Sunbeam PB7910 User Manual

Please read these instructions carefully
and retain for future reference.

MultiBlender Electronic

650 watt electronic blender with
7 programmed functions

Instruction Booklet

PB7910

Sunbeam’s Safety Precautions 1

Features of your MultiBlender Electronic 2

Before using your MultiBlender Electronic 4

Using your MultiBlender Electronic 5

A Guide to your MultiBlender Electronic 6
Handy Blending Hints 7
Care and Cleaning 8
Recipes
Soups 9
Dips/Starters/Pastes 11
Light Snacks 14
Desserts 15
Drinks 17
Thick Shakes 19
Cocktails 20

Contents

1

Sunbeam are very safety conscious when

designing and manufacturing consumer products,
but it is essential that the product user also
exercise care when using an electrical appliance.
Listed below are precautions which are essential
for the safe use of an electrical appliance:

• Read carefully and save all the instructions
provided with an appliance.

• Always turn the power off at the power outlet
before you insert or remove a plug. Remove
by grasping the plug - do not pull on the cord.

• Turn the power off and remove the plug
when the appliance is not in use and
before cleaning.

• Do not use your appliance with an extension
cord unless this cord has been checked
and tested by a qualified technician or
service person.

• Always use your appliance from a power
outlet of the voltage (A.C. only) marked
on the appliance.

• Close supervision is necessary when your
appliance is being used near children or
infirm persons.

• Never leave an appliance unattended while
in use.

• Young children should be supervised to ensure
that they do not play with the appliance.

• Do not use an appliance for any purpose
other than its intended use.

• Do not place an appliance on or near a hot gas
flame, electric element or on a heated oven.
Do not place on top of any other appliance.

• Do not let the power cord of an appliance hang
over the edge of a table or bench top or touch
any hot surface.

• For safety reasons and to avoid maintenance
by unskilled persons, some appliances are
‘sealed’ using tamperproof screws. Such
appliances should always be returned to the
nearest Sunbeam Appointed Service Centre
for adjustment or repair if required.

• Do not operate any electrical appliance with a
damaged cord or after the appliance has been
dropped or damaged in any manner. If damage
is suspected, return the appliance to the
nearest Sunbeam Appointed Service Centre
for examination, repair or adjustment.

• For additional protection, Sunbeam
recommend the use of a residual current
device (RCD) with a tripping current not
exceeding 30mA in the electrical circuit
supplying power to your appliances.

• Do not immerse the appliance in water
or any other liquid unless recommended.

If you have any concerns regarding the performance and use of your appliance,

please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.

Ensure the above safety precautions are understood.

Sunbeam’s Safety Precautions

SAFETY PRECAUTIONS FOR YOUR

SUNBEAM MULTIBLENDER ELECTRONIC
BENCHTOP BLENDER.

• Ensure fingers are kept well away from the
blades when in use.

• Always operate on a flat surface.

• Do not operate for more than 2 minutes
at a time.

• Do not blend hot ingredients.

Ingredient cup.

Handy 70ml ingredient cup.

Flexible lid with pouring hole.

To provide the necessary safety, the lid seals
tightly to the glass jug and features a pouring
hole, that allows you to add ingredients during
the blending process.

1.5 litre heat-resistant glass jug.

The sizeable 1.5 litre glass jug features specially
designed internal ribs to cycle ingredients back
into the blade system for superior results.

The jug features an easy to pour lip and is
marked in both cups and millilitres (ml) for ease
of use. The heat-resistant glass jug is ideal for
pureeing warm soups.

Detachable blade system assembly.

The detachable blade assembly unit unscrews
from the glass blending jug for convenient and
thorough cleaning.

Motor base.

The base houses a heavy-duty 650 watt motor,
which provides unbeatable industrial strength
performance.

Non-slip feet.

Keeps the blender secure on the bench top
during use.

2

Features of your MultiBlender
Electronic

Serrated stainless steel six-blade system.

Specially designed for extra durability, the
heavy-duty, serrated stainless steel blade with
a six-blade construction, smashes ice cubes
to powder, produces a smooth consistency
when pureeing and combines ingredients
perfectly for a frappé.

Recipe programs.

Three blending favourites, just add
ingredients and each of these programs have
been developed to ensure perfect consistent
results everytime.

Functional programs.

To assist with some of the more functional
blender uses, these four programs have been
tested and refined, to remove the guess work
and improve on the final blending result.

Manual operation.

Low and High speed control plus Pulse.

Cord storage facility.

For tidy, convenient storage of the cord
underneath the motor base.

3

4

Important: Always ensure your blender is
unplugged from the power outlet before
fitting or removing the blade assembly.
Always handle the blade assembly with
caution, as the blades are extremely sharp.

To assemble the six-blade system in the glass
jug (see Figure 1).

