPER X6DH8-G2+

E7520

North
Bridge

SEPC

Super

ICH5R

I/O

South
Bridge

USB4

Speake

Power LED

Pin Defi nitions (JF1)

Pin# Defi nition

15 Vcc

16 Control

JPF

COM2

JBT1

JWD

BIOS

J27

PXH

SMBUS

USB2/3

r

SATA

Fan7

CPU 1

CPU 2

IPMI

SI/O

JPA1

7902

SCSI

CTRL

DA2

JPA2
JPA3

SATA1

0

PWR
SMBus

Fa

DA1

Ultra 320

JP13

n8

Fan3

Floppy

SCSI CH B

8-pin
PWR

JP12

Fan1

FP Control

SPK

PW LED

JP15

B

LE1

Fan2

JOH1

JP14

JL1

IDE1

IDE2

OH/Fan Fail LED

Power Supply Fail

SCSI CH A

320

Ultra

Fan4

Ground

PWR LED

HDD LED

NIC1 LED

NIC2 LED

Ground

Ground

1920

A

NMI

X

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset Butto

Power Butto

Pwr

1

2

2-9

X6DH8-G2+/X6DHE-G2+ User's Manual

n

n

HDD LED

The HDD LED connection is located

on pins 13 and 14 of JF1. Attach the

hard drive LED cable here to display

disk activity (for any hard drives on

the system, including SCSI, Serial ATA

and IDE). See the table on the right

for pin defi nitions.

NIC1/NIC2 LED Indicators

The NIC (Network Interface Control-

ler) LED connections for GLAN port1

and port2 are located on pins 9,10

and 11, 12 of JF1. Attach the NIC

LED cables to display network activity.

Refer to the tables on the right for pin

defi nitions.

HDD LED

Pin Defi nitions (JF1)

Pin# Defi nition

13 Vcc

14 HD Active

NIC1 LED

Pin Defi nitions (JF1)

Pin# Defi nition

11 Vcc

12 Ground

NIC2 LED

Pin Defi nitions (JF1)

Pin# Defi nition

9 Vcc

10 Ground

A. HDD LED

B. NIC1 LED

C. NIC2 LED

JPF

ATX PWR

Fan6

Port

JLAN1

JLAN1

JLAN2

JPL1

JPG1

Fan5

S

X8 PCI-Epx #6

I-Epx #5

X8 PC

X4 PCI-Epx #4

PCI-X #3 133 MHz

#2 100 MHz

PCI-X

PCI-X #1 100 MHz ZCR

WOR

WOL

KB/
Mouse

USB0/1

COM1

VGA

RAGE­X

82546

GLAN
Enable

Parrallel

GLAN1

GLAN2

GLAN
CTLR

Battery

24-Pin
4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

UPER X6DH8-G2+

E7520

North
Bridge

SEPC

Super

ICH5R

I/O

South
Bridge

USB4

Speake

JBT1

Fan7

CPU 1

CPU 2

IPMI

SI/O

COM2

JWD

BIOS

USB2/3

JPA1

PXH

7902

SCSI

CTRL

DA2

JPA2
JPA3

SATA1

0

SATA

J27

SMBUS

r

SMBus

Fa

DA1

Ultra 320

n8

JP13

Fan3

Floppy

SCSI CH B

PWR

JP12

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

A

JOH1

JP14

JL1

IDE2

B

C

IDE1

OH/Fan Fail LED

Power Supply Fail

SCSI CH A

320

Ultra

Fan4

Ground

X

PWR LED

HDD LED

NIC1 LED

NIC2 LED

Ground

Ground

1920

NMI

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset Butto

Power Butto

Pwr

1

2

8-pin

PWR

2-10

Overheat/Fan Fail LED (OH)

n

n

Connect an LED to the OH/Fan Fail

connection on pins 7 and 8 of JF1

to provide warnings when a system

overheat or a fan failure occurs.

Refer to the table on the right for pin

defi nitions.

Power Fail LED

The Power Fail LED connection is

located on pins 5 and 6 of JF1. Refer

to the table on the right for pin defi ni-

tions.

OH/Fan Fail LED

Pin Defi nitions (JF1)

Pin# Defi nition

7 Vcc

8 HD Active

PWR Fail LED

Pin Defi nitions (JF1)

Pin# Defi nition

5 PWR Fail LED-

6 PWR Fail LED+

PWR Fail Indicator Status

State Defi nition

Red PWR Failure

Chapter 2: Installation

OH/Fan Fail Indicator

Status

State Defi nition

Off Normal

On Overheat

Flashing Fan Fail

A. OH/Fan Fail LED

B. PWR Supply Fail

ATX PWR

Fan6

Port

JLAN1

JLAN1

JLAN2

JPL1

JPG1

Fan5

S

X8 PCI-Epx #6

I-Epx #5

X8 PC

X4 PCI-Epx #4

PCI-X #3 133 MHz

PCI-X

PCI-X #1 100 MHz ZCR

WOR

WOL

#2 100 MHz

KB/
Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

82546

GLAN
Enable

Parrallel

GLAN
CTLR

Battery

24-Pin
4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

UPER X6DH8-G2+

E7520

North
Bridge

SEPC

Super

ICH5R

I/O

South
Bridge

USB4

Speake

JPF

COM2

JBT1

JWD

BIOS

J27

PXH

SMBUS

USB2/3

r

SATA

Fan7

CPU 1

CPU 2

IPMI

SI/O

JPA1

7902

SCSI

CTRL

DA2

JPA2
JPA3

SATA1

0

PWR
SMBus

Fa

DA1

Ultra 320

JP13

n8

Fan3

Floppy

SCSI CH B

8-pin
PWR

JP12

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

JL1

IDE1

IDE2

OH/Fan Fail LED

Power Supply Fail

SCSI CH A

320

Ultra

Fan4

Ground

PWR LED

HDD LED

NIC1 LED

NIC2 LED

A

B

Ground

Ground

1920

NMI

X

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset Butto

Power Butto

Pwr

1

2

2-11

X6DH8-G2+/X6DHE-G2+ User's Manual

n

n

Reset Button

The Reset Button connection is lo-

cated on pins 3 and 4 of JF1. Attach

it to the hardware reset switch on the

computer case. Refer to the table on

the right for pin defi nitions.

Power Button

The Power Button connection is

located on pins 1 and 2 of JF1. Mo-

mentarily contacting both pins will

power on/off the system.

Reset Button

Pin Defi nitions (JF1)

Pin# Defi nition

3 Reset

4 Ground

Power Button

Pin Defi nitions (JF1)

Pin# Defi nition

1 PW_ON

2 Ground

A. Reset Button

B. PWR Button

JPF

ATX PWR

Fan6

Port

JLAN1

JLAN1

JLAN2

JPL1

JPG1

Fan5

S

X8 PCI-Epx #6

I-Epx #5

X8 PC

X4 PCI-Epx #4

PCI-X #3 133 MHz

#2 100 MHz

PCI-X

PCI-X #1 100 MHz ZCR

WOR

WOL

KB/
Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

82546

GLAN
Enable

Parrallel

GLAN
CTLR

Battery

24-Pin
4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

UPER X6DH8-G2+

E7520

North
Bridge

SEPC

Super

ICH5R

I/O

South
Bridge

USB4

Speake

JBT1

Fan7

CPU 1

CPU 2

IPMI

SI/O

COM2

JWD

BIOS

USB2/3

JPA1

PXH

7902

SCSI

CTRL

DA2

JPA2
JPA3

SATA1

0

SATA

J27

SMBUS

r

SMBus

Fa

DA1

Ultra 320

n8

JP13

Fan3

Floppy

SCSI CH B

PWR

JP12

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

JL1

IDE1

IDE2

OH/Fan Fail LED

Power Supply Fail

SCSI CH A

320

Ultra

Fan4

Ground

X

PWR LED

HDD LED

NIC1 LED

NIC2 LED

Ground

Ground

1920

NMI

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset Butto

A

Power Butto

Pwr

1

2

B

8-pin

PWR

2-12

2-5 Connectors/IO Ports/Headers

ATX Power Connector

The main power supply connector on

the X6DH8-G2+/X6DHE-G2+ meets

the SSI (Superset ATX) 24-pin speci-

fi cation. You must also connect the

4-pin (J32) power connector to your

power supply. See the table on the

right for pin defi nitions.

Chapter 2: Installation

ATX Power 24-pin Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition

13 +3.3V 1 +3.3V

14 -12V 2 +3.3V

15 COM 3 COM

16 PS_ON 4 +5V

17 COM 5 COM

18 COM 6 +5V

19 COM 7 COM

20 Res (NC) 8 PWR_OK

21 +5V 9 5VSB

22 +5V 10 +12V

23 +5V 11 +12V

24 COM 12 +3.3V

Processor Power Connector

In addition to the Primary ATX power

connector (above), the 12v 8-pin Pro-

cessor connector at J1D1 must also

be connected to your power supply.

SEPC

Super

I/O

USB4

®

A

24-Pin

ATX PWR

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

BIOS

PXH

SATA0

KB/

Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

GLAN
CTLR

JPL1

JLAN1

JLAN2

JPG1

C

Fan6

Fan5

4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

JPA1

SATA1

4-Pin 12V Connector

Pin Defi nitions

Pins Defi nition

1 & 2 Ground

3 & 4 +12V

B

PWR

Fan7

SMBus

JP12

JP13

CPU 1

CPU 2

JL1

Fan8

DA1

Ultra 320

Fan3

Floppy

SCSI CH B

SCSI

IPMI

7902

DA2

JPA2
JPA3

SI/O

CTRL

8-pin
PWR

IDE2

Fan1

A. 24-pin ATX PWR

FP Control

B. 8-pin Processor PWR

SPK

PW LED

C. 4-pin PWR

JP15

LE1

Fan2

JOH1

JP14

IDE1

SCSI CH A

Ultra 320

Fan4

8-Pin 12V Connector

Pin Defi nitions (JPW3)

Pins Defi nition

1 through 4 Ground

5 through 8 +12V

2-13

X6DH8-G2+/X6DHE-G2+ User's Manual

Chassis Intrusion

A Chassis Intrusion header is located

at JL1. Attach the appropriate cable to

inform you of a chassis intrusion.

Universal Serial Bus
(USB0/1)

Two USB 2.0 ports (JPUSB1) are

located beside the PS/2 keyboard/

mouse ports. USB0 is the bottom

connector and USB1 is the top con-

nector. See the table on the right for

pin defi nitions.

Chassis Intrusion

Pin Defi nitions (JL1)

Pin# Defi nition

1 Intrusion Input

2 Ground

Universal Serial Bus

Pin Defi nitions (USB0/1)

USB0
Pin # Defi nition

USB1
Pin # Defi nition

1 +5V 1 +5V

2 PO- 2 PO-

3 PO+ 3 PO+

4 Ground 4 Ground

5N/A 5 Key

ATX PWR

KB/
Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

JPL1

JLAN1

JLAN2

JPG1

B

WOR

WOL

Fan6

Fan5

4-Pin
PWR

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

24-Pin

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

SEPC

Super

I/O

USB4

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

BIOS

PXH

SATA0

JPA1

SATA1

CPU 1

CPU 2

7902

SCSI

IPMI

DA2

JPA2
JPA3

PWR

Fan7

SMBus

Fan8

SI/O

CTRL

DA1

Ultra 320

2-14

JP13

A

Fan3

Floppy

SCSI CH B

8-pin
PWR

JP12

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

JL1

IDE1

IDE2

SCSI CH A

Ultra 320

Fan4

A. Chassis Intrusion

B. USB 0/1

Chapter 2: Installation

Serial Ports

The COM1 (J6) and COM2 (J7) serial

ports are located under the paral-

lel port (COM1) and next to IPMI

(COM2). See the table on the right

for pin defi nitions.

Front Panel Universal Serial
Bus Headers

Extra USB headers (FPUSB2/

FPUSB3/FPUSB4) can be used for

front side USB access. You will need

a USB cable to use either connection.

Refer to the tables on the right for pin

defi nitions.

Serial Port Pin Defi nitions

Pin # Defi nition Pin # Defi nition

1 CD 6 DSR

2RD 7 RTS

3TD 8CTS

4DTR 9 RI

5 Ground 10 NC

Note: Pin 10 is included on the header (COM2)

but not on the port (COM1). NC indicates no

connection.

