Sunbeam LC6200 User Manual

MultiProcessor Range

Instruction Booklet

LC6200 Sunbeam MultiProcessor – dedicated food processor LC6900 Sunbeam MultiProcessor Plus – 3 in 1 food processing centre (Pictured below)

Please read these instructions carefully and retain for future reference.

Contents

Sunbeam’s Safety Precautions 2

Features of Your Sunbeam MultiProcessor 4

Features of Your Sunbeam MultiProcessor Plus 6

Attachments for your Sunbeam MultiProcessor 8

Using your Sunbeam MultiProcessor 10

Fitting/using the tools on your MultiProcessor 12

Storing your Sunbeam MultiProcessor 16

Handy hints for In Bowl Processing 18

A guide to your food processor 20

Handy blending tips 22

A guide to your blender 23

Care and cleaning 24

Recipes 25

Drink recipes (LC6900 only) 38

Sunbeam’s Safety Precautions

Sunbeam are very safety conscious when

designing and manufacturing consumer products, but it is essential that the product user also exercise care when using an electrical appliance. Listed below are precautions which are essential for the safe use of an electrical appliance:

• Read carefully and save all the instructions provided with an appliance.

• Always turn the power off at the power outlet before you insert or remove a plug. Remove by grasping the plug - do not pull on the cord.

• Turn the power off and remove the plug when the appliance is not in use and before cleaning.

• Do not use your appliance with an extension cord unless this cord has been checked and tested by a qualified technician or service person.

• Always use your appliance from a power outlet of the voltage (A.C. only) marked on the appliance.

• Close supervision is necessary when your appliance is being used near children or infirm persons.

• Never leave an appliance unattended while in use.

• Young children should be supervised to ensure that they do not play with the appliance.

• Do not use an appliance for any purpose other than its intended use.

• Do not place an appliance on or near a hot gas flame, electric element or on a heated oven. Do not place on top of any other appliance.

• Do not let the power cord of an appliance hang over the edge of a table or bench top or touch any hot surface.

• For safety reasons and to avoid maintenance by unskilled persons, some appliances are ‘sealed’ using tamperproof screws. Such appliances should always be returned to the nearest Sunbeam Appointed Service Centre for adjustment or repair if required.

• Do not operate any electrical appliance with a damaged cord or after the appliance has been dropped or damaged in any manner. If damage is suspected, return the appliance to the nearest Sunbeam Appointed Service Centre for examination, repair or adjustment.

• For additional protection, Sunbeam recommend the use of a residual current device (RCD) with a tripping current not exceeding 30mA in the electrical circuit supplying power to your appliances.

• Do not immerse the appliance in water or any other liquid unless recommended.

If you have any concerns regarding the performance and use of your appliance,

please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.

Ensure the above safety precautions are understood.

Sunbeam’s Safety Precautions

SAFETY PRECAUTIONS FOR YOUR

SUNBEAM FOOD PROCESSOR.

• Always use extreme care when handling processing blades and cutting discs. These are extremely sharp and may cause injury if handled incorrectly. Always store processing blades and cutting discs in their respective covers or processing containers.

• Unplug from power outlet when not in use, before putting on or taking off attachments, and before cleaning.

• Always fit the safety cover before using the food processor.

• Do not put hot liquids into the food processor bowl or blender. Warm liquids only.

• Avoid contacting moving parts at all times.

• Place the processor bowl onto the base of the processor before fitting any attachments.

• All blades and attachments should be removed with care before cleaning.

• Do not over fill the processor.

• Do not process for longer than the time periods recommended in the operating chart.

• Always remove the blade before emptying the processor bowl of its contents.

• When mixing a heavy load, ie. a ‘1.5kg Dough’ do not operate food processor for more than 1 minute at a time.

Important instructions – retain for future use.

If you have any concerns regarding the performance and use of your appliance,

please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.

Ensure the above safety precautions are understood.

Features of Your Sunbeam MultiProcessor

Processing cover

The processing cover activates the automatic safety system. The MultiProcessor will not operate unless the cover is correctly positioned on the processing bowl and locked into place.

800 Motor base

The base houses a powerful 800 watt motor, which provides great processing results every time.

Pulse button

Increases the intensity of the standard processing action to assist in the most demanding tasks.

Variable speed control

The large speed control dial with 5 clearly marked speeds makes it easy to select the desired setting.

