Supermicro X10SDV-4C+-TLN4F User Manual

X10SDV

Flex ATX Series

USER’S MANUAL

1.0a

The information in this user’s manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
and makes no commitment to update or to keep current the information in this manual, or to notify
any person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu­mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE
USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.
SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED
WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between the manufacturer and the customer shall be governed by the laws of
Santa Clara County in the State of California, USA. The State of California, County of Santa Clara
shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for
all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Manual Revision: 1.0a

Release Date: July 29, 2016

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.

Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2016 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

Preface

This manual is written for system integrators, IT technicians and

knowledgeable end users. It provides information for the installation and use of the

X10SDV Flex ATX Series motherboard.

About This Motherboard

The X10SDV Flex ATX Series motherboard supports an Intel® Xeon/

Pentium SoC (System-on-a-Chip) D-1500 Family processor in a BGA package. The

X10SDV Flex ATX Series motherboard addresses a low-power, high-density infra-

structure need with up to 16 Cores and 128 GB of DDR4 memory, two integrated

10 Gigabit Ethernet SFP+ ports, up to 6 Gigabit Intel Ethernet ports, USB 3.0 and a

thermal design up to 65 watts. The X10SDV Flex ATX Series motherboard provides

software consistency from the data center to the storage and network edge with the

same instruction set as the robust Xeon processor.

Please refer to our website at (http://www.supermicro.com/products/) for memory

support updates. This product is intended to be installed and serviced by profes-

sional technicians.

Manual Organization

Preface

Chapter 1 describes the features, specications and performance of the mother-

board, and provides detailed information on the Intel Xeon/Pentium D-1500 Family

processor.

Chapter 2 provides hardware installation instructions. Read this chapter when in-

stalling the processor, memory modules and other hardware components into the

system. If you encounter any problems, see Chapter 3, which describes trouble-

shooting procedures for video, memory and system setup stored in the CMOS.

Chapter 4 includes an introduction to the BIOS, and provides detailed information

on running the CMOS Setup utility.

Appendix A provides BIOS Error Beep Codes.

Appendix B lists software program installation instructions.

Appendix C contains UEFI BIOS Recovery instructions.

Appendix D contains Dual Boot Block instructions.

iii

X10SDV Flex ATX Series Motherboard User’s Manual

Conventions Used in the Manual:

Special attention should be given to the following symbols for proper installation and

to prevent damage done to the components or injury to yourself:

Warning: Critical information to prevent damage to the components or injury to your-

self.

Important: Important information given to ensure proper system installa-

tion or to relay safety precautions.

Note: Additional Information given to differentiate various models or to

provide instructions for correct system setup.

iv

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Web Site: www.supermicro.nl

Contacting Supermicro

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)

Tel: [phone]

Fax: [phone]

Email: [e-mail]

Web Site: www.supermicro.com.tw

v

X10SDV Flex ATX Series Motherboard User’s Manual

Table of Contents

Preface

Chapter 1 Introduction

1-1 Overview ......................................................................................................... 1-1

1-2 Processor Overview ..................................................................................... 1-15

1-3 Special Features ........................................................................................... 1-16

1-4 PC Health Monitoring .................................................................................... 1-16

1-5 ACPI Features ............................................................................................... 1-17

1-6 Power Supply ................................................................................................ 1-17

Chapter 2 Installation

2-1 Standardized Warning Statements ................................................................. 2-1

Battery Handling .............................................................................................. 2-1

Product Disposal ............................................................................................. 2-3

2-2 Static-Sensitive Devices .................................................................................. 2-4

Precautions ..................................................................................................... 2-4

Unpacking ....................................................................................................... 2-4

2-3 Motherboard Installation .................................................................................. 2-5

Tools Needed .................................................................................................. 2-5

Location of Mounting Holes ............................................................................ 2-5

Installing the Motherboard .............................................................................. 2-6

2-4 Memory Support .............................................................................................. 2-7

Memory Population Guidelines ....................................................................... 2-7

Memory Installation Guidelines ....................................................................... 2-8

Installing DIMM Memory Modules ................................................................... 2-8

Removing DIMM Memory Modules ................................................................. 2-8

2-5 Connectors/IO Ports ........................................................................................ 2-9

Back panel I/O Panel ...................................................................................... 2-9

Serial Port ................................................................................................. 2-10

VGA .......................................................................................................... 2-10

Gigabit Ethernet LAN Ports .......................................................................2-11

10G SFP+/Ethernet LAN Ports .................................................................2-11

Universal Serial Bus (USB) ...................................................................... 2-12

Unit Identier Switch ................................................................................ 2-13

Front Control Panel ....................................................................................... 2-14

Front Control Panel Pin Denitions............................................................... 2-15

Power LED .............................................................................................. 2-15

Power Button ........................................................................................... 2-15

HDD LED .................................................................................................. 2-16

vi

Table of Contents

NIC1/NIC2 (LAN1/LAN2) .......................................................................... 2-16

Overheat (OH)/Fan Fail/PWR Fail/UID LED ............................................ 2-17

Reset Button ........................................................................................... 2-17

Power Fail LED ....................................................................................... 2-18

2-6 Connecting Cables ........................................................................................ 2-19

ATX PWR, DC PWR and HDD PWR Connectors (JPW1, JPV1, JPH1) 2-19

Fan Headers (FAN1 ~ FAN4, FANA, FANB)............................................ 2-20

Chassis Intrusion ..................................................................................... 2-20

4-pin External I2C BMC Header ............................................................... 2-21

DOM PWR Connector .............................................................................. 2-21

TPM Header/Port 80 Header ................................................................... 2-22

Overheat LED Header .............................................................................. 2-22

Speaker .................................................................................................... 2-23

Standby Power ......................................................................................... 2-23

Serial Link I/O Header .............................................................................. 2-24

System Management Bus Header ........................................................... 2-24

NVMe I2C Header ..................................................................................... 2-25

Power SMB (I2C) Header ......................................................................... 2-25

General Purpose I/O Header ................................................................... 2-26

2-7 Jumper Settings ............................................................................................ 2-27

Explanation of Jumpers ................................................................................ 2-27

VGA Enable .............................................................................................. 2-27

CMOS Clear ............................................................................................. 2-28

PCI-E Slot SMB Enable (I2C1/I2C2) ......................................................... 2-28

Watch Dog Timer Enable ......................................................................... 2-29

USB Wake-Up ......................................................................................... 2-29

Management Engine (ME) Recovery ...................................................... 2-30

ME Manufacturing Mode .......................................................................... 2-30

BIOS Recovery ......................................................................................... 2-31

BMC Enabled ........................................................................................... 2-31

GbE LAN Ports Enable/Disable ............................................................... 2-32

10GbE LAN Ports Enable/Disable ........................................................... 2-32

SAS Port Enable/Disable ......................................................................... 2-33

2-8 Onboard Indicators ........................................................................................ 2-34

LAN LEDs ................................................................................................. 2-34

BMC Heartbeat LED ................................................................................ 2-34

Onboard Power LED ............................................................................... 2-35

Overheat/PWR Fail/Fan Fail LED ............................................................ 2-35

Unit Identication LED .............................................................................. 2-36

vii

X10SDV Flex ATX Series Motherboard User’s Manual

10G LAN Activity LED .............................................................................. 2-37

10G LAN Link Status LED ....................................................................... 2-37

SAS Hearbeat LED .................................................................................. 2-38

2-9 SATA Connections ......................................................................................... 2-39

SATA Ports .............................................................................................. 2-39

SAS Ports (7TP8F/7TP4F only) ............................................................... 2-39

M.2 Socket ............................................................................................... 2-40

Mini PCI-E Slot ......................................................................................... 2-40

Chapter 3 Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

3-2 Technical Support Procedures ........................................................................ 3-3

3-3 Frequently Asked Questions ........................................................................... 3-4

3-4 Battery Removal and Installation .................................................................... 3-5

3-5 Returning Merchandise for Service................................................................. 3-6

Chapter 4 BIOS

4-1 Introduction ...................................................................................................... 4-1

4-2 Main Setup ...................................................................................................... 4-2

4-3 Advanced Setup Congurations...................................................................... 4-4

4-4 Event Logs .................................................................................................... 4-28

4-5 IPMI ............................................................................................................... 4-30

4-6 Security Settings ........................................................................................... 4-33

4-7 Boot Settings ................................................................................................. 4-36

4-8 Save & Exit ................................................................................................... 4-38

Appendix A BIOS Error Beep Codes

A-1 BIOS Error Beep Codes .................................................................................A-1

Appendix B Software Installation Instructions

B-1 Installing Software Programs ..........................................................................B-1

B-2 Installing SuperDoctor5 ...................................................................................B-2

Appendix C UEFI BIOS Recovery Instructions

C-1 An Overview to the UEFI BIOS ......................................................................C-1

C-2 How to Recover the UEFI BIOS Image (-the Main BIOS Block)....................C-1

C-3 To Recover the Main BIOS Block Using a USB-Attached Device..................C-1

Appendix D Dual Boot Block

D-1 Introduction ......................................................................................................D-1

D-2 Steps to Reboot the System by Using Jumper JBR1 ....................................D-2

viii

Chapter 1: Introduction

Chapter 1

Introduction

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged

leader in the industry. Supermicro boards are designed with the utmost attention to

detail to provide you with the highest standards in quality and performance.

Please check that the following items have all been included with your motherboard.

If anything listed here is damaged or missing, contact your retailer.

The following items are included in the retail box:

• One (1) Supermicro Motherboard

• Four (4) SATA cables

• Four (4) Mini-SAS HD cables (7TP8F/7TP4F only)

• One (1) I/O shield

• One (1) Quick Reference Guide

Note: For your system to work properly, please follow the links below to

download all necessary drivers/utilities and the user's manual for your

motherboard.

Supermicro product manuals: http://www.supermicro.com/support/manuals/

Product Drivers and utilities: ftp://ftp.supermicro.com/

If you have any questions, please contact our support team at support@supermicro.

com.

1-1

X10SDV Flex ATX Series Motherboard User’s Manual

X10SDV-7TP8F Motherboard Image

Note: All graphics shown in this manual were based upon the latest PCB Revision

available at the time of publishing of the manual. The motherboard you have re-

ceived may or may not look exactly the same as the graphics shown in this manual.

1-2

Chapter 1: Introduction

X10SDV-7TP4F Motherboard Image

X10SDV-4C-7TP4F Motherboard Image
X10SDV-2C-7TP4F Motherboard Image

Note: All graphics shown in this manual were based upon the latest PCB Revision

available at the time of publishing of the manual. The motherboard you have re-

ceived may or may not look exactly the same as the graphics shown in this manual.

1-3

X10SDV Flex ATX Series Motherboard User’s Manual

X10SDV-TP8F Motherboard Image

X10SDV-2C-TP8F Motherboard Image

Note: All graphics shown in this manual were based upon the latest PCB Revision

available at the time of publishing of the manual. The motherboard you have re-

ceived may or may not look exactly the same as the graphics shown in this manual.

1-4

Chapter 1: Introduction

X10SDV-2C-TP4F Motherboard Image

Note: All graphics shown in this manual were based upon the latest PCB Revision

available at the time of publishing of the manual. The motherboard you have re-

ceived may or may not look exactly the same as the graphics shown in this manual.

1-5

X10SDV Flex ATX Series Motherboard User’s Manual

X10SDV-4C+-TP4F Motherboard Image

Note: All graphics shown in this manual were based upon the latest PCB Revision

available at the time of publishing of the manual. The motherboard you have re-

ceived may or may not look exactly the same as the graphics shown in this manual.

1-6

Chapter 1: Introduction

X10SDV Flex ATX Series Motherboard Layout

JNVI2C1

JPME2

LED7

A

LEDM1

CPU SLOT7 PCI-E 3.0 X8

4-7:SPEAKER

1-3:PWR LED

JD1:

JD1

SATA DOM + POWER

JSD2

JSAS1
L-SAS0-3

JSAS2

L-SAS4-7

A

C

UID

M2_SRW3

C

LED8

C

M2_SRW2

2-3:DISABLE

M2_SRW1

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

I-SATA0

I-SATA1

JSD1

PRESS FIT

PRESS FIT

PRESS FIT

JPL3

VGA

JPL3:

LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

LEDT1

LEDT4

A

A

C

C

LEDT3

A

A

C

C

LAN 7/8

1-2:ENABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

JPL2

JPL1/JPL2:
LAN1/

LAN 5/6

LAN 3/4

DIMMB2

DIMMA1

DIMMB1

DIMMA2

JPL1

LAN2

2-3:DISABLE

X10SDV-TP8F

REV:1.01

LAN 1/2

DESIGNED IN USA

Intel Xeon
D-1500
SoC

JPME1

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JGP1

FAN2

JF1:

HDD

PWR

OH

PWR

NIC2

NIC1

X

RST

LED

LED

FF

ON

USB 2

JTPM1

LED3

FAN4

C

JF1

IPMI_LAN
USB 0/1(3.0)

JPW1

JPH1

JPUSB1

JSTBY1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPV1

JPI2C1

FAN1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JPB1

JSMB1

JIPMB1

MP_SRW1

BMC
AST2400

CPU SLOT6 PCI-E 3.0 X8

JI2C1

JI2C2

JPG1

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

USB 5/6

LEDS1

A

LSI
2116
(-7TP4F/-7TP8F)

I-SATA3

USB 3/4

JSAS4

JSAS3

L-SAS12-15

L-SAS8-11

PRESS FIT

I-SATA2

FANA

FANB

PRESS FIT

Important Notes to the User

1. See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front

panel connections.

2. " " indicates the location of "Pin 1". Jumpers not indicated are for testing

only.

1-7

MP-SRW1

MP-SRW2

JIPMB1

JPB1
JSMB1
JI2C1

JI2C2

JPG1

COM1

JPS1
JBR1
JWD1

JL1

JOH1

USB5/6
I-SATA3
USB3/4
I-SATA2

FANB

FANA

L-SAS8-11

X10SDV Flex ATX Series Motherboard User’s Manual

X10SDV Flex ATX Series Motherboard Quick Reference

LAN7/8

LEDM1

LED8

LED7

JPL3

VGA

LAN5/6

LAN3/4

UID

Slot7

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JNVI2C1

JPME2

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JD1

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

JSD2

JSD1

A

LED7

C

UID

VGA

M2_SRW3

C

LED8

A

C

LEDM1

M2-SRW2

M2_SRW2

2-3:DISABLE

1-2:ENABLE

JPTG1:

CPU SLOT7 PCI-E 3.0 X8

10Gb LAN

JITP1

M2_SRW1

M2-SRW1

JMD1: M.2

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA0

I-SATA1

I-SATA0

JTPM1

JSD2

JSD1

PRESS FIT

USB 2

PRESS FIT

JSAS2

L-SAS4-7

FAN4

USB2

FAN4

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

i350
AM4
(-7TP8F/

-TP8F)

JPTG1

JPTG1

JTPM1

LED3

LED3

C

JF1

PRESS FIT

JPL3

LEDT2

A

C

A

LEDT4

C

LAN 7/8

Intel Xeon
D-1500
SoC

JPME1

JF1

JPME1

LEDT1

A

C

LEDT3

A

C

JBT1

BT1

JGP1

JGP1

LAN 5/6

JPL2

JPL1/JPL2:
LAN1/
1-2:ENABLE

JPL2

LAN 3/4

DIMMB2

DIMMA1

DIMMB1

DIMMA2

JPL1

JPL1

LAN2

2-3:DISABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

DIMMB2

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

FAN2

OH

PWR

X

RST

FF

ON

FAN2

FAN3

I-SGPIO1

DIMMB1

JF1:

NIC2

NIC1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

Slot6

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

JBR1

JMP1

JWD1

JLANLED1

JLANLED1

JL1

JTGLED1

JTGLED1

JOH1

LSI

A

2116

LEDS1

USB 5/6

(-7TP4F/-7TP8F)

LEDS1

I-SATA3

FANB

I-SATA1

USB 3/4

JSAS3
L-SAS8-11

PRESS FIT

I-SATA2

FANA

L-SAS12-15

BMC
AST2400

L-SAS4-7

L-SAS0-3

IPMI LAN

LAN1/2

LAN 1/2

DIMMA1

DIMMA2

HDD

PWR

LED

LED

JPH1

USB0/1

IPMI_LAN
USB 0/1(3.0)

JPUSB1

JPV1

JPW1

JPH1

JSTBY1

JSTBY1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPI2C1

JPW1

FAN1

FAN1

1-8

Chapter 1: Introduction

X10SDV Flex ATX Series Motherboard Model Variation Tables

X10SDV Flex ATX Series Motherboard Model Variation Table

Model X10SDV-

Processor Name Xeon D-1587 Xeon D-1537 Xeon D-1518 Pentium D1508

# of Cores 16 8 4 2

# of Threads 32 16 8 4

Cache 24 MB 12 MB 6 MB 3 MB

Processor Base Frequency 1.7 GHz 1.7 GHz 2.2 GHz 2.2 GHz

Intel Turbo Boost Frequency 2.3 GHz 2.3 GHz N/A 2.6 GHz

SoC TDP 65 W 35 W 35 W 25 W

16 SAS2/SATA3 ports from LSI 2116 SW Controller Yes Yes Yes Yes

Dual 1GbE LAN from i210 controller Yes Yes Yes Yes

Quad 10GbE LAN from i350-AM2 controller Ye s No No No

Dual 10GbE LAN from SoC Yes Yes Yes Yes

CPU Heatsink with FAN No No No No

7TP8F

X10SDV Flex ATX Series Motherboard Model Variation Table

Model X10SDV-

Processor Name Xeon D-1518 Xeon D-1518 Pentium D1508 Pentium D1508

# of Cores 4 4 2 2

# of Threads 8 8 4 4

Cache 6 MB 6 MB 3 MB 3 MB

Processor Base Frequency 2.2 GHz 2.2 GHz 2.2 GHz 2.2 GHz

Intel Turbo Boost Frequency N/A N/A 2.6 GHz 2.6 GHz

SoC TDP 35 W 35 W 25 W 25 W

16 SAS2/SATA3 ports from LSI 2116 SW Controller No No No No

Dual 1GbE LAN from i210 controller Yes Yes Yes Yes

Quad 10GbE LAN from i350-AM2 controller Ye s No Yes No

Dual 10GbE LAN from SoC Yes Yes Yes Yes

CPU Heatsink with FAN No Yes No No

TP8F

X10SDV-

7TP4F

X10SDV-4C+-

TP4F

X10SDV-4C-

7TP4F

X10SDV-2C-

TP8F

X10SDV-2C-

7TP4F

X10SDV-2C-

TP4F

1-9

X10SDV Flex ATX Series Motherboard User’s Manual

Jumpers

Jumper Description Default

JBR1 BIOS Recovery Pins 1-2 (Normal)