Front Panel Universal Serial Bus

Pin Defi nitions (USB2/3)

USB2
Pin # Defi nition

USB3
Pin # Defi nition

1 +5V 1 +5V

2 PO- 2 PO-

3 PO+ 3 PO+

4 Ground 4 Ground

5 Key 5 No connection

Front Panel USB (USB4)

KB/

Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

GLAN
CTLR

JPL1

JLAN1

JLAN2

JPG1

A

Fan6

Fan5

4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

SEPC

Super

I/O

USB4

®

24-Pin

D

ATX PWR

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

B

COM2

PXH

BIOS

C

SATA0

JPA1

SATA1

CPU 1

7902

SCSI

CPU 2

IPMI

JPA2
JPA3

Pin# Defi nition

1 Vcc

2 Data-

3 Data+

4 Ground

8-pin

PWR

Fan7

Fan8

SI/O

CTRL

DA2

DA1

Ultra 320

SMBus

JP13

Fan3

Floppy

SCSI CH B

JL1

JP12

PWR

IDE2

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

IDE1

SCSI CH A

Ultra 320

Fan4

5NA

A. COM 1

B. COM 2

C. FP USB 2/3

D. FP USB 4

2-15

X6DH8-G2+/X6DHE-G2+ User's Manual

Fan Headers

The X6DH8-G2+/X6DHE-G2+ has

eight fan headers (Fan1 to Fan8).

Fan 7 is designated CPU Fan1 and

Fan8, CPU Fan 2. Pins 1-3 of these

fan headers are backward compatible

with the traditional 3-pin fans. See the
table on the right for pin defi nitions.

(The onboard fan speed is controlled

by Thermal Management via BIOS. To

activate Fan Speed Control, please

refer to "Hardware Monitoring" in the

Advanced Setting.)

ATX PS/2 Keyboard and
PS/2 Mouse Ports

The ATX PS/2 keyboard and PS/2

mouse are located at J9. See the

table at right for pin defi nitions. (See

Figure 2-3 for the locations of each.)

4-pin Fan Header

Pin Defi nitions

Pin# Defi nition

1 Ground (black)

2 +12V (red)

3 Tachometer

4 PWR_Control

PS/2 Keyboard and

Mouse Port Pin

Defi nitions

Pin# Defi nition

1 Data

2NC

3 Ground

4 VCC

5 Clock

6NC

KB/
Mouse

USB0/1

COM1

Parrallel

VGA

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN

Enable

Battery

I

Port

JLAN1

JLAN1

JLAN2

JPL1

JPG1

E

F

Fan6

Fan5

4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

SEPC

Super

I/O

USB4

G

24-Pin

®

E7520

North
Bridge

JBT1

COM2

JWD

BIOS

J27

PXH

SMBUS

USB2/3

SATA0

r

ICH5R

South
Bridge

Speake

JPA1

SATA1

CPU 1

CPU 2

7902

SCSI

IPMI

H

DA2

JPA2
JPA3

Fan7

Fan8

SI/O

CTRL

DA1

Ultra 320

JPF

ATX PWR

PWR
SMBus

JP13

C

Fan3

Floppy

SCSI CH B

8-pin
PWR

JP12

A

Fan1

B

A. Fan 1

B. Fan 2

C. Fan 3

D. Fan 4

E. Fan 5

F. F a n 6

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

JL1

G. Fan 7 (CPU Fan 1)

IDE2

IDE1

H. Fan 8 (CPU Fan 2)

I. Keyboard/Mouse

SCSI CH A

Ultra 320

D

Fan4

2-16

Power LED/Speaker

On the JDI header, pins 1-3 are for

a power LED and pins 4-7 are for

the speaker. See the table on the

right for speaker pin defi nitions. Note:

The speaker connector pins are for

use with an external speaker. If you

wish to use the onboard speaker, you

should close pins 6-7 with a jumper.

GLAN (Giga-bit Ethernet
Ports)

Chapter 2: Installation

Speaker Connector

Pin Setting Defi nition

Pins 6-7 Internal Speaker

Pins 4-7 External Speaker

Two G-bit Ethernet ports are located

beside the VGA port on the IO back-

plane. This port accepts RJ45 type

cables.

JPF

ATX PWR

KB/
Mouse

USB0/1

COM1

Parrallel

VGA

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN
Enable

Battery

Port

JLAN1

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

UPER X6DH8-G2+

S

B

C

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

PCI-X #3 133 MHz

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

24-Pin
4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

SEPC

Super

I/O

USB4

E7520

North
Bridge

ICH5R

South
Bridge

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

BIOS

PXH

SATA0

JPA1

SATA1

CPU 1

7902

SCSI

CPU 2

IPMI

DA2

JPA2
JPA3

SI/O

CTRL

Fan7

PWR
SMBus

Fan8

DA1

Ultra 320

JP13

A

Fan3

Floppy

SCSI CH B

8-pin
PWR

JP12

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

JL1

IDE1

IDE2

SCSI CH A

Ultra 320

Fan4

A. PWR LED/Speaker

B. GLAN 1

C. GLAN 2

2-17

X6DH8-G2+/X6DHE-G2+ User's Manual

Wake-On-Ring

The Wake-On-Ring header is des-

ignated JWOR. This function allows

your computer to wake up when re-

ceiving an incoming call to the modem

in suspend state. See the table on the

right for pin defi nitions. You must have

a Wake-On-Ring card and cable to

use this feature.

Wake-On-LAN

The Wake-On-LAN header is desig-

nated JWOL. See the table on the

right for pin definitions. You must

enable the LAN Wake-Up setting in

BIOS to use this feature. You must

also have a LAN card with a Wake-

on-LAN connector and cable.

Wake-On-Ring

Pin Defi nitions

(JWOR)

Pin# Defi nition

1 Ground (Black)

2 Wake-up

Wake-On-LAN

Pin Defi nitions

(JWOL)

Pin# Defi nition

1 +5V Standby

2 Ground

3 Wake-up

ATX PWR

KB/
Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

4-Pin
PWR

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

A

WOL

B

24-Pin

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

SEPC

Super

I/O

USB4

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

BIOS

PXH

SATA0

JPA1

SATA1

CPU 1

CPU 2

7902

SCSI

IPMI

DA2

JPA2
JPA3

PWR

Fan7

SMBus

Fan8

SI/O

CTRL

DA1

Ultra 320

2-18

JP13

Fan3

Floppy

SCSI CH B

8-pin
PWR

JP12

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

JL1

IDE1

IDE2

SCSI CH A

Ultra 320

Fan4

A. Wake-On-Ring

B. Wake-On-LAN

Chapter 2: Installation

SMB

A System Management Bus header is

located at J22. Connect the appropri-

ate cable here to utilize SMB on your

system.

SMB Power (I

2

C)

Connector

I2C Connector (J24), located between

Fan7 Header and the PWR Fault

header, monitors the status of PWR

Supply, Fan and system tempera-

ture.

SMB Header

Pin Defi nitions

Pin# Defi nition

1 Data

2 Ground

3 Clock

4 No Connection

SMB PWR Header

Pin Defi nitions

Pin# Defi nition

1 Clock

2 Data

3 PWR Fail

4 Ground

5+3.3V

KB/

Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

GLAN
CTLR

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

SEPC

Super

I/O

USB4

®

24-Pin

ATX PWR

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

A

SMBUS

USB2/3

COM2

PXH

BIOS

SATA0

JPA1

SATA1

CPU 1

7902

SCSI

CPU 2

IPMI

JPA2
JPA3

DA2

B

PWR

Fan7

SMBus

Fan8

SI/O

CTRL

DA1

Ultra 320

2-19

JP13

Fan3

Floppy

SCSI CH B

JL1

JP12

8-pin
PWR

IDE2

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

IDE1

SCSI CH A

Ultra 320

Fan4

A. SMB

B. PWR SMB

X6DH8-G2+/X6DHE-G2+ User's Manual

Power Fault

Connect a cable from your power sup-

ply to the Power Fault header (JP12)

to provide warning of power supply

failure. This warning signal is passed

through the PWR_LED pin to indicate

an occurrence of power failure on the

chassis. You need to use this header

(JP12) with the Alarm Reset header

(JP14) together for it to work prop-

erly. See the table on the right for pin

defi nitions.

PWR Fault

Pin Defi nitions

Pin# Defi nition

1 Pin 1 Fail Signal

2 Pin 2 Fail Signal

3 Pin 3 Fail Signal

4 Alarm Reset

Note: This feature is only available when using

Supermicro's triple redundant power supplies.

Alarm Reset (JP14)

The system will notify you in the

event of a power supply failure. Use

this feature to clear alarm when

Supermicro's redundant power supply

units are installed in the chassis. If

you only have a single power supply

installed, you should leave the pins

open (the default setting) to prevent

false alarms. See the table on the right

for jumper settings.

JPF

ATX PWR

KB/
Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

4-Pin
PWR

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

24-Pin

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

SEPC

Super

I/O

USB4

E7520

North
Bridge

ICH5R

South
Bridge

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

BIOS

PXH

SATA0

JPA1

SATA1

CPU 1

CPU 2

7902

SCSI

IPMI

DA2

JPA2
JPA3

SI/O

CTRL

Fan7

Ultra 320

Alarm Reset

Pin Defi nitions

Jumper
Position Defi nition

Open Normal (De-

fault)

Short Clear Alarm

Note: This feature is only available when using

Supermicro's triple redundant power supplies.

A

8-pin

PWR

PWR

SMBus

JP12

JP13

Fan8

DA1

Fan3

Floppy

SCSI CH B

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

JL1

IDE1

IDE2

SCSI CH A

Ultra 320

Fan4

A. PWR Fault

B. Alarm Reset

B

2-20

Chapter 2: Installation

Overheat LED (JOH1)

The JOH1 header is used to connect an

LED to provide warning of chassis over-

heating. It is located beside Fan 2.

3rd PWR Supply PWR Fault
Detect (JP13)

The system can notify you in the event

of a power supply failure. This feature

is available when three power supply

units are installed in the chassis, with

one acting as a backup. If you only have

one or two power supply units installed,

you should disable this connection (the

default setting) to prevent false alarms.

Overheat LED

Pin Defi nitions

Jumper
Position Defi nition

1 5vDC

2 OH Active

3rd PWR Supply PWR

Fault

Pin Defi nitions

Jumper
Position Defi nition

Open Disabled

Closed Enabled

KB/

Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

GLAN
CTLR

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

SEPC

Super

I/O

USB4

®

24-Pin

ATX PWR

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

PXH

BIOS

SATA0

JPA1

SATA1

CPU 1

7902

SCSI

CPU 2

IPMI

JPA2
JPA3

DA2

PWR

Fan7

SMBus

Fan8

SI/O

CTRL

DA1

Ultra 320

2-21

B

JP13

Fan3

Floppy

SCSI CH B

JL1

JP12

8-pin
PWR

IDE2

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

IDE1

SCSI CH A

Ultra 320

Fan4

A. Overheat LED

B. 3rd PWR Supply PWR

Fault

A

X6DH8-G2+/X6DHE-G2+ User's Manual

2-6 Jumper Settings

Explanation of
Jumpers

To modify the operation of the

motherboard, jumpers can be used

to choose between optional settings.

Jumpers create shorts between two

pins to change the function of the

connector. Pin 1 is identifi ed with

a square solder pad on the printed

circuit board. See the motherboard

layout pages for jumper locations.

Note: On two pin jumpers, "Closed"

means the jumper is on and "Open"

means the jumper is off the pins.

Connector

Pins

Jumper

Cap

Setting

3 2 1

3 2 1

Pin 1-2 short

GLAN Enable/Disable

JPL1 enables or disables the GLAN

port(s) on the motherboard. See the

table on the right for jumper settings.

The default setting is enabled.

JPF

ATX PWR

KB/
Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

4-Pin
PWR

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

24-Pin

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

SEPC

Super

I/O

USB4

E7520

North
Bridge

ICH5R

South
Bridge

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

BIOS

PXH

SATA0

JPA1

SATA1

CPU 1

CPU 2

7902

SCSI

IPMI

DA2

JPA2
JPA3

SI/O

CTRL

Fan7

Ultra 320

GLAN Enable

Jumper Settings

Jumper Setting Defi nition

Pins 1-2 Enabled

Pins 2-3 Disabled

8-pin

PWR

PWR

SMBus

JP12

JP13

Fan8

Fan3

Floppy

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

JL1

IDE1

IDE2

SCSI CH A

A. GLAN Enable

A

DA1

SCSI CH B

Ultra 320

Fan4

2-22

Chapter 2: Installation

CMOS Clear

JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact

pads to prevent the accidental clearing of CMOS. To clear CMOS, use a metal

object such as a small screwdriver to touch both pads at the same time to short

the connection. Always remove the AC power cord from the system before clear-

ing CMOS. Note: For an ATX power supply, you must completely shut down the

system, remove the AC power cord and then short JBT1 to clear CMOS. Do not

use the PW_ON connector to clear CMOS.

Watch Dog

JWD controls Watch Dog, a system

monitor that takes action when a soft-

ware application hangs. Close pins

1-2 to reset the system if a program

freezes. Close pins 2-3 to generate a

non-maskable interrupt for the program

that hangs. (This requires software

implementation). Watch Dog must also

be enabled in the BIOS.