Blade storage compartment

Non-slip feet

Keeps the food processor secure on the bench top during use.

Food pusher

Guides food evenly down the feed tube and can also be used to close the chute while processing to prevent food from escaping through the feed tube.

Feed tube

The feed tube is used to guide ingredients down into the selected blades and allows you to add ingredients during other processing tasks.

Spindle

Drives all the food processing attachments. The spindle must be in place to operate the food processor.

Processing bowl

Capacity is 1.75 litres for liquids and 1.5 kilograms for solids. The bowl locks into place on the motor base and is designed to encourage, even, efficient processing.

Cord storage facility

For tidy, convenient storage of the cord on the backside of the motor base.

LC6200 PICTURED

HeadingFeatures of Your Sunbeam MultiProcessor Plus

Blender cover with pouring hole

The blender lid securely seals the jug and features a pouring hole that allows you to add ingredients during blending.

1.5 litre shatter proof blender jug

The sizeable 1.5 litre jug features an easy grip handle and is marked in both cups and millilitres (ml) for ease of use.

The blender jug locks onto the motor base of the food processor and will not operate unless the jug is in the locked position.

Serrated stainless steel blades

These durable, serrated stainless steel blades are strong enough to crush ice cubes and are ideal for pureeing, blending and mixing. The blade assembly is detachable for easy and thorough cleaning.

Pulse button

Increases the intensity of the standard processing action to assist in the most demanding tasks.

Blade storage compartment

Variable speed control

The large speed control dial with 10 clearly marked speeds makes it easy to select the desired setting.

Non-slip feet

Keeps the food processor secure on the bench top during use.

Ingredient cup

Handy 70mL ingredient cup.

Food pusher

Guides food evenly down the feed tube and can also be used to close the chute while processing to prevent food from escaping through the feed tube.

Feed tube

The feed tube is used to guide ingredients down into the selected blades and allows you to add ingredients during other processing tasks.

Processing cover

The processing cover activates the automatic safety system. The MultiProcessor will not operate unless the cover is correctly positioned on the processing bowl and locked into place.

Spindle

Drives all the food processing attachments. The spindle must be in place to operate the food processor.

Processing bowl

Capacity is 1.75 litres for liquids and 1.5 kilograms for solids. The bowl locks into place on the motor base and is designed to encourage, even, efficient processing.

Cord storage facility

For tidy, convenient storage of the cord on the backside of the motor base.

LC6900 PICTURED

Attachments for your Sunbeam MultiProcessor

1. Processing blade

The stainless steel processing blade is contoured to fit the shape of the processing bowl to provide the most efficient chopping/ mixing action.

Please ensure that the processing blade protective cover is placed on the processing blade when not in use.

The processing blade can be used to chop raw meats to mince, chocolate to crumbs and nuts to paste.

2. Dough blade

The dough blade is contoured for fast, efficient processing. It is ideal for mixing doughs, heavy cake mixes and batters.

3. Blade holding disc

The blade holding disc, houses the various processing attachments – slicing, chipping, grating and shredding.

Holding clip

4. Slicing blades - Thick and Thin

The thick slicing blade is ideal for slicing a variety of fruits and vegetables.

The thin slicing blade is ideal for slicing of fruits, vegetables, raw meats, chicken and deli meats like salami.

5. Chipping blade

The chipping blade is ideal for making potato chips and vegetable strips.

Attachments for your Sunbeam MultiProcessor continued

Heading

6. Grating blade

The grating blade is ideal for grating hard cheeses, especially parmesan.

7. Shredding blades - Coarse and Fine

The coarse shredding blade is ideal for a variety of fruits and vegetables.

The fine shredding blade is ideal for chocolate, ginger and garlic and a variety of fruits and vegetables.

9. Safety Cover

This attachment is only available with the MultiProcessor Plus (LC6900).

When the blender is not in use, it is recommended that the blender is removed from the food processor body and the safety cover is locked in place. The MultiProcessor Plus will not operate unless the safety cover or blender jug is locked in place.

10. Citrus Juicer

This attachment is only available with the MultiProcessor Plus (LC6900).

The citrus juicer sits inside the processing bowl (without the spindle) to filter pips and pulp pieces during juicing.

8. Whisk attachment

The whisk attachment is ideal for whisking egg whites, creams, light batters and packet cake mixtures.

The citrus juicer attachment enables you to juice all types of citrus fruits from limes and lemons to oranges and grapefruit.