JBT1 CMOS Clear Open: Normal, Short: Clear CMOS

JI2C1/JI2C2 SMB to PCI-Exp. Slots Pins 2-3 (Disabled)

JPB1 BMC Enable (Debug use only) Pins 1-2 (Enabled)

JPG1 VGA Enable Pins 1-2 (Enabled)

JPL1 LAN1 Enable Pins 1-2 (Enabled)

JPL2 LAN2 Enable Pins 1-2 (Enabled)

JPL3 LAN3/4/5/6 Enable

(7TP8F/TP8F only)

JPME1 ME Recovery Pins 1-2 (Normal)

JPME2 Manufacturing Mode Pins 1-2 (Normal)

JPS1 SAS 2.0 Controller Enable/Dis-

able (7TP8F/7TP4F only)

JPTG1 10Gb Ethernet Enable Pins 1-2 (Enabled)

JPUSB1 USB Wakeup (USB0/1) Pins 1-2 (Enabled)

JWD1 Watch Dog Enable Pins 1-2 (Reset)

Headers/Connectors

Connector Description

BT1 Onboard Battery

COM1 COM1 Header

FAN1 ~ FAN4

FANA, FANB

IPMI LAN Dedicated IPMI LAN Port

I-SATA0 ~ I-SATA5 Intel SATA Ports (I-SATA0 / I-SATA1 support SuperDOM,

I-SGPIO1 Serial Link General Purpose I/O Header

JD1 Speaker (Pins 1-3: Power LED, Pins 4-7: Speaker)

JF1 Front Panel Control Header

JGP1 General Purpose I/O Header

JIPMB1 4-pin External SMbus I2C Header (for an IPMI Card)

JL1 Chassis Intrusion Header

JLANLED1 LAN3 ~ LAN6 Activity LED Header (7TP8F/TP8F only)

JMD1 M.2 PCI-E 3.0 X4 / I-SATA4 Slot

JMP1 Mini PCI-E 2.0 X1 / I-SATA5 Slot

JNVI2C1 NVMe I2C Header

CPU/System Cooling Fans

I-SATA4 via M.2, I-SATA5 via Mini-PCIE mSATA)

Pins 1-2 (Enabled)

Pins 1-2 (Enabled)

1-10

Chapter 1: Introduction

JOH1 Overheat LED Header

JPH1 4-pin Power Connector for HDD use (To provide power

from the motherboard to onboard HDD devices.)

JPI2C1 Power Supply SMBus I2C Header

JPV1 12V 8-pin DC Power Connector (To provide alternative

JPW1 24-pin ATX Power Connector

JSD1, JSD2 SATA DOM (Device On Module) Power Connectors

JSMB1 SMBus Header

JSTBY1 5V Standby Power Header

JTGLED1 LAN7 ~ LAN8 Activity LED Header

JTPM1 Trusted Platform Module (TPM)/Port 80 Connector

LAN1 ~ LAN8 Gigabit Ethernet (RJ45) Ports (LAN1 ~ LAN6)

L-SAS0 ~ L-SAS15 SAS 2.0/SATA 3.0 Ports (7TP8F/7TP4F only)

M2-SRW1 ~ SRW3 M.2 Mounting Screws

MP-SRW1 ~ SRW2 PCI-E 2.0 X1 / I-SATA5 Slot Mounting Screws

SLOT6, SLOT7 CPU PCI-E 3.0 X8 Slot

UID Unit ID Button

USB 0/1 Back panel USB 3.0 Por ts

USB 2 USB Type-A Connector

USB 3/4, 5/6 Front Access USB 2.0 Ports

VGA Back panel VGA Port

power for special enclosure when the 24-pin ATX power is
not in use.)

(LAN3 ~ LAN6 on 7TP8F/TP8F only)
10Gigabit Ethernet (SFP+) Ports (LAN7 ~ LAN8)

LED Indicators

LED Description Color/State Status

LED3 Power LED Green: On System Power On

LED7 UID Switch LED Blue: On Unit Identied

LED8 Overheat/PWR Fail/Fan Fail

LED

LEDM1 BMC Heartbeat LED Green: Blinking BMC: Normal

LEDS1 SAS Heartbeat LED

(7TP8F/7TP4F only)

LEDT1 LAN7 Link Status Green: On LAN7 Normal

LEDT2 LAN7 Activity Green: Blinking LAN7 Active

LEDT3 LAN8 Link Status Green: On LAN8 Normal

LEDT4 LAN8 Activity Green: Blinking LAN8 Active

Red: Solid on
Blinking

Green: Blinking

Red

Overheat
PWR Fail or Fan Fail

SAS Active

SAS Error

1-11

X10SDV Flex ATX Series Motherboard User’s Manual

Motherboard Features

CPU Intel Xeon/Pentium D-1500 Family Processor (BGA)

Memory Supports up to 128GB DDR4 ECC RDIMM or 64GB

DDR4 ECC/Non-ECC UDIMM with a max data rate of

2133MHz in four (4) slots

DIMM sizes

DIMMs 4GB, 8GB, 16GB and 32GB (32GB

for RDIMM only, Dual Rank Data

width x4)

Expansion Slot One (1) M.2 PCIe 3.0 x4 Slot, M Key for 2242/2280/22110

SSD, SATA 3.0 support (Mux with I-SATA4)

One (1) Mini PCI-E 2.0 X1 slot with mSATA support (Mux

with I-SATA5)

Network Connections Network Controllers

Intel SoC integrated 10GbE Controller
Intel® I350 AM4 10GbE Controller (7TP8F/TP8F only)
Intel® I210 1GbE Controller

LAN Ports

Up to Six (6) RJ-45 and two (2) SFP+ ports on the rear
IO panel with Link and Activity LEDs

IPMI LAN Port

Supported by Aspeed AST2400 BMC

IO Devices SATA/SAS Connections

SATA 3.0 (6GB/s) Four (4) SATA 3.0 ports, one (1)

SAS 2.0/SATA 3.0 Sixteen (16) ports via four 4) Mini-

USB Devices

Four (4) USB 2.0 via header
Two (2) USB 3.0 via rear IO panel connector
One (1) USB Type-A

Serial (COM) Port

One (1) header

IPMI 2.0

IPMI 2.0 supported by Aspeed AST2400 BMC (Base­board Management Controller)

VGA (Graphics Display)

One (1) VGA Port on the rear IO panel supported by the
Aspeed AST2400 VGA Controller

via M.2, one (1) via Mini-PCIE
mS ATA

SAS HD cables (7TP8F/7TP4F
only)

1-12

Chapter 1: Introduction

BIOS 128 Mb AMI BIOS® SPI EEPROM BIOS

Plug and Play, ACPI 5.0, SMBIOS 2.8, BIOS Rescue
Hot-Key, RTC Wakeup, Dual-Boot Block

Power Conguration ACPI/ACPM Power Management (S0, S4 and S5 only)

Wake-On LAN

Power Button Override

Power-on mode for AC power recovery

PC Health Monitoring Onboard Voltage Monitoring

+1.8V, +3.3V, +5V, +/-12V, +3.3V Stby, +5V Stdby, VBAT,
HT, Memory, PCH Temp, System Temp, Memory Temp

CPU 1+1-phase switching voltage regulator

CPU/System overheat LED and control

CPU Thermal Trip support

Power Supply Monitoring

Thermal Monitor Support

Fan Control

Low noise fan speed control

BMC Health Monitoring

BMC Fan control and thermal alert by sensors monitor­ing, including CPU, memory and motherboard ambient
temperatures

System Management PECI (Platform Environment Conguration Interface) 3.0

System resource alert via SuperDoctor® 5

SuperDoctor® 5, Watch Dog Timer, NMI, Node Manager

Chassis Intrusion header and detection

Other RoHS (Full Compliance, Lead Free)

Operating Temperature 00-600C

Dimensions Flex ATX form factor (9.0" x 7.25")

1-13

X10SDV Flex ATX Series Motherboard User’s Manual

X10SDV Flex ATX Series Block Diagram

M.2 CONN

mini PCIe

LAN I210

LAN I210

LAN I350

PCIE 3.0 x8

PCIE 3.0 x8

PCIE 3.0 x4

PCIE 3.0 x4

SATA GEN 3

PCIE 2.0 x1

PCIE 2.0 x1

PCIE 2.0 x1

PCIE 2.0 x4

PCIE 2.0 x1

SOC

PROCESSOR

SATA Gen3

PCIE 2.0

PCI-E 2.0

USB

LPC

KR

MINI-SAS HD

SATA3.0#3

JLAN1

JLAN2JLAN3

JPCIE1 PCIE 3.0 x8

JPCIE2 PCIE 3.0 x8

SAS2

SATA3.0#0

SATA3.0#1

SATA3.0#2

LSI SAS2116

SATA3.0#4 SATA3.0#5

DDR4 1600/1866/2133

B1

B1

B

B

DDR4 DIMM

DDR4 DIMM

iXFI

INPHI CS4227

USB 3.0

USB 3.0 connector x2

USB 2.0

(compatible with 2.0)

x2

USB HUB
GL854G

x1

A2

A

A1

A

DDR4 DIMM

DDR4 DIMM

SFP+

USB 2.0 Header x2

USB 2.0 Header x2

USB 2.0 TypeA

VGA
CONN

x1

3rd LAN

+

USB3.0

REAR IO

1G LAN1G LAN

1G LAN

SFP+

COM1

FLASH

IPMI LAN

DDR 3

SPI

AST2400

PHY

RTL8211F

BMC

System Block Diagram

Note: This is a general block diagram and may not exactly represent

the features on your motherboard. See the Motherboard Features

pages for the actual specications of each motherboard.

1-14

VGA

Chapter 1: Introduction

1-2 Processor Overview

The Intel® Xeon D-1500 Series processor is a low-powered 64-bit SoC (System-on-

a-Chip) processor that is optimized to deliver high performance, energy efciency,

and enhances the total cost of ownership solutions. The low-power consumption

of the processor makes it suitable for microservers that can ef fectively take on

hyperscale workloads, intelligent edge network or ultra-dense embedded devices.

Based on the 14nm microarchitecture, the Xeon/Pentium D-1500 Family processor

utilizes up to 16 processor cores on 65W of power.

Intel Xeon/Pentium D-1500 Processor Features

• Low Power Consumption

• Server-Class Reliability, Availability and Serviceability (RAS)

• Intel Hyper-Threading and AVX2

• Intel Turbo Boost (Not available for D-1518)

• Intel Virtualization Technology (VT-x, VT-d)

• 10 Gigabit Ethernet Controller Built In

• Up to 128GB DDR4 ECC RDIMM or 64GB ECC/Non-ECC UDIMM with a maxi-

mum data rate of 2133MHz

• AES-NI, OS Guard, TXT Security Features

• SoC Built-in USB 3.0, USB 2.0 and 6 SATA 3.0 with SGPIO support

• Intel Rapid Storage Technology Enterprise (RSTe)

1-15

X10SDV Flex ATX Series Motherboard User’s Manual

1-3 Special Features

Recovery from AC Power Loss

Basic IO System (BIOS) provides a setting for you to determine how the system will

respond when AC power is lost and then restored to the system. You can choose for

the system to remain powered off, (in which case you must press the power switch

to turn it back on), or for it to automatically return to a power-on state. See the Ad-

vanced BIOS Setup section to change this setting. The default setting is Last State.

1-4 PC Health Monitoring

This section describes the PC health monitoring features of the board. All have

an onboard System Hardware Monitoring chip that supports PC health monitoring.

An onboard voltage monitor will scan these onboard voltages continuously: +1.8V,

+3.3V, +5V, +/-12V, +3.3V Stby, +5V Stdby, VBAT, HT, Memory, PCH Temp, System

Temp, and Memory Temp. Once a voltage becomes unstable, a warning is given,

or an error message is sent to the screen.

Environmental Temperature Control

The X10SDV Flex ATX Series motherboard comes with a passive or active heatsink

built in. Please follow the instructions given in your system design guide or your

system user manual to provide adequate airow to your system. The onboard Base-

Board Management Controller (BMC) monitors CPU, memory and motherboard

environment temperatures for fan control and PC health management.

Note: To avoid possible system overheating, please be sure to provide

adequate airow to your system.

System Resource Alert

This feature is available when the system is used with SuperDoctor® 5 in the

Windows and Linux operating systems. SuperDoctor is used to notify the user of

certain system events. For example, you can congure SuperDoctor to provide

you with warnings when the system temperature, CPU temperatures, voltages

and fan speeds go beyond predened thresholds.

1-16

Chapter 1: Introduction

1-5 ACPI Features

ACPI stands for Advanced Conguration and Power Interface. The ACPI specica-

tion denes a exible and abstract hardware interface that provides a standard

way to integrate power management features throughout a PC system, including

its hardware, operating system and application software. This enables the system

to automatically turn on and off peripherals such as CD-ROMs, network cards, hard

disk drives and printers.

In addition to enabling operating system-directed power management, ACPI also

provides a generic system event mechanism for Plug and Play, and an operating

system-independent interface for conguration control. ACPI leverages the Plug and

Play BIOS data structures, while providing a processor architecture-independent

implementation that is compatible with Windows® 7, Windows 8, and Windows 2008

operating systems. The X10SDV series motherboards support S0, S4 and S5 only.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and

reliable operation. It is even more important for processors that have high CPU

clock rates.

It is strongly recommended that you use a high quality power supply that meets ATX

power supply Specication 2.02 or above. It must also be SSI compliant. (For more

information, please refer to the web site at http://www.ssiforum.org/). Additionally, in

areas where noisy power transmission is present, you may choose to install a line

lter to shield the computer from noise. It is recommended that you also install a

power surge protector to help avoid problems caused by power surges.

Note 1: The X10SDV Flex ATX Series motherboard alternatively supports

an 8-pin 12V DC input power supply for embedded applications. The 12V

DC input is limited to 36A by design. It provides up to 432W power input

to the motherboard. Please keep onboard power use within the power

limits specied above. Over-current DC power use may cause damage

to the motherboard!

Note 2: Do not use the 8-pin DC power at JPV1 when the 24-pin ATX

Power at JPW1 is connected to the power supply. Do not plug in both

JPV1 and JPW1 at the same time.

1-17

X10SDV Flex ATX Series Motherboard User’s Manual

Notes

1-18

Chapter 2: Installation

Chapter 2

Installation

2-1 Standardized Warning Statements

The following statements are industry-standard warnings, provided to warn the user

of situations which have the potential for bodily injury. Should you have questions or

experience difculty, contact Supermicro's Technical Support department for assis-

tance. Only certied technicians should attempt to install or congure components.

Read this section in its entirety before installing or conguring components in the

Supermicro chassis.

Battery Handling

Warning!

There is a danger of explosion if the battery is replaced incorrectly. Replace the

battery only with the same or equivalent type recommended by the manufacturer.

Dispose of used batteries according to the manufacturer's instructions

電池の取り扱い

電池交換が正しく行われなかった場合、破裂の危険性があります。 交換する電池はメー
カーが推奨する型、または同等のものを使用下さい。 使用済電池は製造元の指示に従
って処分して下さい。

警告
电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更
换原有电池。请按制造商的说明处理废旧电池。

警告
電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有
電池。請按照製造商的說明指示處理廢棄舊電池。

Warnung

Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die

Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp.

Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers.

2-1

X10SDV Flex ATX Series Motherboard User’s Manual

Attention

Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer

que par une pile de type semblable ou équivalent, recommandée par le fabricant.

Jeter les piles usagées conformément aux instructions du fabricant.

¡Advertencia!

Existe peligro de explosión si la batería se reemplaza de manera incorrecta. Re-

emplazar la batería exclusivamente con el mismo tipo o el equivalente recomen-

dado por el fabricante. Desechar las baterías gastadas según las instrucciones

del fabricante.

!הרהזא

תנכס תמייקץוציפ .הניקת אל ךרדב הפלחוהו הדימב הללוסה לש ףילחהל שי

גוסב הללוסה תא מ םאותה תרבחלמומ ןרציתצ.

תוללוסה קוליס תושמושמה עצבל שי .ןרציה תוארוה יפל









경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일
하거나 제조사에서 권장하는 동등한 종류의 배터리로만 교체해야 합니다. 제조사
의 안내에 따라 사용된 배터리를 처리하여 주십시오.

Waarschuwing

Er is ontplofngsgevaar indien de batterij verkeerd vervangen wordt. Vervang de

batterij slechts met hetzelfde of een equivalent type die door de fabrikant aan-

bevolen wordt. Gebruikte batterijen dienen overeenkomstig fabrieksvoorschriften

afgevoerd te worden.

2-2

Chapter 2: Installation

Product Disposal

Warning!

Ultimate disposal of this product should be handled according to all national laws

and regulations.

製品の廃棄

この製品を廃棄処分する場合、国の関係する全ての法律・条例に従い処理する必要が
ありま す。

警告
本产品的废弃处理应根据所有国家的法律和规章进行。

警告
本產品的廢棄處理應根據所有國家的法律和規章進行。

Warnung

Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen

des Landes erfolgen.

¡Advertencia!

Al deshacerse por completo de este producto debe seguir todas las leyes y regla-

mentos nacionales.

Attention

La mise au rebut ou le recyclage de ce produit sont généralement soumis à des

lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de

l'organisme compétent.

רצומה קוליס

!הרהזא

ו תויחנהל םאתהב תויהל בייח הז רצומ לש יפוס קוליס.הנידמה יקוח

2-3

X10SDV Flex ATX Series Motherboard User’s Manual

 

경고!