Watch Dog

Jumper Settings (JWD)

Jumper Setting Defi nition

Pins 1-2 Reset

Pins 2-3 NMI

Open Disabled

KB/

Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

GLAN
CTLR

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

4-Pin
PWR

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

24-Pin

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

SEPC

Super

I/O

USB4

ATX PWR

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

PXH

BIOS

SATA0

JPA1

SATA1

CPU 1

7902

SCSI

CPU 2

IPMI

JPA2
JPA3

DA2

PWR

Fan7

SMBus

Fan8

SI/O

CTRL

DA1

Ultra 320

2-23

JP13

Fan3

Floppy

SCSI CH B

JL1

JP12

8-pin
PWR

IDE2

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

IDE1

SCSI CH A

Ultra 320

Fan4

A. CMOS Clear

B. Watch Dog

A

B

X6DH8-G2+/X6DHE-G2+ User's Manual

SCSI Enable/Disable (For the
X6DH8-G2+ only)

Jumper JPA1 allows you to enable or dis-

able the SCSI headers. Jumper JPA1 is

for SCSI Channel A and SCSI Channel B.

The default setting is pins 1-2 to enable all

four headers. See the table on the right for

jumper settings.

SCSI CH A/B Termination
Enable/Disable (For the X6DH8-

G2+ only)

Jumpers JPA2 and JPA3 allow you to en-

able or disable termination for the SCSI

headers. Jumper JPA2 controls SCSI

channel A, and JPA3 is for SCSI channel

B. The default setting is open to enable

(terminate) both SCSI channels. Note: the

manufacture default setting is "Open". For

SCSI to function properly, please do not

change the default setting. See the table

on the right for jumper settings.

SCSI Enable/Disable

Jumper Settings

Jumper Setting Defi nition

Pins 1-2 Enabled

Pins 2-3 Disabled

SCSI channel Termination

Jumper Settings

Jumper Setting Defi nition

Open (Default) Enabled

Closed Disabled

ATX PWR

KB/
Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

4-Pin
PWR

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

24-Pin

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

SEPC

Super

I/O

USB4

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

BIOS

PXH

SATA0

JPA1

SATA1

CPU 1

CPU 2

7902

SCSI

IPMI

DA2

JPA2
JPA3

PWR

Fan7

SMBus

Fan8

SI/O

CTRL

DA1

Ultra 320

2-24

JP13

Fan3

Floppy

SCSI CH B

8-pin
PWR

JP12

Fan1

A. SCSI Enable

B. SCSI Channel A Termi-

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

JL1

IDE1

IDE2

nation Enable

C. SCSI Channel A Termi-

nation Enable

A

SCSI CH A

Fan4

B

C

Ultra 320

Chapter 2: Installation

VGA Enable/Disable

JPG1 enables or disables the VGA

Connector on the motherboard. See

the table on the right for jumper set-

tings. The default setting is enabled.

VGA Enable/Disable

Jumper Settings

Jumper Setting Defi nition

Pins 1-2 Enabled

Pins 2-3 Disabled

KB/

Mouse

USB0/1

COM1

Fan6

Fan5

4-Pin
PWR

24-Pin

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

UPER X6DH8-G2+

S

A

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

SEPC

Super

I/O

USB4

#3 133 MHz

®

VGA

GLAN
Enable

Parrallel

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

Battery

Port

JLAN1

JLAN1

JLAN2

JPL1

JPG1

WOR

WOL

ATX PWR

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

PXH

BIOS

SATA0

JPA1

SATA1

CPU 1

7902

SCSI

CPU 2

IPMI

JPA2
JPA3

DA2

PWR

Fan7

SMBus

Fan8

SI/O

CTRL

DA1

Ultra 320

2-25

JP13

Fan3

Floppy

SCSI CH B

JL1

JP12

8-pin
PWR

IDE2

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

IDE1

SCSI CH A

Ultra 320

Fan4

A. VGA Enable

X6DH8-G2+/X6DHE-G2+ User's Manual

2-7 Onboard Indicators

GLAN LEDs

There are two GLAN ports on the moth-

erboard. Each Gigabit Ethernet LAN port

has two LEDs. The yellow LED indicates

activity, while the power LED may be green,

amber or off to indicate the speed of the

connection. See the table at right for the

status associated with the second LED.

SCSI Channel Activity LED
Indicators (X6DH8-G2+ only)

Two LEDs (DA1, DA2) to indicate SCSI

activity are located near the SCSI controller

(AIC-7902) chip. DA1 indicates the activity

status of SCSI Channel A, and DA2 DA1

indicates the activity status of SCSI Channel

B. See the table at right for the functions

associated with each LED.

Link

LED

Activity

LED

Rear View (when facing the
rear side of the chassis)

GLAN Activity Indicator

LED Setting

Color Status Defi nition

Yellow Flashing Active

GLAN Link Indicator

LED Settings

LED Color Defi nition

Off No Connection or 10 Mbps

Green 100 Mbps

Amber 1 Gbps

SCSI channel Activity

LEDs (DA1, DA2)

LED Defi nition

DA1 Channel A Active

DA2 Channel B Active

ATX PWR

KB/
Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

4-Pin
PWR

UPER X6DH8-G2+

S

A

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

24-Pin

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

SEPC

Super

I/O

USB4

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

BIOS

PXH

SATA0

C

JPA1

SATA1

CPU 1

CPU 2

7902

SCSI

IPMI

DA2

JPA2
JPA3

PWR

Fan7

SMBus

Fan8

SI/O

CTRL

DA1

Ultra 320

2-26

JP13

Fan3

B

SCSI CH B

Floppy

JP12

8-pin
PWR

Fan1

A. GLAN1/GLAN2 ports

B. SCSI Channel A Activity

LED

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

JL1

IDE1

IDE2

SCSI CH A

Ultra 320

Fan4

C. SCSI Channel B Activity

LED

Chapter 2: Installation

2-8 Parallel Port, Floppy Drive, Hard Disk Drive, IPMI

2.0 and SCSI Connections

Note the following when connecting the fl oppy and hard disk drive cables:

• The fl oppy disk drive cable has seven twisted wires.

• A red mark on a wire typically designates the location of pin 1.

• A single fl oppy disk drive ribbon cable has 34 wires and two connectors to provide

for two fl oppy disk drives. The connector with twisted wires always connects to

drive A, and the connector that does not have twisted wires always connects to

drive B.

Parallel (Printer) Port Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition

Parallel (Printer) Port
Connector

The parallel (printer) port is located

at J23. See the table on the right for

pin defi nitions.

1 Strobe- 2 Auto Feed-

3 Data Bit 0 4 Error-

5 Data Bit 1 6 Init-

7 Data Bit 2 8 SLCT IN-

9 Data Bit 3 10 GND

11 Data Bit 4 12 GND

13 Data Bit 5 14 GND

15 Data Bit 6 16 GND

17 Data Bit 7 18 GND

19 ACK 20 GND

21 BUSY 22 Write Data

23 PE 24 Write Gate

25 SLCT 26 NC

KB/

Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

GLAN
CTLR

JPL1

JLAN1

JLAN2

JPG1

Fan6

A

WOR

WOL

Fan5

4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

SEPC

Super

I/O

USB4

#3 133 MHz

®

24-Pin

ATX PWR

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

PXH

BIOS

SATA0

JPA1

SATA1

CPU 1

7902

SCSI

CPU 2

IPMI

JPA2
JPA3

DA2

PWR

Fan7

SMBus

Fan8

SI/O

CTRL

DA1

Ultra 320

2-27

JP13

Fan3

Floppy

SCSI CH B

JL1

JP12

8-pin
PWR

IDE2

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

IDE1

SCSI CH A

Ultra 320

Fan4

A. Parallel Port

X6DH8-G2+/X6DHE-G2+ User's Manual

Floppy Connector

The fl oppy connector is located at

JP8. See the table below for pin

defi nitions.

IPMI 2.0 Socket

Floppy Drive Connector
Pin Defi nitions (Floppy)

Pin# Defi nition Pin # Defi nition

1 Ground 2 FDHDIN

3 Ground 4 Reserved

5 Key 6 FDEDIN

7 Ground 8 Index

9 Ground 10 Motor Enable

11 Ground 12 Drive Select B

13 Ground 14 Drive Select B

15 Ground 16 Motor Enable

17 Ground 18 DIR

19 Ground 20 STEP

21 Ground 22 Write Data

23 Ground 24 Write Gate

25 Ground 26 Track 00

27 Ground 28 Write Protect

29 Ground 30 Read Data

31 Ground 32 Side 1 Select

33 Ground 34 Diskette

There is an IPMI 2.0 Socket on

the motherboard. An IPMI 2.0 card

is needed for you to use this slot.

Refer to the layout below for the IPMI

Socket location.

JPF

ATX PWR

KB/
Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

4-Pin
PWR

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

24-Pin

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

SEPC

Super

I/O

USB4

E7520

North
Bridge

ICH5R

South
Bridge

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

BIOS

PXH

SATA0

JPA1

SATA1

CPU 1

CPU 2

7902

SCSI

B

IPMI

DA2

JPA2
JPA3

SI/O

CTRL

Fan7

Ultra 320

PWR
SMBus

Fan8

JP13

Fan3

Floppy

8-pin
PWR

JP12

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JL1

IDE1

IDE2

A. Floppy

B. IPMI 2.0

JP14

A

SCSI CH A

DA1

SCSI CH B

Ultra 320

Fan4

2-28

Chapter 2: Installation

IDE Connectors

IDE#1 and IDE#2 connectors

are located next to Floppy

Drive Connector (at J3 and J4,

respectively). See the table on

the right for pin defi nitions.

IDE Drive Connectors

Pin Defi nitions

Pin# Defi nition Pin # Defi nition

1 Reset IDE 2 Ground

3 Host Data 7 4 Host Data 8

5 Host Data 6 6 Host Data 9

7 Host Data 5 8 Host Data 10

9 Host Data 4 10 Host Data 11

11 Host Data 3 12 Host Data 12

13 Host Data 2 14 Host Data 13

15 Host Data 1 16 Host Data 14

17 Host Data 0 18 Host Data 15

19 Ground 20 Key

21 DRQ3 22 Ground

23 I/O Write 24 Ground

25 I/O Read 26 Ground

27 IOCHRDY 28 BALE

29 DACK3 30 Ground

31 IRQ14 32 IOCS16

33 Addr1 34 Ground

35 Addr0 36 Addr2

37 Chip Select 0 38 Chip Select 1

39 Activity 40 Ground

KB/

Mouse

USB0/1

COM1

VGA

GLAN1

GLAN2

RAGE­X

82546

GLAN
Enable

Battery

Parrallel

Port

JLAN1

GLAN
CTLR

JPL1

JLAN1

JLAN2

JPG1

Fan6

Fan5

4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

UPER X6DH8-G2+

S

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

#3 133 MHz

PCI-X

PCI-X #2 100 MHz

PCI-X #1 100 MHz ZCR

WOR

WOL

SEPC

Super

I/O

USB4

®

24-Pin

ATX PWR

E7520

North
Bridge

ICH5R

South
Bridge

JPF

Speake

JBT1

J27

r

JWD

SMBUS

USB2/3

COM2

PXH

BIOS

SATA0

JPA1

SATA1

CPU 1

7902

SCSI

CPU 2

IPMI

JPA2
JPA3

DA2

PWR

Fan7

SMBus

Fan8

SI/O

CTRL

DA1

Ultra 320

2-29

JP13

B

Fan3

Floppy

SCSI CH B

JL1

JP12

8-pin
PWR

IDE2

Fan1

FP Control

SPK

PW LED

JP15

LE1

Fan2

JOH1

JP14

A

IDE1

SCSI CH A

Ultra 320

Fan4

A. IDE 1

B. IDE 2

X6DH8-G2+/X6DHE-G2+ User's Manual

Ultra320 SCSI Connectors
(X6DH8-G2+ Only)

Refer to the table below for the

pin defi nitions of the Ultra320

SCSI connectors located at JA1

(Channel A) and JA2 (Channel B).

