Preface
About This Manual

This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and use
of the X6DAL-B2/X6DAL-TB2 motherboard. The X6DAL­B2/X6DAL-TB2 supports single or dual Intel® Xeon NoconaTM processors at
a 800 MHz front side bus. Based upon Intel's NetBurst microarchitecture,
the Xeon EM64T (Nocona) processor supports IA-32 and IA-64 software
and includes features found in the XeonTM processor such as Hyper
Pipelined Technology, which includes a multi-stage pipeline, allowing the
processor to operate at much higher core frequencies. Packaged in a 604­pin Flip Chip Micro Pin Grid Array(FC-mPGA4) platform in a Zero Insertion
Force(ZIF) socket (mPGA 604), the Xeon EM64T Processor (800 MHz) sup­ports Hyper-Threading Technology and is ideal for high performance work­station and server environments with up to two processors on one system
bus. Please refer to the motherboard specifications pages on our web site
(http://www.supermicro.com/products/motherboard/) for updates on sup­ported processors. This product is intended to be professionally installed.

Manual Organization

Chapter 1 begins with a checklist of what should be included in your

mainboard box, describes the features, specifications and performance of
the motherboard and provides detailed information about the chipset.

Preface

Chapter 2 begins with instructions on handling static-sensitive devices.
Read this chapter when you want to install the processor and DIMM memory
modules and when mounting the mainboard in the chassis. Also refer to
this chapter to connect the floppy and hard disk drives, SCSI drives, the IDE
interfaces, the parallel and serial ports, the keyboard and mouse, the power
supply and various control panel buttons and indicators.

If you encounter any problems, see Chapter 3, which describes trouble­shooting procedures for the video, the memory and the setup configuration
stored in CMOS. For quick reference, a general FAQ [Frequently Asked
Questions] section is provided.

Chapter 4 includes an introduction to BIOS and provides detailed informa­tion on running the CMOS Setup utility.

Appendix A lists BIOS Error Beep Codes and DS LED POST Codes.
Appendix B provides BIOS POST codes.
Appendix C provides software installation instructions.

Appendix D provides installation instructions on the Adaptec SATA

HostRAID Driver based on Marvell's chip.