1. Place the silicone rubber seal over the six­blade assembly, as shown in figure 1.

2. Place the six-blade assembly into the
glass jug and turn clockwise to secure
firmly into position (see Figure 2).

Note: The blender jug will leak if the six-

blade system is not assembled correctly.

Note: Do not attempt to remove the

stainless steel blades from the blade
assembly.

3. Plug the power cord into a 230-240 volt
power outlet and turn the power ‘ON’.

Before using your MultiBlender
Electronic

Figure 1

Figure 2

Six-blade
assembly

Silicone
seal

5

1. Place the blender jug onto the motor base.

Note: Do not switch ‘ON’ the MultiBlender

Electronic without the lid in position.

2. Place ingredients into the glass jug. Do
not exceed the maximum indicated level
– 1.5 litres.

3. Position the lid with ingredient cup onto
the blender jug. Ensure the lid is firmly in
place.

4. Using the control panel, select the desired
function, either from the pre-programmed
functions or the manual buttons High, Low
and PULSE settings.

The Blending Guide on page 6 shows

various functions that can be performed
and the suggested speeds to use.

Note: Although the lid fits firmly to the

glass jug, we advise when blending liquid
ingredients, to place your hand on the lid
as you initially select the blending speed/
function. As the powerfull 650 watt motor
could cause the liquid to surge up causing
leakage. Once you have started blending
you can remove your hand.

Further ingredients can also be added

whilst blending by removing the ingredient
cup and pouring ingredients through the
hole in the lid.

Note: The pre-programmed functions can

be stopped by simply pressing the ‘OFF’
button.

5. If using the manual buttons, Low or High,
once you have completed blending, press
the ‘OFF’ button on the control panel.

Note: When removing the six-blade

assembly from the glass jug you may need
to slightly tilt the blade so that it slides
out easily. You shouldn’t force the blades
out of the glass jug as this will ultimately
damage the blades.

Using your MultiBlender Electronic

6

Processing Task Food Suggested Setting Programme Suggested Processing Procedure

Aerating Milkshakes, HIGH Milkshake Use chilled milk. Blend until
Smoothies desired consistency is achieved.

Chopping Nuts, Chocolate, PULSE Process ½ cup at a time, to
Garlic or Herbs ensure evenly sized pieces.

Crumbing Bread Crumbs PULSE Tear bread roughly. Process
until desired consistency.

Biscuit Crumbs PULSE Break into pieces and
process until crumbed.

Crushing Ice PULSE Crush Ice Add ¼ cup of water. Use the
PULSE button 3-4 times in
succession for crushed ice.

Emulsifying Salad Dressing LOW Crush Ice & Blend until well combined.
Cocktails Oil may be added to the
mixture during processing
through the pouring hole
in the lid.

Mixing Batters, Cakes LOW & HIGH MIX Process ingredients until
just combined.
DO NOT OVERPROCESS.

Pureeing Soups, HIGH PUREE Blend until smooth.
Vegetables,
Fruits

A Guide to your MultiBlender
Electronic

7

• Nothing can beat a blender for making
smooth purees and sauces or for whipping
up frothy drinks - from healthy breakfast
shakes to frozen daiquiris.

• Use your blender for chopping small
amounts of food like nuts, bread crumbs
and whole spices.

• Turn any oil-based salad dressing into a
creamy style dressing by blending it until
slightly thickened.

• A brief whirl in the blender will rescue a
lumpy gravy, or an egg-based sauce that
has separated.

• Food items for blending should be cut into
cubes (approximately 2-3cm), this will
assist in achieving an even result.

• Ensure the lid is firmly and securely
placed on the jug. Do not operate the
blender without the lid on, if you wish to
add any additional ingredients remove the
ingredient cup and add as necessary.

• Never fill above the maximum level
indicator – 1.5 litres.

• To ensure efficient mixing when blending
dry mixtures, it may be necessary to stop
the blender and push ingredients down the
sides of the jug with a spatula.

• When pureeing fruit or vegetables, cooked
or raw, cut into small pieces to facilitate
blending.

• When making bread crumbs, use 2 to
3 day old bread, leaving crusts on, to
minimise the possibility of clumping. If
only fresh bread is available, dry it out for
a few minutes in a low heated oven.

• When blending a variety of ingredients
together, blend the liquids first, then add
dry ingredients.

• Always ensure stones are removed from
fruit and bones from meat as these can
harm the blades.

• Don’t allow a used blender to sit for too
long as the food will dry onto the blades,
making it very difficult to clean. If you
can’t clean the blender straight away, pour
some warm water in it and allow to soak.

• Do not process hot liquids in your blender.
Allow to cool before processing.

• Always ventilate the blender jug when
pureéing warm ingredients. This is
achieved by lifting the ingredient cup out
of the lid after starting the blender.

Handy Blending Hints