이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다.

Waarschuwing

De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming

met alle nationale wetten en reglementen.

2-2 Static-Sensitive Devices

Electrostatic-Discharge (ESD) can damage electronic com ponents. To avoid dam-

aging your system board, it is important to handle it very carefully. The following

measures are generally sufcient to protect your equipment from ESD.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing the board from the antistatic

bag.

• Handle the board by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the motherboard and peripherals back into their antistatic bags when not in

use.

• For grounding purposes, make sure your computer chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

• Use only the correct type of onboard CMOS battery. Do not install the onboard

battery upside down to avoid possible explosion.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static damage. When

unpacking the board, make sure that the person handling it is static protected.

2-4

Chapter 2: Installation

2-3 Motherboard Installation

All motherboards have standard mounting holes to t different types of chassis.

Make sure that the locations of all the mounting holes for both motherboard and

chassis match. Although a chassis may have both plastic and metal mounting fas-

teners, metal ones are highly recommended because they ground the motherboard

to the chassis. Make sure that the metal standoffs click in or are screwed in tightly.

Then use a screwdriver to secure the motherboard onto the motherboard tray.

Tools Needed

Philips Screwdriver

(1)

Philips Screws (6)

Location of Mounting Holes

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JD1

JSAS1
L-SAS0-3

PRESS FIT

L-SAS4-7

A

LED7

C

UID

M2_SRW3

C

LED8

A

C

LEDM1

M2_SRW2

CPU SLOT7 PCI-E 3.0 X8

M2_SRW1

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

SATA DOM + POWER

I-SATA1

JSD2

JSD1

PRESS FIT

PRESS FIT

JSAS2

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

JITP1

I-SATA0

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

LSI

A

2116
(-7TP4F/-7TP8F)

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

BMC
AST2400

JSAS4
L-SAS12-15

Standoffs (6)

Only if Needed

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

LEDT1

A

A

C

i350
AM4
(-7TP8F/

-TP8F)

JPTG1

JTPM1

USB 2

FAN4

C

LEDT3

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

JGP1

LAN 3/4

LAN 5/6

DIMMB2

DIMMB1

DIMMA2

JPL2

JPL1

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

DIMMA1

X10SDV-TP8F

FAN2

PWR

ON

LAN 1/2

JF1:

HDD

PWR

OH

NIC2

NIC1

X

RST

LED

LED

FF

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

Caution: 1) To avoid damaging the motherboard and its components, please do

not use a force greater than 8 lb/inch on each mounting screw during motherboard

installation. 2) Some components are very close to the mounting holes. Please take

precautionary measures to avoid damaging these components when installing the

motherboard to the chassis.

2-5

X10SDV Flex ATX Series Motherboard User’s Manual

Installing the Motherboard

1. Install the I/O shield into the back of the chassis.

2. Locate the mounting holes on the motherboard. See the previous page.

3. Locate the matching mounting holes on the chassis. Align the mounting holes

on the motherboard against the mounting holes on the chassis.

4. Install standoffs in the chassis as needed.

5. Install the motherboard into the chassis carefully to avoid damaging other

motherboard components.

6. Using the Phillips screwdriver, insert a Phillips head #6 screw into a mounting

hole on the motherboard and its matching mounting hole on the chassis.

7. Repeat Step 5 to insert #6 screws into all mounting holes.

8. Make sure that the motherboard is securely placed in the chassis.

Note: Images displayed are for illustration only. Your chassis or compo-

nents might look different from those shown in this manual.

2-6

Chapter 2: Installation

2-4 Memory Support

The X10SDV Flex ATX Series motherboard supports up to 128GB of DDR4 ECC

RDIMM or 64GB of DDR4 ECC/Non-ECC UDIMM with speeds up to 2133MHz

in four memory slots. Populating these DIMM slots with memory modules of the

same type and size will result in interleaved memory, which will improve memory

performance.

Note: Check the Supermicro website for recommended memory modules.

CAUTION

Exercise extreme care when installing or removing DIMM

modules to prevent any possible damage.

Memory Population Guidelines

Please follow the table below when populating the motherboard.

Recommended Population (Balanced)

DIMMA1 Slot DIMMB1 Slot DIMMA2 Slot DIMMB2 Slot Total System Memory

4GB 4GB 8GB

4GB 4GB 4GB 4GB 16GB

8GB 8GB 16GB

8GB 8GB 8GB 8GB 32GB

16GB 16GB 32GB

16GB 16GB 16GB 16GB 64GB

32GB 32GB 64GB

32GB 32GB 32GB 32GB 128GB

DIMMB1

DIMMB2

BMC
AST2400

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

JSAS4
L-SAS12-15

PRESS FIT

4-7:SPEAKER

1-3:PWR LED

JD1:

JD1

JSAS1
L-SAS0-3

A

LED7

C

UID

C

LED8

A

C

LEDM1

M2_SRW2

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

M2_SRW3

M2_SRW1

PRESS FIT

JPL3

VGA

JPL3:

LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

2-3:DISABLE

1-2:ENABLE

JPTG1:

A

10Gb LAN

C

i350

A

LEDT4

AM4

C

(-7TP8F/

-TP8F)

JITP1

LAN 7/8

JPTG1

Intel Xeon
D-1500

I-SATA0

JSD1

SoC

JTPM1

USB 2

LED3

JPME1

FAN4

C

JF1

LAN 3/4

LAN 5/6

LEDT1

A

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

JBT1:
CMOS
CLEAR

FAN3

I-SGPIO1

JGP1

DIMMB2

BT1

DIMMA1

DIMMB1

DIMMA2

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

FAN2

PWR

RST

ON

LAN 1/2

JF1:

HDD

PWR

OH

NIC2

NIC1

X

LED

LED

FF

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LSI

A

2116

LEDS1

USB 5/6

(-7TP4F/-7TP8F)

I-SATA3

USB 3/4

JSAS3
L-SAS8-11

PRESS FIT

I-SATA2

FANA

FANB

IPMI_LAN
USB 0/1(3.0)

JPH1

JPUSB1

JPW1

JSTBY1

DIMMA2

DIMMA1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPV1

JPI2C1

FAN1

2-7

X10SDV Flex ATX Series Motherboard User’s Manual

Memory Installation Guidelines

When installing memory modules, the DIMM slots should be populated in the following

order: DIMMA1, DIMMB1, then DIMMA2, DIMMB2.

• Always use DDR4 DIMM modules of the same size, type and speed. Mixing
memory modules of different types and speeds is not allowed.

• The motherboard will support one DIMM module installed. However, for best
memory performance, install DIMM modules in pairs.

Installing DIMM Memory Modules

1. Align the key on the bottom of the DIMM module against the key on the mem-

ory slot. Take note of the notches on the side of the DIMM module, and of the

locking clips on the socket to avoid causing damage.

Module Key

Module Notch

Socket Key

2. Install the DIMM module straight down into the socket until it is securely seat-

ed in the socket. The side clips will automatically lock the module into place.

Locking Clip

Removing DIMM Memory Modules

Reverse the steps above to remove the DIMM modules from the motherboard.

2-8

Chapter 2: Installation

F

2-5 Connectors/IO Ports

The I/O ports are color coded in conformance with the industry standards. See the

gure below for the colors and locations of the various I/O ports.

Back panel I/O Panel

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

D

A

LED7

C

UID

C

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

M2_SRW3

M2_SRW2

M2_SRW1

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

LEDT1

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

FAN4

A

A

C

C

LEDT3

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

JGP1

H

LAN 3/4

LAN 5/6

DIMMB2

DIMMB1

JPL2

JPL1

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

DIMMA2

DIMMA1

X10SDV-TP8F

FAN2

PWR

ON

LAN 1/2

JF1:

HDD

PWR

OH

NIC2

NIC1

X

RST

LED

LED

FF

J

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3

L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

A

B

E

G

I

K

L

C

Back Panel I/O

A. IPMI LAN E. LAN Port 1 I. LAN Port 5 (7TP8F/TP8F only)

B. USB Port 1 F. LAN Port 4 (7TP8F/TP8F only) J. LAN Port 8 (SFP+)

C. USB Port 0 G. LAN Port 3 (7TP8F/TP8F only) K. LAN Port 7 (SFP+)

D. LAN Port 2 H. LAN Port 6 (7TP8F/TP8F only) L. VGA Port

2-9

X10SDV Flex ATX Series Motherboard User’s Manual

Serial Port

A COM port is on the motherboard to

provide a front accessible serial con-

nection. See the table on the right for

pin denitions.

96

1

5

COM1 Pin Layout

VGA

A VGA port is located next to the LAN ports on

the I/O back panel. Use this port to connect to

a compatible VGA display.

B

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JSAS1
L-SAS0-3

JSAS4

L-SAS12-15

PRESS FIT

A

LED7

C

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

PCI-E 3.0 X4 / I-SATA4

JD1:

JD1

SATA DOM + POWER

JSD2

JSAS2

L-SAS4-7

UID

LED8

JMD1: M.2

I-SATA1

PRESS FIT

PRESS FIT

M2_SRW3

C

M2_SRW2

M2_SRW1

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

FAN4

A

A

C

C

A

LEDT4

A

C

LAN 7/8

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

A

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

COM Port 1

Pin Denitions

Pin # Denition Pin # Denition

1 DCD 6 DSR

2 RXD 7 RTS

3 TXD 8 CTS

4 DTR 9 RI

5 Ground 10 N/A

A. COM1

B. VGA

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

LEDT1

JPL2

JPL1

LEDT3

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JGP1

FAN2

JF1:

HDD

OH

PWR

NIC2

NIC1

X

RST

LED

FF

ON

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPW1

JPH1

JSTBY1

PWR
LED

JPUSB1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPV1

JPI2C1

FAN1

2-10

Chapter 2: Installation

Gigabit Ethernet LAN Ports

Up to six Gigabit Ethernet ports (LAN1

~ LAN6, LAN3 ~ LAN6 on 7TP8F/TP8F

only) and an IPMI LAN port are located

on the I/O back panel to provide net-

work connections. These ports accept

RJ45 type cables.

Note: Please refer to the LED

Indicator Section for LAN LED

information.

10G SFP+/Ethernet LAN Ports

Two 10 Gigabit SFP+ (Small-form

Factor Pluggable) Ethernet LAN ports,

supported by the SoC, are located at

LAN7 and LAN8 on the I/O back panel.

Please refer to the 10G LAN LED sec-

tion for 10G LAN LED information.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

M2_SRW3

C

M2_SRW2

M2_SRW1

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

LED3

FAN4

C

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

LSI

A

2116
(-7TP4F/-7TP8F)

JSAS3
L-SAS8-11

PRESS FIT

BMC
AST2400

I-SATA5

LAN Port

Pin Denitions

Pin # Denition Pin # Denition

1 VCC 10 SGND

2 TD0+ 11 Act LED

3 TD0- 12 P3V3SB

4 TD1+ 13 Link 100 LED

5 TD1- 14 Link 1000 LED

6 TD2+ 15 Ground

7 TD2- 16 Ground

8 TD3+ 17 Ground

9 TD3- 18 Ground

A. LAN7/8

B. LAN5/6 ((7TP8F/TP8F only)

C. LAN3/4 (7TP8F/TP8F only)

D. LAN1/2

E. IPMI LAN

A

PRESS FIT

JPL3

LEDT2

LEDT1

A

A

C

C

LEDT3

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

JPME1

JF1

JGP1

C

B

LAN 5/6

DIMMB2

DIMMB1

JPL2

JPL1

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

DIMMA1

DIMMA2

X10SDV-TP8F

FAN2

LAN 3/4

D

LAN 1/2

JF1:

HDD

PWR

OH

PWR

NIC2

NIC1

X

RST

LED

LED

FF

ON

(Green, +3V3SB)

(Yellow, +3V3SB)

E

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

IPMI_LAN
USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

FAN1

2-11

X10SDV Flex ATX Series Motherboard User’s Manual

Universal Serial Bus (USB)

Two USB 3.0 ports (USB0/1) are located on the I/O back plane. Two USB 2.0 head-

ers (USB3/4 and USB5/6) and one USB Type-A header are on the motherboard

to provide front panel access. USB cables are not included. See the tables below

for pin denitions.

Back Panel USB

Pin Denitions

Pin # Denition Pin # Denition

1 +5V 5 +5V

2 USB_PN1 6 USB_PN0

3 USB_PP1 7 USB_PP0

4 Ground 8 Ground

Internal USB Port 2.0

Pin Denitions

Pin # Denition Pin # Denition

1 +5V 2 +5V

3 USB_PN2 4 USB_PN3

5 USB_PP2 6 USB_PP3

7 Ground 8 Ground

9 Key 10 NC

A. USB 3.0 Ports 0/1

B. USB 2.0 Ports 3/4

C. USB 2.0 Ports 5/6

D. USB Type-A

A

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

C

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

M2_SRW3

M2_SRW2

M2_SRW1

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

LEDT1

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

LEDT4

A

C

A

C

LAN 7/8

Intel Xeon
D-1500
SoC

A

C

LEDT3

A

C

D

LED3

FAN4

JPME1

C

JF1

JGP1

LAN 3/4

LAN 5/6

DIMMB2

DIMMB1

JPL2

JPL1

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

DIMMA2

X10SDV-TP8F

DIMMA1

FAN2

LAN 1/2

JF1:

HDD

PWR

OH

PWR

NIC2

NIC1

X

RST

LED

LED

FF

ON

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

C

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

B

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

2-12

Chapter 2: Installation

Unit Identier Switch

A Unit Identier (UID) Switch and two LED

indicators are located on the motherboard. The

UID Switch is located next to the VGA port on

the back panel. The Rear UID LED (LED7) is

located next to the UID Switch. The Front Panel

UID LED is located at Pin 7 of the Front Control

Panel at JF1. Connect a cable to Pin 7 on JF1

for Front Panel UID LED indication. When you

press the UID switch, both Rear UID LED and

Front Panel UID LED Indicators will be turned

on. Press the UID switch again to turn off both

LED Indicators. These UID Indicators provide

easy identication of a system unit that may be

in need of service.

Note: UID can also be triggered via

IPMI on the motherboard. For more

information on IPMI, please refer to

the IPMI User's Guide posted on our

website at http://www.supermicro.

com.

A

B

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JSAS1
L-SAS0-3

JSAS4

L-SAS12-15

PRESS FIT

A

LED7

C

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

PCI-E 3.0 X4 / I-SATA4

JD1:

JD1

SATA DOM + POWER

JSD2

JSAS2

L-SAS4-7

UID

LED8

JMD1: M.2

I-SATA1

PRESS FIT

PRESS FIT

M2_SRW3

C

M2_SRW2

M2_SRW1

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

LEDT1

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

FAN4

A

A

C

C

LEDT3

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

JGP1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

UID Switch

Pin# Denition

1 Ground

2 Ground

3 Button In

4 Button In

UID LED

Status

Color/State Status

Blue: On Unit Identied

A. UID Switch

B. Rear UID LED

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

JPL2

JPL1

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

FAN2

JF1:

OH

PWR

NIC2

NIC1

X

RST

FF

ON

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

HDD

PWR

LED

LED

FAN1

2-13

X10SDV Flex ATX Series Motherboard User’s Manual

1

2

1516

Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally located

on a control panel at the front of the chassis. These connectors are designed spe-

cically for use with Supermicro chassis. See the gure below for the descriptions

of the front control panel buttons and LED indicators. Refer to the following section

for descriptions and pin denitions.

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LSI

A

2116

LEDS1

USB 5/6

(-7TP4F/-7TP8F)

I-SATA3

USB 3/4

JSAS3

L-SAS8-11

PRESS FIT

I-SATA2

FANA

FANB

NIC1 Activity LED

NIC2 Activity LED

OH/Fan Fail/PWR Fail

LED7

A

BMC
AST2400

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JD1

SATA DOM + POWER

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

JSAS2

L-SAS4-7

FP PWR LED

HDD LED

Power Fail LED

Ground

Ground

A

C

UID

VGA

JPL3:
LAN3/4/5/6

M2_SRW3

C

LED8

C

LEDM1

M2_SRW2

CPU SLOT7 PCI-E 3.0 X8

M2_SRW1

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

I-SATA1

JSD2

PRESS FIT

PRESS FIT

1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

LED3

FAN4

C

JF1 Header Pins

PRESS FIT

JPL3

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

LEDT2

A

A

C

C

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

JPME1

JF1

DIMMA2

LEDT1

JPL2

JPL1

LEDT3

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JGP1

FAN2

JF1:

OH

PWR

NIC2

NIC1

X

RST

FF

ON

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

HDD

PWR

LED

LED

FAN1

3.3 V

3.3V Stby

3.3V Stby

3.3V Stby

UID LED

3.3V

Reset

Reset Button

Power Button

PWR

2-14

1

2

1516

Front Control Panel Pin Denitions

Chapter 2: Installation

Power LED

The Power LED connection is located

on pins 15 and 16 of JF1. Refer to the

table on the right for pin denitions.

Power Button

The Power Button connection is located

on pins 1 and 2 of JF1. Momentarily

contacting both pins will power on/off the

system. This button can be congured as

4 Seconds Override or Instant Off (with a

setting in the BIOS setting, see Chapter

4). Refer to the table on the right for pin

denitions.

Power LED

Pin Denitions (JF1)

Pin# Denition

15 3.3V

16 PWR LED

Power Button

Pin Denitions (JF1)

Pin# Denition

1 Signal

2 Ground

A. PWR LED

B. Power Button

FP PWR LED

A

HDD LED

NIC1 Activity LED

NIC2 Activity LED

OH/Fan Fail/PWR Fail

Power Fail LED

Ground

Ground

2-15

3.3 V

3.3V Stby

3.3V Stby

3.3V Stby

UID LED

3.3V

Reset

PWR

Reset Button

Power Button

B

X10SDV Flex ATX Series Motherboard User’s Manual

on

1

2

1516

HDD LED

The HDD LED connection is located

on pins 13 and 14 of JF1. Attach a

cable here to indicate the status of

HDD-related activities, including IDE,

SATA activities. See the table on the

right for pin denitions.