JPF

ATX PWR

KB/
Mouse

USB0/1

COM1

VGA

Parrallel

GLAN1

GLAN2

RAGE­X

GLAN
CTLR

82546

GLAN
Enable

Battery

Fan6

Fan5

N1

Port

JLA

S

JLAN1

JLAN2

JPG1

X8 PCI-Epx #6

X8 PCI-Epx #5

X4 PCI-Epx #4

PCI-X #3 133 MHz

PCI-X #2 100 MHz

JPL1

PCI-X #1 100 MHz ZCR

WOR

WOL

24-Pin
4-Pin
PWR

DIMM 1B (Bank 1)

DIMM 1A (Bank 1)

DIMM 2B (Bank 2)

DIMM 2A (Bank 2)

DIMM 3B (Bank 3)

DIMM 3A (Bank 3)

DIMM 4B (Bank 4)

DIMM 4A (Bank 4)

®

UPER X6DH8-

E7520

North

Bridge

SEPC

Super

ICH5R

I/O

South
Bridge

USB4

G2+

Speaker

COM2

JBT1

JWD

BIOS

J27

PXH

SMBUS

USB2/3

SATA0

JPA1

SATA1

CPU 1

SCSI

CPU 2

IPMI

7902

Ultra320 SCSI Drive Connector

Pin Definitions

Pin# Definition Pin # Definition

1 +DB (12) 35 -DB (12)

2 +DB (13) 36 -DB (13)

3 +DB (14) 37 -DB (14)

4 +DB (15) 38 -DB (15)

5 +DB (P1) 39 -DB (P1)

6 +DB (0) 40 -DB (0)

7 +DB (1) 41 -DB (1)

8 +DB (2) 42 -DB (2)

9 +DB (3) 43 -DB (3)

10 +DB (4) 44 -DB (4)

11 +DB (5) 45 -DB (5)

12 +DB (6) 46 -DB (6)

13 +DB (7) 47 -DB (7)

14 +DB (P) 48 -DB (P)

15 Ground 49 Ground

16 DIFFSENS 50 Ground

17 TERMPWR 51 TERMPWR

18 TERMPWR 52 TERMPWR

19 Reserved 53 Reserved

20 Ground 54 Ground

21 +ATN 55 -ATN

22 Ground 56 Ground

23 +BSY 57 -BSY

24 +ACK 58 -ACK

25 +RST 59 -RST

26 +MSG 60 -MSG

27 +SEL 61 -SEL

28 +C/D 62 -C/D

29 +REQ 63 -REQ

Fan7

SI/O

SMBus

Fan8

PWR

JP12

JP13

JL1

Fan3

Floppy

30 +I/O 64 -I/O

Fan1

31 +DB (8) 65 -DB (8)

FP Control

32 +DB (9) 66 -DB (9)

SPK

PW LED

JP15

33 +DB (10) 67 -DB (10)

LE1

Fan2

34 +DB (11) 68 -DB (11)

JOH1

JP14

IDE1

IDE2

A. SCSI Channel A

8-pin

PWR

B. SCSI Channel B

B

SCSI CH B

SCSI CH A

Ultra 320

Fan4

A

CTRL

DA2

DA1

JPA2
JPA3

Ultra 320

2-30

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all

of the procedures below and still need assistance, refer to the ‘Technical Support

Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.

Note: Always disconnect the power cord before adding, changing or installing

any hardware components.

Before Power On

1. Make sure no short circuits exist between the motherboard and chassis.

2. Disconnect all ribbon/wire cables from the motherboard, including those for the

keyboard and mouse.

3. Remove all add-on cards.

4. Install one CPU (making sure it is fully seated) and connect the chassis speaker

and the power LED to the motherboard. (Check all jumper settings as well.)

5. Use only the correct type of CMOS onboard battery as recommended by the

Manufacturer. Do not install the onboard battery upside down to avoid pos-

sible explosion.

No Power

1. Make sure no short circuits exist between the motherboard and the chassis.

2. Verify that all jumpers are set to their default positions.

3. Check that the 115V/230V switch on the power supply is properly set.

4. Turn the power switch on and off to test the system.

5. The battery on your motherboard may be old. Check to verify that it still supplies

~3VDC. If it does not, replace it with a new one.

No Video

1. If the power is on but you have no video, remove all the add-on cards and cables.

(Note: By default, the onboard speaker is enabled.)

2. Remove the memory and turn on the system.

3. Use the speaker to determine if any beep codes exist. (Refer to the Appendix for

details on beep codes.) If you've got a no-memory beep code, you will need

to replace the memory modules with new and correct ones, for your system

memory is either bad or incompatible. If you do not have a no-memory beep

code, please call the technical support.

3-1

X6DH8-G2+/X6DHE-G2+ User's Manual

NOTE

If you are a system integrator, VAR or OEM, a POST diagnostics

card is recommended. For I/O port 80h codes, refer to App. B.

Memory Errors

1. Make sure the DIMM modules are properly and fully installed.

2. Determine if different speeds of DIMMs have been installed and verify that the

BIOS setup is confi gured for the fastest speed of RAM used. It is recom-

mended to use the same RAM speed for all DIMMs in the system.

3. Make sure you are using the correct type of Registered ECC DDR2-400 (PC3200)

SDRAM (recommended by the manufacturer.)

4. Check for bad DIMM modules or slots by swapping a single module between

two slots and noting the results.

5. Make sure all memory modules are fully seated in their slots. As an interleaved

memory scheme is used, you must install two modules at a time, beginning

with Bank 1, then Bank 2, and so on (see Section 2-3).

6. Check the position of the 115V/230V switch on the power supply.

Losing the System’s Setup Confi guration

1. Ensure that you are using a high quality power supply. A poor quality power

supply may cause the system to lose the CMOS setup information. Refer to

Section 1-6 for details on recommended power supplies.

2. The battery on your motherboard may be old. Check to verify that it still supplies

~3VDC. If it does not, replace it with a new one.

3. If the above steps do not fi x the Setup Confi guration problem, contact your

vendor for repairs.

3-2 Technical Support Procedures

Before contacting Technical Support, please take the following steps. Also, note

that as a motherboard manufacturer, Super Micro does not sell directly to end-us-

ers, so it is best to fi rst check with your distributor or reseller for troubleshooting

services. They should know of any possible problem(s) with the specifi c system

confi guration that was sold to you.

1. Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked Ques-

tion' (FAQ) sections in this chapter or see the FAQs on our web site (

www.supermicro.com/support/faqs/) before contacting Technical Support.

http://

2. BIOS upgrades can be downloaded from our web site at

com/support/bios/

(http://www.supermicro.

).

3-2

Chapter 3: Troubleshooting

Note: Not all BIOS can be fl ashed; it depends on the modifi cations to the

boot block code.

3. If you still cannot resolve the problem, be sure to have the following information

ready when contacting Supermicro for technical support:

• Motherboard model and PCB revision number

• BIOS release date/version (this can be seen on the initial display when your

system fi rst boots up)

•System confi guration

An example of a Technical Support form is on our web site at

supermicro.com/support/contact.cfm).

4. Distributors: For immediate assistance, please have your account number ready

when placing a call to our technical support department. We can be reached

by e-mail at [e-mail] or by fax at: [phone], option 2.

(http://www.

3-3 Frequently Asked Questions

Question: What are the various types of memory that my motherboard can

support?

Answer: The X6DH8-G2+/X6DHE-G2+ has eight 240-pin DIMM slots that support

registered ECC DDRII-400 (PC3200) SDRAM modules. It is strongly recommended

that you do not mix memory modules of different speeds and sizes.

Question: How do I update my BIOS?

Answer: It is recommended that you do not upgrade your BIOS if you are not

experiencing any problems with your system. Updated BIOS fi les are located

on our web site at

BIOS warning message and the information on how to update your BIOS on our

web site. Also, check the current BIOS revision and make sure it is newer than

your BIOS before downloading. Select your motherboard model and download

the BIOS fi le to your computer. Unzip the BIOS fi les onto a bootable fl oppy and

reboot your system. Follow the Readme.txt to continue fl ashing the BIOS.

(

to prevent possible system boot failure!)

Question: What's on the CD that came with my motherboard?

Answer: The supplied compact disc has quite a few drivers and programs that will

greatly enhance your system. We recommend that you review the CD and install the

applications you need. Applications on the CD include chipset drivers for Windows

and security and audio drivers.

Warning: Do not shut down or reset the system while updating BIOS

(http://www.supermicro.com/support/bios/). Please check our

3-3

X6DH8-G2+/X6DHE-G2+ User's Manual

3-4 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required be-

fore any warranty service will be rendered. You can obtain service by calling your

vendor for a Returned Merchandise Authorization (RMA) number. When returning

to the manufacturer, the RMA number should be prominently displayed on the

outside of the shipping carton, and mailed prepaid or hand-carried. Shipping and

handling charges will be applied for all orders that must be mailed when service

is complete.

This warranty only covers normal consumer use and does not cover damages in-

curred in shipping or from failure due to the alternation, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor fi rst for any product problems.

3-4

Chapter 4: BIOS

Chapter 4

BIOS

4-1 Introduction

This chapter describes the Phoenix BIOS™ Setup utility for the X6DH8-G2+/

X6DHE-G2+. The Phoenix ROM BIOS is stored in a fl ash chip and can be easily

upgraded using a fl oppy disk-based program.

Note: Due to periodic changes to the BIOS, some settings may have been added or

deleted and might not yet be recorded in this manual. Please refer to the Manual

Download area of the Supermicro web site <http://www.supermicro.com> for any

changes to the BIOS that may not be refl ected in this manual.

System BIOS

The BIOS is the Basic Input Output System used in all IBM® PC, XT™, AT®, and

PS/2® compatible computers. The Phoenix BIOS stores the system parameters,

type of disk drives, video displays, etc. in the CMOS. The CMOS memory requires

very little electrical power. When the computer is turned off, a backup battery pro-

vides power to the CMOS Logic, enabling it to retain system parameters. Each time

the computer is powered on, the computer is confi gured with the values stored in

the CMOS Logic by the system BIOS, which gains control at boot-up.

How To Change the Confi guration Data

The CMOS information that determines the system parameters may be changed by

entering the BIOS Setup utility. This Setup utility can be accessed by pressing the

<Delete> key at the appropriate time during system boot. (See below.)

Starting the Setup Utility

Normally, the only visible POST (Power On Self Test) routine is the memory test. As

the memory is being tested, press the <Delete> key to enter the main menu of the

BIOS Setup utility. From the main menu, you can access the other setup screens,

such as the Security and Power menus. Beginning with Section 4-3, detailed de-

scriptions are given for each parameter setting in the Setup utility.

Warning: Do not shut down or reset the system while updating BIOS

to prevent possible boot failure.

4-1

X6DH8-G2+/X6DHE-G2+ User's Manual

4-2 Running Setup

Default settings are in bold text unless otherwise noted.

The BIOS setup options described in this section are selected by choosing

the appropriate text from the main BIOS Setup screen. All displayed text is

described in this section, although the screen display is often all you need to

understand how to set the options (see the next page).

When you fi rst power on the computer, the Phoenix BIOS™ is immediately acti-

vated.

While the BIOS is in control, the Setup program can be activated in one of two

ways:

1. By pressing <Delete> immediately after turning the system on, or

2. When the message shown below appears briefl y at the bottom of the screen

during the POST (Power On Self-Test), press the <Delete> key to activate the

main Setup menu:

Press the <Delete> key to enter Setup

4-3 Main BIOS Setup

ʳ

All main Setup options are described in this section. The main BIOS Setup screen

is displayed below.

Use the Up/Down arrow keys to move among the different settings in each menu.

Use the Left/Right arrow keys to change the options for each setting.

Press the <Esc> key to exit the CMOS Setup Menu. The next section describes in

detail how to navigate through the menus.

Items that use submenus are indicated with the

press the <Enter> key to access the submenu.

icon. With the item highlighted,

4-2

Main BIOS Setup Menu

Chapter 4: BIOS

Main Setup Features

System Time

To set the system date and time, key in the correct information in the appropriate

fi elds. Then press the <Enter> key to save the data.

System Date

Using the arrow keys, highlight the month, day and year fi elds, and enter the correct

data. Press the <Enter> key to save the data.

BIOS Date

This fi eld displays the date when this version of BIOS was built.

Legacy Diskette A

This setting allows the user to set the type of fl oppy disk drive installed as diskette A.

The options are Disabled, 360Kb 5.25 in, 1.2MB 5.25 in, 720Kb 3.5 in, 1.44/1.25MB,

3.5 in and 2.88MB 3.5 in.

Parallel ATA

This setting allows the user to enable or disable the function of Parallel ATA. The

options are Disabled, Channel 0, Channel 1, and Both.

4-3

X6DH8-G2+/X6DHE-G2+ User's Manual

Serial ATA

This setting allows the user to enable or disable the function of Serial ATA. The

options are Disabled and Enabled.

Serial ATA RAID Enable

Select Enable to enable Serial ATA RAID Functions. (For the Windows OS environment,

use the RAID driver if this feature is set to Enabled. If set to Disabled, use the

Non-RAID driver.)

Native Mode Operation

This option allows the user to select the native mode for ATA. The options are

Parallel ATA, Serial ATA, Both, and Auto.

IDE Channel 0 Master/Slave, IDE Channel 1 Master/Slave, IDE
Channel 2 Master, IDE Channel 3 Master

These settings allow the user to set the parameters of IDE Channel 0 Master/

Slave, IDE Channel 1 Master/Slave, IDE Channel 2 Master, IDE Channel 3 Master

slots. Hit <Enter> to activate the following sub-menu screen for detailed options

of these items. Set the correct confi gurations accordingly. The items included in

the sub-menu are:

4-4

Chapter 4: BIOS

Type

This option allows the user to select the type of IDE hard drive. Select Auto to

allow the BIOS to automatically determine the hard drive's capacity, number of

heads, etc.). Enter a number from 1-39 to select a predetermined type of hard

drive, CDROM and ATAPI Removable. Select User to allow the user to enter the

parameters of the HDD installed at this connection. Select CDROM if a CDROM

drive is installed. Select ATAPI if a removable disk drive is installed.

