E361 D imens ions( Figur e 2)
The E309D PRO Mini ature Gooseneck Microphone deli vers the professional
features needed to ac hieve optimum speech pickup in board meetings,
conferences, presen tations, houses-of-wo rship and more. The E309D PRO
features a highly se nsitive condenser capsul e and is available in a cardioid,
super-cardioid or omni-di rectional pickup pattern for m aximum flexibility and
control. The three mode l numbers for E309D PRO with di fferent capsule are
as bellow:
E309DU PRO with in corporated cardioid capsule
E309DH PRO with in corporated supercardioid caps ule
E309DO PRO with in corporated omni-directio nal capsule
The E361 is a conden ser gooseneck microphone with a co ntinuously-variable
pickup pattern a chieved by its dual capsule desi gn. The variable pattern
control is selecte d by the button on its base, making th e E361 flexible for a
variety of appli cations.
Both the E309D PRO and E 361 feature a brand-new design i n a high-quality
gooseneck. The y are immune to radio-frequency (RF) i nterference from cell
phones, PDAs, wi reless internet devices, two-w ay radios, etc. An On/Off
switch doubles a s a power LED, providing status indi cation. The integrated
desk stand featu res a programmable membrane switch . The base features
both a 3-pin XLR male output connection and a 4-pi n connector to allow a
hard-wired cable to be le d out from either the bottom or the rear of the base.
Ov er vie w
Hig h quali ty cond enser ca psule
Dur able, h igh qua lity go osenec k struc ture
Int egrat ed progr ammab le stan d
Sel ectab le caps ules fro m cardio id, sup er-card ioid an d omnidire ction al for E3 09D PRO o nly
E36 1 featu res dual c apsul e desig n and con tinuo usly va riabl e patte rn
RF im munit y
E309 D PRO Dim ensio ns(Fi gure 1)
143.0mm
[5.630in]
Ø11.5mm
[0.453in]
Ø6.0mm
[0.236in]
Ø7.3mm
[0.287in]
Ø8.0mm
[0.315in]
44.6.0mm
[1.756in]
445.21 mm
[17.528in]
123.0mm
[4.843in]
143.0mm
[5.630in]
Ø16 .0mm
[0.630in]
465.17mm
[18.314in]
Ø6.0mm
[0.236in]
Ø7.3 mm
[0.287in]
Ø8.0mm
[0.315in]
44.6mm
[1.756in]
123.0mm
[4.843in]
Fe at ur es
Pola r Patte rn
E30 9D PRO : Se lect from 3 caps ules: car dioid , su perca rdioid
and omn i-di recti onal. The thr ee m odel num bers are as bello w:
E30 9DU PR O wi th i ncorp orate d c ardioi d ca psule
E30 9DH PR O wi th i ncorp orate d s uperca rdioi d caps ule
E30 9DO PR O wi th i ncorp orate d o mni-d irecti onal capsu le
E36 1: Dua l cap sule d esign wit h c ontin uousl y va riabl e po lar patte rn
Trans ducer
Bac k Elec tret
Freq uency Respo nse:
E30 9D PRO : 20-2 0,000 Hz
E36 1: 80- 18,00 0 Hz
Dyn amic R ange (stan dard)
E30 9D PRO : 105 dB
E36 1: 107 dB
Sig nal-t o-Noi se Rat io
E30 9D PRO : 75 d B
E36 1: 81 d B
Equ ivale nt Noi se Lev el
E30 9D PRO : 19 d B
E36 1: 15 d B
Max . SPL
E30 9D PRO : 124 dB SPL
E36 1: 120 dB SP L
Sen sitiv ity
E30 9D PRO : - 38±2 dBV/Pa
E36 1: - 31±2 dB V/ Pa
Fin ish
Mat te-bl ack
Powe r Requ iremen t
E30 9D PRO : P48, 5.5m A
E36 1: P48 , 8.6 mA
Out put Im pedan ce
200 ohms
Con necto r
3-p in XLR male jack
Dim ensio ns
E30 9D PRO : see figur e 1
E36 1: s ee f igure 2
Net Weigh t
E30 9D PRO : 938 g (33. 1 oz)
E36 1: 943 g (33 .3 oz)
User Guide
J U S T P L A Y I T
－1
Sp ec if ic at io ns
E36 1
E30 9D PRO
G O A N G - F A N N C O . , L T D .