NIC1/NIC2 (LAN1/LAN2)

The NIC (Network Interface Control-

ler) LED connection for LAN port 2

is located on pins 9 and 10 of JF1,

and the LED connection for LAN Port

1 is on Pins 11 and 12. Attach NIC

LED cables to their respective pins to

display network activities. Refer to the

table on the right for pin denitions.

HDD LED

Pin Denitions (JF1)

Pin# Denition

13 3.3V Standby

14 HD LED

LAN1/LAN2 LED

Pin Denitions (JF1)

Pin# Denition

9-11 3.3V Standby

10-12 NIC Activity LED

A. HDD LED

B. NIC1 Activity LED

C. NIC2 Activity LED

FP PWR LED

A

B

C

OH/Fan Fail/PWR Fail

HDD LED

NIC1 Activity LED

NIC2 Activity LED

Power Fail LED

Ground

Ground

2-16

3.3 V

3.3V Stby

3.3V Stby

3.3V Stby

UID LED

3.3V

Reset

PWR

Reset Button

Power Butt

Chapter 2: Installation

on

1

2

1516

Overheat (OH)/Fan Fail/PWR Fail/ UID LED

Connect an LED cable to pins 7 and

8 of Front Control Panel to use the

Overheat/Fan Fail/Power Fail and

UID LED connections. The blue LED

on pin 7 works as the front panel UID

LED indicator. The red LED on pin 8

works provides warnings of overheat,

fan failure or power failure. The red

LED takes precedence over the blue

LED by default. Refer to the table on

the right for pin denitions.

Reset Button

The Reset Button connection is lo-

cated on pins 3 and 4 of JF1. Attach

it to a hardware reset switch on the

computer case to reset the system.

Refer to the table on the right for pin

denitions.

OH/Fan Fail/PWR Fail/Blue UID LED

Pin Denitions (JF1)

Pin# Denition

7 Blue UID LED

8 OH/Fan Fail/Power Fail Cathode

Reset Button

Pin Denitions (JF1)

Pin# Denition

3 Reset

4 Ground

A. (Blue) UID LED

B. (Red) OH/Fan Fail/PWR Fail LED

B

OH/Fan Fail/PWR Fail

FP PWR LED

HDD LED

NIC1 Activity LED

NIC2 Activity LED

Power Fail LED

Ground

Ground

2-17

3.3 V

3.3V Stby

3.3V Stby

3.3V Stby

UID LED

3.3V

Reset

PWR

A

Reset Button

Power Butt

X10SDV Flex ATX Series Motherboard User’s Manual

on

1

2

1516

Power Fail LED

The Power Fail LED connection is lo-

cated on pins 5 and 6. Refer to the table

on the right for pin denitions.

Pin Denitions (JF1)

Pin# Denition

5 3.3V

6 Power Fail

A. PWR Fail LED

Power Fail

FP PWR LED

HDD LED

NIC1 Activity LED

NIC2 Activity LED

OH/Fan Fail/PWR Fail

Power Fail LED

A

Ground

Ground

2-18

3.3 V

3.3V Stby

3.3V Stby

3.3V Stby

UID LED

3.3V

Reset

PWR

Reset Button

Power Butt

Chapter 2: Installation

1

4

4

5

8

2-6 Connecting Cables

This section provides brief descriptions and pin-out denitions for onboard headers

and connectors. Be sure to use the correct cable for each header or connector.

ATX PWR, DC PWR and HDD PWR Connectors (JPW1, JPV1, JPH1)

The 24-pin ATX power connector at

JPW1 is used to provide power to the

motherboard. JPV1 is the 12V DC power

connector that provides alternative power

for special enclosure when the 24-pin

ATX power is not in use. The 4-pin HDD

power connector JPH1 provides power to

onboard HDD devices.

Note: Do not use the 8-pin DC

power at JPV1 when the 24-pin

ATX Power at JPW1 is con-

nected to the power supply. Do

not plug in both JPV1 and JPW1

ATX Power 24-pin Connector

Pin Denitions (JPW1)

Pin# Denition Pin # Denition

13 +3.3V 1 +3.3V

14 NC 2 +3.3V

15 COM 3 COM

16 PS_ON 4 +5V

17 COM 5 COM

18 COM 6 +5V

19 COM 7 COM

20 NC 8 PWR_OK

21 +5V 9 5VSB

22 +5V 10 +12V

23 +5V 11 +12V

24 COM 12 +3.3V

at the same time.

8-pin DC Power

1

Pin Denitions (JPV1)

Pin# Denition

1-4 GND

5-8 12V

BMC
AST2400

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

JSAS4
L-SAS12-15

PRESS FIT

4-7:SPEAKER

1-3:PWR LED

JD1:

JD1

JSAS1
L-SAS0-3

L-SAS4-7

A

LED7

C

UID

M2_SRW3

C

LED8

A

C

LEDM1

M2_SRW2

CPU SLOT7 PCI-E 3.0 X8

M2_SRW1

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

SATA DOM + POWER

I-SATA1

JSD2

JSD1

PRESS FIT

PRESS FIT

JSAS2

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

JITP1

I-SATA0

USB 2

FAN4

A

A

C

i350

A

LEDT4

AM4

C

(-7TP8F/

-TP8F)

LAN 7/8

JPTG1

Intel Xeon
D-1500
SoC

JTPM1

LED3

JPME1

C

JF1

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

LEDT1

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

FAN2

JGP1

OH

PWR

X

RST

FF

ON

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

JF1:

HDD

PWR

NIC2

NIC1

LED

LED

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LSI

A

2116

LEDS1

USB 5/6

(-7TP4F/-7TP8F)

I-SATA3

USB 3/4

JSAS3

L-SAS8-11

PRESS FIT

I-SATA2

FANA

FANB

4-Pin HDD Power

Pin Denitions (JPH1)

Pin# Denition

1 12V

2-3 GND

4 5V

A. 24-Pin ATX Power

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

B. 12V 8-pin DC Power

C. 4-Pin HDD Power

B

A

C

FAN1

2-19

X10SDV Flex ATX Series Motherboard User’s Manual

F

Fan Headers (FAN1 ~ FAN4, FANA, FANB)

This motherboard has six 4-pin fan headers.

Although pins 1-3 of the fan headers are back-

ward compatible with the traditional 3-pin fans,

we recommend you use 4-pin fans to take ad-

vantage of the fan speed control via Pulse Width

Modulation through the BMC. This allows the

fan speeds to be automatically adjusted based

on the motherboard temperature. Refer to the

table on the right for pin denitions.

Chassis Intrusion

A Chassis Intrusion header is located at JL1 on

the motherboard. Attach the appropriate cable

from the header to the chassis to inform you of

an intrusion when the chassis is opened.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

C

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

D

M2_SRW3

M2_SRW2

M2_SRW1

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

LEDT1

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

FAN4

A

A

C

C

LEDT3

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

H

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

PCI-E 2.0 X1 /

A

E

JMP1

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

JSAS3

L-SAS8-11

PRESS FIT

BMC
AST2400

Fan Header

Pin Denitions

Pin# Denition

1 Ground (Black)

2 12V (Red)

3 Tachometer

4 PWM_Control

Chassis Intrusion

Pin Denitions (JL1)

Pin# Denition

1 Ground

2 Intrusion Input

A. Fan 1

B. Fan 2

C. Fan 3

D. Fan 4

E. Fan A

F. Fan B

H. Chassis Intrusion

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

JPL2

JPL1

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

C

JGP1

FAN2

B

JF1:

HDD

OH

PWR

NIC2

NIC1

X

RST

LED

FF

ON

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

FAN1

PWR
LED

A

2-20

Chapter 2: Installation

4-pin External I2C BMC Header

A System Management Bus header

for IPMI 2.0 is located at JIPMB1.

Connect the appropriate cable here

to use the IPMI I2C connection on

your system.

DOM PWR Connector

The Disk-On-Module (DOM) power

connectors, located at JSD1 and

JSD2, provide 5V power to a solid

state DOM storage device connected

to the SATA port. See the table on the

right for pin denitions.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

C

JSAS1
L-SAS0-3

JSAS4

L-SAS12-15

PRESS FIT

A

LED7

C

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

PCI-E 3.0 X4 / I-SATA4

JD1:

JD1

SATA DOM + POWER

JSD2

JSAS2

L-SAS4-7

UID

LED8

JMD1: M.2

I-SATA1

PRESS FIT

PRESS FIT

C

M2_SRW3

M2_SRW2

M2_SRW1

VGA

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

JITP1

JPTG1

I-SATA0

B

JSD1

JTPM1

USB 2

FAN4

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

A

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

i350
AM4
(-7TP8F/

-TP8F)

External I2C Header

Pin Denitions

Pin# Denition

1 Data

2 Ground

3 Clock

4 No Connection

DOM PWR

Pin Denitions

Pin# Denition

1 5V

2 Ground

3 Ground

A. 4-pin External I2C Header

B. JSD1

C. JSD2

PRESS FIT

JPL3

JPL3:

LAN3/4/5/6

1-2:ENABLE

2-3:DISABLE

LAN 3/4

LAN 5/6

DIMMB2

LEDT2

A

A

C

C

A

LEDT4

A

C

LAN 7/8

DIMMB1

LEDT1

JPL2

JPL1

LEDT3

C

JPL1/JPL2:

LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

REV:1.01

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JGP1

DIMMA2

DIMMA1

X10SDV-TP8F

FAN2

PWR

ON

LAN 1/2

JF1:

HDD

PWR

OH

NIC2

NIC1

X

RST

LED

LED

FF

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

2-21

X10SDV Flex ATX Series Motherboard User’s Manual

TPM Header/Port 80 Header

A Trusted Platform Module/Port 80

header, located at JTPM1, provides

Trusted Platform (TPM) support and

Port 80 connection. Use this header

to enhance system performance and

data security. See the table on the

right for pin denitions.

Note: Please go to the fol-

lowing link for more informa-

tion on TPM: http://www.

supermicro.com/manuals/

other/TPM.pdf

Overheat LED Header

The JOH1 header is used to connect

an LED indicator to provide warnings

of chassis overheating Refer to the

tables on right for pin denitions.

A. TPM Header

B. Overheat LED Header

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

C

M2_SRW3

M2_SRW2

M2_SRW1

VGA

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

FAN4

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE

JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

B

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

LSI

A

2116
(-7TP4F/-7TP8F)

JSAS3
L-SAS8-11

PRESS FIT

BMC
AST2400

I-SATA5

i350
AM4
(-7TP8F/

-TP8F)

TPM/Port 80 Header

Pin Denitions

Pin # Denition Pin # Denition

1 LCLK 2 GND

3 LFRAME# 4 <(KEY)>

5 LRESET# 6 +5V

7 LAD 3 8 LAD 2

9 +3.3V 10 LAD1

11 LAD0 12 GND

13 NC 14 NC

15 +3V_DUAL 16 SERIRQ

17 GND 18 Ground

19 3.3V 20 NC

Overheat LED

Pin Denitions

State Denition

1 3.3V

2 OH Active

OH Status (Red LED)

State Denition

Off Normal

Solid Overheat

PRESS FIT

JPL3

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

LEDT2

A

A

C

C

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

A

LED3

JPME1

C

JF1

DIMMA2

LEDT1

JPL2

JPL1

LEDT3

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JGP1

FAN2

OH

PWR

X

RST

FF

ON

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

JF1:

HDD

PWR

NIC2

NIC1

LED

LED

FAN1

2-22

Chapter 2: Installation

Speaker

On the JD1 header, pins 1-3 are used

for the Power LED and pins 4-7 are

used for the speaker. See the table on

the right for pin denitions.

Standby Power

The Standby Power header is located

at JSTBY1 on the motherboard. See

the table on the right for pin deni-

tions.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

A

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

M2_SRW3

C

M2_SRW2

M2_SRW1

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

LED3

FAN4

C

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE

JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

JSAS3
L-SAS8-11

PRESS FIT

BMC
AST2400

JF1

LEDT2

LEDT4

PRESS FIT

A

C

A

C

LAN 7/8

Intel Xeon
D-1500
SoC

Speaker Connector

Pin Denitions

Pin# Denition

1-3 Power LED

4-7 Speaker

Standby Power

Pin Denitions

Pin# Denition

1 +5V Standby

2 Ground

3 No connection

A. JD1

B. Standby Power

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

LEDT1

A

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JPME1

FAN2

JGP1

JF1:

OH

PWR

NIC2

NIC1

X

RST

FF

ON

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

B

HDD

PWR

LED

LED

FAN1

2-23

X10SDV Flex ATX Series Motherboard User’s Manual

Serial Link I/O Header

The Serial Link General Purpose In-

put/Output (SGPIO) header is used to

communicate with the enclosure man-

agement chip in the system. See the

table on the right for pin denitions.

System Management Bus Header

The System Management Bus header

for additional slave devices or sensors

is located as JSMB1. Refer to the table

on the right for pin denitions.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

C

M2_SRW3

M2_SRW2

M2_SRW1

VGA

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

FAN4

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE

JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

B

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

LSI

A

2116
(-7TP4F/-7TP8F)

JSAS3
L-SAS8-11

PRESS FIT

BMC
AST2400

I-SATA5

Serial Link I/O Header

Pin Denitions

Pin# Denition Pin Denition

1 NC 2 NC

3 Ground 4 DATA Out

5 Load 6 Ground

7 Clock 8 NC

SMBus Power

Pin Denitions

Pin# Denition

1 Data

2 Ground

3 Clock

A. I-SGPIO1

B. JSMB1

PRESS FIT

JPL3

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

LAN 3/4

LAN 5/6

DIMMB2

LEDT2

A

A

C

C

A

LEDT4

A

C

LAN 7/8

DIMMB1

LEDT1

JPL2

JPL1

LEDT3

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

REV:1.01

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

A

FAN3

I-SGPIO1

JGP1

DIMMA2

DIMMA1

X10SDV-TP8F

FAN2

LAN 1/2

JF1:

HDD

PWR

OH

PWR

NIC2

NIC1

X

RST

LED

LED

FF

ON

IPMI_LAN

USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

2-24

Chapter 2: Installation

NVMe I2C Header

Connector JNVI2C is a management header for the Supermicro AOC NVMe PCI-E

peripheral cards. Please connect the I2C cable to this connector.

Power SMB (I2C) Header

The Power System Management Bus header

at JPI2C1 monitors the power supply, fan and

system temperature. Refer to the table on the

right for pin denitions.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

C

M2_SRW3

M2_SRW2

M2_SRW1

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JITP1

I-SATA0

JSD1

LEDT2

JPTG1:

10Gb LAN

USB 2

A

C

i350

A

LEDT4

AM4

C

(-7TP8F/

-TP8F)

LAN 7/8

JPTG1

Intel Xeon
D-1500
SoC

JTPM1

LED3

FAN4

C

JF1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

A

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

Standby Power

Pin Denitions

Pin# Denition

1 +5V Standby

2 Ground

3 No connection

A. PCI-E NVMe I2C Header

B. JPI2C1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

LEDT1

A

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JPME1

JGP1

FAN2

JF1:

OH

PWR

NIC2

NIC1

X

RST

FF

ON

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

B

JPW1

JPH1

JSTBY1

HDD

PWR

LED

LED

FAN1

2-25

X10SDV Flex ATX Series Motherboard User’s Manual

General Purpose I/O Header

The JGP1 header is a general purpose

I/O on a pin header. See the table on

the right for pin denitions. Refer to the

board layout below for the location of

the header.

Pin# Denition Pin Denition

1 P3V3 2 GND

3 GP0 4 GP1

5 GP2 6 GP3

GPIO Header

Pin Denitions

7 GP4 8 GP5

9 GP6 10 GP7

GPIO Register Address Table To Control JGPIO Pin Header

JGPIO1 PIN# SoC GPIO# USE Select IO Select Level

1 Power

2 Ground

3 17 IO 0x500 [17] IO 0x504 [17] IO 0x50C [17]

4 68 IO 0x540 [4] IO 0x544 [4] IO 0x548 [4]

5 01 IO 0x500 [1] IO 0x504 [1] IO 0x50C [1]

6 69 IO 0x540 [5] IO 0x544 [5] IO 0x548 [5]

7 06 IO 0x500 [6] IO x0504 [6] IO 0x50C [6]

8 70 IO 0x540 [6] IO 0x544 [6] IO 0x548 [6]

9 07 IO 0x500 [7] IO 0x504 [7] IO 0x50C [7]

10 71 IO 0x540 [7] IO 0x544 [7] IO 0x548 [7]

Note: Please refer to the Intel Xeon Processor D-1500 Product Family

Datasheet for more information.

A. General Purpose Header

BMC
AST2400

CPU SLOT6 PCI-E 3.0 X8

JPME2

JSAS4

L-SAS12-15

PRESS FIT

JNVI2C1

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

A

LED7

C

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

JSD2

PRESS FIT

JSAS2

L-SAS4-7

UID

JMD1: M.2

I-SATA1

PRESS FIT

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE

M2_SRW3

2-3:DISABLE

C

M2_SRW2

M2_SRW1

PHY
10GbE
CS2447

LEDT2

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

JITP1

JPTG1

I-SATA0

JSD1

USB 2

FAN4

A

A

C

C

i350

A

LEDT4

A

AM4

C

(-7TP8F/

-TP8F)

LAN 7/8

Intel Xeon
D-1500
SoC

JTPM1

LED3

JPME1

C

JF1

LAN 3/4

LAN 5/6

LEDT1

JPL2

JPL1

LEDT3

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

JBT1:
CMOS
CLEAR

BT1

FAN3

A

I-SGPIO1

JGP1

DIMMB2

DIMMB1

DIMMA2

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

LAN 1/2

DIMMA1

FAN2

JF1:

HDD

PWR

OH

PWR

NIC2

NIC1

X

RST

LED

LED

FF

ON

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LSI

A

2116

LEDS1

USB 5/6

(-7TP4F/-7TP8F)

I-SATA3

USB 3/4

JSAS3
L-SAS8-11

PRESS FIT

I-SATA2

FANA

FANB

2-26

2-7 Jumper Settings

Explanation of Jumpers

To modify the operation of the mother-

board, jumpers can be used to choose

between optional settings. Jumpers create

shorts between two pins to change the

function of the connector. Pin 1 is identied

with a square solder pad on the printed

circuit board.