11. Spatula

The spatula is ideal for assisting with all food processing tasks.

Using your Sunbeam

Heading MultiProcessor

Before using your MultiProcessor

• Wash the processing bowl, cover and all attachments in warm water using a mild detergent. Dry each part thoroughly before use.

• Before you assemble the food processor, ensure that the power cord is unplugged.

Before using the processing bowl

• The following steps are only necessary for the MultiProcessor Plus (LC6900).

1. Place the motor base facing you on a dry, level surface.

2. Fit the safety cover onto the food processor body. Simply place the safety cover and twist anti-clockwise, see Figure 1.

LC6900 Pictured

Fig 1

Note:

The MultiProcessor Plus, processing bowl will not operate if the safety cover or blender jug are not in place.

Positioning the processing bowl and cover

The following steps are for both models LC6200 and LC6900.

1. Place the motor base facing you on a dry,

level surface.

2. Position the processing bowl over the drive shaft. The handle of the bowl needs to be facing you and the bowl should now be resting on the base of the food processor, see Figure 2.

LC6200 Pictured

Fig 2

To lock the bowl into position for use, turn the handle to the right, as far as it will go Figure 3.

LC6200 Pictured

Place the processor cover onto the processing bowl, by positioning the ‘align’ label on the cover with the top of the handle which is marked ‘rotate lid to lock’ Figure 4.

UNLOCKED

LC6200 Pictured

, see

Fig 3

, see

Fig 4

Using your Sunbeam MultiProcessor continued

Heading

5. To lock the processor cover into position, ready for use, turn the cover to the right. The holding lip should be flush with the top of the bowl handle, see Figure 5.

LOCKED

Fig 5

Important: If the processing bowl and cover are not correctly assembled, the MultiProcessor will not function.

Using your MultiProcessor

1. Plug the power cord into a 230-240V AC power outlet and turn the power ‘ON’.

2. Using the control dial, select the desired processing speed.

LC6200 Pictured

The Pulse function remains on as long as

the Pulse button is pressed down.

The variable speed settings will provide

continuous processing until the control dial is returned to the ‘0’ position.

Further ingredients can also be added

whilst processing by pouring through the feed tube once the food pusher has been removed.

3. After you have completed processing, turn the control dial to the ‘0’ position.

Note: For maximum control when using your food processor, before turning on your food processor load the feed tube. Always use the food pusher for more evenly processed foods and never use your fingers.

Important: When mixing a heavy load, ie. ‘1.5kg Dough’ do not operate food processor for more than 1 minute at a time.

Heading

Fitting/using the tools on your MultiProcessor

Note: All attachments must be firmly attached to the spindle. Always adjust the attachments until you are sure that they are correctly fitted.

Placing the spindle

1. Fit the spindle onto the drive shaft, see Figure 6.

LC6200 Pictured

Fig

Processing Blade

1. Fit the processor bowl and spindle as detailed previously in Figures 2, 3 & 6.

2. Remove the protective cover from the stainless steel processing blade, see Figure 7.

spindle

drive shaft

Warning: Use extreme caution, as blades are sharp. Always handle the chopping blade by it’s central plastic section.

4. Place food into the processing bowl.

5. Fit the processing cover to the processing bowl, see Figures 4 & 5 and place the food pusher in the feed tube.

6. Plug the power cord into a 230-240V AC power outlet and turn the power ‘ON’.

7. Select the required speed.

8. When processing is complete, remove the spindle and blade from the processing bowl before removing the processed food.

Note: After cleaning, always replace the protective cover on the stainless steel processing blade.

Dough Blade

1. Fit the processor bowl and spindle as detailed previously, in Figures 2, 3 & 6.

2. Fit the dough blade over the spindle and press firmly into place, see Figure 9.

dough blade

spindle

Fig

3. Fit the processing blade over the spindle and press firmly into place, see Figure 8.

chopping blade

Fig 8

spindle

LC6200 Pictured

LC6200

Fig 9

3. Place ingredients into the processing bowl.

4. Fit the processing cover to the processing bowl, see Figures 4 & 5 and place the food pusher in the feed tube.

5. Plug the power cord into a 230-240V AC power outlet and turn the power ‘ON’.

6. Select required speed.

7. When processing is complete, remove the spindle and blade from the processing bowl before removing the dough.

Pictured