CHS Format

The following items will be displayed by the BIOS:

TYPE: This item displays the type of IDE or SATA devices.

Cylinders: This item indicates the status of Cylinders.

Headers: This item indicates the number of headers.

Sectors: This item displays the number of sectors.

Maximum Capacity: This item displays the maximum storage capacity of the

system.

LBA Format

The following items will be displayed by the BIOS:

Total Sectors: This item displays the number of total sectors available in the

LBA Format.

Maximum Capacity: This item displays the maximum capacity in the LBA

Format.

Multi-Sector Transfer

This item allows the user to specify the number of sectors per block to be used

in multi-sector transfer. The options are Disabled, 4 Sectors, 8 Sectors, and 16

Sectors.

LBA Mode Control

This item determines whether the Phoenix BIOS will access the IDE Channel 0

Master Device via the LBA mode. The options are Enabled and Disabled.

32 Bit I/O

This option allows the user to enable or disable the function of 32-bit data transfer.

The options are Enabled and Disabled.

4-5

X6DH8-G2+/X6DHE-G2+ User's Manual

Transfer Mode

This option allows the user to select the transfer mode for the system. The

options are Standard, Fast PIO1, Fast PIO2, Fast PIO3, Fast PIO4, FPIO3/

DMA1, and FPIO4/DMA2.

Ultra DMA Mode

This option allows the user to select the Ultra DMA Mode for the system. The

options are Disabled, Mode 0, Mode 1, Mode 2, Mode 3, Mode 4 and Mode

5.

System Memory

This display informs you how much system memory is recognized and detected

in the system.

Extended Memory

This display informs you how much extended memory is recognized and detected

in the system.

4-4 Advanced Setup

Choose Advanced from the Phoenix BIOS Setup Utility main menu with the arrow

keys. You should see the following display. The items with a triangle beside them

have sub menus that can be accessed by highlighting the item and pressing <Enter>.

All Advanced BIOS Setup options are described in this section.

4-6

Chapter 4: BIOS

Boot Features

Access the submenu to make changes to the following settings.

Quick Boot Mode

If enabled, this feature will speed up the POST (Power On Self Test) routine by

skipping certain tests after the computer is turned on. The settings are Enabled

and Disabled. If Disabled, the POST routine will run at normal speed.

Quiet Boot

This setting allows you to Enable or Disable the graphic logo during boot-up.

ACPI Mode

Use the setting to determine if you want to employ ACPI (Advanced Confi guration

and Power Interface) power management on your system. The options are

Yes and No.

Power Button Behavior

If set to Instant-Off, the system will power off immediately as soon as the user
hits the power button. If set to 4-sec., the system will power off when the user
presses the power button for 4 seconds or longer. The options are instant-off
and 4-sec override.

Resume On Modem Ring

Select On to “wake your system up” when an incoming call is received by
your modem. The options are On and Off.

After Power Failure

This setting allows you to choose how the system will react when power returns

after an unexpected loss of power. The options are Stay Off, Power On, and

Last State.

Watch Dog

If enabled, this option will automatically reset the system if the system is not

active for more than 5 minutes. The options are Enabled and Disabled.

Summary Screen

This setting allows you to Enable or Disable the summary screen which displays

the system confi guration during bootup.

4-7

X6DH8-G2+/X6DHE-G2+ User's Manual

Memory Cache

Cache System BIOS Area

This setting allows you to designate a reserve area in the system memory to

be used as a System BIOS buffer to allow the BIOS to write (cache) its data

into this reserved memory area. Select "Write Protect" to enable this function,

and this area will be reserved for BIOS ROM access only. Select "Uncached" to

disable this function and make this area available for other devices.

Cache Video BIOS Area

This setting allows you to designate a reserve area in the system memory to be

used as a Video BIOS buffer to allow the BIOS to write (cache) its data into this

reserved memory area. Select "Write Protect" to enable the function and this

area will be reserved for Video BIOS ROM access only. Select "Uncached" to

disable this function and make this area available for other devices.

Cache Base 0-512K

If enabled, this feature will allow the data stored in the base memory area:

block 0-512K to be cached (written) into a buffer, a storage area in the Static

DRM (SDROM) or to be written into L1, L2 cache inside the CPU to speed

up CPU operations . Select "Uncached" to disable this function. Select "Write

Through" to allow data to be cached into the buffer and written into the system

memory at the same time. Select "Write Protect" to prevent data from being

written into the base memory area of Block 0-512K. Select "Write Back" to allow

the CPU to write data back directly from the buffer without writing data to the

System Memory for fast CPU data processing and operation. The options are

Uncached, Write Through, Write Protect, and Write Back.

Cache Base 512K-640K

If enabled, this feature will allow the data stored in the memory area: 512K-640K

to be cached (written) into a buffer, a storage area in the Static DRM (SDROM)

or written into L1, L2, L3 cache inside the CPU to speed up CPU operations.

Select "Uncached" to disable this function. Select "Write Through" to allow data

to be cached into the buffer and written into the system memory at the same

time. Select "Write Protect" to prevent data from being written into the base

memory area of Block 512K-640K. Select "Write Back" to allow the CPU to write

data back directly from the buffer without writing data to the System Memory

for fast CPU data processing and operation. The options are Uncached, Write

Through, Write Protect, and Write Back.

Cache Extended Memory

If enabled, this feature will allow the data stored in the extended memory area

to be cached (written) into a buffer, a storage area in the Static DRM (SDROM)

4-8

Chapter 4: BIOS

or written into L1, L2, L3 cache inside the CPU to speed up CPU operations.

Select "Uncached" to disable this function. Select "Write Through" to allow data

to be cached into the buffer and written into the system memory at the same

time. Select "Write Protect" to prevent data from being written into the extended

memory area of Block above 1 MB. Select "Write Back" to allow the CPU to write

data back directly from the buffer without writing data to the System Memory

for fast CPU data processing and operation. The options are Uncached, Write

Through, Write Protect, and Write Back.

Discrete MTRR Allocation

If enabled, MTRRs (-Memory Type Range Registers) are confi gured as distinct,
separate units and cannot be overlapped. If enabled, the user can achieve
better graphic effects when using a Linux graphic driver that requires the write­combining confi guration with 4GB or more memory. The options are Enabled
and Disabled.

PCI Confi guration

Access the submenu to make changes to the following settings for PCI devices.

Onboard GLAN (Gigabit- LAN) OPROM Confi gure

Enabling this option provides the capability to boot from GLAN. The options

are Disabled and Enabled.

Onboard SCSI OPROM Confi gure (X6DH8-G2+ only)

Enabling this option provides the capitally to boot from SCSI HDD. The options

are Disabled and Enabled.

Default Primary Video Adapter

This item allows the user to select the Primary Video Adapter between two

adapters instead of selecting among three or more adapters. The options are

Other and Onboard Video.

4-9

X6DH8-G2+/X6DHE-G2+ User's Manual

PCI Parity Error Forwarding

Enable this item to forward the PCI errors occurring behind P2P bridges

to the South Bridge, so NMI can be asserted. The options are Enabled and

Disabled.

ROM Scan Ordering

This feature allows the user to decide which Option ROM to be activated fi rst.

The options are Onboard Option ROM fi rst and Add-On fi rst.

Reset Confi guration Data

If set to Yes, this setting clears the Extended System Confi guration Data- (ESCD)

area. The options are Yes and No.

Frequency for PCI-X#1-#2/SCSI

This option allows the user to change the bus frequency for the devices installed

in the slot indicated. The options are Auto, PCI 33 MHz, PCI 66 MHz, PCI-X

66 MHz, and PCI-X 100 MHz.

Frequency for PCI-X#3/G-LAN

This option allows the user to change the bus frequency of the devices installed

in the slot indicated. The options are Auto, PCI 33 MHz, PCI 66 MHz, PCI-X

66 MHz, PCI-X 100 MHz, and PCI-X 133 MHz.

Frequency for PCI-X#1 On Riser, Frequency for PCI-X#2-#3 On
Riser

This option allows the user to change the bus frequency of the devices installed

in the slot indicated. The options are Auto, PCI 33 MHz, PCI 66 MHz, PCI-X

66 MHz, PCI-X 100 MHz, and PCI-X 133 MHz.

(Available when a 2U Active Riser Card is present.)

PCI-X 100MHz ZCR Slot#1, PCI-X 100MHzSlot#2, PCI-X 133MHz
Slot#3, PCI-Exp x4 Slot#4, PCI-Exp x8 Slot#5, PCI-Exp x8 Slot#6 (or
PCI-Exp x8 Slot#6 and Riser, if a 2U Active Riser Card is present.)

Access the submenu for each of the settings above to make changes to the

following:

Option ROM Scan

When enabled, this setting will initialize the device expansion ROM. The options

are Enabled and Disabled.

Enable Master

This setting allows you to enable the selected device as the PCI bus master.

The options are Enabled and Disabled.

4-10

Chapter 4: BIOS

Latency Timer

This setting allows you to set the clock rate for Bus Master. A high-priority, high-

throughout device may benefi t from a greater clock rate. The options are Default,

0020h, 0040h, 0060h, 0080h, 00A0h, 00C0h, and 00E0h. For Unix, Novell and

other Operating Systems, please select the option: other. If a drive fails after

the installation of a new software, you might want to change this setting and

try again. A different OS requires a different Bus Master clock rate.

Large Disk Access Mode

This setting determines how large hard drives are to be accessed. The options

are DOS or Other (for Unix, Novellle NetWare and other operating systems).

Advanced Chipset Control

Access the submenu to make changes to the following settings.

Force Compliance Mode

This feature allows you to enable the PCI-Express Compliance Mode. The

options are Disabled or Enabled.

Memory RAS Feature Control

Select this option in order to enable the special feature of DIMM sparing or

memory mirroring. The options are Mirroring, Sparing, and Standard.

Clock Spectrum Feature

If "Enabled", the BIOS will monitor the level of Electromagnetic Interference

caused by the components and will attempt to decrease the interference whenever

needed. The options are Enabled and Disabled.

Memory Remap Function Control

PCI memory resources will overlap with the physical memory if 4GB of memory
or above is installed on the motherboard. When this occurs, enable this function
to reallocate the overlapped physical memory to a location above 4GB to resolve
the memory overlapping situation.

DRAM Data Integrity Mode

If enabled, this feature allows the data stored in the DRMA memory to be

integrated for faster data processing. The options are 72-bit ECC, 144-bit

ECC, Auto, and Disabled.

ECC Error Type

This setting lets you select which type of interrupt to be activated as a result

of an ECC error. The options are None, NMI (Non-Maskable Interrupt), SMI

(System Management Interrupt), and SCI (System Control Interrupt).

4-11

X6DH8-G2+/X6DHE-G2+ User's Manual

SERR Signal Condition

This setting specifi es the ECC Error conditions that an SERR# is to be asserted.

The options are None, Single Bit, Multiple Bit, and Both.

Enabling Multi-Media Timer

Select Yes to activate a set of timers that are alternative to the traditional 8254

timers for the OS use. The options are Yes and No.

USB Function

Select Enabled to enable the function of USB devices specifi ed. The settings

are Enabled and Disabled.

Legacy USB Support

This setting allows you to enable support for Legacy USB devices. The settings

are Enabled and Disabled.

Advanced Processor Options

Access the submenu to make changes to the following settings.

CPU Speed

This is a display that indicates the speed of the installed processor.

Hyper-threading (Available when supported by the CPU.)

Set to Enabled to use the Hyper-Threading Technology, which will result in

increased CPU performance. The options are Disabled or Enabled.

Machine Checking (Available when supported by the CPU.)

Set to Enabled to activate the function of Machine Checking and allow the

CPU to detect and report hardware (machine) errors via a set of model-specifi c

registers (MSRs). The options are Disabled or Enabled.

C1 Enhanced Mode (Available when supported by the CPU.)

Set to Enabled to enable Enhanced Halt State to lower CPU voltage/frequency

to prevent overheat. The options are Enabled and Disabled. (Note: please refer

to Intel’s web site for detailed information.)

4-12

Chapter 4: BIOS

No Execute Mode Memory Protection (Available when supported by

the CPU and the OS.)

Set to Enabled to enable Execute Disable Bit and allow the processor to classify

areas in memory where an application code can execute and where it cannot, and

thus preventing a worm or a virus from inserting and creating a fl ood of codes

to overwhelm the processor or damage the system during an attack.

Note: this feature is available when your OS and your CPU support the function

of Execute Disable Bit. The options are Disabled and Enabled. Note: For more

information regarding hardware/software support for this function, please refer

to Intel's and Microsoft's web sites.

Thermal Management 2 (Available when supported by the CPU.)