Note: On two-pin jumpers,

"Closed" means the jumper is on,

and "Open" means the jumper is

off the pins.

Chapter 2: Installation

VGA Enable

Jumper JPG1 allows the user to enable the

onboard VGA connector. The default setting

is pins 1-2 to enable the connection. See the

table on the right for jumper settings.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

C

M2_SRW3

M2_SRW2

M2_SRW1

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JITP1

I-SATA0

JSD1

LEDT2

JPTG1:

10Gb LAN

USB 2

A

C

i350

A

LEDT4

AM4

C

(-7TP8F/

-TP8F)

LAN 7/8

JPTG1

Intel Xeon
D-1500
SoC

JTPM1

LED3

FAN4

JPME1

C

JF1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

A

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

Jumper Settings

Pin# Denition

1-2 Enabled (Default)

2-3 Disabled

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

LEDT1

A

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JGP1

FAN2

PWR

X

RST

ON

VGA Enable

A. VGA Enable

LAN 1/2

JF1:

HDD

PWR

OH

NIC2

NIC1

LED

LED

FF

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

2-27

X10SDV Flex ATX Series Motherboard User’s Manual

CMOS Clear

JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads

to prevent accidental clearing of CMOS. To clear CMOS, use a metal object such

as a small screwdriver to touch both pads at the same time to shor t the connec-

tion. Always remove the AC power cord from the system before clearing CMOS.

Note 1: For an ATX power supply, you must completely shut down the

system, remove the AC power cord, and then short JBT1 to clear CMOS.

Note 2: Be sure to remove the onboard CMOS Battery before you short

JBT1 to clear CMOS.

Note 3: Clearing CMOS will also clear all passwords.

PCI-E Slot SMB Enable (I2C1/I2C2)

Use jumpers I2C1/I2C2 to enable PCI

SMB (System Management Bus) support

to improve system management for the

onboard PCI-E slot. See the table on the

right for jumper settings.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

C

M2_SRW2

M2_SRW3

M2_SRW1

VGA

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

FAN4

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

B

JI2C2

JPG1

C

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

PCI Slot SMB Enable

Jumper Settings

Pin# Denition

1-2 Enabled

2-3 Disabled (Default)

A. Clear CMOS

B. JI2C1

C. JI2C2

PRESS FIT

JPL3

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

LAN 3/4

LAN 5/6

DIMMB2

LEDT2

A

A

C

C

A

LEDT4

A

C

LAN 7/8

DIMMB1

LEDT1

JPL2

JPL1

LEDT3

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

REV:1.01

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

DESIGNED IN USA

JBT1:

CMOS

A

CLEAR

BT1

FAN3

I-SGPIO1

JGP1

DIMMA2

DIMMA1

X10SDV-TP8F

FAN2

PWR

LAN 1/2

JF1:

HDD

PWR

OH

NIC2

NIC1

X

RST

LED

LED

FF

ON

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

2-28

Chapter 2: Installation

Watch Dog Timer Enable

Watch Dog (JWD1) is a system monitor that

can be used to enter LAN bypass default set-

tings, reset the system or enter NMI when

the Timer expires. Close pins 1-2 to reset the

system if an application hangs. Close pins 2-3

to generate a non-maskable interrupt signal

for the application that hangs. Open all pins

to enter LAN pair default mode only. See the

table on the right for jumper settings. Watch

Dog may be enabled in the BIOS Setup. The

default timer is around 5 minutes.

USB Wake-Up

Use the JPUSB1 jumper to enable the func-

tion of "System Wake-Up via USB devices" for

USB0/1. This jumper allows you to "wake-up"

the system by pressing a key on the USB key-

board or by clicking the USB mouse of your

system. The JPUSB1 jumper is used together

with the USB Wake-Up function in the BIOS.

Enable both the jumper and the BIOS setting

to enable this function. See the table on the

right for jumper settings.

Watch Dog

Jumper Settings

Pin# Denition

1-2 Reset (Default)

2-3 NMI

Open LAN pairs set to default

mode without reset

or NMI

USB Wake-up

Jumper Settings

Pin# Denition

1-2 Enabled (Default)

2-3 Disabled

A. Watch Dog Enable

B. USB Wake-Up

BMC
AST2400

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

JSAS4

L-SAS12-15

PRESS FIT

4-7:SPEAKER

1-3:PWR LED

JSAS1
L-SAS0-3

JD1:

JD1

L-SAS4-7

LED7

A

LEDM1

SATA DOM + POWER

JSAS2

A

C

UID

M2_SRW3

C

LED8

C

M2_SRW2

2-3:DISABLE

1-2:ENABLE

CPU SLOT7 PCI-E 3.0 X8

JITP1

M2_SRW1

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

I-SATA0

I-SATA1

JSD2

JSD1

PRESS FIT

PRESS FIT

PRESS FIT

JPL3

VGA

JPL3:

LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

LEDT1

i350
AM4
(-7TP8F/

-TP8F)

A

A

C

C

LEDT3

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

JPTG1:

10Gb LAN

JPTG1

JTPM1

USB 2

FAN4

LAN 3/4

LAN 5/6

DIMMB2

JPL2

JPL1

JPL1/JPL2:

LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JGP1

DIMMA1

DIMMB1

DIMMA2

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

FAN2

PWR

X

RST

ON

LAN 1/2

JF1:

HDD

PWR

OH

NIC2

NIC1

LED

LED

FF

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

B

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

JBR1

JWD1

JLANLED1

A

JL1

JTGLED1

JOH1

LSI

A

2116

LEDS1

USB 5/6

(-7TP4F/-7TP8F)

I-SATA3

USB 3/4

JSAS3
L-SAS8-11

PRESS FIT

I-SATA2

FANA

FANB

2-29

X10SDV Flex ATX Series Motherboard User’s Manual

Management Engine (ME) Recovery

Use JPME1 to select ME Firmware Re-

covery mode, which will limit resource

allocation for essential system operation

only in order to maintain normal power

operation and management. In the single

operation mode, online upgrade will be

available via Recovery mode. See the

table on the right for jumper settings.

ME Manufacturing Mode

Close JPME2 to bypass SPI ash se-

curity and force the system to use the

Manufacturing Mode, which will allow

the user to ash the system rmware

from a host server to modify system

settings. See the table on the right for

jumper settings.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

B

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

M2_SRW3

C

M2_SRW2

M2_SRW1

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

LED3

FAN4

C

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

JSAS3
L-SAS8-11

PRESS FIT

BMC
AST2400

ME Recovery

Jumper Settings

Pin# Denition

1-2 Normal (Default)

2-3 ME Recovery

Manufacturing Mode

Jumper Settings

Pin# Denition

1-2 Normal (Default)

2-3 Manufacturing Mode

A. ME Recovery

B. Manufacturing Mode

PRESS FIT

JPL3

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

HDD

PWR

LED

LED

FAN1

JF1

LEDT2

LEDT4

A

C

A

C

LAN 7/8

Intel Xeon
D-1500
SoC

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

LEDT1

A

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

A

I-SGPIO1

JPME1

JGP1

FAN2

JF1:

OH

PWR

NIC2

NIC1

X

RST

FF

ON

2-30

Chapter 2: Installation

BIOS Recovery

Close pins 2 and 3 of jumper JBR1 for

BIOS recovery. The default setting is on

pins 1 and 2 for normal operation. See

the table on the right for jumper settings.

BMC Enabled

JPB1 allows you to enable the BMC

(Baseboard Management Control) chip

and the onboard IPMI connection for

debugging purpose only. After the BMC

is disabled, IPMI health and remote

management functions are no longer

supported. See the table on the right for

jumper settings.

Note: Please aways keep BMC

enabled to make sure that the

platform operates reliably with

the health monitor.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

C

LED8

A

C

LEDM1

M2_SRW2

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

M2_SRW3

M2_SRW1

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

LED3

FAN4

C

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

B

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

A

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

BIOS Recovery

Jumper Settings

Pin# Denition

1-2 Normal

2-3 BIOS Recovery

BMC Enabled

Jumper Settings

Pin# Denition

1-2 Enabled (Default)

2-3 Disabled

A. BIOS Recovery

B. BMC Enabled

PRESS FIT

JPL3

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

LEDT2

A

A

C

C

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

JPME1

JF1

DIMMA2

LEDT1

JPL2

JPL1

LEDT3

JPL1/JPL2:

LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JGP1

FAN2

JF1:

OH

PWR

NIC2

NIC1

X

RST

FF

ON

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

HDD

PWR

LED

LED

FAN1

2-31

X10SDV Flex ATX Series Motherboard User’s Manual

GbE LAN Ports Enable/Disable

Jumpers JPL1 and JPL2 are used to enable

or disable LAN por ts 1 and 2, respectively.

Use JPL3 to enable or disable LAN ports 3,

4, 5, and 6. JPL3 is available on X10SDV-

7TP8F/TP8F only. See the table on the right

for jumper settings. The default setting is

enabled.

10GbE LAN Ports Enable/Disable

JPTG1 is used to enable or disable 10GbE

support. See the table on the right for jumper

settings.

C

PRESS FIT

JPL3

VGA

JPL3:

LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JITP1

LEDT2

JPTG1:

10Gb LAN

A

C

i350

A

LEDT4

AM4

C

(-7TP8F/

-TP8F)

LAN 7/8

JPTG1

D

Intel Xeon
D-1500
SoC

I-SATA0

JTPM1

USB 2

LED3

FAN4

JPME1

C

JF1

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

PCI-E 3.0 X4 / I-SATA4

JD1:

JD1

SATA DOM + POWER

JSD2

JSAS2

L-SAS4-7

UID

LED8

JMD1: M.2

I-SATA1

PRESS FIT

PRESS FIT

C

M2_SRW3

M2_SRW2

M2_SRW1

JSD1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

L-SAS8-11

JSAS3

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

GbE LAN Enable

Jumper Settings

Pin# Denition

1-2 Enabled (Default)

2-3 Disabled

10Gb Enable/Disable

Jumper Settings

Pin# Denition

1-2 Enabled (Default)

2-3 Disabled

A. JPL1

B. JPL2

C. JPL3

D. 10Gb LAN Ports Enable/Disable

LAN 1/2

IPMI_LAN
USB 0/1(3.0)

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

LEDT1

A

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

B A

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:

CMOS

CLEAR

BT1

FAN3

I-SGPIO1

JGP1

FAN2

JF1:

HDD

PWR

OH

PWR

NIC2

NIC1

X

RST

LED

LED

FF

ON

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

FAN1

2-32

Chapter 2: Installation

SAS Port Enable/Disable

Use JPS1 to enable the onboard SAS ports.

See the table on the right for jumper settings.

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

C

LED8

A

C

LEDM1

M2_SRW2

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

M2_SRW3

M2_SRW1

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JITP1

LEDT2

JPTG1:

10Gb LAN

A

C

i350

A

LEDT4

AM4

C

(-7TP8F/

-TP8F)

LAN 7/8

JPTG1

Intel Xeon
D-1500
SoC

I-SATA0

JSD1

JTPM1

USB 2

LED3

FAN4

C

JF1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JPB1

JSMB1

JI2C1

JI2C2

JIPMB1

MP_SRW1

BMC
AST2400

JPG1

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

A

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LSI

A

2116

LEDS1

USB 5/6

(-7TP4F/-7TP8F)

I-SATA3

USB 3/4

JSAS3
L-SAS8-11

PRESS FIT

I-SATA2

FANA

FANB

SAS Port Enable/Disable

Jumper Settings

Pin# Denition

1-2 Enabled

2-3 Disabled

A. SAS Port Enable

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

LEDT1

A

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:

LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JPME1

JGP1

FAN2

JF1:

OH

PWR

NIC2

NIC1

X

RST

FF

ON

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

HDD

PWR

LED

LED

FAN1

2-33

X10SDV Flex ATX Series Motherboard User’s Manual

2-8 Onboard Indicators

LAN LEDs

The Ethernet ports have two LEDs. On

each port, one LED indicates activity

when ashing while the other LED may be

green, amber or off to indicate the speed

of the connection. See the tables on the

right for more information.

Activity LED

Link Speed LED

Overheat/PWR Fail/Fan Fail

LED Settings

Color Status Denition

Off No Connection

Yellow Flashing Active

Link Speed LED

Color Denition

Off No Connection or 10 Mbps

Amber 1 Gbps

Green 100Mps (10Gbps for 10GbE Port)

BMC Heartbeat LED

A BMC Hear tbeat LED is located at

LEDM1. See the table on the right for

more information.

A

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JSAS1
L-SAS0-3

JSAS4

L-SAS12-15

PRESS FIT

A

LED7

C

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

PCI-E 3.0 X4 / I-SATA4

JD1:

JD1

SATA DOM + POWER

JSD2

JSAS2

L-SAS4-7

UID

LED8

JMD1: M.2

I-SATA1

PRESS FIT

PRESS FIT

M2_SRW3

C

M2_SRW2

M2_SRW1

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JITP1

I-SATA0

JSD1

LEDT2

JPTG1:

10Gb LAN

i350

LEDT4

AM4
(-7TP8F/

-TP8F)

JPTG1

JTPM1

USB 2

LED3

FAN4

C

JF1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

PRESS FIT

A

C

A

C

LAN 7/8

Intel Xeon
D-1500
SoC

BMC Heartbeat LED Status

Color/State Denition

Green: Blinking BMC: Normal

A. BMC Heartbeat LED

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

LEDT1

A

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:

CMOS

CLEAR

BT1

FAN3

I-SGPIO1

JPME1

JGP1

FAN2

JF1:

OH

PWR

NIC2

NIC1

X

RST

FF

ON

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

HDD

PWR

LED

LED

FAN1

2-34

Chapter 2: Installation

Onboard Power LED

An onboard Power LED is located at

LED3 on the motherboard. When this

LED is on, the system is on. Be sure to

turn off the system and unplug the power

cord before removing or installing compo-

nents. See the table on the right for more

information.

Overheat/PWR Fail/Fan Fail LED

An onboard Overheat/PWR Fail/Fan Fail

LED is located at LED8. See the table on

the right for more information.

B

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

C

M2_SRW3

M2_SRW2

M2_SRW1

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JITP1

I-SATA0

JSD1

LEDT2

JPTG1:

10Gb LAN

i350

LEDT4

AM4
(-7TP8F/

-TP8F)

JPTG1

JTPM1

USB 2

LED3

FAN4

C

JF1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3
L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

PRESS FIT

A

C

A

C

LAN 7/8

Intel Xeon
D-1500
SoC

A

Onboard PWR LED Indicator

LED Settings

Color Denition

Off System Off (PWR cable

not connected)

Green System On

Overheat/PWR Fail/Fan Fail

LED Settings

Color Denition

Solid Overheat

Blinking Power Fail or Fan Fail

A. PWR LED

B. OH/PWR Fail/Fan Fail LED

LAN 3/4

LAN 5/6

DIMMB2

DIMMB1

LEDT1

A

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

REV:1.01

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JPME1

JGP1

DIMMA1

DIMMA2

X10SDV-TP8F

DESIGNED IN USA

FAN2

OH

PWR

NIC2

X

RST

FF

ON

LAN 1/2

JF1:

HDD

PWR

NIC1

LED

LED

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

2-35

X10SDV Flex ATX Series Motherboard User’s Manual

Unit Identication LED

A rear UID LED indicator (LED7) is located

next to the Unit Identier (UID) switch on the

I/O back panel. The front panel UID LED is

located at pin 7 of the Front Control Panel at

JF1. Connect a cable to pin 7 on JF1 for front

panel UID LED indication. When you press

the UID switch, both rear UID LED and front

panel UID LED Indicators will be turned on.

Press the UID switch again to turn off both

LED Indicators. These UID Indicators provide

easy identication of a system unit that may

be in need of service.

Note: UID can also be triggered via

IPMI on the motherboard. For more

information on IPMI, please refer to

the IPMI User's Guide posted on

our website at http://www.supermi-

cro.com.

A

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

PCI-E 3.0 X4 / I-SATA4

JD1:

JD1

SATA DOM + POWER

JSD2

JSAS2

L-SAS4-7

UID

LED8

JMD1: M.2

I-SATA1

PRESS FIT

PRESS FIT

M2_SRW3

C

M2_SRW2

M2_SRW1

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

2-3:DISABLE

1-2:ENABLE

JITP1

I-SATA0

JSD1

LEDT2

JPTG1:

10Gb LAN

USB 2

A

C

i350

A

LEDT4

AM4

C

(-7TP8F/

-TP8F)

LAN 7/8

JPTG1

Intel Xeon
D-1500
SoC

JTPM1

LED3

FAN4

C

JF1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

A

JSAS3

L-SAS8-11

PRESS FIT

I-SATA5

LSI
2116
(-7TP4F/-7TP8F)

BMC
AST2400

UID LED

Status

Color/State Status

Blue: On Unit Identied

A. UID LED

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

LAN 3/4

LAN 5/6

DIMMB2

DIMMA1

DIMMB1

DIMMA2

LEDT1

A

JPL2

JPL1

C

LEDT3

A

C

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

JBT1:

CMOS

CLEAR

BT1

FAN3

I-SGPIO1

JPME1

JGP1

FAN2

JF1:

HDD

OH

PWR

NIC2

NIC1

X

RST

LED

FF

ON

IPMI_LAN

LAN 1/2

USB 0/1(3.0)

JPUSB1

JPV1

JPI2C1

JPW1

JPH1

JSTBY1

PWR
LED

FAN1

2-36

Chapter 2: Installation

10G LAN Activity LED

The 10G LAN Activity LED for LAN7 is

located at LEDT2, and the 10G LAN LED

Activity LED for LAN8 is located at LEDT4.

When the LEDs are blinking, LAN7/LAN8

are active. See the table on the right for

the colors and denitions.

10G LAN Link Status LED

The 10G LAN Link status LED for LAN7 is

located at LEDT1, and the 10G LAN Link

status LED for LAN8 is located at LEDT3.