© 2010, SUPERLUX I
LB100 E36101E N
nc.
E309D PRO
High Quality Condenser Gooseneck Microphone
E361
Continuously Variable Pattern Gooseneck Microphone
Polar Pa ttern ( Figure 3 )
Freq uency Re spons e (Figu re 4)
Polar Pa ttern ( Figure 5 )
Freq uency Re spons e (Figu re 6)
－2
E3 09D P RO
E3 61
E3 09D P RO
E361
－4 －5 －6
Maintainence
Condenser micropho ne shall be kept in low humidity e nvironment for best sound
performance. Sto re the condenser microphones in ai rconditioned room or dehumidif ier
to keep away form mois ture. Clean air is another impor tant factor. Keep away from
smoking environmen t to avoid tar residuals.
Con ferenc e room
Boa rd meeti ngs
Pres entat ions
Hou ses-o f-wors hip
Applications:
Access ori es
Inc luded I tems
S55 F winds creen fo r E309D P RO only
S56 w indsc reen for E 361 onl y
S55 F winds creen S56 w indsc reen
Opt ional Re lated I tems
10m mic cable (open en d and XLR-M): P/N IA100CMB10100
5m mic cable (XLR-XLR): mode l#SFM5.0FM
10m mic cable (XLR-XLR): mode l#SFM10FM
E309D PRO Cardioid cap sule: P/N BM1000B9801AS
E309D PRO Supercardioi d capsule: P/N BM1000B9801AH
E309D PRO Omni-direc tional capsule: P/N BM1000 B9801AO
Operational Settings
Prog ramma ble Mem brane S witch
Both E309D PRO and E36 1 integrate a low-profile microphon e base and require a
phantom power supp ly. Their base provides a soft touch b utton that can be configured
for "push-to-tal k", "push-to-mute" or “togg le on-and-off” operation th rough the dip
switch on the bottom .
E361 bottomE309D PRO bottom
E309D PRO
GOOSENECK
MICROPHONE
BASE
PUSH ON/OFF
POWER UP OFF
PUSH TO TALK
POWER UP ON
PUSH TO MUTE
1. Push-to-talk: The mi crophone is normally muted. Pushi ng and holding the soft
touch button will tu rn the microphone on. As soon as the o perator stops holding the soft
touch button, the mi crophone will return to mute.
2. Push-to-mute: The mi crophone is normally on. Pushing and h olding the soft touch
button will mute the m icrophone. As soon as the operato r stops holding the soft touch
button, the micropho ne will again turn on.
3. Toggle / Power Up ON: As soon as phantom p ower is applied to the base, the
microphone is on. Mome ntarily pressing the soft touc h button will mute the
microphone. Moment arily pressing the soft touch bu tton again will turn the microph one
on. This operation w ill repeat indefinitely.
4. Toggle / Power Up OFF (Muted): As soon a s phantom power is applied to th e base,
the microphone is mute d. Momentarily pressing the so ft touch button will turn the
microphone on. Momen tarily pressing the soft touch b utton again will mute the
microphone. This ope ration will repeat indefinit ely.
For the E361 goosene ck microphone, there is a continuo usly variable pattern cont rol
located on the botto m which can change the microphon e pickup pattern from omnidirectional to figure- 8.
E309D PRO
E309D PRO
GOOSENECK
MICROPHONE
BASE
PUSH ON/OFF
POWER UP OFF
PUSH TO TALK
POWER UP ON
PUSH TO MUTE
E361
Users may use an audio c able terminated with a profess ional 3-pin XLR type connect or
to send a balanced aud io signal to a microphone preamp, or a t hree-conductor cable
with one open end and th e other terminated with a profes sional 3-pin male XLR type
connector. If an audio ca ble terminating in XLR conne ctors on both ends is used, it can
simply be plugged in t o the built-in XLR jack at the bac k of the base. If a hard-wired
installation is pref erred, a three-conductor cable w ith an open end can be directly
attached to the base f ollowing the instructions below; this cable can be led out from the
bottom, or from the back if preferred.