Set to Enabled to use Thermal Management 2 (TM2) which will lower CPU

voltage and frequency when the CPU temperature reaches a pre-defined

overheat threshold. Set to Disabled to use Thermal Manager 1 (TM1), allowing

CPU clocking to be regulated via CPU Internal Clock modulation when the CPU

temperature reaches the overheat threshold.

Adjacent Cache Line Prefetch (Available when supported by the

CPU.)

The CPU fetches the cache line for 64 bytes if this option is set to Disabled.

The CPU fetches both cache lines for 128 bytes as comprised if Enabled. The

options are Disabled and Enabled.

Processor Power Management

This feature allows the user to determine the processor power management

mode. The options are Disabled and C States Only. If set to Disabled, C States

and GV1/GV3 are disabled. If set to C States only, the processor power will be

controlled through CPU power states in the APCI setting.

4-13

X6DH8-G2+/X6DHE-G2+ User's Manual

I/O Device Confi guration

Access the submenu to make changes to the following settings.

KBC Clock Input

This setting allows you to select clock frequency for KBC. The options are 6MHz,

8MHz, 12MHz and 16MHz.

On-board COM 1

This setting allows you to assign control of On-board COM1. The options are

Enabled (user defi ned), Disabled, and Auto (BIOS- or OS- controlled).

Base I/O Address

Select the base I/O address for serial port A. The options are 3F8/IRQ3, 3F8/

IRQ4, 2F8/IRQ3, 2F8/IRQ4, 3E8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, and 2E8/IRQ4.

On-board COM 2

This setting allows you to assign control of On-board COM2. The options are

Enabled (user defi ned), Disabled, Auto (BIOS controlled), and OS Controlled.

Base I/O Address

This setting allows you to select the base I/O address for serial port B. The

options are 3F8/IRQ3, 3F8/IRQ4, 2F8/IRQ3, 2F8/IRQ4, 3E8/IRQ3, 3E8/IRQ4,

2E8/IRQ3, and 2E8/IRQ4.

Parallel Port

This setting allows you to assign control of the parallel port. The options are Enabled

(user defi ned), Disabled and, Auto (BIOS-or OS- controlled).

Base I/O Address

This setting allows you to select the base I/O address for the parallel port. The

options are 378, 278, and 3BC.

Interrupt

This setting allows you to select the IRQ (interrupt request) for the parallel port.
The options are IRQ5 and IRQ7.

DMA Channel

This item allows you to specify the DMA channel for the parallel port. The options

are DMA1 and DMA3.

Mode

This feature allows you to specify the parallel port mode. The options are Output

only, Bi-Directional, EPP, and ECP.

4-14

Chapter 4: BIOS

Floppy Disk Controller

This setting allows you to assign control of the fl oppy disk controller. The options

are Enabled (user defi ned), Disabled, and Auto (BIOS and OS controlled).

Base I/O Address

This setting allows you to select the base I/O address for the parallel port. The

options are Primary and Secondary.

DMI Event Logging

Access the submenu to make changes to the following settings.

Event Log Validity

This is a display to inform you of the event log validity. It is not a setting.

Event Log Capacity

This is a display to inform you of the event log capacity. It is not a setting.

View DMI Event Log

Highlight this item and press <Enter> to view the contents of the event log.

Event Logging

This setting allows you to Enable or Disable event logging.

ECC Event Logging

This setting allows you to Enable or Disable ECC event logging.

Mark DMI Events as Read

Highlight this item and press <Enter> to mark the DMI events as read.

Clear All DMI Event Logs

Select Yes and press <Enter> to clear all DMI event logs. The options are Yes

and No

4-15

X6DH8-G2+/X6DHE-G2+ User's Manual

Console Redirection

Access the submenu to make changes to the following settings.

COM Port Address

This item allows you to specify which COM port to direct the remote console to:

Onboard COM A or Onboard COM B. This setting can also be Disabled.

BAUD Rate

This item allows you to set the BAUD rate for console redirection. The options are

300, 1200, 2400, 9600, 19.2K, 38.4K, 57.6K, and 115.2K.

Console Type

This item allows you to set console redirection type. The options are VT100,

VT100/8bit, PC-ANSI/7bit, PC ANSI, VT100+,

VT-UTF8 and ASCII.

Flow Control

This item allows you to select the fl ow control option for the console. The options

are: None, XON/XOFF, and CTS/RTS.

Console Connection

This item allows you to decide how console redirection is to be connected: either

Direct or Via Modem.

Continue CR after POST

Select on to continue with console redirection after the POST routine. The options

are On and Off.

Hardware Monitor Logic

CPU Temperature Threshold

This option allows the user to set a CPU temperature threshold that will activate

the alarm system when the CPU temperature reaches this pre-set temperature

threshold. The options are 75

Highlight this and hit <Enter> to see monitor data for the following items:

o

C, 80oC, 85oC, and 90oC. (See Note on 4-17.)

CPU1 Temperature: This item displays CPU1 Temperature.

CPU2 Temperature: This item displays CPU2 Temperature.

LM93 Temperature: This item displays LM93 Temperature.

LM30 Temperature: This item displays LM30 Temperature.

System Temperature: This item displays the System Temperature.

4-16

Chapter 4: BIOS

CPU Temperature Threshold

Fan Speed Control Modes

This feature allows the user to decide how the system controls the speeds of the

onboard fans. The CPU temperature and the fan speed are correlative. When the

CPU on-die temperature increases, the fan speed will also increase, and vice versa.

If the option is set to “3-pin fan”, the fan speed is controlled by voltage. If the option

is set to “4-pin”, the fan speed will be controlled by Pulse Width Modulation (PWM).

Select “3-pin” if your chassis came with 3-pin fan headers. Select “4-pin” if your

chassis came with 4-pin fan headers. Select “Workstation” if your system is used as

a Workstation. Select “Server” if your system is used as a Server. Select “Disable”

to disable the fan speed control function to allow the onboard fans to run at the

full speed (12V) at all the time. The Options are: 1. Disable, 2. 3-pin (Server), 3.

3-pin (Workstation), 4. 4-pin (Server), and 5. 4-pin (Workstation).

Fan 1-FAN6/Fan 7 (CPU Fan1)/Fan 8 (CPU Fan2): If the feature of Auto Fan

Control is enabled, the BIOS will automatically display the status of the fans

indicated in this item.

Voltage Monitoring

This feature displays the voltage status of the following items:

P12V_CPU 1_SCALED/P12V_CPU 2_SCALED

P12V_SCALED

CPU Vio

MCH/PXH Vcore

ICH Vcore

CPU1 Vcore/CPU2 Vcore

P3_V3

P5V

1V8_SC

Vdimm

HECETA_MEM_VTT

P1V0_NIC

N12V_SCALED

P3V3_STBY

Note: In the Windows OS environment, the Supero Doctor III settings take pre-

cedence over the BIOS settings. When fi rst installed, Supero Doctor III adopts

the temperature threshold settings previously set in the BIOS. Any subsequent

changes to these thresholds must be made within Supero Doctor, since the SD

III settings override the BIOS settings. For the Windows OS to adopt the BIOS

temperature threshold settings, please change the SDIII settings to be the same

as those set in the BIOS.

4-17

X6DH8-G2+/X6DHE-G2+ User's Manual

4-5 Security

Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow

keys. You should see the following display. Security setting options are displayed by

highlighting the setting using the arrow keys and pressing <Enter>. All Security BIOS

settings are described in this section.

Supervisor Password Is:

This item indicates if a supervisor password has been entered for the system.

Clear means such a password has not been used and Set means a supervisor

password has been entered for the system.

User Password Is:

This item indicates if a user password has been entered for the system. Clear

means such a password has not been used and Set means a user password has

been entered for the system.

Set Supervisor Password

When the item "Set Supervisor Password" is highlighted, hit the <Enter> key. When

prompted, type the Supervisor's password in the dialogue box to set or to change

supervisor's password, which allows access to the BIOS.

Set User Password

When the item "Set User Password" is highlighted, hit the <Enter> key. When

prompted, type the user's password in the dialogue box to set or to change the

user's password, which allows access to the system at boot-up.

4-18

Chapter 4: BIOS

Fixed Disk Boot Sector

This setting may offer some protection against viruses when set to Write Protect,

which protects the boot sector on the hard drive from having a virus written to it.

The other option is Normal.

Password on Boot

When set to Enabled, the user is required to key in a password to enter the setup

utility at boot up. The options are Enabled (password required) and Disabled

(password not required).

4-19

X6DH8-G2+/X6DHE-G2+ User's Manual

4-6 Boot

Choose Boot from the Phoenix BIOS Setup Utility main menu with the arrow keys.

You should see the following display. Highlighting a setting with a + or - will expand

or collapse that entry. See details on how to change the order and specs of boot

devices in the Item Specifi c Help window. All Boot BIOS settings are described in

this section.

+Removable Devices

Highlight and press <Enter> to expand the fi eld. See details on how to change the

order and specs of devices in the Item Specifi c Help window.

CDROM Drive

See details on how to change the order and specs of the CDROM drive in the Item

Specifi c Help window.

+Hard Drive

Highlight and press <Enter> to expand the fi eld. See details on how to change the

order and specs of hard drives in the Item Specifi c Help window.

4-20

Chapter 4: BIOS

4-7 Exit

Choose Exit from the Phoenix BIOS Setup Utility main menu with the arrow keys.

You should see the following display. All Exit BIOS settings are described in this

section.

Exit Saving Changes

Highlight this item and hit <Enter> to save any changes you made and to exit the

BIOS Setup utility.

Exit Discarding Changes

Highlight this item and hit <Enter> to exit the BIOS Setup utility without saving any

changes you may have made.

Load Setup Defaults

Highlight this item and hit <Enter> to load the default settings for all items in the

BIOS Setup. These are the safest settings to use.

Discard Changes

Highlight this item and hit <Enter> to discard (cancel) any changes you made.

You will remain in the Setup utility.

4-21

X6DH8-G2+/X6DHE-G2+ User's Manual

Save Changes

Highlight this item and hit <Enter> to save any changes you made. You will remain

in the Setup utility.

4-22

Appendix A: BIOS POST Messages

Appendix A

BIOS POST Messages

During the Power-On Self-Test (POST), the BIOS will check for problems. If a prob-

lem is found, the BIOS will activate an alarm or display a message. The following is

a list of such BIOS messages.

Failure Fixed Disk

Fixed disk is not working or not confi gured properly. Check to see if fi xed disk is at-

tached properly. Run Setup. Find out if the fi xed-disk type is correctly identifi ed.

Stuck key

Stuck key on keyboard.

Keyboard error

Keyboard not working.

Keyboard Controller Failed

Keyboard controller failed test. May require replacing keyboard controller.

Keyboard locked - Unlock key switch

Unlock the system to proceed.

Monitor type does not match CMOS - Run SETUP

Monitor type not correctly identifi ed in Setup

Shadow Ram Failed at offset: nnnn

Shadow RAM failed at offset nnnn of the 64k block at which the error was de-

tected.

System RAM Failed at offset: nnnn

System RAM failed at offset nnnn of in the 64k block at which the error was de-

tected.

Extended RAM Failed at offset: nnnn

Extended memory not

working or not confi gured properly at offset nnnn.

System battery is dead - Replace and run SETUP

The CMOS clock battery indicator shows the battery is dead. Replace the battery and

run Setup to reconfi gure the system.

A-1

X6DH8-G2+/X6DHE-G2+ User's Manual

System CMOS checksum bad - Default confi guration used

System CMOS has been corrupted or modifi ed incorrectly, perhaps by an application

program that changes data stored in CMOS. The BIOS installed Default Setup Values.

If you do not want these values, enter Setup and enter your own values. If the error

persists, check the system battery or contact your dealer.

System timer error

The timer test failed. Requires repair of system board.

Real time clock error

Real-Time Clock fails BIOS hardware test. May require board repair.

Check date and time settings

BIOS found date or time out of range and reset the Real-Time Clock. May require

setting legal date (1991-2099).

Previous boot incomplete - Default confi guration used

Previous POST did not complete successfully. POST loads default values and offers

to run Setup. If the failure was caused by incorrect values and they are not corrected,

the next boot will likely fail. On systems with control of wait states, improper Setup

settings can also terminate POST and cause this error on the next boot. Run Setup

and verify that the waitstate confi guration is correct. This error is cleared the next

time the system is booted.

Memory Size found by POST differed from CMOS

Memory size found by POST differed from CMOS.

Diskette drive A error

Diskette drive B error

Drive A: or B: is present but fails the BIOS POST diskette tests. Check to see that

the drive is defi ned with the proper diskette type in Setup and that the diskette drive

is attached correctly.

Incorrect Drive A type - run SETUP

Type of fl oppy drive A: not correctly identifi ed in Setup.

Incorrect Drive B type - run SETUP

Type of fl oppy drive B: not correctly identifi ed in Setup.