When the LEDs are on, LAN7/LAN8 are

working properly. See the table on the right

for the colors and denitions.

10G LAN Activity

LED Indicator

Color/State Denition

LEDT2

Green: Blinking

LEDT4

Green: Blinking

LAN7 Active

LAN8 Active

10G LAN Link Status

LED Indicator

Color/State Denition

LEDT1
Green: On

LEDT3
Green: On

LAN7 Normal

LAN8 Normal

LEDT1

LEDT3

LEDT2

LEDT4

BMC
AST2400

CPU SLOT6 PCI-E 3.0 X8

JPME2

JSAS4

L-SAS12-15

PRESS FIT

JNVI2C1

4-7:SPEAKER

1-3:PWR LED

JSAS1
L-SAS0-3

JD1:

JD1

A

LED7

C

UID

M2_SRW3

C

LED8

A

C

LEDM1

M2_SRW2

CPU SLOT7 PCI-E 3.0 X8

M2_SRW1

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

i350
AM4
(-7TP8F/

-TP8F)

A

A

C

C

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

FAN4

LAN 3/4

LAN 5/6

LEDT1

JPL2

JPL1

LEDT3

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JGP1

DIMMB2

DIMMA1

DIMMB1

DIMMA2

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

FAN2

LAN 1/2

JF1:

HDD

PWR

OH

PWR

NIC2

NIC1

X

RST

LED

LED

FF

ON

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LSI

A

2116

LEDS1

USB 5/6

(-7TP4F/-7TP8F)

I-SATA3

USB 3/4

JSAS3
L-SAS8-11

PRESS FIT

I-SATA2

FANA

FANB

2-37

X10SDV Flex ATX Series Motherboard User’s Manual

SAS Hearbeat LED

A SAS heartbeat LED is located at LEDS1.

When LEDS1 ashes, it indicates activity

on a SAS port. See the table on the right

for more information.

SAS Hearbeat

LED Indicator

Color Denition

Green:

Blinking

SAS Active

Red SAS Error

A. SAS Heartbeat LED

BMC
AST2400

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

JSAS4
L-SAS12-15

PRESS FIT

4-7:SPEAKER

1-3:PWR LED

JSAS1
L-SAS0-3

JD1:

LED7

A

LEDM1

JD1

SATA DOM + POWER

JSAS2

L-SAS4-7

A

C

UID

M2_SRW3

C

LED8

C

M2_SRW2

2-3:DISABLE

1-2:ENABLE

CPU SLOT7 PCI-E 3.0 X8

JITP1

M2_SRW1

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

I-SATA0

I-SATA1

JSD2

JSD1

PRESS FIT

PRESS FIT

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

LEDT1

i350
AM4
(-7TP8F/

-TP8F)

A

A

C

C

LEDT3

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

JPTG1:

10Gb LAN

JPTG1

JTPM1

USB 2

FAN4

LAN 3/4

LAN 5/6

DIMMB2

JPL2

JPL1

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

JGP1

DIMMA1

DIMMB1

DIMMA2

X10SDV-TP8F

REV:1.01

DESIGNED IN USA

FAN2

PWR

RST

ON

LAN 1/2

JF1:

HDD

PWR

OH

NIC2

NIC1

X

LED

LED

FF

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE

JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LSI

A

2116

LEDS1

USB 5/6

(-7TP4F/-7TP8F)

I-SATA3

A

USB 3/4

JSAS3
L-SAS8-11

PRESS FIT

I-SATA2

FANA

FANB

2-38

Chapter 2: Installation

F

2-9 SATA Connections

SATA Ports

This motherboard has six SATA 3.0 ports. I-SATA0 and I-SATA1 have built-in power

pins to support Supermicro's SATA DOM (Disk On Module) solutions. I-SATA4 is via

the JMD1 M.2 connector, I-SATA5 is via the JMP1 Mini PCI-E slot.

SAS Ports (7TP8F/7TP4F only)

Sixteen SAS 2.0/SATA 3.0 ports are located at JSAS1 ~ JSAS4 on the motherboard

via four Mini-SAS HD cables. These SAS ports are supported by the LSI2116 SAS

controller. These ports provide serial-link signal connections.

A. I-SATA0

B. I-SATA1

C. I-SATA2

D. I-SATA3

F. L-SAS0-3

G. L-SAS4-7

H. L-SAS8-11

I. L-SAS12-15

E. I-SATA5

BMC
AST2400

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

B

JSAS4
L-SAS12-15

PRESS FIT

I

LED7

A

LEDM1

CPU SLOT7 PCI-E 3.0 X8

1-3:PWR LED

JD1:

JD1

SATA DOM + POWER

JSD2

JSAS1
L-SAS0-3

JSAS2

L-SAS4-7

A

C

UID

M2_SRW3

C

LED8

C

M2_SRW2

M2_SRW1

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

I-SATA1

JSD1

PRESS FIT

PRESS FIT

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

LEDT1

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

A

JTPM1

USB 2

FAN4

G

A

A

C

C

LEDT3

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

JGP1

LAN 3/4

LAN 5/6

DIMMB2

DIMMB1

JPL2

JPL1

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

DIMMA2

DIMMA1

X10SDV-TP8F

FAN2

PWR

ON

LAN 1/2

JF1:

HDD

PWR

OH

NIC2

NIC1

X

RST

LED

LED

FF

IPMI_LAN
USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE
JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

JI2C2

JPG1

E

D

C

JMP1

I-SATA5

PCI-E 2.0 X1 /

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LSI

A

2116

LEDS1

USB 5/6

(-7TP4F/-7TP8F)

I-SATA3

USB 3/4

JSAS3
L-SAS8-11

PRESS FIT

I-SATA2

FANA

FANB

H

2-39

X10SDV Flex ATX Series Motherboard User’s Manual

M.2 Socket

M.2 is formerly known as Next Generation Form Factor (NGFF). The JMD1 M.2

connector is designed for internal mounting devices. The X10SDV series deploys

an M key only dedicated for SSD devices with the ultimate performance capability

in a PCI Express 3.0 X4 interface for native PCIe SSD support. The X10SDV M.2

is mux with the I-SATA4 port for legacy SATA SSD devices.

Mini PCI-E Slot

JMP1 is a mini PCI-E 2.0 X1 slot that is mux with I-SATA5.

A. M.2 Slot

B. Mini PCI-E Slot

CPU SLOT6 PCI-E 3.0 X8

JNVI2C1

JPME2

4-7:SPEAKER

1-3:PWR LED

JD1:

JSAS1
L-SAS0-3

JSAS4
L-SAS12-15

PRESS FIT

A

LED7

C

UID

LED8

A

C

LEDM1

CPU SLOT7 PCI-E 3.0 X8

JMD1: M.2

PCI-E 3.0 X4 / I-SATA4

JD1

SATA DOM + POWER

I-SATA1

JSD2

PRESS FIT

PRESS FIT

JSAS2

L-SAS4-7

C

M2_SRW3

M2_SRW2

M2_SRW1

A

PRESS FIT

JPL3

VGA

JPL3:
LAN3/4/5/6
1-2:ENABLE
2-3:DISABLE

PHY
10GbE
CS2447

LEDT2

LEDT1

2-3:DISABLE

1-2:ENABLE

JPTG1:

10Gb LAN

i350
AM4
(-7TP8F/

-TP8F)

JITP1

JPTG1

I-SATA0

JSD1

JTPM1

USB 2

FAN4

A

A

C

C

LEDT3

A

LEDT4

A

C

C

LAN 7/8

Intel Xeon
D-1500
SoC

LED3

JPME1

C

JF1

JGP1

LAN 3/4

LAN 5/6

DIMMB2

DIMMB1

JPL2

JPL1

JPL1/JPL2:
LAN1/

LAN2

2-3:DISABLE

1-2:ENABLE

REV:1.01

DESIGNED IN USA

JBT1:
CMOS
CLEAR

BT1

FAN3

I-SGPIO1

DIMMA2

DIMMA1

X10SDV-TP8F

FAN2

LAN 1/2

JF1:

HDD

PWR

OH

PWR

NIC2

NIC1

X

RST

LED

LED

FF

ON

IPMI_LAN

USB 0/1(3.0)

JPH1

2-3:DISABLE

1-2:ENABLE

JPUSB1:USB0/1 WAKE UP

JPUSB1

JPV1

JPI2C1

JPW1

JSTBY1

FAN1

JI2C1/JI2C2:

JBR1

1-2:ENABLE

1-2:NORMAL

2-3:DISABLE

2-3:BIOS RECOVERY

BAR CODE

JPG1:
1-2:ENABLE
2-3:DISABLE

JPS1:SAS
1-2:ENABLE
2-3:DISABLE

JWD1:WATCH DOG
1-2:RST

JL1:

2-3:NMI

CHASSIS
INTRUSION

JOH1-OH

MP_SRW2

JIPMB1

JPB1

JSMB1

MP_SRW1

JI2C1

B

JI2C2

JPG1

1

COM1

JPS1

JBR1

JWD1

JLANLED1

JL1

JTGLED1

JOH1

LEDS1

USB 5/6

I-SATA3

USB 3/4

I-SATA2

FANA

FANB

JMP1

PCI-E 2.0 X1 /

LSI

A

2116
(-7TP4F/-7TP8F)

JSAS3
L-SAS8-11

PRESS FIT

BMC
AST2400

I-SATA5

2-40

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all

of the procedures below and still need assistance, refer to the ‘Technical Support

Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.

Always disconnect the AC power cord before adding, changing or installing any

hardware components.

Before Power On

1. Make sure that the PWR LED is not on. (Note: If it is on, the onboard power

is on. Be sure to unplug the power cable before installing or removing the

components.)

2. Make sure that there are no short circuits between the motherboard and chassis.

3. Disconnect all ribbon/wire cables from the motherboard, including those for the

keyboard and mouse. Also, be sure to remove all add-on cards.

No Power

1. Make sure that there are no short circuits between the motherboard and chassis.

2. Make sure that all jumpers are set to their default positions.

3. Check if the 115V/230V switch on the power supply is properly set.

4. Turn the power switch on and off to test the system.

5. The battery on your motherboard may be old. Check to make sure that it still

supplies ~3VDC. If it does not, replace it with a new one.

No Video

1. If the power is on, but you have no video, you will need to remove all the add-

on cards and cables rst.

3-1

X10SDV Flex ATX Series Motherboard User’s Manual

2. Install a PC buzzer via JD1 to determine if any beep codes exist. (Refer to Ap-

pendix A for details on beep codes.)

3. Remove all memory modules and turn on the system. (If the alarm is on, check

the specications of memory modules, reset the memory or try a different one.)

Memory Errors

1. Make sure that the DIMM modules are properly installed and fully seated in

the slots.

2. You should be using either DDR4 ECC RDIMM or ECC/Non-ECC UDIMM up to

2133MHz memory recommended by Supermicro. Also, it is required that you use

the memory modules of the same type and speed for all DIMMs in the system.

Do not use memory modules of different sizes, different speeds, nor different

types on the same motherboard.

3. Check for bad DIMM modules or slots by swapping modules between slots to

see if you can locate the faulty ones.

4. Check the switch of 115V/230V power supply.

Losing the System’s Setup Conguration

1. Please be sure to use a high quality power supply. A poor quality power supply

may cause the system to lose CMOS setup information. Refer to Section 1-6

for details on recommended power supplies.

2. The battery on your motherboard may be old. Check to verify that it still sup-

plies ~3VDC. If it does not, replace it with a new one.

3. If the above steps do not x the Setup Conguration problem, contact your

vendor for repairs.

3-2

Chapter 3: Troubleshooting

3-2 Technical Support Procedures

Before contacting Technical Support, please make sure that you have followed all

the steps listed below. Also, Note that as a motherboard manufacturer, Supermicro

does not sell directly to end users, so it is best to rst check with your distributor or

reseller for troubleshooting services. They should know of any possible problem(s)

with the specic system conguration that was sold to you.

1. Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked

Question' (FAQ) sections in this chapter or see the FAQs on our website (http://

www.supermicro.com/support/faqs/) before contacting Technical Support.

2. BIOS upgrades can be downloaded from our website at (http://www.supermicro.

com/support/bios/).

Note: Not all BIOS can be ashed. It depends on the boot block code of

the BIOS.

3. If you've followed the instructions above to troubleshoot your system, and still

cannot resolve the problem, then contact Supermicro's technical support and

provide them with the following information:

• Motherboard model and PCB revision number

• BIOS release date/version (this can be seen on the initial display when your

system rst boots up)

• System conguration

• An example of a Technical Support form is on our website at (http://www.super-

micro.com/RmaForm/).

4. Distributors: For immediate assistance, please have your account number

ready when placing a call to our technical support department. We can be

reached by e-mail at [e-mail], by phone at [phone],

option 2, or by fax at [phone].

3-3

X10SDV Flex ATX Series Motherboard User’s Manual

3-3 Frequently Asked Questions

Question: What type of memory does my motherboard support?

Answer: The X10SDV Flex ATX Series motherboard supports up to 128GB of DDR4

ECC RDIMM or 64GB of DDR4 ECC/Non-ECC UDIMM memory of speeds up to

2133MHz. See Section 2-4 for details on installing memory.

Question: How do I update my BIOS?

Answer: We do NOT recommend that you upgrade your BIOS if you are not

experiencing any problems with your system. Updated BIOS les are located on

our website at http://www.supermicro.com/support/bios/. Please check our BIOS

warning message and the information on how to update your BIOS on our web

site. Select your motherboard model and download the BIOS ROM le to your

computer. Also, check the current BIOS revision to make sure that it is newer than

your BIOS before downloading. You may choose the zip le or the .exe le. If you

choose the zipped BIOS le, please unzip the BIOS le onto a bootable device or

a USB pen/thumb drive. To ash the BIOS, run the batch le named "ami.bat" with

the new BIOS ROM le from your bootable device or USB pen/thumb drive. Use

the following format:

F:\> FLASH.bat BIOS-ROM-lename.xxx <Enter>

Note: Always use the le named “FLASH.bat” to update the BIOS, and

insert a space between "FLASH.bat" and the BIOS ROM image le name.

If you choose the .exe le, please run the .exe le under Windows to create

the BIOS ash oppy disk. Insert the oppy disk into the system you wish

to ash the BIOS. Then, boot the system to the oppy disk. The BIOS util-

ity will automatically ash the BIOS without any prompts. Please note that

this process may take a few minutes to complete. Do not be concerned if

the screen is paused for a few minutes.

When the BIOS ashing screen is completed, the system will need to be

powered off with the power source completely removed. Unplug the power

source for about 10 seconds before reapplying and turning the system on

to complete the BIOS upgrade.

Warning: Do not shut down or reset the system while updating the BIOS to prevent

possible system boot failure!

Important: The SPI BIOS chip installed on this motherboard is not re-

movable. To repair or replace a damaged BIOS chip, please send your

motherboard to RMA at Supermicro for service.

3-4

Chapter 3: Troubleshooting

3-4 Battery Removal and Installation

Battery Removal

To remove the onboard battery, follow the steps below:

1. Power off your system and unplug your power cable.

2. Locate the onboard battery as shown below.

3. Using a tool such as a pen or a small screwdriver, push the battery lock out-

wards to unlock it. Once unlocked, the battery will pop out from the holder.

4. Remove the battery.

Proper Battery Disposal

Warning: Please handle used batteries carefully. Do not damage the battery in any

way; a damaged battery may release hazardous materials into the environment. Do

not discard a used battery in the garbage or a public landll. Please comply with the

regulations set up by your local hazardous waste management agency to dispose of

your used battery properly.

Battery Installation

1. To install an onboard battery, follow the steps 1 & 2 above and continue

below:

2. Identify the battery's polarity. The positive (+) side should be facing up.

3. Insert the battery into the battery holder and push it down until you hear a

click to ensure that the battery is securely locked.

Warning: When replacing a battery, be sure to only replace it with the same type.

OR

3-5

X10SDV Flex ATX Series Motherboard User’s Manual

3-5 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required

before any warranty service will be rendered. You can obtain service by calling

your vendor for a Returned Merchandise Authorization (RMA) number. For faster

service, you may also obtain RMA authorizations online (http://www.supermicro.

com/RmaForm/). When you return the motherboard to the manufacturer, the RMA

number should be prominently displayed on the outside of the shipping carton, and

mailed prepaid or hand-carried. Shipping and handling charges will be applied for

all orders that must be mailed when service is complete.

This warranty only covers normal consumer use and does not cover damages

incurred in shipping or from failure due to the alteration, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor rst for any product problems.

3-6

Chapter 4: AMI BIOS

Chapter 4

BIOS

4-1 Introduction

This chapter describes the AMI BIOS setup utility for the X10SDV-7TP8F mother-

board. The ROM BIOS is stored in a Flash EEPROM and can be easily updated.

This chapter describes the basic navigation of the AMI BIOS setup utility setup

screens.

Note: For AMI BIOS Recovery, please refer to the UEFI BIOS Recovery

Instructions in Appendix C.

Starting BIOS Setup Utility

To enter the AMI BIOS setup utility screens, press the <Delete> key while the

system is booting up.

Note: In most cases, the <Delete> key is used to invoke the AMI BIOS

setup screen. There are a few cases when other keys are used, such as

<F1>, <F2>, etc.

Each main BIOS menu option is described in this manual. The Main BIOS setup

menu screen has two main frames. The left frame displays all the options that can

be congured. Grayed-out options cannot be congured. Options in blue can be

congured by the user. The right frame displays the key legend. Above the key

legend is an area reserved for a text message. When an option is selected in the

left frame, it is highlighted in white. Often a text message will accompany it. (Note:

the AMI BIOS has default text messages built in. Supermicro retains the option to

include, omit, or change any of these text messages.)

The AMI BIOS setup utility uses a key-based navigation system called "hot keys".

Most of the AMI BIOS setup utility "hot keys" can be used at any time during the

setup navigation process. These keys include <F1>, <F4>, <Enter>, <ESC>, arrow

keys, etc.

Note: Options printed in Bold are default settings.

