Sunfire HRS-SAT4BIP User Manual
User's Manual
High Resolution Series
Surround Loudspeaker
HRS-SAT4BIP
User's Manual
Important Safety Instructions
Safety
1. Read Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all Instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including ampliers) that
produce heat.
WARNING: THIS LOUDSPEAKER IS CAPABLE OF PRODUCING VERY HIGH SOUND PRESSURE LEVELS. YOU
MUST TAKE EVERY PRECAUTION TO PROTECT YOUR
HEARING FROM PERMANENT DAMAGE.
Contents
Safety Instructions ............. 2
Introduction .......................3
Features ............................5
Location ............................
Using a subwoofer ............7
Installation .........................8
Specications ..................10
Troubleshooting .............. 11
Service Assistance .......... 11
8. Refer all servicing to qualied service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as a connector is damaged, liquid
has been spilled or objects have fallen into
the apparatus, the apparatus has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
9. Object and Liquid Entry — Care should
be taken so that objects do not fall into
and liquids are not spilled into the inside of
the apparatus.
6
For more information on this and other Sunre
products, please visit our website:
www.sunre.com
2
User's Manual
Introduction Features Location Installation
Introduction
Thank you for purchasing these
Sunre High Resolution Series surround
loudspeakers. We hope you enjoy them
and the music they make as much as we
have enjoyed creating them for you.
These loudspeakers follow a great
heritage of both world-class loudspeaker
designs and industry-leading subwoofer
technologies.
The HRS-SAT4BIP surround loudspeakers are designed as a perfect
match to our HRS subwoofers, center
and satellite loudspeakers, resulting in an
amazing home theater experience... the
kind of heart-felt experience that could
only come from Sunre.
Unpacking
Your Sunre High Resolution Series
loudspeakers should reach you in perfect
condition. If you do notice any shipping
damage, please contact Sunre immediately.
Gently lift out the loudspeakers and
all the packing material. It is important
to save all the packing materials and
the box in case your loudspeakers ever
needs to be moved or shipped for repair.
Make sure that you keep your sales
receipt. It is the only way to establish
the duration of your Limited Warranty
and it may come in useful for insurance
purposes.
Features
• Perfectly matched to the HRS
subwoofers, and the HRS-SAT4 and
HRS-SAT4C loudspeakers to form a
complete system
• HRS-SAT4BIP can be wall-mounted, or
placed on a cabinet or shelf. They can
be used for surround, and surroundback applications
• Two-way, high pressure design with
fully-sealed enclosure, offers wide,
diffuse rear/side channels for an
enhanced home theater experience
• 4.5" High Back-emf driver
• Dual 1" ring radiating tweeters
• 110 dB maximum output
• 200 watts maximum power
• Magnetic grilles
• Gold-plated spring terminals
• High gloss multi-layer cabinet nish
Care
If a loudspeaker needs servicing,
please read the Troubleshooting section
on page 11. If a problem persists, please
contact your nearest authorized Sunre
Dealer.
Please take a moment to ll out and
mail the Sunre Customer Response
card. Also read the serial number located
on the rear label and record it here:
Misc.
Serial Number:
Purchased from:
Date:
3
User's Manual
Overview
The HRS-SAT4BIP surround loudspeakers are specically designed to provide high output and high performance
for your home theater. Years of research
and decades of experience have gone
into these amazing loudspeakers.
Sunre created the category of small-
box, high-power subwoofers more than
a decade ago with the original True
Subwoofer. This design relies on highpressure, “High Back-emf” technology
that provides very high bass output from
a very small box. When migrating this
subwoofer technology to the woofer of
these HRS surround loudspeakers, you
get the same advantages: high output,
small size, high efciency, and years of
trouble-free operation.
Woofers
The “Trilar” voice coil (actually 3
dual voice coils wound in parallel) has
a much higher output than conventional
multi-layer voice coil designs, and is
also signicantly lighter. This, combined
with the lightweight and incredibly-strong
Kevlar® cone, means that the driver
responds very quickly. As a result, drum
kicks, and other percussive effects will
sound tighter and more lifelike. Having a
lightweight woofer means that it has improved top-end response. This makes for
smoother integration with the tweeter in
the critical upper midrange, lower treble
range – where much of the vocal information lives. As a result, vocals and dialog
sound very natural – not mufed or tinny.
The woofer's 1" excursion is up to four
times that of conventional woofers, and
provides the highest power handling in
its class.
The cast aluminum basket offers more
rigidity than the typical stamped variety.
When driven at high volume, they will not
ex, and the result is tight bass at high
volume, with very low distortion.
Tweeter
The tweeters used in the surround
loudspeakers represent a unique approach to tweeter design that results in
unrivaled performance. It shares design
elements with tweeters found in very
expensive European loudspeakers, with
a frequency response that is at to above
20 kHz for crystal-clear detail from any
source.
The 1" ring radiating silk dome offers
instantaneous response and wide dispersion. The tweeter's vented back chamber
contributes to high power handling,
improves frequency response with lower
distortion, and provides superior transition from high frequencies to the critical
midrange.
Cabinet and bafe
The woofer and tweeters are mounted
to a cast aluminum front bafe that is
clamped to the cabinet from the rear,
forming a fully-sealed enclosure. This
clamping design produces a stiff cabinet
that is very resistant to vibration, result-
ing in tight bass response, high delity
reproduction, and high output for music
and movies.
Nine layers of paint and clear coats
provide an elegant scratch-resistant nish
that matches the HRS subwoofers and
loudspeakers.
4