1. Determine whethe r the cable is to be led out from the bott om or the rear of the
base.
2. If from the bottom, then f irst of all, open the rectangula r plastic panel on the
bottom. The 4-pin co nnector will be visible. Inse rt the open end of the cable int o the
hole located at the ce nter of the bottom and feed the ca ble end into the 4-pin connector
recess. Connect the wi res according to the pin assignmen t below.
3. If the wire is to be led out throu gh the rear of the base, then first of a ll, open the
rectangular plasti c panel on the bottom to expose th e 4-pin connectors. Remove the
small rubber cover from the hole at the back of the base and fe ed the open end of the
cable through this hol e until it reaches the 4-pin conne ctor recess. Connect the wires
according to the pin ass ignment below.
4. Replace the plastic pan el over the 4-pin connectors .
The pin assignment i s as follows:
1.) XLR pin 1 shield cab le to position marked no. 1 on pcb
2.) XLR pin 2 red cable to pos ition no. 2 on pcb
3.) XLR pin 3 white cabl e to position no. 3 on pcb
4.) The no. 4 is disconn ected.
Connection:
Knowing your microphone
Superlux provides a grea t variety of microphones for bot h professionals and amateurs .
Knowing the perfor mance characteristics of y our microphone is the first step i n achieving
a successful result.
Powering the microphone
Condenser micropho nes work with power. The profession al standard is 48VDC phantom
power. Both the E309D and E 361 require 48V phantom power; make sure your audio
system offers a full 48 V phantom power to operate both the E 309D and E361.
Uni-directional co ndenser microphones feature ve ry high sensitivity at -40dB V/Pa for
highly intelligi ble speech application. Th eir reduced off-axis sensitivi ty helps to lower
background noise whil e their maximized on-axis se nsitivity provides the high est gain
before feedback
in a live sound system .
It is recommended that t he user should keep a distance o f 15 cm to 40 cm from the
microphone and maint ain an average speech level. S peaking too close to the
microphone will result i n excessive bass due to the proxim ity effect which will interf ere
with intelligibi lity. A quality conference microph one incorporates a built-i n limiter to help
prevent distorti on due to an overly-excited us er or one who speaks too close to the
microphone.
There are several choice s of gooseneck to suit various d emands. For aesthetics, si ngle or
double bend goosen ecks are a better choice over a full y-bendable design. Having a low
bending noise is ano ther important feature of a good g ooseneck microphone. It is
recommended that the u ser not bend the gooseneck too h ard or too quickly as this may
generate excessi ve noise, thus disturbing th e audience. In most cases, eac h attendee has
his own microphone or a mic rophone is shared by every 2 attende es. Although having
numbers of microphon es in operation in one space at th e same time is not
recommended due to the p otential for a feedback proble m, a good system operator can
minimize this risk b y keeping as few microphones tur ned on at the same time as
possible. An auto- mixer is a good choice for multi ple microphone installatio ns since it
limits the number of t urned-on microphones at one ti me. An advanced auto mixer
features a dynamic thres hold and auto gain reduction whi ch varies according to the
number of turned-o n microphones to keep the same sys tem gain. Wind screens are vital
for windy environmen ts such as outdoor venues or proxi mity to air-conditioning systems.
Keep the capsule and wind s creen clean for good audio perfo rmance.
Using a condenser gooseneck microphone
Type of transducer
Conden ser
Extremely light-we ight diaphragm, very sensi tive to sound. Very small version s are
available for low-vis ibility applications. Hi gh performance condenser m icrophones are
regarded as standard equip ment in recording studios for thei r ability to capture extreme
detail. Operatio n requires a power source such as phanto m power or battery.
White wire
Red wire
Shield
Microphone cable
can be led out from
bottom or back
White wire
Red wire
Shield
Microphone cable
can be led out from
bottom or back