A-2

Appendix A: BIOS POST Messages

System cache error - Cache disabled

RAM cache failed and BIOS disabled the cache. On older boards, check the cache

jumpers. You may have to replace the cache. See your dealer. A disabled cache slows

system performance considerably.

CPU ID:

CPU socket number for Multi-Processor error.

EISA CMOS not writeable

ServerBIOS2 test error: Cannot write to EISA CMOS.

DMA Test Failed

ServerBIOS2 test error: Cannot write to extended DMA (Direct Memory Access)

registers.

Software NMI Failed

ServerBIOS2 test error: Cannot generate software NMI (Non-Maskable Interrupt).

Fail-Safe Timer NMI Failed

ServerBIOS2 test error: Fail-Safe Timer takes too long.

device Address Confl ict

Address confl ict for specifi ed device.

Allocation Error for: device

Run ISA or EISA Confi guration Utility to resolve resource confl ict for the specifi ed

device.

CD ROM Drive

CD ROM Drive identifi ed.

Entering SETUP ...

Starting Setup program

Failing Bits: nnnn

The hex number nnnn is a map of the bits at the RAM address which failed the memory

test. Each 1 (one) in the map indicates a failed bit. See errors 230, 231, or 232 above

for offset address of the failure in System, Extended, or Shadow memory.

Fixed Disk n

Fixed disk n (0-3) identifi ed.

A-3

X6DH8-G2+/X6DHE-G2+ User's Manual

Invalid System Confi guration Data

Problem with NVRAM (CMOS) data.

I/O device IRQ confl ict

I/O device IRQ confl ict error.

PS/2 Mouse Boot Summary Screen:

PS/2 Mouse installed.

nnnn kB Extended RAM Passed

Where nnnn is the amount of RAM in kilobytes successfully tested.

nnnn Cache SRAM Passed

Where nnnn is the amount of system cache in kilobytes successfully tested.

nnnn kB Shadow RAM Passed

Where nnnn is the amount of shadow RAM in kilobytes successfully tested.

nnnn kB System RAM Passed

Where nnnn is the amount of system RAM in kilobytes successfully tested.

One or more I2O Block Storage Devices were excluded from the Setup Boot

Menu

There was not enough room in the IPL table to display all installed I2O block-storage

devices.

Operating system not found

Operating system cannot be located on either drive A: or drive C:. Enter Setup and

see if fi xed disk and drive A: are properly identifi ed.

Parity Check 1 nnnn

Parity error found in the system bus. BIOS attempts to locate the address and display

it on the screen. If it cannot locate the address, it displays ????. Parity is a method

for checking errors in binary data. A parity error indicates that some data has been

corrupted.

Parity Check 2 nnnn

Parity error found in the I/O bus. BIOS attempts to locate the address and display it

on the screen. If it cannot locate the address, it displays ????.

A-4

Appendix A: BIOS POST Messages

Press <F1> to resume, <F2> to Setup, <F3> for previous

Displayed after any recoverable error message. Press <F1> to start the boot process

or <F2> to enter Setup and change the settings. Press <F3> to display the previous

screen (usually an initialization error of an Option ROM, i.e., an add-on card). Write

down and follow the information shown on the screen.

Press <F2> to enter Setup

Optional message displayed during POST. Can be turned off in Setup.

PS/2 Mouse:

PS/2 mouse identifi ed.

Run the I2O Confi guration Utility

One or more unclaimed block storage devices have the Confi guration Request bit set

in the LCT. Run an I2O Confi guration Utility (e.g. the SAC utility).

System BIOS shadowed

System BIOS copied to shadow RAM.

UMB upper limit segment address: nnnn

Displays the address nnnn of the upper limit of Upper Memory Blocks, indicating

released segments of the BIOS which can be reclaimed by a virtual memory man-

ager.

Video BIOS shadowed

Video BIOS successfully copied to shadow RAM.

A-5

X6DH8-G2+/X6DHE-G2+ User's Manual

Notes

A-6

Appendix B: BIOS POST Codes

Appendix B

BIOS POST Codes

This section lists the POST (Power On Self Test) codes for the PhoenixBIOS. POST

codes are divided into two categories: recoverable and terminal.

Recoverable POST Errors

When a recoverable type of error occurs during POST, the BIOS will display an

POST code that describes the problem. BIOS may also issue one of the follow-

ing beep codes:

1 long and two short beeps - video confi guration error

1 repetitive long beep - no memory detected

Terminal POST Errors

If a terminal type of error occurs, BIOS will shut down the system. Before doing

so, BIOS will write the error to port 80h, attempt to initialize video and write the

error in the top left corner of the screen. The following is a list of codes that may

be written to port 80h.

POST Code Description

01h IPMI Initialization

02h Verify Real Mode

03h Disable Non-Maskable Interrupt (NMI)

04h Get CPU type

06h Initialize system hardware

07h Disable shadow and execute code from the ROM.

08h Initialize chipset with initial POST values

09h Set IN POST fl ag

0Ah Initialize CPU registers

0Bh Enable CPU cache

0Ch Initialize caches to initial POST values

0Eh Initialize I/O component

0Fh Initialize the local bus IDE

10h Initialize Power Management

11h Load alternate registers with initial POST values

12h Restore CPU control word during warm boot

13h Reset PCI Bus Mastering devices

14h Initialize keyboard controller

16h 1-2-2-3 BIOS ROM checksum

17h Initialize cache before memory Auto size

B-1

X6DH8-G2+/X6DHE-G2+ User's Manual

POST Code Description

18h 8254 timer initialization

1Ah 8237 DMA controller initialization

1Ch Reset Programmable Interrupt Controller

20h 1-3-1-1 Test DRAM refresh

22h 1-3-1-3 Test 8742 Keyboard Controller

24h Set ES segment register to 4 GB

28h Auto size DRAM

29h Initialize POST Memory Manager

2Ah Clear 512 kB base RAM

2Ch 1-3-4-1 RAM failure on address line xxxx*

2Eh 1-3-4-3 RAM failure on data bits xxxx* of low byte of

memory bus

2Fh Enable cache before system BIOS shadow

32h Test CPU bus-clock frequency

33h Initialize Phoenix Dispatch Manager

36h Warm start shut down

38h Shadow system BIOS ROM

3Ah Auto size cache

3Ch Advanced confi guration of chipset registers

3Dh Load alternate registers with CMOS values

41h Initialize extended memory for RomPilot (optional)

42h Initialize interrupt vectors

45h POST device initialization

46h 2-1-2-3 Check ROM copyright notice

48h Check video confi guration against CMOS

49h Initialize PCI bus and devices

4Ah Initialize all video adapters in system

4Bh QuietBoot start (optional)

4Ch Shadow video BIOS ROM

4Eh Display BIOS copyright notice

4Fh Initialize MultiBoot

50h Display CPU type and speed

51h Initialize EISA board (optional)

52h Test keyboard

54h Set key click if enabled

55h Enable USB devices

58h 2-2-3-1 Test for unexpected interrupts

59h Initialize POST display service

5Ah Display prompt “Press <ESC> to enter SETUP”

5Bh Disable CPU cache

B-2

Appendix B: BIOS POST Codes

POST Code Description

5Ch Test RAM between 512 and 640 kB

60h Test extended memory

62h Test extended memory address lines

64h Jump to UserPatch1

66h Confi gure advanced cache registers

67h Initialize Multi Processor APIC

68h Enable external and CPU caches

69h Setup System Management Mode (SMM) area

6Ah Display external L2 cache size

6Bh Load custom defaults (optional)

6Ch Display shadow-area message

70h Display error messages

72h Check for confi guration errors

76h Check for keyboard errors

7Ch Set up hardware interrupt vectors

7Dh Initialize Intelligent System Monitoring (optional)

7Eh Initialize coprocessor if present

80h Disable onboard Super I/O ports and IRQs (optional)

81h Late POST device initialization

82h Detect and install external RS232 ports

83h Confi gure non-MCD IDE controllers

84h Detect and install external parallel ports

85h Initialize PC-compatible PnP ISA devices

86h Re-initialize onboard I/O ports.

87h Confi gure Motherboard Confi gurable Devices

(optional)

88h Initialize BIOS Data Area

89h Enable Non-Maskable Interrupts (NMIs)

8Ah Initialize Extended BIOS Data Area

8Bh Test and initialize PS/2 mouse

8Ch Initialize fl oppy controller

8Fh Determine number of ATA drives (optional)

90h Initialize hard-disk controllers

91h Initialize local-bus hard-disk controllers

92h Jump to UserPatch2

93h Build MPTABLE for multi-processor boards

95h Install CD ROM for boot

96h Clear huge ES segment register

97h Fix up Multi Processor table

98h 1-2 Search for option ROMs and shadow if successful. One

long, two short beeps on checksum failure

B-3

X6DH8-G2+/X6DHE-G2+ User's Manual

POST Code Description

99h Check for SMART Drive (optional)

9Ch Set up Power Management

9Dh Initialize security engine (optional)

9Eh Enable hardware interrupts

9Fh Determine number of ATA and SCSI drives

A0h Set time of day

A2h Check key lock

A4h Initialize typematic rate

A8h Erase <ESC> prompt

AAh Scan for <ESC> key stroke

ACh Enter SETUP

AEh Clear Boot fl ag

B0h Check for errors

B1h Inform RomPilot about the end of POST (optional)

B2h POST done - prepare to boot operating system

B4h 1 One short beep before boot

B5h Terminate QuietBoot (optional)

B6h Check password (optional)

B7h Initialize ACPI BIOS and PPM Structures

B9h Prepare Boot

BAh Initialize SMBIOS

BCh Clear parity checkers

BDh Display MultiBoot menu

BEh Clear screen (optional)

BFh Check virus and backup reminders

C0h Try to boot with INT 19

C1h Initialize POST Error Manager (PEM)

C2h Initialize error logging

C3h Initialize error display function

C4h Initialize system error fl ags

C6h Console redirection init.

C7h Unhook INT 10h if console redirection enabled

C8h Force check (optional)

C9h Extended ROM checksum (optional)

CDh Reclaim console redirection vector

B-4

Appendix B: BIOS POST Codes

POST Code Description

D2h Unknown interrupt

D4h Check Intel Branding string

D8h Alert Standard Format initialization

D9h Late init for IPMI

DEh Log error if micro-code not updated properly

The following are for boot block in Flash ROM

POST Code Description

E0h Initialize the chipset

E1h Initialize the bridge

E2h Initialize the CPU

E3h Initialize system timer

E4h Initialize system I/O

E5h Check force recovery boot

E6h Checksum BIOS ROM

E7h Go to BIOS

E8h Set Huge Segment

E9h Initialize Multi Processor

EAh Initialize OEM special code

EBh Initialize PIC and DMA

ECh Initialize Memory type

EDh Initialize Memory size

EEh Shadow Boot Block

EFh System memory test

F0h Initialize interrupt vectors

F1h Initialize Run Time Clock

F2h Initialize video

F3h Initialize System Management Manager

F4h Output one beep

F5h Clear Huge Segment

F6h Boot to Mini DOS

F7h Boot to Full DOS

If the BIOS detects errors on 2C, 2E, or 30 (base 512K RAM error), it displays an

additional word-bitmap (xxxx) indicating the address line or bits that have failed. For

example, “2C 0002” means address line 1 (bit one set) has failed. “2E 1020" means

data bits 12 and 5 (bits 12 and 5 set) have failed in the lower 16 bits. The BIOS also

sends the bitmap to the port-80 LED display. It fi rst displays the checkpoint code,

followed by a delay, the high-order byte, another delay, and then the loworder byte of

the error. It repeats this sequence continuously.

B-5

X6DH8-G2+/X6DHE-G2+ User's Manual

Notes

B-6

Appendix C: Software Installation Instructions

Appendix C

Installing Software Drivers and the Windows

Operating System

After all the hardware has been installed, you must fi rst confi gure the Adaptec

Embedded Serial ATA RAID Driver before you install the Windows operating system.

The necessary drivers are all included on the Supermicro bootable CDs that came

packaged with your motherboard. (The following section provides information on

Adaptec's SATA RAID Driver based on the Intel ICH5R Controller. For detailed
information on Adaptec's SCSI SATA HostRAID Utility, please refer to the CDs
included in the shipping package)

C-1 Introduction to the Adaptec Embedded Serial ATA RAID
Controller Driver

Serial ATA (SATA)

Serial ATA(SATA) is a physical storage interface. It uses a single cable with a

minimum of four wires to create a point-to-point connection between devices. It

is a serial link which supports SATA Transfer rates from 150MBps. Because the

serial cables used in SATA are thinner than the traditional cables used in Paral-

lel ATA(PATA), SATA systems have better airfl ow and can be installed in smaller

chassis than Parallel ATA. In addition, the cables used in PATA can only extend

to 40cm long, while Serial ATA cables can extend up to one meter. Overall, Serial

ATA provides better functionality than Parallel ATA.