How To Change the Conguration Data

The conguration data that determines the system parameters may be changed by

entering the AMI BIOS setup utility. This setup utility can be accessed by pressing

<Del> at the appropriate time during system boot.

4-1

X10SDV Flex ATX Series Motherboard User’s Manual

How to Start the Setup Utility

Normally, the only visible Power-On Self-Test (POST) routine is the memory test.

As the memory is being tested, press the <Delete> key to enter the main menu of

the AMI BIOS setup utility. From the main menu, you can access the other setup

screens. An AMI BIOS identication string is displayed at the left bottom corner of

the screen, below the copyright message.

Warning: Do not update the BIOS unless your system has a BIOS-related issue.

Flashing the wrong BIOS can cause irreparable damage to the system. In no event

shall Supermicro be liable for direct, indirect, special, incidental, or consequential dam-

ages arising from a BIOS update. If you have to update the BIOS, do not shut down

or reset the system while the BIOS is updating. This is to avoid possible boot failure.

4-2 Main Setup

When you rst enter the AMI BIOS setup utility, you will enter the Main setup screen.

You can always return to the Main setup screen by selecting the Main tab on the

top of the screen. The Main BIOS Setup screen is shown below.

4-2

Chapter 4: AMI BIOS

The following Main menu items will display:

System Date/System Time

Use this feature to change the system date and time. Highlight System Date or

System Time using the arrow keys. Enter new values using the keyboard. Press

the <Tab> key or the arrow keys to move between elds. The date must be entered

in Day MM/DD/YY format. The time is entered in HH:MM:SS format.

Note: The time is in the 24-hour format. For example, 5:30 P.M. appears

as 17:30:00.

The following BIOS items will also be displayed:

Supermicro X10SDV-7TP8F

Version

Build Date

Memory Information

Total Memory

This displays the total size of memory available in the system.

4-3

X10SDV Flex ATX Series Motherboard User’s Manual

4-3 Advanced Setup Congurations

Use the arrow keys to select Boot Setup and press <Enter> to access the submenu

items.

Warning: Take caution when changing the Advanced settings. An incorrect value, a

very high DRAM frequency, or an incorrect DRAM timing setting may make the system

unstable. When this occurs, revert to the default to the manufacture default settings.

Boot Feature

Quiet Boot

Use this feature to select the screen display between the POST messages and the

OEM logo upon bootup. Select Disabled to display the POST messages. Select

Enabled to display the OEM logo instead of the normal POST messages. The op-

tions are Enabled and Disabled.

AddOn ROM Display Mode

Use this feature to set the display mode for the Option ROM. Select Keep Current to

display the current AddOn ROM setting. Select Force BIOS to use the Option ROM

display set by the system BIOS. The options are Force BIOS and Keep Current.

Bootup NumLock State

Use this feature to set the Power-on state for the <Numlock> key. The options

are Off and On.

4-4

Chapter 4: AMI BIOS

Wait For 'F1' If Error

Use this feature to force the system to wait until the 'F1' key is pressed if an error

occurs. The options are Disabled and Enabled.

INT19 (Interrupt 19) Trap Response

Interrupt 19 is the software interrupt that handles the boot disk function. When this

item is set to Immediate, the ROM BIOS of the host adaptors will "capture" Inter-

rupt 19 at bootup immediately and allow the drives that are attached to these host

adaptors to function as bootable disks. If this item is set to Postponed, the ROM

BIOS of the host adaptors will not capture Interrupt 19 immediately and allow the

drives attached to these adaptors to function as bootable devices at bootup. The

options are Immediate and Postponed.

Re-try Boot

If this item is enabled, the BIOS will automatically reboot the system from a speci-

ed boot device after its initial boot failure. The options are Disabled, Legacy

Boot, and EFI Boot.

Power Conguration

Watch Dog Function

If enabled, the Watch Dog Timer will allow the system to reset or generate NMI

based on jumper settings when it is expired for more than 5 minutes. The options

are Enabled and Disabled.

Power Button Function

This feature controls how the system shuts down when the power button is pressed.

Select 4 Seconds Override for the user to power off the system after pressing and

holding the power button for 4 seconds or longer. Select Instant Off to instantly

power off the system as soon as the user presses the power button. The options

are 4 Seconds Override and Instant Off.

Restore on AC Power Loss

Use this feature to set the power state after a power outage. Select Stay-Off for the

system power to remain off after a power loss. Select Power-On for the system

power to be turned on after a power loss. Select Last State to allow the system

to resume its last power state before a power loss. The options are Power On,

Stay Off, and Last State.

4-5

X10SDV Flex ATX Series Motherboard User’s Manual

CPU Conguration

The following CPU information will be displayed:

• Processor ID

• Processor Frequency

• Processor Max Ratio

• Processor Min Ratio

• Microcode Revision

• L1 Cache RAM

• L2 Cache RAM

• L3 Cache Ram

• CPU Version

Clock Spread Spectrum

If this feature is set to Enabled, the BIOS utility will monitor the level of Electro-

magnetic Interference caused by the components and will attempt to reduce the

interference whenever needed. The options are Disable and Enable.

Hyper-Threading (ALL)

Select Enable to use Intel Hyper-Threading Technology to enhance CPU perfor-

mance. The options are Disable and Enable.

Cores Enabled

Set a numeric value to enable the number of cores. (Please refer to Intel's website

for more information.) Enter 0 to enable all cores.

Monitor/Mwait

Select Enabled to enable the Monitor/MWait instructions. The Monitor instruction

monitors a region of memory for writes, and MWait instructions instruct the CPU to

stop until the monitored region begins to write. The options are Disable and Enable.

4-6

Chapter 4: AMI BIOS

Execute Disable Bit (Available if supported by the OS & the CPU)

Select Enabled to enable the Execute-Disable Bit which will allow the processor

to designate areas in the system memory where an application code can execute

and where it cannot, thus preventing a worm or a virus from ooding illegal codes

to overwhelm the processor or damage the system during an attack. The default is

Enable. (Refer to the Intel® and Microsoft® websites for more information.)

PPIN Control

Select Unlock/Enable to use the Protected-Processor Inventory Number (PPIN) in

the system. The options are Unlock/Enable and Unlock/Disable.

Hardware Prefetcher (Available when supported by the CPU)

If set to Enabled, the hardware prefetcher will prefetch streams of data and instruc-

tions from the main memory to the L2 cache to improve CPU performance. The

options are Disable and Enable.

Adjacent Cache Prefetch (Available when supported by the CPU)

The CPU prefetches the cache line for 64 bytes if this feature is set to Disabled.

The CPU prefetches both cache lines for 128 bytes as comprised if this feature is

set to Enable.

DCU Streamer Prefetcher (Available when supported by the CPU)

Select Enabled to enable the DCU (Data Cache Unit) Streamer Prefetcher which

will stream and prefetch data and send it to the Level 1 data cache to improve data

processing and system performance. The options are Disable and Enable.

DCU IP Prefetcher (Available when supported by the CPU)

Select Enabled for DCU (Data Cache Unit) IP Prefetcher support, which will prefetch

IP addresses to improve network connectivity and system performance. The options

are Disable and Enable.

Direct Cache Access (DCA)

Select Enabled to use Intel's DCA (Direct Cache Access) Technology to improve

data transfer efciency. The options are Disable, Enable, and Auto.

Intel® Virtualization Technology (Available when supported by the CPU)

Select Enabled to support Intel Virtualization Technology, which will allow one

platform to run multiple operating systems and applications in independent parti-

tions, creating multiple "virtual" systems in one physical computer. The options

are Disable and Enable.

4-7

X10SDV Flex ATX Series Motherboard User’s Manual

Note: If a change is made to this setting, you will need to reboot the

system for the change to take effect. Refer to Intel’s website for detailed

information.

Advanced Power Management Conguration

This section is used to congure the following CPU Power Management settings.

EIST (P-States)

EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically

adjust processor voltage and core frequency to reduce power consumption and

heat dissipation. The options are Disable and Enable.

If the above is set to Enable, CPU P State will display:

CPU P State Control

P State Domain

This feature allows the user to indicate the P-State domain for each logical

process in the system. All processes indicate the same domain in the same

package. The options are ALL and ONE.

P-State Coordination

This feature allows the user to change the P-State (Power-Performance State)

coordination type. P-State is also known as "SpeedStep" for Intel processors. Se-

lect HW_ALL to change the P-State coordination type for hardware components

only. Select SW_ALL to change the P-State coordination type for all software

installed in the system. Select SW_ANY to change the P-State coordination

type for a software program in the system. The options are HW_All, SW_ALL,

and SW_ANY.

Energy Efcient P-State

Select Enable to support power-saving mode for P-State. The options are Dis-

able and Enable.

Boot Performance Mode

This feature allows the user to select the performance state that the BIOS will

set before the operating system handoff. The options are Max Performance

and Max Efcient.

Turbo Mode

Select Enable for processor cores to run faster than the frequency specied by

the manufacturer. The options are Disable and Enable.

4-8

Chapter 4: AMI BIOS

CPU HWPM State Control

Enable CPU HWPM

Select Enable for better CPU energy performance. The options are Disable,

HWPM NATIVE MODE, and HWPM OOB MODE.

Enable CPU Autonomous Cstate

Use this feature to enable CPU Autonomous C State, which converts HALT

instructions to Mwait. The options are Disable and Enable.

CPU C State Control

CPU C State

Use this feature to enable the enahnced C State of the CPU. The options are

Disable and Enable.

Package C State Limit

This feature allows the user to set the limit on the C State package register.

The options are C0/C1 State, C2 State, C6 (Non Retention) State, and C6

(Rentention) state.

CPU C3 Report

Select Enabled to allow the BIOS to report the CPU C3 State (ACPI C2) to the

operating system. During the CPU C3 State, the CPU clock generator is turned

off. The options are Enable and Disable.

CPU C6 Report

Select Enabled to allow the BIOS to report the CPU C6 State (ACPI C3) to the

operating system. During the CPU C6 State, the power to all cache is turned

off. The options are Disable and Enable.

Enhanced Halt State (C1E)

Select Enabled to use Enhanced Halt-State technology, which will signicantly

reduce the CPU's power consumption by reducing the CPU's clock cycle and

voltage during a Halt-state. The options are Disable and Enable.

4-9

X10SDV Flex ATX Series Motherboard User’s Manual

CPU T State Control

ACPI (Advanced Conguration Power Interface) T-States

Select Enable to support CPU throttling by the operating system to reduce power

consumption. The options are Disable and Enable.

CPU Advanced PM Turning

Energy Perf BIAS

Energy Performance Tuning

When enabled, this item selects whether the BIOS or Operating System can

turn on the energy performance bias tuning. The options are Disable and

Enable.

If the above is set to Disable, Energy Performance BIAS Setting will display:

Energy Performance BIAS Setting

This feature allows balancing Power Efciency vs Performance. This will

override whatever setting is in the Operating System. The options are Per-

formance, Balanced Performance, Balanced Power, and Power.

Power/Performance Switch

This feature allows dynamic switching between Power and Performance

power efciency. The options are Disable and Enable.

Workload Conguration

This feature allows for optimization of workload. Balanced is recommended.

The options are Balanced and I/O Sensitive.

Program PowerCTL_MSR

PKG C-state Lat. Neg.

Use this feature to indicate whether latency should be negotiated with PCH

for packaging C-States. The options are Enable and Disable.

SAPM Control

This feature indicates whether the PCU should control the System Agent

PM using its power-performance tuning algorithm. The options are Enable

and Disable.

4-10

Chapter 4: AMI BIOS

Energy Efcient Turbo

Use this feature to enable energy efcient turbo mode. The options are En-

able and Disable.

DRAM RAPL Conguration

Override BW_LIMIT_TF

This feature allows the user to turn off the "Override BW_LIMIT_TF (Time

Frame)" setting when the item "Running Average Limit for DRAM modules"

(DRAM RAPL) is set to Enabled so that the DRAM RAPL setting can work

properly. The default setting is 1.

DRAM RAPL Extended Range

Use this feature to set the DRAM Running Average Power Limit (RAPL)

Extended Range. The options are Disable and Enable.

Chipset Conguration

Warning: Setting the wrong values in the following features may cause the system

to malfunction.

North Bridge

This feature allows the user to congure the following North Bridge settings.

IIO Conguration

EV DFX (Device Function On-Hide) Features

When this feature is set to Enable, the EV_DFX Lock Bits that are located on a

processor will always remain clear during electric tuning. The options are Dis-

able and Enable.

IIO1 Conguration

M.2 PCI-E 3.0 X4

This item congures the link speed of the PCI-E port specied by the user. The

options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s),

and Gen 3 (Generation 3) (8 GT/s).

4-11

X10SDV Flex ATX Series Motherboard User’s Manual

CPU SLOT 6 PCI-E 3.0 X8

This item congures the link speed of the PCI-E port specied by the user. The

options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s),

and Gen 3 (Generation 3) (8 GT/s).

CPU SLOT 7 PCI-E 3.0 X8

This item congures the link speed of the PCI-E port specied by the user. The

options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s),

and Gen 3 (Generation 3) (8 GT/s).

IOAT (Intel® IO Acceleration) Conguration

Enable IOAT

Select Enable to enable Intel I/OAT (I/O Acceleration Technology) support, which

signicantly reduces CPU overhead by leveraging CPU architectural improve-

ments and freeing the system resource for other tasks. The options are Disable

and Enable.

No Snoop

Select Enable to support no-snoop mode for each CB device. The options are

Disable and Enable.

Intel® VT for Directed I/O (VT-d)

Intel VT for Directed I/O (VT-d)

Select Enable to use Intel Virtualization Technology support for Direct I/O VT-d
support by reporting the I/O device assignments to the VMM (Virtual Machine

Monitor) through the DMAR ACPI Tables. This feature offers fully-protected I/O

resource sharing across Intel platforms, providing greater reliability, security and

availability in networking and data-sharing. The options are Enable and Disable.

ACS Control

Use this feature to program Access Control Services (ACS) to the PCI-E Root

Port Bridges. The options are Enable and Disable.

Interrupt Remapping

Select Enable for Interrupt Remapping support to enhance system performance.

The options are Enable and Disable.

4-12

Chapter 4: AMI BIOS

Memory Conguration

Enforce POR

Select Enable to enforce POR restrictions on DDR4 frequency and voltage

programming. The options are Enabled and Disabled.

Memory Frequency

Use this feature to set the maximum memory frequency for onboard memory

modules. The options are Auto, 1333, 1400, 1600, 1800, 1867, 2000, 2133,

2200, 2400, 2600, 2667, 2800, 2993, 3000, 3200, and Reserved (Do not select

Reserved).

Data Scrambling

Select Enabled to enable data scrambling to enhance system performance and

data integrity. The options are Auto, Disabled, and Enabled.

DRAM RAPL Baseline

Use this feature to set the run-time power-limit baseline for DRAM modules. The

options are Disable, DRAM RAPL Mode 0, and DRAM RAPL Mode 1.

Set Throttling Mode

Throttling improves reliability and reduces power consumption in the processor

via automatic voltage control during processor idle states. The options are Dis-

abled and CLTT (Closed Loop Thermal Throttling).

A7 Mode

Select Enabled to support the A7 (Addressing) mode to improve memory perfor-

mance. The options are Enable and Disable.

DIMM Information

This item displays the status of a DIMM module specied by the user.

• DIMMA1

• DIMMB1

• DIMMA2

• DIMMB2

4-13

X10SDV Flex ATX Series Motherboard User’s Manual

Memory RAS (Reliability_Availability_Serviceability)

Conguration

Use this submenu to congure the following Memory RAS settings.

Patrol Scrub

Patrol Scrubbing is a process that allows the CPU to correct correctable memory

errors detected on a memory module and send the correction to the requestor

(the original source). When this item is set to Enabled, the IO hub will read and

write back one cache line every 16K cycles, if there is no delay caused by internal

processing. By using this method, roughly 64 GB of memory behind the IO hub

will be scrubbed every day. The options are Enable and Disable.

Patrol Scrub Interval

This feature allows you to decide how many hours the system should wait before

the next complete patrol scrub is performed. Use the keyboard to enter a value

from 0-24. The default setting is 24.

Demand Scrub

Demand Scrubbing is a process that allows the CPU to correct correctable

memory errors found on a memory module. When the CPU or I/O issues a

demand-read command, and the read data from memory turns out to be a

correctable error, the error is corrected and sent to the requestor (the original

source). Memory is updated as well. Select Enable to use Demand Scrubbing

for ECC memory correction. The options are Disable and Enable.

Device Tagging

Select Enable to support device tagging. The options are Disable and Enable.

South Bridge

The following South Bridge information will display:

• USB Conguration

• USB Module Version

• USB Devices

Legacy USB Support

This feature enables support for legacy USB devices. Select Auto to disable legacy

support if USB devices are not present. Select Disable to have USB devices avail-

able only for EFI applications. The options are Enabled, Disabled, and Auto.

4-14

Chapter 4: AMI BIOS

XHCI Hand-Off

This is a work-around solution for operating systems that do not support XHCI (Ex-

tensible Host Controller Interface) hand-off. The XHCI ownership change should be

claimed by the XHCI driver. The settings are Enabled and Disabled.

EHCI Hand-Off

This item is for the Operating Systems that do not support Enhanced Host Controller

Interface (EHCI) hand-off. When this item is enabled, EHCI ownership change will

be claimed by the EHCI driver. The settings are Enabled and Disabled.

USB 3.0 Support

Select Enabled for USB 3.0 support. The options are Smart Auto, Auto, Enabled,

Disabled.

EHCI1

Select Enabled to enable EHCI (Enhanced Host Controller Interface) support on

USB 2.0 connector #1 (at least one USB 2.0 connector should be enabled for EHCI

support). The options are Disabled and Enabled.

EHCI2

Select Enabled to enable EHCI (Enhanced Host Controller Interface) support on

USB 2.0 connector #2 (at least one USB 2.0 connector should be enabled for EHCI

support). The options are Disabled and Enabled.

XHCI Pre-Boot Driver

Select Enabled to enable XHCI (Extensible Host Controller Interface) support on a

pre-boot drive specied by the user. The options are Enabled and Disabled.