Introduction to the Intel ICH5R I/O Controller Hub

Located in the South Bridge of the Intel E7520 (Lindenhurst) Chipset, the ICH5R

I/O Controller Hub provides the I/O subsystem with access to the rest of the sys-

tem. It supports 2-channel Ultra ATA/100 Bus Master IDE controller (PATA) and

two Serial ATA (SATA) Host Controllers, which support up to two Serial ATA ports

and up to two RAID drives. The ICH5R I/O Controller Hub supports the following

Parallel ATA (PATA) and Serial (SATA) device confi gurations:

ATA Operate Mode

You can select from the following two modes: Combined Mode and Enhanced

Mode.

Combined Mode:

In this mode, system BIOS assigns the traditional IRQ 14 and IRQ 15 for the use

of HDD. Up to 4 ATA devices are supported by this mode.

C-1

X6DH8-G2+/X6DHE-G2+ User's Manual

Within the Combined Mode, the following three modes are supported:

Non-Combined Mode: Parallel ATA only:with the maximum of 4 devices sup-

ported;

Non-Combined Mode: Serial ATA only:with the maximum of 2 devices supported;

Combined Mode: SATA devices and PATA: with the support of 2 devices each

(total: 4 devices maximum). (For IDE/SATA confi gurations, please refer to the table

below.)

Primary Master(=PM) Yes Yes No No No No
Primary Slave(=PS) Yes No Yes No No No
Secondary Master(=SM)

Yes No No Yes No No
Secondary Slave(=SS) Yes No No No Yes No
SATA Port0 No SM SM PM PM PM
SATA Port1 No SS SS PS PS PS
*Note: (No=Not Present, Yes=Present) Also, if Logical Primary is
selected, the IDE channels are no longer available.

Enhanced Mode:

In this mode, system BIOS will automatically search for all available IRQs for the

use of HDD. For newer Operating Systems that support the Enhanced Mode, such

as Windows XP, Windows 2000, and Windows 2003, you can set SATA and PATA

to the Enhanced Mode. (The newer Operating Systems can accommodate both

Enhanced Mode and Combined Mode and support up to 6 ATA devices.)

(Please refer to the "Advanced Chipset Control" under the "Advanced" Setup in the

BIOS for the selection of Combined Mode or Enhanced Mode.)

C-2

Appendix C: Software Installation Instructions

Confi guring BIOS settings for the SATA RAID Functions (En­hanced Mode)

1. Press the <Del> key during system bootup to enter the BIOS Setup Utility.

(Note: If it is the fi rst time to power on the system, we recommend that you load the

Optimized Default Settings. If you have already done so, please skip to Step 3.

2. Use the arrow keys to select the "Exit" Menu. Once in the "Exit" Menu, scroll

down the menu to select the item- "Load Setup Default" and press the <Enter>

key. Select "Yes" to confi rm the selection. Press the <Enter> key to load the default

settings to the BIOS.

3. Use the arrow keys to select the "Main" Menu in the BIOS.

4. Scroll down to "SATA RAID Enable" and press the <Enter> Key to select this

option.

5. From this submenu, select "Enable" and press <Enter>.

6. Tap the <Esc> key and scroll down to "Exit". Select "Save and Exit" from the

"Exit" menu. Press the <Enter> key to save the changes and exit the BIOS.

7. Once you've exited the BIOS Utility, the system will re-boot.

8. During the system startup, press the <Ctrl> and the <A> keys simultaneously to

run the Adaptec RAID Confi guration Utility when prompted by the following mes-

sage:

Press <Ctrl><A> for Adaptec RAID Confi guration Utility.

C-3

X6DH8-G2+/X6DHE-G2+ User's Manual

The Adaptec Embedded Serial ATA with HostRAID Controller
Driver

Adaptec's Embedded Serial ATA RAID with HostRAID controller adds RAID func-

tionality to the Serial ATA I/O controller by supporting RAID 0 (Striping) or RAID

1 (Mirroring) to enhance the industry's pioneer PCI-to-e host controller products.

RAID striping (RAID 0) can greatly improve hard disk I/O performance because

of its capability in striping data across multiple drives. RAID mirroring (RAID 1)

allows the data to be simultaneously written to two drives, so critical data is al-

ways available even if a single hard disk fails. Due to the built-in functionality, the

X6DH8-G2+/X6DHE-G2+ is specially designed to keep pace with the increasing

performance demands of computer systems by improving disk I/O throughput and

providing data accessibility regardless of a single disk failure. By incorporating the

Adaptec Embedded Serial ATA into the motherboard design, Supermicro's X6DH8-

G2+/X6DHE-G2+ offers the user with the benefi ts of SATARAID without the high

costs associated with hardware RAID applications.

(Note: For Adaptec's RAID Driver Installation Instructions, please refer to the

Adaptec RAID Controller User's Guide: "Emb_SA_RAID_UG.pdf" in the CD that

came with this motherboard. You can also download a copy of Adaptec's User's

Guide from our web site at www.supermicro.com.)

Using the Adaptec RAID Confi guration Utility (ARC)

The Adaptec RAID Confi guration Utility is an embedded BIOS Utility, including:

Array Confi guration Utility: Use this utility when you want to create, confi gure and

manage arrays.

Disk Utilities: Use this option to format or verify disks.

To run the Adaptec RAID Confi guration Utility, you will need to enable the RAID

function in the system BIOS (refer to Chapter 4 for System BIOS Confi gurations),

and then, press the <Ctrl> and <A> keys simultaneously when prompted to do so

during the system startup. (Refer to the previous page for detailed instructions.)

Note: To select an option, use the arrow keys to highlight the item and then press the

<Enter> key to select it. To return to the previous menu, press the <ESC> key.

A. Using the Array Confi guration Utility (ACU)

The Array Confi guration Utility (ACU) enables you to create, manage, and delete

arrays from the controller’s BIOS, add and delete spare drives, and initialize drives.

During the system startup, press <Ctrl> and <A> key simultaneously, and the main

menu will appear.

C-4

Appendix C: Software Installation Instructions

Managing Arrays

Select this option to view array properties, and delete arrays. The following sections

describe the operations Of "Managing Arrays".

To select this option,

Arrays" from the main menu (as shown above).

use the arrow keys and the <enter> key to select "Managing

C-5

X6DH8-G2+/X6DHE-G2+ User's Manual

Viewing Array Properties

To view the properties of an existing array:

1. At the BIOS prompt, press Ctrl+A.

2. From the ARC menu, select Array Confi guration Utility (ACU).

3. From the ACU menu, select Manage Arrays (as shown on the previous

screen.)

4. From the List of Arrays dialog box, select the array you want to view and press

Enter.

The Array Properties dialog box appears, showing detailed

information on the array. The physical disks associated with the array are displayed

here.

5. Press Esc to return to the previous menu.

Deleting Arrays

Warning: Back up the data on an array before you delete it to prevent the loss of

data. Deleted arrays cannot be restored.

To delete an existing array:

1. Turn on your computer and press Ctrl+A when prompted to access the ARC

utility.

2. From the ARC main menu, select Array Confi guration Utility

(ACU).

3. From the ACU menu, select Manage Arrays.

4. Select the array you wish to delete and press Delete.

5. In the Array Properties dialog box, select Delete and press Enter. The following

prompt is displayed:

Warning!! Deleting the array will render array unusable. Do you want to delete
the array?(Yes/No):

RAID 1 only—the following prompt is also displayed:

Deleting the partition will result in data loss! Do you also want to delete the
partition? (Yes/No):

6. Press Yes to delete the array or partition or No to return to the previous menu.

7. Press Esc to return to the previous menu.

C-6

Appendix C: Software Installation Instructions

Creating Arrays

Before creating arrays, make sure the disks for the array are connected and installed

in your system. Note that disks with no usable space, or disks that are un-initialized

are shown in gray and cannot be used. See

To create an array:

1. Turn on your computer and press Ctrl+A when prompted to access the ARC

utility.

2. From the ARC menu, select Array Confi guration Utility Main Menu (ACU) (as

shown on the fi rst screen on page C-5).

3. From the ACU menu, select Create Array.

4. Select the disks for the new array and press Insert (as the screen shown be-

low).

Note: To deselect any disk, highlight the disk and press Delete.

Initializing Disk Drives.

5. Press Enter when both disks for the new array are selected. The Array Proper-

ties menu displays (as the screen shown on the next page).

C-7

X6DH8-G2+/X6DHE-G2+ User's Manual

Assigning Array Properties

Once you've create a new array, you are ready to assign the properties to the

array.

Caution: Once the array is created and its properties are assigned,

you cannot change the array properties using the ACU. You will need to use the

Adaptec Storage Manager - Browser Edition. (Refer to Adaptec's User's Guide in

the enclosed CD.)

To assign properties to the new array:

1. In the Array Properties menu (as shown in the following screen), select an array

type and press Enter.

Note: only the available array types: RAID 0, and RAID1, are displayed on the

screen. (RAID 0 or RAID 1 requires two drives.)

C-8

Appendix C: Software Installation Instructions

2. Under the item "Arrays Label", type in an label and press Enter. (Note: The label

shall not be more than 15 characters.)

3. For RAID 0, select the desired stripe size. (Note: Available stripe sizes are 16,

32, and 64 KC-default. It is recommended that you do not change the default set-

ting.)

4. The item: "Create RAID via" allows you to select between the different creating

methods for RAID 0 and RAID 1.

The following table gives examples of when each is appropriate.

Raid Level Create Via When Appropriate

RAID 0 No Init Creating a RAID 0 on new drives
RAID 0 Migrate

(*Note)

RAID 1 Build1 Any time you wish to create a RAID 1, but especially if

RAID 1 Clear Creating a RAID 1 on new drives, or when you want to

RAID 1 Quick

RAID 1 Init

Creating a RAID 0 from one new drive and
one drive with data you wish to preserve

you have data on one drive that you wish to preserve

ensure that the array contains no data after creation.
Fastest way to create a RAID 1.
Appropriate when using new drives

Note: If you select Migrate for RAID 0, or Build for RAID 1, you will be asked to
select the source drive. The contents of the source drive will be preserved. However,
the data on the new drive will be lost.

C-9

X6DH8-G2+/X6DHE-G2+ User's Manual

5. When you are fi nished, press Done (as the screen shown below).

Notes:

1. Before adding a new drive to an array, back up any data contained on the new

drive. Otherwise, all data will be lost.

2. If you stop the Build or Clear process on a RAID 1 from ACU, you can restart

it by pressing Ctrl+R.

3. A RAID 1 created using the Quick Init option may return some data mis-com-

pares if you later run a consistency check. This is normal and is not a cause for

concern.

4. The ACU allows you to use drives of different sizes in a

RAID . However, during a build operation, only the smaller drive can be selected

as the source or fi rst drive.

5. When migrating from single volume to RAID 0, migrating from a larger drive to

a smaller drive is allowed. However, the destination drive must be at least half the

capacity of the source drive.

6. Adaptec does not recommend that you migrate or build an array on Windows

dynamic disks (volumes), as it will result in data loss.

Warning: Do not interrupt the creation of a RAID 0 using the Migrate option. If you

do, you will not be able to restart, or to recover the data that was on the source

drive.

C-10

Appendix C: Software Installation Instructions

Adding a Bootable Array

To make an array bootable:

1. From the Main menu, select Manage Arrays.

2. From the List of Arrays, select the array you want to make bootable, and press

Ctrl+B.

3. Enter Y to create a bootable array when the following message is displayed: "This

will make all other existing bootable array non-bootable. Do you want to make this

array bootable? (Yes/No):" Then, a bootable array will be created. An asterisk will

appear next to the bootable array (as shown in the picture below:)

Deleting a Bootable Array

To delete a bootable array:

1. From the Main menu, select Manage Arrays.

2. From the List of Arrays, select the bootable array (*) you want to delete, andpress

Ctrl+B. (*a bootable array is the array marked with an asterisk (as shown in the

picture above.)

3. Enter Y to delete a bootable array when the following message is displayed:

"The array is already marked bootable. Do you want to make this array as not

bootable? (Yes/No):" Then, the bootable array will be deleted and the asterisk will

disappear.

Note: do not use the delete key to delete the bootable array.

C-11

X6DH8-G2+/X6DHE-G2+ User's Manual

Adding/Deleting Hotspares

Note: In order to rebuild a RAID (RAID 0 or RAID 1), you would need to add a

new HDD as a hotspare.

1. Turn on your computer and press Ctrl+A as prompted to access the ARC Util-

ity.

2. From the ARC menu, select Array Confi guration Utility (ACU).

3. From the ACU menu, select Add/Delete Hotspares.

4. Use the up and down arrow keys to highlight and select the disk you want to

designate as a hotspare, and press <Insert>, and then, press <Enter>.

5. Press yes when the following prompt is displayed:

"Do you want to create spare?" (Yes/No?)

The spare you have selected will appear in the Select Drive Menu.

C-12