SATA Conguration

When this submenu is selected, the AMI BIOS automatically detects the presence

of the SATA devices that are supported by the Intel PCH chip and displays the

following items:

SATA Controller

This item enables or disables the onboard SATA controller supported by the Intel

PCH chip. The options are Enabled and Disabled.

Congure SATA as

Select IDE to congure a SATA drive specied by the user as an IDE drive. Select

AHCI to congure a SATA drive specied by the user as an AHCI drive. Select

RAID to congure a SATA drive specied by the user as a RAID drive. The options

are IDE, AHCI, and RAID.

4-15

X10SDV Flex ATX Series Motherboard User’s Manual

*If the item "Congure SATA as" is set to AHCI, the following items will display:

SATA Frozen

Use this item to enable the HDD Security Frozen Mode. The options are Disabled

and Enabled.

SATA AHCI LPM

Use this feature to enable the Link Power Management for SATA AHCI. The options

are Disabled and Enabled.

Support Aggressive Link Power Mgmt

When this item is set to Enabled, the SATA AHCI controller manages the power

usage of the SATA link. The controller will put the link in a low power mode during

extended periods of I/O inactivity, and will return the link to an active state when

I/O activity resumes. The options are Disabled and Enabled.

SATA RAID Option ROM/UEFI Driver (Available if "Congure SATA As" is
set to RAID)

Select Enabled to use the SATA RAID Option ROM/UEFI driver for system boot.

The options are Enabled and Disabled.

SATA Port 0~ Port 5

This item displays the information detected on the installed SATA drive on the

particular SATA port.

• Model number of drive and capacity

• Software Preserve Support

Port 0 ~ Port 5 Hot Plug

This feature designates this port for hot plugging. Set this item to Enabled for

hot-plugging support, which will allow the user to replace a SATA drive without

shutting down the system. The options are Enabled and Disabled.

Port 0 ~ Port 5 Spin Up Device

On an edge detect from 0 to 1, set this item to allow the PCH to initialize the

device. The options are Enabled and Disabled.

Port 0 ~ Port 5 SATA Device Type

Use this item to specify if the SATA port specied by the user should be con-

nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk

Drive and Solid State Drive.

4-16

Chapter 4: AMI BIOS

*If the item "Congure SATA as" is set to IDE, the following items will

display:

SATA Frozen

Use this item to enable the HDD Security Frozen Mode. The options are Dis-

abled and Enabled.

Port 0 ~ Port 5 SATA Device Type (Available when a SATA port is

detected)

Use this item to specify if the SATA port specied by the user should be con-

nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk

Drive and Solid State Drive.

Server ME (Management Engine) Conguration

This feature displays the following system ME conguration settings.

• General ME Conguration

• Operational Firmware Version

• ME Firmware Type

• Recovery Firmware Version

• ME Firmware Features

• ME Firmware Status #1

• ME Firmware Status #2

• Current State

• Error Code

PCIe/PCI/PnP Conguration

The following information will display:

• PCI Bus Driver Version

• PCI Devices Common Settings:

4-17

X10SDV Flex ATX Series Motherboard User’s Manual

PCI PERR/SERR Support

Select Enabled to allow a PCI device to generate a PERR/SERR number for a PCI

Bus Signal Error Event. The options are Enabled and Disabled.

Above 4G Decoding (Available if the system supports 64-bit PCI decoding)

Select Enabled to decode a PCI device that supports 64-bit in the space above 4G

Address. The options are Disabled and Enabled.

SR-IOV (Available if the system supports Single-Root Virtualization)

Select Enabled for Single-Root IO Virtualization support. The options are Disabled

and Enabled.

Maximum Payload

Use this feature to select the setting for the PCI Express maximum payload size.

The options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes,

and 4096 Bytes.

Relaxed Ordering

Select Enable to enable Relaxed Ordering support which will allow certain transac-

tions to violate the strict-ordering rules of PCI bus for a transaction to be completed

prior to other transactions that have already been enqueued. The options are

Disabled and Enabled.

Extended Tag

Use this item to allow a device to use the 8-bit tag eld as a requester. The options

are Disabled and Enabled.

ARI Forwarding

When this feature is enabled, the Downstream Port disables its traditional device

number to 0 when turning Type1 Conguration Request into a Type0 Conguration

Request. The default value is Disabled.

M.2 PCI-E 3.0 X4

Use this feature to select which rmware type to be loaded for the add-on card in

this slot. The options are Disabled, Legacy, and EFI.

CPU SLOT 6 PCI-E 3.0 X8 OPROM

Use this feature to select which rmware type to be loaded for the add-on card in

this slot. The options are Disabled, Legacy, and EFI.

CPU SLOT 7 PCI-E 3.0 X8 OPROM

Use this feature to select which rmware type to be loaded for the add-on card in

this slot. The options are Disabled, Legacy, and EFI.

4-18

Chapter 4: AMI BIOS

PCI-E 2.0 X1 OPROM

Use this feature to select which rmware type to be loaded for the add-on card in

this slot. The options are Disabled, Legacy, and EFI.

Onboard SAS Option ROM

Use this feature to select which rmware to be loaded for the onboard SAS Option

ROM. The options are Disabled, Legacy, and EFI.

Onboard LAN Option ROM Type

Use this feature to select which rmware to be loaded for the onboard LAN. The

options are Legacy and EFI.

Onboard LAN1 Option ROM

Use this option to select the type of device installed in LAN Port1 used for system

boot. The default setting for LAN1 Option ROM is PXE.

Onboard LAN2 ~ LAN8 Option ROM

Use this option to select the type of device installed in the specied LAN Ports

used for system boot. The options are Disabled and PXE.

Onboard Video Option ROM

Use this item to select the Onboard Video Option ROM type. The options are Dis-

abled, Legacy, and EFI.

VGA Priority

This feature allows the user to select the graphics adapter to be used as the primary

boot device. The options are Onboard and Offboard.

Network Stack

Select Enabled enable PXE (Preboot Execution Environment) or UEFI (Unied

Extensible Firmware Interface) for network stack support. The options are Enabled

and Disabled.

*If "Network Stack" is set to Enabled, the four items below will become

available for conguration:

IPv4 PXE Support

Select Enabled to enable IPv4 PXE boot support. The options are Disabled and

Enabled.

IPv6 PXE Support

Select Enabled to enable IPv6 PXE boot support. The options are Disabled and

Enabled.

4-19

X10SDV Flex ATX Series Motherboard User’s Manual

PXE boot wait time

Use this option to specify the wait time to press the ESC key to abort the PXE boot.

Press "+" or "-" on your keyboard to change the value. The default setting is 0.

Media detect count

Use this option to specify the number of times media will be checked. Press "+" or

"-" on your keyboard to change the value. The default setting is 1.

Super IO Conguration

Super IO Chip AST2400

Serial Port 1 Conguration

This submenu allows the user the congure settings of Serial Port 1 or Serial Port 2.

Serial Port

Select Enabled to enable the selected onboard serial port. The options are Disabled

and Enabled.

Device Settings

This item displays the status of a serial part specied by the user.

Change Port 1 Settings

This feature species the base I/O port address and the Interrupt Request address

of a serial port specied by the user. Select Auto to allow the BIOS to automatically

assign the base I/O and IRQ address.

The options for Serial Port 1 are Auto, (IO=3F8h; IRQ=4), (IO=3F8h; IRQ=3, 4, 5,

6, 7, 9, 10, 11, 12), (IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12), (IO=3E8h; IRQ=3,

4, 5, 6, 7, 9, 10, 11, 12) and (IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12).

Serial Port Console Redirection

COM1 Console Redirection

Console Redirection

Select Enabled to enable console redirection support for a serial port specied by

the user. The options are Disabled and Enabled.

4-20

Chapter 4: AMI BIOS

COM1 Console Redirection Settings

This feature allows the user to specify how the host computer will exchange data

with the client computer, which is the remote computer used by the user.

Terminal Type

This feature allows the user to select the target terminal emulation type for Console

Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add

color and function key support. Select ANSI to use the Extended ASCII Character

Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or

more bytes. The options are ANSI, VT100, VT100+, and VT-UTF8.

Bits Per second

Use this feature to set the transmission speed for a serial port used in Console

Redirection. Make sure that the same speed is used in the host computer and the

client computer. A lower transmission speed may be required for long and busy

lines. The options are 9600, 19200, 38400, 57600, and 115200 (bits per second).

Data Bits

Use this feature to set the data transmission size for Console Redirection. The

options are 7 Bits and 8 Bits.

Parity

A parity bit can be sent along with regular data bits to detect data transmission

errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits

is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits

is odd. Select None if you do not want to send a parity bit with your data bits in

transmission. Select Mark to add a mark as a parity bit to be sent along with the

data bits. Select Space to add a Space as a parity bit to be sent with your data

bits. The options are None, Even, Odd, Mark and Space.

Stop Bits

A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard

serial data communication. Select 2 Stop Bits if slower devices are used. The op-

tions are 1 and 2.

Flow Control

Use this feature to set the ow control for Console Redirection to prevent data loss

caused by buffer overow. Send a "Stop" signal to stop sending data when the re-

ceiving buffer is full. Send a "Start" signal to start sending data when the receiving

buffer is empty. The options are None and Hardware RTS/CTS.

4-21

X10SDV Flex ATX Series Motherboard User’s Manual

VT-UTF8 Combo Key Support

Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100 ter-

minals. The options are Disabled and Enabled.

Recorder Mode

Select Enabled to capture the data displayed on a terminal and send it as text mes-

sages to a remote server. The options are Disabled and Enabled.

Resolution 100x31

Select Enabled for extended-terminal resolution support. The options are Disabled

and Enabled.

Legacy OS Redirection Resolution

Use this feature to select the number of rows and columns used in Console Redi-

rection for legacy OS support. The options are 80x24 and 80x25.

Putty KeyPad

This feature selects the settings for Function Keys and KeyPad used for Putty,

which is a terminal emulator designed for the Windows OS. The options are VT100,

LINUX, XTERMR6, SC0, ESCN, and VT400.

Redirection After BIOS POST

Use this feature to enable or disable legacy console redirection after BIOS POST.

When set to Bootloader, legacy console redirection is disabled before booting the

OS. When set to Always Enable, legacy console redirection remains enabled when

booting the OS. The options are Always Enable and Bootloader.

SOL Console Redirection

Select Enabled to use the SOL port for Console Redirection. The options are Dis-

abled and Enabled.

*If the item above set to Enabled, the following items will become available

for user's conguration:

SOL Console Redirection Settings

Use this feature to specify how the host computer will exchange data with the client

computer, which is the remote computer used by the user.

4-22

Chapter 4: AMI BIOS

Terminal Type

Use this feature to select the target terminal emulation type for Console Redirec-

tion. Select VT100 to use the ASCII Character set. Select VT100+ to add color and

function key support. Select ANSI to use the Extended ASCII Character Set. Select

VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.

The options are ANSI, VT100, VT100+, and VT-UTF8.

Bits Per second

Use this feature to set the transmission speed for a serial port used in Console

Redirection. Make sure that the same speed is used in the host computer and the

client computer. A lower transmission speed may be required for long and busy

lines. The options are 9600, 19200, 38400, 57600 and 115200 (bits per second).

Data Bits

Use this feature to set the data transmission size for Console Redirection. The

options are 7 (Bits) and 8 (Bits).

Parity

A parity bit can be sent along with regular data bits to detect data transmission

errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits

is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits

is odd. Select None if you do not want to send a parity bit with your data bits in

transmission. Select Mark to add a mark as a parity bit to be sent along with the

data bits. Select Space to add a Space as a parity bit to be sent with your data

bits. The options are None, Even, Odd, Mark and Space.

Stop Bits

A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard

serial data communication. Select 2 Stop Bits if slower devices are used. The op-

tions are 1 and 2.

Flow Control

Use this feature to set the ow control for Console Redirection to prevent data loss

caused by buffer overow. Send a "Stop" signal to stop sending data when the re-

ceiving buffer is full. Send a "Start" signal to start sending data when the receiving

buffer is empty. The options are None and Hardware RTS/CTS.

VT-UTF8 Combo Key Support

Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100 ter-

minals. The options are Disabled and Enabled.

4-23

X10SDV Flex ATX Series Motherboard User’s Manual

Recorder Mode

Select Enabled to capture the data displayed on a terminal and send it as text mes-

sages to a remote server. The options are Disabled and Enabled.

Resolution 100x31

Select Enabled for extended-terminal resolution support. The options are Disabled

and Enabled.

Legacy OS Redirection Resolution

Use this feature to select the number of rows and columns used in Console Redi-

rection for legacy OS support. The options are 80x24 and 80x25.

Putty KeyPad

This feature selects Function Keys and KeyPad settings for Putty, which is a terminal

emulator designed for the Windows OS. The options are VT100, LINUX, XTERMR6,

SCO, ESCN, and VT400.

Redirection After BIOS POST

Use this feature to enable or disable legacy Console Redirection after BIOS POST.

When set to Bootloader, legacy Console Redirection is disabled before booting the

OS. When set to Always Enable, legacy Console Redirection remains enabled when

booting the OS. The options are Always Enable and Bootloader.

Serial Port for Out-of-Band Management/Windows Emergency Management

Services (EMS)

The submenu allows the user to congure Console Redirection settings to support

Out-of-Band Serial Port management.

EMS (Emergency Management Services) Console Redirection

Select Enabled to use a COM port selected by the user for EMS Console Redirec-

tion. The options are Enabled and Disabled.

*If the item above set to Enabled, the following items will become available

for user's conguration:

EMS Console Redirection Settings

This feature allows the user to specify how the host computer will exchange data

with the client computer, which is the remote computer used by the user.

Out-of-Band Mgmt Port

The feature selects a serial port in a client server to be used by the Microsoft

Windows Emergency Management Services (EMS) to communicate with a remote

host server. The options are COM1 and SOL.

4-24

Chapter 4: AMI BIOS

Terminal Type

Use this feature to select the target terminal emulation type for Console Redirec-

tion. Select VT100 to use the ASCII character set. Select VT100+ to add color and

function key support. Select ANSI to use the extended ASCII character set. Select

VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.

The options are ANSI, VT100, VT100+, and VT-UTF8.

Bits Per Second

This item sets the transmission speed for a serial port used in Console Redirec-

tion. Make sure that the same speed is used in the host computer and the client

computer. A lower transmission speed may be required for long and busy lines. The

options are 9600, 19200, 57600, and 115200 (bits per second).

Flow Control

Use this item to set the ow control for Console Redirection to prevent data loss

caused by buffer overow. Send a "Stop" signal to stop sending data when the re-

ceiving buffer is full. Send a "Start" signal to start sending data when the receiving

buffer is empty. The options are None, Hardware RTS/CTS, and Software Xon/Xoff.

Data Bits

Use this feature to set the data transmission size for Console Redirection. The

options are 7 (Bits) and 8 (Bits).

Parity

A parity bit can be sent along with regular data bits to detect data transmission

errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits

is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits

is odd. Select None if you do not want to send a parity bit with your data bits in

transmission. Select Mark to add a mark as a parity bit to be sent along with the

data bits. Select Space to add a Space as a parity bit to be sent with your data

bits. The options are None, Even, Odd, Mark and Space.

Stop Bits

A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard

serial data communication. Select 2 Stop Bits if slower devices are used. The op-

tions are 1 and 2.

ACPI Settings

WHEA Support

This feature Enables the Windows Hardware Error Architecture (WHEA) support for

the Windows 2008 (or a later version) operating system. The options are Disabled

and Enabled.

4-25

X10SDV Flex ATX Series Motherboard User’s Manual

High Precision Event Timer

Select Enabled to activate the High Performance Event Timer (HPET) that produces

periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in

synchronizing multimedia streams, providing smooth playback and reducing the de-

pendency on other timestamp calculation devices, such as an x86 RDTSC Instruc-

tion embedded in the CPU. The High Performance Event Timer is used to replace

the 8254 Programmable Interval Timer. The options are Disabled and Enabled.

PCI AER Support

Select Enabled to enable the ACPI OS to manage PCI Advanced Error Reporting.

The options are Disabled and Enabled.

Trusted Computing

Conguration

Security Device Support

If this feature and the TPM jumper on the motherboard are both set to Enabled,

onbaord security devices will be enabled for TPM (Trusted Platform Module) sup-

port to enhance data integrity and network security. Please reboot the system for

a change on this setting to take effect. The options are Disabled and Enabled.

TPM State

This feature changes the TPM State. The options are Disabled and Enabled.

Note: The system will restart to change the TPM State.

Pending operation

Use this item to schedule a TPM-related operation to be performed by a security

device for system data integrity. Your system will reboot to carry out a pending TPM

operation. The options are None and TPM Clear.

Device Select

Use this feature to select the TPM version. TPM 1.2 will restrict support to TPM 1.2

devices. TPM 2.0 will restrict support for TPM 2.0 devices. Select Auto to enable

support for both versions. The default setting is Auto.

The following are informational status messages that indicate the current TPM State:

TPM Enabled Status

TPM Active Status

TPM Owner Status

4-26

Chapter 4: AMI BIOS

TXT Support

Intel TXT (Trusted Execution Technology) helps protect against software-based at-

tacks and ensures protection, condentiality and integrity of data stored or created

on the system. Use this feature to enable or disable TXT Support. The options are

Disabled and Enabled.

4-27

X10SDV Flex ATX Series Motherboard User’s Manual

4-4 Event Logs

Use this feature to congure Event Log settings.

Change SMBIOS Event Log Settings

Enabling/Disabling Options

SMBIOS Event Log

Change this item to enable or disable all features of the SMBIOS Event Logging

during system boot. The options are Enabled and Disabled.

Runtime Error Logging Support

Select Enabled to support Runtime Error Logging. The options are Enable and Dis-

able. If this item is set to Enable, the following item will be available for conguration:

Memory Corrected Error Enabling (Available when the item above ­Runtime Error Logging Support is set to Enable)

Select Enable for the BIOS to correct a memory error if it is correctable. The options

are Disable and Enable.

Memory Corr. Error Threshold

Use this item to enter the threshold value for correctable memory errors. The default

setting is 10.

4-28
